Used Faceplate for sale (622)

Condition: used, Year of construction: 2010, Faceplate LD 650 for TOS WHQ 13 For sale: a used faceplate LD 650, manufactured in 2010, suitable for TOS WHQ 13. Iedpfxez I Dvme Ap Djih Suitable for facing, turning, and machining large diameters. Slide stroke: 170 mm, maximum machining diameter: approx. 1,000 mm. The faceplate is intended for use on a TOS WHQ 13. Technical data: Type: LD 650 Diameter: 650 mm Slide stroke: 170 mm Machining diameter: 300 - 1,000 mm Speed: up to 150 rpm including turning tool holder Price: 9,100.00 Euro net (new price: 21,500.00 €)

Condition: used, faceplate diameter 800 mm daylight 130 mm short taper Gr.8 weight of the machine ca. 280 Kg dimensions of the machine ca. 1,2x 0,8x 0,4 m Diameter 800 mm Height 145 mm Total height 225 mm Short taper size 8 Ijdpez R D Hxefx Ap Dsih Bolt circle: 171.4 Bore 130 mm

Condition: used, faceplate diameter 630 mm daylight 140 mm Iodsz Rqpgspfx Ap Deih height 120 mm weight of the machine ca. 120 Kg dimensions of the machine ca. 800x600x600 mm - Faceplate with 630 mm diameter. - Short taper mount size 11 - Includes storage box

Condition: good (used), Year of construction: 2017, functionality: fully functional, Technical details faceplate diameter 2200 mm swing diameter 2500 mm turning height 1600 mm Control Siemens 840 D Additional information CNC Double-Column Vertical Turning Lathe In 2017, the machine was retrofitted by a specialized German company with a Siemens 840D CNC control system. It includes new drive and feed motors, as well as a new electrical cabinet. An inspection under power—with the machine running—is currently still possible. Equipment: Siemens 840D CNC control system Number of controlled axes: 4 linear axes and one C-axis for the faceplate Electronic handwheel Safety fencing Isdpfx Apoz S E N Ds Doih 2 rams Left ram equipped with driven tool stations for drilling and milling Right ram for turning operations Faceplate with 4 clamping jaws Chip conveyor

Condition: used, faceplate diameter 800 mm 130 Iiedjz N Hwdspfx Ap Dsh weight of the machine ca. 300 t dimensions of the machine ca. 1,2 x 0,8 x 0,3 m Faceplate, 800 mm diameter, with short-taper mount (size 11). Bolt circle 235 mm.

Condition: good (used), two very well-preserved faceplates Iiodpoz Nqdhofx Ap Deh

Condition: used, faceplate diameter 1800 mm hollow 300 mm Cone 463 mm 380 thickness of jaw 100 mm Thickness 200 mm total power requirement . kW weight of the machine ca. 590 kg dimensions of the machine ca. . m 340 rpm Bolt circle: 330 mm Fit: 285 mm Jaw width: 55 mm Thickness: 170 mm Opening: 145 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Isdpoz Icxmsfx Ap Deih We look forward to your visit. Your Markus Hirsch Team

Condition: used, functionality: fully functional, We are selling this machine. It is connected and can be tested. A video of the machine can be sent via the WhatsApp application. Documentation for the machine is available. Speeds: Iiodjydqfdspfx Ap Djh 1st range: 0.35-3.5 rpm 2nd range: 1.4-14 rpm Drive: 2 regulating motors, each with 120 kW, powered by a 240 kW Ward-Leonard converter. Diameter of the clamping plate: 8,000 mm Largest turning diameter: 12,500 mm Turning height: 2,200 mm The machine underwent a major overhaul and modernization in 1991. Maximum workpiece weight: 200,000 kg Machine weight: 550,000 kg Please submit your offer.

Condition: used, faceplate diameter 900 mm height 150 mm 4 Stück weight of the machine ca. 0,45 t dimensions of the machine ca. 0,9 x 0,9 x 0,45 m Faceplate Iodpfx Ajzxt Nasp Deih - Short taper size 11 - Bolt circle 235mm - Through hole 155mm

Condition: like new (used), 3 face plates, cast iron. Each with an outer diameter of 500 mm. 1 unit with through-hole = 128 mm Iiodpfx Apez Hpdmj Djh 1 unit with through-hole = 90 mm 1 unit with through-hole = 80 mm.

Condition: used, faceplate diameter 650 mm diameter . mm hollow . mm Cone 138 mm flange diameter 172 mm flange 6 weight of the machine ca. . t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us Morehe tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Iiedez Hd Nkjpfx Ap Doh More than 10,000 items and accessories for your workshop If than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, faceplate diameter 500 mm diameter 500 mm hollow . mm Cone 138 mm flange diameter 172 mm flange 6 weight of the machine ca. . t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us Morehe tech. Data are manufacturer or operator information and therefore non- Iisdpfxsz Hd Nqj Ap Doh binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2007, functionality: fully functional, feed length Z-axis: 1,250 mm, turning diameter: 3,200 mm, turning height: 2,000 mm, faceplate diameter: 3,200 mm, DOUBLE RAM VERTICAL CNC LATHE KOLOMNA 1532 T KOLOMNA VERTICAL TURNING LATHE (VTL) Iiodpfx Apex Nhm Ro Djh • Table diameter: 3,200 mm • Maximum turning diameter: 3,200 mm • Maximum workpiece height: 2,000 mm • Two CNC-controlled rams • Ram travel: 1,250 mm • FAGOR 8070 CNC control • Motor power: 115 kW • Mechanical, hydraulic, electrical, and electronic retrofitting, completed in 2007 • Chip extractor • Complete enclosure • Cooling system • Work light • Refrigerated electrical cabinet We also have a 1540 Kolomna VTL with a diameter of 4,000 mm.

Condition: good (used), Year of construction: 1972, functionality: fully functional, turning height: 1,000 mm, turning diameter: 1,600 mm, faceplate diameter: 1,400 mm, Retrofit: 2001 Siemens control system SINUMERIK 840D Faceplate diameter 1,400 mm Turning diameter 1,600 mm Turning height 1,000 mm Fully functional. Please refer to the photos for further information. A video of the machine in operation can be provided upon request. Inspection appointments are possible by arrangement. Iisdpfx Aszvl R Rjp Deh The buyer must arrange the collection. Loading onto a truck/container provided by the buyer is included. Invoice with VAT shown. Since these are used machines/used accessories, we exclude any warranty or guarantee. The information is provided to the best of our knowledge, and we assume no liability. We reserve the right to make changes to technical data and to correct any errors in the description. The buyer has the right to inspect the goods for condition and functionality before concluding the contract. We exclude any warranty for obvious and hidden defects, as well as compensation for damages of any kind, including damages that did not occur to the delivered item itself.

Condition: used, 2 clamping plates for KK 8, ribbed cast iron plate, diameter 800 mm and 780 mm Iijdpfx Aez Ilinep Djh

Condition: used, Year of construction: 2009, turning height: 3,500 mm, workpiece weight (max.): 20,000 kg, turning diameter: 3,400 mm, faceplate diameter: 2,950 mm, workpiece diameter (max.): 3,300 mm, SCHIESS CNC VERTICAL TURNING CENTER FAGOR 8070 (C-AXIS + POWER TOOL) TECHNICAL SPECIFICATIONS Brand: Schiess Model: TVMF 320-3000 Year: 2009 Max. turning diameter: 3400 mm Max. turning height: 2580 mm Load capacity: 20 tons C-axis (0.001 deg) CNC: Fagor 8070 (70 Kw) Chuck diameter: 2950 mm Distance between columns: 3300 mm Angular milling head Machine in full working order PRICE AND FURTHER INFORMATION AVAILABLE UPON REQUEST Iijdpfx Apexh Hmko Doh (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, TURNING CENTER, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: used, faceplate diameter 2500 mm Thickness 240 mm T-slot - distance 175 mm total power requirement . kW weight of the machine ca. . kg dimensions of the machine ca. . m Iisdpfxsyuqiqs Ap Doh Optional with 4 jaws €3750 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), I am offering for sale a high-quality RÖHM KFD-HS 200/3 hydraulic lathe chuck, designed for professional CNC lathes. The chuck is in very good technical and visual condition. It looks practically new and appears to have been used only a few times. The working surfaces and guides show only minimal signs of use. The set includes: * RÖHM KFD-HS 200/3 lathe chuck, * 3 standard jaws, Iisdpfx Ajz Snc Isp Djh * 3 RÖHM 538-55 top jaws, * operating wrench, * sturdy wooden transport box (I am not sure if this is the original box for this chuck). Technical data: * Manufacturer: RÖHM * Model: KFD-HS 200/3 * Diameter: 200 mm * Type: hydraulic 3-jaw lathe chuck * Maximum clamping force per jaw (Fmax): 48 kN * Total clamping force (Fges): 110 kN * Maximum rotational speed: 6500 rpm * Identification number: 155099 * Top jaws: RÖHM 538-55 * Country of manufacture: Germany The chuck is ideal for professional applications in machining and working on CNC lathes. It is a robust piece of equipment from the renowned German company RÖHM, which is valued for its high quality and precision.

Condition: good (used), Year of construction: 2008, turning height: 1,500 mm, workpiece weight (max.): 20,000 kg, total height: 6,700 mm, total width: 6,300 mm, total length: 9,300 mm, rotary table diameter: 2,000 mm, spindle speed (max.): 200 rpm, table diameter: 2,000 mm, travel distance X-axis: 1,835 mm, travel distance Y-axis: 1,000 mm, workpiece diameter (max.): 2,400 mm, overall weight: 48,000 kg, Equipment: documentation/manual, X Stroke 1835 mm Z Stroke 1000 mm Table load 20 Ton Ram size 230 x 230 mm   Stroke crossrail 800 mm  Stroke crossrail in 5 steps each 200 mm Live tools 2000 Rpm Power live tools 15 kW ATC 18 station max L = 450 mm Taper BT50 BIG PLUS Full C-Axis 360.000   Under power in AEROSPACE precision plant Isdpov R Di Sjfx Ap Doih 2020 Table bearing replaced 2020 Ram bearing replaced 2025 new chip conveyor Max. turning Ø: 2400mm Table Ø: 2000mm ATC / revolver: 18 Speeds / ranges: 200Rpm Power: 48kW Maximum turning height:1500mm C-Axis: 360000° Length: 9300mm Width: 6300mm Height: 6700mm Weight: 48000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, faceplate diameter 2500 mm Thickness 240 mm T-slot - distance 175 mm total power requirement . kW weight of the machine ca. . kg dimensions of the machine ca. . m Optional with 4 jaws €3750 With bed from Schiess KZ 250 Optionally, a Schiess KZ 250 drive gear can be purchased for €9,500 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Iiodpeyuqknefx Ap Doh If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 1979, Single column vertical turning lathe BERTHIEZ TM500 SP Manufacturer: Berthiez (France) Model: TM500 SP Year of manufacture: 1979 Main technical data: Table diameter: 6300 mm Maximum turning diameter: 15000 mm Maximum usable height: 4000 mm Arm travel: 3600 mm Main motor power: 100KW Maximum allowable load on faceplate: 80 t Ram size: 360x360 mm Machine weight: approx. 230 tons Iijdpfx Apox A U Rae Djh The machine is capable of both turning and milling operations. Do not hesitate to contact us for any additional information.

Condition: good (used), Manufacturer: Jungenthal Year of manufacture: 1960 Type: DKE 1200 Machine number: WM 141 Faceplate diameter: 1,180 mm Table diameter: 1,400 mm Iijdpfx Asz A U Uvop Doh Maximum turning height: 1,300 mm Speed range: 4.5 to 140 rpm Feed rate: 0.063 to 5.4 mm/rev Tool holder: Equipment: extended ram support, stop mechanism, measuring device Condition: good, ready for operation Connection: 25 kW Weight: 13 t Dimensions: mm

Condition: excellent (used), Year of construction: 2012, operating hours: 1,800 h, FEELER VMP-1100 CNC Vertical Machining Centre with NIKKEN CNC202 FA 4th Axis Ijdsz R Tn Hspfx Ap Djih Year 2012 Control FANUC 0i-MD Table size 600 x 1200 mm Travels XYZ 1100 x 610 x 600 mm Spindle nose to table 137 - 735 mm Spindle centre to column 660 mm Spindle speeds to 10000 rpm Spindle taper BT 40 Spindle motor 18.5 kW Number of tools 30 ATC Rapid traverse X & Y 36 m/min, Z 24 m/min Weight 6800 kg Supplied with: BLUM Tool Probe, Swarf Augers, Rear Swarf Conveyor, Spindle Chiller, Filtermist FX5002, Tooling Package. NIKKEN CNC202 FA 4th Axis complete with 200 mm Diameter Faceplate, 135 mm Centre Height, 115 mm Riser Block, Tailstock and Mounting Sub Plate/Table. For sale with Jet Machinery Ltd Jet Machinery Stock No: #27003 Machine Serial Number: VNJ1074 Cost: £34,950.00 + VAT

Condition: used, faceplate diameter 610 mm total power requirement . kW weight of the machine ca. . kg dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Iedpfxoyx Ipde Ap Djih More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, faceplate diameter 1600 mm Thickness 170 mm Cone 285 mm 330 total power requirement . kW weight of the machine ca. . kg dimensions of the machine ca. . m Optional with 4 jaws €3750 With bed from Schiess KZ 250 Optionally, a Schiess KZ 250 drive gear can be purchased for €9,500 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Iijdsyuzagspfx Ap Deh More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team
