Used Universal Cylindrical Grinder for sale (5,474)

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Maximum grinding diameter: 200mm Maximum grinding length: 340mm Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Godjzrt Ipjpfx Af Aska Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Coolant system Wheel guard Machine lighting

Condition: good (used), Please refer to the images for all technical specifications. Transport and loading can be arranged throughout Europe for an additional charge upon request. Prices are subject to VAT. Viewing is possible by appointment. Contact us—our team looks forward to assisting you. Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MUCH MORE. Gkjdpfx Aoy H Iigef Aja Do you need a high-quality yet affordable machine for your production? Or are you looking to sell yours? For further information or contact options, please reach us via the contact form.

Condition: new, Year of construction: 2024, functionality: fully functional, Universal CNC cylindrical grinding machine for high-precision internal & external cylindrical grinding MBF 453U from the MaiBase platform The machine is a completely new development with strong dimensions in a small space! Technical data: Center width: 430 mm Standard center height: 200 mm Grinding length: 400 mm Grinding wheel diameter: 500 mm Z-axis adjustment path: 550 mm X-axis travel: 385 mm Dimensions and weight: 2200 x 2500 x 2400 mm // 6500 kg Equipment of the machine: Gsdpfx Afotrf Smj Aska - FANUC Oi-F Plus control system - Grinding headstock (swiveling) with 15kW motor spindle - Workpiece headstock MK5 - Tailstock MK3 with 20 mm stroke (optional 60 mm / 120 mm) - Handwheel for manual axis movement - Z-axis - X-axis - C-axis - B-axis - Glass scales for X- and Z-axis - Internal grinding spindle FISCHER UJ80 - Internal grinding spindle (GMN motor spindle) optional - Dressing spindle attached to the workpiece headstock for rotary dressing - Automatic door drive

Condition: like new (used), Year of construction: 2002, operating hours: 500 h, functionality: fully functional, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm spindle turning speed - stepless 2 - 12000 U/min current capacity 380 kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW weight of the machine ca. 0,6 t !!! We have almost all spare parts for the Deckel S 11 machines in stock !!! !!! Accessories can be varied as desired !!! Gjdpfxew U Eg Ro Af Ajka We would be happy to trade in your used Deckel S 11 - contact us! 2189 400 V, 50 Hz, with CEE plug and cable Colour: body pastel turquoise RAL 6034 Stand blue-grey RAL 7031 Motorized height adjustment, axial grinding spindle adjustment Machine like new !! * Accesories: * Sk ??40 dividing head with 24 R dividing disc * Graduated disc 20 R * Tightening screw M 16 69871 * Spiral and relief grinding device with rack housing * Counter bearing with 4 tailstock centres * Center point with driver * Dressing device * Dressing diamond * Radius grinding device SK 40 complete with setting gauge * Steel holder for ditto * Support fingers with sliding blades * Support finger holder * Complete dust extraction without suction * Halogen light * Tooth support complete * Setting gauge * Plier sleeve and jacking nut and wrench * 35 collets 1.0 - 18.0 mm increasing by 0.5 mm * 1 set of SK 40 direct collets 6, 8, 10, 12, 14, 16, 18, 2, 22, 25 mm * 6 jaw grinding chuck * 3 taper reducing sleeves Sk 40 x Mk 1, 2, 3, 4 * clamping nut * 20 grinding wheel chucks * 2 protective hoods * various diamond/borazon discs * Instruction Manual & Keys, Parts List, Wiring Diagram * Complete set of grinding instructions Machine is partially overhauled and with electrical acceptance report! !! Various measuring optics (new or used) with measuring cross sled available !!

Condition: used, Year of construction: 2002, operating hours: 500 h, functionality: fully functional, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm spindle turning speed - stepless 2 - 12000 U/min current capacity 380 kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW weight of the machine ca. 0,6 t !!! We have almost all spare parts for the Deckel S 11 machines in stock !!! !!! Accessories can be varied as desired !!! We would be happy to trade in your used Deckel S 11 - contact us! 2189 400 V, 50 Hz, with CEE plug and cable Colour: body pastel turquoise RAL 6034 Stand blue-grey RAL 7031 Motorized height adjustment, axial grinding spindle adjustment Machine like new !! * Accesories: * Sk ??40 dividing head with 24 R dividing disc * Graduated disc 20 R * Tightening screw M 16 69871 * Spiral and relief grinding device with rack housing * Counter bearing with 4 tailstock centres * Center point with driver * Dressing device Gkodpfsw U Eh Isx Af Aoa * Dressing diamond * Radius grinding device SK 40 complete with setting gauge * Steel holder for ditto * Support fingers with sliding blades * Support finger holder * Complete dust extraction without suction * Halogen light * Tooth support complete * Setting gauge * Plier sleeve and jacking nut and wrench * 35 collets 1.0 - 18.0 mm increasing by 0.5 mm * 1 set of SK 40 direct collets 6, 8, 10, 12, 14, 16, 18, 2, 22, 25 mm * 6 jaw grinding chuck * 3 taper reducing sleeves Sk 40 x Mk 1, 2, 3, 4 * clamping nut * 20 grinding wheel chucks * 2 protective hoods * various diamond/borazon discs * Instruction Manual & Keys, Parts List, Wiring Diagram * Complete set of grinding instructions ##### Machine is partially overhauled and with electrical acceptance report! ##### !! Various measuring optics (new or used) with measuring cross sled available !!

Condition: new, Year of construction: 2025, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm current capacity 380 kVA power capacity - grinding motor 1,1 kW speeds of grinding spindle 2 - 10.000 U/min total power requirement 2,2 kW !!! We have almost all spare parts for Deckel S 11 machines in stock !!! * Machine and accessories overhaul year of construction 2025 with CE marking DECKEL S 11 TOOL GRINDING MACHINE - UNIVERSAL 400 V, 50 Hz, with CEE plug and cable Color: 2 K new paint Stand RAL 7005 mouse gray Body and accessories RAL 7035 light gray Motorized height adjustment, axial grinding spindle adjustment * Complete electrical conversion includes: > Fi circuit breaker > New three-phase drive > new brake motor > new frequency control > new touch-safe built-in electrics > EMC cable glands > EMC cables > new protective hoses > Emergency stop switch > New control panel * Machine stand milled + ground, new support plate Basic equipment: - LED light Waldmann - Suction without a vacuum cleaner Gjdpfx Asw U Eh Usf Aeka - Protective cover for grinding wheels up to Ø 125 mm - Set of technical information - Abrasive wheel holder 51 mm - Set of suspension devices for transport - 5 adjusting screws Accessories: * Video measuring system with CCD camera and image processing software with new measuring cross slide New RSF scales on the measuring cross slide and on the machine machine axes up and across (4 axes) incl. complete mounting and adjustment * universal index head Sk 40 with dividing disc 24 R with mounting points foroptics * Operating key, operating instructions, spare parts list, circuit diagram * Technical grinding instructions * Machine and accessories overhauled and with electrical acceptance certificate * abroad 6-month warranty We will gladly accept your used Deckel S 11 as a trade-in - please contact us! !!! Accessories can be varied as required !!! Pictures include special accessories

Condition: used, Year of construction: 1984, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm spindle turning speed - stepless 2 - 10000 U/min current capacity 380 kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW DECKEL S 11 TOOL GRINDING MACHINE - UNIVERSAL 465 / 84 380 V, 50 Hz Godpfxew U Eg Do Af Aoka Colour: green !!! Original paint !!! ! Machine is in conditon from seller ! motorised height adjustment, axial grinding spindle adjustment Accessories: * Dividing head Sk 40 with dividing disc 24 R with mounting points for optics * Dust extraction device without suction cup * Protective cover * 3 pcs. transport lugs * 1 set of technical sanding instructions * Operating key, operating instructions, spare parts list, wiring diagram

Condition: excellent (used), Year of construction: 2016, operating hours: 200 h, functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 850 mm, workpiece weight (max.): 12 kg, spindle speed (max.): 10,000 rpm, spindle speed (min.): 500 rpm, feed length X-axis: 100 mm, feed length Y-axis: 190 mm, feed length Z-axis: 325 mm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, grinding length: 270 mm, rotational speed (min.): 500 rpm, rotational speed (max.): 10,000 rpm, center height in crank: 220 mm, center height: 300 mm, collet bore: 25 mm, grinding spindle speed: 10,000 rpm, feed rate X-axis: 1 m/min, feed rate Y-axis: 1 m/min, feed rate Z-axis: 1 m/min, pivoting range: 360 °, travel distance X-axis: 100 mm, travel distance Y-axis: 190 mm, travel distance Z-axis: 325 mm, center width: 620 mm, grinding spindle motor power: 1,100 W, table length: 190 mm, table width: 200 mm, table height: 1,020 mm, power: 1.1 kW (1.50 HP), height adjustment type: electric, workpiece diameter (max.): 400 mm, input current: 20 A, grinding diameter: 300 mm, input frequency: 50 Hz, disc diameter: 125 mm, input voltage: 280 V, space requirement width: 2,000 mm, space requirement length: 1,800 mm, space requirement height: 1,800 mm, grinding wheel speed: 10,000 rpm, year of last overhaul: 2022, distance table to spindle center: 325 mm, tool diameter: 300 mm, workpiece length between centers: 270 mm, distance between centers: 270 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm spindle turning speed - stepless 2 - 12000 U/min current capacity 380 kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW weight of the machine ca. 0,6 t !!! We have almost all spare parts for the Deckel S 11 machines in stock !!! !!! Accessories can be varied as desired !!! We would be happy to trade in your used Deckel S 11 - contact us! 2016 S25 003004 V, 50/60 Hz, with CEE plug and cable Color: light gray motorized height adjustment, axial grinding spindle adjustment Equipment: * Opto-electronic measuring device with measuring electronics Image processing, PC (Original ISOG) * CCD camera and monitor * Dividing head Sk 40 with dividing disk 24 R * 1 dividing disk each 14, 16, 18 * Tightening screw M 16 * Counter bearing complete with 4 center punch points * Center point Sk 40 with driver * Twist-u. Relief grinding device with rack housing * Dust extraction completely without vacuum cleaner * LED machine light * Tooth support complete with support and sliding blades * Setting gauge * Universal setting gauge * Handwheel facility * Dressing device with 3 diamonds * 1 set of collets 1.0 - 17.5 mm by 0.5 mm rising * Pliers sleeve and extraction nut and key Gkedsw U Ehbepfx Af Aoa * 10 pieces of direct collets Sk 40 6 - 25 mm * 4 cone reducing sleeves Sk 40 x Mk 1, 2, 3, 4 * Clamping nut * 12 grinding wheel chucks * Tool cabinet with shelves * 2 protective hoods * various diamond / borazon discs * Operating instructions and key, spare parts list, circuit diagram * Set of technical grinding instructions ##### Machine is partially overhauled and has an electrical acceptance report!#####

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 850 mm, workpiece weight (max.): 12 kg, spindle speed (max.): 10,000 rpm, spindle speed (min.): 500 rpm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, grinding length: 190 mm, rotational speed (min.): 500 rpm, rotational speed (max.): 10,000 rpm, center height in crank: 220 mm, center height: 330 mm, collet bore: 25 mm, grinding spindle speed: 10,000 rpm, feed rate Z-axis: 1 m/min, pivoting range: 360 °, travel distance X-axis: 100 mm, travel distance Y-axis: 190 mm, travel distance Z-axis: 325 mm, center width: 620 mm, grinding spindle motor power: 1,100 W, table length: 500 mm, table width: 180 mm, table height: 1,020 mm, power: 2 kW (2.72 HP), height adjustment type: electric, workpiece diameter (max.): 620 mm, input current: 20 A, grinding diameter: 130 mm, input frequency: 50 Hz, disc diameter: 125 mm, input voltage: 360 V, space requirement width: 2,000 mm, space requirement length: 1,800 mm, space requirement height: 1,800 mm, grinding wheel speed: 10,000 rpm, year of last overhaul: 2025, warranty duration: 12 months, distance table to spindle center: 325 mm, tool diameter: 400 mm, workpiece length between centers: 270 mm, distance between centers: 300 mm, surfacing fence height: 190 mm, Equipment: rotational speed infinitely variable, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm current capacity 380 kVA power capacity - grinding motor 1,1 kW speeds of grinding spindle 2 - 10.000 U/min total power requirement 2,2 kW !!! We have almost all spare parts for the Deckel S 11 machines in stock !!! !!! Accessories can be varied as desired !!! We would be happy to trade in your used Deckel S 11 - contact us! * Machine and accessories completely overhauled with CE marking 400 V, 50 Hz, with CEE plug and cable BASICMACHINE!!! overhauled in 2023 Color: 2 K repainting Stand RAL 7005 mouse gray Structure and accessories RAL 7035 light gray motorized height adjustment, axial grinding spindle adjustment * Complete electrical conversion includes: > Fi circuit breaker > new three-phase drive > new brake motor > new frequency regulation > new touch-safe built-in electronics > EMV screw connections Gkodsw U Ehhopfx Af Asa > EMV cables > new protective tubes > Emergency stop switch > new control panel * Machine stand milled + ground, new carrier plate Basic equipment: - LED light Waldmann - Suction without a vacuum cleaner - Protective cover for grinding wheels up to Ø 125 mm - Set of technical information - Abrasive wheel holder 51 mm - Set of suspension devices for transport - 5 adjusting screws * Operating key, operating instructions, spare parts list, circuit diagram * technical grinding instructions * CE-documents * Machine and accessories overhauled and with electrical acceptance report * abroad 6 months warranty

Condition: used, Year of construction: 2002, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length - 940 mm spindle turning speed - stepless 2 - 10000 U/min Gedpfxew U Ehno Af Ajka current capacity kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW DECKEL S 11 TOOL GRINDING MACHINE - UNIVERSAL 2178 / V, 50 Hz, with CEE plug and cable !! Original paint !!! ! Machine is in delivery condition, depending on customer request the machine can be overhauled ! motorised height adjustment, axial grinding spindle adjustment Accessories: * Dividing head Sk 40 with dividing disc 24 R with mounting points for optics* * Dust extraction device without suction cup * Halogen lamp * Protective cover * 3 pcs. transport lugs * 1 set of technical sanding instructions * Operating key, operating instructions, spare parts list, wiring diagram

Condition: used, Year of construction: 1989, functionality: fully functional, grinding wheel diameter: 125 mm, overall weight: 520 kg, collet bore: 25 mm, grinding spindle speed: 500 rpm, power: 1.1 kW (1.50 HP), input current: 20 A, input frequency: 50 Hz, year of last overhaul: 2021, Equipment: rotational speed infinitely variable, max. grinding diameter 238 - 620 mm grinding length 190 mm workpiece length 380 - 940 mm spindle turning speed - stepless 2 - 10000 U/min current capacity 380 kVA power capacity - grinding motor 1,1 kW total power requirement 2,2 kW weight of the machine ca. 0,6 t !!! We have almost all spare parts for the Deckel S 11 machines in stock !!! !!! Accessories can be varied as desired !!! We would be happy to trade in your used Deckel S 11 - contact us! Notice: We would be happy to provide you with a free offer. However, please understand that we only accept inquiries with a complete address edit. 1218 400 V, 50 Hz, with CEE plug and cable Colour: light grey RAL 7035 Stand traffic grey RAL 7042 (new paint) axial grinding spindle adjustment Accessories: * Machine stand and carrier plate ground * Complete electrical conversion included: > new three-phase drive > new brake motor > new frequency controller > new built-in electrics touch-proof > Fi circuit breaker > EMC cables and screwed connections > new protective cables > new control panel > Emergency stop switch * Opto electronic measuring device with microscope, support arm, parking space, new 2-axis Fagor digital readout and scales completely mounted and adjusted * dividing head Sk 40 with prisms and 24 R dividing disc * 1 graduated disc 14 + 22 R each * Twist and back-grinding device with rack and pinion housing * Setting gauge * Complete tooth support * pivoting support finger * LED lamp waldmann * Dust extraction device without vacuum cleaner * Univ. adjustment gauge * 10 direct collets Sk 40 6/ 8/ 10/ 12/ 14/ 16/ 18/ 20 22/ 25 mm * Collet sleeve with forcing nut * 1 set = 35 collets S 20x2 from 1.0 - 18.0 mm by 0.5 mm each * 1 taper reducing sleeve Sk 40 x Mk 1/ 2/ 3/ 4 * 3 grinding wheel chuck L 48, 35 mm * Protective cover * Exchange grinding spindle * Tool cabinet with 4 drawers * Shelves for dto. * Operating key, operating instructions, spare parts list, circuit diagram * Machine and accessories completely overhauled and with electrical test Gksdsw U Ehzopfx Af Aea certificate!* 6 months warranty !

Condition: used, Year of construction: 2000, grinding diameter 500 mm grinding length 1000 mm centre height 250 mm -major maintenance -New table geometry -partial painting of the interior grinding wheel equipment LEFT 400x63x127mm (standard) grinding wheel equipment RIGHT 300x40x127mm Internal grinding unit Ø120mm for HF spindles CNC control KELCO 120 C-axis for non-circular grinding. Kel-Poly B-AXIS: CNC-controlled B-axis KELCO 120: v constant 35m/s or 45m/s High-frequency internal grinding spindle Operating unit for MFV and MFZ spindles Godpfxoxzk Nio Af Aeka Hydraulic quill retraction for the tailstock NO micro-adjustment on the tailstock Spring-loaded quill insert Top table cooling Standard workpiece headstock MK 5 DIN 55026 size 5" Micro-adjustment for the standard workhead Dressing device on the lower table Active longitudinal positioning KELPOS, MARPOSS, mounted on the grinding head Tool measuring system KELSET, MARPOSS MARPOSS gate sensor Measuring control MARPOSS Minialsar prepared Paper belt filter

Condition: good (used), grinding diameter 450 mm grinding length 600 mm centre height 140 mm Godpfx Ajxcblqof Aska workpiece dia. 280 mm number of turns of spindle head 63 - 400 U/min grinding wheel speeds 20-35 m/s dimensions of the machine ca. 2,4 x 1,9 x 2,1 m

Condition: used, TECHNICAL DETAILS Gjdexrg Hxepfx Af Aeka - center height : 100 [mm] - Distance between centers : 650 [mm] - Max. table orientation : [°] - Travel : 650 [mm] - Speed : 100 - 3500 [mm/min] GRINDING WHEEL HOLDER HEADSTOCK - Orientation : [°] - T1 grinding wheel dimensions : 350 x 32 x 127 [mm] - Power : 3 [kW] - Speed : 1600 - 2200 [rpm] - Peripheral speed : [m/s] PART-HOLDER HEADSTOCK - Spindle speeds : - 1200 [rpm] - Power : 0.5 [kW] - Type of cone : CM4 - Max. part weight : 20 [kg] - Orientation : 0 - 90 [°] POWER SUPPLY - Supply voltage : 400 [V] - Power : 8 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 00 x 00 [mm] - Machine height : 1650 [mm] - Machine weight : 1900 [kg] MACHINE HOURS - Number of hours under power : 01 [h] EQUIPMENT - Sony LG20-2 display - Automatic contact detection : SENSITRON 6 - 1 tailstock with fine adjustment - 2 internal grinding spindles : 20.000 / 60.000 [rpm] - Fixed dressing device - Coolant tank - 1 three-key steady rest - 3-jaw chuck, Ø 100 mm - Various grinding wheels

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - Center height : 175 [mm] - Table orientation : 9 [°] - Universal wheelhead - Left grinding wheels dimensions : 400 x 50 x 127 [mm] - Motor power : 3 [kW] - Spindle speeds : 1500 / 1700 / 2200 - Orientation of grinding wheel holder headstock : 270° (3 x 90 °) - Boring for internal spindle : 90 [mm] - Orientation of part holder headstock : 180 [°] Gsdpfxexy S A Ij Af Aoka - Spindle speeds : 20 - 400 [rpm] - Spindle internal cone : Morse 5 - Motor power : 0,9 [kW] - Inner cone tailstock : Morse 4 - Tailstock sleeve travel : 30 [mm] - Dimensions : 2860 x 1680 x 1670 [mm] - Machine weight : 2500 [kg] EQUIPMENT - Automatic cycle work (rough part, finishing and reverse) - Hydraulic tail stock - Lubricating tank with paper filter - 1 internal grinding spindle - 1 diamond holder - 2 two-key steady rests - 1 three-key steady rest - 1 set of drive knobs - Various wheel holders

Condition: used, TECHNICAL DETAILS - center height : 100 [mm] - Distance between centers : 650 [mm] - Max. table orientation : [°] - Travel : 650 [mm] - Speed : 100 - 3500 [mm/min] GRINDING WHEEL HOLDER HEADSTOCK - Orientation : [°] - T1 grinding wheel dimensions : 350 x 32 x 127 [mm] - Power : 3 [kW] Godpfeyn R I Hox Af Aoka - Speed : 1600 - 2200 [rpm] - Peripheral speed : [m/s] PART-HOLDER HEADSTOCK - Spindle speeds : - 1200 [rpm] - Power : 0.5 [kW] - Type of cone : CM4 - Max. part weight : 20 [kg] - Orientation : 0 - 90 [°] POWER SUPPLY - Supply voltage : 400 [V] - Power : 8 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 00 x 00 [mm] - Machine height : 1650 [mm] - Machine weight : 1900 [kg] MACHINE HOURS - Number of hours under power : 01 [h] EQUIPMENT - Sony LG20-2 display - Automatic contact detection : SENSITRON 6 - 1 tailstock with fine adjustment - 1 internal grinding spindle - Fixed dressing device - Coolant tank - 1 three-key steady rest

Condition: used, TECHNICAL DETAILS - Distance between tips: 400 [mm] - Tip height: 125 [mm] - max. workpiece weight between tips: 150 [kg] - Z axis stroke : 600 [mm] - Z axis rapid feed : 15 [m/min] - Table orientation : +/- 6 [°] WHEELHEAD - grinding wheel dimensions: 500 x 80 x 203.2 [mm] - peripheral speed: 60 [m/sec] - Power : 9.5 [kW] - head position : -30 [°] WORKPIECEHEAD - Type of cone : CM5 - Speeds : 5 - 1500 [rpm] - Power : 2.1 [kW] - Bore : 34 [mm] Gkodpfeuhbxyex Af Aea TAILSTOCK - Cone : CM3 - Quill stroke : 80 [mm] POWER SUPPLY - Voltage: 400 [V] - Frequency: 50 [Hz] - Installed power: 16 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.650 x 3.050 [mm] - Machine height : 2.000 [mm] - Machine weight : 4.850 [kg] MACHINE HOURS - Number of working hours : 42000 [h] EQUIPMENT - CNC : Siemens 840 D - Remote electronic handwheel - Automatic tailstock - Diameter and length control - Loading/unloading robot - Cooling unit - Coolant tank - Oil mist extractor - Wheel diamer - 2nd grinding head with CBN wheel and rotary wheel dresser - Fire extinguisher * *NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - distance between centers : 1000 [mm] - centers height : 175 [mm] - strokes (Z/X) : 1050 x 275 [mm] - max. feeds (Z/X) : 10 x 5 [m/min] - grinding wheelhead type : 2 external, 1 internal - left external grinding wheel dimension : 500 x 63 x 127 [mm] - right grinding wheel dimension : 400 x 63 x 127 [mm] - grinding wheel motor power : 7,5 [kW] - rotation speed : 1670 - 2110 [Rpm] - grinding wheelhead orientation : -15 to +225 [°] - resolution : 0.001 [°] - workhead tapper : MT5 - workhead rotation speed : 1 - 1027 [Rpm] - workhead power : 0,785 [kW] - tail stock : MT3 - quill stroke : 35 [mm] - weight : 7000 [kg] - hours under power : 47.959 [h] EQUIPMENT - control CNC FANUC 16 TB - programming through Pictogramming - Release B version B275 - deported electronic handwheel - 2 grinding wheels left-right internal at 180 [°] - B axis for indexing of the grinding wheelhead every 0,001 [°] - high precision C axis for part indexing and form grinding - tail stock with fine concentricity adjustment - sensitron - upper table swiveling fine adjustment Gkedpfx Afjuhbyqs Aoa - control pedal - lenght positioning device MARPOSS E32R with sensor T25G - measuring scales HEIDENHAIN on X/Z - coolant tank with pump - 1 grinding wheel holder flange - 1 grinding wheel - 1 dry center - 1 electro-spindle : 40.000 [Rpm] - tail stock hydraulic retract through pedal

Condition: used, TECHNICAL DETAILS - distance between centers : 200 [mm] - centers height : 100 [mm] - strokes (X/Z) : 130 / 170 [mm] WHEELHEAD - grinding wheels dimensions : 400 x 63 x 127 [mm] - peripheral speed : 45 [m/sec] - power : 3 [kW] - positioned at : 30 [°] WORKPIECEHEAD - type of cone: MT4 - speeds : 600 - 3000 [rpm] - power : 0,5 [kW] - C axis indexing precision : +/- 0,5 [°] TAILSTOCK - type of cone : CM2 - quill stroke : 30 [mm] ELECTRICAL SUPPLY - voltage : 400 [V] - frequency : 50 [Hz] - installed power : 19 [kVA] DIMENSIONS - floor space : 1760 x 2180 [mm] - height : 2630 [mm] - weight : 4.000 [kg] Gsdpfx Asuhbxmsf Ajka HOURS - under power : 46.943 [h] - working hours : 21.529 [h] EQUIPMENT - CNC FANUC 16TB - soft options : Studer Release B, Pictogramming - interface : RS232C - electronic deported handwheel - direct measuring rules on axes X/Z - tailstock with fine concentricity adjustment - tailstock pinole hydraulic recoil - swiveling dressing wheel upon table : FISCHER AES-72x230/3 - dynamic wheel balancing device : DITTEL HBA 4000 - prepared for diameter sensor : MOVOMATIC ES400 - prepared for parts loading/unloading robot : FELSOMAT - automatic front door - prepared for cooling - electrostatic aspiration : ELOSTA BF2000 - pneumatic collets chuck - 1 wheel-holder - 1 grinding wheel - support arm for zero gravity wheel change - 1 balancing shaft

Condition: used, TECHNICAL DETAILS - Distance between tips : 400 [mm] - Tip height : 125 [mm] - Max. workpiece weight between tips : 150 [kg] - Z axis stroke : 600 [mm] - Z axis rapid feed : 15 [m/min] - Table orientation : +/- 6 [°] WHEELHEAD - Grinding wheel dimensions : 500 x 80 x 203.2 [mm] - Peripheral speed : 60 [m/sec] - Power : 9.5 [kW] - Head position : -30 [°] WORKPIECEHEAD - Type of cone : CM5 - Speeds : 5 - 1500 [rpm] - Power : 2.1 [kW] - Bore : 34 [mm] TAILSTOCK - Cone : CM3 - Quill stroke : 80 [mm] POWER SUPPLY - Voltage : 400 [V] - Frequency : 50 [Hz] - Installed power : 16 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.650 x 3.050 [mm] - Machine height : 2.000 [mm] - Machine weight : 4.850 [kg] MACHINE HOURS - Number of working hours : 31000 [h] EQUIPMENT - CNC : Siemens 840 D - Remote electronic handwheel - Automatic tailstock - Diameter and length control - Loading/unloading robot - Cooling unit - Coolant tank - Oil mist extractor Gsdpfxjuhbx He Af Aeka - Wheel diamond grinding device - 2nd grinding head with CBN wheel and rotary wheel dresser - Fire extinguisher * *NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: used, TECHNICAL DETAILS - distance between centers : 1000 [mm] - centers height : 125 [mm] - table orientation : -/+ 8 [°] - universal wheelhead - grinding wheels dimensions : 400 x 50 x 127 [mm] - motor power : 3 [kW] - spindle speed : 1500 / 1700 / 2200 - orientation of grinding wheel holder headstock : 270 [°] (3 x 90°) - boring for internal spindle : 90 [mm] - orientation of part holder headstock : 180 [°] - spindle speed : 20 - 400 [Rpm] - spindle internal cone : Morse 5 - motor power : 0,9 [kW] - inner cone tailstock : Morse 4 - tailstock sleeve travel: 30 [mm] Gksdjuhbx Topfx Af Asa - dimensions : 2860 x 1680 x 1670 [mm] - weight : 2 500 [kg] EQUIPMENT - automatic cycle work (rough part, finishing and reverse) - tail stock - sinus ruler for part holder headstock - head UR : 2 external and 1 internal grinding wheel - lubricating tank with pump - 1 internal grinding spindle SFJ UJ70 : 14.000 [rpm] - 1 fixed diamond grinding device holder on tail stock - 1 chuck 4 jaws - 1 magnetic chuck - 1 set of driving tocs - 2 rests 2 points - spacer to increase centre height to 175 mm - various grinding wheel holders - various grinding wheels

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - center height : 175 [mm] - Table orientation : 9 [°] GRINDING WHEEL HOLDER HEADSTOCK - Left grinding wheels dimensions : 400 x 50 x 127 [mm] - Right grinding wheels dimensions : 225 x 20 x 76,2 [mm] - Power : 3 [kW] - Spindle speeds : 1500 / 1700 / 2200 [rpm] - Orientation of grinding wheel holder headstock : 270 [°] - Boring for internal spindle : 90 [mm] PART-HOLDER HEADSTOCK - Orientation of part holder headstock : 360 [°] - Spindle speeds : 20 - 400 [rpm] - Spindle internal cone : Morse 5 - Power : 0.9 [kW] TAILSTOCK - Internal cone : Morse 3 - Quill stroke : 30 [mm] Gedpfszfqzajx Af Ajka POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 2860 x 1680 [mm] - Machine height : 1670 [mm] - Machine weight : 2500 [kg] EQUIPMENT - Automatic cycle work (rough part, finishing and reverse) - Kelco 5 display - Coolant tank * with paper filtering unit - 1 internal grinding spindle : 5400 [rpm] - Chuck 4 jaws - 1 three-key steady rest - Set of wheels

Condition: used, TECHNICAL DETAILS - Distance between centers : 650 [mm] - center height : 175 [mm] - Max. part weight between centers : 80 [kg] - X/Z stroke : 285 / 800 [mm] - Axis X programmable feed speed : [mm/min] - Resolution : 0.0001 [mm] - Axis Z programmable feed speed : [mm/min] - Resolution : 0.0001 [mm] - Table orientation : 0 - 8.5 [°] GRINDING WHEEL HOLDER HEADSTOCK - T1 grinding wheel dimensions : 500 x 63 x 203,2 [mm] - Speed : 50 [m/s] - Power : 9 [kW] - Manual orientation : -15 / +195 [°] - Indexing precision : 2.5 [°] - Internal grinding : 40.000 [rpm] - Power : 3 [kW] PART-HOLDER HEADSTOCK - Type of cone : CM5 - Speed : 1 - 1500 [rpm] - Power : 1.8 [kW] - Boring : 30 [mm] - C axis indexing precision : +/- 0,5 [°] - TAILSTOCK - Type of cone : CM4 - Quill diameter : 50 [mm] - Quill stroke : 35 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 20 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.670 x 2.050 [mm] - Machine height : 1.900 [mm] - Machine weight : 4000 [kg] MACHINE HOURS - Number of hours under power : 190 [h] EQUIPMENT - CNC : FANUC Oi-TD Gjdpfx Aoylc R Ujf Ajka - Electronic handwheel - 3 colors status lamp - Oil mist extractor - Linear scales on axes X/Z - Dynamic wheel balancing : MPM - Automatic contact detection : SENSITRON 6 - Fixed dressing device - Workpiece probe - Coolant tank : 375 [l] * with paper filtering unit

Condition: used, TECHNICAL DETAILS - Centers height : 125 [mm] - Distance between centers : 400 [mm] - Grinding wheels dimensions : 400 x 127 x 50 [mm] - Power : 4 [kW] - Max. part weight : 30 [kg] - Floor space : 3000 x 3520 [mm] - Weight : 4000 [kg] Gsdpfouhbxtox Af Aoka EQUIPMENT - CN FANUC 21i-T - B axis with 1° precision - Chuck 3 jaws - Tool-holder flanges - 1 external grinding wheel - 1 diamond grinder - Tail stock with fine adjustment - 1 internal grinding devices with spindle 42000 rpm - Coolant tank with paper filter - Part probe

Condition: used, TECHNICAL DETAILS - Distance between centers : 1000 [mm] - center height : 180 [mm] - Max. part weight between centers : 100 [kg] GRINDING WHEEL HOLDER HEADSTOCK - External grinding * Power : 7.5 [kW] * Grinding wheel dimensions : 500/80/203 [mm] PART-HOLDER HEADSTOCK - Speed : 10-800 [rpm] POWER SUPPLY - Supply voltage : 400 [V] EQUIPMENT - CNC : Fanuc Oi-TF Gedpfx Aezrp Edjf Aeka - 3 colors status lamp - Tool probe : Marposs - Coolant tank * with paper filtering unit * with cooling unit for coolant
