Roller Conveyer Venjakob, Length 1100mm

Venjakob

Year of construction: 2008, condition: used, machine/vehicle number: A0807010-1200, Technical specifications: - Manufacturer: Venjakob - Model: H - Working width: 1,300 mm - Length: 21,500 mm - Total width: 1,510 mm - Feed speed adjustable via frequency inverter - Frequency inverter not included in delivery - Height: 900 ± 50 mm - Motor power: 0.81 kW - Motor ATEX-compliant Lodpfx Absyh Hwzs Tshc - Belt control, pneumatic - Max. load: 70 kg/m - Colour: RAL 7035 light grey - Voltage fluctuations: ±5% - Location: in stock

Condition: good (used), Size max 750 x 1.050 mm Stroke height 940 mm Lodpfx Abed Hp H Is Tjhc Lifting capacity max 600 kg

Condition: used, Painting system consisting of: Pos.1 Venjakob belt conveyor - Manufacturer: Venjakob - Working width: 1,300 mm - Length: 3,000 mm - Feed adjustable via handwheel ~ 2.5 – 7.5 m/min - Volt, Hz: 400 / 50 - Colour RAL 7035 Pos.2 Cefla dust extraction machine - Manufacturer: Sorbini - Type: VS/32-E - Year of manufacture: 1998 - Working width: 1,300 mm - Working height: 900 mm + - 20 mm - Operating side: right - Roller conveyor - Air blowing channel, above 2 pcs. - Air blowing channel, below 1 pc. - Dust remover brush - With ionisation bar from above - With ionisation bar from below - With own drive - With own control - Length ~ 910 mm - Width ~ 2,600 mm - Weight 1,260 kg - Extraction nozzle D 180 + 120 mm - Total connection 7.6 kW - Volt, Hz 400/ 50 Pos.3 Venjakob VEN SRAY Perfect automatic spraying machine - Manufacturer Venjakob - Type. VEN SPRAY PERFECT - Year of construction 2013 - Working width 1,300 mm - Working height 940 + - 20 mm - Operating side left - IR preheating, number of radiators 2 pcs. - Duo-design spray gun drive - Dry suction - Diameter of suction nozzle 600 mm - Exhaust air capacity 10,000 m³/h - Belt transport system - feed speed infinitely variable ~ 4-10 m/min - conveyor belt cleaning system - paint recovery via V-belt system - gun control, EPS-CNC CNC 7000 - colour management system for number of pumps 3+1 pcs. - number of installed airless spray guns 4 pcs. - Quick-change system for spray guns - Remote maintenance system - Dust cover on the outlet side of the machine - Exhaust air recirculation system - Exhaust air control of the suction ventilator - Machine suitable for water-based paints - Machine suitable for solvent-based paints - Length 5,509 mm - Width 4,500 mm + 2,400 mm - Height 3,380 mm + 510 mm - Total connection ~ 20 - 26 kW - Volt, Hz 400/50 - Colour RAL 7035 - Kremlin AVX AirMix spray guns - Small parts container - gun support arm system for quick removal of 4 AirMix spray guns from the spray booth, including quick couplings for pneumatics and material hoses. Pos.4 Venjakob belt conveyor - manufactured by Venjakob - working width 1,300 mm - length 2,000 mm - feed adjustable via handwheel ~ 2.5 – 7.5 m/min - Volt, Hz 400 / 50 - Colour RAL 7035 Pos.5 Cefla high-level dryer Ledov I Akvspfx Ab Tohc - Manufacturer Cefla - Type VN 2000/5500/190.5/30 - Year of construction 2003 - Working width 1,300 mm - Number of pallets 30 pcs. - Pallet length 5,600 mm - Usable pallet length 5,300 mm - Load capacity per pallet 300 kg - Max. part height ~ 110 mm - Clearance between pallets 120 mm - Dimension: centre of pallet to centre of pallet 3,658 mm - Max. part length ~ 5,200 mm - Number of controllable temperature zones 2 pcs. - Supply air flow rate 6,000 m³/h - Exhaust air flow rate 6,000 m³/h - Heat output max. 175 kW - Max. drying temperature ~ 55 - 60 degrees - With heat exchanger, hot water - Without hot water control valves - U-shaped flow direction - Inlet side on the right - Feed speed via frequency converter control ~ 2-20 m/min - Suitable for water-based paints - Suitable for solvent-based paints - Length 7,820 mm mm - Width 6,130 mm - Height 3,905 mm - Total connection ~ 23 kW - Volt, Hz 400 / 50 - Voltage fluctuations max. +/- 5 % - Without control valves and water pumps Pos.6 Cefla belt conveyor - Manufacturer Cefla - working width 1.300 mm - length 2.000 mm - feed adjustable via handwheel ~ 2.5 – 7.5 m/min - volts, Hz 400 / 50 - colour RAL 7035

Condition: used, Year of construction: 2012, - Manufacturer Venjakob - Year of construction 2012 - Working width 1.300mm - Type. Flash off dryer, VEN DRY Flash Off - Part height max. approx. 120mm Lsdpeu Edhuofx Ab Tehc - Zone1, paint calming zone with cover hood without air 3,000+300mm - Zone2, flash off zone 10,000mm - Laminar flow dryer in the opposite direction to the parts - Supply air 4,000m³/h - Exhaust air 4.000m³/h - Air volumes adjustable via flaps - Heat output approx. 65 kW - Air speed 2-5m/s - Max. Drying temperature 30°C - Heat exchanger, heating water PWW max. 90/70 degrees - Belt conveyor, length 13,800 mm - Feed speed approx. 2-10m/min, Frequency converter required on site. - Volt, Hz 400 / 50 - Motor power 2.5+1.5+0.75KW - Without switch cabinet - Location, at the Blomberg warehouse

Condition: good (used), Code: 0749 Brand: TAGLIABUE - COSTA LEVIGATRICI Model: TT 3 1300 Automatic sanding machine for worktops, furniture, panels, tables Technical data: Working width mm 1300 Max working thickness mm 130 Min working thickness mm 1 Composition: 1° Transversal belt - Motor Hp 15 - Electronic speed variator with display 2° Transversal belt - Motor Hp 15 - Electronic speed variator with display Transversal sanding belt size mm 1350 x 150 Chevron belt size mm 5510 x 140 Belt blowers Belt feed speed mt/min 5/25 Fixed table and mobile head for on-line set-up Panel cleaning rotary blowers Vacuum table Belt cleaning brush Ljdpfxoh T Dzqe Ab Tohc Infeed roller conveyor Installed power Kw 32 Compressed air 7 Atm Suction inlets: n° 2 diameter mm 200 - n° 2 diameter mm 150 - n° 2 diameter mm 100 Overall dimensions mmm 4400 x 2500 x 1600 h Weight kg 5000

Condition: used, Year of construction: 2001, machine/vehicle number: A 01 02 004/ 0300, - Manufacturer: Venjakob - With dust cover including folding doors - Ventilation via fans - Fully covered under the rollers - Year of manufacture 2001 - Working width 1,300mm - Working height: 900 +- 20mm - Roller diameter: 80mm - Roller pitch: 140mm Lhedpfsumvmqox Ab Toc - Feed speed: ~ 2-8m/min. - Location: in the warehouse - without control cabinet

Condition: used, Year of construction: 2002, machine/vehicle number: A0207001, -with belt cleaning at the machine outlet under a folding table with belt conveyor. In 2021, the PLC control, the touch screen control, and the frequency converter for the spraying-gun drive were replaced. - Manufacturer: Venjakob - Type: HGS-Duo/C - Retrofit 2026 (year of manufacture 2002) - Working width 1,300 mm - Operating side right - Price for refurbished machine - Current condition, in the refurbishment phase - Gun drive in duo design - Dry extraction - Exhaust air capacity 10,000 m³/h - Extraction nozzle diameter 500 mm - Belt conveyor system - Feed speed approx. 5 and 14 m/min - With belt cleaning system - With paint recovery via V-belt system - Gun control, touch screen - Installed color circles 1 pc. - 4 Airelss sprayers, Krautzberger KAA1300 - 1 HD airless pump - Supply air filter ceiling - Suitable for water-based paints - Suitable for solvent-based paints - Control cabinet integrated into the machine. - Total connection ~ 19kW - Length: 6,485mm - Width: 3,690 mm - Height: 2,497 mm - Volts, Hz 400 / 50 - Color light gray 7035 + black - Location, in stock - Voltage fluctuations max. +/- 5% The pictures are examples of an unrefurbished spray machine of the same type. Lhedpsx Ihvvsfx Ab Toc _____ Optionally, we can also provide you with a quotation for the assembly and start-up of the system, as well as training for your employees. We also offer regular maintenance and servicing of the machine on request. For further information, get in touch with us!

Condition: good (used), Manufacturer: MBT Ljdpfxjhzr U Ij Ab Tohc Tip: MV-250 S Motor: 5,5 kW hopper size: 780 x 600 mm Housing size: 3500 x 1000 x 2200 mm

Condition: used, Year of construction: 2004, machine/vehicle number: P 04-09-002, neu U05 10 001, Spraying machine Venjakob VEN SPRAY-K All pictures only for example - Producer Venjakob - Year of construction 2004 - Current condition: not refurbished - Offer price for refurbished condition - Working width 800 mm (1000) mm - Operating side, right - Duo gun drive system - Dry filter system 4.000 m³/Std. - Diameter exhaust air pipe 400 mm - Transport belttransport System - Feed speed adjustable 3 - 8 m/min - Lacquer reclaiming system with v-belt - Gun control system LS 1 - Number of installed lacquer circles 1 Stk. - Airless spraying system 4 Stk. Krautzberger KAA 1300 - Number of lacquer pumps 1 Stk. - Producer lacquer pump Wagner 35-70 - Suitably for solvent based lacquer - Suitably for water based lacquer - Total connection power 7 kW, Stromaufnahme 17 A , Absicherung 35 A - Location, on stock - Voltage fluctuation max. +/- 5 % _____ Optionally, we can also provide you with a quotation for the assembly and start-up of the system, as well as training for your employees. We also offer regular maintenance and servicing of the machine on request. For further information, get in touch with us! Lhjdpfsumvr Tsx Ab Toc

Condition: used, Year of construction: 2009, Dust removal brush with spiral brush, suitable for installation on an existing transport system. - Manufacturer: Venjakob - Height adjustable via a hand wheel - Working width: 1,300 mm - Total width: 2,450 mm of the brush unit - In stock in Blomberg - Voltage/Hz: 400/50 - Extraction system required on site - Extraction nozzles, 2 pcs - Diameter: 120 mm each - Volume flow: approx. 2,000 m²/h Ljdsuulpqopfx Ab Tehc - Machine without control cabinet and frequency converter (Optionally available) - Without roller conveyor, only the brush machine

Condition: excellent (used), Year of construction: 2001, Complete Parquet painting shop Manufacturer - SORBINI/ VIET Year - 2001 Capacity - 800 m2/shift Time of one cycle - 8 min. Lsdpfxsrdgrvj Ab Tehc Lenght of the line - 42 m

Condition: used, Year of construction: 2013, 3D-Venjakob Perfect Air Jet painting line: - Manufacturer: Venjakob - Year of construction: 2013 - Working width: 1.300mm - Max. part length 6.500mm - In U-shape with angle transfer Consisting of: 1. loading belt, length 3,050mm 2. free space für Sanding machine (only optional, not included in the price) 3. spraying machine VEN SPRAY PERFECT, length 5.510mm 4. flash-off dryer OIR, length 6,000mm 5. nozzle dryer VEN DRY AIR JET, length 4,160mm 6. angle transfer 180 degrees, with nozzle dryer 7. nozzle dryer VEN DRY AIR JET, length 5,160mm 4pcs. IR tubes 8. nozzle dryer VEN DRY AIR JET, length 5,160mm 4pcs. IR tubes 9. nozzle dryer VEN DRY AIR JET, length 5.160mm 4 pcs, IR tubes 10. 3D UV dryer, VEN DRY UV, GA + HG 11. removal area, belt of the UV dryer Further information: On request Lhsdpfxju Afu Rs Ab Tjc

Condition: used, Year of construction: 2005, machine/vehicle number: A0407004, - Producer Venjakob - Type. VEN SPRAY DUO/C CNC 6000 - year of construction 2005 - Working width 1300 mm - Operating side right - Price for overhauled machine - Actual condition, machine not overhauled - Pistol drive in duo version - Dry extraction system - Extraction nozzle diameter 500 mm - Exhaust air capacity 10,000 m³/h - Belt conveyor system - Infinitely variable feed speed ~ 2 - 7.5 m/min - With belt cleaning system - With paint recovery via V-belt system - Gun control, touch screen CNC- Installed colour circles 2 pcs. - Quick-change system for spray guns - Supply air filter ceiling - Suitable for water-based paints - Suitable for solvent-based paints - Control cabinet integrated in machine - Total connection ~ 29 - Volt, Hz 400 / 50 - Colour RAL 7035- Location, in stock - Voltage fluctuations max. +/- 5 % Picture shows an example of a reconditioned automatic machine _____ Optionally, we can also provide you with a quotation for the assembly and start-up of the system, as well as training for your employees. Ledsumvu Uopfx Ab Tshc We also offer regular maintenance and servicing of the machine on request. For further information, get in contact with us!

Year of construction: 2013, condition: used, Kuka industrial robot with 6 articulated axes with point-to-point positioning. Independent control panel Lhsdpfsr Am Sqjx Ab Toc Panel alignment table Barcode reader on the robot arm Panel introduction system via: * 1 motorized roller conveyor for panel stack preloading * 1 motorized translating roller conveyor * 1 motorized roller conveyor for panel stack unloading Technical features: * Type: KR210-2 * Number of axles: 6 * Admissible nominal load: 210 Kg * Machine weight: 1267 kg * Sound level: 75dB * Installed power: 25.8 KW * Panel dimensions - Min\max length: 300\3000 mm * Panel dimensions - Min\max width: 180\1500 mm * Panel dimensions - Min\max thickness: 8\60 mm * Max panel weight: 90 kg

Condition: used, Year of construction: 2007, with light barriers in the inlet area, the dryer only switches on when parts are detected by the light barrier, otherwise Lhedpfx Abju S N R Eo Tec the dryer is in energy-savingstandby mode with almost closed mirror halves. Operation via a Siemens panel. - Manufacturer: Venjakob - Type: VEN DRY UV 3D - Year of manufacture: 2007 - Operating side: right - Working width: 1.300mm - Max. Part height: approx. 100mm - Number of tubes: 2 pieces - Suitable for mercury and gallium tubes - 3D for edge drying - Tube power max. 120W/cm - Tube power infinitely adjustable 50-120Watt/cm - With standby mode- With belt conveyor - Feed rate: ~ 2.5 - 7.5m/min. - Length: 3,000mm - Bretie: 2.750mm - Total connection ~45KW - Location: in stock - Volt/HZ: 400/50
