Used Shaft Grinding Machine for sale (68,563)

Condition: good (used), Year of construction: 1990, Hydraulic surface grinding machine with automatic vertical feed Max. grinding length: 670 mm Max. grinding width: 280 mm Max. grinding height: 400 mm Table speed, longitudinal: 2 – 35 m/min Table speed, cross: 0.3 – 40 mm/stroke Rapid traverse: yes Grinding wheel dimensions: 300 / 76 x 40 mm Drive power: 4 kW Machine dimensions L x W x H: 2000 x 1850 x 2000 mm Machine weight: 2300 kg Hydraulic & electrical system dimensions L x W x H: 1200 x 800 x 2000 mm Hydraulic & electrical system weight: 650 kg Accessories / Special features: • Permanent magnetic chuck 630 x 200 mm • Automatic vertical feed with digital display Bsdpfx Absf Um Rao Ujlf • Manual dressing device • Coolant system • Separate hydraulic unit • Grinding wheel • Machine levelling elements Note: o Hydraulic cylinder for table stroke newly sealed o New filters in hydraulic unit o Handwheel adjustment for crossfeed newly mounted Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, REFORM AR 101/61 Blade grinding machine available immediately. 8100mm grinding length Bedpfeygvlujx Ab Uelf Please contact us for more information.

Condition: excellent (used), Year of construction: 2004, Table size 450 x 150 mm Max. Grinding area 450 x 150 mm Grinding wheel dimensions 180 x 13 x 31,75 mm Min. / max. distance table / spindle center 450 mm Table speed manual Cross feed manual Handwheel, transverse 1 revolution 5 mm 1 graduation mark 0.02 mm Vertical infeed manual Handwheel, vertical 1 revolution 2 mm 1 graduation mark 0.01 mm Grinding motor speed 2900 rpm. grinding motor 1,5 kW Machine dimensions L x W x H approx. 1820 x 1280 x 1950 mm Weight 870 kg Accessories / Special features: Bsdpoh Ukrqefx Ab Ujlf - 2-axis digital display - Permanent magnetic clamping plate L x W 450 x 150 mm - Manual grinding wheel dresser - Manual fine adjustment vertical + cross - 1 pc. grinding wheel with flange - Lighting system - exhaust system - Coolant system - Machine feet - CE conform Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: good (used), Hydraulic cylindrical grinding machine Center height 100 mm Center width 500 mm Grinding wheel diameter min./max. 200 - 300 mm 3 grinding wheel revolutions 2,250 - 2,420 - 2,680 rpm Workpiece spindle head: 8 workpiece speeds, adjustable 30 - 750 rpm. Spindle taper or inner taper of the workpiece spindle MK 4 Tailstock: Inner taper of quill MK 3 Quill travel 30 mm Table: Maximum table inclination +/- 6° Table speed, adjustable 0.1 - 6.0 m / min. Motor power 3 kW Dimensions L x W x H 1650 x 1350 x 1400 mm Weight 1900 kg Accessories / Special features: - Manual or automatic operation - Automatic infeed - Grinding wheel flange with grinding wheel - Wet grinding device Bodpfor E Aziex Ab Ujlf Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund-Wambel

Condition: good (used), functionality: fully functional, total height: 1,600 mm, total width: 700 mm, total length: 1,000 mm, grinding length: 250 mm, grinding width: 150 mm, grinding spindle speed: 3,150 rpm, disc diameter: 200 mm, Grinding stone diameter: 200 mm Clampingtable: 250 x 150 mm Diameter magnetictable: 120 mm Spindle speeds: 11 - 3.150 Rpm Country of origin: Italy Bljdpfsyg E Urox Ab Uef Machine LxWxH: 1.000 x 700 x 1.600 mm Machine weight: 250 kg

Condition: excellent (used), Year of construction: 2010, Cylindrical grinding machine Bedpfx Aewhm Rfeb Uolf Fab. Robbi Group Typ. Omicron 600 RT5 Year 2010 Technical data Make Robbi Group, IT Type OMICRON 600 RT5 Year of manufacture 2010 table Center width 600 mm Sanding length max. 600 mm Swivel range + 9° / - 5° Center height above table 160 mm Workpiece weight between centers 120 kg Workpiece weight for fly grinding 40 kg Tailstock Quill stroke 25 mm Quill diam. 43 mm Internal mounting cone CM 4 Workpiece headstock Rotation speed 0 - 600 Internal mounting cone CM 4 Spindle passage 26 mm Grinding wheel Diameter 450 mm Width min 20 / max 50 mm Bore 127 mm Equipment - Manual or automatic cycle - Automatic dressing compensation - Simplified presetting of grinding wheel and workpiece All information without guarantee. A demonstration under power is possible at any time in our exhibition hall.

Condition: used, Year of construction: 1970, surface area 600 x 200 mm Magnet size 500 x 200 mm dimensions of grinding wheel 225 x 25 x 51 mm Distance spindle/table max. 400 mm Table longitudinal feed 1 - 20 m/min creep feed 0 - 500 mm/min grinding wheel speeds 800 -4.200 U/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. The machine was overhauled in 2002. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Bsdpfxjyyqqmj Ab Ujlf Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2008, Deburring machine belt grinder Manufacturer: Weber Type: MK 900 Year of manufacture: 2008 Control: Weber "i-Touch" controller with multi panel Abrasive belt length: 2,620 mm Bjdpfx Absyy Dcvo Uolf Working width: 900 mm Working height: 900 mm (constant) Workpiece thickness: 3–120 mm (depending on model, up to 1–100 mm) Feed rate: 1–10 m/min (infinitely variable) Belt drive power: up to 37 kW (depending on station) Specially designed for processing oxy-fuel and plasma cut parts (heavy plate) 2426

Condition: good (used), Year of construction: 2001, Machine-Details: Stock-No. 1022-2276 Type of machine Surface Grinding Machine - Vertical Make REFORM Type AR 42 Typ 19 CNC Year of manufacture 2001 Type of control CNC Storage location Monheim (Germany) Country of origin Germany Delivery time Immediately Freight basis Ex warehouse, loaded on truck Blodpfsyx Duvsx Ab Uef Technical details: grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW weight of the machine ca. 50,0 t Additional information: Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Machine-Details: Stock-No. 1022-2424 Type of machine Surface Grinding Machine - Horizontal Make OKAMOTO Type ACC 64 CA-iQ Year of manufacture 2019 Type of control CNC Storage location Monheim (Germany) Country of origin Thailand Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details: grinding length 600 mm grinding width 400 mm workpiece height 400 mm weight of the machine ca. 4,5 t dimensions of the machine ca. 3592 x 3519 x 2203 mm Additional information: Horizontal surface grinder in almost new condition Operating hours: CNC on: 1198 hours Machine on: 1117 hours Automatic operation: 509 hours Grinding operation: 228 hours Okamoto Touch Screen Control Travel X-axis: 600 mm Travel Y-axis: 22.5 – 497 mm Travel Z-axis: 400 mm Speed range rpm: 1-2800 (stepless) Rapid traverse mm/min: 4000 Main drive kW: 7.5 Maximum table load in kg: 1000 Accessories: Bedpfxeyx Drho Ab Ujlf - Electro-permanent magnetic clamping plate: 400 x 600 P13 mm, height 80 mm (make Wagner) - 2 grinding wheel flanges - Table dresser - Automatic straight dresser, spindle box mounted - Automatic compensation of the wheel dressing amount - Automatic central lubrication - Ball screw in the Y and Z axes with AC servo motor and measuring system - Coolant system with belt filter system

Condition: good (used), Year of construction: 1995, functionality: fully functional, Machine-Details: Stock-No. 1022-2330 Type of machine Internal and Face Grinding Machine Make GLAUCHAU Type SIP 400x500 Year of manufacture 1995 retrofit Type of control conventional Storage location Monheim (Germany) Country of origin Germany Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details: internal diameter 800 mm grinding depth 500 mm swing diameter 850 mm weight of the machine ca. 6,4 t Additional information: Used internal cylindrical grinding machine with face grinding device in special design with enlarged swing diameter and extended, hydraulic transverse movement Reconstructed and modernized 1995 in the Glauchau manufacturer’s plant, put into operation 1996 1. TECHNICAL DATA 1.1 Working area Grinding diameter in the workpiece guard internal grinding, min./max. mm 30/630(800) External grinding, max. mm 800 Grinding depth, up to approx. mm 500 Table stroke mm 800 Workpiece diameter, max. mm 800 Swing diameter in workpiece protection, max. mm 800 Without workpiece protection, approx. mm 850 Bodpfx Aeyx Dmxeb Uelf Distance from workpiece spindle head to grinding spindle carrier, max. mm 1225 Adjustment of the internal grinding device on the table, max. mm 545 1.2 Workpiece headstock Cross shift, max. mm 650 Cross adjustment via gear motor and positioning device with HEIDENHAIN digital position display Swivel, max. degrees 15 Workpiece spindle Speeds rpm 16/22/32/ 45/63/90/ 125/18/250 Load capacity, max 1000 Spindle head (with bayonet flange) DIN 55021 size 11 Machine accessories: 2-axis digital displays made by HEIDENHAIN Coolant system with magnetic separator Fixators (machine shoes) Various grinding wheels Diamond dresser Large face plate Internal and face grinding device Halogen machine lamp Machine documentation

Condition: excellent (used), Year of construction: 1998, Erwin Junker BUAJ BN29C CNC Universal Cylindrical Grinder Excellent condition Can be viewed underpower and demonstrating if you wish to visit. Year 1998 Fanuc series 35i CNC Control Weight 2800kgs Dimensions approx 3000mm x 1850mm x 1800mm Specification - Distance between centres - 800mm Centre table clearance 150mm Work piece weight between centres, max 120kg Machine working capacity IT4 ISO Wheelhead Grinding wheel, max diameter - 400mm Grinding wheel, max, width - 63mm Grinding wheel, clamping diameter - 127mm Motor power - 5.5kW Grinding wheel, max. peripheral speed - 45m/s Wheel head, path of adjustment - 300mm Wheel head, adjustment angle - +45°/-15° Workhead Spindle taper - MK5 Spindle, stepless speed control - 23-291 or 56- 700rpm Work head, adjustment angle - 90° Tailstock Taper - MK4 Tailstock barrel, stroke 30mm Taper ratio, fine adjustment +/-0.15mm Blodpfx Abjyvupxj Uof Longitudinal feed Table travel 756mm Table, working travel speed 0÷7.5m/min Top table, swiveling +/8°30

Condition: good (used), grinding diameter 450 mm grinding length 600 mm centre height 140 mm workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m Blodpfx Aexcblqob Usf

Condition: good (used), Year of construction: 1985, functionality: fully functional, The ELB SW 4/2 is a classic conventional surface grinding machine. Specific data may vary depending on the version (e.g., VA I, VAI-Z), but the key technical specifications typically fall within the following range: Machine type: Surface grinding machine (horizontal) Working area Grinding length: approx. 450 mm Grinding width: approx. 250 mm Max. workpiece height: approx. 280 mm Grinding spindle Grinding wheel: Ø 250 mm × 25 mm width Bore: 51 mm Speed: approx. 1,430 / 2,900 rpm Spindle motor: approx. 2.5 kW (total power ~4.5 kW) Bodpfxoyy Aczo Ab Uslf Axis travels Vertical travel (Z): approx. 400 mm General data Total power: approx. 4.5 kW Machine weight: approx. 1,800 kg Dimensions (L×W×H): approx. 1,800 × 1,400 × 2,000 mm

Condition: excellent (used), max. workpiece diameter 300 mm Bjdpfx Absyyqufo Uslf hobbing length 1000 mm clamping length 2400 mm spindle head ISO 40 distance work spindle /surface of the table 180 - 330 mm surface area 2410 x 375 mm longitudinal feed 1000 mm vertical movement of the milling spindle 150 mm turning speeds 45 - 500 U/min weight of the machine ca. 5,6 t dimensions of the machine ca. 3,0 x 1,6 x 1,9 m

Condition: excellent (used), grinding length 600 mm grinding width 300 mm workpiece height 350 mm magnetic clamping plate, electical 500 x 200 mm grinding wheel diameter 225 x 25 x 51 mm Bljdpfjyyqt Iex Ab Uof total power requirement 4 kW weight of the machine ca. 2,1 t dimensions of the machine ca. 1,5x1,5x1,8 m

Condition: used, Year of construction: 2014, functionality: fully functional, grinding length: 600 mm, grinding width: 300 mm, Main machine data: - Table size (W x L): 600 x 300 mm - Electro-magnetic chuck: 300 x 600 x 70 mm - Grinding wheel size: 355 x 25 x 127 mm Drive performance: - Spindle motor: 2.2 kW Machine dimensions: Dimensions: - Length: 2,300 mm - Depth / Width: 1,550 mm - Height: 1,950 mm - Machine weight: 1,650 kg Standard equipment: - CNC-controlled vertical feed AD1 - Electro-magnetic chuck - Automatic demagnetizing device - Electronic cross-feed adjustment via operator panel - Coolant system with extraction, paper filter, and magnetic separator - Parallel dressing device (head-mounted) - Dressing device for table mounting - Motorized rapid traverse adjustment (vertical) - Grinding wheel flange Blodpfsyyymwsx Ab Uof - Grinding wheel - Halogen lighting - Balancing arbor - Balancing scale - 1 set of splash guards Incl. 3 grinding wheel flanges Incl. fine-pole electro-magnetic chuck 300 x 600 mm Pole pitch: 3 mm, pole width: 1 mm Instead of standard electro-magnetic chuck

Condition: used, Year of construction: 1998, Technical details: height of profile: 180 mm max. dia. of grinding wheel: 200 / Topfscheibe mm grinding wheel hole diameter: k.A. grinding spindle speed: 2800 U/min Table dimensions: LxB: 500 x 160mm mm voltage: 220 / 380 V total power requirement: 3,0 kW weight of the machine ca.: 0,57 t dimension machine xH: 1,28 x 1,0 x 1,75 m Bljdpju Ngrqefx Ab Ujf Application for face grinding Magnet mount: LxW = 680 x 200mm; tilt approx. 15°; swivel 360° via radial scale magnet: Type S2D; permanent magnet, clamping surface 300 x 150mm. Grinding wheel support: -adjustment vertical = length 180mm manual; swivel = approx. 45° right/left manual. Operation via control panel on machine. Coolant tank with pump and feed *

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, machine/vehicle number: 1, center height: 150 mm, center width: 480 mm, grinding diameter: 299 mm, New arrival 1 Hydraulic Universal External and Internal Cylindrical Grinding Machine TSCHUDIN HTG 410 U – Year 1988, partial overhaul in 2026 – 150 mm center height x 480 mm center distance – workpiece spindle head MK 5 with stepless speed adjustment. Grinding wheel left and right – swiveling internal grinding attachment with 18,000 RPM Machine equipped with four-axis digital readout – X-axis – Y-axis and rotary encoder with one-micron resolution when swiveling the universal grinding spindle head and workpiece spindle head! Pneumatic air cushion lifting for effortless swiveling of workpiece spindle head and grinding spindle head. Machine includes four-jaw chuck, halogen lamp, paper band filter, folding dresser, and balancing arbor. Guideways in X-axis newly scraped – machine thoroughly inspected by specialist. Automatic cycle with "rapid traverse to automatic infeed – dwell time – retraction – infeed dimension remains set". Very little used machine from prototype manufacturing! Price on request (Domestic sales plus 19% VAT.) Technical data not binding – subject to prior sale and errors. Best regards, INDUBA GmbH Bjdpfxovdumbj Ab Ujlf Mathias Becker D-78628 Rottweil

Condition: good (used), Year of construction: 2013, grinding diameter 140-355 mm grinding length 3000 mm Bedpfeynmpyox Ab Ujlf centre height 260 mm weight of the machine ca. 8,3 t dimensions of the machine ca. 8500 x 3500 mm SA 6Ux3000 external cylindrical grinding machine Year of manufacture: 1981 Retrofit: 1 x 2013 SERWEMA Maximum grinding diameter with tailstock: 140 mm Maximum grinding diameter without tailstock: 355 mm Maximum grinding length: 3,000 mm Center height 260 mm Workpiece weight max. 500 kg Machine footprint 8500 x 3500 mm Machine weight 8500 kg

Condition: good (used), Year of construction: 1989, grinding length: 400 mm, grinding width: 200 mm, Grinding area: 400 x 200 mm Magnetic table: 400 x 175 mm Blodpfxov Tcy Uo Ab Usf Height adjustment: 410 mm Grinding stone dimensions: 225 x 25 x 50.8 mm Grinding toe speed: 1420 / 2840 rpm Complete with: - Coolant system - Hydraulic unit - Documentation Country of origin: Germany Motor power: 1.5 kW Machine LxWxH: 2200 x 1500 x 2100 mm Machine weight: 1100 kg

Condition: used, Engraving Cutter Grinding Machine MBB - Maschinenfabrik Baden Baden Type FSS Serial No. 2861 Year of manufacture: 1987 Bjdpfjyxy S Rjx Ab Uolf Grinding wheel diameter: 100 mm Grinding wheel speed: 4,600 rpm Motor power: 0.25 kW Power connection: 380 Volt, 50 Hz - Collet clamp device for collet 355E (saw thread M20x2 mm) - Including 3 collets Ø 0.5 - 6.0 - 17.0 mm - Maximum collet bore: 18 mm - Grinding wheel dressing device - Cup wheel Ø 100 mm - Operating manual Space required (L x W x H): 450 x 450 x 300 mm Weight: 32 kg Very good condition

Condition: refurbished (used), machine/vehicle number: 2257, Manufacturing origin France Voltage 380/50/3 Netweight 3000 kg Custom position 8460.29 20 Dimensions 2400x1550 mm TECHNICAL DATA Diameter capacity 80 mm Type 2HA : 120 mm Bsdjfnm Iiepfx Ab Uolf Maximum infeed grinding length 200 mm Maximum throughfeed grinding length (with normal-type guides) 300 mm Grinding wheel : -diameter 400 mm -maximum width 200 mm -bore 203.2 mm Driving wheel : -diameter 254 mm -width 200 mm -bore 127 mm Main drive motor 11-22 kW Driving wheel motor 1,1 kW Driving wheel speed 10 – 200 U/Min Standard accessories : 1 flange with grinding wheel 1 flange with driving wheel 1 workpiece support bridge 1 set of shims for workpiece support -Hydraulic dressing and trueing device for grinding and driving wheels -Variable speed drive of driving wheel -Electrical equipment for 3x380 v, 50 Hz -Main drive motor, 11 kW -Ammeter for main drive motor Starter keys and operating manual errors and omissions excepted data given without obligation.

Condition: excellent (used), Year of construction: 2011, Profile Belt Sander, PS0 Rasprofil by Zimmermann with Extensive Accessories Belt sander with tilting table and additional fittings for rasping. Ideally suited for model making and mold construction. Designed for precision contour sanding. All settings made via clamping lever and fine adjustment. Drive motor: 400 Volt, 1.1 kW Table tiltable up to 45 degrees forwards and up to 20 degrees backwards Machine table approx. 400 x 400 mm Upper extraction arm foldable for sanding large parts. By locking the freestanding profile rail in the upper machine section, high angular accuracy can be achieved. Includes three reversible profile rails (15, 30, and 40 mm, straight and radius profiles). Several sanding belts included, see photos Three unused rasps Extraction connection 80 mm Waldmann mounted work light Original paint, touched up in places CE marking Very well-maintained machine from prototype manufacturing in the motorsport department of a Wolfsburg automotive manufacturer. Apparent minimal previous usage. Bodpjw Iqvqefx Ab Uelf Dimensions approx. 600 x 850 x 1350 mm (LxWxH). Weight approx. 220 kg. The machine can be demonstrated on-site by appointment. We only offer machines that are ready for demonstration in our warehouse. See 'other offers from this seller.'

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, The machine is in very good mechanical condition and can be demonstrated under power. A selection of grinding pins, which can be used with the machine, can be selected and matched on site. The original operating manual and wiring diagram are available. Bedpfx Aeyx Dqdob Uelf
