Used Slitter Rewinder for sale (319)

Year of construction: 2008, condition: used, Offered for sale is a slitter rewinder with rewinding and unwinding units. Roll width: up to 1060mm. Additional technical specifications: Processable grammage: 60-173g/m², maximum unwind width: 1060mm, maximum parent roll diameter: 1200mm, maximum parent roll weight: 600kg, parent roll core inner diameter: 70mm, rewinding width: 530-1060mm, maximum rewind diameter: 250mm, finished roll core inner diameter: 51mm. Control system: Electronic machine control system with operator panel and OMRON F7 frequency inverters. Equipped with roll unwinding unit, deflection and guide rollers, slitting unit, rewinding unit, safety guard and separate electrical cabinet. Inspection possible by arrangement. Hodpfxoz N E Uzj Ak Uonu

Condition: ready for operation (used), Year of construction: 1997, year 1997, speed: 500 m/min, roll dimension: 450 – 1550 mm, Max diameter of unwinding roll 1500mm Max width 1300 mm Min width 380mm Brakes - hydraulics and disc brakes Hsdsxwp Uvepfx Ak Ujnu Max weight of unwinding roll - 2000 kg

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 3769, total width: 1,667 mm, roll diameter: 1,067 mm, overall weight: 1,360 kg, product width (max.): 1,067 mm, input voltage: 460 V, ROTARY SHEAR SLITTING STATION: The rotary shear slitting station is a modular design allowing detachment from the main frame. The powered 60mm (2.367 inch) diameter upper and lower knife shafts drive the male and female shear knife assemblies. The male and female shear knife assemblies may be positioned anywhere within the web area and are held in position by eccentric locking keys. The removable male shear knife shaft assembly is mounted to a rigid dovetail bar assembly. The dovetail bar assembly is adjustable axially for shear knife face contact pressure and rotationally for knife overlap. A two-position lock lever assembly is used to rotate the dovetail bar assembly 900to the open position for removal of knife shaft assembly or closed in the slitting position. Rotary shear drive speed is proportional to web speed or manually controlled by the operator. REWIND: Hnedjy Ufgxjpfx Ak Ueu The slit web is alternately rewound on the duplex air expanding rewind shafts. Flange mounted rewind shafts provide ease of change to other desired types or diameters. The outboard rewind support swings open for removal of finished rolls from the cantilevered rewind shafts.

Condition: excellent (used), Year of construction: 2014, Ref:11125 . Fotoba XLD 170 + Fotoba REW 104 Slitter Rewinder. 2013 Fotoba XLD 170 High speed cutter. Primarily used for digitally printed wallpaper up to a maximum thickness of 0.8 mm. Including polycarbonate, photo paper, vinyl, self adhesive vinyl, PVC, film, Duratrans, TDF, canvas, laminated or encapsulated prints, etc. Using cut marks generated by the RIP and with 'True Image Edge Tracking', the cutting is executed with precise accuracy. The sensor automatically follows the prints. Extremely easy roll loading. Hodpfx Aszmx Nusk Uonu 'Digitrim' function enhances the versatility of the XLD 170. Features & specification: Self squaring to the edge of the image 'X' Automatic tracking of the image edge 'Y' Memory channels to store different cut marks. All mechanisms controlled by stepper motors. Self sharpening knife system. Vertical slicers; single 8 mm double or adjustable double. Adjustable cutting lengths & quantities - accuracy +/- 1 mm (0.039") Max. linear speed: 18m / 50ft. Cutting width, Max: 170 cm (67") Min: 28 cm (11") Max. load 200kg (440 lbs), max. diameter 60 cm. 2014 Fotoba REW 104 Automatic in-line coreless rewinder. Made for non-stop industrial production. Can rewind two rolls simultaneously up to 20m long. Can wind up tiles of the same job for better logistic. Maximum roll diameter: 90 mm Maximum rolled weight: 8 kg

Condition: excellent (used), Year of construction: 2023, machine/vehicle number: 454 31178 T15, Max. master reel width: 1400 mm Max. master reel weight: 1000 kg Max. master reel diameter: 1000 mm Minimum standard slit: 25 mm Rewinding reel maximum diameter: 610mm Maximum production speed: 1000m/min Separated shaftless unwinder Automatic positioning of the web guide camera Razor blades/circular knives/pneumatic knives with automatic slit positioning ASP Automatic tape applicator Hnedezhwgbepfx Ak Uou Linear lay-on rollers 4 differential or pneumatic shafts, mounted on two turrets with automatic reel change Automatic slit reel unloading and positioning Automatic core positioning 6 motors Automatic web tension control through loading cells The machine has chucks for 76 and 152mm The machine has positioning for top knife AND bottom knife; the Automatic Slit Positioning handles the positioning of both the knife and the counter knife APPLICATIONS: Bags, Food packaging, Outer packing, Soft drinks/mineral waters labelling, Aluminum covers for pharmaceuticals MATERIALS: PE, Aluminium, Papers & Laminates

Condition: like new (used), Year of construction: 2015, functionality: fully functional, mandrel diameter: 76 mm, product width (max.): 1,600 mm, Eruomac rewinder / slitter TB 6.10M Year of construction 2015 Unwinding Roll width 1600 mm Roll diameter 400 - 1200 mm Equipped with web edge control Hjdpfxotyxu Ee Ak Ujnu Rewind Roll width 1600 mm Roll diameter 350 - 1000 mm

Year of construction: 1997, condition: used, Max. machine speed: 600m/min, min./max. parent roll width: 600mm/1650mm, max. parent roll diameter: 1000mm, max. roll weight: 2000kg, unwind core diameter: 76mm/152mm, min./max. slitting width: 190mm/1200mm, number of winding stations: 6, number of winding stations for slit widths from 600mm: 2, material thickness range for monofilms: 20µm-170µm, laminates: 40g/m²-190g/m², composite materials: up to 200g/m², rewind core inner diameter: 70mm/76mm/152mm. Equipped with shear slitting with upper and lower knives, contact rewinder with individual lay-on rollers, spreader roller, material infeed device, ionization system at the unwinder and rewinder, adjustable guide rollers at the unwinder and edge trim extraction system. Documentation available. Inspection possible by arrangement. Hnodpfx Akjz R A Ihj Uou

Year of construction: 2014, condition: good (used), DT250 Slitter / Rewinder Year of manufacture: 2014 Machine type: Tabletop slitter rewinder for narrow web label materials Condition: Used – in good working condition Technical Data Maximum web width: 254 mm Maximum unwind diameter: 450 mm Maximum rewind diameter: 360 mm Rewind shafts: 2 × 76 mm 1 × 40 mm Slitting system: Rotary shear slitting with knife holders Accessories and Tooling Spare slitting knives included Core adapters included Machine Dimensions Length: approx. 1300 mm Depth: approx. 700 mm Height: approx. 600 mm Application The Daco DT250 is designed for finishing self-adhesive label materials and is ideally suited for digital label production environments such as HP Indigo, Konica Minolta AccurioLabel, Xeikon, and similar presses. Typical applications include: - Slitting wide master rolls into multiple narrow label rolls - Rewinding and roll inspection - Production of finished label rolls for customers - Converting digital label print jobs into finished products Hnsdpfx Aeyt H R Ijk Usu Advantages of this Machine - Compact and space-saving tabletop design - Ideal for small and medium-sized label converters - Reliable and user-friendly operation - Suitable for a wide range of self-adhesive label materials - Cost-effective finishing solution for digital label production

Condition: used, Rollenschneider Aufwickler / Slitter Rewinder Kampf Conslit 16/06 ÜK in good working condition. Rollenschneider Aufwickler / Slitter Rewinder Kampf Conslit 16/06 ÜK Baujahr / Year 1999 - Serial-No. 210271 Arbeitsgeschwindigkeit / Speed max. 550m/per Minute Arbeitsbreite / Working width max. 1650mm Schnittbreite min. 50mm bei Hülsen 70 & 76mm /  Cutting width min. 50mm  Cutting width 70 & 76mm Hedpoz H A Rgjfx Ak Usnu Schnittbreite min. 200mm bei Hülsen 152mm /  Cutting width min. 200mm  Cutting width 152mm Zu verarbeitendes Material / Material to be processed: Kunststofffolien aus / plastic films made of: PE, PP, PA, PET, PVC, Papiere und Laminate Hartfolien / hard films ca. 10 - 250 µm Weichfolien / Soft films ca. 20 - 500 µm Aufwicklung / Rewinder Aufwickel-Druchmesser / Rewinder Diameter max. 610mm Aufwickelhülse / Winding Sleeve: Pappe, Kunststoff oder Metall / Cardboard, Plastic or Metal Innendurchmesser d. Hülse / Diameter inside 70mm, 76mm and 152mm Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: used, Year of construction: 2022, Maximum parent roll width: 1420 mm Minimum parent roll width: 600 mm Maximum parent roll diameter: 1500 mm Maximum parent roll weight: 2500 kg Maximum unwinding tension (Ø1500 mm): 600 N Minimum unwinding tension (Ø1000 mm): 40 N Minimum standard slitting width: 100 mm Maximum rewinding width: 1400 mm Maximum rewinding diameter: 1050 mm Maximum rewinding weight: • Ø76 mm shaft: 600 kg • Ø152 mm shaft: 1000 kg Maximum rewinding tension: 600 N Maximum production speed: 600 m/min Power supply: 3 x 400V 50Hz Installed power: 30 kW Compressed air: 6 bar, dry Hnedjyx Uy Aepfx Ak Ueu Materials to be slit: • Paper-based / liner-based packaging laminates. • Board from 80 to 300 g/m². Unwind section: A separate between-centers unwinder, type T9, 1500 mm diameter, including: • Hydraulic cylinder control for lifting parent rolls from the floor. • Two motors driving the unwinding roll, controlled by an ultrasonic diameter sensor and a tension-control dancer roller. • Two pneumatic expanding adapters, SVECOM, for 70/76 mm (3”) cores. • Two pneumatic expanding adapters, SVECOM, for 150/152 mm (6”) cores (mounted on the pneumatic end adapters). • Floating edge-correction roller. • Automatic web guiding system, FIFE DP20, with SE26A photoelectric sensor, ±100 mm correction via electric actuator — for controlling sheet edge or continuous printed line. • Connecting walkway allowing web threading at floor level while keeping full access to the slitting station. • All web path rollers are anodized. • Safety guarding for operator protection. Slitting section: A slitting station with individual pneumatic knives and circular counter-knives: • Shear cut performed against the counter-knives. • Counter-knife shaft driven by an independent motor; counter-knife shaft is pneumatic. • Pneumatic knife holders mounted on a beam with a dovetail guide (TIDLAND) and an air supply manifold for individual activation. • 10 slitting sets, each including: Individual TIDLAND pneumatic knife holder (25 mm width) and double-bevel circular knife Ø 90/60 mm. • Set of multi-groove counter-knife rings, 5 mm pitch, 50 mm length. Web separation section: • A separator roller driven by the slitting motor; angle and curvature fully adjustable. Lay-on roller: • Lay-on roller made of anodized ground aluminum or polyurethane (depending on materials). • Pressure is adjustable and synchronized with winding diameter. • Roller is removable. Automatic splicing / transverse cutting system: • Hydraulically operated pivoting arm including a transverse knife with linear motion and a backing plate for securing the web onto new cores. Trim extraction system: • Trim suction unit with two width-adjustable nozzles. • Turbine enclosed in a sound-insulated cabinet, conveying trim to a centralized system or container (not included). Rewinding section: • Motorized turret (two-position) supporting two rewinding shafts. • Rewinding shaft drive by an oversized asynchronous motor. • Hydraulic centering point for the active rewinding roll. • Two pneumatic expanding shafts Ø76 mm (3”), max load 600 kg each, equipped with full-width rubber strips with individual bladders. • Two pneumatic expanding shafts Ø152 mm (6”), max load 1000 kg each, also equipped with full-width rubber strips with individual bladders.

Condition: used, Year of construction: 2014, Material: PET aluminum-metallized film Material thickness: 9–50 μm Web width: 500–2000 mm Roll width: 2100 mm Web diameter (unwind): max. φ1150 mm Web weight (unwind): max. 1500 kg Product winding diameter: • φ600 mm (3” friction shaft) • φ750 mm (6” air shaft) Winding shaft load: max. 500 kg/shaft (center-supported) Core dimensions: • Web core: 3” (φ76.2–76.5 mm), 6” (φ152.4– 153 mm) • Product core width: 100–1050 mm Slit width: 200–1950 mm (up to 5 slits) Machine speed: max. 400 m/min Typical operating speed: 200–250 m/min Unwinding tension: • 50–500 N (φ650 mm or less) Hnedpfx Aex Ez Umek Usu 1. Unwinding Section • Shaftless single-axis fixed unwind • Direction: upward or downward • Automatic tension control with feedback detector • Dancer roll included • Core clamping: rotary mechanical chuck • Core sizes: 3” standard, 6” via adapter • Web alignment: manual ±5 mm, automatic ±100 mm 2. Main Drive Rollers • Multiple rollers with specified diameters and surface finishes • Nip and touch rollers with pneumatic pressure control 3. Slitting Mechanism • Upper/lower NC shear cutter • Number of blade units: 6 upper + 6 lower • Slit width adjustment via touch panel • Accuracy: ±0.1–0.2 mm • Dust suction: upper blade nozzles + lower blade suction • Optional razor cutter (manual adjustment) 4. Mini Winder Placement: below slitter Units: 2 (left / right) Drive: AC servo motor Tension: dancer roll control Traverse width: 300 mm Winding diameter: φ500 mm 5. Winding Section • Duplex center drive • 3” air friction shaft + 6” air shaft • Automatic tension control linked to winding diameter • Touch roll with pressure control • Core positioning via collar bar 6. Product Discharge • Hydraulic lift tray • Motorized slide-out with tilt mechanism Electrical & control: Line motor: 7.5 kW AC servo Winding motor: 11 kW AC induction Unwinding motor: 11 kW AC servo Static eliminators: 5 units (Keyence SJ-HA) Control panels: main panel, winding panel, unwind panel, mini winder panel, auxiliary panel PLC: Fuji Electric Utilities, dimensions & environment: Power supply: AC 200 V, 60 Hz, 3-phase Power consumption: 70 kVA Air supply: 0.5 MPa, 500 L/min (dry air) Machine weight: approx. 12 tons Paint color: urethane coating (E-31872) Installation environment: cleanroom Class 10,000 Floor load capacity requirement: ≥ 2 ton/m²

Condition: ready for operation (used), Year of construction: 1985, max web width 1900 mm Hsdpfx Asw Nvkijk Ujnu

Condition: used, Year of construction: 1996, Technical Data: Working width: 1200 mm Materials: BOPP, OPP, CPP, PET, OPA Hjdpfxox Ezwzj Ak Usnu Parent roll diameter: 800 mm Final roll diameter: 600 mm Maximum speed: 300 m/min Web guiding system: Yes Knife type: Razor & rotary blades Trim exhauster: Included

Condition: good (used), functionality: fully functional, Used slitter rewinder Goebel 2 shafts on unwinder max diameter on unwinder - 650 mm max web widght - 2200 mm Hnsdpfxjyqx Dne Ak Uju

Year of construction: 2021, condition: excellent (used), machine/vehicle number: 29092021, T-503 PAPER SLITTER REWINDER MACHINE GENERAL INFORMATIONS: Machine weight : ≈ 2000 kg Number of Knives : 12 Units Bobbin Loading Stand : Yes Air Shafts : Yes Hodpfx Ajy Twcijk Uenu Tension Control System : Yes Brake System : Yes Speed Control System : Yes Trucker motor power : 5,5 KW Top rewind motor power: 7,5 KW Bottom rewind motor power : 7,5 KW Unwind: 1250mm Rewinder: 920 mm Width: 1200 mm

Condition: used, functionality: fully functional, working range: 2,320 mm, Slitter rewinder Goebel Hsdpfoypua Aex Ak Uenu web widht - 2320 mm rotary mechanism at the receiving station

Year of construction: 2020, condition: new, A fully automated film rewinding machine according to GMP guidelines. Foil rewinding machine type FUM-900 CP Hnjdpfofwfpbjx Ak Ueu This film rewinding machine is used to rewind film rolls that have run in large systems or are not wound with the correct winding tension, and thus to prepare them for further processing. It was designed according to the special pharmaceutical guidelines and for the processing of PVC film. Advantage of our machine: with two separate drives, we can guarantee both right and left winding. Technical details: Width: 1,600 mm Depth: 850 mm Height: 1,100 mm Materials: In contact with the product: 1.4301 / acrylic Performance: up to 120 m / s Speed: infinitely variable Ø film rolls: max. 450 mm Connection: 230 V / 50 Hz Drive: direct current 0.25 kW

Year of construction: 2025, operating hours: 140 h, condition: like new (used), functionality: fully functional, machine/vehicle number: X-1500, Equipment: CE marking, Only 12 months old – like new , only 140 working hours. Immediate availability. Full documentation + CE. Can be demonstrated producing corners. Unique capability: up to 130×130 mm. Perfect condition – ready for production. Manufacturer: SIA Model: Edge Protector 130x130, Slitter 1500x1500, SCC Base 7 Year of Manufacture: 2025 Working Hours: 140 hours Technical Condition: Like new State: In production Edge Protector Specifications: - Size: Minimum 35x35mm, Maximum 130x130mm - Wall Thickness: Minimum 1.5mm, Maximum 8mm (10mm optional, depending on paper thickness) - Maximum Reels: 12 + 1 craft - Speed: 50m/min (60m/min optional, available on data regulation) Hnjdjz I S Idspfx Ak Ueu - Glue heating - 7,5kw. Slitter Rewinder Specifications: - Reel Size: Maximum 1500x1500mm, Minimum Width 500mm - Minimum Cutting Width: 35mm - Number of Knives: 15 - Speed: Maximum 250m/min - Electrical Power: 11kW SCC Air Compressor Specifications: - Base: SCC Base 7 VSD TD - Electrical Power: 7.5kW - Air Volume: 0.92m³/min - Tank Volume: 500 liters Dimensions: EDGE PROTECTOR ; SLITTER : Length: 26000 mm; 3000MM - Width: 3000 mm ; 2300MM - Height: 2500 mm ; 1300MM - Weight: 6000 kg ; 3500KG Keywords: corner production line, cardboard corner machine, edge protector machine, packaging corner line, cardboard profile machine, V profile machine, 130×130 mm corner, automatic corner cutting, high‑speed corner line, packaging machinery, cardboard converting machine, protective corner production, industrial packaging equipment.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 120 h, functionality: fully functional, machine/vehicle number: 638 TTR, film width: 1,100 mm, The Slitter Dusenberry is a slitting and rewinding machine manufactured by Dusenbery® Converting Systems. Hedpfez Rq Ebox Ak Ujnu

Year of construction: 2026, condition: new, functionality: fully functional, BRONSE ULTIMA 250 | Fully Automatic Stretch & Cling Film Slitter Rewinder Hnedsy N Un Ijpfx Ak Uju The ULTIMA 250 is a fully automatic, high-performance slitting and rewinding machine engineered for extreme ease of use, maximum versatility, and continuous industrial production. Built with high-end electronic and mechanical components, it ensures precise tension control and reliable long-term operation. Key Applications & Versatility: Multi-Product Output: Seamlessly produces stretch film hand rolls, machine rolls, and jumbo rolls, as well as PVC/PE cling film rolls. Flexible Core Diameters: Easily adjustable to produce rolls with various core diameters to meet rapidly evolving market demands. Advanced Slitting Capability: Equipped with a precise longitudinal cutting platform. Technical Features & Dimensions: Slitting Configuration Options: From 50 mm x 10 rolls up to 250 mm x 2 rolls. User-Friendly Interface: Operated via an embedded main control panel for flexible, intuitive, and safe management. Low Maintenance & High Ergonomics: Designed so that all manual operations and routine maintenance can be easily performed, even by inexperienced operators. For detailed technical specifications, quotation, and video demonstrations, please send us an inquiry directly through Machineseeker.

Condition: good (used), Year of construction: 2019, functionality: limited functionality, machine/vehicle number: 377/2019, cutting width (max.): 1,000 mm, type of input current: three-phase, input current: 25 A, working width: 1,050 mm, input voltage: 380 V, input frequency: 50 Hz, Equipment: documentation/manual, TTR and hot foil slitter/rewinder. TTR1000 Material width: max 1050mm Max unwinding diameter: 700mm Max rewinding diameter: 150mm Max jumbo core length: 1100mm Rewinding shafts with tooling: 1 inch and 1/2 inch Hjdpfx Akjz R Rdrj Uenu Slitting system: razor blade manual set 2 rewind turrets (upper and lower) for easy change The machine is generally in good condition. It has tension control issues on one of the shafts, likely related to the magnetic powder clutch. The machine is still installed and ready for production, so we can arrange a live demo.

Year of construction: 1986, condition: used, We offer for sale a complete paper roll rewinder with high utility value. The machine has undergone a range of significant upgrades, greatly enhancing its reliability, quality of operation, and performance. The unit is fully assembled and ready for immediate use. Technical Data: - Machine type: FAMPA KM36 slitter - Year of manufacture: 1986 - Manufacturer: Fampa Beliot, Poland - Working width: up to 2450–2500 mm - Max. working speed: up to 1000 m/min - Paper grammage range: 30–400 g/m² - Max. unwinding roll diameter: Ø 2000 mm - Max. winding roll diameter: Ø 1500 mm Machine Upgrades and Advantages: - Drive system upgrade – value approx. EUR 95,000. The old thyristor (DC) drive has been replaced with a modern system based on two Siemens (AC) motors. - New DIENES knife holder (Germany) – value approx. EUR 50,000. Completely new knife carriage, capable of operating up to 9 knives simultaneously. - GOHA ES automatic unwinder – value approx. EUR 70,000. - ProfiCool Genius PCG 300 01-NEB chiller – capacity 2.9 kW. Hnjdpfx Asx Sdctok Usu - Control cabinet modernization – improved safety and operational reliability. Commercial Information: The machine is complete and in our plant storage. Location: 57-256 Bardo Availability: Immediate For further information or to arrange a viewing, please contact us.

Condition: refurbished (used), Year of construction: 2016, Stainless Slitter 1500x3, made SAMO OCEMI Completely revamped in the year 2016. Technical specifications Thickness minimum: 0,4mm Thickness maximum: Up to 4mm with Rm 400N/mm2 | Up tp 3mm with 700 N/mm2 Hodsymcmfepfx Ak Uonu Coil width: max 1.540 mm. Max coil weight: 16 t Direction: left to right Speed: up to 150 m/min. Scope of supply · Coil car, hydraulic, Over floor · Decoiler, hydraulic expansion, with DC motor 28 kW-717-2.200 rpm, for dynamic brake and energy recovery. Stationary disk brake. Motorized snubber roll. Paper rewinder. Alignment. · Coil opener with telescopic table. · Feeding unit with pinch-roll and 3-rolls straightener. · Centering unit (motorized) with 3 flattening rolls (poliurethane). · PVC film applicator (new 2017) · Slitting head, shaft diam.: 200 mm. DC motor 72 kW 780-2.652 rpm + stationary brake. · Turnstile knife charger – 2 arms couples. · Tension pinch-roll DC motor 23 kW 1.960 rpm + stationary brake. Scrap table, movable, with scrap conveyor. · Scrap rewinder, single drum dimension 600x600. Ac motor 15 kW with inverter. · Bypass table (loop) · Braking car (movable) with: - double separating roll - Deburring pinch-roll (new in 2017) - Felt press - Braking rolls-with DC motor 33kw-2.550 rpm for strip tension adjustment and energy recovery. - Cross cutting shear (crop shear) - Deflector roll - Recoiler, hydraulic expansion, separating arm with automatic lifting system. DC motor 114 kW 800-2.400 rpm + stationary brake. · Discharging coil car, over floor, with press arm. · Turnstile arm 4 x 20 t, motorized · Electric EQUIPMENT (NEW in year 2016). Supply voltage 3x380V Consisting of: Cabinet Dimension mm 5.600 x 600. With PLC Siemens S7-300. N. 3 operator switchboards. The main switchboard with HMI touch-screen Siemens Touch · Hydraulic equipment. Hydraulic power pack with oil-air cooling. Manifolds with electric valves on each machine, 24 V DC · Complete safety fences, mechanical/optical. · Cutting tools (knifes approx. 160 pieces, spacers, separating discs..). Documentation Foundation drawings Electric drawings. Hydraulic plan. PLC and HMI Software. CE declaration of Conformity Thickness minimum: 0,4 mm Thickness maximum: Up to 4 mm with Rm 400N/mm2 | Up tp 3 mm with 700 N/mm2 Coil width: max 1.540 mm Max coil weight: 16 t Speed: up to 150 m/min Direction: left to right

Condition: good (used), Year of construction: 1975, functionality: fully functional, total width: 1,900 mm, roll diameter: 1,800 mm, overall weight: 3,100 kg, product width (max.): 1,900 mm, input voltage: 440 V, Slitter rewinder 190 wide DC motors Shaftless input with hydraulic platform to raise the web, the system supports core sizes ranging from 3 inches up to 12 inches and processes of 150 to 1900 mm width webs, output core sizes ranging from 3 to 12 inches  Hnjdpfx Aksy Ufkqe Uju

Year of construction: 1985, condition: used, functionality: fully functional, PM 5 PAPER MACHINE + STOCK PREPARATION / DEINKING PLANT + GOEBEL U16M !contact for full details and photos! Package sale of an integrated paper production installation in Hainsberg, Germany. The package includes the PM 5 paper machine, its associated stock preparation and deinking plant, and a Goebel U16M roll slitter rewinder. PM 5 was originally built in 1985 and modernised several times. Main sections: approach-flow system – PAMA; headbox – Voith; Fourdrinier section – PAMA; top-wire former – Valmet; press section – PAMA; dryer sections – PAMA; SpeedFlow system – Voith; after-dryer section, calender and Pope reel – PAMA. Reported modernisations: Valmet top-wire former (1994); approach-flow system expansion/modernisation (2002–2003); MAP quality-control system (2006); Voith SpeedFlow (2009); automatic tail cutter (2025). PM 5 specifications: Hsdpoz Hvmhjfx Ak Uonu • Working width: approx. 2,730 mm; trimmed width: approx. 2,640 mm • Maximum speed: up to 600 m/min • Maximum gross capacity: up to 150 tonnes/day • Basis-weight range: approx. 45–130 g/m² • Grades produced include office, copy, writing, printing, envelope and newsprint papers • Installed electrical power: approx. 2.5 MW • Steam consumption: up to approx. 16 tonnes/hour Stock preparation/deinking plant: • Normal capacity: approx. 125 tonnes/day; up to approx. 140 tonnes/day under suitable raw-material and process conditions • Essential components listed in the available technical documentation are reported to remain installed on site • Older Siemens S5 and Teleperm control and automation system Goebel U16M: built in 2005, machine no. 053-9031. Working width 2,800 mm; maximum speed 2,000 m/min; maximum unwind diameter 2,000 mm; maximum rewind diameter 1,500 mm; minimum cutting width 150 mm. Available accessories include winding shafts and an edge-trim extraction system with shredder and flat turbo disintegrator. Operating status: Production stopped on 23 January 2026. According to the seller, PM 5 and the stock preparation/deinking plant were operating until the controlled shutdown. The Goebel U16M was also reported operational until that date, with no significant functional faults Maximum capacities depend on paper grade, raw material and operating conditions. Inspection by appointment. Price on request.
