Used Measuring Column for sale (11,109)

Year of construction: 2010, condition: excellent (used), Measuring column in a suitable transport case Height: 500 mm Diameter: 120 mm Weight: 37 kg Kodpfofdzvaox Aafedt

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, center width: 1,200 mm, overall weight: 7,000 kg, travel distance X-axis: 500 mm, travel distance Z-axis: 800 mm, controller model: Bosch Rexroth MTX, TECHNICAL DETAILS Center distance: 1,200 mm Max. outer diameter: 350 mm Max. workpiece weight between centers: 50 kg Cross slide, X-axis Travel, X-axis: 500 mm Max. speed: 30 m/min Resolution: 0.1 µm Longitudinal slide, Z-axis Travel, Z-axis: 800 mm Max. speed: 30 m/min Resolution: 0.0005–0.1 mm Multi-function head, B-axis Swivel range: -45° to +225° Swivel time for 180°: < 3 s Positional accuracy: 0.0002° Repeatability: 1″ Resolution: 0.001° External machining Max. machining length: 750 mm Peripheral speed: 50 corundum / 80 CBN Drive power: 15 kW Max. grinding wheel dimensions: Ø 400 × 50 × 152.4 mm Internal machining Max. bore diameter: 250 mm Max. bore depth: 235 mm Drive power S1: 1.8–7.5 kW Speed range: 30,000–50,000 rpm Workpiece spindle, C-axis Max. speed: 1,500 rpm Drive power: 1.8 kW Drive torque: 90 Nm Resolution of measuring system: 0.001° Roundness accuracy: 0.8 µm Positional accuracy: 0.0001° Tailstock Quill stroke: 50 mm / 80 mm Quill diameter: 60 mm Bearing: hydrostatic Fine adjustment for cylindricity corrections: ± 40 µm 3-point steady rest Clamping range, diameter: 20 – 150 mm Coarse adjustment: 40 µm Fine adjustment: 2 µm Adjustability: stepless MACHINE DETAILS CNC control: Bosch Rexroth MTX Dimensions & Weight Dimensions (L x W x H): 2,850 x 2,470 x 2,290 mm Weight: 7,000 kg EQUIPMENT Kdedpfozwm Akox Aafst 3-point steady rest

Condition: ready for operation (used), Year of construction: 2007, pressing force: 28 t, stroke length: 200 mm, throat depth: 200 mm, installation height: 325 mm, working length: 835 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Press force: 28 t Bending length: 835 mm Travel range of the back gauge: 0 – 370 mm Stroke: 200 mm Distance between frames: 890 mm Support table: 200 x 275 mm Overhang: 200 mm Installation height: 325 mm Number of cylinders: 1 Working speed Press travel: 8-10 mm/s Kodpfezzkwgsx Aafedt Retraction: max. 35 mm/s Positioning accuracy: +/- 0.05 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,600 x 1,500 x 2,200 mm Total weight: 3,500 kg EQUIPMENT Operating manual Safety device Mechanical tool clamping (top) The height and weight of the asset must be taken into account when selecting the transport vehicle. A forklift is available for loading. If the asset is not collected on time, a storage fee of €20.00 per lot and per day (or part thereof) will be charged. The fee must be paid before collection. The sale is made without any warranty or guarantee. The information on the technical data comes from the original offer. No guarantee is given for typographical or measurement errors. If in doubt, please compare the information with the photos provided or inspect the goods on-site before the end of the auction.

Condition: used, For sale is a high-quality TESA Micro-Hite 3D height gauge in a large, motorized version, offered as a complete measuring workstation. This system combines precise height measurement with extended 2D/3D coordinate functions, making it ideal for use in quality assurance, metrology, and production. Particularly noteworthy is the extensive range of accessories and the existing PC connection with printing capability, which allows measurement reports to be created and documented directly. Technical specifications: Manufacturer: TESA (Switzerland) Model: Micro-Hite 3D Type: Height gauge / 3D-capable measuring column Measuring range: approx. 600 mm (large version) Resolution: up to 0.0001 mm (0.1 µm) Drive: motorized adjustment Measuring system: digital / electronic Data output: interfaces for PC / peripherals Measuring functions: Height measurement Internal and external measurement Diameter measurement Distance measurement 2D/3D point measurement Geometry and position calculations Equipment: Granite measuring plate Stable machine base Motorized measuring column Integrated control unit External PC workstation (monitor, computer, input devices) Printer for report output Accessories: Extensive set of measuring probes (ruby tips, extensions, etc.) Tool holders and fixtures Accessory case / wooden box The measuring device has already been disassembled and packed. Ksdpsy Tkg Uofx Aafodt

Condition: ready for operation (used), Taylor Hobson Form Talysurf PGI 820 Measuring Instrument Measuring range: 8mm Resolution: 3.2mm Motorized column: 450mm Feed unit: 200mm Roughness calculation Waviness calculation Contour measurement Accessories: Stylus Calibration standard Witte cross slide table Base table PC & software You are welcome to visit us for a viewing. We can also arrange cost-effective shipping for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and check out our other offers. Ksdpfoz Dtttjx Aafodt The company names and trademarks mentioned are the property of their respective owners and are used solely for identification and description of the products. Deviations in technical data as well as errors in the description of the item may occur and are subject to change.

Condition: excellent (used), Year of construction: 2019, operating hours: 7,000 h, functionality: fully functional, MACHINE CONSTRUCTION: - Cast iron bed, spindle head, and saddle system developed through computer-aided design and analysis (CAD/CAE), ensuring high rigidity and vibration damping - Fully supported table guide in every working position - X-axis (table movement) on 2 precision cylindrical roller guides, supported by 6 runner blocks each - Y-axis with 2 precision cylindrical roller guides - Z-axis with hardened and ground guideways, with TURCITE-B coating - Guideway protection via metal telescopic covers - Hydraulic counterweight / balance system - CE conformity Axes: - Preloaded ballscrews with large pitch for long-lasting precision - Digitally controlled, liquid-cooled ballscrew on the X-axis - Gear-driven ballscrews, ballscrew nuts with centralized lubrication, and lifetime-lubricated bearings CONTROLLER & ELECTRONICS + CAPACITY: - High-speed CNC, 1 ms block processing time - Storage capacity: 120 GB SSD - Technology program memory: 100 GB SSD Kjdpfxjzzf Rus Aafjdt - Number of processor cores: 4 CNC operating system: - User interface operating system: Windows 10 - Technology program storage: WINDOWS file system - Total storage capacity (system program, PLC, parameters, technology program memory) on a single SSD - New user interface (40-00005216-00w) SCREEN: Color graphical LCD touchscreen COMMUNICATION: USB, Ethernet, EtherCAT MEASURING SYSTEM: - HEIDENHAIN absolute EnDat 2.2 - PROGRAMMING: ISO, myNCT TECHNICAL DATA: - X-travel: 2100 mm - Y-travel: 1500 mm - Z-travel: 1000 mm Distance from spindle nose to table surface: 200~1000 mm Distance between columns: 1650 mm Distance between table and gantry/crossrail: 1710 mm AXES: - Rapid traverse speed X / Y / Z axis: 20 / 20 / 15 m/min - Max. working speed: 10 m/min - Motor power: 4 kW ACCURACY (according to JIS6338): - Positioning accuracy: +/- 0.01 mm (In the entire working area!) - Repeatability: +/- 0.004 mm TOOLING: - Max. tool diameter / with adjacent tool omitted: 125 / 215 mm - Max. tool length: 400 mm - Max. tool weight: 20 kg - Optional tool taper: SK50 Accessories & Equipment: - Angle head (manual) - Chip conveyor - Coolant flush gun - 15 pcs of SK50 tool holders - Machine leveling feet - Manuals The machine is in good used condition and operates accurately.

Year of construction: 2014, condition: used, Empty weight: 4 kg Length: 78 cm Serial number: 22220 V251403 5-axis machining center comprising: - a NAKAMURA lathe, TYPE: NTMX, year: 2014, 5-axis dual-spindle + milling head. - a SAMSYS+ bar feeder, Model: M3000, year: 2014 - an LNS YOSHIDA chip conveyor Technical specifications: - capacity: - max turning diameter: 200 mm - Max turning length: 780 mm - Distance between centers: max 980 mm / min 210 mm - Bar capacity: 51 mm on both left and right - Chuck size: 165 or 210 mm - Axis travel: - X1/X2 slide travel: 570 mm / 130.5 mm - Z1/Z2/B2 slide travel: 1,297/658/770 mm - Y-axis travel: ±100 - Left/right spindle: - Speed: 5,000 rpm - Tool spindle: - Speed: 12,000 rpm - Tool type: CAPTO C4 - Number of tools in magazine: 24 - Max. tool diameter: 60 mm - Max. tool length: 180 mm - Max. tool weight: 4 kg - Indexing range: 190° - Turret: - Type: 12-sided drum turret - Number of indexing positions: 24 - Square tool size: 20 mm Kdjdpfx Ajzvccdeafet - Round tool size: 20 mm diameter - Spindle speed: 6,000 min⁻¹ - Floor dimensions: L 4,225 mm x W 3,015 mm x H 2,650 mm - Approximate machine weight: 14,500 kg Hours on the counter: approximately 3,622 h Sold with 1 cabinet and 2 workbenches, including contents Online auction held following the closure of the "Supadis" production facility in Le Plessis-Pâté (91), a company specializing in precision machining. This sale includes more than 100 lots, notably several 3-, 4-, and 5-axis CNC machining centers from “Matsuura,” “OKK,” “Biglia,” and “Nakamura Tome,” as well as a “Kasto Functional A” automatic saw. The lot also includes grinding machines, a “Cincinnati” column drill press, “Trimos” and “Mitutoyo” measuring columns, as well as numerous tools, workbenches, and inspection equipment. The sale also includes stocks of raw materials (steel, aluminum, titanium, “Inconel,” “PEEK,” copper, etc.), workshop equipment, compressors, shelving, and various material-handling equipment. Sale organized by Dome Auctions France, OVV No. 331-2026, auctioneer Blandine Camper. The online auction opens Tuesday 18 August and closes Thursday 24 September. Register your account via our website and place your bid. For viewings and inspections check the auction information on the website. Viewing day is on: - Tuesday 22 September Dome Auctions is an innovative auction platform dedicated exclusively to the industrial sector. By focusing on machinery sales from business closures, restructurings, and bankruptcies, we provide a trusted marketplace where buyers and sellers connect with confidence. Unlike general auction houses, Dome Auctions specializes in selling complete industrial assets directly from factories, ensuring quality and reliability. With a commitment to transparency, industry expertise, and tailored service, we streamline the sales process and maximize value for all parties. As online...

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: G0E 1075, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 460 mm, spindle speed (max.): 12,000 rpm, controller model: Mitsubishi 64S, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 600 mm Travel in Y-axis: 400 mm Travel in Z-axis: 460 mm Spindle speed: 12,000 rpm Tool holder: BT40 Kedozx Ahxopfx Aafedt Table size: 700 x 410 mm Maximum table load: 250 kg Number of tool magazine slots: 24 MACHINE DETAILS CNC control: Mitsubishi 64S Coolant pressure: 20 bar Dimensions & Weight Machine dimensions (L x W x H): 1,880 x 3,550 x 2,790 mm Machine weight: 4,300 kg Operating hours: The seller estimates the operating hours to be approximately 20,000 hours. EQUIPMENT Spindle cooling Chip conveyor Extraction system Electronic handwheel Renishaw measuring probe Ethernet interface Approx. 100 tool holders including cabinet

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 200008301032, measuring range X-axis: 400 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 350 mm, table width: 680 mm, table length: 855 mm, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item on time between October 7, 2026, and October 14, 2026! TECHNICAL DETAILS Measuring range X-axis: 400 mm Measuring range Y-axis: 500 mm Measuring range Z-axis: 350 mm Maximum workpiece weight: 280 kg Table width: 680 mm Table length: 855 mm MACHINE DETAILS Kdodpfx Aszu Ixueafot Dimensions & Weight Dimensions (L x W x H): 2,000 x 1,100 x 1,100 mm Total weight: 500 kg EQUIPMENT PC including accessories Calypso 2017 (Rev. 6.4.16)

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, overall weight: 980 kg, measuring range X-axis: 700 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 500 mm, Coordinate measuring machine Coord3 ARES NT 7.7.5 Year of manufacture: 2014 Motorized indexable head Renishaw PH10M hand controller: Renishaw MCU LITE-2 MPEe accuracy: 2.5 µm + L/300 Repetition accuracy: from 2.3 µm Measuring range: 700 x 700 x 500 (mm) Granite bed size: 1330x963.5x170mm Kedou E U Hbjpfx Aafsdt Software: TouchDMIS 5.2 + dongle The Z-axis support column is made of silicon carbide, which increases rigidity. DC servo motors, air bearings on all axes, free-floating linear scales with 0.1 µm resolution.

Year of construction: 2002, condition: good (used), functionality: fully functional, machine/vehicle number: 023116, Wenzel RS 1012 CNC 3D Coordinate Measuring Machine The Wenzel RS 1012 is a CNC 3D coordinate measuring machine (CMM) with a horizontal-arm design, engineered for the precise measurement of medium-sized to large workpieces, such as components and assemblies. The machine design is based on a stable cast iron or granite base plate serving as the measuring table, with a side-mounted guide system that allows for open loading from three sides. Kdedpfxezz Hyws Aafst Key Technical Components & Specifications Machine Type: Horizontal-arm 3D coordinate measuring machine (CMM) Manufacturer: WENZEL Präzision GmbH Model / Year of Manufacture: RS 1012 / 2002 Serial Number: 023116 Measuring Volume (X/Y/Z): 2,000 mm × 1,000 mm × 1,200 mm Probing system: Renishaw PHC10-3 PLUS (interface/control for PH10 motorized rotary-tilting head) Design: Horizontal-arm measuring machine (column-type CMM) with integrated base plate Measuring accuracy (MPE): 15.0 μm+ (L / 45.0 mm total maximum longitudinal measurement error in the measuring range is approximately 50.0 micrometers) Sensor system (standard configuration): Delivered without a PC Key Features of the RS Series High Flexibility: The machine generally does not require a special foundation and can be flexibly integrated into existing production and laboratory spaces. Barrier-Free Accessibility: Thanks to the horizontal arm’s lateral guidance, the measuring table is freely accessible, which facilitates the loading of heavy workpieces using a crane or forklift. Multi-sensor technology: In addition to tactile sensing systems (such as the TP20), the series can often be equipped by the manufacturer with optical line lasers or scanning sensors. “Everything from a single source: We’d be happy to offer you suitable bank financing for your project.” komplett-konzept.leasingo.de

Condition: used, Year of construction: 2015, functionality: fully functional, machine/vehicle number: SAA81E9S0112721, Technical characteristics: System Components - XR1 Evaluation Unit: PC-based system with MarWin software - SD26 Drive Unit: Skidless tracing system with motorized height adjustment - ST-G Measuring Stand: Granite base (500 × 300 mm) with manual column adjustment Measurement Capabilities - Tracing length: 1.75 mm, 5.6 mm, 17.5 mm (DIN/ISO); 1–16 mm (ISO 12085) - Tracing speed: 0.2 mm/s or 1 mm/s - Positioning speed (X-axis): 5 mm/s - Height adjustment (Z-axis): 7.5 mm motorized - Positioning speed (Z-axis): 2 mm/s - Measuring range: ±250 µm (±500 µm with extended probe arm) - Probe force: ~0.7 mN Probe System: BFW 250 (skidless, magnetic mount for fast change) Software & Evaluation - Supported parameters: R, P, W, Motif, D profiles - Standards: ISO, JIS, MOTIF (ISO 12085) - Features: Kdedpfx Aasxx R Rnsfjt - Over 80 surface parameters - Automatic cutoff and measuring path selection - Quick & easy measuring programs - PDF report generation - ASCII export and USB data transfer - Multi-user levels and calibration reminders Hardware & Interface - PC: All-in-one or industrial PC (optional) - Connectivity: USB and Bluetooth (for drive unit) - Display: Touchscreen interface with intuitive icons Accessories: - CT 120 cross table - Calibration set - Magnetic probe arm holder - Optional contour evaluation module Machine status: WORKING

Condition: used, Year of construction: 2021, functionality: fully functional, Dürr Ecopure VAR 2206 Thermal Oxidizer with Flue Gas Cleaning (2021) For burning liquid and gaseous waste streams including fluorinated gases, e.g. PFAS, and recovery of aqueous hydrogen fluoride Emissions limits SO2 ≤ 100 mg/Nm³ NOX ≤ 30 mg/Nm³ CO ≤ 50 mg/Nm³ CF4 ≤ 70 mg/Nm³ HF ≤ 1 mg/Nm³ NH3 ≤ 2 mg/Nm³ Comprising Direct fired thermal oxidizer Hot gas cooling and acid recovery Alkaline wet scrubber Honeycomb selective catalytic reduction deNOx system >1M cost spare parts Direct fired thermal oxidizer Including 2x natural gas combustion chambers and burners - High calorific liquid waste requires safe ignition supplemental hydrogen supply for acid formation - Gaseous waste streams injected via nozzles downstream and close to the burner - 1.5MW multi-fuel natural gas & liquid waste (minor fuel stream) burner with natural gas capacity up to 200Nm3/h - 1400C normal, 1540C max allowable temperature destruction of pollutants to reduce emissions with 3.28 MW thermal energy transfer - 2 seconds minimum residence time in combustion chamber at 1400C - 1,800mm combustion chamber internal dia. - Approx 300mm refractory lining - 2,400mm combustion chamber external dia. - 12,000mm combustion chamber internal length - 3.28MW maximum thermal capacity - 4,900Nm3/h, 60mbar, 14kW combustion air fans One chamber is active, the other one is on standby and can be prepared, repaired, or maintained. This allows minimizing shutdown and changeover time to only several days Wet scrubber hot gas cooling and acid recovery SGL Carbon Diabon HT-PQ 850 graphite pipe quencher - 6,000 Nm3/h capacity flow - 1,100 mm dia. - 2,000mm high - pumps SGL Carbon Diabon THX-RS falling film absorber shell & tube heat exchanger - 1,100mm dia. - 4,500mm tube length - 595 no. tubes - 22mm tube internal dia. - Graphite, carbon steel - pumps Quench vessel Kodpfez Ai Tpox Aafjdt - PP/FRP - 1,100mm dia. - Approx. 6,000mm high 2x Scrubber absorber columns, each - Shell FRP/PP - Internals PP - 1,000mm dia. - 11,000mm high - Pumps - Dosing station FRP 5m3 Emergency water tank - 1,600mm dia. - 3,000mm high - 3kW heating 2x Teblick 100,000L HDPE hydrofluoric acid tanks (2019) Honeycomb selective catalytic reduction deNOx system - 5,900Nm3/h, 130mbar, 42kW induced draft fan - 320 kW gas/gas heat exchanger - 500 kW capacity reheat burner - 1.2m deNOx honeycomb catalyst Clean gas outflow Stack with flow & temperature measurement Spare parts include - 200 items of sensors, pumps, valves, gaskets, joints etc. - Graphite quencher - Falling film absorber With the redesign and maintenance support of Dürr, the system could also - be adapted to other halogenated gases with bricks to be selected according to gas application - cope with the presence of VOCs or contaminated air - larger volumes with the addition of a small lance for 15kg/h liquid injection

Condition: not inspected (used), Year of construction: 2020, functionality: unexamined, machine/vehicle number: 71193, measuring range X-axis: 3,000 mm, total width: 500 mm, total length: 1,000 mm, total height: 1,000 mm, overall weight: 30 kg, positioning accuracy: 0.045 mm, ● Availability: By arrangement ● Internal No.: ZM3 Technical data: Measuring volume: 3,000 mm Accuracy: 0.045 mm Scope of delivery: ● Including laptop and software as shown in the images (completeness not guaranteed) ● Including transport case Dimensions & weights: ● Installation dimensions (L x W x H): approx. 1,000 x 500 x 1,000 mm ● Weight: approx. 30 kg Additional notes: ► Upon request, we can offer transport to the destination. Kdsdpfx Aoz A Tcfeafjt ► The goods are sold with no warranty whatsoever. ► Technical data subject to change without notice.

Condition: ready for operation (used), Year of construction: 2011, operating hours: 51,000 h, functionality: fully functional, travel distance X-axis: 700 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 700 mm, controller model: FANUC 16i, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range X-axis: 700 mm Travel range Y-axis: 650 mm Travel range Z-axis: 700 mm Spindle speed: 12,000 rpm Tool interface: HSK A63 Number of tool magazine positions: 295 Rotary table: stepless, 360,000 indexing positions Rotary table speed: 65 rpm Pallet system: 7-position multi-pallet system Pallet size: 500 x 500 mm Maximum pallet load: 550 kg Maximum workpiece diameter: 800 mm MACHINE DETAILS CNC control: FANUC 16i Coolant tank: 750 l Coolant filtration system: self-cleaning Loading/unloading stations: 1 Operating hours: 51,000 h EQUIPMENT Cooling unit for temperature control of the spindle unit Spindle prepared for coolant supply through the tool flange Climate-controlled control cabinet with air conditioning unit Full enclosure of the work and machine area Work area lighting Scraper-type chip conveyor with rear discharge Conveyor screws for chip removal Closed upper machine cover, prepared for connection to a central extraction system C301 Workpiece cleaning C303 Tool taper cleaning C410 Tool Monitor MCM C305 Oil separator Kjdpfx Aajzxztasfjdt C333 Automatic coolant refill C308 High-pressure coolant system, 65 bar C403 Tool presence monitoring via laser C412 Balluff read/write system with JTERM-01 C408 Marposs wireless measuring probe MIDA T36 jFMX MCM monitoring system including Network Part Program

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 700 mm, measuring range Z-axis: 400 mm, Equipment: type plate available, Coordinate measuring machine Mitutoyo EURO M 574 in excellent condition for sale. without computer and software year of manufacture: 1998 without PC!!! X - axis 500 mm Y - axis 700mm Z - axis 400 mm resolution: 0.0005 mm Measuring table material Granite Renishaw MH 20i probe head, Granite bed size 850 mm x 1160 mm, Kdjdpfx Aaeu E Uzxjfjt length standard: high-precision linear encoder centering microscope: mitutoyo CF-10 fixing and fine adjustment: one-touch air clamp for each axis continuous fine adjustment throughout the entire stroke range of each axis. effective size: 680x1160 workpiece clamping method: threaded insert M8X1.25 workpiece: Dimensions between columns 720 mm, maximum height: 480 mm maximum weight: 160 kg without PC Length measurement uncertainty ISO 10360 E = [3.5 + 4.0L/1000] µm in the temperature range of 18 ... 22 °C machine weight: 450/540kg

Condition: excellent (used), functionality: fully functional, measuring range X-axis: 25 mm, measuring range Z-axis: 1 mm, travel distance Z-axis: 550 mm, Well-maintained Mahr surface roughness measuring instrument SD26 with fixture for measuring shafts and axles from Messtechnik Triesen. Measuring ranges: Z = 0.8 mm (manually height-adjustable column), X = 25 mm. Machine has been completely overhauled and inspected. PC (Windows 10) and Mahr measuring software are installed. Extensive set of new replacement styli included. Includes base frame for PC and printer as well as accessories. Price for delivery within the EU. Kdjdpfx Aoxddf Noafst

Condition: new, Year of construction: 2025, functionality: fully functional, pressing force: 100 t, stroke length: 380 mm, table width: 300 mm, table length: 1,500 mm, throat depth: 1,100 mm, TECHNICAL DETAILS Kjdpfozxcldsx Aafsdt Pressing force: 100 t Max. stroke: 380 mm Stroke length: 100 mm Overhang: 1,100 mm Vertical adjustment: 750 mm Table length: 1,500 mm Table width: 300 mm Width between uprights: 1,100 mm Clearance under the hydraulic cylinder: approx. 1,100 mm MACHINE DETAILS Press type: Single-acting Control system: Conventional Motor power: 3.0 kW Dimensions & Weight Dimensions (L x W x H): 1,450 x 800 x 2,200 mm Net weight: 970 kg Shipping packages: 1 unit EQUIPMENT Movable press cylinder Documentation CE certificate CE marking

Year of construction: 1978, condition: used, pressure 2000 /1000* t distance between columns 2650 mm stroke 500 mm column travel -side 500 x 1000 mm diameter of piston 710 mm number of pistons 2 distance between table / ram 1000 mm operating pressure 130 / 230 bar dayligth 800 mm table length 2500 mm table width 1600 mm table height 250 mm draw back pressure 500 kN number of T-slots 8 turning speeds 1500 U/min rapid speed 120 - 140 mm/min closing speed max. 120 - 140 mm/sec. return of plunger by small single cylinders 100 - 110 mm/sec hydraulical ram locking cutting sound absorber 300 t die cushion capacity 200 t die cushion stroke 250 mm speed of die cushion 100 mm/sec frequency 50 Hz voltage 380 V Kedpfx Ajd Ih Ncoafodt quantity of oil 2000 l total power requirement 93 kW weight of the machine ca. 100 t dimensions of the machine ca. 5000 x 2500 x 7200 mm transport measurements ca. 6500 x 3750 x 2190 mm 1991 assembly of a die cushion, pressure reduction to 1000 tons reason: tools were only constructed to 1000 tons press has run in a perfect condition until disassembly. It was replaced by a press line. important for UVV: press has a hydraulic ram locking!

Condition: used, Year of construction: 2013, functionality: fully functional, machine/vehicle number: 130304, GOM ATOS II Triple Scan - Industrial Blue Light Optical 3D Scanner {CEE ID: 7494} GOM Year: 2013 System includes lenses and calibration plates for the following measurement volume sizes: 320 mm 170 mm Travel roller cases for measuring head, lenses, accessories, and tools. Computer - Dual Xeon processor, 32 GB RAM, RAID hard drives Metal-enclosed reinforced case for computer equipment. Installed software Kodpfx Aeyfgn Deafodt ATOS Professional v8, includes: GOMInspect V1.2.1 Online system manuals. Copy of original software on CD FOBA AROBE studio / camera stand - 12-foot height with 2M horizontal arm, rotating column, and tilting head. Printed manual, CD with test reports and calibration plate data for each calibration plate Rotary table (manual) Parts set (touch probe)

Condition: used, Year of construction: 2017, machine/vehicle number: 1739289, input current: 10 A, protection type (IP code): IP20, welding current (max.): 2,000 A, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Supply voltage: 24 V DC / 90 V DC Input current: 1 A / 10 A Welding current: up to 2,000 A at 2% duty cycle Protection class: IP20 Polarity: STD Design: Closed protective housing made of aluminum profiles Safety enclosure: With protective doors Kdodpfezzk Rmjx Aafjt MACHINE DETAILS Control cabinet: Integrated Equipment cabinet: Mobile EQUIPMENT Signal light Welding torch Connection cable Mobile equipment cabinet Documentation The height and weight of the asset must be taken into account when selecting the transport vehicle. A forklift is available for loading. If the asset is not collected on time, a storage fee of €20.00 per lot and commenced day will be charged. The fee must be paid before collection. The sale is made without any guarantee or warranty. The information on the technical data is based on the original offer. No liability is accepted for typographical or measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the end of the auction.

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, turning diameter: 295 mm, spindle speed (max.): 3,000 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 750 mm, controller model: Hurco WinMax V11, TECHNICAL DETAILS Swinging diameter over cross slide: 402 mm Swinging diameter: 295 mm Spindle speed (max.): 3,000 rpm Travel in X-axis: 250 mm Travel in Z-axis: 750 mm Driven tools: VDI 40 Speed of driven tools (max.): 4,000 rpm MACHINE DETAILS Control system: Hurco WinMax V11 Kodpfxjzy Ikne Aafedt Machine weight: 5,000 kg EQUIPMENT Renishaw tool measuring arm Internal cooling: 20 bar

Year of construction: 1990, condition: used, x-travel 850 mm y-travel 1200 mm z-travel 600 mm total power requirement kW weight of the machine ca. t Kedot Hwqkjpfx Aafedt dimensions of the machine ca. m Universal 3D measuring center, double-column, modern software, many accessories

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 20 t, Double column press 20 T capacity, a) Closing speed up to 10 mm/sec b) opening speed up to 30 mm/sec c) table size between columns 1400x1100 mm d) ram size between columns 1400x1100 mm e) Manual lubrication (via grease nipple) f) UKF pump-cooling-filtration ( electrical cooling ) g) Pressure adjustment from 4 T to 20 T ( adjustable via rotary control ) h) Travel adjustable via slide control Type of construction Press design Double column press ,hydraulic Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 200 kN Free ripping force max. 20 kN Pressure build-up time Closed tool Steel on steel Max. 4 sec. Dimensions Max. Opening width 500 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 2800 mm Hall height min. 3,500 mm Parallel deviation at 20°C #ERROR! mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.4 mm/m Weight Total weight of the press without operating materials approx. 3 to Table cut-out Size 1100x850 mm Speeds Fast closing with 9 mm sec. Pressing speed 9 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of press/driving cylinders 2 pcs. Operating pressure max. 280 bar Pressing pressure build-up time 3-5 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH/PARKER approx. 35 L/min Oil volume approx. HLP 46 D 150 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Ksdshmbhqjpfx Aafedt Flow temperature °C Circulation pump for cooling ACS approx. 6.5 L/min Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 5 kW

Year of construction: 1990, condition: used, x-travel 4070 mm y-travel 1185 mm Kdodpot Hwt Esfx Aafet z-travel 1985 mm total power requirement kW weight of the machine ca. 15 t dimensions of the machine ca. 6000 x 4500 x 4000 m Consisting of: Working Range: Measuring column, longitudinal movement, X Axis 4,070 mm Measuring slide, cross, as Y Axis (measuring head) 1,185 mm Measuring slide, vertical, as Z Axis (vertical) 1,985 mm Adjustment of measuring head, roll axis 360 ° pitch axis 220 ° Measuring table 5,000 x 2,000 mm Weight, approx. 15,000 kg Space required 6,000 x 4,500 x 4,000 mm Accessories / Special Features : o 3D tracer head, with turning/swivelling device. o Universal 3D Measuring Software, KOROS CAD 5.2.0 from November 2001 (with lots of enhancements), as well as HOLOS UX for manual or automatic measuring of all geometric elements and free-form surfaces, ideally on passenger car bodies, engineering parts and large forming tools. o Separate switch cabinet (Master F1) with programming possibility and a mobile manual control console. o Steel clamping table, which can be levelled, 2,000 x 5,000 mm. o Machine was maintained annually by DEA Company, and the software was updated regularly. This unit is ideal for measuring complete car bodies. Condition : Very good. Machine is assembled and can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We have a selection of measuring machines on stock.
