Used Profile Punching for sale (6,733)

Condition: used, machine/vehicle number: 007650, Max working width: 450 mm Max. machinable height: 120 mm Pgjdpfsu Evi Rsx Aklep Gluing System: EVA Hotmelt

Condition: used, machine/vehicle number: 007649, Max working width: 600 mm Gluing System: EVA Hotmelt Pgsdpfsu Eviqex Aklop

Condition: used, Danley Onsrud, model WT-2-1284A, 460V, 3 phase profile machine, S/N 797387-01, with push button controls, winning bidder responsible for proper disassembly and removal, includes table with assorted components, and hydraulic unit with 3 phase electric motor and 35" width x 12" height x 24" depth tank and coolant unit, also includes (1) skid of assorted parts, no other info available, winning bidder responsible for proper disassembly and removal, and capping of all wires. Pgsdpfsxdddrsx Akljp

Condition: new, functionality: unexamined, Year of construction: 2024, machine/vehicle number: 16.41-PS0382, control type: CNC control, degree of automation: automatic, actuation type: electric, sheet thickness (max.): 8 mm, input voltage: 400 V, input current: 20 A, type of input current: three-phase, 2024 Pima Power PS 1225 Brand new Complete machine. Machine was tipped on its side during transit and was damaged. Machine is stored in Our warehouse in California USA. Contact to set up in person inspection. Pedpfxsw Nbh Hj Aklegp

Condition: excellent (used), Year of construction: 2016, Ref:11127 . 2016 SCS Automaberg Trim & Perf Die-cut, Trim, Split, Cut, Perforate, Punch System, handling any material. Recently serviced (at a cost of £5k). A highly versatile and productive line which is a genuine “ALL-IN-ONE” solution for finishing operations. The line can include different workstations for multiple tasks and process optimization. The combination of TRIM & PERF with complementary modules offers high quality products combined with reliability, allowing the needs of digital systems to be met, as well as those for binding, in particular, the production of products for single and multi-up work IN A SINGLE PASS. Features: Easily moveable. In-feed belt height adjustable for easy connection with upstream machines. A simple push button transforms TRIM & PERF into a regular conveyor belt, no bypass or similar equipment needed. ‘CONTINUOUS FEEDER’ Top loading, bottom feeding, rubber belt type feeder for single or folded sheets, saddle stitched products and perfect bound books. ‘3 WAY’ This module allows perfect alignment of digital sheets to a print reference mark. ‘GRIPPER’ Electronic system for pass die-cutting: reduces machine set-up times and overlaying, allows a high level of product repeatability and reduces costs of American style dinking dies. Waste ejection system allows for die cutting without waste, clean shape products. ‘THERMO STICK’ holds some sheets together on the ink reference sides by ‘thermo’ welding - improving the die cutting process. ‘PRE-CUT DEVICE’ Perfect 'spine' cutting system up to 14 mm thickness. ‘TEAR OFF - PULL AWAY’ The system pulls away mingled perforation sheets in preparation for the sewing step. ‘SIMPLE DECK’ Collects cards in series after die cutting. ‘EXIT BELT’ Shingle delivery belt with batch counter. DIE CUTTING No nicks! Connections between the cut product and the waste are not required. Automatic waste ejection. 'Clean' shapes ready to be packed. TRIMMING-SPLITTING Superior quality in splitting and trimming - also for very small dimensions. Pgodpfezmx Scjx Akljp ROUND CORNER CUTTING Cutting including all four corners in a single pass. PERFORATING PUNCHING Combined perforating-punching jobs in a single pass to optimize production process efficiency. IDEAL FOR:- Flat cardboard, also laminated up to 2 mm thickness, and on plastic material up to 1 mm thickness. Folded and stitched product die cut without waste. Pre-cut device for perfect spine cutting up to 14 mm thickness. Standard corner radii from 3 to 15 mm. Stamp perforating, wire-comb perforating, tear-off perforating, single hole punching, file hole punching, euro hole. TOOLING, PLEASE NOTE: The machine only comes with the pre trim device. Also includes the metal caddie to hold various dies so you can easily swap in different wooden steel rule dies as required. Specifications: Product size untrimmed (LxW) (sizes subject to jobs) Standard max. 500 x 600 mm Standard min. 50 x 50 mm Product thickness, Standard max. 4mm (optional max.) 14mm Mechanical speed, max. 9.000 cycles/hr Compressed air requirement: 200 l/min at 6 bar.

Condition: used, Year of construction: 2015, functionality: fully functional, overall weight: 24,000 kg, sheet thickness steel (max.): 60 mm, cutting length (max.): 6,000 mm, cutting width (max.): 2,540 mm, drill diameter: 40 mm, FICEP TIPO B254 - CNC PUNCHING, DRILLING & THERMAL CUTTING CENTER | YEAR 2015 The Ficep Tipo B254 is a CNC-controlled punching, drilling and thermal cutting center for the complete processing of steel plates and flat products in a single pass. Punching, drilling, countersinking, tapping, marking and thermal cutting via plasma and oxy-fuel are carried out on one machine without intermediate handling. CONDITION Used - technically sound. The machine is currently in productive operation and CAN BE INSPECTED UNDER POWER (by appointment). Handover as preferred: directly from ongoing production (cleaned and serviced) or - at additional cost - reconditioned by ASM. Details on the technical condition are disclosed individually upon serious interest. FUNCTION & APPLICATION The system combines three processing units in one CNC-controlled line: hydraulic punching unit (1000 kN), drilling head (20.1 kW) and thermal cutting unit with plasma torch (Hypertherm HPR 260) plus oxy-fuel torch. All processes run via the Mitrol CNC as automated machining cycles; the machine processes steel plates up to 2540 x 6000 mm. Typical applications: structural steel fabrication, structural engineering and prefabrication of gusset plates, end plates and connection plates. TECHNICAL DATA - Machine type: Automatic CNC punching and thermal cutting system for plates - Year: 2015 | Serial number: 34201 | Machine weight: 24,000 kg - Working height: approx. 1,090 mm | Max. positioning weight (plate): 5,000 kg - Max. plate size: 2540 x 6000 mm | Min. plate width: 508 mm - Punching force: 1000 kN | Stripping force: 100 kN | Punching tools: 8 - Max. punch diameter: 32 mm | Max. punching thickness: 20 mm - Drilling heads: 1 | Drilling tools per head: 8 - Max. drilling diameter: 40 mm | Max. drilling thickness: 100 mm Pgedpexn T H Djfx Akljp - Spindle power: 20.1 kW | Max. spindle speed: 4000 rpm - Plasma torches: 1 | Oxy-fuel torches: 1 | Plasma source: Hypertherm HPR 260 - Max. plasma cutting thickness: 35 mm (pierce start) / 60 mm (edge start) - Max. longitudinal feed speed: 30 m/min - CNC control: Mitrol CNC (master/slave), online remote diagnostics - Processes: punching, drilling, countersinking, tapping, milling, marking, scribing, oxy-fuel and plasma cutting Min. plate length, max. overall material thickness and cross positioning speed are confirmed during inspection. SCOPE OF DELIVERY - 1 x Ficep Tipo B254 plate processing center (year 2015) - 1 x Hydraulic punching unit 1000 kN with 8-position tool changer - 1 x Drilling unit 20.1 kW with 8-position tool changer - 1 x Plasma cutting torch | 1 x Oxy-fuel cutting torch - 1 x Hypertherm HPR 260 plasma cutting system - 1 x Marking unit (configuration to be confirmed during inspection) - 1 x Chip conveyor - 1 x Donaldson Torit dust extraction system | 1 x Punching tool set LOGISTICS & LOCATION Location: Ulft (Netherlands), directly at the German border. Dismantling, transport, installation and commissioning by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM) specializes in Ficep structural steel machines. Further Ficep machines on request. CONTACT / INQUIRY Arrange a viewing under power | Price on request | Request a callback. Sale exclusively to commercial customers (B2B).

Condition: good (used), Triangular notching tool, notching side knife, die holder, separating tool, punching tool, punch, punching die, corner notching punch, punching punch, square notching punch, notching punch, notching tool -Punching tool: Holder for punching tool -Holes: Ø 60 mm Podpfx Akjzpwq Noljgp -Dimensions: see photos -Dimensions: 253/71/H104 mm -Weight: 6.6 kg

Condition: good (used), pressure 100 t punching cross-cut in cmm 40.0 in 22.0 mm ST stroke 120 mm column arm 760 mm total power requirement 8.5 kW weight of the machine ca. ca. 3.800 kg dimensions of the machine ca. ca. 2500 x 1700 x 2000 mm Original price, including stop system: approx. 45.000 euros Special price available upon request Features: - Robust / heavy-duty hydraulic hole punch Podpfxozn Ahkj Aklogp - Punch stroke continuously adjustable - NC stop system "MUBEA MATIC 82" * Travel range in X and Y axes * With "FAGOR" control unit * Includes large support table * Separate control cabinet - Various (custom) punching tools (see Figure 9) - Front safety guard, including sheet metal scraper - 1 freely movable foot switch - Operating instructions for machine and stop system

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, -Stamping tool: Die holder with fine adjustment -Bore: Ø 25 mm -Dimensions: see photos -Dimensions: 300/250/H210 mm Podoznu Ayopfx Aklsgp -Weight: 32.1 kg

Condition: used, Year of construction: 1994, Product information "Boschert Hydraulic CNC Punching Machine" Type / Model: Boschert EL 750 digital Condition: Used Year of manufacture: 1994 Technical data Working area & dimensions Overhang (Y-axis): 750 mm Podpfozp Raqsx Aklogp Travel range (X-axis): 1500 mm Max. sheet size (without repositioning): 720 x 1700 mm Performance data & capacity Max. hydraulic punching force: Standard 280 kN Max. sheet thickness*: up to 12.7 mm Max. punching diameter: Ø 105 mm Stroke rate: max. 100 strokes/min Tooling: Original Trumpf® tool system Positioning accuracy with 2-axis digital display: ± 0.1 mm Connection power: 4 kVA Control voltage: 220 V Required fuse rating: 3 x 16 A Installation dimensions (W x D x H): approx. 3400 mm x 1580 mm x 1600 mm Weight: approx. 3400 kg Equipment - includes various tools / accessories * Material-dependent, usually designed for thin sheet metal up to 6 mm at full diameter or any shape that fits into a circle of Ø 105 mm Inquiry item: Transportation costs in individual offer.

Condition: ready for operation (used), pressure 30.0 t punching cross-cut in cmm 30.0 in 9.0 mm stroke ca. 35 Hub/min throat 610 mm stroke - stepless adjustable 0 - 28.0 mm oil volume 35.0 l work height max. 1010 mm total power requirement 4.0 kW weight of the machine ca. 1200 kg. Features: - Electro-hydraulic punch press with long reach - Material/sheet metal scraper - Very large material support table (!) * with adjustable depth stops - Continuously variable stroke adjustment Pgsdpjznng Sjfx Aklsp - Freely movable foot switch, including protective cover - Side storage shelf - Assortment of punches and dies - Original operating instructions

Condition: good (used), Triangular notching tool, notching side knife, die holder, separating tool, punching tool, punch, punching die, corner notching punch, punching punch, square notching punch, notching punch, notching tool -Punching tool: Square notching die for profile steel shears and flat steel shears -Width: 50 mm Pgedpjznk Aiofx Aklsp -Dimensions: see photos -Dimensions: 175/60/H125 mm -Weight: 6.6 kg

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, -Punch tool: Intermediate block -Bore: Diameter 65 mm -Dimensions: see photos -Dimensions: 370/250/H125 mm Pedpfx Akjznklqoljgp -Weight: 46.7 kg

Condition: good (used), Die holder, separating tool, punching tool, punch, punch die, punch stamp, gill forming tool, die holder Pgjdpfszniqxex Aklsp -Stamping tool: die holder -Hole: Ø 45 mm -Bore: Ø 33 mm -Hole spacing: 180 x Ø20 mm -Dimensions: 240/85/H120 mm -Weight: 7.3 kg

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, -Punch tool: for holding dies -Hole: Ø 100/43 mm Pgodpfxozniqro Aklsp -Dimensions: see photos -Dimensions: 345/280/H245 mm -Weight: 55.9 kg

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, wiper, wiper plate -Scrapers: Scraper plate for punching tool, 4 pieces -Size: 10/15/30/40 mm -Dimensions: see photos -Submission/Price: complete -Transport dimensions: 150/110/H60 mm Pedjznafyopfx Aklegp -Weight: 6.1 kg

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, -Punch tool: Intermediate block -Dimensions: see photos -Dimensions: 310/17/H110 mm Pedpfx Akszm Sd Soljgp -Weight: 22.6 kg

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, die holder -Stamping tool: die holder -Hole: Ø 35 mm -Dimensions: see photos -Dimensions: 235/105/H130 mm -Weight: 11.1 kg Pgjdezm Satjpfx Aklep

Condition: good (used), Separating tool, punching tool, punch, punch die, punch stamp, die holder -Punch tool: Intermediate block -Bore: Ø 73 mm / Mounting Ø 90 mm / Hole spacing 90/75 mm M10 -Dimensions: see photos -Dimensions: 200/100/H120 mm Pgsdpfx Akezm Samslop -Weight: 6.8 kg

Condition: excellent (used), functionality: fully functional, Year of construction: 2006, Beam on time: 12,577 hours Pgodoznir Aspfx Aklep Laser on time: 72,745 hours Includes Sheetmaster.

Condition: used, Profile cold circular saw Manufacturer: Trennjäger Pgsdpfxjznvdls Aklep Type: PMC 12-F Year of manufacture: unknown Circular saw blades from 760 mm (30") to 910 mm (36") Includes roller conveyors 23726

Condition: good (used), functionality: fully functional, actuation type: hydraulic, punching force: 70 t, punching diameter: 28 mm, throat depth: 500 mm, overall weight: 1,600 kg, Used hydraulic punching machine Brand: GEKA Model: HYD 70-SD Serial number: 3659 Throat: 500mm Cutting capacity: - L 90º: 130x130x13mm - Plate: 450x13mm - Round: 45mm - Square: 45mm Psdpoznh Shsfx Aklsgp - Notched: 250x250x6mm Maximum punching size: 28x20mm Tonnage: 70T Includes punches and dies as shown in the photographs. *Machine has been completely inspected and is in perfect working order.

Condition: excellent (used), Lightly used automatic TC, TU, TZ profile production lines, designed for manufacturing and roll forming TC, TU, TZ profiles up to 1.5 mm metal thickness. Technical Specification: Manufactured in: Estonia Adjustable profile height: 100 – 250 mm Pedpfjx Sx R Ssx Aklsgp Profile width: 50 mm Profile edge (folded): 15 mm Minimum rollable sheet thickness: 1 mm Maximum rollable sheet thickness: 1.5 mm Roll distance: 300 mm Machine dimensions: 900 x 4000 mm The machine is not equipped with a guillotine or perforating rolls. Operation is straightforward, controlled via two buttons. If you have further questions, we will be happy to answer them.

Condition: used, Max. Stanzkraft: 500 kN Reach out: 610 mm Quick change device Variablely adjustable spindle Pgodpsu T Nv Dofx Aklop Inclusive assortment of punches and dies Weight: 1700 kg Very good condition

Condition: used, functionality: fully functional, Year of construction: 2012, Standard equipment: Machine - Work area 2500 x 1250 mm - Sturdy, easily accessible C-frame - Coordinate guidance for highly precise machining - Linear magazine with 21 tool stations and 3 clamping claws - Drives with maintenance-free three-phase motors - Follow-up device with programmable clamping device - Foot pedal for clamping claw closure - Ball tables - Two good part containers - Scrap container - Initial oil fill - Transport and assembly device - ContourLine - FocusLine - NitroLine - FastLine - FlyLine - PlasmaLine - Ejector cylinder for laser parts - Fast flap for laser parts 500 x 500 mm incl. sensor for part chute - Liftable laser cutting support - Slug detection TRUMPF Laser - Laser TruFlow 2700 with LensLine and optimized standby mode - High-frequency excitation - Cooling unit - Laser control TASC - Enclosed beam guidance - Beam tube ventilation with compressed air Cutting head - Lens cutting head with 170 mm focal length - Universal cutting head quick-change device UTI with bus connection - ControlLine Programming - Extended workshop programming (TruTops via network access) Punching station - Electro-hydraulic punching head - Rotatable mono-tool holder - Tool length compensation - Programmable clamping device with manually adjustable clamping force - Stroke counter punch - Spray lubrication punch - Punch slug extraction - Deformation detection - Flap for punching parts 500 x 500 mm incl. sensor for part chute - Reaching the fill level in the punching console - Level monitoring for thread forming and tool lubrication Control system - TRUMPF control system based on Rexroth IndraMotion MTX - External control panel with 15" TFT touchscreen - Hard disk with 160 GB storage capacity - Integrated technology data - Teleservice via internet - Integrated e-shop - Programmable cutting gas pressure - Automatic shutdown - Production plan Data transmission - Network connection RJ45 and USB interface Safety - CE marking - Dual light barriers - Monitoring system for gas pressure, temperature, coolant, etc. - Quick shutdown - Protection against stray radiation - Compact dust extraction system Pgsdpfx Ajzmgm Ieklsp Extended equipment - Brush tables - MultiTool function - MultiShear function - MultiBend function - Thread forming function - Deburring and rolling technology - Active die - StripLine - Adaptive stroke calibration - Spray lubrication die - 3 clamping claws - Vibration-damped installation - Chip conveyor with tilting container - Brush tables with loading and unloading aid - Air blow-out device for small parts - Follow-up cylinder Automation: - Toolmaster
