DMG MORI HSC 55 Linear

DMG MORI HSC 55 Linear

Condition: ready for operation (used), Year of construction: 2009, Travel X/Y/Z: 450mm/580mm/400mm, swivel range A/B: -110°/+10°, rotation range C: 360°, table dimensions X/Y: 400mm/400mm, tool positions: 30, tool holder: HSK-E50, spindle speed: 42000rpm, max. workpiece weight: 200kg, feed: 80m/min, max. tool length/diameter: 250mm/80mm. Machine dimensions X/Y/Z: approx. 3250mm/2950mm/2900mm, weight: approx. 9500kg, control: Heidenhain iTNC530. Documentation available. An on-site inspection is possible. The machine is located in China. Fsdsxf Ii Uopfx Afnefu

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, turning length: 1,540 mm, turning diameter: 660 mm, Swing over crosslide: 660 mm Turning length: 1540 mm Spindle bore: 91 mm Spindle speed main/sub: 4000/5000 rpm Tool magazine: 76 positions Taper in milling spindle: Capto C6 Milling spindle speed: 12000 rpm Spindle motors: 26/22 kW Max power supply: 200V/255A Year of manufacture: 2013/9 Length: 5825 mm Width: 2850 mm Height: 2750 mm Weight: 15860 kg Full B-axis Fsdpfx Afox A E U Nonofu Coolant through milling spindle: 70 Bar Knoll 110/700 Part picker & outfeed belt Automatic presetter for lower turret & milling spindle Robot interface (no robot), automatic door & prepared for barfeeder Spindle 2 tailstock function Renishaw OMP60 probe MAPPS-IV CNC 5-axis simultaneous control 5 extra M-codes

Condition: used, Year of construction: 2008, x-travel 800 mm y-travel 700 mm z-travel 600 mm control SIN 840D Powerline spindle turning speed - stepless 1 - 8.000 U/min power capacity at 40 % load 28,00 kW spindle diameter in front bearing 80,00 mm spindle taper HSK-A100 B-axis 187 ° feed X/Y/Z-axis 15.000 mm/min rapid traverse X/Y/Z 50,00 m/min feed force X/Y/Z axis 10.000 N rapid traverse B-axis 11,20 U/min size of pallet 800 x 630 mm table load 0,80 t c-axis 360,000 x 0,001 ° table turning speeds 1 - 500 U/min toolpiece magazine: chain magazine 120 Stück tool diameter 100 mm tool diameter with 2 vacant positions 160 mm tool length - max. 350 mm weight of tools max. 10,00 kg total power requirement 60,00 kW weight of the machine ca. 13,00 t dimensions of the machine ca. 7,40 x 5,30 x H3,50 m With Siemens SIN840D control, tool taper cleaning, tool breakage monitoring, coolant system, 2 pressure levels (40bar / 80bar), chip conveyor, operating mode 4, exhauster. Fedjw Df A Sjpfx Afnsfu

Condition: excellent (used), Year of construction: 2006, operating hours: 32,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, torque: 121 Nm, controller manufacturer: Siemens, table width: 700 mm, table length: 900 mm, table load: 1,400 kg, rotational speed (min.): 20 rpm, rotational speed (max.): 18,000 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 32,000 h, coolant supply: 40 bar, spindle nose: HSK63A, number of slots in tool magazine: 30, tool length: 350 mm, tool diameter: 100 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, DMG MORI DMU 80P duoBlock Year of manufacture: 2006 Operating hours: 62,000 h Spindle hours: 31,000 h Function tested and cleaned Maintenance performed according to manufacturer's specifications Geometry within new machine tolerance Equipment: Fsdjw Ht Ibopfx Afnjfu 5 axes Swivel head (controlled B-axis) Direct linear measurement in X/Y/Z (glass scales) Chip conveyor Extraction system NC rotary table Tool magazine with 30 positions Heidenhain touch probe BLUM laser Handwheel Rotating viewing window ICS 40 bar (internal coolant supply) Chip flushing Operating mode 4

Condition: used, Year of construction: 2014, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm travel -z axis 375 mm c-axis 360 ° control FANUC Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2 Ffodpfxoqvd Iqj Afneu

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, nominal power (apparent): 10 kVA, overall weight: 6,500 kg, spindle speed (max.): 20,000 rpm, Heidenhain TNC530, 4th axis rotary table spindle 20,000 rpm, HSK 63 table 850x530 mm travels 600x450x450 mm 30-tool changer Ffodpfew Dc Irex Afneu weight 6,500 kg

Condition: good (used), Year of construction: 2009, Ref. -No.: 10556 Manufacturer: DMG MORI Type: DMC 60 FD Year of construction: 2009 Type of control: CNC Control: Siemens 840DSL-721 Storage location: Halberstadt Country of origin: Germany X-Travel: 630 mm Y-Travel: 800 mm Z-Travel: 850 mm Max. Workpiece diameter: 600 mm Max. Workpiece Weight: 400 kg Turning Speeds: 12000 RPM Tool changer: 60 Max. Workpiece height: 500 mm Weight Of The Machine Ca.: 10 t Numbers Of Pallets: 2 Ffsdpjxc Tt Tefx Afneu Motor spindle: 24000 RPM Further information: - Internal cooling - Swivel range of the B-axis -5/ +110° - Cooled table console, table bearings and motors - Cooled bearing blocks and spindle nuts of the ball screw drives - Cooled guides in the linear axes X/Y/Z - Drive power: 100%ED/40%ED 24 KW/35 KW - Chip conveyor - Internal coolant supply - Electric handwheel - Rotary function Rotary table - Operating mode 4 - 2 pallets ø 630 mm - Rotary pallet changer - IKZ 40bar , 980 liters, paper belt filter - Dsc Htetzywvjlwwxokp - Measuring probe Heidenhain - 3D Quickset Machine can be inspected under power by arrangement.

Condition: used, Year of construction: 2001, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 12 m/min, nominal power (apparent): 17 kVA, torque: 82 Nm, controller manufacturer: Heidenhain, controller model: Mill Plus, total height: 2,450 mm, total length: 4,000 mm, total width: 2,200 mm, table width: 700 mm, table length: 500 mm, table load: 200 kg, overall weight: 3,500 kg, We are offering here a Deckel Maho DMU 50 T with Heidenhain Mill Plus control for sale. Ffedpfjw Dfbhox Afnou

Condition: used, Year of construction: 1992, Technical details: spindle diameter: 100 mm x-travel: 1500 mm y-travel: 1450 mm Ffodpfxeu Idqbj Afnju z-axis: 930 mm w-axis: 506 mm B-axis (table): 360 ° control for program: HdH TNC 407 tool taper: SK50 number of spindle speeds: 5 - 1.600 / stufenlos table load: 4,0 t table-size: 1100 x 1400 mm table rotating: 360 ° feed steps: X/Y/W/Z-Achse: 2 - 2000 mm/min Rapid feed X axis: X/Y/W/Z-Achse 5000 mm/min. total power requirement: 40 kW dimensions electric cabinet: 2000 x 600 x 2000 mm machine dimensions LxWxH: 4,9 x 3,7 x 3,8 m weight of the machine ca.: 14 t CNC drilling-milling machine with hydraulic power unit. Working paths from the table: X-axis table transverse 1500mm W-axis table longitudinal 1000mm 9x T-slots according to DIN 650 Equipment: measuring probe electronic handwheel hydr. weight compensation Y-axis universal milling head And some accessories, ask for them! i.D. *

Condition: used, Year of construction: 2006, x-travel 1.000 mm Ffjdsw E Nnnspfx Afneu y-travel 1.000 mm z-travel 1.200 mm C-axis 360 x 0,001 ° A - axis ° Control SINUMERIK 840D Powerline SIEMENS Size of table plate 900 x 700 mm milling spindle - taper HSK - A100 spindle turning speed - stepless 12000 U/min toolpiece magazine: chain magazine 180 Stück total power requirement 85 kW weight of the machine ca. 20,5 t dimensions of the machine ca. 6,5 x 6,1 x 3,5 m 5-axis machining center with horizontal milling spindle arrangement SIEMENS SINUMERIK 840D Powerline control system Electronic handwheel NC swivel rotary table Rotoclear window Measuring probe ready Blum laser tool measurement Vibration sensor Tool taper cleaning 4th operating mode Internal coolant system with 2 pumps, 40 bar and 80 bar Chip conveyor Belt filter system Mist and smoke separator Cooling/heating unit
