Used Start Hole Edm Machine for sale (69,592)

Condition: good (used), Year of construction: 2017, Datasheet: en-datasheet-robocut-ds-c600ib     FANUC ALPHA C600iB – 2017 Wire Cutting EDM Machine Standard specifications – Maximum workpiece dimensions: 1050 × 820 × 300 mm – Maximum workpiece weight: 1000 kg – XY axis table travel: 600 × 400 mm – Z axis travel: 310 mm – UV axis travel: 200 × 200 mm – Maximum taper angle: ±30° / 150 mm – Minimum step increment: 0.0001 mm – Wire diameter: Ø 0.10 to Ø 0.30 mm – Maximum wire weight: 16 kg – Footprint (W × D): 2440 × 2680 mm – Machine weight (approx.): 3000 kg – Controller: FANUC 31i-WB – Part program storage size: 4 MB Acoustic noise level – LPA: 64 dB – LPCpeak: 81 dB Optional equipment Z axis 400 – Z axis travel: 410 mm – Maximum workpiece dimensions without automatic front door: 1050 × 820 × 400 mm – Footprint: 2790 × 2680 mm Automatic front door – Maximum workpiece dimensions: 1050 × 775 × 300 mm 45° die guide – Maximum taper angle: ±45° / 70 mm Rsdpsyccqiefx Aglsn 30 kg wire feed unit – Maximum wire weight: 30 kg

Condition: good (used), Year of construction: 1995, 1 used hydraulic punching machine Manufacturer: Mubea Type: KLH 500 / 610 Year of manufacture: 1995 Rodpfswxy Dgjx Agljn - Punching force: 50 tons - Stroke: 60 mm - Punches up to Ø 30 mm in 15 mm, Ø 50 mm in 9 mm, Ø 100 mm in 4.5 mm - Throat depth: 610 mm - with support table

Condition: good (used), Year of construction: 2008, CNC Deep Hole Drilling Center Machine type: Degen UTB800/G Redpfjwxaf Rsx Agljn Control: Heidenhain TNC310 Year of manufacture: 2008 TECHNICAL DATA: Travel distances: X-axis: 630 mm Y-axis: 400 mm Z-axis: 800 mm W-axis: 600 mm Feed rate: 6,000 mm/min Swivel range: Z: +/- 10° Table size: 1,100 x 650 mm Max. table load: 2,000 kg Tool holder: HSK 63 Max. speed: 4,000 rpm Drive power: 7.5 / 5.5 kW Drilling diameter: 4–25 mm Accessories: Electronic handwheel High-pressure pumps Internal cooling (IKZ): 0–90 bar Coolant tank: 600 l Paper band filter

Condition: excellent (used), Year of construction: 2017, Manufacturer Fanuc Model Robocut ∝-C 600iB Rsdpfxex Avh Hj Aglsn Year 2017 Condition Used Maximum weight of the part 1000 kg X 600 mm Y 400 mm Z 310 mm Z (optional) 410 mm U ±100 mm V ±100 mm Maximum tapered cutting angle ±30° in 150 mm Wire diameter 0.10 to 0.30 mm CNC System FANUC Series 31i-WB Machine dimensions (W x D x H) 2440 x 2430 x 2160 mm Machine weight 3000 kg

Condition: used, Year of construction: 1975, Technical details: table length: 430 mm table width: 270 mm x-axis: 300 mm y-axis: 240 mm z-axis: 250 mm total power requirement: 2 kVA weight of the machine ca.: 0,72 t weight: Schaltschrank: ca. 200 kg space requirements of the machine approx.: L:0,9 x B:1,0 x H:2,1 m Rjdpeu Nu Elefx Aglen START HOLE EROSION MACHINE - size of cooling pond: 1000 x 510 x 900mm - incl. electric cabinet: 600 x 550 x 1400mm Machine is on sale as is, without been checked and will be sold as is! i.D. *

Condition: used, Year of construction: 2011, table length 900 mm table width 900 mm Rjdpfoxf Nbfex Aglon ampere 32 A Control MF 20 weight of the machine ca. 6 t dimensions of the machine ca. 2070x2850x2980 m

Condition: used, functionality: fully functional, Year of construction: 1990, machine/vehicle number: 0166890274834, control type: manual, degree of automation: manual, actuation type: hydraulic, punching force: 50 t, punching diameter: 100 mm, stroke length: 60 mm, throat depth: 650 mm, sheet thickness steel (max.): 15 mm, overall weight: 1,700 kg, total length: 1,500 mm, total width: 650 mm, total height: 1,700 mm, power: 7.5 kW (10.20 HP), input voltage: 220 V, input current: 26 A, input frequency: 50 Hz, type of input current: three-phase, year of last overhaul: 2023, Equipment: foot remote control, Muhr & Bender (Mubea) Punching Machine KLH 500/610 – incl. punching tools Used punching machine from Muhr & Bender (Mubea), model KLH 500/610, Made in West Germany. Condition: The machine has been professionally inspected by a machinery technician and is in very good, fully operational condition. All functions have been tested. Technical data (all information without guarantee): – Punching force: approx. 500 kN / 50 t – Max. punching diameter: up to approx. Ø 100 mm (e.g. Ø 30 mm in 15 mm steel) – Max. sheet thickness (steel): approx. 15 mm – Throat depth: approx. 610 mm – Stroke: approx. 60 mm – Drive: hydraulic, manual/conventional control with foot switch – Connection: 220/380 V, 3~, 50 Hz – Power: approx. 7.5 kW – Rated current: 26.3 A / 15.2 A Scope of delivery: – Muhr & Bender (Mubea) KLH 500/610 punching machine – including corresponding punching tools (scope as per photos) Important notes: – The stated price applies to self-collection only. Redpsx Dtp Rjfx Aglon – Dismantling, loading, and transport are the exclusive responsibility and at the expense of the buyer. – Sale is from used stock, without guarantee or warranty. Inspection possible by appointment. I am happy to answer further questions.

Condition: like new (used), Year of construction: 2025, GANNOMAT "JUNIOR 323" FRAME DOWEL AND SLOT MORTISING MACHINE Complete in standard configuration as per price list 01/22/D with: - Precision collet chuck for ER 40 collets Ø 3–26 mm, including collets Ø 10 / 13 / 16 / 20 - Motor 1.5 kW, 2800 rpm - Positioning via digital counter - Pneumatic 2-level positioning adjustment (0–100 mm) - Max. drilling depth: 150 mm - Precision indexing rail with 12 mm pitch, featuring: - Center detent and lateral adjustment 320 mm - 2 pneumatic safety clamping cylinders - Complete fence system consisting of: • 1 center stop and 1 stop for oversized frames • 1 round stop bar approx. 850 mm long (can be mirrored from left to right) Rsdpfxexdttie Agljn • 2 flip stops - Tiltable slot mortising device with 2 program cams (400V, 3Ph, 50Hz, 1.5kW) - Extraction hood Ø 80 mm, dust-tested - Central mitre stop 45° - Pair of auxiliary workpiece supports, pivotable (left and right) - Drill head holder - 3-spindle drilling head, 32 mm pitch (can be rotated 90°) - Chassis with 4 wheels for easy machine movement Availability: Short-term – immediately –

Year of construction: 2014, condition: ready for operation (used), General Data Measurements width 2700 mm Rodpfxsx D D Dfj Aglsn Measurements depth 1600 mm Measurements height 2858 mm Machine weight 4400 kg Movement X-Axis Movement 600 mm Y-Axis Movement 400 mm Z-Axis Movement 400 mm This AgieCharmilles FORM 30 was manufactured in 2014. A robust die-sinking EDM machine, it's ideal for detailed and precise metalwork. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking edm machine. Contact us for more information. Application Types EDM

Year of construction: 2008, condition: ready for operation (used), General Data Measurements width 1900 mm Measurements depth 1800 mm Measurements height 2200 mm Movement X-Axis Movement 550 Y-Axis Movement 400 Z-Axis Movement 350 Rodsx D N Hropfx Aglsn This 5-axis AgieCharmilles Spirit 3 was manufactured in 2008. It features an integrated C-axis and electrode magazine, multitasking operating system with object-oriented graphical interface (AEP Spirit), and a table size of 850×650 mm. Movement range includes X:550, Y:400, Z:350. Consider the opportunity to buy this AgieCharmilles Spirit 3 wire EDM machine. Contact us for more information about this machine. Application Types EDM

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, workpiece weight (max.): 450 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, AGIECUT Challenge 2 eCut Year of manufacture: 2005 Rodpfxoxyxfpe Aglen Travel ranges (X/Y/Z): 350 x 250 x 256 mm Travel ranges (U/V): +/- 70 mm Maximum taper: 30° at 100 mm Maximum workpiece dimensions (length/width/height): 750 x 550 x 250 mm Maximum workpiece weight (with/without bath): 200/450 kg Best achievable surface finish: 0.2 µm Ra Available wire diameters: 0.10 - 0.33 mm Includes AGIE universal clamping frame Includes AGIE JOGGER handbox Includes console with USB port The machine will be cleaned, overhauled, and tested by us after receipt of the order. Commissioning and training can also be provided upon request.

Condition: used, Used machine Equipment and technical data: - Double-sided line boring machine - 2 drilling motors, each 1.8 kW, with oil brake cylinder Rodpfewlwpgex Aglon - Stroke max. 130 mm - With pneumatic directional control valve - 21 spindles, spindle pitch 32 mm - Max. drilling distance 640 mm (by moving the workpiece up to 2656 mm) - Portal clearance 850 mm - Air consumption at 5 bar approx. 11 l per cycle - Extraction nozzle 160 mm Dimensions: approx. 3100 x 1100 x 1800 mm Weight: approx. 350 kg Availability: short-term Storage location: 63934 Röllbach

Condition: used, Year of construction: 2017, machine/vehicle number: 57CR2093, x-axis: 600 mm y-axis: 400 mm z-axis: 310 mm Max. workpiece weight: 1500 kg min. part length: 1050 mm maximum workpiece width: 800 mm max. workpiece height: 295 mm Weight of machine approx.: 3500 kg Rodpfxex Ed H Ne Aglon Standard configuration Max. workpiece dimensions 1050 x 800 x 295 mmWork table dimensions 840 x 640 mm (square table)Rapid traverse rate of the work table 1300 mm/minElectrode wire diameter 0.1 to 0.3 mmMax. wire feed speed 23 m/minElectrode wire tension 0.5 to 25 NTaper unit Opto - linearAxis travel +/- 75 x +/- 75 mmMax. taper angle 15° (with 260 mm workpiece thickness)External dimensions 2687 x 3030 x 2150 mm Extended machine accessories including cooler

Condition: used, Travel: 260x160x180mm Work-place: 600x900mm Complete with belongings Rodpsx Igc Usfx Aglon - Documentation available: Yes - CE certificate present: No - Control: CNC Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 525 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 1,000 kg, workpiece height (max.): 375 mm, Ingersoll (OPS Ingersoll) Sinker EDM Machine OPS INGERSOLL GANTRY EAGLE 500 Year of manufacture: 2009 Control system: EAGLE Powertec PC/NC 2060 MultiProg Powertec technology programming on PC/NC Rsdpfx Aox I D R Nsglon Powertec Easy Burn quick programming Powertec Handheld – multifunctional hand control device Manual eroding with Powertec Handheld High speed jump up to 18 m/min Generator output: 60 Amperes, EAGLE Powertec Travel paths (X, Y, Z): 525 x 400 x 450 mm 20-position pick-up disk electrode changer Work tank (W x D x H): 770 x 670 x 440 mm Work table (W x D): 750 x 650 mm Load capacity: 1,000 kg Accessories: CO2 fire extinguishing system Integrated cartridge filter system Condition: Refurbished Special equipment: Linear measuring system on all axes (standard on Z-axis in Z series)

Condition: like new (used), Year of construction: 2018, operating hours: 2,700 h, functionality: fully functional, machine/vehicle number: MR24D1056, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, wire diameter (max.): 0.3 mm, workpiece height (max.): 295 mm, workpiece width (max.): 1,050 mm, workpiece length (max.): 800 mm, empty load weight: 3,500 kg, tank capacity: 860 l, Equipment: documentation/manual, For sale: Mitsubishi MV2400R precision wire EDM machine (2018), in excellent technical condition, continuously operated, fully functional, and ready for immediate use – very low operating hours (only 2,700 hours). Technical Specifications: - Year of manufacture: 2018 - Manufacturer: Mitsubishi Electric - Model: MV2400R - Control system: Mitsubishi M700 Series - Axis travel (X/Y/Z): 600 / 400 / 310 mm - Max. workpiece dimensions: 1050 × 800 × 295 mm - Max. workpiece weight: 1,500 kg - Worktable size: 840 × 700 mm - Wire diameter: 0.1 – 0.3 mm (0.25 mm currently in use) - Positioning accuracy: ±1 µm - Power supply & cooling: complete and fully functional - Machine dimensions (L×W×H): 2687 × 3030 × 2150 mm - Weight: approx. 3,500 kg Equipment and Accessories: - Original upper and lower wire guides - Automatic Wire Threading (AWT) - Filter tank with ion-exchange resin - Complete set of clamping and locating devices (in carrying case) - Wire alignment device - Original operation manuals and documentation Additional accessories purchased for over €10,000: - Wire guides for 30° angle cutting (upper and lower) - Processor battery - Precision workpiece clamping vise - 0-600 PSI pressure gauge (2 pcs) - MV power contact (259320) (2 pcs) - CF card with software - 0.25 mm EDM wire – 3 new spools - 2 sets of new filters - Machine transport and handling system Condition: Redpfx Asxu Hvlsglsn The machine is well-maintained, regularly serviced, and ready for immediate operation. Complete filtration and cooling systems included. We offer assistance with transport, installation, and commissioning of the machine, as well as operator training – we are EXPERIENCED. Price negotiable. VAT invoice available. Export (0% VAT) possible.

Condition: used, Hole rows + fitting drilling machine LAUTENSCHLÄGER Meplamat 300 pneumatic hold-down device, pressing device, stop rulers Redpfx Agevtm Ayolen

Condition: used, GANNOMAT Compact 30 hole drilling machine - used - pneumatic clamps, foot control, 2 drilling beams with 15 spindles each ----- Technical specifications ----- Number of spindles: 30, Drill spindle spacing: 32 mm, Motor power: 2 x 0.75 kW, Voltage: 400 volts, Pneumatic connection: 6 bar, Rodpewmmt Rsfx Aglon Dimensions without stop ruler: 850 x 1,100 mm, Weight: 240

Year of construction: 2016, operating hours: 4,439 h, condition: ready for operation (used), General Data Machine weight 4200 kg Control Unit Brand FANUC Model 31i-WB Dimensions Machine Length 2900 mm Main Drive Number of axis 5 Min. Wire Diameter 0.1 mm Max. Wire Diameter 0.3 mm Movement X-Axis Movement 800 mm Z-Axis Movement 310 mm Y-Axis Movement 600 mm This 5-axis FANUC ROBOCUT alpha C800iB was manufactured in 2016, featuring a large work area with X-axis travel of 800 mm, Y-axis travel of 600 mm, and Z-axis travel of 310 mm. It supports a maximum workpiece weight of 3000 kg and utilizes a CNC control FANUC 31i-WB for precise operations. If you are looking to get high-quality wire EDM capabilities, consider the FANUC ROBOCUT alpha C800iB machine we have for sale. Contact us for more information. Application Types EDM Redpfx Agox Nr N Aeljn

Year of construction: 2017, operating hours: 6,417 h, condition: ready for operation (used), General Data Machine weight 4400 kg Movement Rjdpfx Agsx Nr N Njlen X-Axis Movement 600 mm Z-Axis Movement 400 mm Y-Axis Movement 400 mm Main Drive Number of axis 4 This 4-axis AgieCharmilles FORM 30 was manufactured in 2017. It features a stroke of 600mm x 400mm x 400mm, with axis speeds up to 6 m/min. The machine can handle workpiece weights up to 1000kg and dimensions of 1000 x 700 x 400 mm. It includes a dielectric unit with a 750l capacity and a robust weight of 4400kg. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking EDM machine. Contact us for more information about this machine. Application Types EDM

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, For sale is a die-sinking EDM machine of the brand OPS Ingersoll and the type Gentry Eagle 500 A matching Erowa automation for tool and workpiece change, as well as an identical 2nd system are also for sale in the package Offer is only valid for one Ingersoll machine if you are interested in the complete machine please mention in your inquiry The machine is in very good condition and fully functional. Both machines are loaded via Erowa Automation, this machine has its own tool changer. Technical data sheets available for download below in the advertisement Technical data for the EDM machines: Rsdpfx Agotdkkuolon Container dimensions: WxDxH: 770 x 670 x 440 mm Dielectric height: max 395 mm max top load: 100 kg min. Distance: 135 mm max. distance: 585 mm speed: 1-20 1/min Measuring resolution: 0.001 ° Work table (W x D): 750 x 650 mm load capacity: 1000 kg travel X/Y/Z: 525x400x450 mm Filter system: Cartridge filter: Filter area: 16 m² Total volume: 400 l Dimensions (WxHxD): 1356x2653x2284 mm Weight: approx. 4400 kg Technical data Erowa Automation: X-axis: 1200 mm Z-axis: 1050 mm C-axis: 350 ° A-axis: +/-180 ° B-axis: +/- 90 ° Y-axis: 1.1-18.74 m (METER!) Transfer weight: max. 130 kg The system is also equipped with 2 magazines Dismantling, loading and shipping can be organized throughout Europe for an additional charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: excellent (used), Year of construction: 2009, travel distance X-axis: 525 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, table width: 650 mm, For sale are 2 OPS Ingersoll EDM machines, model Gentry Eagle 500. The machines are being sold from a production facility, are in very good condition, and fully functional. Technical data: Year of manufacture: 2009 Operating hours: approx. 30,758 Available from: By arrangement Rsdpsxrpm Ujfx Aglsn Travel paths: X-axis: 525 mm Y-axis: 400 mm Z-axis: 450 mm (430 mm with Erowa) C-axis: controlled (0.001 mm resolution) Electrode holder (quill): Erowa ITS Work tank: 770 mm x 670 mm x 440 mm Table: 750 mm x 650 mm Accuracy: 0.005 mm to 0.015 mm Max. dielectric height: 395 mm Max. pallet size: 750 x 950 x 420 mm Max. workpiece weight: 1,000 kg Max. electrode weight: 100 / 50 / 15 kg Max. throat depth: 585 mm Equipment: - Filter system with 16m² paper candle - Compressor - Recooling unit - Liftable tank with automatic tank refilling (ATA) - CO2 fire extinguishing system Machine weight: 3,640 kg (incl. generator and control panel) Operating weight: 6,450 kg (ready for operation) Footprint: 3,135 x 3,944 x 2,871 mm Options: - Pallet holder for four Power-Grip160 (not included in price) - Various 4-fold aluminum exchange pallets with chip - Various Erowa ITS electrode holders with chip Transport and loading can be organized Europe-wide at an additional cost upon request. Prices plus VAT. Inspection possible by appointment. Please contact us, our team will be happy to assist you. Trade-in or exchange possible! Machine purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Looking for a high-quality yet affordable metalworking machine for your production? Or would you like to sell yours? For further information or contact options please visit our website.

Condition: repair required (used), Year of construction: 1996, For sale is an IXION TL 601 deep hole drilling machine. Unfortunately, the machine is experiencing electrical problems. Constants need to be reset by a technician, and the backup battery needs to be replaced. New LCD display was recently installed. New LED display. Machine No. 950192 Year of manufacture 1996 Manufacturer: Maschinenfabrik IXION Otto Hafner -Travel paths + Quill Tl 601 (Z) 600 mm + Vertical drilling unit (Y) 300 mm + Transverse table (Table surface 1200 mm x 600 mm) (X) 700 mm + In drilling direction (W) 1000 mm -Clamping table + Table surface (standard) 1200 mm x 600 mm + Table load (T1200) 1000 kg -Tool holder + SK 40 holder according to DIN + Pull stud 69871 According to DIN 69872 -AC main spindle drive 3.0 kW + At 100% duty cycle, S1 5.5 kW At 50% duty cycle, S6 7.5 kW +Spindle turning speed Directly programmable 100-4000 rpm Performance: +Drilling capacity in steel 2312 D 32 mm +Tapping M24 -Weight / Dimensions Weight 2500 kg Length approx. 4230 mm Width approx. 1885 mm Height approx. 1870 mm Rodpjh Dpv Refx Aglsn All prices plus VAT We can deliver and commission the machine. All prices plus VAT Machine Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality, yet affordable metalworking machine for your production? Or do you want to sell yours?

Condition: excellent (used), For sale is a system with 2 OPS Ingersoll Gentry Eagle 500 machines and an Erowa automation for tool and workpiece change. The system is in very good condition and fully functional. Redeq Su Hnepfx Aglon Both machines are loaded via the Erowa automation, one machine has its own tool changer. Technical data sheets available for download below in the advertisement Technical data for the EDM machines: Container dimensions: WxDxH: 770 x 670 x 440 mm Dielectric height: max 395 mm max top load: 100 kg min. Distance: 135 mm max. distance: 585 mm speed: 1-20 1/min Measuring resolution: 0.001 ° Work table (W x D): 750 x 650 mm load capacity: 1000 kg travel X/Y/Z: 525x400x450 mm Filter system: Cartridge filter: Filter area: 16 m² Total volume: 400 l Dimensions (WxHxD): 1356x2653x2284 mm Weight: approx. 4400 kg Technical data Erowa Automation: X-axis: 1200 mm Z-axis: 1050 mm C-axis: 350 ° A-axis: +/-180 ° B-axis: +/- 90 ° Y-axis: 1.1-18.74 m (METER!) Transfer weight: max. 130 kg The system is also equipped with 2 magazines Dismantling, loading and shipping can be organized throughout Europe for an additional charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: good (used), Year of construction: 2009, operating hours: 20,709 h, functionality: fully functional, machine/vehicle number: 106516-11, drilling depth: 1,200 mm, overall weight: 7,500 kg, For sale: A very well-equipped deep hole drilling machine from TBT, including various accessories. Drilling specifications: - Spindle 1: 5–18 mm; Spindle 2: 1–4 mm - Drilling depth: approx. 1200 mm with Ø8 mm using 3 steadies - Number of spindles: 2 - Spindle drive: Spindle 1: 1 x 4 kW; Spindle 2: 1 x 1.2 kW - Spindle speed: Spindle 1: 600–6000 rpm; Spindle 2: 2000–24000 rpm - Rapid traverse: 15,000 mm/min - Saddle stroke (nominal): 1800 mm - Coolant: Deep hole drilling oil - Tank capacity: 1,100 liters - Operating voltage: 3AC 400V, 50Hz (Total connected load: 25 kW) Condition: Good, appropriate for its age Rsdpexgnhaefx Aglsn Accessories: Includes drip tray and various drills On-site inspection is recommended!
