Used Torque Multiplier for sale (2,410)

Condition: used, Year of construction: 2007, x-travel 1.035 mm y-travel 560 mm z-travel 510 mm control iTNC 530 Heidenhain Gtedpfx Agox R Em Rj Tst turning speed range - main spindle 20 - 10.000 min/-1 power capacity - main spindel 13 / 9 kW max. Torque 83 / 57 Nm tool taper SK 40 DIN 69871 table surface area 1.200 x 560 mm max. table load 1.000 kg table height over floor 720 mm number of toolpositions 30 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 300 mm change time 1,6 sec change-time chip to chip 7,0 sec feed speeds 20.000 mm/min rapid traverse 30 m/min Feed force 5 kN total power requirement 20 kVA weight of the machine ca. 4,5 t dimensions of the machine ca. 3,0 x 3,0 x 2,8 m CNC - Machining Center Vertical DECKEL MAHO - DMC 1035 V - 28,796h operating hours, 11,512h spindle hours

Condition: excellent (used), Year of construction: 1995, x-travel 14000 mm y-travel 5000 mm z-travel 1500 mm w-axis 3000 mm column daylight 4000 mm column: max. dist. table - spindle nose 4500 mm workpiece weight 100 t table dimension - longitudinal 9000 mm table dimension - cross 3000 mm spindle taper ISO SK 50 spindle turning speed range 2-2500 U/min spindle motor 113 kW spindle diameter 200 mm max. torque on the spindle 9500 Nm feed in x - axis 1-10000 mm/min feed in y - axis 1-10000 mm/min feed range Z-direction 1-10000 mm/min rapid traverse 20000 mm/min height over floor 8600 mm control SIEMENS 840C weight of the machine ca. 360 t Gtjdjvwgm Hepfx Ag Tst ATTACHMENTS angular milling head yes autom. tool clamping yes ball spindles yes guideway covers yes coolant unit yes high pressure cooling syst. (through spindle) yes closed cabin yes chip conveyor yes TECHNICAL DESCRIPTION 2 portal milling centres, each with 3 table pallets 9000 x 3000 mm: - Tool changer with 420 tools - Head pick-up system - Video monitoring via camera - High pressure lubrication unit for inner cooling 70bar AVAILABLE HEAD UNITS: - Fixed angle head HS800C600 105 Kw 600 long - Fixed angle head HSD350C850 50 Kw 850 long - Fixed angle head HSD 40C880 12 Kw 880 long - Fixed angle head HSD 190C1000 30 Kw 1000 long - Vertical spindle unit VS800C 105 Kw 900 long - Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time - Angle spindle unit SO800C905 - 22,5° fix - Angle spindle unit HSE1200CS -25° fix - Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth --> 1.350 1/min , B-Achse 0,5 Grad Hirth One additional drilling extension SE 350C plus 1 SE500C. DESCRIPTION OF CONDITION In 2011/2012 these 2 identical machines were retrofitted The milling length was extended to 14meters and an automatic changing system for table pallets was installed. Both machines can be seen under power by prior appointment.

Condition: good (used), Servo motor, electric motor, DC motor, stepper motor, stepper motor -Max. speed: 3000 rpm Gjdjcv Sitopfx Ag Tett -Torque: 1.9 Nm -Power: 0.6 kW -Shaft: Ø 19 mm -Design: B5 -with NIKKI-DENSO-Encoder-E2-1-2000-PR -Number: 5x stepper motors available -Price: per piece -Dimensions: 290/120/H180 mm -Weight: 11.4 kg

Condition: excellent (used), ROLLER THREADING MACHINE KING2 SET C R1/2-2. Threading machine, electric Design: sturdy, maintenance-free gearbox with special ratio for perfect power transmission, left/right handed, with thermal overload protection and emergency stop. Self-reinforcing clamping effect by diagonal adjustment of the clamping screw. Stable torque support for torque support in both directions of rotation. Easy and quick replacement of cutting heads. Unique locking of the cutting head in the ratchet lever, guaranteeing secure seating during threading. Supplied with Central cutting heads and carrying case. Gsdpfxsvgng He Ag Tstt

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 1,185 mm, turning diameter: 640 mm, spindle speed (max.): 4,000 rpm, turning diameter over bed slide: 640 mm, counter spindle torque (max.): 5,000 Nm, Turning and Milling Center with Main and Counter Spindle and Comprehensive Equipment! TECHNICAL DETAILS Turning diameter: 640 mm Turning length: 1,185 mm Swing diameter: 640 mm Distance between headstocks: 1,500 mm SLIDE I X-Axis travel: 550 mm Y-Axis travel: 180 mm Z-Axis travel: 1,185 mm B-Axis: 240° Feed rate X-axis: 0 – 40,000 mm/min Feed rate Y-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 70,000 mm/min Feed rate B-axis: 1 – 20 rpm Rapid traverse X/Y/Z: 40 / 24 / 70 m/min Feed force X/Y/Z S6: 7.00 / 11.00 / 7.50 kN Tool interface: HSK 63 Milling spindle speed: 10 – 12,000 rpm Drive power 100% duty cycle: 13.20 kW Drive power 40% duty cycle: 22.00 kW Milling spindle torque: 60 / 100 Nm Max. tool length: 350 / 200 mm Tool diameter: 80 mm Tool diameter with 2 free pockets: 120 mm Max. tool weight: 6 / 10 kg SLIDE II X-Axis travel: 180 mm Z-Axis travel: 1,050 mm Feed rate X-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse X + Z axes: 24 / 36 m/min Feed force Z / X S6: 11.00 / 9.00 kN Turret (positions): 12 Tool holder: DIN 69880 Ø40 Driven tool positions: 12 Speed: 1 – 4,000 rpm Drive power 100% duty cycle: 10.70 kW Torque S1: 32 Nm SLIDE III Z-Axis travel: 1,150 mm Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse Z-axis: 36 m/min Feed force Z-axis S6: 13.00 Nm MAIN SPINDLE Model: ISM90 Speed: 10 – 4,000 rpm Drive power 100% duty cycle: 36.00 kW Drive power 40% duty cycle: 45.00 kW Torque at 40% / 100% duty cycle: 800 / 630 Nm Spindle bore: 80 mm COUNTER SPINDLE Speed: 10 – 5,000 rpm Drive power 100% duty cycle: 21.00 kW Drive power 40% duty cycle: 28.00 kW Torque at 40% / 100% duty cycle: 320 / 240 Nm Spindle bore: 80 mm MACHINE DETAILS Electrical Data Total power requirement: 70.00 kW Dimensions & Weight Machine weight: approx. 20.00 t Footprint: approx. 8.50 x 4.50 x H3.10 m Control Gsdowyvc Ujpfx Ag Tett Control manufacturer: Siemens Control model: SINUMERIK 840D EQUIPMENT Chip conveyor Oil mist separator DMG Automation WH10top Main spindle ISM90: Hollow chuck, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Counter spindle ISM76: Partial hollow chuck, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Pick-off unit with integrated conveyor belt Automatic safety cover Differential pressure clamping With pump stand for coolant: Pump 1: 17 l/min at 80 bar / Pump 2: 20 l/min at 8 bar / Pump 3: 40 l/min at 20 bar Hainbuch collet chuck including collets Ø30, 45, 50, 55, 60, 65, 72, 82, 85, 90 1 workpiece pick-off for turret

Condition: used, functionality: fully functional, Year of construction: 2022, operating hours: 820 h, load capacity: 5,000 kg, lifting height: 5,500 mm, free lift: 1,765 mm, fuel type: diesel, mast type: triplex, construction height: 2,910 mm, power: 55 kW (74.78 HP), fork length: 1,200 mm, empty load weight: 7,760 kg, total length: 3,748 mm, drive type: Diesel, construction width: 2,080 mm, All-terrain forklift Load center: 600 mm Fork width: 150 mm Fork thickness: 60 mm ISO class: ISO Class 4 = 5,000 - 10,000 kg Mast type: Triplex Transmission: Torque converter Speed class: 20 Technical condition: good Front tire type: Pneumatic Front tire size: AS 340/80 R18 Front tire condition: 80 - 100% Gtodpfjx R Hcmox Ag Tst Rear tire type: Pneumatic Rear tire size: AS 18-22.5 163A8 Rear tire condition: 80 - 100% Description: The M 50-4 all-terrain forklift is designed for operations in challenging environments or areas with obstacles. With 4-wheel drive and a ground clearance of 43 cm, this forklift ensures optimal maneuverability under all conditions. A wide range of tire options is available for adaptation to varied surfaces, optimizing your productivity. The pendulum-mounted cab, accessible from both sides, offers a spacious driver’s area with ergonomic controls. The elevated driving position provides a 360° panoramic view for enhanced safety for both operator and surroundings. Side shift, 3rd and 4th hydraulic valve, work lights (front/rear), cabin heater, full cab, CE certificate. Includes: service booklet, EC declaration of conformity, operator’s manual, spare parts manual.

Condition: used, Year of construction: 2011, x-travel 835 mm y-travel 510 mm z-travel 510 mm distance spindle nose and table 120 - 630 mm control iTNC 530 ERGOLine Heidenhain Gsdpsx R Em Defx Ag Tott turning speed range - main spindle 20 - 10.000 min/-1 power capacity - main spindel 13 / 9 kW tool taper SK 40 DIN 69871 max. Torque 130 / 87 Nm table surface area 1.000 x 560 mm max. table load 800 kg number of T-slots 5 T-slot - width 14 mm T-slot - distance 100 mm number of toolpositions 20 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 250 mm max. tool weight 6,0 kg rapid traverse ( X / Y / Z ) 30 m/min feed speeds 1 - 20.000 mm/min total power requirement 23 kVA weight of the machine ca. 4,0 t dimensions of the machine ca. 4,5 x 3,5 x 2,7 m CNC - MachiningCenter Vertical DECKEL MAHO - DMC 835 V New Design - 20,796h operating hours, 7,544h spindle hours

Condition: excellent (used), Year of construction: 2002, x-axis 4000 mm y-axis 3500 mm z-axis 1500 mm Control SIEMENS 840 D w-axis 1500 mm column daylight 2500 mm surface area 3000 x 2000 mm workpiece weight 10000 kg spindle turning speed range 5-6000 U/min transmission ratio 2 power capacity - milling spindle 45 kW dist. cutter spindle - workpiece spindle 3500 mm max. torque on the spindle 1250 Nm tool change unit 200 -fach tool diameter 135 / 250 mm weight of tools max. 50 kg tool length - max. 400 mm tool taper ISO SK-50 the portal milling machine is in very good condition. ADDITIONAL EQUIPMENT DRILLING/MILLING Angle milling head yes automatic tool clamping yes Tool clamping yes Ball screws yes Guideway cover yes Gedpfx Agovwgmmj Tstt Coolant system yes High-pressure cooling system (internal cooling) yes Full work area panelling yes Portal machining centre with tool changing system and second table top.

Condition: excellent (used), Kitchen Worktop Router FG 314-2 - with top router HM /18 Scheer - Routing length: 900 mm - Routing depth: 0-90 mm - Complete with template Gtodpfx Ajx R Efgog Tot - Weight: approx. 21 kg - 2000 Watts - 7 kg torque - 10,000 – 18,000 rpm

Condition: excellent (used), Product Information "POLY-PTX 800 satin finishing machine" From the inventor of the longitudinal sander. Our multifunctional longitudinal sander with 1750 watts of power, speed control, ergonomic design and versatility - including up to 150 mm working width. High torque and power reserves guarantee professional, continuous use and greater profitability. Gtedpju Su Tzefx Ag Tot Features: Infinitely variable speed control from 1000 to 3800 min-1 with a tachogenerator to ensure constant speed even under load. Grinds from coarse to fine. Balanced, simple manual guidance without support rollers. This allows free movement (oscillation effect). Guarantees shadow-free, seamless, highly decorative surfaces in satin, matte and industrial finishes. It satin polishes to a mirror shine and refines the surfaces of stainless steel, steel, non-ferrous metals such as brass, bronze, copper, aluminum, as well as wood. Finest sanding on large surfaces, without shadows or edges. Removes welds, deep scratches, rust, dirt, layers of paint and oxides. Goes from coarse grinding to mirror shine on stainless steel and non-ferrous metals in just three steps. It's also ideal as a round tube grinder using a sanding belt roll. Grinds and polishes open and closed pipe structures. For pipe processing, the "hole system" allows safe and fast bonding of fleece and felt tapes to closed pipe structures. It does not require complex tape bonding. Huge range of grinding tools , which offers a solution for every task. With rubberized handle for optimal handling! Set contents: 1 POLY-PTX® 800 basic unit 1 robust, impact-resistant plastic carrying case 1 QUICK-LOCK cable 4 m 1 POLY-PTX® mounting screw 1 fleece disc 100 mm wide Machine type: Satin finishing machine Cable/battery: Cable Suitable tools: Brushes, bushings, polishing rings, wheels Plug type/power connection: EU (C+F) 220-240 V ~ 50-60 Hz Power consumption: 1750 watts Max tool size: Diameter 115 x width 100 mm Tool holder: 19mm spline shaft WEEE Reg. No.: DE 51395731 Speed in min-1: 1000 - 3800

Condition: good (used), Year of construction: 2009, Ref. -No.: 10616 Manufacturer: DMG Type: DMU 210 P Year of construction: 2009 Type of control: CNC Control: Heidenhain ITNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 257XXXX X-Travel: 1800 mm Y-Travel: 2100 mm Z-Travel: 1250 mm B-Axis: -30 / +180 ° C-Axis: 360 ° Table Load: 8000 kg Clamping Area: 1.700 mm Tool Taper: SK 50 Spindle Speed: 10.000 RPM Max. Torque: 288 Nm Total Power Requirement: 38 kW Gsdpox R R Hcsfx Ag Tett No. Of Working Stations: 60 Internal cooling: 40 bar Holding torque: 22.700 Nm Further information: - The DMG DMU 210 P 5-axis machining center is suitable for high-precision machining of large, heavy workpieces. The machine can be viewed under power.

Year of construction: 2020, condition: ready for operation (used), General Data Machine weight 15000kg Control Unit Brand SIEMENS Model 840D Additional Equipment Toothed Spindle 1: Tool clamping interface: HSK-C63/ Tool speed max: 4500 1/min /Screw tightening torque, expansion chuck: 20 Nm Toothed Spindle 2: Tool clamping interface: UTS 50 /Tool speed max: 7000 1/min/ Screw tightening torque UTS clamp: 40 Nm This PROFILATOR DV370-HL-05 was manufactured in 2020. A robust and reliable unit, it is ideal for those looking to enhance their machining operations. Consider the opportunity to buy this PROFILATOR DV370-HL-05. Contact us for more information. Gtodjx R E Nropfx Ag Tst Application Types Other Machine Tools

Condition: good (used), Servo motor, electric motor, DC motor, stepper motor, stepper motor -Manufacturer: Eurotherm, servomotor type ACM2n Speed: 4000 rpm Gedeh Hbxuepfx Ag Tstt -Torque: 2.2 Nm -Shaft: Ø 14 x 30 mm -Protection class: IP54 -Dimensions: 200/88/H120 mm -Weight: 4.2 kg

Condition: used, Used Becomix model Beco Mini Lab homogenizing mixer.  Manufacturer: Becomix. Capacity: Working capacity maximum of 5 Litres approximately Dimensions: 820mm x 820mm x 1250mm high approximately Pressure: -1/+1 Bar maximum working pressure  internally; 4 Bar maximum working pressure of the external jacket Conical welded bottom with a clamped dish top. Pressure and vacuum sealed by a double acting axial seal rings and cooled by barrier water flow. Bottom entry homogenizer: Gjdox Nixuopfx Ag Tstt Power 1.55kW Torque 2.5Nm Weight: Estimated: Kg250.0 Dimensions: 820mm X 820mm

Condition: used, EMAG VL 4 is a machining cell / vertical lathe engineered for high-precision work, exceptional accuracy and production reliability. Capacities: 2 machines, 2 axes; max workpiece dimension 200 mm; Z travel 400 mm; X travel 750 mm; turret 12 positions with 12 driven tools. Specs: spindle speeds up to 6000 min-1 with stepless control to 4500 min-1; spindle power 25/18 kW; torque 280/202 Nm; supply 3x400V 50Hz; total power 36 kW; footprint L5300×W2300×H3650 mm. Equipment: chip conveyor, automatic loading/unloading, set of toolholders, status light, spare parts. Achieves tight tolerances; suited for automotive, aerospace, machine tools and medical. Gedpfxjx Ry Txj Ag Tjtt

Condition: excellent (used), HOLEX SK40 collet chuck for ER collets – robust design, ideal for use on CNC machining centers. • Type SK40 – DIN 69871 • ER collet (diameter Ø16 mm) • Chuck lengths: 70 mm, 100 mm, 110 mm (depending on model) • Max. speed 12,000–15,000 rpm • Torque up to 70 Nm Gtedew S Itbepfx Ag Tst • Balancing class G6.3 – stable operation at high speeds • Brand HOLEX – Hahn+Kolb Germany • Very good, warehouse condition • Available individually or as a larger set

Condition: new, The UWF 5 is a state-of-the-art universal milling machine that falls under the category of Conventional Vertical Milling Machines and is part of the Universal Milling Machines product group. This top model in the UWF series boasts a large work area of 1325 x 360 mm and supports a table load capacity of up to 500 kg, making it ideal for both repair shops and production departments. Constructed with a robust machine bed from high-strength HT-200 cast iron and precision-ground guideways, it ensures long-term accuracy and wear resistance. The universal cutter head can swivel on two planes, allowing for quick changes between horizontal and vertical machining, while the powerful servo axis motor enables finely stepped motorized feeds in all axes. Additionally, the 5.5 kW main drive guarantees high torque, significantly enhancing productivity and offering features like a 3-axis position indicator and a user-friendly control panel. With extensive standard equipment, including a coolant system and tool storage, the UWF 5 is built for ease of use and maintenance-free operation. For those interested in enhancing their machining capabilities, request a quote for this impressive milling machine today. Gtjdpfx Aop Aucwog Tst

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Control: SIEMENS Sinumerik 840D Solution Line Working area: Maximum workpiece height: 200 mm Maximum workpiece diameter: 250 mm Maximum swing diameter: 390 mm Maximum distance spindle stop–turret: 580 mm Minimum distance spindle stop–turret: 240 mm Spindles Maximum spindle speed: 5,500 rpm Spindle power per spindle: 37.7 kW Maximum spindle torque per spindle: 300 Nm Spindle nose with short taper (DIN 55026): A6 Axis travels X-axis travel (within working area with cover closed): 365 mm X-axis total travel: 886 mm X-axis travel (over turret center): -20 mm Y-axis travel: +100/-80 mm Z-axis travel: 250 mm Gtedpfsx Rwv Dox Ag Tot 12-station disc turret VDI 40

Condition: new, functionality: fully functional, Year of construction: 2026, Yanigav Earth Auger TAH250 / TAH350 / TAH450 • Required flow rate (l/min): 20-40 / 30-60 / 40-80 • Effective torque (N/m): 2000 / 3000 / 4000 • Working pressure (bar): 230 / 250 / 25 • Speed (rpm): 47-93 / 44-88 / 37-75 • Maximum discharge head (mm): 400 / 600 / 600 • Excl. frame and drill bit Price: €2,750 / €3,750 / €4,500 Gtsdper Ezm Tsfx Ag Tet

Condition: like new (used), Year of construction: 2022, operating hours: 800 h, functionality: fully functional, turning length: 610 mm, turning diameter over cross slide: 500 mm, turning diameter: 725 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 610 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 30 m/min, feed length X-axis: 260 mm, feed length Y-axis: 80 mm, feed length Z-axis: 610 mm, torque: 250 Nm, bar passage: 65 mm, Equipment: documentation/manual, rotational speed infinitely variable, For sale: As-new EMCO MAXXTURN 65-G2 SMY, year of manufacture 2022, equipped with Siemens Sinumerik ONE CNC control featuring ShopTurn! CNC turning center for complete machining of turned/milled parts. Key features include: - Integrated spindle motors, counter-spindle, water-cooled (preloaded roller guides) with Y-axis, operative on main and sub-spindle - Latest SINUMERIK ONE control with ShopTurn conversational programming Main Spindle: - Max. bar capacity: 65 mm - Max. torque: 250 Nm - Speed range: 0–5000 rpm Sub-Spindle: - Drive power: 22 kW - Max. torque: 130 Nm - Speed range: 0–7000 rpm Tool Turret: - 12-station VDI 30 radial turret with directional logic for up to 12 driven toolholders - Max. drive power: 6.7 kW - Max. torque: 25 Nm - Max. speed: 5000 rpm Y-Axis: - Travel: ±40 mm Additional Equipment: - Hollow chuck cylinder incl. draw tube - C-axis for both spindles - Sinumerik ONE / OPERATE control - 22" multi-touch display - ShopTurn, 3D simulation, remnant material detection - USB interface - Electrical cabinet climate control - Coolant system incl. pump (3.5 bar) - Chuck flushing (extra pump 3.5 bar) - Parts ejector and flush through sub-spindle - Hydraulic unit - Interface for chip conveyor - Documentation and CE certificate - Control languages: German / English - Electronic handwheel - EMCO TOOL BREAKAGE AND WEAR MONITORING / SINUMERIK ONE - Alternating spindle speed - Sub-spindle as tailstock: This cycle allows use of the sub-spindle with mounted live center for workpiece support, permitting shaft machining even on machines without a conventional tailstock. Max. support force limited to 50% of maximum axis force. - EMCO PROFI-NET ROBOTIC INTERFACE: Connection interface for robot integration via HARTING connector. Signal exchange via Profinet. Safety signals: 2-channel/potential-free. - Digitalization package for Sinumerik: Condition monitoring - SIEMENS ONE INTERFACE for connection to MDE/BDE systems. Standard info includes: • Machine on - AUX ON • Automatic mode Gtjdpfx Agex E Dnco Tjt • Production mode - program active • Program running and override between 95–105% • Part count pulse (M30) • Programmable pulse (M300) - 3D machine data / MT65-G2: 3D model of the machine included Pneumatically actuated finished parts catcher for gentle unloading of finished components. Parts are transported to a collection box (standard) or onto a conveyor belt (optional). - Max. finished part length: 175 mm - Max. finished part diameter: 65 mm - Max. finished part weight: 4.5 kg INTERFACE SL1200 HT65-DT/TT + MT65-1000: For connecting the EMCO SL1200 bar feeder. Etc. The machine is immediately available!

Condition: good (used), Gearbox, planetary gear for hydraulic motor, axle drive, gear axle drive, wheel drive, double planetary gear -Manufacturer: Trasmital Bonfiglioli, wheel drive -Type: 601R1L10BC5DODHP011 -Translation: 1 : 5 -Torque: 3000 Nm -Drive side mount: KW-21 splined shaft -Dimensions: see photos / technical drawing -Number: 20x gearbox available -Price: per piece Gtedpfx Ager H Nlps Tst -Dimensions: Ø 262 x 270 mm -Weight: 42 kg/piece

Condition: excellent (used), For sale: CNC tool holder GARANT (Hoffmann Group) – model SK40-16-100. High-quality clamping system for milling machines and machining centres, ideal for precision metalworking. • SK40 taper – industrial standard • Clamping diameter Ø16 mm • Length 100 mm • Balancing G2.5 – up to 25,000 rpm • Max. tightening torque 50 Nm • Premium brand – GARANT (Hoffmann Group) • Very good condition, used, fully functional – equipped with cutters/drills. Gtodow Sy Epopfx Ag Tet -- PRICE IS FOR 1 PIECE --

Condition: excellent (used), Year of construction: 2019, operating hours: 403 h, functionality: fully functional, turning length: 1,200 mm, spindle bore: 120 mm, controller model: Siemens 840 Dsl, Equipment: documentation/manual, Technical data: Turning length 1200 mm Chuck diameter 350 mm Working stroke X top/bottom 200 mm Working stroke Y. axis 210 mm (+130/-80) Working stroke Z. axis 1200 mm Maximum travel speed W/X/Y/Z meters/minute 45/40/40/46 Ball screw diameter W/X/Y/Z mm 40/40/40/40 Profile rail guide, B/X/Y/Z mm 45/45/45/55 Tool flight circle 700 mm Maximum center distance 1200 mm Gtsdpfevw Upcex Ag Tst Main spindle/counter spindle Spindle bearing diameter 120 mm/160 mm Spindle passage 65/105 mm Spindle bore diameter 80/120 mm Spindle flange/spindle head DIN 55026 A6 / A8 Drive power 100% ED 22 KW/67.4 Drive power, 40% ED 24 KW/80 Nominal speed 1400 rpm Maximum speed 5,700 rpm Torque 100% ED 150 nm/585 Torque 40% ED 191 nm/795 C-axis resolution 0.001 degrees Both turrets: Tool holder: VDI 40 Maximum speed rpm 6000 torque drive 12,000 speed drive Maximum drive power kW: 28.5 torque drive 23.5 speed drive Maximum torque (25% ED) Nm: 85 torque drive 56 speed drive Dimensions: 4500 x 2500 x 2500 Weight approx. 16000 kg Control: Siemens 840 Dsl

Condition: good (used), Year of construction: 2006, 1 used 4-axis horizontal machining center Brand Haas Type EC 1600 Year of manufacture 2006 Travel ranges X-axis 1626 mm Y-axis 1270 mm Z-axis 813 mm Spindle centerline to table 304 mm Gjdpfxsv N Di Aj Ag Tott Spindle SK 50 Max. rated power 22.4 kW Max. speed 7500 rpm Max. torque 460.0 Nm 700 rpm Table size Length 1626 mm Width 914 mm T-slot width 16.00 mm T-slot center-to-center distance 125 mm Number of T-slots in standard configuration: 7 Max. load capacity on table (evenly distributed) 4536 kg Integrated 4-axis (B-axis) Table 1626 mm x 813 mm mm Clamping surface diameter 762 mm Adjustability 360° Max. workpiece swing diameter 1270 mm Table load 4536.0 kg Max. rated power 3.7 kW Rotational torque (continuous) 2712 Nm Backlash 30 arc-sec Gear ratio 500:1 Braking torque 5423 Nm Minimum resolution 0.001° Indexing accuracy ± 30 arc-sec Repeatability 15 arc-sec Rapid traverse rate on B axis 36°/sec Max. feed rate for machining on B axis 36°/sec Spindle centerline to table 146 mm Max. feed rate for machining in x, y, and z axes 12.7 m/min Rapid traverse rate on X axis 15.2 m/min Rapid traverse rate on Y axis 15.2 m/min Rapid traverse at Z 15.2 m/min Axis motors 30-station tool changer Max. tool diameter (full) 102 mm Max. tool diameter (adjacent positions empty) 254 mm Max. tool length 508 mm Max. tool weight 13.6 kg Tool-to-tool (average) 8.00 s Chip-to-chip (average) 12.60 s General information Coolant tank capacity 360 L Dimensions Domestic pallet 488 cm x 366 cm x 346 cm Export crate 488 cm x 366 cm x 348 cm Weight 13608.0 kg

Condition: excellent (used), Year of construction: 2015, With a view to optimized and energy-saving drives in the vehicle industry, significantly higher demands are placed on the components of the drive system. Higher power transmission and higher torques combined with smaller size are the challenges. This development has increased the demand for cold-formed splines. With the Vertical Splines Press (VSP) Sack & Kiesselbach provides the customer with a solution that offers technological and also logistical advantages compared to conventional technologies (such as roller burnishing or broaching). The relatively small and very user-friendly press can be configured both manually and as an automated system. In addition to the splines press, the customer can also obtain the appropriate die system and process technology from a single source. 1 used Vertical Splines Press make Sack & Kiesselbach type VSP 50/30 Year 2015 Technical data: Gtsdpfegtty Tjx Ag Tet Pressing force 500KN ram stroke 450 mm Closing speed 200 mm/s pressing speed 5,5 mm/s opening speed 120 mm/s table dimension 500 x 400 mm installation height 1000mm width between columns 530 mm splines cylinder speed 3-9,5 mm/s Dimensions height 2900 mm width 3100 mm depth 1400 mm Drive power 8 KW Special equipment Digital measuring system Splines tool for internal splines
