Used Ddr Smalcalda Drilling Machine for sale (65,681)

Condition: used, Year of construction: 1992, Elcos 2 head drilling machine is a machine manufactured by Elcos in 1992, with a format of 45 x 150 mm. Currently stored in Germany, it features a drill distance of 45 - 150 mm, space behind the drill heads of 100 mm, and is a double head paper driller. It operates with a lever and is single phase 240 volts. The delivery terms are FCA. Format: 45 x 150 mm Kedpfx Abewvuubo Todi Equipment: Double head paper driller Drill distance 45 - 150 mm Space behind drill heads 100 mm Operation Lever operated, single phase 240 Volts

Condition: not inspected (used), Year of construction: 2009, functionality: unexamined, workpiece length (max.): 2,500 mm, workpiece width (max.): 700 mm, number of spindles: 40, TECHNICAL DETAILS Panel length min.: 170 mm Panel length max.: 2,500 mm Panel width min.: 50 mm Panel width max.: 700 mm Number of injectors: 2 Number of support units: 2 Vertical spindles Kedpfeyq Irhox Ab Todi Speed: 2,800 rpm Number of spindles: 40 Horizontal spindles Speed: 2,780 rpm Number of spindles for horizontal drilling in Y-axis: 6 Number of spindles for horizontal drilling in X-axis: 8 (4 on each side) MACHINE DETAILS Control system: WINDOWS Motor power (vertical drilling): 3 kW Motor power (horizontal drilling): 2.2 kW Note: Tools not included The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of descriptive character. The buyer has the right to inspect the goods prior to collection and is responsible for the installation, securing, and use of the machine at the destination. External reference: 6106

Condition: used, machine/vehicle number: 004922, Max. panel width: 250 mm Max. panel length: 1500 mm Kdjdpfx Abjg E Th So Tji No of Top Units: 2 Lateral horizontal groups: yes

Condition: used, machine/vehicle number: 008321, X axis working area: 4200 mm Y axis working area: 1350 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Kedpfx Ajx A Tdlob Tsdi Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 18 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Kedpfjwuz Ekox Ab Tedi Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Kedpfx Aortrx Reb Tjdi Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges Kdodpfx Abjw Nytno Toi - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 - Number of tool positions: 5

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle adaptor MK 3 - right - left rotation - Drilling spindle stroke 150 mm - drilling spindle speed infinitely variable 80 - 1170 rpm - 2 feeds 0,1 / 0,2 mm/rev - throat 290 mm - max distance table - drilling spindle 780 mm - table with 2 T-slots 480 x 400 mm - Height adjustable via toothed rack with hand crank - Drive 400 V / 0,9 / 1,3 kW Kdodpfsdkx Ansx Ab Tei - Space requirement approx. W 600 x H 2100 x D 900 mm - Weight approx. 420 kg - with: - coolant device - quick-action drill chuck 1-13 - illumination

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm total power requirement 4 kW Kdodpev S Iqcsfx Ab Toi

Condition: used, Year of construction: 2020, total height: 2,100 mm, total length: 2,000 mm, total width: 2,500 mm, Price: On request - Machine available from: 2025-12-15 - Year: 2020 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 1000040377 - Main motor power [kW]: 10 - Number of controlled axes [pcs]: 3 - Working range X [mm]: 975 - Working range Y [mm]: 1321 Kdsdpfx Absx Ad R Ne Tei - Working range Z [mm]: 243 - Number of milling spindles [pcs]: 1 - Tool holder interface: ISO30 - Spindle diameter [mm]: 16 - Min. spindle speed [rpm]: 1000 - Max. spindle speed [rpm]: 18000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 10 - Vertical drilling unit: Yes - Software: Biesse works - Saw unit present: Yes - Safety feature: - Spindle speed control: Variable - Voltage [V]: 400 - Current consumption [A]: 18 - Fuse [A]: 32 - Power [kW]: 10.0 - Transport dimensions: 2000mm x 2500mm x 2100mm (l x w x h) - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, machine/vehicle number: 007842, X axis working area: 5000 mm Y axis working area: 1200 mm Kdjdpfx Abeyhbiuj Tji Working Table: Pod and Rail Main Electrospindle power: 18 KW Number of controlled axes: 4 axes Maximum edge height: 64 mm Total number of drilling spindles: 14 Total number of tool changer positions: 18

Condition: used, machine/vehicle number: 007841, X axis working area: 4200 mm Y axis working area: 1200 mm Working Table: Pod and Rail Main Electrospindle power: 18 KW Kjdpfxeyg Ef Ds Ab Todi Number of controlled axes: 4 axes Maximum edge height: 64 mm Total number of tool changer positions: 18

Condition: used, Empty weight: 4.200 kg Kdsdpfxjwnifro Ab Tei - Documentation available: Yes - CE certificate present: No - Control: Conventional - Motor power: 2.0kW - Transport weight [kg]: 4200kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Year of construction: 1990, Gebruikte radiale boormachine van MAS Type VO 80 Boorcapaciteit 80 mm Kjdpeyu Su Usfx Ab Tsdi

Condition: used, Box column drilling machine WEBO Series- No 132 Machine No: 9 Drilling capacity 50 mm Spindle cone MK 5 - long quill throat 430 mm spindle stroke 280 mm Height adjustment of drill head 500 mm Table size Ø 725 mm Distance between drill spindle and table max. 740 mm Distance between drill spindle and clamping surface on machine base max. 1240 mm Spindle speed 55-820 rpm Feed rate level 1 0.13 - 0.2 - 0.27 - 0.4 mm/rev. Feed rate stage 2 0.6 - 0.83 - 1.17 - 1.8 mm/rev. Column diameter 300 mm Motor power 2.8 / 3.6 kW pole-changing Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and infinitely variable via variator - Manual drill head height adjustment via hand crank, clamping with clamping screws - Rotatable drill table with mechanical clamping - Table height adjustment via hand crank - Clamping surface on machine base 600 x 550 mm Top height of drill head 3020 mm Overall height drill head bottom 2520 mm Space requirement L x W x H 1400 x 780 x 2520 mm Ksdpfoqa Txqsx Ab Todi Weight 1600 kg good condition

Condition: used, Line boring machine WEBO with 4 stations type B 20 make no. 376/13; 376/14; 376/27; 376/36 year of construction approx. 1970 drilling capacity 20 mm spindle adaptor MK 2 - long spindle sleeve drilling head distance 335 mm throat 260 mm pinol stroke 190 mm table size 350 x 1500 mm distance drilling spindle/table min.30 mm / max. 700 mm Kdedpfxjihmwte Ab Tji Spindle speed drill head 376/13 355, 500, 710, 1000, 1400, 2000, 2800, 4000 rpm. Spindle speed drill head 376/14 355, 500, 710, 1000, 1400, 2000, 2800, 4000 rpm. Spindle speed drill head 376/27 250, 355, 500, 710, 1000, 1400, 2000, 2800 rpm. Spindle speed drill head 376/36 180, 250, 355, 500, 710, 1000, 1400, 2000 rpm. Motor power 1,1 / 1,3 kW Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 4 V-belt steps - drill head height adjustment via toothed rack and hand crank approx. 300 mm - height adjustable drilling table approx. 350 mm space requirement L x W x H 1750 x 1100 x 1900 mm weight 1900 kg good condition

Condition: used, Year of construction: 2022, drilling capacity steel/cast iron 50/60 mm throat max. 1600 mm workpiece height max. 1300 mm throat min. 300 mm spindle taper: MK5 drilling depth in one stroke 300 mm vertical adjustment of arm 800 mm base plate surface area 1600 x 800 mm spindle turning speed range 125- 1250 U/min total power requirement 3,5 kW Kdodpsyuy Szofx Ab Tei weight of the machine ca. 3,5 t dimensions of the machine ca. 2,4 x 1,2 x 2,7 m feed per revolution 0,025- 1,38 mm/r Without table.

Condition: excellent (used), Digital display Heidenhain Type: conventional Table KS 320 D Clamping surface: 530 x 270 mm Speed: 125 - 4400 rpm Feed: 0.03 – 0.40 mm/rev Drilling capacity in steel: 22 mm Thread cutting up to M16 Milling capacity in steel: 25 mm Drill spindle stroke: 120 mm Spindle motor power: 0.51 / 1.47 kW Dimensions: 2000 x 1200 x 1000 mm Kedoyv Af Uspfx Ab Tedi Weight approx. 900 kg

Condition: used, bore capacity in steel St 60 18 mm 23 mm Kjdpfx Aboyv N N Tj Tsdi spindle MK 2 bore depth 100 mm throat 240 mm column diameter 82 mm 340x280 mm T-Slots Amount - Width - Distance 2 x 13 x 125 mm Spindle Speed 125-2.000 U/min 160-880 mm total power requirement 0,45/0,8 kW weight of the machine ca. 205 kg dimensions of the machine ca. 765x510x1850 m

Condition: used, bore capacity in steel (diameter) 60 mm Kodpfxjyv N H So Ab Tsdi Center of spindle to wall or column min./max. 320 - 160 mm spindle turning speed range 20 - 2.500 U/min quill stroke 310 mm total power requirement 4 kW weight of the machine ca. 4.500 kg

Condition: used, Year of construction: 2008, bore capacity in steel (diameter) 32 mm throat 232 mm bore stroke 150 mm Spindle Speed 115 - 2470 U/min. weight of the machine ca. 280 kg dimensions of the machine ca. 500 x 950 x 1800 mm Kodpfsyv N Dqex Ab Todi

Condition: new, bore capacity in steel (diameter) 40 mm Kdedpfjyv Nr Uex Ab Tji bore stroke 190 mm turning speeds 50-1800 U/min Short spindle MK 4 Table dimensions 500x400 mm total power requirement 2,2 kW weight of the machine ca. 330 kg dimensions of the machine ca. 670 x 500 x 2120 mm

Condition: new, 32 bore stroke 125 mm Short spindle MK 3 throat 210 mm Machine table - usable table surface 390x390 mm table load 65 kg spindle turning speed range 105-2.650 UpM total power requirement 0,75 kW Overall size 750x450x1745 mm weight of the machine ca. 192 kg Kdjdpfoyv Nqwox Ab Tsi Standard equipment: - Number of speed ranges 9x2 steps - Coolant device in the machine base - Movable LED machine light - Swivel work table with integrated machine vice on the opposite side opposite side with jaw width 120 mm - Mains cable and plug therefore immediately ready for use - Drilling table adjustable via gear rack - Depth stop with scale - Emergency stop - According to current CE conformity

Condition: used, Year of construction: 1959, turning speeds 63-1000 U/min Kdjdpfjyv Np Tjx Ab Tsi feeds - fine adjustment 0,08-1,25 mm/min Boring power 40 mm total power requirement 2,3 kW table surface area 550x450 mm weight of the machine ca. 1.000 kg dimensions of the machine ca. 860x570x2350 mm

Condition: used, bore capacity in steel (diameter) 32 mm Short spindle MK 3 bore depth 175 mm spindle throat 320 mm column diameter 130 mm distance spindle /table 140-790 mm feed 0,1 - 0,16 - 0,25 m/min number of spindle speeds 60-1600 Ksdpfxjyv I Une Ab Tsdi weight of the machine ca. 450 kg
