Used Precision Drill for sale (11,222)

Condition: good (used), Mikron WF31D Precision Milling and Drilling Machine Machine with chip and splash guard enclosure Equipped with a Heidenhain TNC355 control system Technical Specifications The WF 31 D is a precision milling and drilling machine for series production and CNC training. Drive via an automatically switchable stepped gearbox and Poly-V belt. Vertical spindle can be extended by 90 mm; conversion from vertical to horizontal machining is possible. Ball screws with DC drives enable simultaneous feed movements. Guides are protected against dust, chips and coolant. Technical Data Manufacturer: Mikron Type WF31D Control system: Heidenhain TNC 355 Longitudinal movement (X): 560 mm Transverse movement (Y): 500 mm Vertical movement (Z): 400 mm Drive power: 3.3/4.0 kW Speed range: 40-4000 rpm Feed rate: 2-3000 mm/min Rapid traverse rate X/Y: 6000 mm/min, Z: 5000 mm/min Electrical Equipment Total installed rated power: 10.0 kW Installed useful power: 7.3 kW Operating voltage: 3 x 380 V - 50/60 Hz Protection class: IP 54 Max. permissible ambient temperature: +35 °C Relative humidity: 75 %. Dimensions and Weights Width: 2450 mm Length: 2800 mm Height: 2000 mm Net weight of the machine: approx. 2570 kg. Dodpfswiucfsx Acpeku Heidenhain TNC355 Operating Manual Heidenhain TNC355 Programming Examples Heidenhain TNC 355 Service Manual More items - new and used - can be found in our shop! International shipping costs available upon request!

Condition: good (used), Year of construction: 2009, CN Heidenhain TNC 530 Dkodpfxoz H Ui Ue Acpou Travel X – 3000 mm Travel Y – 2000 mm Travel Z – 1200 mm Travel W – 730 mm CNC table 1600 x 1800 mm Max. workpiece weight – 15 t External coolant system, 4 nozzles Heidenhain rotary table with B-axis Heidenhain linear scale, X-axis – 3000 mm Heidenhain linear scale, Y-axis – 2000 mm Heidenhain linear scale, Z-axis – 1200 mm Spindle support 250 mm Safety guard

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,000 rpm, controller model: DIXI CNC 4400, TECHNICAL DETAILS Travel range, X-axis: 1,000 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 1,000 mm Vertical movement with pallet changer (Y-axis): 880 mm Distance from spindle axis to top of table: 0 – 1,000 mm Distance from spindle axis to top of table with changer: 0 – 880 mm Table dimensions without changer: 840 x 1,000 mm Table dimensions with standard changer: 800 x 800 mm Dsdszd Rizspfx Acpeku Max. table load: 2,000 kg Max. table load with pallet changer: 1,200 kg Table rotation: 360° continuous Rapid traverse: 1,500°/min T-slots: 7 equally spaced slots, width 18 H7 Tool interface: ISO 50 Spindle speeds: 8 – 3,000 rpm (in 3 ranges) Drive power: 11 kW Drive power in overload: 13.75 kW Max. torque: 200 kpm Working feed rates (X, Y, Z): 1 – 9,999 mm/min Rapid traverse (X, Y, Z): 9,999 mm/min Measuring system resolution: +/- 0.001 mm / 0.001° Positioning accuracy: 0.001 mm / 0.001° Distance from table axis to spindle flange: 390 mm to 1,390 mm MACHINE DETAILS Control system: DIXI CNC 4400 Installed total power: 47 kW Compressed air requirement: 6 kg/cm² Dimensions & Weight Dimensions (L x W x H): 4,835 x 4,160 x 3,190 mm Machine weight: approx. 17 t Compressed air requirement: 6 kg/cm²

Condition: excellent (used), Year of construction: 2000, Description to follow! Djdpfx Ajz Ebqpocpoku

Condition: excellent (used), Control system: Heidenhain TNC 124 Travel distances X/Y/Z: 450/260/120 mm Travel distance W: 450 mm Clamping area (L x W): 770 x 320 mm Permissible table load: 100 kg Distance table – spindle nose (min. – max.): 0 – 110 – 560 mm Dsdpsipmmuofx Acpeku Feed rate X/Y: 1 – 2000 mm/min Tool – quick-change system: SF 32 Speed range, continuously variable: 100 – 9200 rpm Drive power: 5 kW Space requirement (W x D x H): 1500 x 1480 x 2330 mm

Condition: excellent (used), Year of construction: 1990, High-precision drilling and milling machine Aciera 22 VA Good condition, from a school workshop Dsdpfx Acjhqm D Njpoku Year of manufacture approx. 1990 Table 600 x 320 mm Speed 40 - 3600 rpm Speed setting rpm 4 automatic feeds 40-280 80-560 275-1800 550-3600 Spindle diameter 65 mm Drilling spindle stroke 120 mm Spindle mount: Aciera quick-change system Automatic thread cutting Drilling capacity in solid material 25 mm Max. drilling capacity up to 30 mm Height adjustment via hand crank Motor: 1.1 kW Lamp Some quick-change chucks Dimensions WxDxH 90 x 130 x 185 cm Weight approx. 800 kg Technical specifications subject to change.

Year of construction: 1975, condition: used, General / Technical Data: Used machine, Speed control via flat belt drive with 3 stages Speed range: 700 rpm, 1400 rpm, and 2800 rpm Spindle travel: 90 mm Spindle diameter: 35 mm Column diameter: 60 mm Overhang: 200 mm Mounting: Direct mounting for drill chuck Table surface: 380 mm x 300 mm Dimensions: approx. 720 mm x 480 mm x 750 mm Weight: 60 kg Dksdocu I Exepfx Acpju Remarks: Excellent running condition of the drill spindle, three-phase connection, robust industrial design, Year of manufacture estimated to be approx. 1975

Condition: excellent (used), Professional paper drilling machine from the renowned German manufacturer Constantin Hang Maschinenfabrik Göppingen. Model 114-4 is equipped with four drilling heads designed for precise drilling of paper, documents, catalogs, calendars, and print materials. The machine is suitable for use in: • printing houses, • bookbinding shops, Djdpfxey Nm A Rs Acpeku • print production facilities, • binder and catalog manufacturing, • technical documentation preparation. Robust German engineering guarantees high working precision and long-term durability. Technical specifications: • Manufacturer: Constantin Hang Maschinenfabrik • Model: 114-4 • Number of heads: 4 • Adjustable head distance • Adjustable worktable • Foot pedal operation • Safety guard • Made in Germany

Condition: new, CATALOG NUMBER M0261 TECHNICAL DATA Number of spindles: 21 Distance between the first and last drill: 640 mm Distance between the centers of individual spindles: 32 mm Maximum size of the workpiece: 50 x 915 x 3000 mm Maximum drilling depth: 65 mm Number of pneumatic clamps: 2 Height of the drilling machine worktable: 860 mm Maximum height of clamps above the table: 70 mm Operating pressure: 6-7 bar Air consumption: 10 l/cycle Motor power: 1.5 kW Noise level: 76.1 dB Revolutions: 2800 rpm Dimensions (L/W/H): 1030/1030/1285 mm Weight: 275 kg PRODUCT FEATURES Main features of the machine: - Single-head drilling machine for drilling in the range of 0 - 90 ° - Pneumatically adjustable head tilt angle - Cast iron fences - Spindles adapted for quick-release couplings - Patented pneumatic material clamps - Cast iron worktable - Quick and precise adjustment - Precise drilling - Italian production Dsdpfx Acjzw Dwrjpjku Standard machine equipment: - 2 aluminum rulers with a length of 1.5 m (right and left) with two stops - 5 quick-release couplings - Wooden crate to protect the machine during transport. ADVANTAGES - Drilling in vertical/horizontal/angled positions - Multi-spindle - New machine - CE certificate - Robust - Professional Net price: 13,800 PLN Net price: 3,200 EUR Net price calculated based on an exchange rate of 4.3 PLN/EUR (Price may change in case of significant exchange rate fluctuations) - We ship machines to every corner of the country - Possibility of trade-in for another machine. The prices quoted are net prices. Net price quoted for international transactions, EU customers with a valid EU VAT number. Before placing an order for a new product, please confirm availability and current price.

Condition: used, machine/vehicle number: 007665, Position 1: Automatic Drilling Machine WEEKE-BST 503 + BST 507 Dedewuz Dgjpfx Acpeku Position 2: Automatic Drilling Machine WEEKE-BST 503 + BST 507

Condition: used, Year of construction: 1993, Used machine Year of manufacture: 1993 Features and technical data: 2-jaw drill chuck up to 20 mm shank diameter Pneumatic positioning adjustment on 2 levels 0-100 mm Max. drilling depth: 150 mm Precision indexing rail 12 mm Center locking and cross adjustment 2 pneumatic safety clamping cylinders Motor 1.5 kW Speed: 2800 rpm Long hole drilling device, lowerable, with 2 program cams Dodpfew I Uy Tox Acpeku Machine weight approx. 310 kg Machine dimensions (W x D x H): 1100 x 1100 x 1500 mm (without stop) Availability: short-term Location: Röllbach

Condition: new, Drill and milling machine OPTIMUM OPTImill MB 4 - Exhibition machine - This offer includes an equipment package. The following items and options are already included in the price: - Drill and milling machine OPTImill MB 4 Optimum Djdpfx Aju R Tftjcpsku - Machine base MSM 3 Optimum - Collet chuck set MK 4/ ER 32 - M16 Optimum - Shank milling cutter set HSS, 20-piece, OPTIMUM - Precision machine vise FMS 100 Optimum - New exhibition machine -

Condition: good (used), Nagel Citoborma 280B Paper Drill This machine is 100% functional. It is one of the newest models. The drill table is adjustable in all directions (sides, front/back). It has stops for setting the drilling spacing. The installed table is an enlarged version. Additionally, the paper drill has an automatic table lock that releases after each cycle. Excellent condition. Solid construction – weight 76 kg. 380V power supply Two drilling heads with adjustable spacing from 45-120 mm. Drill diameter 2-20 mm. Stack height 60 mm. The machine has been serviced. Dkodpfx Acszt H Nvjpju Includes drills and tools, a new cutting stick, and an instruction manual.

Condition: used, overall weight: 45,000 kg, Maus MTV4LSL500 Turning Machine/Drill. Weight 45,000 kg. Delayed removal unit will be ready for removal by the end of September. Dsdpfxsz Hc Nps Acpjku Buyer responsible for removal, contractor must be licensed and insured.

Condition: used, Year of construction: 2008, machine/vehicle number: LV082, overall weight: 44,000 kg, Pittler PV1250 Vertical Turning Machine/Drill. Weight 44,000 kg. Condition Machine needs work. Delayed removal unit will be ready for removal by the end of September. Dksdpfx Acsz Hb U Repju Buyer responsible for removal, contractor must be licensed and insured.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, OKAMOTO ACC-16*24SA1 Precision Surface Grinding Machine Okamoto Precision Surface Grinding Machine ----- Model ACC-16•24SA1 Dedpfx Acszmhknopsku Automatic Wheelhead Approach, Retraction to Start Position, Automatic Dress Cycle with Wheel Wear Compensation, Shift Plunge Cycle--- ----- Grinding Capacity 16”x 24” Standard Accessories • Automatic Overhead Wheel Dresser • Touch Screen Controller with 10” Display With Compensation, including Diamond Tool • Vertical & Crossfeed Pulse Generator • Rapid Wheel head Retraction • Teach-Input Positioning • Load Meter for Grinding Wheel Motor • 5 HP Wheel Spindle Motor • Shift-Plunge Rough Grinding Cycle • Stainless Steel Wheel Guard • Selectable Rough/Fine Infeed Grinding Method • Leveling Bolts with Plates • Table Park for Safety • Necessary Tools & Tool Box • Stainless Steel Splash Guard • Installation and Training • Instruction Manual

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, Equipment: documentation/manual, We offer you: Manufacturer: Chiron Type: FZ08 MT Precision+ high speed plus Year of manufacture: 2017 Control system: Fanuc 31i-B5 Technical data: Travel ranges: X-axis: 210 mm Y-axis: 200 mm Z-axis: 360 mm B-axis: -10° to +100° C-axis: 360° Main spindle: Speed range – main spindle: max. 54,000 rpm Drive power – main spindle (100/25%): 3.5 / 5.2 kW Torque: max. 2 Nm Turning spindle: Max. bar diameter: 32 mm Speed range: 15 – 8,000 rpm Drive power (100/15%): 9 / 12 kW Djdpfx Acsz I U D Uspsku Torque: max. 14.3 Nm NC 2-axis swiveling unit: Swiveling angle: -60° to +180° NC rotary table diameter: 170 mm Tool changer: Tool holder: HSK-E 32 Number of tool positions: 40 Max. tool diameter: 45 / 100 mm Max. tool length: 200 mm Max. tool weight: 1.2 kg Tool change time: approx. 0.8 sec Chip-to-chip time: approx. 2.5 sec Feed rates: Rapid traverse (x/y/z): 75 m/min Operating hours: approx. 37,280 h Spindle hours: approx. 11,360 h Please refer to the PDF in the attachment for technical features and accessories. Accessories, tools shown in the images, and clamping devices are only included in the scope of delivery if this is noted in the additional information. Subject to change and errors in technical data and specifications, as well as prior sale!

Condition: new, grinding range 8 - 32 mm sharp cornered angle min./max. 90 - 140 Grad connected load 230 V weight of the machine ca. 16 Kg dimensions of the machine ca. 0,43 x 0,24 x 0,24 m Drill grinding machine: Additional station for grinding back the drilling cutting surface (clearance angle) 25tk. Collets ER 40 are included in the scope of delivery, these are also suitable for clamping intermediate sizes. For grinding twist drills made of HSS and Dodeupxh Nopfx Acpsku Hard metals with a TiN layer of 8 - 32 mm. Rotor with precision ball bearings guarantees smooth running. Vibration-free running thanks to its heavy weight and rubber feet. Sharpening angle adjustable for all common twist drills. Package dimensions: 430 x 240 x 240mm. Weight 16kg.

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg dimension machine approx.LxWxH: 0,73 x 0,56 x 0,22 m Heavy-duty, solid cast-iron construction Automatic gear lubrication via oil pump Smooth and quiet operation thanks to precision-ground gears running in an oil bath High spindle concentricity thanks to the hardened and ground main spindle Thread-cutting device up to M24 in steel Main switch and motor protection switch Mechanical quill feed, 2 stages: 0.1 / 0.2 mm/rev. Coolant system Dkedpfjyli Sfex Acpeu Adjustable drilling depth stop 18 spindle speeds from 50 to 1,450 rpm 9 selectable speeds via gear selector levers in combination with a two-speed motor *

Condition: used, Year of construction: 1997, Technical details: bore capacity in steel (diameter): 32 mm x-travel: 750 mm y-travel: 520 mm drill capacity in cast iron: 45 mm revolution per minute: 90 - 4500 U/min feed steps: 6 bore spindle stroke: 250 mm boring spindle diameter: 30 mm drill spindle - Morse Taper: MK4 vertical adjustment of the arm: 520 mm throat max.: 1000 mm throat min.: 250 mm Djdpfx Aozgwgfecpoku column diameter: 400 mm swivel range of the arm: 180 ° table clamping surface LxW: 1150 x 800 mm total power requirement: 3,5 KW weight of the machine ca.: 2000 kg dimension machine approx.LxWxH: 1,7 x 1,07 x 2,61 m The KOVOSVIT VO 32 is a robust and versatile radial drilling machine designed for industrial applications. The machine is suitable for drilling, boring, countersinking, reaming, and tapping operations in steel, cast iron, and other materials. Thanks to its swiveling radial arm and large reach, even large and heavy workpieces can be machined conveniently without the need for complex repositioning. The machine features a massive cast-iron construction, a powerful main drive, and an automatic feed system. The drilling head can be moved along the radial arm, providing a large working area. Its solid design ensures high precision, reliability, and a long service life, even under continuous operation. Equipment: ·Including coolant pump ·1 × boring tool block (boring cube) ·1 × machine vise *

Condition: used, Technical details: bore capacity in steel (diameter): 2-20 mm Dsdpszgaiiefx Acpeku throat: 210 mm bore stroke: 100 mm Distance spindle/table max.: 450 mm range of revolution per miute: I : 450-1800 + II: 900-3550 / 4step U/min spindle taper MT: 2 table surface area: 340x280 mm total power requirement: 1,1 kW machine weight ab.: 165 kg transport dimensions LxWxH: 0,6 x 0,5 x 1,28 m Robust industrial drilling machine manufactured in the former East Germany by the "Fritz Heckert" Machine Tool Combine. Equipped with a 1.1 kW motor, 380 V three-phase power supply, and a machine weight of approximately 165 kg. Precision machine suitable for drilling, countersinking, and light reaming operations. Solid cast-iron construction, ideal for toolmaking, workshops, maintenance departments, and training facilities. *

Condition: new, Year of construction: 2025, Heavy-duty, solid cast-iron construction High running smoothness due to ground, oil-bath lubricated gears Right-hand/left-hand operation Automatic quill feed with manual fine feed Motorized positioning of the Z-axis Motorized table feed of the X-axis Coolant system Machine lamp Gear head can be swiveled ± 60° Adjustable wedge strips Solid dovetail guide for the column, hand-scraped, for maximum stability and precision Height-adjustable, large-sized protective shield with microswitch Drilling depth stop Digital position display DRO 5 Drilling/tapping function Solid and large-sized cross table, precisely surface-finished with T-slots and adjustable wedge strips Solid machine base made of cast iron with chip collection groove Single-stage, high-quality industrial electric motor Large speed range of 60 - 2,760 rpm through 2 continuously adjustable speeds Dimensions and weights Length approx. 1600 mm Width/Depth approx. 930 mm Height approx. 2110 mm Weight approx. 495 kg Drilling/Milling performance Arbor size max. 63 mm Shell mill size max. 26 mm Drilling capacity steel (S235JR) 24 mm Continuous drilling capacity steel (S235JR) 20 mm Electrical data Connection voltage 230 V Mains frequency 50 Hz Electrical connection Total connected load 1.5 kW Milling table, horizontal Dkedpjg U Uv Usfx Acpeu Length 800 mm Width 240 mm Distance Vertical spindle - Milling table max. 420 mm T-slot size 14 mm Number of T-slots 3 T-slot spacing 80 mm Standards and approvals Standard DIN EN 55011 EMC class C2 Travel X-axis manual 560 mm Y-axis manual 195 mm Z-axis manual 350 mm X-axis automatic 480 mm Vertical spindle Overhang 258 mm Spindle mount MK 4 Speed range 60 – 2760 rpm Number of speed ranges 2 Speed control Steuerung der Drehzahlregelung electronic Draw bar M 16 Swivel range milling head Z - X plane ± 45 ° Quill diameter 75 mm Quill stroke 120 mm Location: In stock at 54634 Bitburg - available immediately -

Condition: used, WFL M 35 G MILLTURN is a CNC Turning‑Milling‑Drilling Center delivering high precision, accuracy and reliability. Capacities: distance between centres 2000 mm, max turning Ø 520 mm, spindle bore 77 mm; travels Z1 1500 mm/X1 550 mm, Z2 1355 mm/X2 230 mm, Y 250(-100/+150), B 220°. Specs: main/back spindles up to 4000 rpm, 29/33 kW (551/630 Nm), driven tools 6/13 kW, milling spindle 9000 rpm 15/20 kW (165 Nm); rapid traverses Z 40 m/min X 30/10 m/min; weight ~20000 kg; size 7900×5700×3250 mm. Accessories: lamp, coolant system, paper filtration, oil mist extractor, chip conveyor, automatic load/unload, Renishaw measurement. Enables tight tolerances; suited for automotive, aerospace, medical, watchmaking and machine‑tool sectors. Dkodpfsz Dv Dbjx Acpou

Condition: excellent (used), Four-head paper drill. Several pieces available !!! Brand Hang Model 106DTK4 Details 4-head paper drilling machine With adjustable drilling heads Operation Electric foot switch, 2 speeds Available directly This additional information is standard for this model. Always check the details carefully during your visit. The 1975 Hang 100DTK4 printing machine is an iconic and reliable piece of equipment that has made a significant impact on the printing industry. Manufactured by Hang, the machine offers advanced features for its time and set the standard for high quality and efficient printing. The Hang 100DTK4 features a robust and durable design, ensuring stability and consistent performance during the printing process. Its printing technology, although conventional by today's standards, allowed for precise and sharp prints with satisfactory resolution for its era. Equipped with user-friendly controls and mechanical automation, the machine offered programmable settings for various printing formats and configurations. Its operation required skilled operators who were able to achieve accurate and repeatable printing results. The printing machine's capabilities extended to a variety of substrates, including paper, paperboard and lightweight cardboard, satisfying a range of printing applications common at the time. Dkodpfx Acsudl Ikspeu Launched in 1975, the Hang 100DTK4 presented a technological advance for its era. Its sustained performance and contribution to the printing industry are remarkable. While newer printing machines with advanced digital technology have emerged, the Hang 100DTK4 remains a historic symbol of performance and innovation in the printing industry in the 1970s. The machine has collector's value and serves as a testament to the evolution of printing technology over the decades.

Condition: new, bore capacity in steel (diameter) 15 / 18 mm throat 180 mm bore stroke 80 mm turning speeds 200 - 4000 U/min 250 x 220 mm distance drilling head - clamping area max. 380 mm total power requirement 1,1 / 400 kW / Volt column diameter 65 mm tool taper MK 2 Djdpfxofg U Thj Acpoku weight of the machine ca. 0,08 t dimensions 0,4 x 0,5 x 0,9 m Precise table drill: - high accuracy and quality - Drill table adjustable via rack and swiveling around the column - Full engine protection - Star grip - 230 volt mains connection
