Used Induction Heating Device for sale (27,923)

Condition: good (used), Year of construction: 2005, Offer 25190 Technical Data approx.: - max. temperature 400°C - temperature control 0 - 250°C - time automatic 0 - 60 min. - working space under the yoke 320 - 200 mm - max. ball bearing weight 250 kg - drive 400 V / 12 kVA - space requirement approx. W 850 x D 600 x H 1150 mm - weight approx. 150 kg Gsdpjwp Exdofx Ah Eebw - yokes 40 + 50 + 80 mm - mobile base

Condition: excellent (used), GH Induction Type: 30 SMBC Transistor generator for inductive heating Medium frequency with series resonant circuit The SMBC generator series retains the traditional advantages of the Transithermic family of generators (high reliability, simple operation and high efficiency) in a series resonant circuit and a compact design, with cooling enclosed in the generator enclosure. Rittal generator cabinet and GH induction TC150 / 2 resonant circuit Godpfxjb E I Utj Ah Eobw Voltage 400V Frequency 50 Hz Current 56 A Power 37.5 KVA as good as new condition! Scope of delivery: Transistor generator, Rittal generator cabinet with cooling and TC150 / 2 resonant circuit (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone.

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: SINAC 25/40 SM Exp, total height: 1,500 mm, total width: 1,000 mm, total length: 2,500 mm, type of input current: three-phase, input voltage: 400 V, pressure: 6 bar, input current: 45 A, Induction heating station with 25 kW power for transporting and pressing bearings. Gbjdjw Hwp Nspfx Ah Eew

Year of construction: 2019, operating hours: 34,933 h, condition: ready for operation (used), machine/vehicle number: NO-19-05-07358/GE1101824, Technical data (German) Manufacturer: EFD Induction a.s. Type: SINAC 50/80 SM Serial number: NO-19-05-07358/GE1101824 Year of manufacture: 21/19 Electrical data: Input voltage: 400-480 V AC Input current: 90 A Mains frequency: 50/60 Hz Gbsdpfx Aovw S Rwjh Eow Input power: 62 kVA Reactive power: 62 kVAr Output data: Output voltage: Not specified Output current: 350 A Output power: 50 kW Frequency range: 10-25 kHz Cooling & operating conditions: Water consumption: 21 l/min Maximum inlet temperature: 35°C Maximum pressure: 6 bar Min. pressure difference inlet/outlet: 4.5 bar Ambient temperature (operation): +5°C to +50°C Protection class (IP): IP54

Condition: used, Flame Heating Device Roland Groß + Söhne GmbH Ring Burner for Preheating Weld Seams, Casting Preheating, etc. Model: 1 x 1" Ionization Serial No.: ALMA Year of Manufacture: 03/20 Connection Voltage: 230 Volt Max. Gas Pressure: 500 mbar Max. Air Pressure: 10 bar Max. Gas Flow Rate: 30 Nm³/h Max. Air Flow Rate: 300 Nm³/h Including 10 Different Flame Ring Nozzles - Flame monitoring by Hans Henning - Hinged ring nozzle made of two half-shells, inner Ø 310 mm, with hose quick-connect coupling and ignition device, outlet at the face side - Hinged ring nozzle made of two half-shells, inner Ø 400 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 490 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 500 mm, with hose quick-connect coupling and ignition device, outlet at the face side - Hinged ring nozzle made of two half-shells, inner Ø 590 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 690 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 690 mm, with hose quick-connect coupling and ignition device, outlet at the face side - Hinged ring nozzle made of two half-shells, inner Ø 800 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 890 mm, with hose quick-connect coupling and ignition device, outlet at the face side Gbodpfx Aodz Spwsh Eow - Hinged ring nozzle made of two half-shells, inner Ø 890 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, inner Ø 990 mm, with hose quick-connect coupling and ignition device, central outlet - Hinged ring nozzle made of two half-shells, arc length 1500 mm, with hose quick-connect coupling and ignition device, central outlet For heating pipes and vessels. For heating steel to welding temperature. Ideal for repair welds and the fabrication of welded assemblies from fine-grain steels. Preheating for powder flame spraying or Sulzer Metco high velocity flame spraying. Gas heating for thermal coating applications.

Year of construction: 2018, condition: excellent (used), EFD Type: MINAC 6/10 SM Heat treatment The compact design of the Minac induction heating system allows for easy installation and offers fast, concentrated and controlled heating with full repeatability. repeatability. Medium frequency product line Technical data: Maximum output power 10 kW Continuous output power 6 kW Mains voltage 400-480 V Frequency range 10-25 kHz Control range of output power 2-100% Recommended back-up fuse 16 A Cooling water approx. 4 l/min Cooling water flow temperature min./max. 18 - 35°C Cooling water pressure min./max. 4 - 6 bar Weight approx. 50 kg Dimensions (WxDxH): 345 x 708 x 453 mm Year of construction: 2018 optris CTlaser infrared thermometer Abbreviation: 3ML Measuring range: 50 to 400 °C Spectral sensitivity: 2.3µm Typical application: Metals at low object temperatures (from 50°C) Temperature control ECU 1214C Hyfra eChilly water cooler 4-S Cooling capacity 4395W The device comes from the laboratory sector. Only a few operating hours. Condition: used Scope of delivery: (see picture) (Changes and errors in the technical data, specifications are reserved!) We will be happy to answer any further questions you may have on the phone. Gbedpfxot Din Aj Ah Esw

Year of construction: 1981, condition: used, Heating elements control device Godpfxjb A H Uzs Ah Eebw -for: heating elements -Connection: from the electrode welder -Controller and scribe -Transfer in current condition as seen -in transport box -Weight: 80 kg

Year of construction: 2008, condition: good (used), heating cooling device Regloplas 90 XL M 90°C 21,5 kW year: 2008 Godpsh Uubhjfx Ah Esbw price: 2.150 € contact: Mr. Rainer Eckerle

Condition: excellent (used), LECTROTHERM AJAX TOCCO INDUCTION HEATING Power supply Inductron Inductotherm 330kw Gjdpfx Ahsfhnwyj Esbw

Year of construction: 1981, condition: used, Heating elements control device -for: heating elements -Connection: from the electrode welder -Controller and scribe -Transfer in current condition as seen Gedpfx Aheb A Ruij Eobw -in transport box -Weight: 95 kg

Year of construction: 2017, condition: good (used), heating cooling device HB Therm 140 Z1 Serie 5 Water, 160°C 9 KW + new Service ! year: 2017-2018 price: 4.950 € Gjdpekn Enuefx Ah Eebw contact: Mr. Rainer Eckerle

Year of construction: 2018, condition: good (used), heating cooling device HB Therm 160 Z2 Serie 5 Water, 160°C 17 KW Gbodjk Tapwspfx Ah Esw year: 2017-2018 price: 5.950 € contact: Mr. Rainer Eckerle

Year of construction: 2018, condition: good (used), heating cooling device180 Z2 Serie 5 Water, 180°C 17 KW New Service ! Gedpfxsk Tap Ts Ah Eebw price: 7.950 € contact: Mr. Rainer Eckerle

Year of construction: 2017, condition: good (used), heating cooling device HB Therm 140 Z1 Serie 5 Water, 140°C 9 KW + new Service ! year: 2017-2018 Gedokn Elnepfx Ah Ejbw price: 4.650 € contact: Mr. Rainer Eckerle

Condition: good (used), Image processing control unit, camera control -Manufacturer: Vision Device, camera controller for 2 cameras -Type: unfortunately no further type designation -Individual components/connectors: see photos -Dimensions: 200/145/H110 mm -Weight: 1.4 kg Gedpfsxvp S Ejx Ah Esbw

Condition: ready for operation (used), A good used induction heat sealer model ICS 1H from Relco UK - ideal for low speed semi-automatic or manual line with diaphragm in cap for sealing onto container. Gbedpfx Ajua E Rqoh Ejw

Condition: used, Year of construction: 1997, functionality: fully functional, power: 1,000 kW (1,359.62 HP), Boiler with feed system - Year of release: 1997 - manufacturer: Komforts - Power 1 mW. - moving floor supply system with hydraulic station, - chimney, Gbsdpfx Ajv D Uz Ejh Eew - pumps, - control, - hot water accumulator.

Condition: like new (used), Device for cleaning die-cut sheets Gbsdpfx Aowyxi Rjh Eow German production, Metabo. 230V power supply. Easy-to-use, manual device for removing external waste from the pallets of die-cut sheets. Safe, two-handed operation of the device.

Year of construction: 2016, condition: ready for operation (used), Suitable for stainless steel wire: 1.4301, 1.4310, 1.4401, wire diameter: 0.25-0.5mm with a strength up to 2400 N/mm², working speed: 75-80m/min, temperature range: 400-650°C, suitable for four wires at the same time with one temperature gauge (movable), shielding gas: forming gas grade 95/5 95%N2/5%H2, nitrogen gas, cooling: water-cooled tubes. Gjdpfx Ahen R Nhqo Ejbw

Condition: good (used), electric motor, three-phase motor -Power: 1.1 kW -Speed: 920 rpm -Shaft diameter: 24 mm -Bolt circle flange: Ø 165 mm -Flange: Ø 200 mm Gbedpfodd Ax Tsx Ah Ejw -Design: B5 -Protection class: IP 54 -Dimensions: 315/200/H205 mm -Weight: 15.5 kg

Year of construction: 2019, condition: ready for operation (used), Connected load: 84kVA, length: 5065mm, width: 1100mm, height: 1530mm. Godpog A Trgjfx Ah Esbw

Year of construction: 2020, condition: used, functionality: fully functional, machine/vehicle number: MY2002/018, Y2002/034, The compact FOBA M1000 laser workstation is designed for high-quality laser marking of small components, medium-sized workpieces, and small production runs. In addition to the automotive industry and the metal, tool, and mechanical engineering sectors, this small and mobile universal marking machine is particularly suitable for medical technology, plastics processing industries, and contract laser marking (e.g., promotional items). The M1000 enables both small metallic and plastic components and series to be marked efficiently and with high-quality results. Operating in laser class 1, the marking station features a programmable Z-axis, a small work table, and a smooth manual or optionally electrically operated lift door that provides access to the interior from three sides. To cover a wide range of applications, various fiber laser markers can be integrated. Gbedpfx Ahjw Npfgo Esw Main application areas: Automotive and automotive supply industry, tool and mold making, mechanical engineering, medical technology, plastics processing industries, contract laser marking (e.g., promotional items). The M-Series comprises advanced manual workstations for precise and economical laser marking of small to large and geometrically complex workpieces, as well as batches and small production runs. Two housing sizes (M2000 and M3000) and three models each (B: with work table; R: with rotary table; P: with X/Y/Z axis) are available. Modern fiber and UV lasers can be integrated, as well as camera systems for marking alignment, mark inspection, and code reading. The highly productive R models: motorized Z-axis, 2-station rotary table; ideal for marking a variety of serial parts (e.g., automotive interior components, metal parts, tools, medical products such as implants or instruments). Main application areas: Automotive and automotive supply industry, tool and mold making, mechanical engineering, medical technology, plastics processing industries.

Condition: used, Rotating Device Gunter Seibold Rotating Device for HTS Coils – Infinitely Adjustable Drive (Type S05082) Description: Professional rotating device designed for accommodating and rotating HTS coils with winding mandrel. Engineered for uniform distribution of two-component resin during the curing process. Ideal for development, laboratory, or manufacturing environments working with high-temperature superconducting (HTS) coils. The winding form is electrically heated, with power supplied directly to the mold (not included in the scope of delivery). The machine impresses with precise control, intuitive operation, and a service-friendly design. Technical Specifications: Solid machine stand: Welded square tube construction with leveling bolts and floor anchors Drive: - Three-phase planetary gear motor (11 kW, 400 V, 50 Hz, 3 phases) - Infinitely variable speed (0.2 – 100 rpm) - Soft-start & soft-stop via frequency inverter (4-quadrant controller) - Electromagnetic spring-applied brake (safe stopping in case of power failure) - Switchable rotation direction (left/right) Control Panel: - 5.7" touchscreen for setting speed, direction, ramps, time, or number of revolutions - Emergency stop button, ergonomically integrated - 2 programmable analog inputs Electrics & Control Cabinet: - Controls integrated into machine base - 400 V / 230 V supply, 24 V DC control voltage - Circuit breakers, RCD protection 30 mA - Sockets: 8× 230 V / 16 A, 2× 400 V / 16 A CEE, 1× 400 V / 32 A CEE - Control cabinet with climate unit - Complete grounding & static discharge of main shaft - Workstation lamp, swivel-mounted and height-adjustable Feature / Value Max. coil diameter: 1,500 mm Gbedpsxwmkujfx Ah Ejw Coil passage: 1,700 mm Center height above floor: 1,100 mm Max. load on face plate: 500 kg Face plate Ø 600 mm, 4 T-slots (DIN 650) Speed range: 0.2 – 100 rpm (infinitely variable) Torque: 775 – 539 Nm Operating voltage: 400 V / 50 Hz Control voltage: 24 V DC Connected load: 11 kW Rated current: 32 A Color scheme (according to RAL): Base machine: blue (RAL 5010) Moving parts: yellow (RAL 1021) Control panel / cabinet: light grey (RAL 7035 / 5010) Condition: used Scope of delivery: (see photo) (Subject to changes and errors in technical data! Details and technical specifications are subject to confirmation.) If you have further questions, we are happy to answer them by phone.

Condition: good (used), continuous welding machine, film welding machine Gsdpfx Ahovyq Duo Eobw -Manufacturer: Rische, continuous welding machine film welding machine Polystar -Type: Polystar 350/5 DSM-TE -Voltage: 220 V -Technical data: see photo type plate -Dimensions: 520/250/H5600 mm -Weight: 12.1 kg

Condition: excellent (used), Instron Instron 2663-822 Standard Video Extensometer (SVE) Non-contact strain measurement system for materials testing machines Description: The Instron 2663-822 Standard Video Extensometer (SVE) is a non-contact optical measurement system for precise detection of strain during tensile, compression, and flexural testing. Using contactless measurement via digital image processing, markers on the specimen surface are tracked—completely without mechanical influence on the test results. Ideal for applications where traditional contact extensometers (e.g., with blades) are unsuitable, such as with thin, sensitive, or elastic materials. The SVE is compatible with Instron materials testing machines and can be integrated into the Bluehill software (depending on system version). Special features: - Contactless strain measurement – no impact on the specimen - High resolution and measurement accuracy - Ideal for retrofitting older Instron systems - Low-maintenance and robust for laboratory use Technical specifications: Feature / Specification Measurement principle: Optical, contactless strain measurement Fields of view (FOV): 50 mm / 100 mm / 200 mm / 350 mm / 500 mm Resolution: - 50 mm FOV: 3 µm - 100 mm FOV: 4 µm - 200 mm FOV: 5 µm - 350 mm FOV: 25 µm - 500 mm FOV: 50 µm Measurement accuracy: - 50 mm FOV: ±5 µm or ±0.5% - 100 mm FOV: ±7.5 µm or ±0.5% - 200 mm FOV: ±10 µm or ±0.5% - 350 mm FOV: ±50 µm or ±1% - 500 mm FOV: ±100 µm or ±1% Data rate: 50 Hz Recommended markers: Dots approx. Ø 2 mm (at 50 mm FOV) / Lines approx. 1 mm wide Gauge length: Depending on the field of view, e.g., minimum 5 mm with 50 mm FOV Application range: Tensile, compression, and flexural tests under ambient or temperature-controlled conditions Power supply / interface: Via Instron system controller (compatible controller required) Reliable & durable: Proven Instron model 2663-822 Important note: “The table shown in the photos is not included in the sale.” Condition: used Gbodpexvxwkjfx Ah Eow Scope of delivery: (See picture) (Specifications, subject to change and error!) We are happy to answer any further questions by phone.
