Used Gear Grinder for sale (12,993)

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 180 mm max. module: 5 min. module: 1 weight of the machine ca.: 14 t dimensions of the machine ca.: 4,5 x 2,84 x 2,8 m min. number of teeth: 7 toolpiece turning speed range: 4000-10000 U/min tool length: 210 mm Bjdpfx Agjwv Ug Rezjct With tail stock No dressing device Only CBN *

Condition: good (used), Gearboxes, spur gears, bevel gears, worm gears -Manufacturer: SEW, Angle gearbox type SSG3W i 75.36 -Speed: 19 rpm with a 1.1 kW / 1400 rpm motor Bcjdpfxegyb Egs Agzet -Drive shaft: Ø 19 x 40 mm -Output shaft: Ø 35 x 70 mm -Dimensions: 360/240/H230 mm -Weight: 31 kg

Condition: like new (used), Year of construction: 2010, Haas Multigrind CB multi axis CNC grinder, 12 station, Siemens Sinumerik 840D control, load / unload, LTA industrial air cleaning unit, (2010) Bodpev Igg Iofx Agzoct Technical Data - Grinding Spindles (With Two spindle ends) Interface - Cone ø 31.75mm Performance 100% / 40 % ED - 11.5 / 14.5kW Standard rotation speed - 8,000rpm Option: One spindle end Interface - HSK 50E Performance - 100% / 40% ED - 11.5/ 14.5 kW Standard rotation speed - 8,000rpm Option: One spindle end Interface - HSK 50E Performance 100% / 40% ED - 11 / 12 kW Standard rotation speed - 18,000rpm Option: One spindle end Interface - HSK 80E Performance 100% / 40% ED - 30/30 kW Standard rotation speed - 8,000 rpm Option: High Frequency spindle - On request Machine Table Clamping surface - 1000 x 500mm Number, distance and width of the T slots - 9 / 50 / 12H7mm Work Range X- Axis - 700mm (optional) 1000mm (optional) 1200mm Y Axis - 410mm Z Axis - 500mm C Axis angle of rotation - 320° Option: X3 - auxilliary axis Work range - 400mm Probing system and feed Resolution of linear axes - 0.0005mm Rapid feed of linear axes - 30,000mm/min Resolution of rotary axes - 0.001° Rotation speed of C Axis - 400rpm Rotary axis ( A axis) Standard tip height - 175mm Rotation speed as spindle - 2600rpm Standard interface - ISO SK 50 / centering 70H5 Optional - HSK 100 / 80 / 63 / 50 Tool Changer option HSK50E Number of tools / Diameter of tools Inner wheel - 5 / 300mm to 9 / 100mm Outer wheel - 7 / 300mm to 16 / 100mm HSK80E Number of tools / Diameter of tools Inner wheel - 5 / 300mm to 8 / 100mm Outer wheel - 7 / 300mm to 14 / 100mm Workpiece size Diameter 340mm Length 550mm Length between tips 500mm Electrical supply Operating voltage 400V / 50Hz fused to 80 A Controller Siemens contouring control - Sinumerik 840 DSL Pneumatics Operating pressure - 6 - 10bar Weight Total weight depending on equipment 10,000kg or more Floor space requirement Length x width (standard) 3227 x 2700mm Height during operation 3550mm Height with option of coolant nozzles 3810mm (min hall height 4100mm)

Condition: used, Year of construction: 2020, operating hours: 2,530 h, Field of application: Construction Please contact ATS Norway for more information Please provide reference number upon request: 20719 Bjdswrl U Rjpfx Agzoct Specifications: Model year: 2020 Operating hours: approx. 2,530 Engine power: 129 kW Undercarriage: See photo Interchangeable jaws Includes one extra jaw for finer fractions Description:Arjes waste shredder, model year 2020, primarily used for processing wood and bark. Equipped with interchangeable jaws, and delivered with an additional jaw suitable for producing finer output fractions.Quick delivery available. Hours: 2530 Own weight: 14500 Model: 2020 Arjes Impaktor 250 Avfallskvern

Condition: excellent (used), Year of construction: 2009, Machine-Details : Stock-No. 1022-2352 Type of machine Gear Hobbing Machine - Horizontal Make MONNIER & ZAHNER Type KOEPFER MZ 120 Year of manufacture 2009 Type of control CNC Storage location Monheim (Germany) Country of origin Switzerland Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details : max. wheel diameter 2-45 mm gear width 250 mm max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information : The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) Bcedpfx Asx Nh Stogzot 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: used, Year of construction: 1999, Table size 1550 x 500 mm Bodpfox Itaasx Agzoct Grinding area 1550 x 500 mm Speed on the table 5-25 m/min Wheel dimensions 406 x 50,8 x 127 mm Max. table load 1200 kg NC-controlled grinding cycle NC-controlled stone dressing Equipped with: 3 stones w/hubs Magnetic chuck Balancing stand for stones

Condition: used, Year of construction: 2003, Technical details: max. wheel diameter: 80 mm max. module: 3 total power requirement: 25-35 kW Bcodpfx Agowwlunjzot weight of the machine ca.: 10 t workpiece weight: 15 kg workpiece length - max.: -50....+450 mm table diameter: 145 mm diameter of hob: 90 mm cutter length max.: 220 mm hob turning speeds: 1.000 U/min

Condition: good (used), Gearboxes, spur gears, bevel gears, worm gears -Manufacturer: Stöber, Gearbox type C002NO 105MQ10 Bcsdpfxshu Hw Ho Agzjt -Translation: i 10,297 -Drive shaft: Ø 20 x 40 mm -Dimensions: see photo technical drawing -M2 perm: 43 Nm / n1= 3000 rpm -Dimensions: 240/140/H155 mm -Weight: 9.1 kg

Condition: like new (used), Year of construction: 2012, 12 station, Siemens Sinumerik 840D control, load / unload, VAS air cleaning unit, (2012) Technical Data - Grinding Spindles (With Two spindle ends) Interface - Cone ø 31.75mm Performance 100% / 40 % ED - 11.5 / 14.5kW Standard rotation speed - 8,000rpm Option: One spindle end Interface - HSK 50E Performance - 100% / 40% ED - 11.5/ 14.5 kW Bedpfov Igghex Agzect Standard rotation speed - 8,000rpm Option: One spindle end Interface - HSK 50E Performance 100% / 40% ED - 11 / 12 kW Standard rotation speed - 18,000rpm Option: One spindle end Interface - HSK 80E Performance 100% / 40% ED - 30/30 kW Standard rotation speed - 8,000 rpm Option: High Frequency spindle - On request Machine Table Clamping surface - 1000 x 500mm Number, distance and width of the T slots - 9 / 50 / 12H7mm Work Range X- Axis - 700mm (optional) 1000mm (optional) 1200mm Y Axis - 410mm Z Axis - 500mm C Axis angle of rotation - 320° Option: X3 - auxilliary axis Work range - 400mm Probing system and feed Resolution of linear axes - 0.0005mm Rapid feed of linear axes - 30,000mm/min Resolution of rotary axes - 0.001° Rotation speed of C Axis - 400rpm Rotary axis ( A axis) Standard tip height - 175mm Rotation speed as spindle - 2600rpm Standard interface - ISO SK 50 / centering 70H5 Optional - HSK 100 / 80 / 63 / 50 Tool Changer option HSK50E Number of tools / Diameter of tools Inner wheel - 5 / 300mm to 9 / 100mm Outer wheel - 7 / 300mm to 16 / 100mm HSK80E Number of tools / Diameter of tools Inner wheel - 5 / 300mm to 8 / 100mm Outer wheel - 7 / 300mm to 14 / 100mm Workpiece size Diameter 340mm Length 550mm Length between tips 500mm Electrical supply Operating voltage 400V / 50Hz fused to 80 A Controller Siemens contouring control - Sinumerik 840 DSL Pneumatics Operating pressure - 6 - 10bar Weight Total weight depending on equipment 10,000kg or more Floor space requirement Length x width (standard) 3227 x 2700mm Height during operation 3550mm Height with option of coolant nozzles 3810mm (min hall height 4100mm)

Condition: used, total height: 1,200 mm, total width: 1,200 mm, total length: 4,000 mm, Empty weight: 4.000 kg Bcsdpewnib Tjfx Agzet - Documentation available: No - CE certificate present: No - Control: Conventional - Transport dimensions: 4000mm x 1200mm x 1200mm (l x w x h) - Transport weight [kg]: 4000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 2001, tip circle diameter 1000 mm root circle diameter 50 mm max. module 18 mm min. module 1 mm max. wheel diameter 1000 mm gear width 630 mm Profile height max. 41 mm helical angle (left/right) max. 45 ° table diameter 720 mm max. table load 1500 kg grinding wheel diam. min/max. 180 / 400 mm grinding wheel width 60 (45/30) mm grinding spindle speed 0 - 3100 U/min total connected load 30 kVa Bcsdpfowp S Thjx Agzjt

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 275 mm Bedpev N Hilofx Agzoct gear width: 55 mm max. module: 6,5 min. module: 1,5 Face Hobbing-Continious Process Continuous process: The workpiece and tool (usually Spiron) rotate at the same time, and all teeth are created in one operation at the same time. Knife head has several knife groups (not arranged in a circle) Parallel tooth Conical tooth tip surface Single Item procedure: The workpiece is stationary and the tool (usually Arcon) rotates and cuts a tooth by immersing the tool. Once a tooth is cut, the tool moves out of the tooth again, the workpiece divides by one tooth width and the next tooth is cut until all teeth are finished. Knife head has arranged all knives in a circular path. Conical tooth height Parallel tooth head surface C28 can do both, wheel + pinion. However, a C28 must be “prepared” for the individual part procedure. I.e. direct measuring system + part gear brake, workpiece axis + license file for the production of individual parts. *

Condition: good (used), Gear hobbing machine, milling machine, tool milling machine, vertical milling machine, roller milling machine, gear hobbing machine, gear hobbing machine, high-performance hobbing machine -Manufacturer: Liebherr, high-performance gear hobbing machine type SS 5- K/500 -Working area: Ø max. 500 mm -Max. cutter diameter: 186 mm Bcedpfx Agev Dtmmszst -Accessories: including extensive accessories see photos -Machine dimensions: 2300/1460/H1870 mm -Dimensions accessories: pallets 1420/1300/H300 / 1200/800/300 mm -Weight: 5300 kg plus 535 kg accessories

Condition: used, max. wheel diameter 1800 mm gear width 725 mm max. module 5 Control Siemens 840D sl Bcodpfx Agjvylirszjt axial travel 725 mm turning speed range - stepless 44 - 440 U/min cutter diameter max. 240 mm cutter width - max. 300 mm table diameter 1500 mm boring diameter 350 mm weight of the machine ca. 27 t dimensions of the machine ca. 8,8 x 6,1 x 3,25 m Equipment / Accessories: - max. distance from clamping table to counterholder/to center of milling spindle: 1045 mm - milling spindle: - max. axis distance between milling spindle and clamping spindle with/without counterholder: 1200 mm - min. axis distance between milling spindle and clamping spindle with/without counterholder: 525 mm - quick cutter change device - chip extraction device - milling arbors - documentation

Condition: used, Year of construction: 2001, Technical details: Bjdpfx Asxxl Sgjgzoct max. wheel diameter: 50 mm gear width: 20 mm max. module: 4 mm min. module: 0,1 mm total power requirement: 12,5 kW weight of the machine ca.: 4000 kg dimensions of the machine ca.: 2,2 x 2,5 x 2,3 m workpiece length - max.: 300 mm

Condition: good (used), Gear motor, electric motor, three-phase motor, electric gear motor -Speed: 20 rpm -Power: 0.4 kW -Construction: B3 -Diameter shaft: Ø 38 mm -Protection class: IP 44 -Height shaft axis: 160 mm -Price: per piece -Number: 1x available Bedpfxechfcbj Agzect -Dimensions: 500/250/H270 mm -Weight: 37 kg

Condition: used, Year of construction: 2007, max. dia. of teeth cutting 2000 mm workpiece dia. 2700 mm max. module 22 mm Ring thickness for internal gearing max. 500 Control Siemens 840D table diameter 1500 mm table hole 500 mm Table rpm 3,5 1/min table load 200 kN Bcodpjxylm Hsfx Agzst Stroke length 30-330 mm no. of strokes doubel-strokes per min. 10 - 200 1/min. axis distance 70 ... 1220 mm max. radial velocity 3000 mm/min weight of the machine ca. 38000 kg Equipment/ accessories: - Intermediate plate between head and column: Center distance modified min. 0 mm max. 1500mm - column increased for axial stroke 1200 mm max. - Shaping head drive power 30 kW - spindle diameter 160mm - max. tool diameter 300mm - max. cutter wheel speed 10 1/min - Cutting speed 5 ... 45m/min - max. lateral offset 50mm - coolant device coolant tank capacity 2500 l - documentation

Condition: used, Year of construction: 2008, Technical details: max. wheel diameter: 300 mm gear width: 60 mm max. module: 5 weight of the machine ca.: 14 t Bodoxz Akfspfx Agzect table turning speeds: 80 - 200 U/min adjustment movement of the stroke: 400 mm length of stroke min./max.: 0-70 mm no. of strokes: 1500 Hub/min *

Condition: good (used), pneumatic angle grinder, Flex, grinding wheel, cut-off grinder, cut-off grinding machine, angle grinder -Max. discs: Ø 178 mm -Speed: max. 8500 rpm Bjdjb A Intjpfx Agzsct -Number: 74 angle grinders available Price: per piece -Weight: 4 kg/piece

Condition: used, Year of construction: 2007, workpiece diameter nominal 2400 mm max. workpiece diameter 2800 mm max. module 30 mm control Siemens Sinumerik 840 D dividing plate diameter 2200 mm table diameter 2500 mm Bsdew Rf S Sspfx Agzoct Table hole Diameter / depth 800 / 875 mm max. table load 40000 kg Table rpm 4,5 min-1 clamping length max. 375 mm clamping diameter max. 350 mm cutter diameter max. 2800 mm Cutter arbor cone HSK-B160 swivelling range milling head + 30/-45° Distance Cutter - Workpiece 615 / 1600 mm weight of the machine ca. 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation

Condition: used, Year of construction: 2001, Technical details: max. wheel diameter: 200 mm gear width: 50 mm max. module: 6 table diameter: 168,14 mm boring diameter: 65,532 mm weight of the machine ca.: 11 t table turning speeds: 0-1.000 U/min length of stroke min./max.: 0-70 mm Bodpfx Agjxz Avbezsct no. of strokes: 180-1.800 Stück *

Condition: good (used), heavy gearbox, spur gear gearbox -Translation: 186:1 -Drive shaft: Ø 16 mm -Output shaft: Ø 50 mm -Number: 2x gearboxes available Bcjdpfx Agjb A I Iwjzjt Price: per piece -Weight: 80 kg/piece

Condition: used, Year of construction: 1984, max. wheel diameter 1500 mm gear width 700 mm max. module 5 Control Liebherr LH90 smallest number of teeth to be hobbed 6 milling head: Motorfräskopf milling spindle speeds (infinitely variable) 44 - 440 U/min Bedovvcgtopfx Agzect milling head -swivable +/- 45 ° table diameter 1100 mm max. table load 8000 kg total power requirement 66 kVA Equipment / Accessories: - chip extraction device - milling arbors - documentation

Year of construction: 2002, condition: used, max. wheel diameter 275 mm gear width 55 mm max. module 6 min. module 1,5 control Sinumerik 840C tooth width 5,5 mm spiral angle 0/60 ° max. number of teeth 120 min. number of teeth 5 transmission ratio max. 1:10 transmission ratio min. 1:1 spindle speeds max. 110 mm blade head turning speeds 20-110 1/min total power requirement 100 kW weight of the machine ca. 16700 kg Bcedpfx Ajgtvbpjgzst dimensions of the machine ca. 5200x2300x2400 mm

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2,35 x 2,24 x 2,5 m Bsdeukitxopfx Agzect
