Used Lathe Shaft for sale (11,140)

Condition: good (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: ASS.NO.330165301, turning length: 1,017 mm, turning diameter: 420 mm, total height: 2,840 mm, total length: 5,500 mm, total width: 2,800 mm, overall weight: 7,400 kg, bar passage: 70 mm, number of driven tool stations in tool turret 1: 12, MAZAK SUPER QUICK TURN 300 M CNC lathe Gbodpfxsz Nwape Al Ueu Note: Technical data is provided without guarantee. - Swing diameter: approx. 620 mm - Max. turning diameter: approx. 420 mm - Max. turning length: up to approx. 1017 mm - Bar capacity: presumably 70 mm - Diameter of the three-jaw chuck: 250 mm - Number of powered tool stations: 12 - Includes technical documentation - Includes machine accessories such as tool holders, some powered, chuck jaws, and other accessories Transport will be carried out on a standard truck. FCA D-01445 Radebeul - loaded onto truck.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 9712854F, center width: 2,000 mm, center height: 275 mm, spindle speed (max.): 2,000 rpm, controller model: Fagor, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Gjdoz Ninxepfx Al Ujbu Maximum turning height: 275 mm Swinging diameter over bed: 550 mm Swinging diameter over carriage: 360 mm Distance between centers: 2,000 mm Bed width: 360 mm Spindle bore: 105 mm Spindle speed: 180–2,500 rpm MACHINE DETAILS Control system: Fagor Connected load: 14 kW Dimensions & Weight Dimensions (L x W x H): 4,100 x 1,900 x 1,850 mm Net weight: 5,000 kg EQUIPMENT Documentation CE marking

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 25693, turning diameter: 150 mm, Specifications: Number of Axes: 3 Maximum Workpiece Diameter: 300 mm (approx.) Maximum Workpiece Length: 300 mm (approx.) Chuck Size: 6” (standard, options for larger sizes) Machine Dimensions: 2,400 mm x 2,200 mm x 2,500 mm (approx.) Machine Weight: 3,200 kg (approx.) Spindle Speed: Up to 6,000 RPM (standard) Spindle Power: 15 kW (continuous) Spindle Torque: 75 Nm Spindle Bore: 65 mm X-Axis Travel: 300 mm Y-Axis Travel: 250 mm Z-Axis Travel: 300 mm Rapid Traverse (X, Y, Z): 20 m/min (maximum) Gbodozn Ay Tepfx Al Uju Feed Rate: 12 m/min (max feed rate in all axes) Number of Tool Stations: 6 to 12 tool stations Maximum Tool Diameter: 32 mm (in fully populated tool turret) Maximum Tool Length: 100 mm Positioning Accuracy (X, Y, Z): ±0.005 mm Repeatability (X, Y, Z): ±0.002 mm Spindle Runout: < 0.003 mm

Condition: good (used), Year of construction: 1979, Single column vertical turning lathe BERTHIEZ TM500 SP Manufacturer: Berthiez (France) Model: TM500 SP Year of manufacture: 1979 Main technical data: Table diameter: 6300 mm Maximum turning diameter: 15000 mm Maximum usable height: 4000 mm Arm travel: 3600 mm Main motor power: 100KW Maximum allowable load on faceplate: 80 t Ram size: 360x360 mm Machine weight: approx. 230 tons Gbsdpfxjx A U Raj Al Usu The machine is capable of both turning and milling operations. Do not hesitate to contact us for any additional information.

Condition: used, Year of construction: 2005, functionality: fully functional, KIATURN 15N SLANT BED CNC LATHE 170 MM HYD 3 JAW CHUCK MAX TURNING DIA 250 MM BAR CAPACITY 38.1 Gbodpfez Rnwbjx Al Uou 12 STATION TURRET TAILSTOCK FANUC CONTROL TOOL SETTER PARTS CATCHER BARFEED

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: UC-1871, spindle speed (max.): 3,500 rpm, center width: 635 mm, center height: 115 mm, No minimum price – guaranteed sale to the highest bidder! This is a CNC internal grinding machine, converted from a CNC lathe. TECHNICAL DETAILS Center height: 115 mm Distance between centers: 635 mm Swinging diameter over bed: 380 mm Swinging diameter over removable bed: 520 mm Spindle bore: 75 mm Max. spindle speed: 3,500 rpm MACHINE DETAILS Control system: Fanuc 0-T Connected power: 15 kW Dimensions (L x W x H): 3,800 x 1,700 x 2,000 mm Weight: 6,000 kg Shipping packages: 2 pcs. EQUIPMENT Documentation Gbsdpsz Nithefx Al Usu

Year of construction: 2000, condition: ready for operation (used), functionality: fully functional, controller model: TX8H, swing diameter over cross slide: 445 mm, turning length: 1,000 mm, machine/vehicle number: 321, TECHNICAL DETAILS Spindle head according to DIN 55026: A8 Chuck diameter: 250/315 mm Spindle bore: 80 mm Turning length: 1,000 mm Swinging diameter over cross slide: 680 mm Swinging diameter over compound slide: 445 mm Main drive Motor power with direct drive: 31 kW Speed with direct drive: max. 2,800 min⁻¹ Motor power with 2-stage gearbox: 37 kW Speed with 2-stage gearbox: max. 3,150 rpm Tool holder W1 Number of tools: 12 Cylindrical tool shank according to DIN 69880: 40 × 63 mm Tool holder W2 Number of tools: 12 Cylindrical tool shank according to DIN 69880: 40 × 63 mm Swinging diameter over compound slide: 355 mm MACHINE DETAILS Gbedpfx Alsz Im U Sj Ueu Control system: TX8H EQUIPMENT Tool holder W2 as an optional extra.

Condition: good (used), Hwacheon HI Eco 31A CNC Lathe, C Axis & Live Tools, Serial Number 1053444L45, Year 1998, Swarf Conveyor, Foot Pedal, Fanuc CNC Control, 2 Jaw & 3 Jaw Power Chucks, Tool Arm, Tailstock, 10 Station Turret, Manuals, Toolholders, Transformer Gsdsz N A Avopfx Al Ujbu

Condition: good (used), Year of construction: 2003, functionality: fully functional, turning length: 650 mm, turning diameter: 250 mm, spindle bore: 65 mm, spindle speed (max.): 5,000 rpm, CNC lathe Gildemeister Twin 65Y RG2 Year of manufacture: 2003 Control system: Siemens 840D Type: CNC twin-spindle turning center Main/counter spindle: Yes Turret: 2 × 12 stations Tool holder: VDI 30 Driven tools: Yes Y-axis: Yes (upper turret) Gbodpozl Dy Nofx Al Uou C-axes: Main and counter spindle Working area Characteristic Value Max. turning diameter: 250 mm Max. turning length: 650 mm Max. turning diameter over the bed: approx. 340 mm Bar passage: 65 mm Main spindle Characteristic Value Speed: 20–5,000 min⁻¹ Power: 35 kW Torque: 370 Nm C-axis: 0.001° Counter spindle Characteristic Value Speed: 20–5,000 min⁻¹ Power: 35 kW Torque: up to 370 Nm Bar passage: 65 mm C-axis: 0.001° Travel paths Axis Value X1: 300 mm Z1: 650 mm Y: 80 mm (±40 mm) X2: 180 mm Z2: 650 mm Tool turret Number of stations: 12 + 12 Tool holder: VDI 30 Driven tools: 4,000 min⁻¹ Power of tool drive: 11 kW Torque of tool drive: 28 Nm Chip conveyor High-pressure pump Bar loader magazine, manufacturer IRCO, type SiMag 42

Condition: ready for operation (used), Year of construction: 2018, operating hours: 4,193 h, functionality: fully functional, machine/vehicle number: 71, total length: 13,000 mm, total width: 5,700 mm, total height: 4,300 mm, overall weight: 35,000 kg, hopper volume: 5,000 l, rotational speed (max.): 45 rpm, rotational speed (min.): 45 rpm, power: 404.52 kW (549.99 HP), year of last overhaul: 2024, The machine is available immediately + a second set of shafts is included!!! -Year of manufacture: 2018 -In July 2024, new hydraulic pumps and motors were installed at 3,014 operating hours. The entire hydraulic system was converted from Danfoss to Bosch, including an additional oil cooler. Currently: 1,179 hours of operation with the new pumps. The cost of the conversion was €67,000. Service: Company Kurz (2,516 hours) Service: Engine oil + filter & fuel filter (July 31, 2024, at 3,111 hours) Service: Engine oil + filter & fuel filter (May 8, 2025, at 3,772 hours) Service: Engine oil + filter & fuel filter (November 6, 2025, at 4,106 hours) Gbodpfxoz Rmwms Al Uju -Decommissioned on March 27, 2026 -Operating hours in March 2026: 4,193 hours -A second set of shafts is included.

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 180 mm turning dia. over face-slide: 75 mm turning length: 325 mm facing movement (x-axis): 56 mm longitudinal traverse (z-axis): 176 mm control: FANUC 21T revolution per minute: 50 - 3000 U/min external spindle dia. in forward position: 50 mm feed force Z - max.: 3000 N Gjdpfx Aoy Emfqjl Ujbu spindle bore: 30 mm Main spindle capacity: max. 3,7 KW kW electrics - voltage/frequency: 400 / 50 -60 V/Hz Weight approx.: 1,0 t dimension machine approx.LxWxH: 2,2 x 1,0 x1,62 m The EMCO TURN 325 is a universal CNC/conventional lathe from the EMCO Group (Austria). It is positioned in the mid-range performance and size segment and is frequently used in training, workshops, and production. It is particularly designed for the precision machining of small parts, shafts, and chuck components. Automatic chuck Interface for bar feeder available Various accessories *

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 180 mm turning dia. over face-slide: 75 mm turning length: 325 mm facing movement (x-axis): 56 mm longitudinal traverse (z-axis): 176 mm control: Fanuc 21T range of revolution per miute: 20 - 6300 U/min external spindle dia. in forward position: 50 mm feed force Z - max.: 3000 N spindle bore: 30 mm Main spindle capacity: max. 3,7 kW electrics - voltage/frequency: 400 / 50- 60 V/Hz Weight approx.: 1,0 t Gbedey Emfwepfx Al Uju dimension machine approx.LxWxH: 2,2 x 1,0 x 1,62 m The EMCO TURN 325 is a universal CNC/conventional lathe from the EMCO Group (Austria). It is positioned in the mid-range performance and size segment and is frequently used in training, workshops, and production. It is particularly designed for the precision machining of small parts, shafts, and chuck components. Automatic chuck Interface for bar feeder available Various accessories *

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, spindle speed (max.): 6,000 rpm, bar passage: 65 mm, Equipment: bar feeder, chip conveyor, TECHNICAL DETAILS Tool turret Number of turrets: 3 Tool holder: VDI 25 W-gear Main and counter spindle Main and counter spindle speed: up to 6,000 rpm Bar diameter: 65 mm MACHINE DETAILS Coolant tank: 600 l Coolant pressure: 8 / 18 bar EQUIPMENT Gantry removal device Hainbuch HS Axzug / GS Axfix Chip conveyor Coolant tank with strainer basket Coolant pump Coolant cooling unit FMB Turbo 10-65, 3-meter bar feeder Gsdpfx Alsz Ibf Ee Usbu

Condition: good (used), Year of construction: 2012, functionality: fully functional, CNC control Haas C-axis driven tools 12-fold revolver hydraulic 3-jaw chuck Tool Eye chip conveyor coolant device without tailstock Technische Daten / technical details: max. Drehlänge / max. turning lenght 660 mm Gjdpfxsz Rk Trj Al Uebu max. Drehdurchmesser / max. turning diameter 533 mm Umlaufdurchmesser über Bett / rotary diameter over bed 806 mm Drehzahl Spindel / spindle speed 3400 UpM /rpm Anzahl Revolverwerkzeugplätze / number of places in revolver 12 fach /fold Eilgang Z, X / rapid feed Z, X 24 m/min Antriebsleistung Spindel / drive capacity spindle 22,4 kW Gewicht der Maschine ca. / weight ca. 4100 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 1986, Hollow Spindle Oil Country Lathe SARO SBF 710X2000 Made in Romania Year of manufacture: 1986 Main technical data: - Max. diameter passing through main spindle: 263.3mm - Max. swing over guideways: 710mm - Max. swing over cross slide: 400mm - Max. swing in gap: 950mm - Length between centres: 2000mm - Main spindle speed range: 4 – 500 rpm Gbjdpfx Aleumtbrj Uju - Main motor power: 22 KW - Machine weight ab. 6,3ton The machine is in good condition. The electric equipment was changed with new one. For more information please contact us.

Condition: excellent (used), XYZ SLX 425 x 1.25m CNC Lathe Year 2016 Serial number L769 ProtoTRAK SLX Distance between centres 1,250 mm Maximum cutting length 1,080 mm Swing over bed 480 mm Swing over cross slide 257 mm Swing in gap 700 mm Gap in front of faceplate 170 mm Cross slide travel 230 mm Spindle bore 80 mm Spindle nose D1-8 Camlock Spindle motor 7.5 kW / 10 hp Godpfx Asz N Ambol Uobu Spindle speed range 25–2,500 rpm in 3 ranges Tailstock quill travel 160 mm Tailstock taper No. 5 Morse taper Tailstock quill diameter 75 mm Bed width 370 mm

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, spindle speed (max.): 5,000 rpm, controller model: INDEX C200-4, TECHNICAL DETAILS Main Spindle Spindle bore with collet clamping: 65 mm Spindle diameter in the front bearing: 100 mm Speed: max. 5,000 rpm Spindle nose according to ISO 702/1: Size 5 Torque at 100%: max. 62/95 Nm Power at 100%: max. 13/20 kW Turret 1 Number of tools: 8 Tool system according to DIN 69 880: 25 mm Indexing time for 1 station: 0.2 s Cross Slide 1 XZ Slide travel X-axis: 90 mm Slide travel Z-axis: 280 mm Godpfxoz Im Uro Al Ujbu Feed force X-axis: 5,500 N Feed force Z-axis: 5,500 N Rapid traverse X-axis: 24 m/min Rapid traverse Z-axis: 24 m/min Resolution X-axis: 0.0005 mm Resolution Z-axis: 0.001 mm Turret 2 Number of tools: 6 Indexing time for 1 station: 0.25 s Cross Slide 2 XZ Slide travel X-axis: 81 mm Slide travel Z-axis: 80 mm Feed force X-axis: 8,300 N Feed force Z-axis: 5,500 N Rapid traverse X-axis: 16 m/min Rapid traverse Z-axis: 24 m/min Resolution X-axis: 0.0005 mm Resolution Z-axis: 0.001 mm Driven Tools Speed: max. 6,000 rpm Torque: max. 8 Nm Tool holder bore: 25.4 mm MACHINE DETAILS Control system: INDEX C200-4 Correction accuracy: 0.001 mm Input accuracy: 0.001 mm Output accuracy: 0.001 mm Coolant system Pump capacity: 60 l/min at 5.5 bar Pump capacity: 20 l/min at 20 bar Filling volume: approx. 210 l Hydraulics Delivery rate: 19 l/min System pressure: 90 bar Filling volume: 50 l Dimensions & Weight Footprint: 3,708 (2,495) × 1,240 mm Height: 1,750 mm Floor space requirement without material handling: 3,708 (2,495) × 1,890 mm Weight: approx. 2,500 kg Three-phase connection: 400 V, 50/60 Hz Connected power: 20–45 kVA Protection of the mains supply line: 35–80 A EQUIPMENT

Condition: used, Year of construction: 1997, CNC Turning Center VDF Boehringer VDF 250 Cm (NO TAILSTOCK) General Manufacturer: VDF Boehringer Model: VDF 250 Cm Type: CNC slant bed turning center, chuck work Year: 1997 Serial no.: 1114.3705-24 Control: Siemens Sinumerik 840C Location: Korschenbroich, Germany Working area Swing over bed: 550 mm Swing over cross slide: 480 mm Max. turning length: 1,000 mm Tailstock: none (chuck work only) Main spindle Spindle nose: size 8, DIN 55026 Spindle bore: 103 mm Max. speed: 4,500 rpm C-axis: yes Axes X travel: 405 mm Z travel: 1,099 mm Rapid traverse: 10 m/min Feed range: 0.1 to 10,000 mm/min Gbjdsz Rnrrspfx Al Uou Turret 12 stations, VDI 50 (DIN 69880) Driven tools: yes, up to 2,500 rpm, 5.4 kW Driven tool torque: 25 Nm (standard), 100 Nm (low range) Clamping Hydraulic power chuck, special swivel chuck (Sonderschwenkfutter) Full hydraulic clamping cylinder Equipment Coolant system: 600 l tank, 5.5 bar, 60 l/min Chip conveyor: right-hand discharge Hydraulic unit: Hydrokraft Control cabinet: Rittal, with cooling unit Oil mist extractor: yes Pivoting operator panel Electrical 400 V, 3 phase, 50 Hz Main fuse: 125 A Operating current: 100 A Total connected load: approx. 50 kW Dimensions and weight Approx. 5,400 x 3,200 x 2,400 mm (L x W x H) Weight: approx. 10,500 kg Points to check before sending: Weight. The other listing says about 11,000 kg. I used 10,500 kg because that is what is written on the machine (“10,5 to.”). Chuck make. The listing names a Forkardt chuck. The marking on the chuck in your second photo looked like it could be Röhm, so it’s worth a quick look. resale Chip conveyor. It is not visible in the photos. Confirm it is with the machine. Control model. The 840C comes from the listing only. The screen photo doesn’t show it clearly.

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Okuma OSP-P300L CNC Control 8" 3-Jaw Chuck Expanding Mandrel Turret Tooling Gantry Loader Gbedpfx Aortrlzjl Usu Pendant Controller Chip Auger Stack Light

Condition: good (used), Year of construction: 1975, turning length 1000 mm turning diameter over bed 430 mm turning diameter over slide rest 235 mm spindle turning speed range 11.2 - 2.000 U/min spindle bore 56.0 mm morse taper 4 MK quill stroke 135 mm bed width 333 mm spindle taper DIN 55022 Gr. 6 total power requirement 7.75 kW weight of the machine ca. 1950 kg From a maintenance workshop Good condition (!!) Features: - Heavy-duty, robust conventional lead/feed screw machine Gbedjz I Uckopfx Al Ueu - 3-jaw chuck, Ø 250 mm, including replacement jaws - "RSF Elektronik" digital display Type Z735 - MULTIFIX tool holder, with 5 inserts - "FINN SAFETY" foldable chuck guard Type SPS 400 - Sliding tailstock * Includes RÖHM rotating center point - Freely adjustable machine lamp - 1x chuck key - Chip guard - Sliding bed stop - Coolant system with drip pan

Condition: new, functionality: fully functional, power: 18.5 kW (25.15 HP), color: other, Year of construction: 2026, *All of our products are made with care and covered for 1 year warranty! *Installation and Operator Training FREE FABO Concrete Mixers; single shaft, twin shaft and planet-type models are produced in three different models and different capacities. The durable and long-life wearing plates, reinforced mixing arms and paddles, has been projected by our engineers to suit every need and capacity. Our mixers have a significant market share both at home and abroad with the price advantage brought by mass production, short delivery time, quality manufacturing and spare part supply guarantee. Technical details:  Type: Twinshaft mixer (TWS 01)  Wet concrete capacity: 1 m3  Dimensions (length x width x height): 1700 x 2900 x 2000 mm Gbjdozar I Sepfx Al Uou  Feeding capacity: 1500 lt  Fresh concrete capacity: 1250 lt  Compacted concrete capacity: 1000 lt  Motor power: 2 x 18.5 kW  Hydraulic discharge gate  Automatic lubrication FOR FURTHER INFORMATION PLEASE FEEL FREE TO CALL US!!!

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, CATALOG NUMBER 7563 Technical data: - track width 340mm - roller width 360mm - disc bore diameter 70mm - max disc diameter 315mm - max cutting height 180mm * from above - feed roller, toothed, pneumatically pressed - 2 rows of ejectors - 3 sliding, smooth pressure rollers - ejectors - roller with saws - 3 sliding, smooth pressure rollers - ejectors * from below - feed roller, toothed - track - roller with saws - track - stepless feed rate adjustment via frequency inverter - main motor 2x55kW - feed motor 4kW - electric lifting of the upper body up/down - electric adjustment of the rollers with saws - central lubrication - diameter of the dust extraction nozzle 2x150mm - dimensions L/W/H 2800x2400x1900mm - weight approx. 5000kg ADVANTAGES – Made in Italy – Two-roller Gbsdpfezxqtvsx Al Usu – Ideal for large components – Multi-blade saw, used, very good condition Net price: 145900 PLN Net price: 33930 EUR, depending on the exchange rate of 4.3 EUR (Prices may change due to higher fluctuations)

Condition: excellent (used), Year of construction: 2020, 2020 Haas ST-25 CNC Slant Bed Lathe & Tooling Package Gbjdpsz Rqmrofx Al Uou Haas Autogrip 3H-H12 Ø250mm 3 Jaw Power Chuck. Maximum Swing Ø806mm. Maximum Swing Over Cross Slide Ø527mm. Maximum Cutting (Varies With Turret) Ø381mm. Bar Capacity Ø76mm. Axis Traverses 'X'=236mm, 'Z'=527mm. Rapid Traverses 'X'=24m/min, 'Z'=24m/min. Spindle Bore Ø117.3mm. Maximum Spindle Speed 3,400rpm (22.4kW Motor). Spindle Nose A2-6. 12 Station Turret. Power On Hours 1,979. S/No. 3119435 (2020). With Coolant System (Tank Capacity 208L), Marposs Tool Setting Arm, Tailstock, Footswitches, Signal Tower, Tooling Package (Turning Tools, Jaws, Collets & coolant Fixings) & Manual. Machine Foot Print W3,630 x D2,290 x H2,340mm. Weight 4,536kg.

Condition: good (used), Year of construction: 2016, operating hours: 23,500 h, machine/vehicle number: 8107000021B, spindle bore: 32 mm, spindle speed (max.): 8,500 rpm, overall weight: 4,300 kg, total length: 7,500 mm, total height: 2,500 mm, total width: 1,600 mm, number of spindles: 2, Equipment: documentation/manual, DMG MORI GILDEMEISTER SPRINT 32/5 – Short/Long Turning Center Well-maintained machine, low operating hours, including IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016, as well as conversion kit to long turning center (Swisstype kit) for short and long turning on one machine. Delivery conditions: Free on truck. Location: 58332 Schwelm Availability: Immediate - by arrangement NOTE: The machine must be picked up on a fixed date in mid/late October 2026; the exact date will be provided in advance! Payment terms: Payment in advance - by bank transfer. Technical data: Control: FANUC 32i MB Operating hours recorded: 25,263 Spindle hours recorded: 22,772 MAIN SPINDLE DATA: Max. turning diameter: 32 mm (bore for draw tube: 38 mm) Stroke Z1: 100 mm Max. speed: 8,500 RPM Drive power S1: 5.5 kW Gbodpfszxhdljx Al Ueu COUNTER SPINDLE DATA: Max. turning diameter: 32 mm (bore for draw tube: 38 mm) Stroke Z2: 200 mm Max. speed: 8,500 RPM Drive power S1: 2.2 kW AXIS DATA X1: Travel: 70 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² AXIS DATA Y1: Travel: 405 mm Max. speed: 30 m/min Max. acceleration: 5 m/s² AXIS DATA X2: Travel: 300 mm Max. speed: 40 m/min Max. acceleration: 5 m/s² TOOL HOLDER DATA – SLIDE 1: Diameter of tool holder: 25 mm Number of fixed tools for external machining: 6 Tool holder size: 16 × 16 mm Number of driven tools: 4 Collet type: ESX20 TOOL HOLDER DATA – SLIDE 2: Number of fixed tools for internal machining: 4 Diameter of tool holder: 25 mm Scope of supply: IEMCA BOSS 338/32 HD bar feeder (up to 3,200 mm bar length), year of manufacture 2016 Chip conveyor Available manuals Accessories as shown in the pictures Dimensions & weights: Installation dimensions L x W x H approx.: 7500 x 1600 x 2500 mm Weight approx.: 4300 kg Attention: Disc damaged! If you have any questions or would like to arrange a viewing, please do not hesitate to contact us! Additional notes: ►If desired, we can offer transport to the destination. ►The quoted price is net plus VAT. ►The goods are sold excluding any warranty. ►Technical data is without guarantee. ►Subject to prior sale. ❗The sale of the goods is exclusively to business customers❗

Condition: used, Year of construction: 2017, functionality: limited functionality, machine/vehicle number: 1950, turning diameter over cross slide: 225 mm, turning length: 425 mm, turning diameter: 320 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 165 mm, travel distance Z-axis: 400 mm, spindle motor power: 7,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, total height: 1,729 mm, total length: 3,255 mm, total width: 2,612 mm, quill diameter: 80 mm, quill stroke: 100 mm, type of input current: three-phase, For sale is a SAEILO ACE 12+ CNC turning center, manufactured in 2017 and first commissioned in July 2018. It includes a BOSS 552 bar feeder with 32 tool positions, manufactured in 2018. The machine is based on the ACE Designers Jobber LM Elite and is equipped with a FANUC Series 0i-TF control. The machine number is 1950. The machine is currently connected and can be inspected while powered on. It is in used condition with typical signs of wear from industrial use. The scope of delivery includes an IEMCA Boss 552-HD heavy-duty bar feeder, type 32 LL, manufactured in 2018, serial number 021835GA03. The bar feeder weighs approximately 830 kg, operates on 400 V / 50 Hz, and requires 6 bar of compressed air. Technical data of the machine: max. machining diameter 320 mm, swing over bed 500 mm, swing over slide 225 mm, distance between centers 425 mm, X-axis travel 165 mm, Z-axis travel 400 mm, spindle speed up to 5,000 rpm, 8 tool stations, tool cross-section 25 x 25 mm, rapid traverse X/Z 30 m/min, and a machine weight of approximately 4,000 kg. Electrical data: 380/400 V AC, 3-phase, 50 Hz, 24 V DC control voltage, 40 A fuse, 23/22 A rated current, and 15 kVA connection power. Gjdpfezl D Ruox Al Uobu Important note: The measuring arm is currently not functioning. Other functions can be tested during an on-site inspection while the machine is powered on. The machine is located in Bocholt. Inspection and pickup are possible by arrangement. Transport and loading are the responsibility of the buyer.
