Miter saw

Elumatec AF 222

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 22 002, type of input current: three-phase, input voltage: 400 V, ❇️ elumatec AF 222 – Notching and End Milling Machine for Aluminium | Excellent Condition | Fully Functional For sale is a high-quality elumatec AF 222 notching and end milling machine from a window and metalworking business. The machine is in excellent, well-maintained, and fully operational condition and was in regular use up to the present time. Inspection and function testing on site are possible at any time. ⸻ ❇️ Technical Data • Manufacturer: elumatec (Eugen Lutz GmbH & Co. KG), Germany • Model: AF 222 • Machine type: Notching / End Milling Machine • Year of manufacture: 07/1997 • Power supply: 230 / 400 V, three-phase • Frequency: 50 Hz • Spindle speed: approx. 2,800 rpm • Pneumatic connection: 5–8 bar • Application range: Aluminium and plastic profiles • Applications: Mullion, door and profile notching • Design: heavy-duty, long-life industrial version ⸻ ❇️ Features & Highlights • Heavy, low-vibration industrial machine • Precision milling unit for notching and end milling operations • Pneumatic material clamping / hold-down devices • Large worktable with scale and stops • Adjustable profile supports • Extraction port with protective brushes • Safe, ergonomic operation • Ideal for window, door, and façade construction • Ready for immediate use ⸻ ❇️ Condition • Very good, well-maintained condition • Fully functional • Clean mechanics, smooth running • No known technical defects • Machine was in use until recently ⸻ ❇️ Sale & Processing • Sale on behalf of a client • Invoice with VAT can be issued • Delivery possible by arrangement and at cost • Location: 72229 Rohrdorf • Loading facilities available on site via overhead crane ⸻ ❇️ Price ➡️ Offer price (net): €2,200 plus VAT ⸻ ❇️ External dimensions (approx.) • W 120 cm × D 90 cm × H 160 cm Fjdpjx Rpfkefx Afnefu ⸻ ⚠️ In my other listings, I offer additional machines and accessories for window manufacturing, metalworking, and workshop operations. ‼️ Please take a look at my other offers as well – it’s worth your while!

Condition: new, A dedicated machine for producing a straight trench / notch in a variety of timber products used in general joinery, garden furniture, shed, roof truss and timber frame manufacturing. Also can be used for door framing, notching of roof bearers and for log cabin manufacture.As standard the machine is fitted with horizontal pneumatic workpiece clamps and also a hydrocheck damper control to give a smooth stroke action to the cutterhead movement. Precision ball bearing movement on hardened steel runners. Sturdy cast iron construction with steel base stand. 3kw motor. Max tool dia 250mm Bore of tool 40mm. Handwheel rise and fall of cutter motor arm. Max depth of trench / notch 60mm. Width of trench / notch 60mm - in one pass. Fsdjdy Hm Dspfx Afnefu Max. length of travel of tool 250mm. 2 x horizontal workpiece clamps. Hydrocheck damper to movement of cross cut arm. Dust extraction outlet 100mm. Machine stand

Condition: excellent (used), shipping EU ~300euro Ffedpel Skk Usfx Afnsu

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, Cutter diameter max. 280 mm Cutter bore 40 mm Manual feed Profile height max. 200 mm Milling area: Length 400 mm Depth 110 mm Height up to 150 mm Power 2.5 kW at 400 V/50 Hz Spindle speed 2,800 rpm Compressed air connection 7 bar Air consumption 10 l per cycle, with minimal quantity lubrication 20 l Fedpfswpchvjx Afnjfu Length 1,540 mm, Depth 905 mm, Height 1,200 mm, Weight 248 kg

Year of construction: 1996, condition: good (used), machine/vehicle number: 9182, Offer 23168 Technical data: - Notching possibilities + miters in 3 planes - right-angled, one-sided + two-sided + three-sided oblique . - Can be used as a shift cut crosscut saw - Pneumatic profile clamping Machining with semi-automatic sawing units - Saw blade dimensions - vertical 500 x 3,5 x 40 mm positive - horizontal 500 x 3,5 x 40 mm negative - notching width / notching height at 90° 300 / 285 mm - vertical saw blade 60° - 90° - 25° mot. positioning with digital display - Swiveling range saw blade horiz. with vert. saw blade Saw blade - 45° - 90° - 45° mot. positioning with digital displays - Notching height adjustment with digital displays - profile stop shoulder manually tiltable 30° - 90° - 45° - pneumatic coolant check device - air connection 6 bar - drive 400 V / 2 x 3 kW Fedpfxemb U E Aj Afnjfu - space requirement approx. W 2400 x H 2000 / D 1400 mm - weight approx. 1200 kg

Condition: used, Year of construction: 2013, functionality: fully functional, saw blade diameter: 500 mm, CNC cutting center fully automatic CAT500 The machine is operational and ready for use Blade diameter: 500 mm Cutting angles in range: -45°/90°/+45° Operator panel with Windows Working direction from right to left Chip extraction Waste conveyor Label printer Fodpfx Ajx Ez Igofnefu

Condition: good (used), Year of construction: 2009, Elumatec SBZ 140 Extended Length Version: 7.6 meters Approximate weight: 5,000 kg Automatic tool changer 2-section clamping system 2 pneumatic stops Safety hood Light curtains Automatic clamp detection Central lubrication Coolant spray system Chip trolley Conditioning unit Max spindle speed: 24,000 rpm Tool holder: HSK-63F, 8-position tool changer Max milling diameter: 80 mm Max saw blade diameter: 200 mm Compressed air: 7 bar The SBZ 140 is a 4-axis profile machining center (axes: X, Y, Z + A). Designed for aluminum and thin-walled steel profiles. 4-axis CNC machining center (X/Y/Z + tilt/rotation axis A) X-axis: approx. 7,900 mm travel Y-axis: approx. 850 mm travel Z-axis: approx. 650 mm travel A-axis (rotation/tilting): Freely programmable angle, –90° to +90° Ffodpfxjx E Ahzj Afnou Axis traverse speed: X-axis up to approx. 65 m/min, Y- and Z-axis up to approx. 60 m/min (varies with configuration) Control: 4-axis CNC system, PC control, color display, USB & network connectivity. Software: eluCam. Automatic material clamps; automatic positioning via index pins Pendulum/shuttle operation (two work zones), improving production throughput time. In addition to milling and drilling, also tapping, sawing, and profile machining—all with stationary clamped profiles. Please note: The information on this page has been obtained and compiled to the best of our knowledge, but its accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend verifying all relevant details. Financial information VAT/margin: VAT: The price shown is exclusive of VAT (VAT deductible for business customers).

Year of construction: 2008, condition: excellent (used), ELUMATEC SLK 118 3-Axis CNC Profile Machining Center.Template-free Profile Copy Router with (3) Controlled axii; designed for machining aluminum and thin-walled steel profiles and extrusions, aluminum, PVC, light alloyed steel.It is particularly suitable for companies who are automating their door production processes; designed for the door and window sector; machining from above, rotate workpiece for machining other side.Specifications:Traverse X-axis 2450 mm/ V max. 36 m/min. (with double linear guides)Traverse Y-axis 350 mm/ V max. 15 m/min.Traverse Z-axis 280 mm/ V max. 15 m/min.Spindle speed 18,000 rpm6.5 HP (4.5 kw) Motor-driven spindle,Routing spindle cooling device(4) Tool holders for tools.Dimensions: 3100 x 1850 x 2250 mm (122" x 73" x 89")Weight: 1400 Kg (3087 Lbs.)Features: PC Touch Screen Control w/Windows Software3-axis Control Light Barrier for operator protection;(4) Horizontal Material ClampsPulsed Coolant SystemCollet holderQuick-action chuckNOTE: The machine is in excellent condition an Ffsdexc Udgjpfx Afnou

Year of construction: 2007, condition: used, functionality: fully functional, Equipment: CE marking, For Sale: Elumatec SBZ 122/10-30 CNC Profile Machining Centre (2007) The Elumatec SBZ 122/10-30 is a reliable and versatile CNC machining centre designed for processing aluminium, PVC, and thin-walled steel profiles. This 2007 model offers precise 3-axis CNC control combined with a rotating angle head, allowing machining on five sides of the profile without repositioning. With its robust construction, proven Elumatec technology, and automatic tool changer, the SBZ 122/10-30 remains a valuable machine for window, door, façade, and general profile machining applications. 🔧 Technical Specifications Year of manufacture: 2007 Axes: 3 CNC-controlled (X, Y, Z) Working range: X-axis: approx. 3,850 mm Y-axis: approx. 350 mm Z-axis: approx. 280 mm Max profile length: Without end machining: approx. 3,750 mm With end machining: approx. 3,650 mm Spindle power: ~6 kW (S6) Spindle speed: up to 21,000 rpm Tool system: HSK-F63 Tool changer: 4 positions + angle head (5 tools total) Accuracy: ±0.1 mm 📐 Dimensions & Weight Machine dimensions (L × W × H): approx. 4,600 × 3,230 × 2,420 mm Weight: approx. 1,690 kg 💻 Control PC-based CNC control (Windows environment) Programming via Elusoft Ffsdpfx Asw Syy Tefneu Automatic clamping system for secure and flexible profile positioning ✅ Highlights: Five-sided machining without manual repositioning Automatic tool change for increased efficiency Suitable for aluminium, PVC, and light steel applications Trusted Elumatec design with long-lasting performance

Year of construction: 2007, condition: ready for operation (used), A 4-head welding machine Rotox for window construction is available. Profile height range: 30mm-125mm, max. profile width: 140mm, min. welding length with/without gasket forming unit: 320mm/430mm, max. welding length without/with gasket forming unit: 4000mm/4000mm, min. welding width without/with gasket forming unit: 430mm/500mm, max. welding width without/with gasket forming unit: 3500mm/3500mm, welding bead limitation: 0.2mm-2mm, material: uPVC hollow bar profiles, weight: approx. 3100kg. Documentation available. On-site inspection possible. Expected to be available from the end of 2026. Fodpoxvru Nefx Afnofu
