Used Mill Turn for sale (16,265)

Condition: good (used), Year of construction: 2017, Standard turning diameter 150mm, maximum cutting diameter 255mm, maximum cutting length 685mm , Bar capacity main spindle 51mm, spindle speed 5,000rpm, sub-spindle 5,000 rpm, C axis 0.001 degrees, 3 x turrets 24 stations, Y axis +/-45mm, milling speeds 6,000 rpm, main spindle 15kw, Fanuc 31i, swarf conveyor, barfeed unit, parts catcher Podpfx Aiozwm Hpj Djgr

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm Podpfxozw H Ruo Ai Dogr spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, Equipment: documentation/manual, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm C-axis indexing 360° Spindle nose A2-6 Pedpfszv Sfbjx Ai Dsgr Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, Year of construction: 2003, Manufactured: July 2003 (Factory ID #2) Swing over bed: approx. 680 mm (interference with front cover: approx. 454 mm) Swing over cross slide: approx. 510 mm Distance between centers: approx. 575 mm Max. turning diameter: approx. 390 mm Standard turning diameter: approx. 250 mm Max. turning length: approx. 485 mm Bar capacity: approx. 73 mm Z-axis travel: approx. 520 mm Spindle speed range: 35-3,500 rpm Spindle nose type: JIS A2-8 Through-spindle hole diameter: approx. 86 mm Spindle bearing inner diameter: approx. 130 mm Turret: 10 tool stations (12 optional), shank height for square tools approx. 25 mm, max. boring bar shank diameter approx. 50 mm, indexing time 0.2 sec Hydraulic power chuck: Kitagawa, cylinder type B-210, S/N 1875 Tailstock travel: approx. 515 mm Tailstock spindle diameter: approx. 85 mm, taper MT5 (live center) Tailstock spindle travel: approx. 120 mm Rapid traverse rate: X 18,000 mm/min, Z 24,000 mm/min Jog feedrate: X/Z 0-1,260 mm/min Spindle drive motor (30 min rating): 15/11 kW, high-output option 18.5/15 kW (as fitted per nameplate) Feed motors: X 1.0 kW, Z 3.0 kW Electrical power supply: 34 kVA (high-output specification, per nameplate; standard rating 27.4 kVA) Coolant tank capacity: approx. 205 l (front-removal option: approx. 160 l) Machine height: approx. 1,890 mm Floor space: approx. 2,380 x 1,835 mm Machine weight: approx. 4,500 kg Electrical rating (per nameplate): 3-phase, 50 Hz, 200V AC, full load current 99A, spindle motor current rating 114A, interrupting capacity 5 kA Data Accessory Tool Cabinet (Hahn & Kolb) Podpfxjzwf Dao Ai Degr Multi-drawer mobile tool cabinet with turning tool holders, inserts, clamping/chuck jaws and measuring instruments.

Condition: good (used), Year of construction: 2008, MAZAK QUICK TURN NEXUS 350-II MY x 1500 Pgodpfxezwqm Ts Ai Djr Max. swing diameter: 750 mm Max. turning diameter: 420 mm Max. turning length: 1,538 mm Max. milling speed: 4,500 rpm Max. spindle speed: 3,300 rpm The machine is equipped with: - CNC control Mazatrol Matrix - KITAGAWA 3-jaw chuck B-212, diameter 304 mm - Main spindle with bar capacity of 102 mm!!! - Tool Eye - C-axis - NC tailstock - Reinforced coolant pump - Chip conveyor - 8 pcs. fixed tool holders - 2 pcs. driven tool holders

Condition: excellent (used), Year of construction: 2024, MAZAK INTEGREX i-100H Pgjdpfxey Hwn Es Ai Djr Max. machining diameter: 600 mm Max. machining length: 590 mm Max. milling speed: 12,000 rpm Max. spindle speed: 6,000 rpm Machine is equipped with: - CNC control Mazatrol SmoothAi - Tool magazine for 74 tools - KITAGAWA 3-jaw chuck B-206, diameter 169 mm - Tool Eye - C-axis input accuracy 0.0001° - Y-axis - B-axis 0.0001° - 5-axis machining package for SmoothAi - Reinforced coolant pump 15 bar - Chip conveyor, side discharge

Condition: excellent (used), Year of construction: 2019, Sub-spindle, driven tools, Y-axis, C-axis FANUC 32i B-NT-SmartX control Turning diameter max 225 mm Turning length -910 mm Chuck Diameter -210 mm Main-spindle speeds 5'000 rpm Sub-spindle speeds 5'000 rpm Turret head 1+2: 24 positions with 12 driven positions each Barloader LNS Sprint 565 S2 Piece catching device Misc. accessories Pgedsvwkiropfx Ai Dor MARCELS MASCHINEN CH

Condition: good (used), Year of construction: 2002, Control: Siemens Sinumerik 840D Pedpfxozv Hw So Ai Djgr Center distance max.: 5000 mm Swing diameter over bed max.: 890 mm Turning diameter max.: 820 mm Spindle bore: 122 mm Spindle diameter in front bearing: 240 mm Spindle nose: A15 / DIN 55026 Main drive power: 80 kW (100% ED) / 105 kW (40% ED) Number of axes: 4 (X, Y, Z, C)C-axis: yes, max. torque 5000 Nm Tool system: Vert./Hor. head, Capto C8 (Sandvik) Milling spindle: 28 kW / 267 Nm (100% ED) Tool magazine: 100 positions, max. tool length 650 mm Travel X: -10 / +490 mm Travel Y: -130 / +300 mm Travel Z: +180 / +5038 mm Rapid traverse X / Z: 15 m/min, Y: 10 m/min Tailstock: yes, quill diameter 160 mm, taper MK 6 2 steady rests (one of them programmable) Chip conveyor and paper belt filter system Dimensions approx. (L x W x H): 16000 x 4900 x 3300 mm Weight approx.: 35.000 kg

Condition: good (used), Year of construction: 2010, functionality: fully functional, Fanuc control, spindle bore 65mm, two turrets, Y-axis, counter spindle, powered tools, chip conveyor, Psdpfx Aiezwhhho Dogr short bar magazine, accessories.

Condition: used, Year of construction: 2005, turning length: 705 mm, turning diameter: 356 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, controller model: MORI SEIKI MSX-850, TECHNICAL DETAILS Turning diameter: max. 356 mm Standard turning diameter: 275 mm Turning length: max. 705 mm Travel in X-axis: 260 mm Travel in Y-axis: ±50 mm Total travel in Y-axis: approx. 100 mm Travel in Z-axis: approx. 795 mm Rapid traverse rate X/Y/Z: 30 m/min Pgsdszwgwzjpfx Ai Djr Tool stations: 12 MACHINE DETAILS Design: SY with Y-axis Control system: MORI SEIKI MSX-850 Bar feed magazine: LNS Quick Load Servo 2 Bar length: max. approx. 1,500–1,600 mm / 63″ EQUIPMENT Tailstock Driven tools Y-axis LNS Quick Load Servo 2 bar feed magazine

Condition: used, Year of construction: 2015, Technical details: max. turning diameter: 255 mm turning length: 500 mm control: FANUC 31i manual guide swing dia.: 270 mm centre distance: 639 mm bar material dia.: 66 mm travel -x axis: Rev. 1+2:: 190 mm travel -y axis: Rev. 1+2: +- 40 mm travel -z axis: Rev. 1+2: 500 mm spindle turning speed - stepless: S1 / S2: 4000 / 5000 1/min spindle nose: A2-8 / A2-6 spindle bearing diameter: 120 / 100 mm Pgsdpjzv Tmtofx Ai Dor C-Axis: 0,001 ° Turret No.1 stations / rotary tools: 12/12 Turret No.2 stations / rotary tools: 12/12 Driven Tools: 6000 1/min rapid traverse X-axis: 16 m/min rapid traverse Y-axis: 12 m/min rapid traverse Z-axis: 20 m/min spindle drive: S1: 15/11, S2: 7,5/5,5 kW Driven Tools: 18 kW total power requirement: 65 kVA weight of the machine ca.: 9,6 t dimensions of the machine ca.: 2,85 x 2,2 x 2,05 m CNC-turning-center with 2 turrets, 2x 12-pockets (24 position) turret with 12 live-tools, Y-axis on both turrets. subspindle travel 635mm, rapid feed 30 m/min, chipconveyor, approx. ? h "machine on", approx. ?h "spindle on" *

Condition: used, Year of construction: 2006, turning length: 1,298 mm, turning diameter: 356 mm, spindle speed (max.): 4,000 rpm, controller model: MORI SEIKI MSX 850III / MAPPS III, center width: 1,250 mm, TECHNICAL DETAILS Maximum turning diameter: 1,250 mm Maximum turning length: 1,298 mm Maximum turning diameter: 356 mm Standard turning diameter: 275 mm Swinging diameter over bed: 923 mm X-axis travel: 260 mm Z-axis travel: 1,345 mm Maximum spindle speed: 4,000 rpm Spindle bore: approx. 80 mm Number of turrets: 1 Number of tool positions: 12 MACHINE DETAILS Control system: MORI SEIKI MSX 850III / MAPPS III Dimensions & Weight Dimensions (L x W x H): 5,000 × 2,300 × 2,400 mm Machine weight: 7,600 kg EQUIPMENT IRCO SIMAG loader magazine Chip conveyor Powered tools C-axis Pgsdpfx Aiezwgquo Djr Y-axis

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, Pgodezt Spnspfx Ai Dor C axis 0.001 degrees on both spindles, 24 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter, LNS barfeed unit.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Pjdpfx Aiezvx T Se Dogr Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, turning diameter: 145 mm, CNC turning machine Gildemeister Twin 42 Year of manufacture: 2004 Control system: Siemens 840D Powerline Turning diameter: 145 mm Max. bar diameter: 45 mm Spindle head: Flat flange 120 h5 Pedpfezl Dvkox Ai Dogr Chuck: 130 / 140 mm Main spindle speed: 20–7,000 min⁻¹ Main spindle power: 28 / 22 kW (40/100 % duty cycle) Main spindle torque: 180 / 140 Nm Counter spindle: Yes, same power X-axis: 220 mm Z-axis: 320 mm Y-axis: ±30 mm Rapid traverse X/Y/Z: 30 / 15 / 30 m/min Turret: 2 × 12 stations Tool holder: VDI 25 Machine weight: approx. 5,300 kg Connected power: approx. 40 kVA Design: 60° inclined bed, linear guides Chip conveyor, Bürener type SPE 63/30-250 Z60 Tool monitoring system, Artis type CTM Tailstock mounted on counter spindle slide, tailstock stroke = 230 mm Tailstock force = 300 daN Center bore MK3 Overload clutch for the X and Z axes of slides 1 and 2 Package for bar machining consisting of: Workpiece extraction device Workpieces can be automatically unloaded from both the main and counter spindles Workpiece dimensions: Ø6 – Ø65 mm, length approx. 300 mm, max. weight 3.5 kg Collet chuck for quick-change tool holders, size 42 Hainbuch Spanntop Connection for bar feed Bar loader magazine, IRCO type SiMag 42

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning diameter: 145 mm, Feature | Gildemeister Twin 42 Control system | Siemens 840D Powerline Turning diameter | 145 mm Max. bar diameter | 45 mm Spindle head | Flat flange 120 h5 Chuck | 130 / 140 mm Main spindle speed | 20–7,000 min⁻¹ Main spindle power | 28 / 22 kW (40/100 % duty cycle) Main spindle torque | 180 / 140 Nm Counter spindle | Yes, same power X-axis | 220 mm Z-axis | 320 mm Y-axis | ±30 mm Rapid traverse X/Y/Z | 30 / 15 / 30 m/min Turret | 2 × 12 stations Tool interface | VDI 25 Machine weight | approx. 5,300 kg Connected load | approx. 40 kVA Design | 60° inclined bed, linear guides Chip conveyor Bürener type SPE 63/30-250 Z60 Tool monitoring system, Artis, type CTM Tailstock mounted on the counter spindle slide, tailstock travel = 230 mm Tailstock force = 300 daN Center boring tool MK3 Overload clutch for the X and Z axes of slides 1 and 2 Package for bar machining consisting of: Workpiece retrieval device Workpieces can be automatically unloaded from both the main and counter spindle Pgodpfx Aiezl Drxe Dor Workpiece dimensions: Ø6 – Ø65 mm, length approx. 300 mm, max. weight 3.5 kg Collet chuck for quick-change tool holders, size 42, Hainbuch Spanntop Connection for bar feed Bar loader magazine, IRCO, type SiMag 42

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details turning diameter 400 mm turning length - mm control DMG Mori SLIMline z-axis ca. 750–755 mm x-axis 276 mm y-axis +/-60 mm greates pass round over bed 700 mm Pgedpfxszu Nxpj Ai Dsr Additional information The machine is in very good condition and has recently been inspected and measured by a service technician. The lathe was primarily used to manufacture turned plastic parts. CNC lathe with driven tools, C-axis, Y-axis, and counter-spindle CNC control: DMG Mori SLIMline multi-touch control (19"/Operate 4.7 on Siemens) Screen language: German/English Main spindle: A2-8 with AC motor Drive power 25.5/17 kW (100/40% duty cycle) Spindle speed 4000 rpm Hollow clamping system, max. bar capacity 80 mm Counter-spindle: A2-6 designed as a built-in motor spindle ISM 52 with hydraulic clamping device Drive power 14/13 kW (100/40% duty cycle) Spindle speed 5000 rpm 12-station servo tool turret: VDI 40 mount with 12 driven tool stations Equipment: Y-axis +/- 60 mm Direct position measuring system (X and Y axes) Bar package & interface IEMCA KID80/16 short bar loader, bar capacity 80 mm Differential pressure clamping for main spindle Chuck flushing for main spindle Reduction tube for main spindle Hainbuch SPANNTOP nova Combi G80 Axzug collet chuck Differential pressure clamping for counter-spindle Chuck flushing for counter-spindle Automatic workpiece ejector Counter-spindle with internal coolant supply for workholding flushing SMW BB-D210 hydraulic 3-jaw chuck for counter-spindle SMW BB-D250 hydraulic 3-jaw chuck High-pressure pump 12 bar Coolant spray gun bar Dual cartridge filter for coolant, filtration fineness 60 µm Manual tool measuring device in the workspace, Marposs make Tool monitoring system, Easy Tool Monitor 1.0 technology cycle Alternating Speed ??technology cycle 3D data model in STEP format DMG MORI Messenger V2 DMG MORI Netservice – client Finished part discharge conveyor Chip conveyor with right-hand discharge External electronic handwheel Tool holder package

Condition: used, Year of construction: 2004, functionality: fully functional, turning length: 1,000 mm, turning diameter over cross slide: 350 mm, TECHNICAL DATA Turning diameter: max. 465 mm Turning length: 1050 mm Diameter when turning: 680 mm Pgjdpfev Epzvox Ai Dsr Chuck diameter: 325 mm X-axis travel: 300 mm Z-axis travel: 1050 mm Control system: Fanuc Series 21I-TB Spindle speed range: Max. 3500 rpm Drive power: 33 kW Torque: max. 630 Nm Bearing diameter in the spindle: 120 mm Max. bar diameter: 90 mm Tailstock stroke: 850 mm Tool post stroke: 150 mm Rapid traverse X/Z: 30 m/min Number of tool positions: 12 positions Tool holder: VDI 40 Accessories: Chip conveyor Tool holders, chuck jaws

Condition: used, Year of construction: 2006, Victor V26-II CNC lathe; with C-axis; with driven tools; FANUC 21i-TB control; chuck: 10"; turning diameter: 520 mm; turning length: 1090 mm; spindle speed: 3,500 rpm; upper turret toolholder with 12 positions, 6 of which are driven; tool presetting device; chip conveyor; oil mist extraction. Pgsdjr E Amgepfx Ai Der

Condition: used, Year of construction: 2007, turning diameter 65 mm turning length 150 mm control Siemens 840D spindle passage 75 mm Pgsdpfx Aszdk Evsi Dor turning length 150 mm c-axis 2x 0,001 ° gripping station 65 mm speeds 5000 U/min rapid traverse 30 m/min turret (x-stations) 3x12 Number of axles 10 St. number of toolholder-holes 36 chip conveyor ja / yes kW coolant filtering unit ja / yes kW Number of working hours 35000 h total power requirement 22 kW weight of the machine ca. 9 t dimensions of the machine ca. 4,4 x 2 x 2,3 + Iemca m DMG Sprint 64 Linear CNC lathe, built in 2007, 10 axes, 2 spindles, 3 turrets with Iemca Master 880 loading magazine Accessories: a large number of tool holders in total 104 off, 24 of them are driven tool holder

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, MAIN INFORMATION Capacity and Working Area • Model: Mazak Integrex J-200 500U • Control: Mazatrol Matrix Nexus 2 • Year: 2014-05 • Serial No.: 255239 • Cutting time: 8,867 hours • Network: LAN connection • Condition: The machine is in very good technical condition with extremely high precision. • Max. turning diameter: 530 mm • Max. turning length: 500 mm • Bar capacity: 65 mm • Spindle bore: 76 mm Axis Travels • X-axis: 450 mm • Y-axis: 200 mm • Z-axis: 550 mm Spindles and Axes Main Spindle • Speed: 5,000 rpm • Power: 15 kW (increased power) • C-axis: 360° with 0.001° indexing Milling Spindle • Speed: 12,000 rpm • Tool holder: Capto C6 • Through-spindle coolant (liquid/air) B-axis • Angular range: -30° to -190° • Full indexing Tooling, Magazine and Additional Equipment • Tool magazine: 72 positions • Tailstock: MT5 Auto • Chuck: Hainbuch Ø65 collet chuck • Tool measurement: Yes (measuring arm) • Parts catcher: Yes • Chip conveyor: Mayfran • High-pressure pump: 15 bar • Bar feeder: Irco ILS-MUK-7012 Machine Condition and History • The machine is fully operational and functions as it should. • No alarms or critical faults. • Smooth movement on all axes. • Spindles run smoothly without vibration. • Linear guides and ball screws are in good condition. • Hydraulic and pneumatic systems operate normally. • Regular in-house servicing. • Lubrication system OK. • The machine is clean and well maintained. Pgsdpezwhdvsfx Ai Der Included Documentation • Photos of the machine • Video of the machine in operation • Screenshot of service history • Electrical diagrams on CD • Manuals on CD Machine Strengths • Multitasking machine with both turning and milling capabilities • Full 5-axis interpolation (C + B) • Capto C6 milling spindle with 12,000 rpm • Large machining capacity: 530 mm diameter / 500 mm length • 72 tool positions – rare and highly attractive • Through-spindle coolant (liquid/air) • Integrated robot interface (Smartshift BASE) • Irco bar feeder • Hainbuch collet chuck

Condition: excellent (used), Year of construction: 2004, MAIN INFORMATION Pgsdpfx Aszwhdcji Dsr Capacity and Working Area • Model: Mazak Integrex 200 MkIII • Control: Mazatrol PC Fusion 640 MT Pro • Year: 2004–06 • Serial No.: 169996 • Network: LAN connection • Condition: The machine is in very good technical condition and has been very well maintained. • Mainly used for machining aluminium and plastic. • Max. turning diameter: 530 mm • Max. turning length: 1,000 mm • Bar capacity: 65 mm • Spindle bore: 76 mm Axis Travels • X-axis: 580 mm • Y-axis: 160 mm • Z-axis: 1,045 mm Spindles and Axes Main Spindle • Speed: 5,000 rpm • Power: 15 kW • C-axis: 360° full interpolation Milling Spindle • Speed: 12,000 rpm • Tool holder: Capto C6 • Through-spindle coolant B-axis • Angular range: -30° to -190° • Full indexing Tooling and Magazine • Tool magazine: 40 positions • Tool measuring arm: Yes • Tailstock: MT5 Auto • Chuck: Kitagawa B-210, 10-inch 3-jaw chuck • Collet chuck: SMW AUTOBLOK KSB-MB-A60 • Smartshift BASE quick coupling for robot • Parts catcher: Yes • Parts collector: Yes • Chip conveyor: Mayfran • Bar feeder: STC Super 65 Included Documentation • Photos of the machine • Video of the machine in operation • Service history (photo) • Manuals • Electrical diagrams • Complete machine manuals • Complete programming manuals • Complete maintenance manuals Machine Strengths • Multitasking machine with both turning and milling capabilities • Full 5-axis interpolation (C + B) • Capto C6 milling spindle with 12,000 rpm • Large machining capacity: 530 mm diameter / 1,000 mm length • 40 tool positions • Through-spindle coolant • Integrated robot interface (Smartshift BASE) • STC Super 65 bar feeder

Condition: excellent (used), Year of construction: 2013, MAIN INFORMATION Capacity and Working Area • Model: Mazak Quick Turn Smart 200 • Control: Mazatrol Smart • Year: 2013 • Serial No.: 249187 • Accumulated operating time: 11,755 hours • Cutting time: 1,561 hours • Network: LAN connection • Condition: The machine is in very good technical condition, clean, precise, and very well maintained. • Max. swing diameter: 530 mm • Max. swing over cross slide: 343 mm • Bar capacity: 65 mm • Spindle bore: 76 mm • Axis travels: X-axis: 195 mm Z-axis: 560 mm • Rapid traverse: X-axis: 30,000 mm/min Z-axis: 33,000 mm/min Spindle and Tooling • Spindle speed: 5,000 rpm • Spindle power: 15 kW • Selectable threading start position • Through-tool coolant • Tool turret: 12 positions Indexing time: 0.17 sec / 1 step • Tailstock: MT5 Auto • Tool measuring arm: Yes • Parts catcher: Yes • Robot interface: Additional M-function (1 pair) • Smartshift BASE quick coupling: Yes • Chuck: SMW AUTOBLOK collet chuck Automation and Additional Equipment Integrated Automation Solution with UR5e • Model: Universal Robots UR5e (demo use only) • Type: Collaborative robot (cobot) • Year: 2021/01 • Condition: Fully integrated and operational with the Mazak Smart 200 • Payload: 5 kg Podpfozwhc Eex Ai Degr • Reach: 850 mm • Repeatability: ±0.03 mm • Working envelope: 2.6 m³ • Max. TCP speed: 1,000 mm/s • Joint speed: 180°/s • Robot weight: 21 kg • Mounting: Floor, ceiling, wall, or inclined • Power supply: 100–240 V AC, approx. 200 W • Controller: UR control box (e-Series) • Programming: URScript + graphical block programming • Safety: ISO 10218-1, ISO/TS 15066, PLd Cat. 3 • Fieldbus: PROFINET, EtherNet/IP, Modbus TCP • Digital I/O: 16 inputs / 16 outputs • Analog I/O: 2 inputs / 2 outputs • Tool flange: ISO 9409-1-50-4-M6 Integration with Smart 200 • Smartshift BASE quick coupling • Additional M-function (robot interface) • Pre-programmed sequences • Quick changeover between manual and robot operation • Video available showing the robot and machine in operation • Fully tested and used in production Condition Description • The machine is fully operational and functions as it should. • No alarms or critical faults. • Smooth movement on all axes. • Spindle runs smoothly without vibration. • Linear guides and ball screws are in good condition. • Hydraulic and pneumatic systems operate normally. • Regular in-house servicing. • Lubrication system OK. • The machine has been used for light production (aluminium/plastic). • Robot and machine are fully integrated and tested.

Condition: used, Year of construction: 2008, turning diameter / mm centre distance / mm swing diameter / mm Manufacturer: DMG GILDEMEISTER Model: CTX 510 eco Year of manufacture: 2008 Machine type: CNC lathe / turning center Control system: Siemens SINUMERIK 810D Powerline Max. spindle speed: 3,250 rpm Spindle speed range: approx. 500–3,250 rpm Spindle power: 33 kW at 40% duty cycle / 22 kW at 100% duty cycle Spindle torque: 630 Nm at 40% duty cycle / 420 Nm at 100% duty cycle X-axis travel: 300 mm Z-axis travel: 1,050 mm Max. turning diameter: 465 mm Max. swing / turning diameter: 680 mm Spindle bore / bar capacity: approx. 76–92 mm (depending on configuration) Front spindle diameter: 140 mm Pedpezu A Ukjfx Ai Degr Turret: 12-station Driven tools: Depending on equipment Driven tool speed: up to 4,000 rpm Driven tool power: approx. 8.4 kW Chuck: 250 mm or 315 mm Max. workpiece weight between centers: 350 kg Total power requirement: approx. 50 kVA Power supply: 400 V, 50/60 Hz Machine weight: 7,500 kg Incl. chip conveyor Note: All technical specifications are for guidance only and are subject to change. Actual machine data may vary due to different equipment variants and subsequent modifications. No warranty or guarantee is provided regarding the accuracy or completeness of the technical specifications. The specifications and actual condition of the offered machine are the sole determining factors.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Technical details turning diameter 820 mm turning length 6000 mm control Siemens Si 840 D sl max. workpiece weight between centres 4000 kg total power requirement 155 kW weight of the machine ca. 65 t dimensions of the machine ca. 16350 x 3700 x 3850 m Additional information Original purchase price in 2019: EUR 1.550.000,- Podpfx Aijzuygdo Djgr Time recording from Feb. 2025 Operating hours = 38601 h Main spindle = 1958 h Milling spindle = 1760 h CNC control Si 840D sl Working area 6000 mm Working height 1390 mm Swing diameter over bed slide/bed 820 mm X-axis travel +850 -25 mm Z-axis travel 6820 mm C-axis, smallest increment +/-0.001° Workpiece spindle Spindle head according to DIN 55026 A15 Bathing through 160 mm Front diameter Bearing 240mm 2-stage gearbox, infinitely variable programmable Drive power at 100/60% duty cycle: 78/87kW Speed ranges: 2 Speed range I: 10-501 rpm Speed range II: 10-1750 rpm Torque I, 60% duty cycle: 8000 Nm Torque II, 60% duty cycle: 2308 Nm C-axis Holding torque with backlash-free spindle brake: 3000 Nm Speed: 0-50 rpm Maximum torque (100/60% duty cycle): 3700/4430 Nm Steady rest clamping range: 70-425 mm Turning, drilling, milling head Tool taper Capto C8 Tool magazine Storage locations: 2 magazines, Baluff chip system Max. tool diameter (each position/every 2nd position) 125/200mm Max. tool length 600mm Tool weight 25kg Tailstock Quick diameter 180mm Stroke 170mm Internal taper MK6 Axially force, manually adjustable 5-30 kN Quick tip height adjustment +/-0.15mm Other: Collision monitoring sensor ACS 3-ARTIS Chip conveyor system Coolant system 980l tank and more
