Used Internal Grinding Machines for sale (70,785)

Condition: excellent (used), Year of construction: 1979, Kapp AST‑305B – Technical Specifications Machine type: automatic hob and gear cutter sharpening machine Year of manufacture: circa 1979 Machine function: resharpening of hobs, spiral or straight gash cutters; wet or dry grinding Maximum tool diameter capacity: 12 inches (300 mm) Maximum tool length between centers: 27 inches (700 mm) Ledpfxjwwkt Aj Ab Tshc Maximum table traverse: 21.56 inches (550 mm) Maximum grinding wheel diameter: 12 inches (300 mm) Maximum center height: 6.1 inches (155 mm) Table speed (infinitely variable): – deep grinding: 30 to 1000 mm/min – surface grinding: 3 to 16 mm/min Flute lead angle range: 0° to 45° Flute lead range: selectable, up to 24‑inch to zero or 12‑inch to zero Grinding spindle speed: 2200 rpm (optional 1000–4000 rpm) Axial grinding spindle adjustment: 16.54 inches (420 mm) Vertical grinding head adjustment: 11.81 inches (300 mm) Spindle taper: Morse 4 or steep taper 40 Preselectable single in-feed: range 0 to 9999 (units) Machine dimensions: length 118 in × depth 82 in × height 93 in (≈3000 × 2080 × 2360 mm) Machine weight: approximately 7,500 lbs (3,000 kg) Control system: originally manual/analog, often upgraded with Allen‑Bradley PLC

Condition: like new (used), Year of construction: 2023, machine/vehicle number: 153, functionality: fully functional, operating hours: 100 h, Wide belt grinding machine for grinding steel sheets. Working width 1300 mm Lhodpfx Aeylbi Aob Tsc Working height from 0.5 to 160 mm Max. material deflection 0.3 mm/m Steel brush diameter 200 / 300 mm Felt brush diameter 200 / 300 mm Grinding wheel diameter 150 mm Number of grinding wheels 12 Grinding belt length 1900 / 2200 mm Grinding belt speed 18 m/sec Disc rotation speed 12 m/sec Rated voltage 400V Motor power 15 kW Air requirement 6 bar Air consumption 20 - 1100 NL/min Extraction pipe diameter 2 x 150 mm Noise level 96 dB Dimensions L x W x H: 1600 x 1900 x 2200 mm Weight 1800 kg (with (two units)

Condition: ready for operation (used), grinding length: 457 mm, grinding width: 152 mm, total height: 504 mm, grinding wheel speed: 2,640 rpm, Equipment: CE marking, documentation/manual, JONES & SHIPMAN 540 X Surface Grinder Grinding capacity: 152 x 457 mm Standard wheel dimensions: 200 x 20 x 31.75 mm Spindle speed: 2,640 rpm Machine complete with magnetic table 360 x 150 mm Wheel dresser Ledpsyi Trdefx Ab Tshc Coolant tank Operation and maintenance manuals CE declaration of conformity

Condition: good (used), Year of construction: 1990, Hydraulic Surface Grinding Machine with Automatic Vertical Feed Max. grinding length: 670 mm Max. grinding width: 280 mm Max. grinding height: 400 mm Table speed, longitudinal: 2 – 35 m/min Table speed, cross: 0.3 – 40 mm/stroke Rapid traverse: yes Grinding wheel dimensions: 300 / 76 x 40 mm Drive power: 4 kW Lhsdjf Um Rajpfx Ab Tsc Machine dimensions (L x W x H): 2000 x 1850 x 2000 mm Machine weight: 2300 kg Hydraulic & electrical unit dimensions (L x W x H): 1200 x 800 x 2000 mm Hydraulic & electrical unit weight: 650 kg Accessories / Special features: • Permanent magnetic chuck 630 x 200 mm • Automatic vertical feed with digital display • Manual dresser • Coolant system • Separate hydraulic unit • Grinding wheel • Machine leveling elements The following works have been carried out by us: o Hydraulic cylinder for table stroke re-sealed o New filters installed in hydraulic unit o Cross feed handwheel adjustment rebuilt with new bearings Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: ready for operation (used), Year of construction: 1999, Immediately available ex location: Universal cylindrical grinding machine TOS Face, internal as well as plunge, and external cylindrical grinding between centers Model BHU 32 A Year of manufacture: 1999 Very few operating hours Internal grinding device Center height: 160 mm Grinding diameter: 320 mm Grinding length: 1500 mm Workpiece weight between centers: 250 kg Headstock speed: 1230 rpm Table feed rate: 0.005 – 5 m/min Drive power: 14 kW Lhedpeymcniofx Ab Tec Workpiece headstock with 3-jaw chuck, 200 mm diameter Spindle speed: 12 – 400 rpm in 16 steps Grinding spindle head swiveling left/right Internal grinding spindle speed up to 16,000 rpm Belt filter system Numerous accessories – see pictures Weight: 5.5 t Offered at EUR 12,500.—plus VAT ex location

Condition: ready for operation (used), Year of construction: 1972, Immediately available from university: Hydraulic horizontal surface grinding machine Blohm, type HFS 204 A, year of manufacture 1972. Grinding length 400 mm, grinding width 220 mm, X travel 500 mm, installation height (grinding wheel to table) 520 mm. Automatic feed, weight 2.5 t, magnetic chuck, coolant system. Priced at EUR 2,750.— plus VAT ex location. Ljdpfx Aboyl T Tgs Tshc

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Model PSG 63 – UAN Year of manufacture 1988 Grinding length 600 mm Grinding width 320 mm Maximum workpiece height 500 mm Table longitudinal travel 750 mm Table cross travel 340 mm Grinding wheel diameter 350 mm Grinding wheel width 40 mm Spindle speed 1,500 rpm Rapid vertical traverse 400 mm/min Power 3.7 kW Automatic feed Magnetic chuck Coolant system Ljdpfx Absyl T Tas Tshc Weight 2,500 kg Price: €2,500 plus VAT, ex-site

Condition: ready for operation (used), Year of construction: 1977, Immediately available due to business closure: Reform Hydraulic Knife Grinding Machine Type AR 40 Type 40 Year of manufacture: 1977 Grinding length: 1000 mm Grinding head: 400 mm diameter Swivelling magnet: 1000 x 150 mm Ledpeyl T S Aofx Ab Tjhc Coolant system Grinding motor: 4 kW Weight: 2 tons Offered at a price of EUR 3,250—plus VAT, ex location.

Condition: good (used), functionality: fully functional, total height: 1,600 mm, total width: 700 mm, total length: 1,000 mm, grinding length: 250 mm, grinding width: 150 mm, grinding spindle speed: 3,150 rpm, disc diameter: 200 mm, Grinding stone diameter: 200 mm Clampingtable: 250 x 150 mm Diameter magnetictable: 120 mm Spindle speeds: 11 - 3.150 Rpm Lhedpoyg E Ursfx Ab Tjc Country of origin: Italy Machine LxWxH: 1.000 x 700 x 1.600 mm Machine weight: 250 kg

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Lisec double glazing line Left Right 2500 x 5000 mm sealnig robot 2021 installed 2022. Lsdpsyl Scysfx Ab Tohc

Condition: used, Technical details: Lhjdpfjwc A Snjx Ab Tec grinding length: 12000 mm grinding width: 2800 mm workpiece height: 2510 mm max. workpiece weight: 24.000 kg table surface area: 11990 x 2500 mm distance between columns: 2820 mm cross rail adjustment: 2510 mm table feed: 1 - 40 m/min total power requirement: 110 kW weight of the machine ca.: 151 t dimensions of the machine ca.: 32,5 x 9 x 6,73 m .....machine is in top condition for high precision work! with CNC SIEMENS 840 D 1 universal grinding head, 22 kW swivelling of the grinding spindle +/-110° grinding wheel dimension 700 x 130 mm vertical stroke 1000 mm with dressing unit 1 surface grinding head, 30 kW grinding wheel dimension 600 x 150 mm vertical stroke 230 mm with dressing unit coolant and filtering unit diverse grinding wheel flanges *

Condition: used, Year of construction: 1980, Technical details: Ledpewy Ri Nefx Ab Tjhc grinding diameter: 380 mm grinding length: 1000 mm centre height: 180 mm grinding wheel diameter: 400 mm max. workpiece weight between centres: 250 kg total power requirement: 10 kW weight of the machine ca.: 4,1 t dimensions of the machine ca.: 3 x 2 x 1,6 m with internal grinding attachment with fixed and swivelling headstock with coolant tank *

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, spindle speed (max.): 7,000 rpm, type of input current: three-phase, grinding wheel diameter: 200 mm, overall weight: 4,650 kg, grinding length: 350 mm, center height: 190 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, travel distance X-axis: 490 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 660 mm, grinding spindle motor power: 24,000 W, workpiece diameter (max.): 320 mm, input voltage: 400 V, nominal power (apparent): 35 kVA, spindle nose: ISO 50, swivel angle A-axis (min.): 360 °, CNC tool grinding machine WALTER Helitronic Power Production TECHNICAL CHARACTERISTICS: CNC control: HMC 500 Software installed: Tool Studio 2.1 R4 Number of axes: 5 Height of centers: 190 [mm] Stroke X: axis 490 [mm] Resolution X axis: 0.00001 [mm] Stroke Y axis: 320 [mm] Resolution Y axis : 0.00001 [mm] Stroke Z axis: 660 [mm] Resolution Z axis: 0.00001 [mm] Traversing feeds X, Y and Z axes: 15000 [mm/min] A axis: 360 [°] C axis: +/- 200 [°] Resolution C axis: 0.0001 [°] Max. workpiece lenght: end face grinding: 320 [mm] Max. grinding length: 350 [mm] Max. grinding diameter: 320 [mm] Grinding spindle attachment: NCT Grinding spindle diameter: 80 [mm] Grinding wheel max. speed: 7000 [rpm] Grinding spindle motor power: 24 [kW] Max. diameter grinding wheel: 200 [mm] Internal workpiece spindle nose: ISO 50 Workpiece spindle max. speed: 60 [rpm] Total power required: 35 [kVA] Weight: 4650 [Kg] EQUIPMENT INCLUDED: x1 TRANSOR 12290-800A filtration unit x1 MTA oil chiller model TAE 015 x1 DSL oil mist extractor model AES-GAMMA 30 x1 RENISHAW part probe x1 disc-type tool loader 40 positions x1 SCHUNK gripper x2 grinding wheel arbor adapters x1 fire protection system - to be inspected by the buyer through a certified organization x1 electrical schematic manual x1 Service Instructions manual LICENSED WALTER WINDOW MODE (WWM) PACKAGES: - Package 001 (cylindrical mills) - Package 002 (tapered mills) - Package 003 (drills) - Package 004 (step drills) - Package 006 (woodwork tools) - Package 013 (reamers) - Package 015 (insert seats) Lhsdpeyh Nf Iefx Ab Tsc - Package 016 (warmup program) - Package 027 (flexible program) - Package 090 (loader package) - Package 091 (acm) - Package 098 (loader package) - Package 099 (loader package) - Package 100 (reference data m.) - HELICONE (flute calc. conical.) - HELIDRILL (flute calc. drills) - HELIFLUTE (flute calc. cyl. mill.) - MCS (machine control .) - SCHEIBE (wheels menu) - TS_ADVANCED (toolstudio (v1.0-v.) - TS_STANDARD (toolstudio (v1.0-v.) - TS_STEPTOOLS (toolstudio (v1.0-v.) LICENSED TOOLSTUDIO OPTIONS: - Tool Studio 2.0 server/machinecontrol - Tool Studio 2.0 standard license - Tool Studio 2.0 advanced license - Tool Studio 1.9 upgrade options - Tool Studio 2.0 upgrade options - Option steptools - Option profile light (contour roughing ...) - Option calibration w/ touch probe - Option drills Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed.

Condition: like new (used), functionality: fully functional, Year of construction: 2017, operating hours: 2,600 h, control type: CNC control, controller model: Fanuc 32 C, Equipment: documentation/manual, Standard programs such as parameter settings Dressing settings Speed settings Program management settings Limitation of travel distances x + y Basic parameter settings Grinding wheel management program Warming-up cycle program Surface plunge grinding program Measuring program 15 kVA transformer Full enclosure Meister G3 Spindle upgrade to 3.7 kW, disc 225 mm ETHER interface for network connection Control module with extended memory Fanuc Macro B option Program creation for batch programs Programmable spindle speed WinWop program for contour creation (Windows) WINWop program for error compensation WinWop postprocessor CGS Complete Grinding Solutions software Option Dressing Swiveling profile dressing device Diamond dressing wheel Pre-dressing device VPA 100 L Diamond wheel 100 mm for pre-dressing device Regrinding package diamond wheel G3 / W Option – Clamping and Balancing Magnetic chuck 400 x 200 400 mm stop bar with prism Fully automatic balancing device, size 1 Lhsdpew I Tt Ssfx Ab Tsc Grinding wheel flange for G3, bore 51 mm Option Filter Systems Belt filter system 175 l Extraction unit for emulsion mist 500 Inquiries only from Europe, preferably the EU.

Condition: good (used), Year of construction: 1972, Slideway grinding machine WMW SFBZ 2200/6000 Manufactured by WMW Germany in 1972 Lhjdpfx Absw U A Rmj Tjc Main technical data: Table size: 2240x6000 mm Max. grinding width: 2200 mm Max. grinding length: 6000 mm Max. grinding height: 2000 mm Max. workpiece weight: 15,000 kg Machine weight: 130 tons For more information, please contact us.

Condition: good (used), Year of construction: 2001, Machine-Details: Stock-No. 1022-2276 Type of machine Surface Grinding Machine - Vertical Make REFORM Type AR 42 Typ 19 CNC Year of manufacture 2001 Type of control CNC Storage location Monheim (Germany) Country of origin Germany Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details: grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW Lhjdpfsyhcxqox Ab Toc weight of the machine ca. 50,0 t Additional information: Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: good (used), Year of construction: 2008, Machine-Details: Stock-No. 1022-E06336 Type of machine Surface Grinding Machine - Horizontal Make ABA / Z & B Type MULTILINE 2507 CNC Year of manufacture 2008 Type of control CNC Storage location Germany Country of origin Germany Delivery time Short-dated Freight basis Ex site, without dismantling and loading Technical details: grinding length 2000 mm grinding width 850 mm distance spindle center to table 900 mm control Siemens 840 D Lodpfx Aoyhcwtsb Tehc total power requirement 155 kVA weight of the machine ca. 15 t dimensions of the machine ca. 8815 x 4185 x 2963 mm Additional information: CNC Precision Surface and Profile Grinding Machine Technical Specifications: Grinding length 2000 mm Grinding width 850 mm Travel, transverse 750 mm Distance from table to spindle center 900 mm (or 800 mm with intermediate plate) Magnetic plate size 2000 x 700 mm Table load without magnet 3500 kg Table speed 60 m/min. Spindle drive 26 kW Grinding wheel dimensions 500 x 150 x 203.2 mm Grinding wheel peripheral speed 35 m/s Equipment: 3-axis contouring control Siemens 840 D Grinding programs: Full-cut grinding Face grinding Plunge grinding Path grinding X/Y-axis and Y-Z-axis Profile grinding Automatic program sequence with roughing, finishing, fine finishing and spark-out grinding. Multiple plunge grinding for economical production Surface grinding with continuous, continuously programmable cross feed Grinding wheel calibration Plunge/step grinding Face grinding Dressing in the grinding cycle with lift-off amount Fully automatic compensation of dressing amounts Tool management AC servo drives with ball screw and absolute measuring system in the X, Y, and Z axes Preloaded precision roller guides in the X, Y, and Z axes with linear guides Portable electronic handwheel Automatic belt filter system Coolant heating Electro-permanent magnetic chuck Fully enclosed Direct measuring system in the vertical axis Temperature-controlled machine bed for consistent accuracy Linear motor in the X-axis, table speed max. 60 m/min. Swiveling control panel Continuous speed control of the grinding spindle Electrical linear measuring device for cross-travel adjustment with zero point setting in any position, resolution 0.001 mm Electro-mechanical locking via position control of the headstock in the cross direction for profile and plunge grinding Mechanical extraction of coolant mist TAG table dresser Pre-profiling dresser VPG 190 Diamond grinding wheel, 190 mm diameter Software program for pre-profiling dresser VPG Rough profiling (roughing) CNC table profile dresser TAD 190 Profile depth max. 45 mm Contour accuracy +/- 0.0025 mm Swivel angle +/- 65 degrees Max. dressing speed 210 mm/min. Diamond wheel for table dressing machine TAD 190 Regrinding package for diamond wheel Intermediate plate for raising the magnet WinWop profiling software Import of CAD profile data SP 60 JOB Listing expansion package Additional holes for the magnet clamping plate to facilitate removal of workpieces using compressed air Ghost shift circuit for shutting down the machine after the end of the program

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, CNC Tool Grinding Machine Walter Helitronic Power FH, Year of manufacture: 2015 Fanuc control system with cylindrical pallet loader, pallets from 4 mm to 25 mm 8-position disc changer, electrostatic mist collector fire extinguishing system, Ledpeyh Dl Nsfx Ab Tehc Software: Walter Window Mode and Toolstudio, Software packages: 001, 002, 003, 016, 017, 026, 090, 091, 098, 099, 032, Helicone, Helidrill, Heliflute, NC-Mode, Power-IMS, Toolstudio_Standard, with preparation for hydraulic unit (steady rest), The grinding spindle (single spindle) is directly driven and equipped with an oil cooler. The hollow shaft motor for the A-axis operates at a speed of 0-750 rpm. The C, X, Z, and A axes were overhauled in 2022.

Condition: used, Year of construction: 2004, functionality: fully functional, BAVELLONI GEMY V10 – Year 2004 Lodjykpv Uopfx Ab Tehc Straight line edger 10 spindles Thickness: 3 – 51 mm Variable angle: 0 – 45° Minimum sheet height: 70 mm Working speed: 0.5 – 5 m/min Pneumatic supply: 8 bar Power: 27 kW

Condition: used, Rotary indexing thread tapping machine, 8-station rotary table. 1 inspection station, 1 vertical and 1 horizontal thread tapping unit. With guide bush 1 mm pitch Chiron, thread tapping unit with guide bush 0.7 mm pitch, M4. One discharge station, coolant system. Ledpfx Aboyl Ntpj Tehc

Condition: good (used), Year of construction: 2004, Ref. -No.: 10629 Manufacturer: MICHAEL DECKEL Type: S20 Turbo Year of construction: 2004 Lodpfx Aboyhvu Ej Tshc Type of control: CNC Storage location: Halberstadt Country of origin: Germany Workpiece Diameter: 250 mm Max. Grinding length: 340 mm Max. Workpiece Weight: 50 kg Grinding wheel diameter (max.): 150 mm Turning Speeds: 8000 RPM Workpiece holder: SK 50

Condition: new, The RSM 1500 C, a precision cylindrical grinder from KNUTH, is designed for long and heavier workpieces within the Conventional Cylindrical Grinders category. This robust machine features a large machine bed that supports workpieces up to 2000 mm in length and 320 mm in diameter, ensuring maximum accuracy and stability. Wide, precision-ground guideways contribute to reliable performance, while the grinding spindle with hydrostatic bearings guarantees high precision and surface quality. The powerful motor allows for continuous operation, making it ideal for both individual parts and small series production. Operators can benefit from adjustable dwell times and precise micro-feed control, enhancing the grinding process. With an integrated internal grinding device, the RSM 1500 C offers exceptional flexibility. If you're looking for a reliable solution for cylindrical grinding, request a quote or buy now to experience the efficiency of this powerful Conventional Cylindrical Grinder from KNUTH. Ledpfxeu E N Dno Ab Tehc

Condition: new, The HFS 40100 F Advance is a state-of-the-art Conventional Surface Grinder in the Grinding Machines category, offering a robust solution for precision machining. Designed with a cast-iron frame that ensures superior rigidity and torsional strength, this machine delivers exceptional machining quality. Equipped with a powerful coolant pump and an easily accessible enclosure, it guarantees a clean workspace while the preloaded precision bearings optimize grinding performance. One of its standout features is the magnetic clamping plate, which includes a built-in demagnetizing function to enhance efficiency. The advanced Siemens technology facilitates easy programming through a user-friendly touchscreen, allowing for high precision across different operations. Perfect for those who require more than conventional options but find CNC overwhelming, the HFS 40100 F Advance is ready to meet your grinding needs. Don't hesitate to request a quote for this exceptional Conventional Surface Grinder and experience the efficiency of advanced machining technology. Lhjdpju E Ivvofx Ab Toc

Condition: new, The HFS 2550 F Advance is a remarkable addition to the range of Conventional Surface Grinders, showcasing the latest advancements in the KNUTH line of grinding machines. This robust machine features a cast-iron frame that ensures superior rigidity and torsional strength, combined with precision guideways for unmatched machining quality. Users will appreciate the advanced Siemens technology that facilitates easy programming and operation via a user-friendly touchscreen. The HFS 2550 F is designed for those who find conventional machines insufficient but CNC technology overly complex. With a powerful coolant system and integrated hydraulic functions, it provides optimal performance and reliability. This machine comes standard with a magnetic clamping plate, an automatic central lubrication system, and extensive equipment for enhanced versatility. For those considering investment in a reliable surface grinding solution, the HFS 2550 F Advance stands out in both the Conventional Surface Grinder category and the broader segment of Grinding Machines. Request a quote today and experience the precision and efficiency that KNUTH delivers. Lhjdpfxouyig Ee Ab Tec

Condition: new, The HFS 4080 F Advance is a remarkable Conventional Surface Grinder from KNUTH, designed to elevate precision machining within the realm of Grinding Machines. This advanced surface grinding machine is built on a robust cast-iron frame, ensuring superior rigidity and quality while featuring precision guideways for excellent machining outcomes. Enhanced with Siemens technology, including a user-friendly touchscreen, the HFS 4080 F Advance offers intuitive programming and automatic processing of roughing and finishing parameters, perfect for users seeking more than conventional solutions without venturing into full CNC systems. With extensive standard equipment such as a large magnetic clamping plate, automatic central lubrication, and a powerful coolant system, this grinder guarantees exceptional efficiency and minimal maintenance. The preloaded precision bearings and high-quality servo motors ensure maximum reliability and repeatability, making it an ideal choice for demanding manufacturing environments. For those interested in enhancing their operations, you can request a quote for the HFS 4080 F Advance today and experience the benefits of a top-tier Conventional Surface Grinder. Lhsdpfx Abjq I Nfps Tsc
