Press brake

TRUMPF

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, pressing force: 173 t, stroke length: 500 mm, overall weight: 16,000 kg, working length: 4,250 mm, Equipment: CE marking, The machine can be inspected under power until 04.05.2026! TRUMPF TruBend 5170 including BendMaster! TECHNICAL DETAILS Stroke: 500 mm Pressing force: 1,700 kN Working length: 4,250 mm Tool clamping: Hydraulic, top and bottom Number of axes: 6 Load capacity: 60 kg MACHINE DETAILS Voltage: 3 x 400 V Rated current: 41.0 A Frequency: 50 Hz Connected load: 28.0 kVA Control voltage: 24 V DC Overrun time: max. 90 ms Overrun distance at 220 mm/s: max. 10 mm Overrun distance at 160 mm/s: max. 8.5 mm Operating pressure: max. 300 bar Weight: 16,000 kg EQUIPMENT CE marking Documentation/Manual Backgauge with sensors CNC crowning CNC tool displacement BendMaster (robot, 8 m travel) Vacuum suction cups for sheets (up to 40 kg) CNC regripping station Double sheet detection Safety system BendGuard Lasersafe Cjdpfx Aoy Hqc Nenwerb

Condition: used, Year of construction: 2011, Press capacity approx.: 360 kN Bending length approx.: 1020 mm Distance between side frames: 932 mm Effective open height: 295 mm Throat depth: 150 mm Working speed: 25 mm / sec feeding speed: 220 mm / sec Control: TASC 6000 Working hours machine: 41422 h working time jacking beam: 4713 h Length: 1805 mm Width: 1330 mm Height: 2380 mm Weight of machine approx.: 2600 mm Standard configuration Machine - Stable machine frame - Optimized in terms of deformation - Highly-dynamic electro-mechanical direct drive (torque motor) - Inductive linear measurement system with temperature compensation - Switch cabinet air-conditioning- Ergonomic Machine designBack Gauge System - Highly-dynamic safety backgauge system - Gauge fingerControl - Integrated Machine controller TASC 6000 - Numerical workshop programming - Windows XPe, Pentium M with 1.1 GHz clock frequency - 1 GB RAM memory - 15 " Touch screen - Network capability - TeleserviceSafety - Safety doors, can be swung sideways - Rear cover - 2-button footswitch, for seated or standing operationOptions for ergonomy - Comfort supporting table (front)- Comfort foot rest - LED work area lighting, front - Operating unit, swivel-mounted - 1 shelf bracket and 2 document repositoriesOptions for productivity - BendGuard (with block laser) - Graphic workshop programming - Automatic tool clamps Csdpfxjyrf Dkj Anwsrb Extended machine accessories Extended Machine Accessoires Backgauge System - Backgauge system 6-axes Automation

Condition: defective spare-parts repository (used), Year of construction: 2011, functionality: not functional, laser power: 6,000 W, laser source model: TruFlow 6000, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Laser power: 6,000 W Laser source: TruFlow 6000 MACHINE DETAILS Connected load: 114 kVA Mains connection: 400 V Control voltage: 24 V Fuse protection: 200 A Compressed air connection: 6 – 14 bar Package dimensions Cabinet: 2600 x 800 x 1200 mm Crsdpfoy Hqahjx Anwsb Laser head: 1200 x 1200 x 1200 mm Laser: 3000 x 1600 x 2800 mm 800 x 800 x 2000 mm 1400 x 1000 x 2000 mm 2 x 1200 x 800 x 2200 mm

Condition: ready for operation (used), TRUMPF Laser 17x E11V 060050840, used, in good condition, 100% fully functional, scope of delivery as per photos Cjdpfx Aney Ntb Howjrb

Condition: new, Year of construction: 2023, arm reach: 1,400 mm, load capacity: 6 kg, New welding robot TIG OKIO AB6-C1400 -Country of origin: China -Type: AB6-C1400 -Number of axes: 6 -Reach: 1400 mm -Maximum payload: 6 kg -Control cabinet -Remote control -Wire feeder -Welding source: TIG WSM400R Cedpfeqnt N Djx Anworb -Cooler

Condition: ready for operation (used), Trumpf 12-11-59-00/02 Radiation Protection B SN: , used, in good condition, 100% fully functional, scope of delivery as per photos. Crsdpfx Aney Ntbyewsb

Condition: excellent (used), functionality: fully functional, Year of construction: 2023, Operating hours: approx. 3,000 h Cedpfx Ajy Nl U Sonwerb

Condition: good (used), x-way 410 mm y-way 310 mm z-way 400 mm taper of the main spindle SK 40 table clamping surface 700 x 280 mm speed 45 - 2000 rpm Crsdpfoi Elydex Anweb quill stroke 63 mm total power requirement 2,2 kW Machine weight approx. 1300 kg space requirement approx. 2,1 x 2,1 x 1,7 m Voltage 400 V 3-axis digital display Heidenhain Fixed angle table Coolant device Vertical milling head swiveling

Condition: excellent (used), functionality: fully functional, Year of construction: 2013, Operating hours: 49,000 h Laser on: 37,000 h active matrices Crsdpfey Nl Ewex Anwob

Condition: reconditioned (used), functionality: fully functional, Year of construction: 2018, operating hours: 4,691 h, machine/vehicle number: A0261G0093, controller model: Siemens Sinumerik 840D SL, laser type: fiber laser, laser power: 8,000 W, sheet thickness (max.): 32 mm, travel distance X-axis: 6,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 115 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area X-axis: 6,000 mm Working area Y-axis: 2,500 mm Working area Z-axis: 115 mm Maximum sheet thickness, mild steel: 32 mm Maximum sheet thickness, stainless steel: 30 mm Maximum sheet thickness, aluminum: 25 mm Maximum sheet thickness, copper: 10 mm Maximum sheet thickness, brass: 10 mm Maximum workpiece weight, pallet changer: 3,300 kg Maximum workpiece weight, both pallets: 5,700 kg Max. speed: 140 m/min MACHINE DETAILS Control unit: Siemens Sinumerik 840D SL Operating system: Windows 10 IoT Laser power: 8,000 W Laser type: TruDisk 8001 Average power consumption: 17 kW Compressed air: 5 m³/h Dimensions (L x W x H): 16,770 x 7,158 x 2,130 mm Operating hours NC on-hours: 17,501 h Laser on-hours: 4,691 h EQUIPMENT Incline conveyor Fully enclosed machine frame Viewing window Automatic pallet changer Left-side installation Cooling unit Dust cover for control cabinet Working area lighting Process monitoring cameras Multi-sheet processing Positioning laser DetectLine BrightLine Smart Collision Prevention Performance Package Melt Cutting Crodpfoy Iz N Aex Anwob Copper cutting package Brass cutting package Highspeed cutting package Drop&Cut

Condition: used, Year of construction: 2008, Crowning CNC controlled Bending length 4250 mm 5-axis backgauge Work area lighting Parking position 900 mm Hydraulic lower tool clamping Crjdpfsyvr Ewjx Anwjb Hydraulic upper tool clamping CNC lower tool displacement Installation height 615 mm ACB preparation

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2001, operating hours: 13,817 h, controller model: Siemens Sinumerik 840 D, laser power: 3,200 W, punching force: 22 t, travel distance X-axis: 2,585 mm, travel distance Y-axis: 1,280 mm, No reserve price – guaranteed sale to the highest bidder! Codpfx Asy Iz H Ienwjrb TECHNICAL DETAILS Laser power: 3,200 W Laser model: High-frequency excited CO2 laser TLF 3200W Press force: 22 t X-axis travel: 2,585 mm Y-axis travel: 1,280 mm MACHINE DETAILS Control system: Siemens Sinumerik 840 D Laser beam hours: 13,817 h Laser on hours: 71,637 h Operating hours: 80,188 h EQUIPMENT - Sturdy C-frame - Linear guide with integrated magazine - Maintenance-free three-phase servo motors - Programmable hold-down for repositioning - Sensor-monitored part chute 500x500 mm for punching and laser station - Ejector cylinder at the laser chute - Programmable cutting gas pressure control - Laser cutting head: 5'' lens, quick-change system, height control - Multi-beam light barriers - Quick shut-off hydraulics - Extraction system - Compact dust extractor - Protective device against stray radiation at the cutting head - Brush table - Sign function / rapid beading - Softpunch - Small parts blow-out device - Repositioning cylinder - Warp detection - Chip conveyor

Condition: used, #200103 Trumpf EVO22W10 (without identification groove) 86.00° R1.00 / H=100.00 / 500 kN/m Segment lengths: 2x 25 mm 2x 30 mm 1x 35 mm 2x 40 mm 1x 45 mm 2x 50 mm 7x 100 mm 2x 200 mm 2x 300 mm 7x 500 mm ----- #200104 Trumpf EVO22W10 (identification groove on bottom) 86.00° R1.00 / H=100.00 / 500 kN/m Segment lengths: 2x 40 mm 2x 45 mm 2x 50 mm 2x 200 mm 1x 300 mm 3x 500 mm ----- Crsdpfx Asyx Hxwjnwsb #200105 Trumpf EVO22W10 (identification groove centered) 86.00° R1.00 / H=100.00 / 500 kN/m Segment lengths: 3x 25 mm 2x 30 mm 2x 35 mm 2x 40 mm 2x 45 mm 1x 50 mm 4x 100 mm 2x 200 mm 2x 300 mm 8x 500 mm ----- #200107 Trumpf EVO26W24 86.00° R2.50 / H=100.00 / 700 kN/m Segment lengths: 1x 30 mm 1x 35 mm 1x 40 mm 1x 45 mm 1x 50 mm 3x 100 mm 1x 200 mm 1x 300 mm 4x 500 mm ----- #200108 Trumpf / Schmid EVO24W16 86.00° R1.60 / H=100.00 / 700 kN/m Segment lengths: 1x 25 mm 1x 30 mm 1x 40 mm 2x 45 mm 2x 50 mm 3x 100 mm 1x 200 mm 1x 300 mm 5x 500 mm ----- #200109 Trumpf EVO20W6 86.00° R0.60 / H=100.00 / 400 kN/m Segment lengths: 3x 100 mm 2x 200 mm (1x damaged) 6x 500 mm ----- #200110 Trumpf EVO22/S-W10 86.00° R1.00 / H=100.00 / 380 kN/m Segment lengths: 1x 40 mm 2x 100 mm 1x 200 mm 1x 300 mm 4x 500 mm ----- #200116 Trumpf / Schmid EVO28W40 86.00° R5.00 / H=100.00 / 1200 kN/m Segment lengths: 2x 25 mm 1x 30 mm 1x 35 mm 1x 40 mm 1x 45 mm 1x 50 mm 1x 200 mm 1x 300 mm 4x 500 mm

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel Credpfovt D D Usx Anwob - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, pressing force: 85 t, stroke length: 215 mm, throat depth: 410 mm, clearance between the columns: 1,750 mm, working length: 2,050 mm, TECHNICAL DETAILS Press force: 85 t Bending length: 2,050 mm Frame gap: 1,750 mm Stroke: 215 mm Throat depth: 410 mm Controlled axes: y1, y2, x, R MACHINE DETAILS Crjdpfoy Ix Ipjx Anwob Control manufacturer: DELEM Total power: 13 kW Dimensions & Weight Dimensions (L x W x H): 3,190 x 2,100 x 2,375 mm Machine weight: 8,750 kg EQUIPMENT Two-hand foot operation 2 support arms Crowning Die shifting CNC control Side safety doors 2 manual backgauge fingers
