Band saw

KASTO Twin A2

Condition: excellent (used), Year of construction: 2012, machine/vehicle number: 6459105039, functionality: fully functional, power: 5 kW (6.80 HP), total height: 1,568 mm, total length: 1,755 mm, total width: 2,149 mm, table height: 700 mm, empty load weight: 1,700 kg, cutting range round steel at 90°: 260 mm, saw band length: 4,530 mm, saw band width: 34 mm, saw blade length: 4,530 mm, Fully hydraulic production band saw for continuous operation, suitable for cutting materials ranging from easy to difficult to machine such as solid stock, tubes, and profiles. Modern, precise linear guides ensure high stability and maximum service life. A special feature of this machine is the dual bearing of the driven flywheel. This design provides ideal bearing alignment and thus optimal support for the driven flywheel. Dkedpfxsx Sdyre Abmoi The standard KASTO Basic Control system allows for intuitive and efficient machine operation. Up to 98 jobs (length/quantity combinations) can be programmed. Once the set quantity is reached, the machine automatically shuts off. The material feed unit positions the material length with high precision via a ball screw. A frequency-controlled drive with bevel gears, jam protection, bandsaw breakage protection, and clamping force control are included as standard features. These ensure perfect operation for both single cuts and small to medium batch runs. KASTO’s universal hydraulics ensure optimal cutting results and long band saw blade life. Technical data: Saw capacity round [mm]: 260 Saw capacity square [mm]: 260 x 260 Saw capacity rectangular [mm]: 260 x 260 Maximum feed length [mm]: 750 with repeat function [mm]: 9,999 Shortest cut length [mm]: 6 Minimum cut diameter [mm]: 10 Remnant length: Semi-automatic operation [mm]: 15 Automatic operation [mm]: 100 Power: Saw motor power [kW]: 3 Total power [kW]: 5 Infinitely variable cutting speed [m/min]: 20–110 Saw blade: Saw blade dimensions [mm]: 4530 x 34 x 1.1 Dimensions and weights: Table height [mm]: 700 Length [mm]: 1,755 Width with chip conveyor [mm]: 2,475 Width without chip conveyor [mm]: 2,149 Height (saw frame bottom) [mm]: 1,568 Weight [kg]: 1,700
