Used Cnc Milling Centre for sale (18,291)

Condition: good (used), Year of construction: 1999, operating hours: 1,887 h, functionality: fully functional, machine/vehicle number: 142031, spindle speed (max.): 5,000 rpm, Mazak Super Quickturn 200 (1999). Serial Number: 142031. Date: 1999. Weight: 5000kg/11,000lbs. Mazak tooleye measuring system. Tailstock. Swarf Conveyor. Parts Catcher. 12 Station Turret. Mazatrol PC-Fusion- CNC 640T control panel. Main Spindle Max 5000RPM. Collet Chucks and Collets. Hydrafeed barfeeder NOT included. Iodpfstz A Dfjx Abgjtf This item is physically in stock and can be seen in full working order, at our showroom. Delivery and installation can be arranged at extra costs.

Condition: excellent (used), Year of construction: 2007, operating hours: 2,770 h, machine/vehicle number: 199581, Mazak Vertical Centre Nexus 510C-II (2007) 4th axis Serial number: 199581 Low working hours: 2770 Matrix Nexus control Kitagawa 4th axis Iedjv D E Iiopfx Abgstf EIA/Mazatrol Control Mazatrol tool length measuring system Through coolant CAT40 tooling 12,000 rpm main spindle Full set of manuals This item is physically in stock and can be seen in full working order, at our showroom. Delivery and installation can be arranged at extra costs.

Condition: like new (used), Year of construction: 2022, operating hours: 2,085 h, turning diameter: 240 mm, spindle motor power: 11,000 W, spindle speed (min.): 3,200 rpm, spindle bore: 90 mm, travel distance X-axis: 142 mm, travel distance Z-axis: 165 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, rotational speed (max.): 2,500 rpm, type of input current: three-phase, total height: 2,700 mm, total length: 3,590 mm, total width: 2,610 mm, overall weight: 5,200 kg, Equipment: documentation/manual, rotational speed infinitely variable, Front set Double SPindel Turning Center. with 2 spindle, 2 rew.head, with DRIVEN tools, and C axis, 2 linear robots. Machine is almost new, we used only 2000 hrs. This is the FULL-FULL version of the machine, with two side feeders. collet + 3 jaw chucks. Chain conveyor. FANUC 0ITD control. machine bought new from Takisawa dealer in Hungary. ( SZIMKER ZRT ) RAKU-RAKU MONITOR. Itodpfx Aerzq N Uebgsf

Condition: used, Year of construction: 2023, controller manufacturer: Mazak, controller model: Mazatrol SmoothAi, _____ Description: Year of manuf. : 2023 Control : Mazak Mazatrol SmoothAi Turning diam. : 600 mm Turning length : 850 mm In General: Year of manufacture:2023 Control system:Mazak Mazatrol SmoothAi Max. machining diameter:600 mm Max. machining length:850 mm Main spindle: Technology:Motor spindle Speed:6,000 rpm Power:11 kW Max. torque:184 Nm Bar capacity:51 mm C-axis:0.0001° Chuck:3-jaw chuck Clamping cylinder:Hollow clamping cylinder Sub spindle: Technology:Motor spindle Speed:6,000 rpm Power:11 kW Max. torque:184 Nm Bar capacity:51 mm C-axis:0.0001° Tailstock function:Yes Tool carrier (X/Y/ZB): Technology:Travelling column with milling spindle X-axis:535 mm Y-axis:210 mm Z-axis:900 mm B-axis:-30° / +210° Milling spindle speed:20,000 rpm Power:24 kW Tool magazin: Technology:Shelf magazine Number of stations:250 Tool changer:Double gripper Equipment: Chip disposal:Chip conveyor Coolant supply:Internal coolant system, 15 bar Workpiece measurement:Renishaw RMP 60 Tool measurement:Renishaw tool setter Bar loader:IRCO ILS-MUK 7012 Finished part removal:Parts catcher Software option I:5-axis simultaneous machining Isdpjyrvzmofx Abgstf Software option II:Synchronous thread cutting Software option III:Cylinder interpolation Software option IV:Tool radius compensation Software option V:Tool length compensation Emulsion mist separator:Mechanical Setup mode:Electronical handwheel

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel Itodpjvt D D Uefx Abgof - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: refurbished (used), Year of construction: 2003, functionality: fully functional, turning length: 2,260 mm, turning diameter over cross slide: 690 mm, turning diameter: 690 mm, spindle motor power: 40,000 W, spindle speed (max.): 3,300 rpm, spindle bore: 115 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 2,260 mm, rotational speed (min.): 4,000 rpm, chuck outer diameter: 500 mm, spindle nose: A11, swing diameter over bed slide: 690 mm, tool length: 500 mm, feed force X-axis: 20,000 N, feed force Y-axis: 20,000 N, feed force Z-axis: 20,000 N, Equipment: rotational speed infinitely variable, Overhauled 5-Axis CNC Turning-Boring-Milling Centre WFL M60 Millturn / 2000mm with control Siemens Sinumerik 840D PL. YOC: 2003 The machine is completely overhauled, fully checked and fully working. The Turninmg -boring-milling und and the tailstock are completely refurbished. Milling spindle and spindle bearings are new. Cables and hydraulic hoses area also new. The machine geometry is within the original protocol values of a new machine (with measuring protocol). The machine is equipped with steady rest slide and tailstock (both with autom. Positioning and extremely rigid hydraulic clamping on the bed. Chuck and steady rest according to customer requirement (brand new items will be included). Chuck dia. Max. 500mm and steady rest max. 380mm opening dia. Tool system is HSK100 (external 90 station magazine with ATC). The machjine is equipped with glass scales for all linear machining axis. Furtthermore the machine is equipped with a 80 bar high pressure pump for deep hole drilling and 2t feed force for Z, X- and Y axis. The B-axis increment is 0.001° and is equipped with and additional indexing system with extremely high torque. Putting into operation and Training can be offered upon request. If rquired the outside colour can be adjusted according to customer requirements. Main spindle: 40kW (S1) Iodpfoyuu A Iox Abgetf Milling spindle: 25kW (S1) 4000rpm Tool system: HSK100 Magazin: 3x30 Plätze

Condition: used, _____ Description: Year of manuf. : 2009 Control : Siemens C200-4D SL In General: Year of construction:2009 Control system:Siemens 840 Dsl (C200-4D SL) Bar capacity:65 mm Milling spindles:18,000 rpm Main spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° Z-axis:390 mm Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:3-jaw chuck Sub spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° X-axis:600 mm Z-axis:390 mm Ijdpfx Asvxmy Njbgetf Bar capacity:65 mm Chuck:3-jaw chuck Tool carrier I: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 X-axis:350 mm Y-axis:160 mm (+/- 80 mm) B-axis:230° Tool carrier II: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 Y-axis:160 mm(+/- 80 mm) B-axis:230° Tool magazin: Technology:Chain magazine Number of stations:80 pieces Tool changer:Double gripper Tool length max.:180 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system with filter Parts removal:Gantry-type pick-up Bar loader interface:Electrically prepared Tool monitoring:Drill breakage monitoring

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm C-axis indexing 360° Spindle nose A2-6 Itsdpfsydc Evex Abgsf Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: refurbished (used), Year of construction: 2007, turning length: 5,200 mm, turning diameter over cross slide: 1,140 mm, turning diameter: 1,140 mm, spindle motor power: 90,000 W, spindle speed (max.): 1,000 rpm, spindle bore: 245 mm, travel distance X-axis: 920 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 5,370 mm, mount diameter: 100 mm, rotational speed (max.): 3,200 rpm, torque: 730 Nm, spindle nose: B20, Equipment: rotational speed infinitely variable, WFL Millturn M120/5000 CNC TURNING-DRILLING-MILLING CENTER TYPE M120 MILLTURN WITH TAILSTOCK AND SINUMERIK 840 D CONTROL SYSTEM Ijdpfjul S Eyox Abgjtf

Condition: used, _____ Description: Year of manuf. : 2022 Control : Okuma OSP-P300 SA Turning diam. : 650 mm Turning length : 1000 mm Main spindle: Technology:Motor spindle Speed:4,200 rpm Power:22 kW Iedpfjwu I Irjx Abgstf Torque:427 Nm spindle bore:91 mm Hollow clamping cylinder:86 mm C-axis:High precision package Chuck:SMW KNCS-N 275-86 K8 Sub spindle: Technology:Motor spindle Speed:5,000 rpm Power:22 kW Torque:420 Nm spindle bore:80 mm Hollow clamping cylinder:77 mm C-axis:High precision package Chuck:SMW BHD-FC 210-52-3 Tool carrier X/Y/Z/B: Technology:Milling spindle Speed:12.000 rpm Power:22 kW Torque:120 Nm Tool holder:HSK 63 Y-axis:250 mm (+/- 125 mm) B-axis:240° Tool magazin: Number of stations:80 Equipment: Measuring systems:Direct in X/Y/Z axis (glass scales) Chip disposal:Chip conveyor Coolant supply:IKZ system, 70 bar Coolant temperature control:Deltatherm E4 Chip rinsing:working area, manual gun Accuracy package:C-axis high accuracy Software package:5-axis auto-tuning Software option:Multifunction tool Gear cutting software package:Gear hobbing, gear peeling Control extension:Dialogue programming Workpiece measurement:Renishaw measuring probe Tool measurement:Tool setter Tool breakage monitoring:Renishaw TRS2 B-axis:NC function and turning function Bar loader:LNS Quickload Servo III+ Automation preparation:Robot interface Work area door:Automatic Set-up mode:Electronic handwheel

Condition: good (used), Year of construction: 2012, 750mm Swing, 500mm max. machining diameter, 1300mm max turning length, 3000rpm main spindle, Itsdpfxsxqyg Ns Abgsf 65mm bar capacity, 8,000rpm milling 20kW, C axis 0.001 degrees, Y axis - 90/+120mm, 40 station ATC, , milling speed 4,000rpm, 30kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant, tool setter, parts catcher, barfeed unit.

Condition: refurbished (used), Year of construction: 2008, WFL Millturn M120X/3000 WORKING RANGE centre distance = 3000mm Swing over bed = 1220mm Swing over slide top = 1140mm Longitudinal travel (Z) = 3330mm Face travel (X) = 920mm Distance spindle nose to tailstock tip = 3812mm ROTATING SPINDLE Spindle head DIN 55026 form size A15 spindle bore 165mm MAIN DRIVE AC-drive with 2-stage gearbox Drive power 100% ED 60kW Max. Spindle speed 1600 1min Max. Spindle torque 100% ED 4472 NM C-AXIS. SERVO-CONTROLLED MAIN SPINDLE Smallest programmable increment 0.001°. Max. Speed 20min-1 Max. Torque on spindle 100% ED Nm 3000 Holding torque of disc brake Nm 6000 FEED DRIVE Cross slide, rotary drilling-milling unit: AC servo drive Feed force longitudinal (Z) kN 30.0 Feed force plane (X) kN 31,5 Feed force Y-axis 55kW kN 25.0 Rapid traverse speed: longitudinal (Z) m/min 15.0 plane (X) m/min 15.0 Y-axis m/min 12.5 Rapid traverse B-axis °/s 90 BALL SCREW LENGTH (Z axis) ø x pitch mm 63X20 PLAN (X-axis) ø x pitch mm 63X10 RIDGE STOCK Quill diameter mm 180 Quill stroke mm 200 Quill force (adjustable) N 5400-40000 Quill with built-in bearing MK 6 TOOL CARRIER (single tool carrier, rotary drilling-milling unit) AC drive, drive power 100% ED kW 55 Itsdpjl Smhlofx Abgjf Spindle speed max. min-1 3200 Max. Torque at spindle 100% ED Nm 730 Travel perpendicular to X/Z plane (Y axis) 55kW mm 650(-300/+350) Tilting angle of the milling spindle (B axis) ° -110/+90 Spindle head for tools according to DIN 69893 HSK-A100 Milling spindle diameter in front bearing mm 130 TEMPERATURE STABILISATION through controlled cooling circuit with compressor - cooling unit EXTERNAL TOOL MAGAZINE: Number of Storage spaces (space-coded) Size HSK100 pcs 90 Max. Tool length mm 500(800) DIMENSIONS Length(max. tool magazine with chip conveyor) m 13 Height m 4,1

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 30214501, turning length: 2,000 mm, total length: 12,000 mm, WFL Millturn M60/2000 WORKING RANGE center distance mm 2000 swing over bed, turning diameter mm 690 MAIN DRIVE Itedsu Hl R Topfx Abgof AC-drive with 2 gear steps drive power 100% duty cycle kW 40 max. speed min-1 3300 max. torque at the spindle 100% duty cycle Nm 1830 TAILSTOCK quill diameter mm 140 quill travel mm 160 quill force (adjustable) N 3500-31000 quill with installed live center MK 5 TOOL HOLDER (single tool holder, turning-boring-milling unit) AC-drive drive power 100% duty cycle kW 30 speed range max. min-1 6000 max. torque at the spindle 100% duty cycle Nm 315 travel vertical to the X/Z-plane (Y-axis) mm 300[-125/+175] pivot capability of the milling spindle (B-axis) ° -110/+90 spindle head acc. DIN 69893 HSK-A100 spindle diameter in front bearing mm 100 DIMENSIONS length (max. tool magazine) m 11 width/height m 3,9/3,3

Condition: excellent (used), Year of construction: 2015, CNC glass milling and working centre NEPTUN QUICKMILL 160-30 NC Year of production: 2015 Milling, seaming of milled profiles and drilling (only with frontal head) Maximum working height: 1600 mm Maximum working length: 3000 mm Minimum glass size: 800 x 340 mm Glass thickness: 5 - 12 mm NC controlled (with software) Excellent condition Good working order, still in production As is Isdpfx Asrzazysbgjtf Available immediately

Year of construction: 2010, condition: like new (used), I sell the radius copy milling aggregate for edges suitable for CNC working centres with edge banding HOMAG, WEEKE, BIESSE, SCM, MORBIDELLI, HOLZ-HER, IMA, FELDER, MASTERWOOD, BUSELLATO, etc. n 12.000 rpm. Itsdjhw Db Iopfx Abgof Radius R2mm. HSK63 holder. Available immediately.

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 06651, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,700 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 15,000 mm, total width: 7,500 mm, spindle speed (max.): 4,000 rpm, total height: 7,000 mm, table height: 1,100 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 3,300 mm, type of input current: three-phase, table load: 50,000 kg, rotational speed (max.): 4,000 rpm, distance table center to spindle nose: 2,110 mm, overall weight: 110,000 kg, spindle motor power: 50,000 W, control cabinet length: 7,000 mm, control cabinet height: 2,000 mm, control cabinet width: 600 mm, Equipment: rotational speed infinitely variable, MODEL: Portal Type AGE: 1992 S/N #: 06651 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 6800 mm Y-Axis Head Travel: 3700 mm Z-Axis Ram Stroke: 1500 mm, fixed crossrail Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 3300 mm Distance Table To Ram Face: 2110 mm, vertical passage 2000 mm Table Size: 6000 x 2500 mm Spindle (Quill) Diameter: 250 mm Spindle Taper: ISO #50 Spindle Speeds: 0-4000 RPM Spindle Motor: 50 KW EQUIPPED WITH: FIDIA System C20 CNC Control, new in 2002 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors both side Way Covers Rapid movements: Z-10.000 mm/min, X and Y-15.000 mm/min Table load: max 50.000 kg Weight of the machine: 110.000 kg Iedpfx Aboyahv Ssgotf Outside dimensions: 15.000 x 7.500 x 7050 mm Machine has been tested before dismantling and is fully operational, all mechanical components in excellent condition, electrics new in 2018. Machine available from stock. The price is now SPECIAL FROM STOCK. Once we will reassemble the machine, price will grow significantly. We can assist you to assemble and run up the machine.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 21,269 h, functionality: fully functional, machine/vehicle number: 0082, turning length: 1,500 mm, turning diameter: 580 mm, travel distance X-axis: 598 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,660 mm, TECHNICAL DETAILS Travel X-axis: 598 mm Travel Y-axis: 230 mm Travel Z-axis: 1,660 mm Max. turning diameter: 580 mm Turning length: 1,500 mm Swing diameter over bed: 610 mm Swing diameter over cross slide: 580 mm Main Spindle Main spindle speed range: 12 - 2,800 rpm Spindle bearing diameter: 150 mm Spindle bore: 110 mm Spindle nose: JIS A2-11 Main spindle drive power: 37 (30) kW C-axis accuracy: 0.001° Rapid traverse X/Y: 12,000 mm/min Rapid traverse Z: 20,000 mm/min Rapid traverse C: 100 rpm Cutting feed rate: 0.001 - 1,000 mm/rev Tool Turret Type: H2 ATC Number of tool stations: 2 (1x L-Tool / 1x M-Tool) positions Driven stations: stepless Speed range - driven tool stations: 40 - 3,000 rpm Tool shank height: 25 mm Boring bar holder diameter: 50 mm Tailstock Ijdpfeyxmyuox Abgotf Quill diameter: 120 mm Quill stroke: 170 mm Tailstock taper: MT 5 Tool Magazine Number of tool stations: 50 positions Tool holder: MAS BT 50 Max. tool diameter: 170 mm Max. tool length: 350 mm Max. tool weight: 20 kg Magazine drive: 3.2 kW MACHINE DETAILS Total power requirement: 53 kVA Dimensions & Weight Space requirement: 6.0 x 3.2 x 3.0 m Machine weight: 18.5 t Operating Hours Main switch on-hours: 79,607 h NC operating hours: 27,814 h Main spindle hours: 21,269 h EQUIPMENT Chip conveyor Central coolant system High-pressure coolant system, 20 bar Tailstock Signal lamp C-axis Y-axis Hydraulic unit Steady rest Various tool holders (44 pcs.) Three-jaw chuck Schunk - ROTA NC 400-120 Electronic handwheel

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, spindle speed (max.): 7,000 rpm, spindle bore: 42 mm, controller model: Siemens 840 D - SL, counter spindle speed (max.): 7,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Bar diameter: 42 mm Travel X-axis 1/2/3: 180 mm Travel Y-axis 1/3: ±45 mm Travel Z-axis 1/2/3: 704 / 620 / 704 mm Main spindle Speed: 7,000 rpm Drive power: 22 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Counter spindle Speed: 7,000 rpm Drive power: 19 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Tool turret Number of turrets: 2 + 1 pos Number of tool stations: 3 x 12 pos Number of live tool stations: 3 x 12 pos Rotational speed of driven tools: 8,000 rpm Power: 11.4 kW / 2.3 kW Torque: 26 Nm / 14 Nm Tool holder: VDI 25 Rapid traverse (X / Y / Z): 30 m/min Acceleration: 0.5 g MACHINE DETAILS Control: Siemens 840 D - SL Ijdpfx Aeyxmnxebgotf Total power requirement: 60 kW Dimensions & Weight Space requirement: approx. 8.2 x 3.3 x 2.5 m Machine weight: approx. 7.5 t EQUIPMENT Documentation Knoll chip conveyor High-pressure coolant (14 bar) Parts catcher Counter spindle Interface for bar feeder Spinner Barload BL 0146 bar loading magazine C-axis: 2x 0.001° Hydraulic unit Hainbuch collet chuck Y-axis: 2x ±45 mm Various tool holders Various collets Tool measuring arm

Condition: defective spare-parts repository (used), Year of construction: 2005, functionality: not functional, turning length: 600 mm, turning diameter: 140 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 110 mm, travel distance Z-axis: 360 mm, controller model: Siemens 840 D PowerLine, Hydraulic unit, main and counter spindles defective TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Distance between spindles: 615 mm Travel X-axis: 110 mm Travel Z-axis: 360 mm Travel Y-axis: 70 mm Iodpfxeyxgc Ne Abgotf B-axis: 2x +/-1° Rapid traverse (X / Y / Z-axis): 25 / 12 / 50 m/min Main spindle Max. speed: 5,000 rpm Drive power: 20 / 27 kW Max. torque: 105 / 145 Nm C-axis positioning: 0.001° Chuck diameter: 140 - 160 mm Spindle nose: ISO 702/1 A5 Max. bar diameter: 65 mm Spindle bearing diameter: 110 mm Counter spindle Max. speed: 5,000 rpm Drive power: 20 / 27 kW Max. torque: 105 / 145 Nm C-axis positioning: 0.001° Chuck diameter: 140 - 160 mm Spindle nose: ISO 702/1 A5 Max. bar diameter: 65 mm Travel X-axis: 150 mm Travel Y-axis: 600 mm Spindle bearing diameter: 110 mm Turrets Number: 3 Tool holder: VDI 25 x 48 DIN 69880 Number of tool stations: 3 x 12 Number of live tool stations: 3 x 12 Max. speed of live tools: 6,000 rpm Drive power for live tools: 8 kW Max. torque: 16 Nm MACHINE DETAILS Total power requirement: 53 kVA Dimensions & Weight Space requirement: 8.0 x 3.5 x 2.5 m Machine weight: 6.5 t EQUIPMENT 2(3) Y-axes +/-35 mm 2 B-correction axes (+/-1°) Chip conveyor Parts catcher Tool breakage monitoring Bar feeder: IRCO Profimat 65.6

Condition: ready for operation (used), Year of construction: 2007, operating hours: 19,357 h, functionality: fully functional, spindle speed (max.): 12,000 rpm, travel distance X-axis: 800 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 510 mm, controller model: Fanuc Series 31i-Model A5, TECHNICAL DETAILS X-axis travel: 800 mm Y-axis travel: 520 mm Z-axis travel: 510 mm Milling spindle: 12,000 rpm Tool holder: Capto C6 Rapid traverse: 60 m/min Ijdpfx Aoyw I Htjbgetf MACHINE DETAILS Control: Fanuc Series 31i-Model A5 Chain tool magazine: 48 positions Additional magazine: 90 positions Operating hours Total operating hours: approx. 48,974 h Machining time: 19,357 h EQUIPMENT Coolant system Chip conveyor Note: Clara extraction unit is not included in the scope of delivery.

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 7024NL256160890J, spindle speed (max.): 10,000 rpm, travel distance Y-axis: 200 mm, rotational speed (max.): 4,000 rpm, bar diameter (max.): 80 mm, distance between centers: 700 mm, Condition: Ball screw drives in X, Y, and Z axes replaced; major maintenance package carried out approx. one year ago (machine has not been in operation since)! TECHNICAL DETAILS Distance between centers: 700 mm Spindle speed range: 1 - 4,000 rpm Tool spindle speed: 10,000 rpm Bar capacity: 80 mm Mounting: MT5, revolving tailstock Without center Turret: 12 stations, bolt-on turret Overhang for driven tools: ±100 mm Assemblies: Integrated MK4 bearing for live center Chip and coolant system: Scraper-type chip conveyor with magnetic separator, discharge height approx. 1,000 mm Coolant system: high pressure 5 bar, pump 800 W, delivery rate 20 l/min Coolant shower at chuck, including high-performance pump Compressed air blow-off system for tool holder sleeves Compressed air blow-off system for tailstock live center Line filter for coolant system MACHINE DETAILS Itsdpfey A Icrex Abgef Control: M730UM, CELOS - ERGOline Touch Total power: 18.5 / 18.5 / 15 kW (25% duty cycle / 50% duty cycle / continuous) Tool spindle power: 5.5 / 5.3 / 7 kW (3 min / 5 min / continuous) EQUIPMENT Interface for oil mist separator (diameter: 150 mm) Signal beacon: red, yellow, green, blue EtherNet/IP interface for automation Robot interface for portal robot DMG Mori Seiki Transformer: 45 kVA, three-phase autotransformer X-axis direction ISO Note: The machine is supplied without a chuck, tool pre-setter, or workholding devices.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 61,440 h, functionality: fully functional, machine/vehicle number: 06800003891, rotational speed (max.): 5,000 rpm, controller model: Siemens 840D powerline, Equipment: chip conveyor, documentation/manual, TECHNICAL DETAILS Max. speed: 5,000 rpm MACHINE DETAILS Control: Siemens 840D powerline Electrical Data Apparent power: 50 kVA Rated current: max. 72 A Current: 80 A Mains voltage: 400 V Frequency: 50 Hz Control voltage: 230 V Itjdpfx Aoyzqtkobgsf Voltage: 24 V Operating hours: approx. 76,300 h Spindle hours: approx. 61,440 h EQUIPMENT Pallet circulation system Material conveyor belts for machined parts Chip conveyor Documentation/manual Note: The machine is sold without chuck, tools or raw part holders. Additionally, the seller can offer the following accessories: SMW KNCS225 chuck for €1,500 Ewab pallets (base pallets) 10 units for €500 Extension of transport belts for finished parts €2,000 Basic holder set VDI 40 suitable for the machine, 10 units for €1,000

Condition: ready for operation (used), Year of construction: 2005, operating hours: 60,683 h, functionality: fully functional, turning length: 1,524 mm, turning diameter: 820 mm, spindle speed (max.): 3,300 rpm, rapid traverse X-axis: 40 m/min, milling spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Turning length: 1,524 mm Turning diameter: 820 mm Travel X-axis: 870 mm Travel Y-axis: 500 mm Travel Z-axis: 1,598 mm Main spindle Max. spindle speed: 3,300 rpm Main spindle drive power: 30 kW / 22 kW Max. torque main spindle: 588 Nm Main spindle nose: A2-11" Spindle bore: 104 mm Indexing: 0.0001 Sub spindle Max. spindle speed: 3,300 rpm Sub spindle drive power: 30 kW / 22 kW Max. torque sub spindle: 588 Nm Sub spindle nose: A2-11" Indexing: 0.0001 Milling spindle Milling spindle drive power: 37 kW Max. torque milling spindle: 260 Nm Milling spindle speed range: 0-10,000 rpm Rapid traverse X-axis: 40 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 40 m/min Ijdpfx Aey Akpnsbgotf MACHINE DETAILS Control: Mazatrol 640M PRO Tool holder: SK50 Number of tool stations: 120 Operating voltage: 400 V / 50 Hz Connected load: 104 kVA Required floor space (L x W): 7 x 3.5 m Operating hours: 60,683 h EQUIPMENT Infinitely variable speed adjustment 120-position tool magazine High-pressure coolant 70 bar Renishaw Laser measuring system for rotating tools Interface set Air / water cooling through the spindle Overload monitoring system Mayfran Consep 2000 chip conveyor SMW quick-change chuck

Condition: ready for operation (used), Year of construction: 2008, operating hours: 3,858 h, functionality: fully functional, turning length: 705 mm, turning diameter: 275 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, controller model: MSX-850III, TECHNICAL DETAILS Travel X-axis: 260 mm Travel Z-axis: 795 mm Turning length: 705 mm Max. turning diameter: 275 mm Swing over bed: 923.8 mm Itodoyz Aq Ispfx Abgjf Swing over cross slide: 755 mm Bar work capacity diameter: 80 mm Upper turret Number of tool stations: 12 Main spindle Spindle speed: 4,000 rpm Spindle drive power: 18.5/18.5/15 kW (10 min/30 min/cont) Spindle nose: JIS A2-8 Tailstock Tailstock travel: 734 mm Taper: MT5 MACHINE DETAILS CNC control: MSX-850III Dimensions & Weight Dimensions (L x W x H): 3,100 x 1,922 x 2,120 mm Weight: 5,800 kg Operating Hours Main spindle hours: 3,858 h Power-on hours: 21,543 EQUIPMENT Chip conveyor Tool measuring arm

Condition: used, machine/vehicle number: 008490, X axis working area: 3657 mm Y axis working area: 1524 mm Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 3 axes Total number of drilling spindles: 10 Total number of tool changer positions: 12 Itjdpfx Aboyxmwasgsf
