Used Vertical Machine Center for sale (68,873)

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 550 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 10,000 rpm, The machine spindle was replaced in 2022! TECHNICAL DETAILS Traverse path X-axis: 800 mm Traverse path Y-axis: 520 mm Traverse path Z-axis: 550 mm Spindle type: SK40 Spindle speed: 10,000 rpm Tool changer: 24-position Table size: 950 x 520 mm MACHINE DETAILS Dkedpfx Aoy E Hqtenwjl Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (LxWxH): approx. 2.60 x 2.60 x 2.70 m Weight: 6,800 kg Operating Hours Machine on-time: approx. 47,000 h Program run time: approx. 5,700 h Spindle: approx. 4,800 h EQUIPMENT IKZ (internal coolant supply) Hexagon probe Note: NC clamps and tool holders are not included in the offer.

Condition: defective spare-parts repository (used), Year of construction: 2005, operating hours: 38,534 h, functionality: not functional, machine/vehicle number: 29310001024, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 560 mm, controller model: Heidenhain iTNC530, rotational speed (max.): 18,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 750 mm Travel Y-axis: 600 mm Dsdpfx Ansy Ib H Ijwskl Travel Z-axis: 560 mm Worktable size: 950 x 650 mm Table load: 1,000 kg Spindle speed: 18,000 rpm Number of axes: 3 Tool changer: 30 positions Tool holder: HSK63 MACHINE DETAILS CNC control: Heidenhain iTNC530 Dimensions & Weight Dimensions (L x W x H): 3,500 x 3,000 x 3,200 mm Transport dimensions (L x W x H): 3,500 x 3,000 x 3,200 mm Weight: 10.2 t Operating hours Spindle hours: 38,534 h Operating hours: 98,381 h Note: DMG has measured the clamping force on the machine, which is so low that there is a risk of the tool falling out. The machine has suffered spindle damage. There are various leaks, for example at the chip conveyor or in the door area.

Condition: defective spare-parts repository (used), Year of construction: 2003, operating hours: 30,434 h, functionality: not functional, machine/vehicle number: 1114 000402 3, travel distance X-axis: 1,060 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, controller model: Heidenhain iTNC530, rotational speed (max.): 10,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 1,060 mm Y-axis travel: 710 mm Z-axis travel: 710 mm Working area: Ø800 NC rotary table Spindle speed: 10,000 rpm Number of axes: 5 Dedey Ib A Njpfx Anwokl Tool changer: 30 stations Tool holder: HSK63 MACHINE DETAILS Control: iTNC530 Dimensions & Weight Machine dimensions (L x W x H): 4,080 x 4,490 x 3,117.5 mm Transport dimensions (L x W x H): 3,500 x 2,500 x 2,410 mm Weight: 9.7 t Operating hours Spindle hours: 30,434 h Operating hours: 66,001 h Note: The machine temperature rises immediately, and in the past there has even been smoke. The machine has spindle damage. Various cable insulations are worn.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 6,023 h, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, spindle speed (max.): 8,000 rpm, number of axes: 4, TECHNICAL DETAILS Travel X-axis: 1,020 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Table length: 1,150 mm Table width: 500 mm Tool holder: BT40 Main spindle power: 11 kW Max. spindle speed: 8,000 rpm MACHINE DETAILS Control: CNC Number of axes: 4 Power: 15 kW Dimensions & Weight Dimensions (L x W x H): 3,500 x 2,000 x 2,500 mm Net weight: 5,000 kg Transport packages: 1 Operating hours: 6,023 h EQUIPMENT Dkodpfx Asy Hh Iionwol Chip conveyor External cooling Tool magazine

Condition: ready for operation (used), Year of construction: 2006, operating hours: 32,790 h, functionality: fully functional, travel distance X-axis: 2,032 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, table load: 3,000 kg, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel X-Axis: 2,032 mm Dksdpfx Aoy Hkhrenwol Travel Y-Axis: 750 mm Travel Z-Axis: 750 mm Max. workpiece height: 870 mm Max. table/workpiece load: 3,000 kg Table width: 800 mm Table length: 2,240 mm Spindle speed: 40 – 6,000 rpm Spindle taper: SK 50 Standard spindle power: 18.5 kW Standard torque: 759 Nm Increased spindle power: 26 kW Increased torque: 1,067 Nm MACHINE DETAILS Control system: MAZATROL Dimensions & Weight Dimensions (L x W x H): 5,685 mm x 4,096 mm Weight: 14,000 kg Operating hours: 32,790 h EQUIPMENT Measuring probe (manufacturer: Renishaw) Chip cart 47 SK50 tool holders, including approximately 25 Weldon holders Emulsion cleaning unit

Condition: ready for operation (used), Year of construction: 2000, operating hours: 23,574 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, controller model: Siemens Sinumerik 840D, spindle speed (max.): 8,000 rpm, The following machine components have been renewed: - Motor & pump of the hydraulic system - Hydraulic and pneumatic hoses (partially) - Control cabinet LT module replaced - Drum of the Knoll system TECHNICAL DETAILS Travel distance X-axis: 600 mm Dkodpfxoy Nbuns Anwjl Travel distance Y-axis: 560 mm Travel distance Z-axis: 560 mm B-axis: 360 x 0.001° (60 rpm) Spindle speed: 8,000 rpm Table size: 6 pallets, each 500 x 400 mm Table width: 400 mm Table length: 500 mm Table load capacity: 350 kg Working feed rate: 1 - 60,000 mm/min Rapid traverse: 60 m/min MACHINE DETAILS CNC control model: Siemens Sinumerik 840D Total length: 7,000 mm Total width: 5,000 mm Coolant supply: 50 bar Coolant system capacity: approx. 1,100 L Motor power: 13 kW / 20 kW Torque: 124 / 191 Nm Total power requirement: 20 kW Dimensions & Weight Space requirement (L x W): 7 x 5 m Machine weight: approx. 16,000 kg Operating hours Power-on time: approx. 48,804 h Spindle operating hours: total 23,574 h EQUIPMENT - Documentation/Manual - Steplessly adjustable spindle speed - Chip conveyor - Knoll cooling unit with drum filter (30/40/50 bar via M-command) - Tool measurement: Renishaw probe - Tool breakage monitoring in the working area - Pallet storage (4 positions) - Pallet sequence operation - Fully enclosed work area in accordance with UVV - Network capability - Technical documents & layout plan

Condition: ready for operation (used), Year of construction: 2016, operating hours: 9,956 h, functionality: fully functional, machine/vehicle number: 17211, travel distance X-axis: 650 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 680 mm, controller model: Siemens Sinumerik 840 D solution Line, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS X-axis travel: 650 mm Y-axis travel: 650 mm Z-axis travel: 680 mm Table width: 400 mm Table height: 30 mm Table length: 500 mm Table load capacity: 500 kg Max. workpiece height: 850 mm Max. pallet load: 500 kg Pallet changer: 2 pallets, automatic Change time: approx. 8 s Tool magazine: 60 tools Spindle speed (max.): 18,000 rpm Spindle motor power: 32,400 W MACHINE DETAILS Control system: Siemens Sinumerik 840 D Solution Line Dkedpfx Ansy Nbt Djwjl Dimensions & Weight Dimensions (L x W x H): approx. 5,150 x 2,800 x 3,025 mm Weight: approx. 12,800 kg Noise emission: 80 dB(A) according to EN ISO 3744 Coolant supply: 80 bar Operating hours Total operating hours: 27,412 h Automatic operation: 11,155 h Spindle hours: 9,956 h EQUIPMENT Documentation/manual Chip conveyor Siemens spindle diagnostics & remote diagnostics (Teamviewer) Energy-efficient system with regenerative feedback Standby mode for energy savings Direct drive NC rotary table 6-channel clamping hydraulics (90 bar) Increased spindle torque for high-performance machining Torque support Central coolant supply system Renishaw OMP60 optical touch probe Tool breakage control Pallet sequence operation Crane infeed/outfeed software Signal light for operating states Work area/machine equipment: shower nozzle, cleaning pistol, vortex nozzle, emission extraction interface Foot switch for air nozzle Documentation: fully digital (PDF)

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: Dedpfxjyzkdvj Anwjkl POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: Dkodjyzkdcopfx Anwol X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, table width: 450 mm, table length: 1,200 mm, spindle nose: BT40, Dugard Eagle 1000 Vertical Machining Centre Model: 1000 VMC Year: 2005 Control: FANUC Oi-MD Table Area: 1200mm x 450mm ‘X’ Traverse: 1020mm ‘Y’ Traverse: 510mm ‘Z’ Traverse: 510mm Dsdpsy N Ukcefx Anwjkl Max. Spindle Speed: 8000 RPM Spindle Taper: BT 40 ATC capacity: 20 station Machine with: Swarf Conveyor

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 610 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 450 mm, table width: 450 mm, table length: 800 mm, spindle speed (max.): 8,000 rpm, Model: 610L Control: Fanuc Series Oi-MC Year: 2012 Table Area: 800 x 450mm ‘X’ Axis: 610mm ‘Y’ Axis: 460mm ‘Z’ Axis: 450mm Spindle Taper: BT 40 Spindle Speeds: 8000 RPM Carosel 12 Station Tool Changer Dkodpfoy N Uh Ujx Anwel Dimensions: 2200 x 2300 x 2300mm high Weight: 3400 KGS

Condition: used, Year of construction: 2000, travel distance X-axis: 600 mm, travel distance Y-axis: 430 mm, travel distance Z-axis: 460 mm, MORI SEIKI SV-400 WITH 4TH AND 5TH AXIS VERTICAL MACHINING CENTRE MAKE MORI SEIKI, MADE IN JAPAN MODEL SV-400 YEAR 2000 CONTROL MORI FANUC MSC 501 TABLE SIZE 900.0 x 500.0 mm TRAVERSES (XYZ) X: 600.0 mm Y: 430.0 mm Z: 460.0 mm SPINDLE SPEED Up to 12,000 rpm SPINDLE TAPER BT 40 ATC 30 STATIONS RAPID TRAVERSE XYZ: 32,000 mm/min Dkedpfx Anotvau Hjwel FEEDRATE 1-16000mm/min PLUS NIKKEN 4th and 5th AXIS UNIT RENISHAW PROBBING TWIN SWARF CONVEYOR COOLANT SYSTEM

Condition: not inspected (used), Year of construction: 2004, functionality: unexamined, machine/vehicle number: 10651-7, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 300 mm, table load: 800 kg, spindle speed (max.): 42,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel distance X-axis: 600 mm Travel distance Y-axis: 450 mm Travel distance Z-axis: 300 mm Rapid traverse X-axis: 30 m/min Rapid traverse Y-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Maximum spindle speed: 42,000 rpm Spindle taper: HSKE40 Number of spindles: 1 Table width: 405 mm Table length: 405 mm Max. table load: 800 kg Number of tool magazine slots: 26 MACHINE DETAILS Control system model: RMS6, version 3.18 Input voltage: 400 V Dksdpoy Nzuhefx Anwjl Dimensions & Weight Dimensions (L x W x H): 4,210 x 2,350 x 2,600 mm Weight: approx. 7,000 kg EQUIPMENT Documentation/manual Infinitely variable spindle speed control Chip conveyor Blum laser 3D tool setter Hirschmann 9000 zero-point clamping system Electronic handwheel Extor extraction system

Condition: used, Year of construction: 2000, x-travel 1.050 mm y-travel 560 mm Dedpfx Anjy Rakkowekl z-travel 450 mm Control OKUMA OSP-U100M-H table dimensions 1.300 x 560 mm spindle tunring speed 10.000 U/min tool taper BT 40 In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: like new (used), Year of construction: 2020, operating hours: 16,785 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 610 mm, CNC Machining Center Manufacturer: Fehlmann, Model: Picomax 95 Year of manufacture: 2020 Technical Data Make: Fehlmann Model: Picomax 95 Year: 2020 Operating hours: 16,785 total / 7,181 spindle hours Spindle speed: 50 – 18,000 rpm Spindle power: 25.2 kW Max. torque: 120 Nm at 50–2,010 rpm Control: Heidenhain TNC 640 X-axis travel: 800 mm Y-axis travel: 500 mm Z-axis travel: 610 mm Machine table: 1,600 x 550 mm, 10 slots, 12H8, 50 mm spacing XYZ positioning accuracy (ISO 230-2): A = 0.005 mm / R = 0.003 mm Electrical connection: 400 V 3P+N+E / 50 Hz / 63 A (T) Standard Equipment - Feed rate range: 1 – 30,000 mm/min (standard) - Automatic tool changer, operator side, main time parallel loading incl. Fehlmann extended tool management on TNC 640 - Direct linear measurement system with pressurized air in XYZ - Pressurized air cleaning with activated carbon filter - Coolant system with chip drawer and fine-chip filter insert, coolant spray gun, chip flushing, machine shutdown via M function - Cooled motor spindle and Y-axis drive Dkedpfx Ajy Ny A Dsnwjl - Spindle and thermal expansion compensation - Graphical machine diagnostics system via softkey - Drawer block, lower right - Interfaces: RJ45, USB, RS232 - 48-position chain magazine HSK-A63, double-gripper tool changer. Magazine accessible operator side, parallel to machining - Electronic handwheel HR 510 for TNC 640 - Active cooling system for motor spindle and Y-axis drive - Work area enclosure with polycarbonate safety windows; powder-coated; large-opening stainless steel sliding door at front/top for crane loading - Left side door with lockable polycarbonate windows - Chip flushing via machine bed - FEHLMANN cycle package Special Equipment - Automatic length compensation of the milling spindle via direct measuring system - Tool clamping system HSK-A63 - Leakage sensor to monitor coolant supply through spindle - Automatic right-side enclosure door for PICOMAX 95 - ProfiNet robot interface to PICOMAX as per Fehlmann interface description for customer-specific robot integration - Coolant system 700 l, BF/HD80, with through-spindle cooling, 80 bar, and chip conveyor - Emulsion and oil mist extractor system for work area; programmable operation via M function: on, off, intermittent - 3D probing system Blum TC52LF incl. spindle adapter HSK-A63 - LaserControl Blum LC50-DIGILOG for tool measurement and monitoring D 0.02 – 120 mm - Reference tool HSK-A63, Ø 8 mm - FEHLMANN 5-axis cycle package Automatic Indexing & Swivel Unit ATS 200 D - with Schunk TANDEM center vise KSP100 Automation – Unirobot pro Unirobot M-20iA-10P pro Robot: Fanuc 6-axis industrial robot - Manipulator: FANUC M-20iA - Max. payload: 20 kg - Teach pendant Safety fence system uniprotect Drawer system incl. workpiece carrier ALB - 10 pneumatic drawers with workpiece carriers (400 x 600 mm) FMB quick-change head Workpiece detection via light barrier Profinet interface Robot cell incl. program creation - Double gripper system Gripper modules: SCHUNK JGP 100-1 Max. workpiece weight: 3.3 kg All information subject to change. A demonstration is possible at any time in our showroom.

Condition: used, Year of construction: 1998, functionality: fully functional, Travel X/Y/Z: 1800mm/850mm/750mm Spindle nose to table distance: 200mm-950mm Spindle center to column distance: 920mm Table dimensions X/Y: 2000mm/800mm Max. table load: 2200kg Tool holder: NT50 Speed: 6000 rpm Djdpfx Aey N Suxonwokl Feed: 5m/min Rapid traverse: 12m/min Machine dimensions X/Y/Z: approx. 5700mm/3850mm/3350mm Weight: approx. 16,500kg Control: Heidenhain Operating hours: approx. 51,000h Spindle hours: approx. 26,000h Documentation available On-site inspection possible.

Condition: used, Year of construction: 2013, x-travel 635 mm y-travel 510 mm z-travel 460 mm control Sinumerik 840 D SL Siemens Dkodpfxeym Dz Rs Anwel turning speed range - main spindle 20 - 10.000 min/-1 power capacity - main spindel 13 / 9 kW tool taper SK 40 DIN 69871 max. Torque 83 / 57 Nm tension force 8 kN table surface area 790 x 560 mm number of T-slots 4 + 1 T-slot - distance 100 mm T-slot - width 4x 14H12 / 1x 14H7 mm max. table load 600 kg table height over floor 720 mm distance spindle nose and table 120 - 580 mm number of toolpositions 30 pos. Max. mould width 80 / (130) mm max. tool length 250 mm max. tool weight 6 kg max. total weight 80 kg change-time tool to tool 1,6 sec change-time chip to chip 6,0 sec rapid traverse 30 m/min feed speeds 1 - 20.000 mm/min Feed force max. 5 kN total power requirement 28 kVA weight of the machine ca. 3,8 t dimensions of the machine ca. 3,5 x 4,0 x 2,7 m CNC - MachiningCenter Vertical DECKEL MAHO - DMC 635 V New Design - ShopMill - WITHOUT perforated plate - WITHOUT clamping device - WITHOUT tools

Condition: used, Year of construction: 2006, x-travel 450 mm y-travel 330 mm z-travel 350 mm control Heidenhain iTNC 530 turning speeds 42.000 U/min tool taper HSK 40 E table surface area 470 x 400 mm T-slots 5 max. table load 500 kg Number of working hours 51993 h spindle hours 13858 h total power requirement 15 kW In our assessment, the machine is in good used condition and can be inspected under power by appointment. Dsdpfxjy Nn Ete Anwskl Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, CNC Vertical Machining Center FEHLMANN Type PICOMAX 60 CNC Control System: HEIDENHAIN TNC 426 Serial No.: 14599641 Year of manufacture: 1999 Travel paths X: 500 mm, Y: 350 mm, Z: 610 mm Feed rate: 1 - 20,000 mm/min Rapid traverse: 20 m/min Feed force: 12,000 N Table clamping surface: 920 x 380 mm T-slots: 7 pcs, 12-H8 mm Table load capacity: max. 250 kg Table height: 1004 mm Distance spindle nose - table: 94 - 704 mm Overhang spindle - column: 405 mm Spindle speed: 50 - 18,000 rpm, stepless Spindle drive: 10.2 kW (60% duty cycle) Max. torque: 70 Nm (up to 1240 rpm) Spindle taper: SK 30 / DIN 69871A Pull stud: DIN 69872 Drilling capacity in steel: 25 mm Dsdsy N Du Djpfx Anwokl Milling capacity in steel / aluminium: 100 / 700 cm³/min Thread cutting in steel / aluminium: M20 / M24 Tool changer: 24 positions Tool change time: approx. 6 sec. Chip-to-chip time: approx. 8 sec. Control: Heidenhain TNC 426 Power supply: 400 Volt, 50 Hz Connected load: 20 kW - Electronic handwheel Heidenhain HR410 - 3D probe Renishaw MP12 - Tool measurement system - TFT display - Direct path measuring system - Coolant system (200 liters, lateral) - Spindle cooling unit (lateral) - Central lubrication Vogel - Air supply: 6 bar, 40 - 200 l/min - Oil mist extraction - Operating hours: - Control on: 97,000 h - Machine on: 80,000 h - Program run: 42,000 h Required space (L x W x H): 2,000 x 1,700 x 3,000 mm Weight: approx. 3.2 t Good condition

Condition: used, Year of construction: 2001, controller model: Siemens 840D, 1 CNC 5-axis vertical machining center, make Stama, type MC 535/S, with fixed rotary table, SK-40, 42-tool magazine, tool breakage control, year 2001, machine no. 5351126, Siemens 840 D control, with Knoll filter unit type VRF 300/800, with chip conveyor Knoll type 340 K-1/100. Dkedpfx Ansy Nb Syewjl

Condition: used, Year of construction: 2001, x-travel 630 mm y-travel 500 mm z-travel 500 mm control Heidenhain TNC 430 spindle speed: 10000 U/min power capacity - milling spindle 13/9 kW feed 30 m/min rapid traverse 30 m/min no. of workpieces in the magazine 24 Stück tool taper SK 40 table surface area 800 x 500 mm table load 0,5 t Overall size 1,9 x 3,3 x 2,6 mm weight of the machine ca. 4500 kg Used vertical machining centre in good condition. - external eletronic hand wheel Dodpfx Anoy I A Umowekl - coolant system - servo tool magazin

Condition: good (used), Year of construction: 2007, functionality: fully functional, Year of manufacture 2007 Fanuc control system Quaser 1500/750/750 Dksdpfoy I Dpxsx Anwjl

Condition: like new (used), Year of construction: 2021, operating hours: 694 h, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 660 mm, torque: 979 Nm, controller manufacturer: Heidenhain, controller model: TNC640, spindle speed (max.): 6,000 rpm, operating hours of spindle: 694 h, coolant supply: 20 bar, spindle nose: SK50, number of slots in tool magazine: 32, Equipment: chip conveyor, documentation/manual, Hartford HCMC 1682 – Heidenhain TNC640, used – Year of manufacture 2021 – low hours! Hartford vertical CNC machining center equipped with Heidenhain TNC640 control, oversized precision flat guides in X, Y, and Z axes, moveable clamping table, and a powerful main spindle with SK50 tool holder. The machine features a closed cooling circuit for the spindle and an automatic two-stage gearbox, spindle speed n = 10–6,000 rpm, max. power Pmax = 38 kW, max. torque Mmax = 979 Nm, a 32-position tool magazine with quick-change arm, and an ergonomically optimized work area enclosure. The enclosure has electronically monitored front sliding doors with inspection windows, as well as loading/unloading access to the tool magazine from the rear. Dkodpfoy I Uzrsx Anwol Spindle: SK50, 38 kW, max. 979 Nm / max. 6,000 rpm Air cooling with compressed air nozzle at the spindle nose, cooling via M-function is programmable. Working area: X-axis, longitudinal: 1,600 mm Y-axis, lateral: 820 mm Z-axis, vertical: 660 mm Clamping table size: 1,750 x 820 mm Max. table load: 2,200 kg T-slots: 5 units T-slot spacing: 150 mm T-slot width: 18 mm Tool magazine: 32 positions Tool diameter: Ø 125 mm Max. tool length: 350 mm Max. tool weight: 20 kg Cooling system: Coolant: External coolant supply nozzles installed at the spindle nose (vertical slide). Coolant returns via two transverse and one longitudinal conveyor into the coolant tank. The coolant is pumped from the tank as required (via M-function or switch on the control panel) through the nozzles. Mechanical sieves are provided in the coolant tank for coolant filtration. Optional: For internal coolant supply (ICS), a high-pressure pump with a simple filter system is available. When ICS is activated, coolant is pumped from the tank through the high-pressure pump and filter system. Electronic handwheel Oil skimmer in the cooling system Blow-off and rinse guns Chip conveyor Automatic wireless 3D probe (Renishaw) for workpiece probing Automatic tool breakage control (Renishaw) The machine has only been used for a single job. As that order is no longer present, the machine is surplus to requirements. This is a very robust machine with high spindle performance – ideal for heavy-duty machining operations. The machine can be inspected under power at its current location. Note: The clamping devices shown in the pictures are not part of the delivery! Price: ex works Dismantling, transport, and commissioning can be offered on request!

Condition: used, Year of construction: 2016, Technical details: x-travel: 1000 mm y-travel: 610 mm z-travel: 600 mm table-size: 1150 x 600 mm table load capacity: 1000 kg rapid traverse X- and Y-axis: 24 m/min Dksdow Hg Syopfx Anwjl rapid traverse Z-axis: 24 m/min spindle taper:: SK 40 spindle turning speed range: 10.000 1/min spindle drive: 15/22,5 kW tool change unit: 30 Pos. CNC-control: SIEMENS 828D operate shopmill distance spindle nose and table: 110 / 710 mm weight of the machine ca.: 7 t dimensions of the machine ca.: 3,2 x 2,2 x 2,7 m vertical machining center, - internal coolant supply 30 bar - chipconveyor - cartridge filter - flat tracks - el. handwheel - prepared for 4th axis - 3D touchprobe RENISHAW OMP 60 - indirect measuring system - accessories (approx. 30 pcs. SK 40 toolholders incl. 2 racks, chip tray) approx. 6.000h "spindle on" *

Condition: excellent (used), Year of construction: 2007, Controller Mitsubishi 64S Travel X/Y/Z 600 x 400 x 460 mm Table size 700 x 410 mm Table load capacity 250 kg Spindle speed 12,000 min⁻¹ Dodpfoy N D Hgjx Anwjkl Tool magazine for 24 tools, BT 40 Internal coolant 20 bar Exhaust system Chip conveyor
