Used Mori Seiki Lathes for sale (195)

Condition: used, Swing Diameter Over Bed: 400 mm Swing Diameter Over Longitudinal Slide: 350 mm Distance Between Centers: 610 mm Travel Limit: 240 mm Suggested Workpiece Diameter: 200 mm Max Longitudinal Travel: 560 mm Machining Length: 550 mm Max Cross Travel: 40 mm + 120 mm Height of Spindle Axis from Floor: 1135 mm Programmable Spindle Speed Range: 40 to 4000 rpm Spindle Bore Diameter: 52 mm Spindle Interior Cone: MK 6 Slide/Bed Slope: 45/45° Turret Positions: 12 Tools Main Motor: 15 kW Control: Hedpfexg Nd Aex Alyenr Fanuc 6T Equipped with: See photos

Condition: ready for operation (used), Year of construction: 2011, operating hours: 31,113 h, functionality: fully functional, machine/vehicle number: NHX40KB0083, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 660 mm, controller model: MITSUBISHI MSX-853 IV, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 560 mm Travel range, Y-axis: 560 mm Travel range, Z-axis: 660 mm Feed rate: 0–60 m/min Distance from spindle nose to table surface: 80–640 mm Number of pallets: 2 Pallet dimensions: 400 × 400 mm Table length: 400 mm Table width: 400 mm Max. workpiece length: 630 mm Max. workpiece width: 630 mm Max. workpiece height: 900 mm Max. workpiece diameter: 630 mm Max. workpiece size: Ø 630 × 900 mm Max. workpiece weight: 400 kg Pallet changing time: 9 s Max. spindle speed: 12,000 rpm Spindle drive power: 15/11 kW Spindle torque: 110 Nm Spindle bearing inner diameter: 80 mm Spindle type: SJ-2B4351TK Tool positions: 40 Max. tool diameter: 70 mm Max. tool diameter with free neighboring positions: 170 mm Max. tool length: 450 mm Max. tool weight: 8 kg Tool holder: MAS-BT40 MACHINE DETAILS Control system: MITSUBISHI MSX-853 IV Rated power: 38 kVA Total power consumption: 38 kVA Dimensions & Weight Dimensions (L x W x H): 2,720 x 4,224 x 2,513 mm Total weight: 7,600 kg Coolant tank capacity: 170 l High-pressure coolant: 15 bar Operating hours Hours under power: 64,734 h Operating time: 31,113 h EQUIPMENT Chip conveyor Work area light 4th axis Hnjdezrl H Ropfx Alyer Cooling High-pressure cooling 2-pallet changer

Condition: ready for operation (used), Mori Seiki MV-Junior vertical machining center... Tool magazine for 30 tools, travel X: 560 mm; Y: 410 mm; Z: 460 mm, table size: 900x450 mm, maximum table load: 300 kg, maximum spindle speed: 8,000 rpm, total weight: 3,900 kg Hsdpfjx I D Syox Alyonr

Condition: used, Year of construction: 1988, Technical details: x-travel: 800 mm y-travel: 410 mm z-travel: 510 mm control: Fanuc 10 MA rapid travel x/y/z: 20/20/15 mm/min table surface area: 1100 x 450 mm tool taper: BT 40 tool magazin:: 30 BT 40 max. tool length: 250 mm max. tool weight: 8 kg power requirement: 7,5/5,5 kW turning speed range: 6000 1/min weight of the machine ca.: 6,3 t Hnjdpfey S T T Usx Alyor Accerories 2 Chip conveyor, rear side disposal Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup" *

Condition: used, Year of construction: 1998, Technical details: x-travel: 630 mm y-travel: 600 mm Hnodjy Er Tgepfx Alyor z-travel: 650 mm control: MSC 502 (Fanuc 16) Spindle RPM: 12000 1/min spindle drive: 22 / 18,5 kW rapid travel x/y/z: 32 m/min Pallet dimension: 500x500 mm numbers of pallets: 2 table load: 0,5 t working diameter: max. 610 mm Number of tool station: 60 BT40 max. tool length: 360 mm max. tool weight: 12 kg tool changing time: 1,3 sec B-axis positioning (non continuous): 1 total power requirement: 50 kVA weight of the machine ca.: 14 t dimensions of the machine ca.: 3,3 x 5,8 x 3,2 m Accerories Chip conveyor spindle load monitor Typ C Coolant gun Chamfering and corner rounding Tool life management Interface for coolant through the spindle This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface, *

Condition: used, Year of construction: 2008, Technical details: x-travel: 1400 mm y-travel: 1200 mm z-travel: 1350 mm control: MSX- 701 Mapps III table surface area: 800 x 800 mm rapid traverse: 50 m/min table rotating: 360.000 x 0,001 B-Achse ° table load: 2,0 t numbers of pallets: 2 turning speed range: 8000 1/min power capacity - milling spindle: 37 kW Hnsdpfx Alswi Ibusyer no. of tools in the magazine: 60 Stück tool taper: HSK-A 100 weight: 31 t dimensions: 5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis *

Condition: used, Year of construction: 2008, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS III greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle Y-axis 2 x part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface Hnedpfozd Su Eex Alyjr Lehmann Robot with parts belt for feeding and disposal CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. For shaft parts loading and unloading there is a Lehmann Robot with conveyor belts for loading and unloading. The machine can also be sold without robot. *

Condition: used, Year of construction: 2011, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS IV greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. The robot cell has been diemanteled, it is now a stand alone machine. A bar feeder can be added. Hodpfxozk U Rpe Alyjnr *

Condition: ready for operation (used), functionality: fully functional, turning length: 230 mm, turning diameter: 190 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 125 mm, travel distance Z-axis: 195 mm, The machine was manufactured in the 1990s. Hsdpfxozul Uye Alyjnr TECHNICAL DETAILS Turning diameter: 190 mm Turning length: 210–230 mm Swinging diameter over bed: 190–200 mm Travel in X-axis: 125 mm Travel in Z-axis: 195 mm Spindle speed range: 6,000 rpm Spindle bore: 43 mm MACHINE DETAILS Machine weight: approx. 2,500 kg EQUIPMENT Chip conveyor

Condition: repair required (used), Year of construction: 1998, functionality: limited functionality, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 370 mm, The machine’s control system is defective. TECHNICAL DETAILS Turning diameter: 248 mm Turning length: 330 mm Travel distance X-axis: 370 mm Travel distance Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock quill travel: 120 mm MACHINE DETAILS Transformer: 400 V / 200 V EQUIPMENT Integrated CNC control Machine and control as a closed transport unit Linear guides in the X and Z axes Continuously variable AC main spindle drive Programming for constant cutting speed Integrated cold light Power meter for the main spindle drive Controls for automatic, manual operation and CNC programming Central control panel on the right side of the machine High-dynamic three-phase servo motors for the X and Z axes Backlash-free, pre-tensioned precision lead screws for the X and Z axes Automatic central lubrication with electrical monitoring for bed, cross slide and ball screw drives Coolant system with tank, pump, lines and nozzle Electric 12-station turret system MORI SEIKI with automatic direction logic Direct coolant supply through the turret Hodpfezul Utox Alyenr Fixed hydraulic unit for the power chuck Full enclosure of the working area Front sliding door with large viewing window Electrical connection for chip conveyor prepared Data interface V.24 / RS-232-C Control cabinet Freestanding transformer 400 V / 200 V

Condition: defective spare-parts repository (used), Year of construction: 1996, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 190 mm, TECHNICAL DETAILS Turning diameter: 248 mm Turning length: 330 mm Hnodpfozul Umjx Alysr Travel range X-axis: 370 mm Travel range Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock travel: 120 mm

Condition: ready for operation (used), Year of construction: 2001, operating hours: 27,267 h, functionality: fully functional, turning length: 180 mm, turning diameter: 100 mm, spindle bore: 43 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 125 mm, travel distance Z-axis: 195 mm, TECHNICAL DETAILS Turning diameter: 190 mm Turning length: 180 mm Max. turning diameter: 100 mm Travel X-axis: 125 mm Travel Z-axis: 195 mm Rapid traverse X-axis: 15 m/min Rapid traverse Z-axis: 20 m/min Spindle bore: 43 mm Spindle bearing diameter: 80 mm Spindle speed range: 60–6,000 rpm Tailstock diameter: 40 mm Tailstock taper: MK 3 Tailstock travel: 45 mm Number of tool positions: 10 MACHINE DETAILS Hnjdpszul T Nefx Alyjr Transformer: 400 V / 200 V Data interface: V.24 / RS-232-C Operating hours: 27,267 h EQUIPMENT Bar feeder Integrated CNC control Space-saving, compact design Inductively hardened flat guideways for bed and carriage Continuously variable AC main spindle drive Constant cutting speed programming Integrated cold light Ammeter for main spindle drive Swiveling central control panel Controls for automatic, manual, and CNC programming modes Three-phase servo motors for X and Z axes Backlash-free, pre-tensioned precision ball screws for X and Z axes Automatic central lubrication with electrical monitoring Coolant system with tank, pump, lines, and spray nozzle Electric 10-position turret system, MORI SEIKI Automatic turret indexing logic Direct coolant supply through the turret disk Fixed hydraulic unit for power chuck Front sliding door with large viewing window Electrical connection for chip conveyor, prepared Electrical equipment according to VDE 0113 Attached control cabinet Freestanding transformer

Condition: ready for operation (used), Year of construction: 2003, operating hours: 4,256 h, functionality: fully functional, turning length: 570 mm, turning diameter: 176 mm, travel distance X-axis: 245 mm, travel distance Z-axis: 570 mm, controller model: MSG-805 V, TECHNICAL DETAILS Turning diameter: 176 mm Turning length: 570 mm Swinging diameter: 510 mm Machining diameter: 420 mm Travel X-axis: 245 mm Travel Z-axis: 570 mm Rapid traverse X/Z-axis: 24 m/min Spindle bore: 43 mm Spindle speed: 60–6,000 rpm Tailstock diameter: 85 mm Tailstock travel: 120 mm MACHINE DETAILS Control system: MSG-805 V Total power requirement: 5.5 kW Dimensions & Weight Footprint: approx. 2,000 × 1,700 × 1,800 mm Machine weight: approx. 3,400 kg Operating hours: 4,256 h EQUIPMENT Integrated CNC control system Inductively hardened flat guides for bed and cross slide Continuously variable AC main spindle drive Programming of constant cutting speed Integrated cold light Power meter for main spindle drive Operator controls for automatic and manual operation CNC programming and control panel Tailstock with hydraulically actuated quill, MK 4 Continuously variable quill pressure Programmable actuation of the tailstock quill via toggle switch and M function High-dynamic three-phase servomotors for X and Z axes Backlash-free, pre-tensioned precision ball screws for X and Z axes Hedpfozul Tvjx Alyonr Automatic central lubrication with electrical monitoring Coolant system with tank, pump, lines, and nozzle Electric 12-station turret system MORI SEIKI Automatic direction logic on the turret Direct coolant supply through the turret disk Fixed hydraulic unit for power chuck Full enclosure of the work area Front sliding door with large viewing window Electrical preparation for chip conveyor Electrical equipment according to VDE 0113 Data interface V.24 / RS-232-C Mounted control cabinet Freestanding transformer: 400 V / 200 V

Condition: ready for operation (used), Year of construction: 2011, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 880 mm, table load: 500 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 22,000 W, number of axes: 4, This 4s MORI SEIKI NHX 5000 was manufactured in 2011. It features a dual pallet system with a pallet size of 500 × 500 mm and a maximum pallet load of approximately 500 kg. The spindle speed reaches up to 12,000 rpm, with a tool magazine capacity of 40 tools. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NHX 5000 horizontal machining center we have for sale. Contact us for further details. • Pallet system: Dual pallet; size 500 × 500 mm; max load ≈ 500 kg Hsdjyh Hzyepfx Alysnr • Tool system: Magazine 40 tools (optional 60 / 120); tool-to-tool ≈ 0.9 s; chip-to-chip ≈ 2.8 s • B-axis: Continuous 360°; indexing resolution 0.001° • Rapid traverse (X/Y/Z): ≈ 60 m/min • Accuracy/Construction: High-precision linear guides; thermal displacement control system; glass scales (depending on configuration) Technical Specification Taper Size BT 40

Condition: excellent (used), Year of construction: 1998, Mori Seiki SH630 Horizontal Machining Centre Year 1998 Spindle speed - 10,000rpm CNC Control - Fanuc drives / Mori Seiki MSC control 4 Axis Table Length 630mm Table Load 1000kg Table Width 630mm Y axis travel - 760mm Hjdpfx Alezp Rftoyenr Z axis travel - 840mm X axis travel - 840mm Tool magazine with capacity for 60 tools 2 Tombstones Comes with Metal standing frame

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Hnsdpjzr Hgxofx Alyor Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: excellent (used), functionality: fully functional, * Mori Seiki NMV 5000 DCG. * Year: 2008. * Equipment value, including zero points, chucks, BT taper chucks, turning tool chucks, and pallets: 50,000–55,000 euros. * 5-axis continuous machining center. * High-precision Heidenhain linear guides. * Interface for connecting a pallet loader and robot. * Table with turning function. * Independent high-pressure cooling system at 40 bar. * Spindle oil cooling system. * BT 40 tool magazine. * Magazine capacity: 60 tools. * Maximum tool diameter: 125 mm. * Maximum tool length: 300 mm. * Maximum tool weight: 8 kg. * Travel on the X-axis: 730 mm. * Travel on the Y-axis: 510 mm. * Travel on the Z-axis: 510 mm. * Table with turning function. * Maximum workpiece diameter in turning mode: 450 mm. * Maximum turning diameter in turning mode: 700 mm. * Mori Seiki Mapps 4 conversational control. * Spindle speed: 20,000 rpm. * Spindle motor power: 18.5 / 15 kW. * Maximum cutting torque: 135 Nm. * C-axis table: 360,000 x 0.001 * B-axis rotation: +160 / -180 * Rapid traverse X/Y/Z: 50 / 50 / 50 m/min * Renishaw tool measurement system. * Renishaw workpiece measurement system. * Automatic zero-point adjustment. * Automatic cutting power control. * Program memory: 2 MB. * Dynamic zero-point correction (up to 8 points). * Pre-check of tool availability. * Custom macro (999 variables). * Rear chip conveyor. * Tool life management (128 x 2 groups). * Electrical transformer. * Documentation, parts list, electrical diagrams, programming, and instruction manual. * Weight: 13,500 kg. * Machine is currently in operation. * Available for inspection by an authorized Mori Seiki technician. * Immediate delivery, subject to immediate sale. Hsdjzuxntepfx Alysnr

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, * Mori Seiki NL 2500 SY. * Year 2009. * Y-axis. * C-axis. * 5-axis machine. * 1.5-meter Lns Quick Load bar loader. * Sub-spindle. * 12-station turret, all stations motorized. * Y-axis travel: ±60 mm. * C-axis on both spindles. * Integrated main spindle motor: 18 kW. * Integrated sub-spindle motor: 15 kW. * Direct-drive motor for powered tools: 5.5 kW. * Motor starting torque: 640 N·m. * Motors without belts or gear stages. Hnsdszuxm Aopfx Alyer * Main spindle size: A2-8. * Sub-spindle size: A2-6. * Bar capacity: 80 mm. * 250 mm Kitagawa B-210 main spindle chuck with metric system. * 210 mm Kitagawa B-208 sub-spindle chuck with metric system. * Prismatic guides on all axes. * Main spindle speed: 4,000 rpm. * Motorized tool speed: 6,000 rpm. * Daikin oil cooler for both spindles. * Mapps 4 conversational automatic programming system. * Automatic force control and tool wear monitor. * Rapid traverse speed: 30 m/min on the X and Z axes. * Turret indexing time: 0.2 seconds. * Two Renishaw arms for automatic tool measurement. * Communication ports via USB, PCMCIA card, and RS-232. * Installation interface for bar loader. * Automatic workpiece collector. * Dual pedal for independent opening and closing of the main spindle and sub-spindle. * Side-mounted hinged chip extractor. * Extensive range of static and motorized tool holders. * Electrical transformer. * Documentation, parts list, electrical schematics, programming, and operating manual. * Weight: 5,800 kg. * Machine is currently in operation. * It is essential to check the precision videos. * Immediate delivery, unless sold immediately.

Condition: used, Year of construction: 1999, functionality: fully functional, Equipment: chip conveyor, documentation/manual, Machining Center 3-Axis X, Y, Z Mori Seiki Hnodpszp E E Ijfx Alyor Model MV-653/50 Year 1999 CNC Fanuc MSG-803 Phase 3

Condition: good (used), Year of construction: 1990, CNC machining center Manufacturer: MORI SEIKI Type: Partner M300 A-1 Year of manufacture: 1990 Control: FANUC O-M Travel ranges: X/Y/Z: 400 x 300 x 495 mm Distance between spindle center and pallet table (Y-axis): 25 – 325 mm Distance between spindle nose and pallet table (Z-axis): 125 – 620 mm Rapid traverse: 24 m/min Feed rate up to 5 m/min Spindle: Ball screw: 36 mm diameter Feed drives FANUC AC X/Y-axis model 5, Z-axis model 10 Main spindle speed: 100 – 6000 rpm Main spindle motor: AC 5.5 kW Main spindle taper: BT 40 Pallet: Hnsdpfx Alot Rg E Sjyor Pallet size: 315 x 315 mm Pallet indexing angle: 7.5 degrees Indexing accuracy: + / - 2 sec. Repeatability: + / - 1 sec. Pallet clamping force: 3,400 kg Maximum workpiece weight: 150 kg Automatic tool changer: Number of tools: 30 Tool change time: 2.5 sec. Collet clamping time: 7 sec. Maximum tool diameter: 110 mm Maximum tool length: 250 mm Maximum tool weight: 8 kg Special accessories: Work end display with alarm light Magazine for 30 tools Operating hours display Tool life monitoring Coolant system Work area lighting Weight: approx. 4,500 kg Space requirement: 1,900 x 2,300 mm 3826

Condition: used, Year of construction: 2004, functionality: fully functional, The machine is equipped with a twin spindle and two tool turrets. Y-axis available. Y-axis travel: 190 mm. Main spindle speed range: 8,000 rpm. Hnjdszuk U Sepfx Alyjr Counter spindle speed range: 8,000 rpm. Tool magazine capacity: 16 (for both spindles). Bore diameter: 52 mm (for both spindles). Various tool holders, including driven tool holders.

Condition: used, Year of construction: 2005, Available immediately ex-yard: CNC turning and milling center Mori Seiki Type ZT 1500 YB Year of manufacture 2005 CNC control MSX 501 Main and counter spindle, 2 tool turrets, powered tool stations Turning diameter max. 310 mm Max. distance between spindle centers 1000 mm Max. turning diameter 190 mm Max. turning length 235 mm Spindle speeds 50 – 5000 rpm Drive power main spindle 22/18.5 kW Spindle bore 73 mm Chuck diameter 210 mm Bar diameter 52 mm Tool turret 2 Tool positions 2 x 16 stations Number of powered stations 2 x 16 stations Speeds of powered stations max. 6000 rpm Drive power each 5.5 / 2.2 kW Chip conveyor Coolant system Hnodezukghopfx Alysr Y-axis 1 x C-axis 2 x Counter spindle Powered stations 2 x Tool turrets 2 x Fixed tool holders 12 plus 10 Powered tool holders 6 plus 1 Bar loader IEMCA Master 880 MP – E Weight 10 tons

Year of construction: 2008, condition: ready for operation (used), A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible. Hjdszlt Sbspfx Alyenr

Year of construction: 1990, condition: ready for operation (used), Travel X/Y/Z: 400mm/300mm/495mm, spindle center table distance: 25mm-325mm, spindle nose table distance: 125mm-620mm, rapid traverse: 24m/min, feed rate: 5m/min, spindle type: ball screw, spindle diameter: 36mm, speed: 6000rpm, spindle power: 5.5kW, spindle mount: BT40. Tool slots: 30, tool change time: 2.5s, clamping time: 7s, max. tool diameter/length: 110mm/250mm, max. tool weight: 8kg. Table dimensions X/Y: 315mm/315mm, table angle: 7.5°, table clamping force: 3400kg, max. workpiece weight: 150kg. Dimensions X/Y: approx. 1900mm/2300mm, weight: approx. 4500kg, control: Fanuc 0-M, operating hours: 732h, piece counter: 172776. Including cooling lubricant system and tool magazine with 30 places. Documentation available. On-site inspection is possible. Hodot Nhmzopfx Alyonr

Condition: ready for operation (used), Year of construction: 1998, Offered is a horizontal machining center (HMC). Travels X/Y/Z: 560mm/510mm/510mm, max. dynamics: 40000mm/min, spindle: 12000rpm, tool holder: MAS BT 40, tool magazine: 60 positions (chain magazine), pallet system: 2-station pallet changer, pallet size X/Y: 400mm/400mm, accessories: approx. 200 tool holders (BT 40), 2 MMI towers with 8 clamping bars, hinged belt chip conveyor, Blum laser/probe, Renishaw 3D probe, machine weight: approx. 9000kg. Inspection possible by appointment. Hnsdpfxsyzh A Ns Alyor
