Extruder 20 mm 25 l/d

PMH GmbH EX-20-25l/d

Year of construction: 2003, condition: reconditioned (used), Stock - No. 2651 Ncodpfx Akjiyyf Ioqer 1 used underwater pelletizing unit, partially overhauled in 2023 Throughput up to approx. 450 kg/h depending on the material, consisting of: Type BKG ( Nordson ) Start-up valve with hydraulic station Granulator type A300 including die-plate and cutter bar, drive 4.4 kW by-pass system TVE 1000 ED pellet-dryer drive 4 kW incl. Agglomerate catcher Tempered water system with Water box 200 liters, installed heating capacity 9 kW Water pump 2.2 kW with 15³/h heat exchanger Control unit - NEW Further UWP pelletizing units are available ex workshop in Wuppertal-Germany ( as Gala, BKG Nordson, Econ ) Available from the Wuppertal warehouse: complete compounding, pelletizing extrusion lines, with single-screw or twin-screw extruder.

Condition: excellent (used), Boy 80M Year 1998 Closing 80 tons Nedsmt Hh Eopfx Akqjcr Scrow 36 mm Spray weighted 132 g spar distance 41x 35,8

Condition: new, Year of construction: 2024, machine/vehicle number: 302340, Profile Bending machine KB Türkei model MB 30 bottom shaft 30 mm top shaft 35 mm two rollers driven with basement capacity: Ncsdpod S Uf Sofx Akqsr up to round tube 48 x 3,0 mm flat material 50x10 mm square tube 40x40x3,0 mm weight 170 kg motor 0,75 kw 400 Volt 50 Hz 3 ph.

Condition: used, Year of construction: 2003, functionality: limited functionality, machine/vehicle number: 0 278 06 1192, film width: 700 mm, roll diameter: 700 mm, Used Friz rotary cutter. 1 set of blades has been resharpened. The machine is used and is sold without warranty. Inspection is possible and welcome. Loading facilities available. Nodsv Radxepfx Akqscr

Condition: excellent (used), functionality: fully functional, Year of construction: 1984, Loading capacity: max. 300 Kg. Diameter of decoiler: 1.000 mm Diameter of spool: max. 900 mm Nodpsf S I I Hjfx Akqjcr Inside diam of spool: 240 - 560 mm Hight of spool: max. 180 mm

Condition: excellent (used), functionality: fully functional, Werner & Pfleiderer Twin-Screw Extruder ZSK 40 – Excellent Condition For sale is a Werner & Pfleiderer (WP) ZSK 40 co-rotating twin-screw extruder. Nsdpfx Akjycuuyoqjcr Technical Specifications: • Machine Type: ZSK 40 • Screw Diameter: 40 mm • Screw Length: 7 barrels × 4 D → approx. 28 L/D • Main Drive: 34.5 kW • Motor Speed: 1,800 rpm • Screw Speed: 40 – 400 rpm • Max. Torque per Screw Shaft: 325 Nm • Heating: Electric, connected load approx. 17 kW • Cooling: Water chiller unit • Temperature Control Zones: 6 zones • Barrel Temperature Sensors: 6 • Material Temperature Sensor: 1 • Material Pressure Sensor: 1 Barrel Configuration: • Feed barrel with liquid injection port • Open barrel with insert and 2 liquid injection ports • Multiple closed barrels with ports for liquid injection or measurement points • Degassing barrel General Features: • Co-rotating, closely intermeshing (self-cleaning) screws • High mixing and dispersing performance thanks to modular mixing and kneading elements • Modular system for screws and barrels • Drive section and process section mounted on stable base frame Fields of Application: • Plastics compounding • Masterbatch • Additive and filler incorporation • Laboratory and pilot plant use • Formulation and product development Condition & Runtime: According to the operating hour counter, the machine has run for less than one year and is therefore in excellent, nearly as-new condition. The screw elements are also as new. Options & Customizations: Upon request, we can design and install suitable tooling, such as strand dies, and integrate additional peripherals such as screen changers, pelletizing units, dosing technology, or other customer-specific components. The machine can thus be configured and delivered ready-for-operation according to customer requirements.

Condition: excellent (used), functionality: fully functional, Eccentric granulation EGR is used in the production of temperature- and shear-sensitive plastics. It is specifically designed for the granulation of soft PVC, rigid PVC, HFFR formulations, or compounds for low-, medium-, and high-voltage cables based on elastomers. Ncsdpfxsw Iu T Tj Akqor Additionally, the machine can also be used as a conventional single-screw extruder for various processing purposes. • Screw diameter: 200 mm • with degassing zone • Drive power: 72.5 kW

Year of construction: 2024, condition: new, noris- Extruder MINI ESE 20/25 D Technical data Screw diameter [mm] 20 Screw length [L/D] 25 Screw speed [min-1] 20-200 min -1 Screw axial pressure [bar] 300 Continuous load 350 maximum Drive Three-phase drive with frequency converter Drive power [kW] max. 2.5 Reduction gear with integrated axial bearing Weight [kg] approx. 160 Dimensions [Lx Wx H] [mm] approx. 1050 x 600x 1590 *) Electrical connection values 3 / N / PE Supply voltage [V] 400 at 50 Hz Control voltage [V] 230 Ncodpfx Ajhx Elfskqor Temperature control electrical resistance heating bands in mica design. Max. processing temperature [°C] 300 Switch cabinet and control panel The electrical installation of the extruder is located in the machine base. The base contains all the necessary switching, control and display devices. The feed zone is water-cooled, the water connection is provided by the customer, a cooling unit for cooling the water is not included in the offer. Extruder tools are not part of the offer

Year of construction: 2020, condition: ready for operation (used), A color measurement device Datacolor is available. Measurement geometry: d/8°, illumination system: Dual, integrating sphere diameter: 152mm, wavelength range: 360nm-700nm, wavelength resolution: 2nm, measurement interval: 10nm, photometric range: 0%-200%, spectral analyzer: SP2000. Machine dimensions X/Y/Z: approx. 320mm/340mm/420mm, weight: approx. 17kg. Documentation available. An on-site inspection is possible. Ncsdpfx Aoxg Riyekqor

Year of construction: 2023, condition: like new (used), functionality: fully functional, Our compact extruder model EX20-25d Manufacturer: PMH GmbH Screw diameter [mm] 20 Screw length [L/D] 25 Screw speed [min-1] 10-192 Screw nitrided Torque 55Nm Ncodpoq R Tkwofx Akqor Drive Three-phase drive with frequency converter Drive power [kW] 1.1kW Barrel material: nitrided Electrical connection values 3 / N / PE Supply voltage [V] 400V at 50 Hz Control voltage [V] 24V Ceramic heating tapes [W] 1200W Number of heating tapes 3 Max. Output approx. 5kg/h Max. Processing temperature [°C] 300
