Used Milling Spindle for sale (16,879)

Condition: used, Year of construction: 2000, x-travel 6000 mm Isdpfx Aoxmaqyecqjba y-travel 1600 mm z-travel 1300 mm control FIDIA C20 /4H-SB tool taper SK50 spindle turning speed range 22 - 4000 U/min SHW – UFZ5 Year of manufacture: 2000 Specifications X-axis 6000 mm Y-axis 1600 mm (stroke with vertical head rotated 1900 mm) Z-axis 1300 mm Orthogonal head 2 axes, indexed 1° Automatically swivelling milling head holder (rear) 360x1 degree Automatically swivelling milling head holder (front) 180x1 degree Control: Fidia - C20 / 4H-SB SK 50 - DIN 69871 Infinitely variable feed range; X-axis: 2–12,000 mm/min. Y-axis: 2–18,000 mm/min. Z-axis: 2–18,000 mm/min. Rapid traverse; X-axis: 12,000 mm/min. Y-axis: 18,000 mm/min. Z-axis: 18,000 mm/min. Spindle/auto. Milling head: Speed 22 - 4,000 rpm Torque max. 1180 Nm Total current load: approx. 50 kVA/80 A. Without clamping plate Without chip conveyor

Condition: used, Year of construction: 1999, x-travel 12000 mm y-travel 3600 mm z-travel 1500 mm spindle turning speed range 3000 U/min Control: Heidenhain iTNC430 Milling head 2 axes, indexed 2.5° Vertical (Y-axis): 3600 mm Transverse (Z-axis): 1500 mm Longitudinal (X-axis): 12,000 mm Guide rail length: 14,700 mm Guide rail width: 1400 mm Lowest milling position of the spindle nose measured from the floor (head horizontal): 855 mm Low column design 870 x 900 x 2,625 mm: 3,000 kg High stand design 870x900x3,025 mm: 3,500 kg Motor power: 37 kW Iedexwdygjpfx Acqjba Mounting: ISO 50/ DIN 69871-A Speeds: 11.7:231:3000 rpm Feed range: 2:2500 mm/min Rapid traverse X-axis: 12000 mm/min Z-Y axis: 15000 mm/min Feed motor power X-axis: 55 Nm Z-axis: 37 Nm Y-axis: 37 Nm Accuracy Positioning accuracy: 0.025 mm Repeatability: 0.015 mm Weight: approx. 42,000 kg Air supply to the machine: 300 L/min at 4.5 bar NOTE: The clamping plates and chip conveyors are not included in the scope of delivery. However, we can offer you both used and new clamping plates and chip conveyors on request.

Condition: used, diameter / mm weight / kg Type / 0 Iodpfxezcgf Ro Acqsba

Condition: used, inner taper of milling spindel / collet diameter / Ibedpfx Acezcq H Eeqoa turning speed range / U/min

Condition: used, diameter / mm Iodpey Supkefx Acqoba weight / kg Type / 0

Year of construction: 1998, condition: used, x-travel // mm y-travel / mm z-travel // mm Ibedeig A Erepfx Acqsa total power requirement / kW weight of the machine ca. 950 KG

Condition: not inspected (used), x-travel 850 mm y-travel 440 mm z-travel / mm Iodpfxsud Illo Acqsba Control TNC 355C

Condition: used, inner taper of milling spindel / collet diameter / Ijdol Ichvopfx Acqsba turning speed range / U/min

Condition: used, Year of construction: 1998, x-travel 6000 mm y-travel 4000 mm z-travel 1250 mm w-axis 1500 mm Control Fidia max. workpiece weight 60000 kg Ibedpou I E Emsfx Acqea Control unit for tool magazine/tool changer Siemens turning speeds 6,3 - 4000 U/min surface area 2500 x 4500 mm 48 St. tool taper SK50 daylight between the side columns 3700 mm rapid traverse 30000 m/min total power requirement 63 kW weight of the machine ca. 150 t required space 16,8 x 10,3 x 7,9 m

Condition: used, inner taper of milling spindel / collet diameter / turning speed range / U/min Ibodpfxjzcq Hro Acqea

Condition: used, inner taper of milling spindel / collet diameter / Iodpfxjhprk Ho Acqoba turning speed range / U/min

Condition: used, inner taper of milling spindel / Iodpfx Aehwt Elecqeba collet diameter / turning speed range 1500 U/min

Condition: good (used), Year of construction: 1998, functionality: fully functional, Siemens 840D control system, two turrets, all stations are powered, counter spindle, spindle bore 60mm, chip conveyor, FMB magazine loader, fire extinguishing system (as the machine operates with cutting fluid), Ibjdpfxozu Awxs Acqea extensive accessories.

Condition: ready for operation (used), Fanuc A06B-6078-H206 #H500 Spindle Amplifier Module, Version: C, Serial Number: EA8708221, used, in good condition, 100% functional, scope of supply as shown in the photos. Iodpfx Acjzuiggeqsba

Condition: ready for operation (used), Fanuc A06B-6078-H206 # H500 spindle amplifier module Version: C SN: EA8307634, used, normal signs of use, 100% functional, scope of delivery as shown in photos. Iedpfx Aox Eq Uiecqsba

Condition: excellent (used), Year of construction: 2015, FANUC 31i-B control C-axis on both spindles Milling drive on the upper turret Milling drive on the lower turret Travel range – Y1 axis: 80 (+/- 40) mm Travel range – Y2 axis: 65 (+/- 32.5) mm Swivel range of B-axis: +/- 91° Incline angle: 90° MAIN SPINDLE Bar diameter: 42 mm Spindle diameter: 51 mm Spindle speed: 6,000 rpm Drive power – spindle motor max./continuous: 11 / 7.5 kW Ibsdpfxezum Tdj Acqsa TAILSTOCK SPINDLE Bar diameter: 42 mm Spindle diameter: 51 mm Spindle speed: 6,000 rpm Drive power – spindle motor max./continuous: 11 / 7.5 kW TOOL TURRET Tool magazine positions, upper turret: 12 / 24 + 6 Tool magazine positions, lower turret: 12 / 24 INCLUDED Inclined bed filter system Hinged belt chip conveyor, discharge to the right Coolant system Material collection tray

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Ibsdpfx Aozum Aljcqja Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: good (used), Year of construction: 1995, functionality: fully functional, Control system: Heidenhain iTNC 530 Operating hours: 54631 h X-axis 3500 mm Y-axis 1000 mm Z-axis 900 mm Drive power 30 kW Speed ??range 20–3800 rpm Rapid traverse 15 m/min Feed rate 4 m/min Clamping surface 2x 1600 x 960 mm Max. table load 2 x 4000 kg Machine weight (approx.) 21 t Machine dimensions (WxDxH) 10770 x 4100 x 3150 mm Technical data / Accessories Universal bed-type milling and boring machine Milling head position: Vertical, horizontal (top, center, left, right) Heidenhain TS 120 3D touch probe Ibodozufi Rjpfx Acqja Kekeisen TW 32 drum-type tool changer Knoll hinged-belt chip conveyor

Condition: used, Year of construction: 2001, turning diameter 390 mm centre distance 1850 mm swing diameter 610 mm control SINUMERIK 840D turning speeds 20-4000 U/min spindle bore 79 mm bar capacity 65 mm weight of the machine ca. 18000 kg total power requirement 33 kW Control System Siemens Sinumerik 840D Bed Design: 4-rail bed Guideways: Roller guides Working Area Maximum swing diameter: 610 mm Standard turning diameter: 390 mm Distance between spindles: 1850 mm Traverse travel cross/longitudinal – Slide 1: 605 / 1470 mm Y-axis – Slide 1: 210 mm B-axis – Slide 1: 240° Traverse travel cross/longitudinal – Slide 2: 227 / 1440 mm Longitudinal travel – Slide 3: 1460 mm Turning and Milling Spindle – Slide 1 Number of tools: 80 Tool holder: HSK-A63 Max. spindle speed: 12,000 rpm Max. drive power 40/100% duty cycle: 10 / 15 kW Indexing unit: 1.0° Clamping torque (locking): 500 Nm Spindle 1 – Left Max. bar capacity: 65 mm Spindle nose faceplate: 220 h5 Spindle bore: 79 mm Internal draw tube: 68 mm Front bearing diameter: 140 mm Spindle 2 – Right Max. bar capacity: 65 mm Spindle nose faceplate: 220 h5 Spindle bore: 79 mm Internal draw tube: 68 mm Front bearing diameter: 140 mm Main Drive 1 and 2 – Left / Right Max. drive power 40/100% duty cycle: 25 / 33 kW Speed range: 20 – 4000 rpm Rated speed: 700 rpm Max. torque 40/100% duty cycle: 840 / 460 Nm Drive type / design: AC / 1 Iodpfx Acsx Tu Suoqoba Design: Integrated spindle motor C-axis speed (rapid traverse): 100 rpm C-axis torque (holding torque): 350 Nm C-axis indexing accuracy: 0.025° Slide 1 Rapid traverse speed X/Ys/Z: 46 / 24 / 60 m/min Feed force X/Ys/Z: 11 / 16 / 11 kN Position resolution X/Y/Z: 0.001 mm Ball screw X (d × p): Ø40 × 15 mm Ball screw Ys (d × p): Ø40 × 10 mm Ball screw Z (d × p): Ø50 × 25 mm Slide 2 Rapid traverse speed X/Z: 24 / 60 m/min Feed force X/Z: 7.5 / 11 kN Position resolution X/Z: 0.001 mm Ball screw X (d × p): Ø32 × 15 mm Ball screw Z (d × p): Ø50 × 25 mm Slide 3 Rapid traverse speed Z: 60 m/min Feed force Z: 12 kN Position resolution Z: 0.001 mm Ball screw Z (d × p): Ø50 × 25 mm Tool Changer – Turret Head Gripper type: Double gripper Control type: Cam-controlled Tool change time G1/G2: 1.3 / 2.6 s Tool Spindle Speed 4000 rpm Coolant Unit 180 liters

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or Iodpfx Aezubyrocqjba *

Condition: used, Radial drilling machine REFORM, type RB 50-16 Year of manufacture: 2002 Drilling capacity in steel: max. 50 mm Tool holder: MK 5 Nominal overhang: 1600 mm Maximum overhang of the spindle to the column: 1600 mm Ibjdpfx Ajzupamjcqja Maximum overhang of the spindle to the column base: 1500 mm Minimum overhang of the spindle to the column: 340 mm Minimum overhang of the spindle to the column base: 240 mm Travel of the drilling head: 1260 mm Height adjustment of the arm: 600 mm Distance between clamping surface and drilling quill: max. 1100 mm Spindle speed: 25-2000 rpm Quill stroke: 300 mm Quill diameter: 80 mm Feed rate: 0.04 to 3.2 mm/rev (16 steps) Clamping surface of the base plate: 1750 x 980 mm (1650 x 840 mm) Column diameter: 350 mm Motor power, spindle drive: 4 kW Mains connection: 400 volts, 50 Hz - Spindle speed controlled via 16 gear stages with speed preselection and hydraulic gear shifting - Right and left rotation of the drilling spindle - Automatic feed via 16 gear stages with feed rate preselection and hydraulic gear shifting - Electro-mechanical height adjustment of the arm, with hydro-mechanical arm clamping - Hydro-mechanical central clamping of the head and column via push buttons - Coolant system in the machine base Machine height with drilling head at the top: max. 2840 mm Space requirement L x W x H: 2400 x 1000 x 2650 mm Weight: 3.5 tons Good condition

Condition: good (used), CMZ brand CNC lathe, TX66 Y2 Quattro model, year 2012, with powered tooling on both turrets, Y-axis... Ibsdpfezcu Hisx Acqea

Condition: good (used), Year of construction: 1971, Model making milling machine, universal model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine, model making milling machine, vertical milling machine -Manufacturer: Steinel, vertical milling machine type SV 4 -Clamping table: 740 x 200 mm -Cross table: 620 x 130 mm -Travel: X/Y/Z 340/100/300 mm -Spindle holder: MK2 Ibedot E D D Ispfx Acqea -Speed: 112 - 2240 rpm right/left rotation -Feed: 0.10 - 0.71 mm/min -Quill stroke: 100 mm -Coolant system -Dimensions: 1000/950/H1830 mm -Weight: 650 kg

Condition: used, Year of construction: 1968, max. wheel diameter 120 mm gear width 130 mm max. module 2 no. of teeth to be hobbed 6-325 Z min/max. spiral pitch 20-5000 mm hobbing length 130 mm weight of the machine ca. 860 kg Universal hobbing machine MIKRON 102.05 MPS > External surface gearing Technical data: Maximum millable workpiece diameter: 120 mm Maximum millable length: 130 mm Maximum number of modules: 2 Number of millable teeth: 6-399 (with gear ratio 80:5) Pitch of the spirals: 20 - 5000 mm Pitch angle of the spirals (left or right): 0 - 90° 14 milling cutter revolutions (50c/s): 140 - 1870 rpm 13 Axial feeds: 0.05 - 3.0 mm/w.p.rev. Main motor speed: 1500 rpm Main motor power: 1.1 kW Connected load: 3 x 380 VAC Frequency: 50 Hz Ibsdpfxjzuplij Acqoa Control unit: Omron CP1L Machine dimensions L/W/H: 1030x800x1520 mm Weight of the machine: 880 kg

Condition: excellent (used), DOOSAN PUMA 3100 XLY CNC LATHE ONLY 2163 RUN TIME HOURS !!!!! UPGRADED FANUC I CONTROL 305 MM HYD CHUCK 420 MM TURNING DIA 2125 MM TURNING LENGTH MAX SWING 850 MM MAX SWING OVER CROSS SLIDE 670 MM X TRAVEL 293 / Y TRAVEL 130 MM / Z TRAVEL 2190 MM FULL C AXIS AND Y AXIS HYD STEADY - SMW SLU-X-4-MS ( CAPACITY 30 - 245 ) MAX SPINDLE SPEED 2800 TOOL PROBING DRIVEN TOOLS - 2+2 + STATIC HOLDERS SPINDLE POWER 35 HP YEAR 2012 THIS MACHINE HAS BEEN ONE OWNER ONE OPERATOR SINCE NEW - NEVER REQUIRED A REALIGNMENT - IMPECCIBLE CONDITION THROUGHOUT LOCATION NORTHERN IRELAND Ibedezumadspfx Acqoa LOADING - FREE TRANSPORT CAN BE PRICED - PLEASE GIVE FULL ADDRESS
