Band Saw - Vertical

STARTRITE V 900 H

Condition: good (used), Year of construction: 1993, machine/vehicle number: 28794, Offer 24419 Technical data: - Roller diameter 520 mm - projection 510 mm - max. passage height 420 mm - Table size 750 x 800 mm Lhodpfxjuk D I Ro Alzjl - Table swivels left + right 15 / 30 ° - Table height from floor 1020 mm - Saw blade length 4120 - 4200 mm - saw blade width 20 - 25 mm - infinitely variable cutting speed - level 1 18 - 160 m/min - Stage 2 240 - 2280 m/min - Pneumatic connection 6 bar - Drive 400 V / 5.5 kW - Weight approx. 1100 kg - Space requirement approx. W 1200 x H 2200 x D 900 mm - with: - table feed - Saw blade welding unit in the machine stand - Grinding stone - Shears + air pump - lighting

Condition: ready for operation (used), Year of construction: 2014, operating hours: 13,000 h, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, total height: 2,700 mm, total length: 3,800 mm, total width: 2,350 mm, table width: 500 mm, table length: 750 mm, overall weight: 9,500 kg, spindle speed (max.): 10,000 rpm, number of slots in tool magazine: 22, Equipment: chip conveyor, documentation/manual, For sale: AXA DBZ milling machine - 2014 Heidenhain iTNC 530 HSC control 2 machining areas of 750x500 5-axis rotary table on one table (continuous) 22-tool magazine, SK40 Optical scales on all axes Mist extractor Chip conveyor High-pressure pump External coolant filtration unit Lhodpfey D Enhjx Alzsl Machine in good working order, under power = can be tested 3-month warranty Installation and commissioning at the customer's site possible Suitable for pendulum machining (machining on one table, loading on the other).

Condition: used, roll diameter / mm throat / mm workpiece height / mm With saw blade welder Mod: BSO Tape width: 16mm Volts: 360 Ljdeikggdepfx Alzjhl Hz: 50-60 Amp: 5.2 . 91622F Saw blade length max.: 4250mm Saw blade length min.: 4150mm Table dimension: 600x600mm Max working length: 1120mm

Condition: used, Universal Tool Milling Machine MAHO Type MH 800 P with digital readout and HEIDENHAIN TNC 121 contouring control . 80983 Year of manufacture: 1982 Machine overhauled by MMD in 2008, subsequently used only occasionally in the workshop of an electronics company. Travel X: 700 mm, Y: 450 mm, Z: 500 mm Table size: 1050 x 627 mm Spindle taper: ISO 40 Spindle speed: 40–2000 rpm, 18 steps Feed X, Z-axis: 10–500 mm/min, stepless Lhjdpfx Asv Amryolzol Feed Y-axis: 5–250 mm/min, stepless Rapid traverse X, Z-axis: 1.4 m/min Rapid traverse Y-axis: 0.7 m/min Quill vertical travel: 100 mm Quill feed, vertical: 0.02 / 0.03 / 0.05 / 0.08 / 0.12 / 0.2 mm/rev Quill horizontal travel: 100 mm Spindle drive: 5.5 kW Power supply: 380 Volt, 50 Hz, 10 kW - NC contouring control HEIDENHAIN TNC 121 - Vertical milling head with automatic quill feed 0.02–0.2 mm/rev (6 steps) - Hydro-mechanical tool clamping - Coolant system integrated in the machine base - Universal rotary table, 360° rotatable, tilts and swivels 30°, 225 mm cross adjustment - Rotary table with direct indexing 72 x 5° and indirect indexing via index plate 1:120 = 1 rev = 3° - Swiveling control panel - Central lubrication - Operating manual - Machine mounted on steel plate L x W x H 1400 x 1000 x 50 mm = 550 kg Space requirements L x W x H 2650 x 2000 x 2450 mm Weight: 3700 kg + 550 kg steel plate Total weight: 4250 kg (actual) Very good condition

Condition: used, Year of construction: 1972, table-size 670 x 670 mm throat 1030 mm workpiece height max. 300 mm saw band length min. 4700 mm saw band length max. 4800 mm sawing motor 2,2 kW total power requirement 3,2 kW weight of the machine ca. 1,0 t Lhodotqqrkjpfx Alzsl dimensions of machine L x W x H 2,31 x 1,05 x 2,03 m Accessories: saw band welding and grinding attachment - table swivelling left / right - hydr. feed in table

Condition: used, Vertical band saw JAESPA, type MSU 4 Manufacturer's No. 724749, year of manufacture approx. 1980 Roller diameter 420 mm Overhang 400 mm Table size 610 x 610 mm Cutting height 260 mm Saw band length min. 3200 - max. 3400 mm Saw band speed 10-1500 m/min, infinitely variable Power supply 400 Volt, 50 Hz - Infinitely variable saw band speed via 2 gear stages and infinitely variable via belt drive - Tilting saw table - Saw blade butt welding machine IDEAL BS0-16 Lsdped Nbk Tofx Alzohl - Saw blade shears - Grinding stone for grinding the weld seam Space requirement L x W x H 1000 x 850 x 1850 mm Weight 400 kg Good condition

Condition: used, vertical bandsaw, manufacturer PEHEKA, type SU 6.33 Overhang: 615 mm Max. cutting height: 250 mm Cutting speed: min. 12 meters per minute, max. 3000 meters per minute, steplessly adjustable Includes bandsaw welding device, manufacturer IDEAL Saw blade length: 4700 - 4800 mm Saw blade width: 8 - 25 mm Lhjdpfx Aedawl Helzjl 380 volts Space requirement: L 1400 mm, W 1100 mm x H 2280 mm

Condition: new, roll diameter 520 mm throat 520 mm workpiece height 310 mm cutting speed 25 - 500 m/min table surface area 600 x 500 mm band length 3.880 x 3-16 mm mm Table tiltable up to 15° Grad work height max. 1000 mm total power requirement 1,5 kW weight of the machine ca. 500 kg. dimensions of the machine ca. 1,3 x 0,76 x 2,14 m Furnishing: - Solid gray cast iron table - Safe working is guaranteed by the large contact surface - Standard with band welding device, annealing device - Scissors and sharpening stone - As standard with continuously adjustable cutting speed - Machine body made of robust steel construction for smooth running - Precision blade guide for optimal cutting results - Ideal for sawing complicated contours and shapes - Work table can be swiveled by 15 ° in all 4 directions - Blow-out device with compressor included in delivery Lsdpfx Ajxaazxolzjhl - For radius sawing saw bands from 3 mm wide available scope of delivery: - saw band - Tape welding device with annealing device - halogen light - Scissors - grindstone - Chip brush - blow-out device - LED digital display - Longitudinal table groove

Condition: used, Technical details: dimensions of saw-band: 5750 mm throat: 605 mm workpiece height: 460 mm max. table load: 250 kg table - inclinable: 15 -30 Grad band speed: 27 - 2200 m/min table height: 1125 mm Table dimensions: 740 x 785 mm motor capacity: 5,5 kW Lhjdpfey Rm T Esx Alzel machine weight approx.: 1750 kg dimension machine approx.LxWxH: 1,82 x 0,97 x 2,55 m Machine is sold without electrical control cabinet! This machine was integrated into a production system and operated as part of a larger manufacturing process. The Mössner Rekord SSF 630 is a heavy-duty vertical industrial band saw designed for metal and special materials. It belongs to the renowned REKORD series by Mössner (Germany) and is considered an extremely robust and precise machine for workshop and industrial applications. The SSF 630 is suitable for sawing: ·Steel ·Stainless steel ·Aluminum ·Tool steel ·Plastics · Special materials *

Condition: used, Year of construction: 2000, functionality: fully functional, power: 8 kW (10.88 HP), input voltage: 400 V, input frequency: 50 Hz, cutting height (max.): 550 mm, cutting width (max.): 650 mm, total length: 2,250 mm, total width: 3,700 mm, overall weight: 2,400 kg, Equipment: CE marking, documentation/manual, lighting, motor brake, For sale: immediately available, fully operational vertical bandsaw, Friggi 104/FG 700 TS, manufactured in 2000. Work surface: 1200mm x 1500mm Table load capacity: 1000kg Lhodpfezvhr Dox Alzsl Vertical cutting capacity: 550mm Horizontal cutting capacity: 650mm The machine is available for immediate delivery! Technical specifications can be found in the photo!
