Used Worm Gear Cutter for sale (10,051)

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Iiodjxh Rqtjpfx Akxjf Swivel angle: +/- 90°

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm Iijdpfxsw N S E Aj Akxef travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: excellent (used), Year of construction: 2019, Geared motor, electric motor, electric geared motor, worm geared motor, flat geared motor -Condition: Geared motor is unused -Manufacturer: NORD DRIVESYSTEMS, Flat gearbox series F -Type: SK7382AZH-180MP/4 TF Iisdpfszu S Hpsx Akxsf -Speed: 22 rpm -Power: 18.5 kW -Protection rating: IP55 -Hollow shaft: Ø 70 mm -Dimensions: 930/450/H660 mm -Weight: 410 kg

Condition: good (used), Geared motor, electric motor, electric geared motor Iodpfx Asckbgaokxoif -Engine manufacturer: VEM -Manufacturer of gearbox: VEM -Speed: 40 rpm -Power: 1.1 kW -Design: B3 -Shaft diameter: 48 mm -Protection class: IP 44 Quantity: 1 piece available -Dimensions: 580/250/H300 mm -Weight: 41 kg

Condition: good (used), Year of construction: 1980, functionality: fully functional, Gear-driven drill press, no belt changes required Very quiet and smooth operation - Drilling capacity in steel ST 60: 30 mm - Drill spindle mount: MK 3 - Drill spindle stroke: 160 mm - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions, swiveling: 500 x 450 mm - Table dimensions, base plate: 350 x 400 mm - Distance from base plate to spindle nose: 1100 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Column diameter: 120 mm - Drive: 380 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 670 mm - Weight: approx. 350 kg - Includes drill chuck Iedezuxxfopfx Akxjif

Condition: used, Year of construction: 2012, - Cutting width 2200 mm Iijdpfx Akjzuy Arjxof - Equipped with an IR pre-heating zone and cooling unit Film cutter Manufacturer: HSM Maschinentechnik Type: ABW - ROTA - 2200 Year of manufacture: 2012 Technical data - Cutting width 2200 mm - Equipped with an IR pre-heating zone and cooling unit - Front: semi-automatic roll change - Rear: individual sheets are automatically stacked on a pallet Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: new, Fully automated block cutting machine for pallet legs. Maximum length of raw material 6m. The machine suits all type of pallet production. OKKR-2006 can operate as a separate standing machine or as part of a production line. How does it work? The machine is fed block material on the chain infeed conveyor. The material is fed automatically and the machine cuts the blocks into the preinstalled length. OKKR-2006 can be programmed to cut several different lengths of blocks from the original piece of raw material. Maximum length of the raw material is 6m. Asssembled block size: Min / max length: 600 mm - 6000 mm Width min / max: 75 mm - 150 mm Thickness min / max: 75 mm - 100 mm Ijdpfx Ajwdutmekxoif Specifications Operators | 0 Length | 7,5 m Width | 2,5 m Height | 1,8 m Power | 7 kW, 3x400 V+N Pneumatic system | 7 bar compressed dried air: 450 L/min Should be filled and controlled | Lubrication points Machine capacity | 36 blocks/min Standard equipment | 1 electric motor for saw blade 1 electric motor for material infeed 1 electric motor for chain infeed Mychrome has various additional machine modules that can be easily docked onto existing machines to achieve a higher level of automation. The ability to change the design and size of the pallets is still available with these additional machine modules.

Condition: good (used), amount 1 STK Ijdpfx Aozuum Ejkxeif Dimensions (HxWxD) 280 x 190 x 190 mm diameter 60 mm -> Bestcut gear hobbing cutter with HSS cutting material - Chip angle < 8° -> Module 16 F.20° 1gg Lks -> BP IV D-Stg < 5°40' -> 5° 40' Sp Stg 00

Condition: good (used), amount 1 STK Dimensions (HxWxD) 280 x 190 x 190 mm diameter 60 mm Iiedpfxszuumxo Akxof HSS hob for high wear resistance

Condition: good (used), amount 1 STK Dimensions (HxWxD) 300 x 190 x 190 mm Ijdpezuumrefx Akxjif diameter 60 mm -> Gear hobbing cutter with HSS cutting material -> Module 18 20°1 gg Lks. -> HSS-C 70.251VF

Condition: good (used), amount 1 STK Dimensions (HxWxD) 300 x 190 x 190 mm Iedpfx Akszuumlsxeif diameter 60 mm -> Gear hobbing cutter with HSS cutting material -> Module 18 -> L1 -> 5° 48`

Condition: good (used), amount 1 STK Dimensions (HxWxD) 300 x 190 x 190 mm diameter 60 mm -> Gear hobs from Franken with HSS cutting material -> M52083/1 K Ijdezuumfjpfx Akxeif -> C 13 A

Condition: like new (used), number 1 Stück Iijdpezupmasfx Akxsf LIEBHERR/LORENZ disc cutting wheel Modul 4 - EW 30° - Zähne 12 - DIN 5480 - new

Condition: like new (used), number 1 Stück LORENZ disc cutting wheel HM: HB10 - F Z2/Z0= 15/60 14 - 44C 46 711/1 mn3.08 an21° z60 Iiedpfxjzupl Aj Akxjf

Condition: good (used), Year of construction: 1965, max. wheel diameter 900 mm max. module 6,5 stroke up to 150 mm table diameter 900 mm table hole 360 mm weight 3,7 t External: Iijdpjywnt Tefx Akxof max. diameter 900 mm Max. gear width 150 mm Internal: Max. diameter 630 mm Max. gear width 150 mm Spindle bore table 360 mm Table diameter Ø 900 mm Module 6.5 mm Length 2500 mm Width 2300 mm Height 2600 mm Weight 4100 kg

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm y-travel 560 mm gear width 180 mm max. module 8 min. module 1 workpiece dia. 750 mm table diameter 450 mm draw-in arbor diameter 58 mm spindle stroke 200 mm Iisdpfx Aoyb Sx Tskxof adjustment range 230 mm distance between table/spindle 225-450 mm taper Morse 4 down feeds 0,03 mm/Hub roll feed 10n: 0,18-0,74 mm/Hub no. of strokes 12n: 47-300 Hub/min electrics - voltage/frequency 380/50 V/Hz weight of the machine ca. 5500 kg The machine was raised by 100 mm.

Condition: used, Year of construction: 2003, Control BWO tip circle diameter max. 700 mm root circle diameter min. 50 mm height of profile max. 35 mm number of spindle speeds 0 - 5400 min-1 table load capacity max. 500 kg Overall size 370x220x300 cm Total weight, approx. 15000 kg Number of working hours 94082 h Equipment: BWO control system Iijdsxt Ur Sepfx Akxof All axes CNC controlled Oil mist extraction Coolant cleaning system with cooling unit Dittel balancing unit Accessories: Grinding wheels Ø400mm incl. Grinding wheel flanges 1 diamond dressing roller, manufacturer Dr. Kaiser, Ø160mm Counterholder tip Control cabinet: Width 70 cm x length 280 cm x height 220 cm Machine: Width 220 cm x length 370 cm x height 300 cm Coolant system: Width 170 cm x length 240 cm x height 250 cm

Condition: good (used), Year of construction: 1972, max. wheel diameter 80 mm Iiedpfx Aew N S D Sjkxsf gear width 60 mm max. module 3 min. module 0,1 total power requirement 0,4 kW weight of the machine ca. 120 kg dimensions of the machine ca. 0,6x0,6x0,75 m

Condition: good (used), Year of construction: 1982, max. wheel diameter 600 mm gear width 500 mm max. module 15 min. module 1 total power requirement 2 kW weight of the machine ca. 2 t dimensions of the machine ca. 2x1,5x2 m The rounding of the teeth is obtained by coordinating alternative movement of the cutter and rotary movement of the piece. The alternative movement of the cutter is obtained by rotating a cam, shaped in order to obtain radius or cusp rounding. A series of 4 cams allows to work modululus from 1 and 16 included. An regulation device allows change the modulus between the minimum and maximum value of every cam. The rotation of the piece is controlled by a three-stage gear wheel which forms the dividing system. The piece lock and the movement of the rapid entry of the cutter to the piece is controlled by pneumatic servo devices. The practicality and rapidity of the equipment, as well as the wide range of profiles available on the cams and the ability to process internal gears, make the machine a universal machine suitable for machining small and large series. --> technical features Max module: 15 --> Max diameter: 600 mm --> Spindle/head speed: 1450 - 2100 - 2800 rpm --> Production output teeth per minute: 35 - 50 - 75 --> Motor output spindle: 2800 rpm - 1.5 HP --> Motor power piece rotation (self-braking): 1.5 HP --> Motor power automatic (self-braking): 0.35 HP --> Motor power cooling system: 0.25 HP --> Dimensions: 2000 x 1500 mm --> Total weight: 2000 kg Accessories Cam x 5 Indexing wheels Tools Isdpfewftuxox Akxeif Serial no. 152/0589/94 Machine with full enclosure Counter support

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 stroke length max. 0 - 52 mm spindle taper innen MK 4 Iiodpfx Akou Uu S Texsf table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg Year of construction: Approx. 1970

Condition: used, Geared motor, electric motor, electric geared motor -Handover: in its current condition as inspected -Condition: Gearbox makes quiet noises -Speed: 40 rpm -Power: 0.55 kW Iodpfsckd Eksx Akxoif -Design: B3 -Shaft diameter: 32 mm -Protection class: IP 44 -Number: 2x motors available -Price: per piece -Dimensions: -Weight: 26 kg

Condition: used, Year of construction: 2008, Maximum workpiece outer diameter 3420 mm Minimum workpiece inner diameter 630 mm max. module 30 mm control Siemens Sinumerik 840 D Workpiece tooth width - max. 600 mm tip circle diameter 440 mm Milling arbour diameter 80 mm x-travel 1110 mm y-travel 1300 mm spindle turning speed - stepless 18 - 180 U/min rotary table speeds infinitely variable 0 - 6 U/min Ring stength 500 mm total connected load 100 kVA weight of the machine ca. 38 t dimensions of the machine ca. 8,41 x 9,05 x 5,19 m Feed rate: - X-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in 1/min - Tool 18 to 180 - Workpiece table 0 to 6 Ijdoztz Ruspfx Akxjif Equipment/accessories: - IFK2 internal milling head - Milling arbor with spacer discs - Chip conveyor - Oil mist extraction - Dry machining only - Technical documentation

Condition: used, Year of construction: 2007, workpiece diameter nominal 2400 mm max. workpiece diameter 2800 mm max. module 30 mm control Siemens Sinumerik 840 D dividing plate diameter 2200 mm table diameter 2500 mm Table hole Diameter / depth 800 / 875 mm max. table load 40000 kg Table rpm 4,5 min-1 clamping length max. 375 mm clamping diameter max. 350 mm cutter diameter max. 2800 mm Cutter arbor cone HSK-B160 swivelling range milling head + 30/-45° Distance Cutter - Workpiece 615 / 1600 mm weight of the machine ca. 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction Iiodpfjw Rf S Sox Akxof - technical Documentation

Condition: used, Second-hand adjustable joint and rebate cutter, Leitz Type 024243, for professional jointing and rebating work in woodworking. The tool is designed for use on suitable woodworking machines and allows for the machining of variable joint and rebate widths. Iiedpfx Akjzunzvexsf Technical data: - Blade: WP Z4 V4 - Flight circle (ø): 160 mm - Bore: 40 mm - Marking: BG-Test - Length: 56.4–99 mm - Material: Steel

Year of construction: 2021, condition: good (used), 1 complete granulation line, cutting/compacting/extruder combination, tangential, since 2021 only operated in a single shift using production waste, including DPE ground material/aluminum (pipe material). System consisting of: Hydraulic roller cutter, 140 cm width, for roller diameters up to 60 cm, 18.5 kW drive. Erema conveyor belt with metal detection bridge, 900 cm x 110 cm, with timer. Wagner WS30 shredder, 30 kW, rotor width 140 cm with hydraulic slide, rotor with 74 reversible cutting blades, discharge and inclined conveying screw. Roller feed for heavy rolls with cutting device in the longitudinal direction to relieve the mill, frequency inverter-controlled drive, 3.5 kW. Cutting mill with 11 kW, downstream for parallel operation with shredder/roller feed, suction/conveying fan to the buffer silo with agitator, frequency inverter-controlled for discharge rate/dust protection. Feed screw for ground material. Conveyor belt, L 9 m x W 80 cm, metal detection bridge, frequency inverter controlled via load detection from the cutting compactor. Conveying screw for 100% ground material, stainless steel, L 4.5 m and diameter 100 mm. Cutting compactor, 138 kW, frequency inverter controlled, suction fan, water spray cooling, tangential to extruder ES 180 mm 30 LD with 2-stage vacuum degassing, including: Laser filter LF with diameter 500 mm / 2-disc system, discharge screw for contaminants with timer, melt pressure sensor, spare screens: 60 mesh 2x, 70 mesh. Strand die, 26 holes - interchangeable dies, year of manufacture 2021, melt pressure sensor, complete overhaul/replacement of wear parts in January 2026. Strand cooling water tank, L 700 cm x W 70 cm, stainless steel. Strand rollers made of plastic with stainless steel ball bearings, height-adjustable, year of manufacture 2023. Strand granulator SG 200 E with 7.5 kW as well as 1 spare granulator 5.5 kW for quick replacement during overhaul or cleaning/maintenance work. Granulate classification sieve, stainless steel, including conveying fan and pipes. BIG BAG filling frame, 2-place, with ladder and platform. BIG BAG floor scale with receipt printer. Throughput material-dependent, up to 900 kg/h. Start-up, commissioning by our technicians, details and costs upon request - after consultation. Iedpfx Akszb Dr Sexjif Inspection in Wuppertal, appointment can be arranged shortly.
