CNC lathe

DOOSAN PUMA TT1800 SY

Condition: ready for operation (used), Year of construction: 2014, spindle speed (max.): 5,000 rpm, travel distance X-axis: 165 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 770 mm, spindle motor power: 18,500 W, controller manufacturer: FANUC, controller model: 31i-MODEL B, number of axes: 9, This 9-axis DOOSAN PUMA TT 1800 SY was manufactured in 2014, offering advanced capabilities for horizontal turning. Ideal for complex machining tasks, this machine ensures precision and efficiency. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA TT 1800 SY machine we have for sale. Contact us for more information. Additional equipment • LNS bar interface • the robot is not included Machine Benefits Qualitative Machine Benefits • Part ejector + internal cooling for sub-spindle • Automatic electric tool measurement • Air conditioning in the electrical cabinet • Lns lamella-type chip conveyor • Auto door for robot application • Absolent air system mounted on the machine • 3 pcs driven tools radially • 4 pieces of m-l21590377d triple holders with v-offset, 2 pieces of m-l21590337e axial external holders, 2 pieces of m-l21590347d double holders (single l/h), 4 pieces of m-l21590367d double holders (external), 6 pieces of m-l21590317 single holders (external), 2 pieces of m-l21590387c single holders (external), and 6 pieces of m-l21590327b internal holders • 3 pcs hard jaws Technical Machine Benefits • Max turning diameter: 230 mm • Max turning length: 230 mm • Bar capacity: 65 mm • C1-c2 axis: 360, x2: 190 mm, z2: 720 mm • 2 x 12 position turrets, all positions driven (24/24 index) • Tool holder: bmt 55 p • Driven tools: 5. 5 kw, max: 5000 rpm • Coolant pump for main turret: 3. 7 kw, 14 mpa, 30 l/min • Coolant supply via sub-/right spindle • Belt-type oil skimmer, part ejector Kwodjyaqq Eepfx Afzjt Extra Information Machine still under power

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 800 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, controller manufacturer: HEIDENHAIN, controller model: TNC 530i, table width: 870 mm, table length: 3,500 mm, table load: 3,500 kg, rotary table diameter: 800 mm, overall weight: 24,000 kg, spindle speed (min.): 60 rpm, spindle speed (max.): 12,000 rpm, coolant supply: 20 bar, spindle motor power: 22 W, spindle nose: ISO 40, number of slots in tool magazine: 60, tool length: 300 mm, tool diameter: 76 mm, tool weight: 8 g, input voltage: 400 V, Equipment: documentation/manual, Used 5-axis universal traveling-column machining center with Heidenhain TNC-530 CNC, Ksdpfjxixn Nex Afzowt swivel head, integrated rotary table.

Condition: good (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: ML0177-000528, turning diameter: 230 mm, spindle bore: 76 mm, spindle speed (max.): 5,000 rpm, total height: 2,700 mm, total length: 11,000 mm, total width: 2,400 mm, overall weight: 10,000 kg, spindle nose: A2#6, bar diameter (max.): 65 mm, controller manufacturer: FANUC, controller model: SERIES 31 i-Model A, spindle torque (max.): 208 Nm, number of tool stations in tool turret 1: 12, number of tool stations in tool turret 2: 12, DOOSAN PUMA TT 1800 SY CNC Lathe - Operating voltage: 200/220 V - Frequency: 50/60 Hz - Connection load: 75.21 kVA - Rated current: 13 KA - Total connected load: 68.4 kVA - Maximum distance between spindle noses: 980 mm - Saddle swing: 230 mm - Recommended turning diameter: 210 mm - Maximum turning diameter on upper turret: 230 mm - Maximum turning diameter on lower turret: 230 mm - Maximum machining length (left and right spindle): 230 mm - Bar working diameter: 65 mm - Front spindle diameter: 110 mm - Boring bar diameter: 32 mm - Travel X1: 165 mm, X2: 190 mm - Travel Z1: 700 mm, Z2: 720 mm - Y-axis travel: 100 (+-50) mm - C1 and C2-axis travel: 36° (0.001°) - Rapid traverse X1 and X2 axes: 20 m/min - Rapid traverse Z1 and Z2 axes: 40 m/min - Rapid traverse Y axis: 7.5 m/min - Rapid traverse B axis: 40 m/min - Rapid traverse C1 and C2 axes: 600 rpm - Bed guideway span Z1 axis: 414 mm, Z2 axis: 339 mm - Guideway span X1 and X2 axes: 240 mm - Includes main and counter spindles, each equipped with a HAINBUCH chuck, as well as the tool holders shown in the photos - Includes FMB Turbo 5-55 bar feeder and LNS chip conveyor, year of manufacture: 2013 Attention: The item must be collected at a binding date to be agreed, between 18 and 26 February 2026. FCA D-78087 Mönchweiler – loaded onto truck Kwsdpfsx Tzuiox Afzst

Condition: like new (used), Year of construction: 2022, operating hours: 942 h, functionality: fully functional, turning length: 600 mm, turning diameter: 230 mm, spindle motor power: 22 W, spindle speed (min.): 50 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 700 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 40 m/min, rotational speed (max.): 5,000 rpm, rotational speed (min.): 50 rpm, bar passage: 65 mm, total height: 2,100 mm, total length: 5,000 mm, total width: 2,200 mm, overall weight: 8,800 kg, Equipment: documentation/manual, rotational speed infinitely variable, USED ​​8-axis CNC lathe "DN Solutions mod. PUMA TT1800SY" with motorized upper turret equipped with Y axis, motorized lower turret, opposing spindles and DN Solutions-Fanuc i-Plus iHMI CNC. Kwjdpfswuqp Eox Afzot

Condition: excellent (used), Year of construction: 2011, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 625 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, nominal power (apparent): 30 kVA, torque: 163 Nm, table load: 400 kg, rotary table diameter: 400 mm, rotational speed (max.): 15,000 rpm, coolant supply: 20 bar, number of spindles: 48, tool length: 300 mm, tool diameter: 70 mm, tool weight: 10 g, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Technical characteristics: CNC OSP P 200 Chip conveyor Kodpfxouw Sq Us Afzswt 48 tools Continuous table 360,000 pos. 15,000 rpm BT 40 Cooling through spindle 20 Bar Presetting on board table Shower work area washing system P.S. The machine has always worked in full oil Teflon material

Condition: excellent (used), Year of construction: 2010, turning length: 230 mm, turning diameter: 230 mm, spindle speed (max.): 5,000 rpm, spindle bore: 68 mm, spindle nose: A2-6, DOOSAN PUMA TT1800 SY Kwsdpfsxx Nc Nox Afzot

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm travel z1 700 mm travel x2 190 mm travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min Kwedpfx Asxn Amtjfzet sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min max. torque 47 Nm work piece power 5,5 kW C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min total power requirement 68,4 kVA weight of the machine ca. 7,8 t Accessories: collet fixture on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Condition: used, TECHNICAL DETAILS - distance between centers : 600 [mm] - center's height : 175 [mm] - table orientation : 11 [°] UNIVERSAL GRINDING WHEEL HOLDER HEADSTOCK - left grinding wheel dimension : 400 x 50 x 127 [mm] - right grinding wheel dimension : 225 x 20 x 76,2 [mm] - motor power : 3 [kW] - spindle speed : 1500 / 1700 / 2200 - grinding-wheel holder headstock orientation : 270 [°] PART HOLDER HEADSTOCK Kwjdpfjuhbywsx Afzot - part-holder headstock orientation : 360 [°] - spindle speeds : 20 - 400 [Rpm] - internal taper : Morse 5 - motor power : 0,9 [kW] TAIL STOCK - internal taper : CM4 - quill stroke : 30 [mm] DIMENSIONS - floor surface : 2580 x 1680 [mm] - height : 1670 [mm] - weight : 2200 [kg] EQUIPMENT - FISCHER internal spindle: 14,000 [rpm]

Condition: new, Discover our selection of robust and precise conventional lathes! Are you in search of a reliable lathe that boosts your productivity? Experience precision and performance with our new conventional lathes equipped with a wide range of accessories. Our machines offer turning diameters from 400-1000mm and turning lengths up to 10m, also available as a cycle variant. With various models, you have limitless possibilities. Some machines are quickly available from stock! Explore our extensive special accessories, such as hollow spindle, infinitely variable speeds, Siemens controls, and more, to make your lathe even more versatile. Whether for complex workpieces or demanding tasks, our machines always deliver the best results. Kjdpod Afn Iofx Afzswt Trust in our long-standing experience and let us optimize your machining processes together. Invest in quality and precision - contact us today! Here's a selection of STOCK MACHINES (see images), and we are happy to offer additional models or special machines upon request: Technical Main Data: DLZ Series including 15% or more BAFA subsidy! - Turning diameter over bed: 400-1000 mm - Turning length: 1000/1500/2000/3000 mm - Spindle bore: 80 (opt. 105) mm - Workpiece weight up to 2t - Spindle speed up to 2800 rpm Accessories: Digital display, 3-jaw chuck, faceplate, Multifix tool holder, and more. Extensive SPECIAL ACCESSORIES such as infinitely variable speed, steady rests, larger spindle bore, and more to make the machine even more productive. Currently available new machines with warranty and BAFA subsidy, for example: - SDM 850: Turning diameter over bed 850mm, turning length 3m - DLZ 325: Turning diameter over bed 650mm, turning length 2m and 3m - DLZ 250: Turning diameter over bed 500mm, turning length 1m and 1.5m - DLZ 200: Turning diameter over bed 400mm, turning length (missing information) More models (also with cycle control) available on request. Contact us now and discover the world of innovative turning technology! Our service for you: - Consultation and solution finding at your location - Organization of machine transport to your facility - Installation, assembly, commissioning, and ready-to-use handover - Financing and exploration of funding opportunities through KFW and BAFA, and more.

Condition: reconditioned (used), For Sale: EOS M400 – High-Performance Metal 3D Printer This EOS M400, is a cutting-edge metal additive manufacturing system located at the customer’s site. It is equipped with a 1kW laser, ensuring high precision and productivity for large-scale industrial applications. Specifications: • Laser Power: 1kW • Technology: Direct Metal Laser Sintering (DMLS) Compatible Materials: This system supports a wide range of materials, making it ideal for diverse applications across industries such as aerospace, automotive, and medical. Compatible materials include: • Nickel-based alloys: IN718_1, HX-1, IN625_1, IN939_1 • Aluminum alloys: AlF357_1, AlSiMg_1 • Copper alloys: CuCrZr_1, Cu_1 • Stainless steels: GP1_1, PH1_1 • Tool steels: MS1_1, SP2_1 • Titanium alloys: Ti64_1, Ti64ELI_1, Ti64Grade23_1, TiGrade5_1, TiCP_1 • Custom gas options: CustomAr, CustomN2 • Cobalt chrome: MP1_1 Why Choose the EOS M400? • Large build volume for industrial-scale production. • High laser power for enhanced speed and precision. • Wide material compatibility for versatile applications. Services Included: • Transport & Installation Support: We can arrange safe relocation and installation at your facility. • Expert Maintenance Plans: Flexible plans to keep your machine in peak condition. About Inframotion 3D (IM3D) At Inframotion 3D B.V., we specialize in providing high-quality refurbished EOS additive manufacturing machines with comprehensive support. As the only provider offering a complete solution for used EOS equipment, we ensure reliable machines, tailored services, and premium materials for your production needs. What we offer: • Expert service: Installation, servicing, and upgrades performed by skilled ex-EOS technicians. • Exclusive materials: High-quality consumables tested and optimized for EOS systems. • End-to-end support: From transport to tailored maintenance plans, we handle every detail. Trust IM3D to help you scale your metal additive manufacturing capabilities with confidence. Kedpsvq Sm Eofx Afzewt Contact us for more information or inquiries!
