Used Mini Cnc Lathe for sale (13,862)

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, turning diameter over cross slide: 470 mm, turning length: 3,000 mm, turning diameter: 720 mm, spindle bore: 104 mm, CNC Lathe Geminis 4 Plus 720 x 3000 mm Description Manufacturer: Geminis Model: CNC 4 Plus Control: CNC Fagor 8055 FL-BT Capacities: Distance between centers: 3,000 mm Swing over bed: 720 mm Swing over cross slide: 470 mm Isdpfx Aewuligohyetb Spindle bore: 104 mm Tailstock diameter: 100 mm (Morse 6 taper) Bed width: 550 mm Speeds: 2 speed ranges: 0–1600 rpm Rapid traverse: X-axis: 8 m/min Z-axis: 8 m/min Motor: Power: 22 kW Weight: 8,000 kg Equipment: CNC Fagor 8055 FL-BT 3-jaw SHUNK Rota-S Plus chuck Ø 315 mm Additional 3-jaw chuck Fixed steady rest Chip conveyor General condition: Lathe in excellent condition

Condition: excellent (used), Year of construction: 2015, CNC Lathe with c-axis GEMINIS - GHT4-G4 MACH-ID 9182 Make: GEMINIS Type: GHT4-G4 Control: FAGOR 8055 TC Year: 2015 Full C-Axis 360.000 Driven tools Axiaal & Radial  Driven tailstock  Steady rest C-Type Front chuck with 180 bore Rear chuck with 180 bore 3 guide way bed width 750 mm Max. turning Ø: 800mm X-Axis: 450mm Z-Axis: 4200mm Spindle bore: 162mm Speedrange: 900Rpm ATC / revolver: 8 Speed live tools:3000Rpm Power live tools:7.5kW Pinole taper: 5Mk Stroke pinole: 250mm Workpiece load: 2500 Length: 8200mm Width: 3200mm Height: 2900mm Weight: 24000kg Itsdpfxewzh Eqe Ahysb

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: G3169-0110, turning length: 530 mm, turning diameter: 420 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 65 mm, travel distance X-axis: 220 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 550 mm, overall weight: 4,700 kg, turning diameter over bed slide: 800 mm, HYUNDAI WIA L200SY CNC TURNING CENTER Year: 2012 | Fanuc 18i-TB CNC Control SN: G3169-0110 • 5-Axis CNC Turning Center – Hyundai WIA L200SY • Main Chuck: 8″ | Sub Spindle: 5″ • Live Tooling & Y-Axis + C-Axis indexing • Max Turning Diameter: approx. 419–420 mm / 16.5″ • Max Turning Length: approx. 520–530 mm / ~20.5–20.9″ • Swing Over Bed: approx. 800 mm / 31.5″ • X Travel: approx. 220 mm / 8.7″ • Z Travel: approx. 550 mm / 21.7″ • Y Travel: approx. 80 mm / 3.1″ • Max Spindle Speed: up to 4,000 rpm • Main Spindle Power: ~20 HP (~15 kW) Itsdpfxjx I A Hcj Ahyeb • Sub Spindle Speed up to 6,000 rpm • C-Axis indexing: 0.001° possible • Tool Stations: approx. 12 • Coolant system and chip conveyor included • Approx. Dimensions: 120″ × 68″ × 80″ • Approx. Weight: ~10,500 lbs (~4,760 kg) NOTE: MACHINE WAS REMOVED FROM GOOD WORKING CONDITION 2 YEARS AGO. PLANNED TO PUT BACK IN SERVICE BUT SELLER WILL NO LONGER BE DOING MACHINING.

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Iedpsxpqm Rsfx Ahyetb Front door: partial opening M0 / full opening

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm Itodjxdmgvjpfx Ahysb We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: used, Year of construction: 2002, functionality: fully functional, machine/vehicle number: 26956, Specification Table size 914mm x 305mm X axis traverse 406mm Y axis traverse 305mm Ijdpfxowkrq Aj Ahyotb Z axis traverse 254mm Spindle BT 40 Spindle speeds 0-6000rpm Spindle motor 5.6kW Rapid feed rate 15.2m/min Toolchanger capacity 10 tools Approximate weight 1542kg   Machine equipped with:- Haas CNC Control System Coolant system Lighting Enclosed guarding Manual

Condition: ready for operation (used), Year of construction: 1998, operating hours: 7,984 h, functionality: fully functional, machine/vehicle number: 1408, turning length: 250 mm, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, bar passage: 65 mm, controller model: Okuma OSP7000L, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum turning diameter: 340 mm Maximum turning length: 250 mm Main Spindle Technology: Motor spindle Speed: 4,500 rpm Power (max.): 22 kW Bar capacity: 65 mm Workpiece clamping: 3-jaw chuck, Kitagawa B-210 Tool Turret I (X/Z) Technology: 12-station turret Tool holder: VDI40 Travel in X: 260 mm Travel in Z: 640 mm Rapid traverse in X: 15 m/min Rapid traverse in Z: 20 m/min Tool Turret II (X/Z) Technology: 8-station turret Tool holder: VDI40 Travel in X: 140 mm Travel in Z: 615 mm Rapid traverse in X: 15 m/min Rapid traverse in Z: 20 m/min MACHINE DETAILS Control: Okuma OSP7000L Dimensions & Weight Dimensions (L x W x H): 3,305 x 2,100 x 1,927 mm Weight: 4,800 kg Electrical connection data Rated voltage: 400 V Number of phases: 3 Frequency: 50 Hz Power consumption: max. 30 kVA Itedpfox Hx Dnsx Ahyob Total current: 43.4 A Motor current: max. 106 A Operating Hours Power-on hours: 36,348 h Cutting time: 7,984 h Spindle run time: 8,674 h EQUIPMENT Chip conveyor Coolant pump Automatic measuring arm Transformer

Condition: ready for operation (used), Year of construction: 2006, operating hours: 32,503 h, functionality: fully functional, machine/vehicle number: 01510006441, controller model: MANUAL PLUS 4110, TECHNICAL DETAILS Iodsx Uz Edepfx Ahyotb Control: MANUAL PLUS 4110 MACHINE DETAILS Electrical Supply Rated voltage: 400 V Phases: 3~ Frequency: 50 Hz Performance Data Power: 24 kVA Rated current: 35 A Fuse rating: 50 A Operating hours: 32,503 h

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 81 mm, turning diameter: 99 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 240 mm, TECHNICAL DETAILS Maximum turning length: 81.3 mm Maximum turning diameter: 99.1 mm X-axis: 300 mm Z-axis: 240 mm Spindle head: A2-6 Spindle bore: 33 mm Variable spindle speed: 4,000 rpm Spindle motor power: 11 kW Number of turret tools: 8 Number of driven tools: 10 MACHINE DETAILS Control: Fanuc 21iT Dimensions & Weight Machine dimensions (incl. chip conveyor): 290 x 235 cm Machine weight: 4,000 kg Transformer station dimensions: 65 x 60 cm Itjdox Upv Repfx Ahyeb Transformer station weight: 150 kg Overall dimensions (L x W x H): 2,600 x 2,300 x 2,400 mm Total weight: 3,900 kg EQUIPMENT Chip conveyor

Condition: excellent (used), Year of construction: 2004, operating hours: 1,000 h, functionality: fully functional, turning diameter over cross slide: 380 mm, turning length: 350 mm, turning diameter: 200 mm, travel distance X-axis: 240 mm, rapid traverse X-axis: 12 m/min, Hembrug Mill-Turn Machine Model: Slantbed Mikroturn 100 CNC Siemens 840D Control Approximate Actual Run Time Hours: 1,000 Hydeostatic Spindle Hydrostatic Ways Scale Feedback Suspended Granite Bed Garnite Spindle Housing Coolant Pump Coolant Circulation Pump Pneumatic Bearing Purge Hydraulic Temperature Control Coolant Temperature Control Return Oil Pump and Reservoir for Remote Location of Hydraulic / Cooling Unit. Options & Additional Purchased Features: Tailstock Vacuum Pump for Vacuum Chucking Programable Controlled Spray Mist C-Axis Milling / Drilling Renishaw Tool Touch Probe Non-Contact Tool Incoming Air Dryer / Filter Thousands of Dollars of Brand New Tooling: Live Center Isdpfx Ahswcfgboyetb Tailstock Taper Adapter 8” Micro-Centric Pneumatic Chuck 3 Sauter Straight Live tooling heads 2 Sauter 90 degree Live tooling heads 1 Special VDI offset Tooling holder 16 VDI Tool Holders for Turning, boring, and on center drilling. Tool Pick-up Video System Additional Backup Hard Drive with Software Fully Loaded and Tested. Extra Siemens Control Pannel Complete Set of Manuals Machine Upgrades I added at additional cost. New Digital Hard Drive New Backup Hard Drive with software already loaded, plug and play ready, no downtime. New Z-Axis Heidenhain Scale Rewound Hydraulic Pump Motor, factory motor was running too hot for my liking. Replaced Operator Panel, back light on monitor went out, have the original, back light needs replacing. 50 Foot Extended Wiring Harness For Remote Location of Hydraulic / Cooling Unit.

Condition: excellent (used), Year of construction: 2000, INDEX ABC CNC Lathe. Mfd. 2000 Control: Siemens 840C Capacity 65mm Ran oil Still in production, running nylon With 12-ft Bar Feed (pictured) Chip Conveyor Comes the a good amount of tooling Control Type: Siemens SINUMERIK 840C Spindle Speed (max.): 6,000 RPM Power Requirements (V/Hz/PH): 400/60/3 Main Spindle Speed (max.): 6,000 RPM Bar Capacity: 65 mm Power: 20 kW (at 100%) Power: 27 kW (at 40%) Synchronous Spindle Speed (max.): 4,500 RPM Power (max.): 4.2 kW Capacity Tool Carrier 1: 8 (7 + synchronous spindle) Tool Carrier 2: 6 Dimensions Bar Feeder: L 150" x W 27" x H 52" Iodpfx Ahow Td U Rjystb Turning Center: L 80" x W 48" x H 65" Power Enclosure: L 52" x W 18" x H 70" Chip Conveyor: L 88" x W 48" x H 35"

Condition: good (used), Year of construction: 2007, Traub TNX 65/42 Milling and Turning Center Mfd. 2007 Serial #7060107 Commissioned in 2010 TX 8i-S control (Mitsubishi/Traub based control with Mitsubishi drives and motors) 15 CNC axis’s (4) X-Y-Z turrets with 10 positions each. Up to 20 tools per turret Itodjq Npqmjpfx Ahyjb 65 mm thru hole main and sub spindle (sub spindle has coolant flush) Foot pedal control for clamp/unclamp of spindle chucks Servo driven gantry receiver Hydraulic swivel w/ pneumatic finished part and bar remnant gripper Finished part conveyor belt RESY paper band coolant filter Knoll Coolant tank with BKW refrigerated coolant temperature control 20 Bar High pressure and 8 Bar Low pressure coolant pumps Knoll chip conveyor FMB Turbo 5-55 magazine bar feeder (new in 2010) 2) Single stick turning tool holders 2) Double stick turning tool holders 1) Cut-off tool holder 1) Overdriven double radial live ER Collet tool holder 1) Overdriven radial live ER Collet tool holder 4) Radial live ER Collet tool holders 1) Radial live End Mill tool holder 1) Angle adjustable live ER Collet tool holder 2) Radial live Shell Mill tool holders 2) Axial live End Mill tool holders 6) Axial live ER Collet tool holders 43) Additional tool holders on separate list (see supplemental attachment) Hainbuch main spindle collet chuck Rohm sub spindle 2 jaw chuck 2 Spare sets of spare Z-axis ball screws and bearing packs.

Condition: good (used), Year of construction: 2018, Mfd. 2018 Equipped with: BWG Bar Loader (20mm), Itsdowrty Uspfx Ahyob LNS MH250 Chip Conveyor, MP Systems High Pressure Coolant System, Tri-Dim Tri-Mist 850 Mist Collector Power on time: 30513 hours Cutting time hours: 6275 hours

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Okuma OSP-P300L CNC Control Itjdpsrtrlzofx Ahyeb 8" 3-Jaw Chuck Expanding Mandrel Turret Tooling Gantry Loader Pendant Controller Chip Auger Stack Light

Condition: good (used), Year of construction: 2013, control Siemens 840D sl turning length 2000 mm turning speeds max. 3100 1/min Torque 1200 Nm diameter of quill 140 mm Itedpfev Nw Npox Ahyob quill power 5-30 kN total power requirement 125 kW weight of the machine ca. 20 t The machine can still be inspected under power at the seller's factory. It is in good condition, the precision of the turning operation is very good. The milling drive is not functional. An offer from Niles for the repair of the milling drive is available on request. Hydraulic steady rest included. Technical details: Turning length 2000 mm Control Siemens 840 D sl Main spindle: Speed max.3800 1/min Main spindle: Torque max. 1200 Nm Pinole diameter 140 mm Center point MK6 Quill force 5 - 30 kN Feed speed Z-axis mm/min Rapid traverse Z-axis 40 m/min Feed rate X-axis - mm/min Rapid traverse X-axis 25 m/min Total power requirement 125 kW Machine weight approx. 20 tons

Condition: used, Year of construction: 2007, turning length 2500 mm control Sinumerik 840 D spindle head A 11 tool numbers 48 swing diameter over bed slide 750 mm swing over bed 780 mm c-axis 0,1-30 1/min diameter of quill 160 mm taper bore MK 5 tool length - max. 500 mm weight of tools max. 15 kg weight of the machine ca. 27 t dimensions of the machine ca. 8,4 x 4,0 x 2,5 m Technical details: Itsdswwaruepfx Ahyeb Nominal turning length: 2,500 mm Swing diameter over bed slide: 750 mm Swing diameter over bed: 780 mm Working height: 1,300 mm Spindle head to DIN 55026: A 11 Bore through: 123 mm Diameter in front bearing: 200 mm Oriented spindle stop: 0-359 degrees Drive power at 100/60 % duty cycle: 37/45 kW Total speed range: 10-2,500 1/min Number of speed ranges: 2 Speed range I: 10-775 1/min Speed range II: 20-2,500 1/min Max. torque at 60 % duty cycle: 2,500 rpm. Torque at 60 % ED: 2,083 Nm (up to 186 rpm)

Condition: used, Year of construction: 2008, control 840 D Sinumerik weight of the machine ca. 25 t dimensions of the machine ca. 5100 x 3034 x 4500 mm Technical Details: Largest workpiece diameter Ø 1000 mm Internal workpiece diameter Ø 100-500 mm Largest workpiece length 500 mm Itjdpfxewwar Is Ahyjb Largest oscillation diameter 1250 mm Workpiece spindle flange diameter 520 mm Through-hole of the workpiece spindle Ø 45 mm Workpiece spindle speeds NC - programmable 0-440 rpm Table strokes: Z1/Z2 axis 1000 mm, X1/X2 axis approx. 1300 mm Table speed infinitely variable: Z axis 0-30 m/min, X axis 0-50 m/min Infeed speed infinitely variable 0.01-15 mm/min Infeed stroke-dependent 0.0005-0.1 mm Workpiece spindle positioning C-axis Operating voltage 3~400 VAC/50 Hz SINUMERIK 840 D control Machine connected load approx. 75 kW

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, functionality: fully functional, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step Itodpfeuu Rybsx Ahyjb RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Condition: excellent (used), Year of construction: 2020, Swing over bed 720mm, Swing over cross-slide 590mm, maximum machining diameter 481mm, maximum machining length 1275mm, bar capacity 102 mm, 12 station turret, Iedjx Uy Haepfx Ahyotb spindle speed 2,800 rpm, Fanuc I series control, tool setter, swarf conveyor, 3 jaw chuck,

Condition: new, Year of construction: 2024, functionality: fully functional, HYUNDAI-WIA SE2200M CNC LATHE WITH FANUC 0IT PLUS CONTROL AND C-AXIS MACHINE CONSTRUCTION & FEATURES  8” STANDARD CHUCK SIZE.  30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY.  HIGH PERFORMANCE ROLLER LM GUIDEWAYS.  12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION INCLUDED]  4,500 RPM HIGH POWER MAIN SPINDLE.  30 X 36 M/MIN RAPID TRAVERSE RATES - X & Z AXES.  C-AXIS MAIN SPINDLE.  ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 288 MM Ijdpfxsx Trgce Ahystb Bar Capacity - Main Ø 65 MM MAIN SPINDLE Chuck Size 8” Ø 203 MM Spindle Bore Ø 75 MM Spindle Speed (Rpm) 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max.) 167 NM Spindle Type BELT Spindle Nose A2-6 C-Axis Indexing 360° (0.001°) FEED Travel X 210 MM Travel Z 340 MM Rapid Speed X 30 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDE TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP LIVE TOOL Motor (Max / Cont.) 2.75 / 1.85 KW Milling Tool Speed 6,000 RPM Torque (Max.) 26.2 NM Collet Size ER 20 - Ø 13 Type BMT45 TAILSTOCK HYDRAULIC NC TAILSTOCK (STD LIVE CENTRE) Taper MT 4 Quill Diameter Ø 56 MM Tailstock Travel 580 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 0.7 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 2,220 X 1,610 MM Height 1,700 MM Weight 3,250 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO (RENISHAW) HYDRAULIC TYPE NC TAILSTOCK TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-i (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FRONT DOOR INTERLOCK FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER TOOLBOX STANDARD TOOLING PACKAGE

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD2200 FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 45° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET. ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. Iodpox Tqppofx Ahystb ▪ ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. Swing Over the Bed Ø 550 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 380 MM Maximum Turning Length 565 MM Bar Capacity Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” – 203 MM 10” - [254] MM Spindle Bore Ø 76 MM Spindle Speed (rpm) 4,500 RPM Motor (Max/Cont.) 18.5 / 15.0 KW Torque (Max/Cont.) 206 / 125.3 NM Spindle Type BELT Spindle Nose A2-6 FEED Travel X 215 MM Travel Z 580 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.12 SEC / STEP TAILSTOCK Taper MT 4 Quill Diameter Ø 65 MM Quill Travel 80 MM Travel 513.7 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 23 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W) 2,925 x 1,650 MM Height 1,820 MM Weight 4,100 KGS INCLUDED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD OIL SKIMMER BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) MACHINE MANUALS & OPERATOR HANDBOOKS TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK - 4MT WITH STD LIVE CENTER

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100L FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 10 STATION HIGH SPEED RIGID SERVO TURRET. 2,800 RPM 26.0 /18.5 KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 500 MM Maximum Turning Length 1,300 MM Bar Capacity Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (rpm) 2,800 RPM Motor (Max/Cont.) 26.0 / 18.5 KW Torque (Max/Cont.) 1,123 / 657 NM Spindle Nose A2-11 FEED Travel X 265 MM Travel Z 1,350 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 10 Tool Size - OD 25 MM² Tool Size - ID Ø 50 MM Indexing Time 0.15 SEC / STEP TAILSTOCK Type QUILL TYPE TAILSTOCK [PROGRAMMABLE TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM TANK CAPACITY Coolant Tank 220 L Itodpfx Ahjx Tiggoysb Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 27 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W)4,405 x 1,978 MM Height 1,850 MM Weight 7,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO STEADY REST PREPARATION - PROGRAMMABLE CLAMPING & TRAVEL PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FACTORY FITTED OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE STANDARD LIVE CENTER

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Itjdpex Thzvefx Ahyeb Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.

Condition: excellent (used), Year of construction: 2010, The XYZ 200TC is a CNC lathe known for its precision and versatility. It features a Siemens 810D Shopturn control system, a 12-station VDI turret. Key Features and Specifications: Control System: Siemens 810D Shopturn. Turret: 12-station VDI turret. Chuck: Hydraulic 200mm 3-jaw chuck. Bar Capacity: 52mm. Swing Over Bed: 420mm. Maximum Machining Diameter: 200mm. Maximum Machining Length: 550mm. Spindle Speed: 4800 rpm. Spindle Bore: 62mm. Itsdpfx Ahexrvcveyeb Spindle Motor Power: 14.9kW. Other Features: Automatic tool setting arm, swarf conveyor, parts catcher, hydraulic tailstock, remote electronic handwheel, and through-tool and flood coolant. Weight: 4100kg. The XYZ 200TC is a slant-bed CNC lathe, which means the lathe bed is angled, allowing for better chip evacuation and access to the workpiece. It can be equipped with a multi-feed barfeed for automated feeding of bar stock. The machine is typically used in small to medium-sized workshops and production environments. Complete with bar feed, swarf conveyor and tooling.

Condition: excellent (used), Dugard Eagle BNC2680X CNC Lathe CNC Fagor 8055 Control Year 2007 Swing in gap 870mm Between centres 2000mm With Steady and boring attachment 15" Chuck 3.5" Spindle bore Itedpfxewwlake Ahyob
