CNC lathe

CMZ TX 52 Y3

Condition: like new (used), Year of construction: 2011, functionality: fully functional, spindle motor power: 15,000 W, spindle speed (min.): 5,000 rpm, travel distance X-axis: 157 mm, travel distance Y-axis: 35 mm, travel distance Z-axis: 464 mm, rotational speed (max.): 6,000 rpm, total height: 1,885 mm, total length: 3,675 mm, total width: 2,258 mm, overall weight: 9,000 kg, CNC controller: Fanuc 18i-TB Capacity X-axis travel mm: 157,5 Y-axis travel mm: 35 Z-axis travel mm: 464,8 B-axis travel mm: 600 C-axis: 360º (0,001º) Turning length mm: 399 Max. turning diameter mm: ø: 190 Distance between spindle centers mm: 750 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Number of upper turrets: 1 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Kedoxiwnnjpfx Agzefa Milling function: Both Turrets Number of lower turrets: 1 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 15 / 11 Counter spindle Speed spindle rpm: 4.500 Drive power spindle kW: 11 / 7.5 Equipment Part catcher Workarea light Bar Loader ILS - RBK Machine running time: Nominal Kva: 67,2 Basic machine dimensions / weight Length mm: 3.675 Width mm: 2.258 Height mm: 1.885 Weight kg: 9.000

Condition: used, Year of construction: 2023, In the market for a Top of the Range Miyano? Then have a look at this one! 18 months old and just over 1000 hours on the clock…it is as new! Still on site where it can be seen under power. The following is from Miyano’s Spec sheet: The Miyano ABX-64SYY – is a Top of the range, twin spindle, twin turrets with Y-axis on each turret. The ability to machine simultaneously at the left and right spindles using the upper and lower turrets, both featuring a Y-axis function, means that complete front and back machining of products with complex shapes can be accomplished simply and in a short time. High rigidity and high torque with 40 Nm driven tools. The use of rigid 40 Nm driven tool drives capable of heavy cutting ensures stable milling. Two turrets with a total of 24 tool positions, all driven, handle complex machining just like a machining centre. This machine also features the optional parts conveyor, Hainbuch collet chucks on both spindles, high pressure coolant, probing and a steady rest that’s mounted on the lower turret. Machining Capacity and Chuck System Maximum Machining Diameter of Bar Work SP1/SP2 ø64/51mm Collet Chuck SP1/SP2 Stationary Power Chuck SP1/SP2 6″/6″ hydraulic drive Standard Turning Length 125mm Spindle Spindle Nose SP1/SP2 A2-8/A2-6 Spindle motor(30min./Cont.) SP1 15/11kW SP2 7.5/5.5kW Spindle Speed Range SP1 50 – 5,000min-1 40 – 4,000min-1 SP2 50 – 5,000min-1 Turrets(Upper L/R Turrets & Lower Turret) Type of Turret 2 x 12 Station Turret Shank Height of Square Turning Tool □20mm Diameter of Drill Shank ø40mm ø20mm ø25mm Slide Stroke X1, X2 axis 190mm Z1/Z2 axis 550mm/721mm Y1, Y2 axis ±40mm Zs axis 756mm Rapid Traverse Rate X1, X2 axis 16m/min Z1/Z2 axis 30/20m/min Y1, Y2 axis 12m/min Zs axis 30m/min Driven Tools Maximum Number of Revolving Tools 24 Rotation speed of Driven Tools 60 – 6,000min-1 Driven Tool Motor AC Servo 4.5kW Machine Dimensions Machine Height 2,222mm Floor Space 3,290×2,204mm Machine Weight 10,900kg Name of the machine: Miyano ABX-64SYY Kfsdsw I D Dujpfx Agzja

Condition: new, 2021 Durma 15 kW Fiber Laser Make: DURMA Type: HD-F(L) 3015 Working range X-Y-Z: 3060x1530x160 mm Laser power: 15000 Watt IPG Control: Siemens Sinumerik 840D sheet thickness mild steel: 40 mm Sheet thickness stainless steel: 30 mm Sheet thickness aluminium: 30 mm Sheet size: 3048x1524 mm Loading weight: 200 kg/m² Speeds X-Y axes: 100 m/min. Kedpfx Agogk Nlpjzjfa Speeds X-Y axes simultaneous: 280 m/min. positioning accuracy: +/- 0,05 mm Repeating accuracy: +/- 0,05 mm Installation area L/W/H: approx. 14500x7500x2420 mm weight: approx. 12000 kg Standard equipment Automatic pallet changer Control Sinumerik 840D Auto-focus cutting head Precitec Procutter F150 focus Automatic sheet position and sheet size measuring system Automatic nozzle cleaning Position laser diode Central lubrication Simple user interface parameter page (power-speed-pressure) External CAD/CAM programming software with autonesting optional Lantek software Work area lighting Warning light Multi-chamber exhaust system Special laser cutting options Remote maintenance CE marking IPG fiber laser source 15000 Watt including cooler Extended equipment possible: Filter, compact dust collector Vanterm Motorized chip conveyor for small parts/waste Laser Service Set Cloud License Lantek Expert Inside Software Lantek software with positioning - laser diode with automatic sheet metal position detection, measurement Camera Inside Linear drive We will be pleased to send you further information on request.

Condition: as good as new (ex-display), Year of construction: 2022, functionality: fully functional, controller manufacturer: Beckhoff, Spindle Speed: 60,000 rpm Spindle power: 0.625 kW Torque: 10 Nm Tool holder: HSK-EZ15 Number of tools: 60 Working area Travel X: 78 mm Travel Y: 56 mm Travel Z: 50 mm B-axis: -110° to +110° C-axis: 400 rpm Chip-to-chip time: 3.5 sec Rapid traverse: X/Y/Z 30/30/30 m/min Workpiece changing device Technology: Zero-point clamping system Workpiece changing time: 10 sec Max. table load: 10 kg Accessories Chip management: Chip trolley Coolant management: Coolant system Workpiece measurement: Renishaw measuring probe – RMP24-micro Tool measurement: tool length measurement / breakage Kjdpfx Agevyp Ewjzefa Other: Automation Feed 5

Condition: excellent (used), Year of construction: 2006, operating hours: 6,650 h, functionality: fully functional, Equipment: documentation/manual, The used HAAS SL 30 THE CNC lathe is a fast, medium-sized, slant-bed numerically controlled lathe equipped with a tailstock, C-axis spindle, and a 12-position powered turret with VDI 40 tooling interface. The configuration also includes a tool presetter, chip conveyor, programmable tailstock body, hydraulic 3-jaw chuck 250mm BB, and fixed toolholders. Main features: Maximum workpiece diameter: 350 mm Kedpfx Aexdvarsgzsfa Maximum workpiece length: 826 mm Maximum bar diameter: 76 mm Spindle speed: 3,400 rpm Spindle power: 30 HP Year of manufacture: 2006, with only 6,650 spindle hours, CE compliant machine.

Condition: new, Year of construction: 2025, Applicable Material: metal Condition: New Laser Type: Fiber Laser Cutting Area: 3000*1500mm Cutting Speed: 0-40000mm/min Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT Cutting Thickness: 0-30mm CNC or Not: Yes Cooling Mode: WATER COOLING Control Software: Bodor Pro Place of Origin: China Kfodpog Ev T Ejfx Agzja Brand Name: Bodor Certification: CCC, CE, GS, ISO, Sgs Laser Source Brand: IPG/MAX Laser Head Brand: bodorgenius Control System Brand: bodorpro Weight (KG): 2200 KG Key Selling Points: Tenon-and-mortise type plate welding structure bed Warranty: 3 years Laser power: 1000W Power supply: 110V/220V/380V 50Hz/60Hz

Year of construction: 2007, condition: ready for operation (used), - USED - 4-AXIS CNC LATHE MAX ROTATING DIAMETER: 550 mm MAX TURNING LENGTH: 513 mm MAX TURNING DIAMETER: 300 mm BAR CAPACITY: 65 mm SPINDLE: 4500 rpm; 15-18,5 kW; ASA A2-6 COUNTER SPINDLE: 6000 rpm; 5,5 kW Kodpfx Agsxburuezjfa X-AXIS TRAVEL: 205 mm Z-AXIS TRAVEL: 580 mm RAPID FEEDS X-Z: 24 - 30 m/min DRIVEN TURRET HEAD: 12 POS; 5000 rpm; 3,7 kW CONTROL UNIT: FANUC 18i-TB WEIGHT: 4240 Kg OVERALL DIMENSIONS: 3315 x 1600 x 1750 mm ACCESSORIES: PARTS CATCHER ; SWARF CONVEYOR ; PIECE CONVEYOR ; TOOL SETTER

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Travel : 310 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 7,5 [kW] - C axis indexing precision : 0,01 [°] COUNTER-SPINDLE Kfjdpfx Ageuha Elezsa - Max. bar diameter : 32 [mm] - Z stroke : 150 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 3,7 [kW] - C axis indexing precision : 0,01 [°] - Number of turrets : 1 UPPER TURRET - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 5.700 [rpm] - Live tools power : 2,8 [kW] GUIDE BUSH HOLDER 1 - Number of positions : 4 - Number of motorized positions : 3 - Live tools speed : 6.000 [rpm] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 8 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.645 x 1.403 [mm] - Machine height : 1.680 [mm] - Machine weight : 3.880 [kg] EQUIPMENT - CNC : Fanuc 16 iTB - 3 colors status lamp - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank - Bar loader : IEMCA BOSS 432/32LL - Electric transformer

Condition: excellent (used), consisting of: 2 pcs. Art. No. 47155: Makro Grip 125 Centering Vise, clamping range 155 mm 1 pc. Art. No. 41350: Extended Stamping Unit Ksdpjxauacefx Agzjfa 1 pc. Art. No. 41010: Center Marking Device for Stamping Unit 16 pcs. Art. No. 45570: Mounting Bolts, diameter 20 mm 1 pc. Art. No. 47520: Double Mounting Body 1 pc. Art. No. 47355: Makro Grip 125 Centering Vise, clamping range 355 mm 1 pair Art. No. 44251: Avanti Base Jaws 4 pcs. Art. No. 44258.76: Top Jaw 77x126mm for Avanti 125 4 sets Art. No. 45570.10: Spacer Mounting Bolts, diameter 20 mm 2 pcs. Art. No. 47255: Makro Grip 125 Centering Vise, clamping range 255 mm 3 pcs. Art. No. 45742: Plate L384xW384xH27 mm, 4-position grid plate 96 (photo attached) 1 set Art. No. 47355-TG27: Twin-Grip Conversion Kit for Makro Grip 125 No. 47355 1 pc. Art. No. 47520: Double Mounting Body 1 pc. Trolley for Stamping Unit

Condition: good (used), Year of construction: 2003, Main spindle: Speed range - main spindle max. 6,000 min/-1 Drive power - main spindle 16 kW Max. torque 155 Nm C-axis 360 ° Tool turret: Number of tool positions 12 pos. Number of driven tool stations 12 pos. Speed range - driven tools max. 5,000 min -1 Drive power - driven Tools 10 kW Tool holder (VDI 30) Tool shaft 20 x 20 mm Travel paths: x-axis 160 mm z-axis 450 mm Feed rates: Rapid traverse X: 60 m/min Rapid traverse Z: 45 m/min Feed force X: 2.5 kN Feed force Z: 4 kN Rapid traverse C: 200 1/min Max. torque C: 155 Nm Total power requirement Machine weight approx. 3.7 t Space requirement approx. 4.5 x 2.5 x 2.5 m Ksdpfx Agev Drigezefa Heidenhain control Hollow clamping cylinder C-axis and tool drive a Chip conveyor Oil and emulsion mist separator with electrostatic filter
