Used Hurco Vmx 1 for sale (150)

Year of construction: 2006, condition: ready for operation (used), Travel X/Y/Z: 1270mm/660mm/610mm, speed: 10000rpm, max. table load: 3000kg, spindle mount: CAT40, tool positions: 40, machine dimensions X/Y/Z: approx. 3300mm/2800mm/3000mm, weight: approx. 9000kg, control: Ultimax. Documentation available. On-site inspection is possible. Gkjdpsuzyafofx Abhod

Condition: ready for operation (used), Year of construction: 2018, operating hours: 7,200 h, functionality: fully functional, travel distance X-axis: 1,067 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller model: Hurco MAX 5 mit WinMax Software, TECHNICAL DETAILS Travel range X-axis: 1,067 mm Travel range Y-axis: 610 mm Travel range Z-axis: 610 mm Number of axes: 3 Number of tools in the magazine: 30 Tool holder: SK40 Table size X-axis: 1,270 mm Table size Y-axis: 610 mm Gkjdpfxszaprzo Abhod MACHINE DETAILS Control system: Hurco MAX 5 with WinMax software Drive power: 12 kW Torque: 237 Nm Operating hours: approx. 7,200 h EQUIPMENT Internal coolant supply Spindle cooler

Condition: excellent (used), Year of construction: 2014, Controller WIMNAX V09 (DSM) Table size 2184 x 865 mm T-slots in table 7 x 18 x 125 mm Table load max. 2268 kgs X travel 2134 mm Y travel 864 mm Z travel 762 mm Spindle speed 12000 rpm Spindle power 18 kW Tool holder type SK40 ATC magazin 40-fold Max tool dia. 74.9 mm Max tool length 300 mm Max tool weight 7 kgs Rapid speeds X/Y/Z = 18, 18, 13.5 m/min Weight 17000 kgs Dimensions LxWxH = 7570 x 4450 x 3260 mm Accessories, features - Coolant device - DXF, NCPP, ISNC, Herical, rigid tapping, pocket/islands options - CTS 20 bar - Spindle cooler - Chip conveyors - Manuals Gsdpfxopiaqxo Abhjkd Very good condition. Ready to sale immediately. The tools are not in with the machine.

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 36.5 [kW] - Spindle speeds : 12000 [rpm] - B Rotary Axis : 90 [°] (+/-) LINEAR AXES - Travels on X/Y/Z axes : 1525 / 660 / 610 [mm] - Rapid traverses rates (X/Y/Z) : 32 / 32 / 24 [mm/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : 1680 x 660 [mm] - Distance table / spindle nose (min./max.) : 12.7 - 622.3 [mm] - Maximum weight upon table : 1360 [kg] - Diameter of the C-type rotary table : 600 [mm] - Travel : 360 [°] - Maximum load on the rotary table : 500 [kg] POWER SUPPLY Gkedpey Tzc Hjfx Abhjd - Supply voltage : 400 [V] - Total installed power : 69 [kVA] WEIGHT & DIMENSIONS - Machine weight : 9.800 [kg] EQUIPMENT - CNC : WinMax / MAX5 - Electronic handwheel - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Spindle cooling unit - Tool probe

Condition: ready for operation (used), Year of construction: 2003, A vertical CNC machining center is offered. Table diameter: 320mm, travels X/Y/Z: 1270mm/660mm/610mm, spindle speed: 16000rpm, tool holder: SK40, number of axes: 4, rapid traverse: 30000mm/min, max. feed rate: 15240mm/min, rotary table spindle bore: 105mm, rotary table center height: 225mm, control system: WINMAX MIL, overall dimensions X/Y/Z: approx. 4750mm/3200mm/3000mm, weight: approx. 9000kg, operating hours: approx. 61762h. Including a Yaskawa spindle motor and Hurco transport equipment. Documentation available. Inspection possible by appointment. Expected to be available from December 2026. Godpfx Aozdkn Dsbhjkd

Year of construction: 2002, condition: ready for operation (used), Hurco VM 1 machining center Spindle speed max. 8000 RPM Travel: X: 660 mm Gjdpfoi E Iacsx Abhjkd Y: 406 mm Z: 508 mm Spindle: 2000 hours Complete software options, DXF, thread cutting without collet Various tools included, Hilma vise, drawer cabinet with tools.

Condition: excellent (used), Year of construction: 2003, control: Ultimax tool taper: SK40 table size: 1270 x 610 mm travel: x-1060; y-610; z-610 mm Gkodpfeitk I Usx Abhed spindle speed: 10000 rpm 40 fold tool changer internal cooling chip conveyor accessories: 2 hydrl. vices, div. tool holder

Condition: used, Year of construction: 2000, functionality: not functional, Hurco VMX 50 machining center with Ultimax control IKZ chip conveyor Gsdpfjt H I Ugex Abhokd

Condition: excellent (used), Year of construction: 2003, control: Ultimax tool taper: SK40 table size: 1020 x 510 mm travel: x-760, y-510, z-610 mm spindle speed: 10000 rpm 24 fold tool changer Gksdpeitk Ncefx Abhsd internal cooling accessories: 2 hydrl. vices, div. tool holder

Condition: ready for operation (used), Year of construction: 2004, General Data Gkjdpfxjx D Ikpj Abhsd Measurements width 2300 mm Measurements depth 2800 mm Measurements height 2700 mm Machine weight 4500 kg Main Drive Spindle speed range 10000 Spindle motor power CAT40 / SK40 Number of axis 4 Movement X-Axis Movement 762 mm X-Axis Rapid Traverse 24 m/min Y-Axis Movement 508 mm Y-Axis Rapid Traverse 24 m/min Z-Axis Movement 610 mm Z-Axis Rapid Traverse 24 m/min Table Tslots size 18 mm Number of tslots 5 Table load 750 kg This 4-axis Hurco VMX30 was manufactured in 2004. It features a CNC milling machine with a rotary table for 4th axis capabilities. Key specs include a 762 mm X-axis travel, 508 mm Y-axis travel, 610 mm Z-axis travel, and a table size of 1,016 × 508 mm. It supports a maximum spindle speed of 10,000 rpm and a tool magazine capacity of 24. Consider the opportunity to buy this Hurco VMX30 vertical machining centre. Contact us for more information. Application Types Milling

Condition: used, A CNC machining center with T-slot table is offered. Control: HURCO Ultimax with dual-screen console. Equipped with several fixtures mounted on the machine table, coolant system and available HURCO documentation including training documentation for the Ultimax CNC control. Inspection possible by appointment. Gkjdjz Hzd Sepfx Abhjd

Condition: ready for operation (used), Year of construction: 2002, A CNC machining center by Hurco requiring repair is offered, including spindle through-coolant and a chip conveyor. Travels X/Y/Z: 1625mm/860mm/760mm, operating hours: approx. 39025h, max. spindle speed: 8000rpm, tool stations: 40, tool holder: HSK40, cover of the Z-axis is defective. Inspection possible by appointment. Gkedpfxszghfre Abhod

Condition: ready for operation (used), Year of construction: 2006, Offered is a Hurco CNC vertical machining center including spare parts. Travel X/Y/Z: 1270mm/660mm/610mm, table dimensions X/Y: 1500mm/660mm, max. table load: approx. 1360kg, spindle speed: 10000rpm, spindle taper: SK40, main drive power: approx. 18.5kW, tool pockets: 24, feed X/Y/Z: 30m/min, feed Z: 20m/min, rapid traverse X/Y: 30m/min, rapid traverse Z: 20m/min, spindle operating hours counter: approx. 7676h, control: Hurco Ultimax. Machine dimensions X/Y/Z: approx. 3300mm/2800mm/3000mm, machine weight: approx. 9000kg. Inspection possible by arrangement. Gksdpezkvmfjfx Abhjd

Condition: good (used), Year of construction: 2003, x-Weg 1270 mm y-Weg 660 mm z-Weg 610 mm Steuerung Ultimax 4 Gsdpfoiv R Hlsx Abhokd Tischbelastung 1300 kg Drehzahl 10.000 U/min Werkzeugwechseleinrichtung 24-fach Werkzeugaufnahme SK 40 Antrieb 15 kW Tischgröße 1500x660 mm Gesamtleistungsbedarf kW Maschinengewicht ca. 9 t Raumbedarf ca. 4,8x4,5x2,95 m

Condition: used, Year of construction: 2006, Spare parts for Hurco VM1, manufactured in 2006 - F7 spindle drive CIMR-F7UXXXXX-063 AC drive Software version: VSF11006X Price: €800 - Ejector cylinder Price: €100 International shipping can be arranged. Godpfjzx Sqiex Abhokd

Condition: ready for operation (used), Year of construction: 2016, travel distance X-axis: 661 mm, travel distance Y-axis: 407 mm, travel distance Z-axis: 508 mm, table load: 1,500 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 11,000 W, number of slots in tool magazine: 24, tool weight: 7,000 g, number of axes: 3, This 3-axis Hurco VM10i was manufactured in 2016. It features an X-axis travel of 661 mm, Y-axis travel of 407 mm, and Z-axis travel of 508 mm. The machine includes a robust table size of 762 x 406 mm and a maximum table load of 1,500 kg. If you are looking to get high-quality machining capabilities, consider the Hurco VM10i vertical machining centre we have for sale. Contact us for further details. • CNC Control: HURCO MAX 5 (WinMax software version V10.01.131.12) • Table Dimensions: 762 x 406 mm • T-Slots: 3 x 18 mm • T-Slot Center Distance: 10 mm • Spindle Nose to Table Distance: 102 - 610 mm • Spindle Torque: 72 Nm • Rapid Traverse (X/Y/Z): 28,000 mm/min • Tool Magazine Capacity: 24 positions • Maximum Tool Diameter (Adjacent Occupied): 80 mm • Maximum Tool Diameter (Adjacent Empty): 120 mm • Maximum Tool Length: 250 mm • Machine Working Hours: 15,420 h 10 min • Spindle Hours: 2,727 h 59 min • Monitor: 19" Touch Screen • Hardware: 128 GB SSD, 4 GB RAM, Dual-Core 2.7 GHz Processor • Connectivity: 2x USB 2.0 (console), 2x USB (electrical cabinet), 1x Ethernet LAN Additional equipment • Remote electronic handwheel • Auger-type chip conveyor • Wash gun (water/air) • Status tower lamp • Retention knobs • Leveling pads Technical Specification Gedpfx Ajzgf Htebhekd Taper Size ISO 40

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : HSK63 - Spindle speeds : 18000 [rpm] - Spindle power : 25 [kW] LINEAR AXES - Travels on X/Y/Z axes : 760 / 510 / 520 [mm] - Rapid traverses rates (X/Y/Z) : 45 / 45 / 40 [mm/min] A ROTARY AXIS - Travel : -110 / +30 [°] - C ROTARY AXIS - Travel : 360 [°] - Rapid traverse rate : 25 [rpm] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : Ø248 [mm] - Maximum weight upon table : 200 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 48 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.940 x 4.060 [mm] - Machine height : 2.865 [mm] - Machine weight : 6000 [kg] EQUIPMENT - CNC : Hurco WinMax / MAX5 - Interactive programming - Electronic handwheel - Coolant tank * with high-pressure pump Gjdpfx Ajy Tzctsbhekd - Coolant through spindle - Chips conveyor - Spindle cooling unit

Condition: ready for operation (used), Year of construction: 2023, operating hours: 346 h, travel distance X-axis: 203 mm, travel distance Z-axis: 560 mm, total height: 3,296 mm, total width: 2,552 mm, overall weight: 7,500 kg, controller manufacturer: HURCO, controller model: MAX5 Single Control, product length (max.): 5,519 mm, number of axes: 5, This 5-axis Hurco CNC TMX 8 MYSi was manufactured in 2023. It features a maximum turning diameter of 508 mm and a turning length of 560 mm, with a main spindle speed of 4,500 rpm and a sub-spindle speed of 6,000 rpm. The machine includes a tool turret with 12 stations and a rapid traverse of 24 m/min in the X-axis. If you are looking to get high-quality turning and milling capabilities, consider the Hurco CNC TMX 8 MYSi turn-mill centre. Contact us for further details. Gkedpfx Aoym T Itsbhsd - Number of Axes: 5- X-Axis Travel: 203 mm- Y-Axis Travel: ±55 mm- Z-Axis Travel: 560 mm- W-Axis Travel: 640 mm- Rapid Traverse (X/Y/Z/W): 24 / 12 / 30 / 30 m/min- Positioning Accuracy Pmax: 0.01 mm- Repeatability Ps: 0.005 mm- C-Axis Accuracy: 25 arcseconds- Max. Turning Diameter: 336 mm (Email text states 508 mm max turning / swing)- Max. Turning Diameter at Full Y-Travel: 216 mm- Max. Swing Diameter: 508 mm- Max. Turning Length: 560 mm- Max. Workpiece Diameter Over Bed: 335 mm- Max. Workpiece Weight without Sub-spindle/Tailstock: 23.2 kg- Max. Workpiece Weight with Sub-spindle/Tailstock: 145.5 kg- Turret Type: VDI 40 / DIN 1809- Turret Stations: 12- Turret Indexing Time: 0.31 s- Max. Boring Bar Diameter: 40 mm- Tool Shank Cross Section: 25 mm- Driven Tool Max. Speed: 5,000 rpm- Driven Tool Power: 6.3 kW- Driven Tool Max. Torque: 28 Nm- Main Spindle Max. Speed: 4,500 rpm- Main Spindle Speed with Synchronous Sub-Spindle: 2,500 rpm- Main Spindle Power (S6 / S1): 25 / 17.2 kW- Main Spindle Torque (S6 / S1): 239 / 164 Nm- Main Spindle Chuck Diameter: 203 mm (Kitagawa BB208A6 3-jaw chuck)- Main Spindle Draw Tube Diameter / Bar Capacity: 64.5 mm- Main Spindle Nose: A2-6- Main Spindle Collet Type: CR60A6- Main Spindle Acceleration (0 to n max): 3.2 s- Main Spindle Deceleration (n max to 0): 4.5 s- Sub-Spindle Max. Speed: 6,000 rpm- Sub-Spindle Speed with Synchronous Main Spindle: 2,500 rpm- Sub-Spindle Power (S6 / S1): 15 / 11 kW- Sub-Spindle Torque (S6 / S1): 102 / 75 Nm- Sub-Spindle Chuck Diameter: 150 mm (Kitagawa B206A5 3-jaw chuck)- Sub-Spindle Draw Tube Diameter / Bar Passage: 46 mm- Sub-Spindle Nose: A2-5- Sub-Spindle Collet Size: 173E- Sub-Spindle Acceleration (0 to n max): 4.0 s- Sub-Spindle Deceleration (n max to 0): 4.0 s- Machine Bed Material: GJS (Ductile cast iron)- Guideways: Ball linear motion guideways on X/Y/Z/W- Ball Screws: Direct drive ball screws on X/Y/Z/W- Control System: HURCO MAX5 Single Control (Pentium technology, SSD storage, 2 GB RAM, Ethernet, USB, Windows platform)- Display: 1 x 19" LCD color screen plus optional secondary screen- CNC Software Options: Dialogue/NC Mix package, NCPP, ISNC (FANUC 0 compatibility), DXF software, dual software units (Plain text dialogue + ISO code)- Additional Installed Equipment: Sub-spindle parts ejector, finished parts catcher, finished parts conveyor, tool presetter/calibration, spindle chiller, electrical cabinet heat exchanger/air conditioner, LED work light, bar feeder interface, air/coolant blast chuck cleaning- Electrical Supply: 400 V, 50 Hz, 3-Phase (Standard configuration: 61 kVA / 110 A; Nominal: 58 kVA / 83 A; Largest motor: 22 kVA / 32 A)- Short Circuit / Interrupting Capacity: 5 kA RMS symmetrical / 10,000 A- Pneumatic Supply: 7 bar, 140 L/min (Dry, clean air per DIN ISO 8573-1, Class 4)- Max.

Condition: excellent (used), Hurco VMX50i (2014) 3-Axis Vertical Machining Centre Godpfxoyx H Rts Abhjkd Control: Hurco WinMax Travels & Capacity X Axis Travel: 1270 mm Y Axis Travel: 660 mm Z Axis Travel: 610 mm Table Size: 1500 x 660 mm Max Table Load: 2000 kg

Condition: used, Year of construction: 2002, functionality: fully functional, The machining center has been inspected by a Hurco technician and found to be fully operational without any faults. Technical Data - Travel ranges: X 1,270 mm, Y 600 mm, Z 610 mm - Drive power: 30 kW - Spindle speed: 15,000 rpm - Spindle taper: SK 40 Type B - Feed rate: up to 23 m/min Work Table: - Dimensions: 1,500 mm x 660 mm - Max. workpiece weight: 1,300 kg Control: - Hurco Ultimax 4, incl. software for milling simulation - electronic hand control unit - Interfaces: RS 232C / V24 - 2 monitors for text and graphics processing - 2 software units for plain text and ISO programming Gsdpfxex Iikbe Abhjkd Machine Construction: - High rigidity, suitable for roughing operations Tool Changer: - Double-arm changer with 24 stations Equipment: - Cooling unit for milling spindle - Rinsing system for chip removal - Splash guard cabin - Coolant system with filtration - Internal coolant supply ICS 20 bar - Chip conveyor Machine Data: - Required space (without service areas!) LxWxH approx. 4,750 mm x 3,120 mm x 2,950 mm - Weight approx. 9,000 kg - Connected load 50 kVA, 400V, 50/60 Hz An inspection of the machine is possible by appointment. All tools and operating materials visible in the photos are not included in the scope of delivery. Technical changes and errors excepted.

Condition: ready for operation (used), Year of construction: 2006, Travel X/Y/Z: 1060mm/610mm/610mm, table dimensions X/Y: approx. 1270mm/610mm, max. table load: 1100kg, spindle power: 18kW, feed rate: 7600mm/min, rapid traverse: 30m/min, tool positions: 24, tool holder: SK40, speed: 12000rpm, positioning accuracy: +/-0.01mm, repeatability: +/-0.005mm. Machine dimensions X/Y/Z: approx. 450mm/3750mm/2800mm, weight: approx. 6700kg, control: Hurco Ultimax 4. Documentation available. On site inspection is possible. Gkedpoyh Nvmefx Abhod

Condition: good (used), Year of construction: 2012, power: 0.018 kW (0.02 HP), travel distance X-axis: 1,067 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, rotational speed (min.): 12,000 rpm, Hurco machining center V 42 T Gjdpfxetxrbis Abhskd 3-axis technology Travel in x 1067 mm Travel in y 610 mm Travel in Z 610 mm Table dimensions 1270 x 610 mm Spindle speed 12000 rpm 40-fold tool changer Chip conveyor Simulation graphics Tool and material library Pocket milling with island Synchronous thread cutting without compensating chuck Win Max control IKZ high pressure through the spindle

Condition: used, Year of construction: 2002, Technical details: x-travel: 1060 mm y-travel: 610 mm z-travel: 610 mm control: Ultimax 4 spindle speed:: 10 - 10.000 U/min tool taper: SK40 tool changer with: Trommelmagazin mit 24 Plätze places feed speed: XYZ: 3 - 7.000 mm/min rapid traverse:: XY: 30 m/min rapid traverse: Z: 20 m/min table-size: 1220 x 510 mm table load: 1,1 t air-pressure connection: für 6 bar bar Total power requirement: 30 kVA Weight approx.: 6,28 (ohne Anbauteile) t dimension machine xH: 2,82 x 3,2 x 2,7 m dimension swarf conveyor LxWxH: 3,0 x 0,65 x 1,5 The machine is currently in the technical department. delimited working area by chip splash guard cabin incl. cooling device with feeding (30bar internal coolant system) (size 1200x500x150mm) capacity for 340Liter spindle with internal coolant system Scraper belt chip conveyor control panel with two screens Attention! Tool gripper arm for tool change is missing on the machine! Is on sale with this limitation! i.D. * Gkodju Iddnopfx Abhod

Condition: used, Year of construction: 1999, x-travel 610 mm y-travel 405 mm z-travel 510 mm table surface area 760 x 400 mm spindle taper SK 40 Godpfevh Nbujx Abhekd spindle turning speed - stepless 80 - 8000 U/min spindle drive 7,5 kW max. torque on the spindle max. 142 Nm feeds 3,0 - 7600 mm/min rapid motion -longitudinal/cross/vertical 24 / 24 / 15 m/min distance table / vertical spindle max. 600 mm table load 350 kg no. of tools in magazin 24 workpiece diameter at full load 80 mm tool length - max. 300 mm weight of tools max. 6,8 kg control ULTIMAX SSM total power requirement 18 kVA weight of the machine ca. 4,1 t Accessories: 2 tool fixtures SK 40, 3-jaw chuck RÖHM, chip conveyor, coolant

Condition: excellent (used), Year of construction: 2003, Ultimax 4 control unit Gkjdpfxjt Rubbs Abhed Travel X/Y/Z 760 x 510 x 610 mm Table size 1020 x 510 mm Speed 12,500 min-1 Tool magazine for 24 tools, SK 40
