Used Mori Seiki M 300 for sale (193)

Year of construction: 1990, condition: ready for operation (used), Travel X/Y/Z: 400mm/300mm/495mm, spindle center table distance: 25mm-325mm, spindle nose table distance: 125mm-620mm, rapid traverse: 24m/min, feed rate: 5m/min, spindle type: ball screw, spindle diameter: 36mm, speed: 6000rpm, spindle power: 5.5kW, spindle mount: BT40. Tool slots: 30, tool change time: 2.5s, clamping time: 7s, max. tool diameter/length: 110mm/250mm, max. tool weight: 8kg. Table dimensions X/Y: 315mm/315mm, table angle: 7.5°, table clamping force: 3400kg, max. workpiece weight: 150kg. Dimensions X/Y: approx. 1900mm/2300mm, weight: approx. 4500kg, control: Fanuc 0-M, operating hours: 732h, piece counter: 172776. Including cooling lubricant system and tool magazine with 30 places. Documentation available. On-site inspection is possible. Cjdpfx Acot Nhmzjperh

Condition: good (used), Year of construction: 2004, turning length: 1,345 mm, turning diameter: 420 mm, spindle speed (min.): 3,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,280 mm, Manufacturer: Mori Seiki Co., Ltd. (Nagoya, Japan) + chuck system Crsdpfx Ajzm Tkaecpeh Machine model: NL3000MC/1250 Serial number: NL301DJ0070 Year of manufacture: October 2004 Machine weight: 7600 kg Electrical data Voltage: AC 200 V Phases: 3 Frequency: 50 Hz Rated power: 44 kVA Full load current: 127 A Spindle motor current: 200 A Interrupting capacity: 5 kA Electrical diagram number: NL301DJ0070 The machine is a CNC turning center (Mori Seiki NL series) with a nominal electrical power of 44 kVA. CHUCK SYSTEM: Manufacturer: Kitagawa Chuck: B-212A821F Chuck cylinder: S2091 Technical data Permissible pressure (when using external chuck jaws on the standard package): 2.7 MPa Maximum speed: 3000 min⁻¹ CNC turning center of the NL series (Mill Center version) with milling capability (driven tools + C-axis). The data is compiled from original Mori Seiki / DMG MORI catalogs and matches your machine's nameplate (year 2004, weight 7600 kg, 44 kVA, 200 V). Capacity ValueMax. turning diameter420 mmMax. turning length1250–1345 mm Swing over bed995 mm Swing over carriage825 mm Bar capacity90 mm (3.5") Standard chuck12" (Kitagawa B-212A821F) Travels X-axis: 260–280 mm Z-axis: approximately 1280–1370 mm (depending on the exact configuration /1250) Y-axis: option (usually ±60 mm for Y/SY versions) Spindle Max. speed: up to 4000–6000 min⁻¹ (limited to 3000 min⁻¹ with your Kitagawa chuck) Spindle bore diameter: 105 mm (approximately 91 mm with chuck) Spindle mounting: A2-8 Spindle motor power: 22/18.5 kW (30/25 HP) or up to 30 kW (depending on the version) Minimum indexing angle: 0.001° Turret (MC version) Number of stations: 10 or 12 Rotary tools: yes (max. 6000 min⁻¹) Power of rotary tool drive: 5.5 / 5.5 / 3.7 kW Indexing time: approximately 0.2–0.3 s Rapid traverses and drives Rapid traverse X/Z: up to 30 m/min Rapid traverse Y: up to 10 m/min (if equipped) C-axis: up to 300–400 min⁻¹ Electrical and other data (from your nameplate) Rated power: 44 kVA Voltage: 200 V AC, 3-phase, 50 Hz Full load current: 127 A Machine weight: 7600 kg Controller: typically MSX-850 / MAPPS

Condition: excellent (used), Year of construction: 2010, FANUC MSX-711 Mapps 4 control with B + C axis Working travels 500 x 350 x 510 mm Table swivelling -180°/+160° Table rotating 360° Spindle taper HSK63 Spindle speeds -20'000 rpm tool changer 61 pos. Coolant through spindle 3D tracer M&H Tool lenght measuring device Codpfxjzwt N Dj Acpjrh Tool breakage control device MARCELS MASCHINEN CH

Condition: good (used), Year of construction: 1990, CNC machining center Manufacturer: MORI SEIKI Type: Partner M300 A-1 Year of manufacture: 1990 Control: FANUC O-M Travel distances: X/Y/Z: 400 x 300 x 495 mm Distance between spindle center and pallet table (Y-axis): 25 – 325 mm Distance between spindle nose and pallet table (Z-axis): 125 – 620 mm Rapid traverse: 24 m/min Feed rate up to 5 m/min Spindle: Ball screw: 36 mm diameter Feed drives FANUC AC X/Y-axis Model 5, Z-axis Model 10 Main spindle speed: 100 – 6000 rpm Main spindle motor: AC 5.5 kW Main spindle taper: BT 40 Pallet: Pallet size: 315 x 315 mm Pallet indexing angle: 7.5 degrees Cjdjt Rg E Sjpfx Acpsrh Indexing accuracy: + / - 2 sec. Repeatability: + / - 1 sec. Pallet clamping force: 3,400 kg Maximum workpiece weight: 150 kg Automatic tool changer: Number of tools: 30 Tool change time: 2.5 sec. Collet clamping time: 7 sec. Maximum tool diameter: 110 mm Maximum tool length: 250 mm Maximum tool weight: 8 kg Special accessories: End-of-cycle indicator with warning light Magazine for 30 tools Operating hours display Tool life monitoring Coolant system Work area lighting Weight: approx. 4,500 kg Space requirement: 1,900 x 2,300 mm 51026ä

Condition: used, Year of construction: 1991, turning length: 530 mm, turning diameter: 340 mm, spindle bore: 78 mm, spindle speed (max.): 3,500 rpm, rotational speed (max.): 3,500 rpm, overall weight: 6,000 kg, CNC MF T4, 3-axis machine with C-axis 12-position motorized tool turret Codpfx Aceznvizsperh 250mm chuck 78mm spindle bore Maximum spindle speed: 3500 rpm, power: 15 kW Distance between centers: 625mm Maximum turning diameter: 625mm Chip conveyor Weight: 6000 kg

Condition: used, Year of construction: 1983, functionality: limited functionality, overall weight: 6,500 kg, The machine can be inspected by appointment. Crodpfezy Efiox Acpeh Delivery is the customer's responsibility, but we can assist with packing and loading if required.

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,000 rpm, travel distance X-axis: 280 mm, travel distance Z-axis: 820 mm, overall weight: 6,000 kg, number of slots in tool magazine: 12, number of axes: 3, Horizontal turning machine manufactured in 2008. This MORI SEIKI NL 3000 MC/700 features a maximum turning diameter of 430 mm and a turning length of 713 mm. It includes a 12-station turret for efficient tool changes and operates at a spindle speed of 3000 rpm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NL 3000 MC/700 machine we have for sale. Contact us for further details. - Chuck: 12" (3-jaw chuck)- Max Turning Diameter: 430 mm- Swing Over Bed: 978 mm- Turning Length: 713 mm- Phase: 3 Phase- Frequency: 50 Hz- Voltage: AC 200 V- Full Load Current: 133 A- Current Rating of Spindle Motor: 300 A- Short Circuit Current: 1 kA (220 V Maximum)- Rated Power: 46 kVA- Machine Dimensions: 3,400 mm x 2,089 mm x 2,270 mm- Optional Accessories/Equipment: Tooling, chip conveyor, accessories/manuals available Cedpfx Acezwxzxsporh Technical Specification Counter Spindle No Driven Tools Yes

Condition: used, Year of construction: 2012, x-travel 500 mm y-travel 450 mm z-travel 400 mm control iTNC 530 Heidenhain turning speed range - main spindle 20 - 14.000 min/-1 power capacity - main spindel 18,9 / 14 kW max. Torque 100 Nm Cjdpfszyu Umjx Acporh tool taper HSK A-63 table surface area 630 x 500 mm max. table load 300 kg Swivel range -5 / +110 ° rotation range 360 ° T-slots 7x 14 x 63 mm number of toolpositions 30 pos. max. tool weight 6 kg max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. workpiece length 300 mm rapid traverse 24 m/min Feed force 4,8 kN feed speeds 1 - 24.000 mm/min total power requirement 25 kVA weight of the machine ca. 5,0 t dimensions of the machine ca. 4,5 x 3,5 x 2,3 m CNC - Milling Machine Universal DMG MORI SEIKI - DMU 50 - 5 Axis - swivable rotary table

Condition: used, Year of construction: 1986, Technical details: Cedpfx Acjwvblajperh x-travel: 800 mm y-travel: 460 mm z-travel: 510 mm total power requirement: 20 kW weight of the machine ca.: 8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough. *

Condition: excellent (used), Year of construction: 2012, Technical data: 3-axis machine: X, Y, Z Cedpszn Ransfx Acporh Travel ranges (X/Y/Z): 635 / 510 / 460 mm CNC control: SIEMENS 840D Table size: 790 x 560 mm Max. workpiece weight: 600 kg Tool holder: SK 40 Number of positions in the tool changer: 30 Spindle speed: 20 – 12000 rpm Motor power: 13 kW Dimensions (length x width x height): approx. 3400 x 2450 x 2800 mm Machine weight: approx. 4.3 tons Condition: very good condition, little use The seller is not liable for typographical or data transmission errors. The machine's appearance, technology, and wear are consistent with its age; used machines are sold without any warranty.

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, operating hours: 25,350 h, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 750 mm, number of slots in tool magazine: 120, number of spindles: 1, spindle nose: BT50, spindle speed (max.): 6,000 rpm, Equipment: chip conveyor, Tool breakage option included 7-pallet carousel Csdpfxetqfk Ns Acporh NC FANUC MF-M6

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 34, spindle bore: 86 mm, overall weight: 16,000 kg, Turning and Milling Center acquired through business takeover Manufacturer: Mori Seiki / Model: MT 250S / 1500 / Year of Construction: 2000 / Refurbishment cost: 200,000 Euros Condition: good, Control: CNC Mori Seiki MSC 501 Technical Data: See attached PDF Max. turning diameter: 570 mm Turning length: 1530 mm Max. swivel diameter: 800 mm Swivel diameter over cross slide: 420 - 860 mm Distance between centers: 1,828 mm Main spindle: Crodpfxjzxg Sue Acpoh Speed range: 35 - 3500 min-1 Main spindle power: 18.5 kW / 15 kW Number of curve speeds: 2 Spindle nose: JIS A2-8 Max. bar capacity: 73 mm Spindle bore: 86 mm Spindle bearing diameter: 130 mm C-axis: 0.001° Tailstock: Tailstock spindle speeds: 50 - 3500 min-1 Tailstock power: 11 / 7.5 kW Number of curve speeds: 2 Spindle nose: JIS A2 - 6 Max. bar capacity: 60 mm Spindle bore: 73 mm Spindle bearing diameter: 110 mm C-axis: 0.001° Milling spindle: Spindle speeds: 8000 min-1 Power: 7.5 kW / 5.5 kW Tool taper: KM 63 Spindle bearing diameter: 80 mm B-axis: 120° / 105° Resolution: B 0.001° Number of tools: 42 Tool taper: KM 63 Max. tool diameter: 80 / 125 mm Max. tool length: 400 mm Max. tool weight: 8 kg Tool change time: 1.6 sec. X-axis: 635 mm / Y-axis: + / - 110 mm / Z-axis: 1595 mm / B-axis: 120° / 105° + Chuck: Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min Max. feed rate: 30,000 mm/min / Total power: 72.3 kW / Weight: 22 tons / Dimensions: 7.0 x 3.5 x 3.5 m, Steady rest: 30 Tailstock: Not required 31 Tool magazine capacity: 42 32 Chip conveyor: Available 33 Chip conveyor type: Slatted belt 34 Chip container: Available 35 Cooling system: Standard (635 W / 1040 W) 36 Coolant supply through the tool spindle: Available 37 Compressed air cleaning of chuck (spindle 1): Available 38 Compressed air cleaning of chuck (spindle 2): Available 39 Tool presetter (in the machine, spindle 1): Automatic 40 Bar loader: Interface only 41 Measuring system X-axis: Heidenhain 42 Signal light: 3-stage signal tower (red, milky white, green) 43 Foot switch for chuck: Double foot switch 44 Steady rest: Automatically centering steady rest (programmable) 45 Type of automatically centering steady rest: SLU3 (SMW) 46 Steady rest unit (SMW): Available 47 Automatic door: Available 48 Hydraulic fluid (fluorocarbon): Not compatible 49 Number of total counters: 1 50 Number of workpiece counters: 1 51 Automatic shutdown: Available 52 Language of NC screen: Spanish 53 Language of PC screen: Spanish 54 Language of warning screen: Spanish 55 Memory capacity for part program (m): 1160 m 56 Number of stored programs: 125 57 Number of tool correction pairs: 240 58 Optional sentence masking: Softkey version 59 Programmable data input: Available 60 Number of shared variables for user macros: 600 61 Tool life monitoring: B 62 Number of tool life monitoring (MORI): MAX. 128 PAIRS * 4 63 LOAD MONITORING: B

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, CNC Control MSX-850 Maximum turning diameter: Ø 420 × 720 mm X/Z axis travels: 280 / 820 mm Swing over bed: Ø 995 / Ø 825 mm Maximum bar diameter: Ø 90 mm Rapid traverse X/Z: 30 / 30 m/min Main spindle diameter: Ø 300 mm Main spindle speed: 3,000 rpm Main spindle power: 22 / 18.5 kW Crjdjzz Ak Espfx Acpsh Main spindle nose: A2-8 Number of motorized turret positions: 12 Tool speed / power: 6,000 rpm / 5.5 kW

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 980 mm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 50 m/min, rotational speed (max.): 8,000 rpm, spindle nose: ISO 50, number of spindles: 240, CNC MSX 701 III Travels (X/Y/Z axes): 900 / 800 / 980 mm Pallet working surface: 630 x 630 mm Pallet load capacity: 1,200 kg High-torque spindle max speed: 8,000 rpm Rapid traverse rate (X, Y, Z): 50 m/min Tool magazine capacity: 240 tools Spindle motor power (30 min / continuous): 37 / 30 kW Machine Configuration: 240-position RACK tool magazine Spindle taper DIN 69871 – ISO 50 Tool breakage detection in magazine Index table with 1° indexing FASTEMS interface, model MLS-MD Spindle speed 8,000 rpm – 37/30 kW TOOL IC SYSTEM BALLUFF interface No. 600 macro variables No. 1 load monitor No. 200 storable programs No. 512 tool life management No. 999 tool offsets No. 48 workpiece coordinate systems Data server + ATA card Mori Seiki scraper-type chip conveyor with drum filter Codeykpg Hopfx Acpsrh MARPOSS application, model MIDA T25G, with E86N radio transmission system META pumping unit, model M 50/50, partial filtration system, 50 bar high pressure COMET drilled pallet Instruction manuals and CE Declaration of Conformity

Condition: excellent (used), Year of construction: 2012, Technical specifications: 5-axis machine: X, Y, Z, C, B Travel distances (X/Y/Z): 500 / 450 / 400 mm Travel range B axis: +110/-5° Travel range C axis: 360° CNC control: SIEMENS 840D Table width: 500 mm Table diameter: 630 mm Table angle adjustable in degrees Max. workpiece weight: 200 kg Number of tool changer positions: 30 Spindle speed: 20 – 10,000 rpm Crodpfxjyzzpvo Acpeh Motor power: 13 kW Dimensions (L x W x H): approx. 3400 x 2550 x 2200 mm Machine weight: approx. 4.8 t Additional equipment: Workpiece measuring probe Chip conveyor Condition: Very good condition, little used, approximately 12,850 operating hours

Condition: used, Year of construction: 2013, x-travel 735 mm y-travel 650 mm z-travel 560 mm control 840D sl FD operate Siemens turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 35 / 24 kW max. Torque 119 Nm tool taper HSK-A63 DIN 69893 table diameter 680 mm max. table load 600 kg max. workpiece sizes 650 x 650 x 500 mm swivellable +/- 120 ° rotatable 360 ° number of toolpositions 30 pos. Crodpozipzyofx Acpoh tool taper HSK-A63 max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 315 mm max. tool weight 8,0 kg change-time chip to chip ca. 4,9 sec feed speeds max. 40.000 mm/min rapid traverse 40 m/min total power requirement 65 kVA weight of the machine ca. 11,6 t dimensions of the machine ca. 4,0 x 3,0 x 2,95 m 5 Axis CNC - MachiningCenter Universal DMG - DMU 65 FD monoBLOCK - Swivel-Rotary-Table - without tools - only 8,444 operating hours - only 2,246 spindle hours - Air blast cooling through spindle center - MDynamics package - Power failure safety package - Coolant ring jet: 7x air jets, 13x water jets - Tropical package (35° – 50° Celsius) - Coolant unit (ICS) with two pressure levels: 40 and 80 bar - Use of special tools (18 kg / 370 mm)

Condition: used, Year of construction: 1995, overall weight: 5,500 kg, center distance: 650 mm swing over bed: 520 mm bar capacity: 78 mm tool turret: 10 tools maximum spindle speed: 3500 rpm Crodpfx Acez Eaiqspoh weight: 5500 kg

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) Crsdpfozr Hgxex Acpjh * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: good (used), Year of construction: 1998, functionality: fully functional, Maximum turning diameter: 650mm, Maximum Machining length: 863mm X345 Z900mm, live tooling, C-axis, spindelbore 130mm. MSC 501 (Fanuc) Cjdpfx Aoz Api Dscpsrh

Condition: used, Year of construction: 1999, functionality: fully functional, machine with 65mm bar passage C-axis with double turret (upper turret motorized) tailstock bar feeder interface FANUC CNC year 1999 CE standards complete with manuals and tool holder set. Spindle Speed 0-4,000 rpm Spindle Diameter 200 mm (160 mm) X-axis Travel 235 (195+40) mm Z-axis Travel 500 mm Maximum Turning Diameter over Bed 680 mm C-axis 0.01° Turret 12 + 8 Tools Rapid Traverse X 18 m/min Z 24 m/min Number of Tools 12 M + 8 Motorized Tools YES on the upper turret Tool Change Time 0.7 sec Credpfx Acoz Hn A Uopjh Machine Weight 6,500 kg Dimensions (length x width x height) 4000 x 2200 x 2300h

Year of construction: 2007, condition: ready for operation (used), Turning diameter: 420mm, turning length: 820mm, spindle bore: 105mm, speed: 3000rpm, spindle power: 22kW, travel X/Z: 280mm/820mm, tool positions: 10, drive tool speed: 6000rpm. Machine dimensions X/Y/Z: approx. 4400mm/2100mm/2300mm, weight: approx. 6000kg, control: Mitsubishi M-720BM (MAPPS 2), operating hours: 10000h. Including various accessories. The driven tools have never been used, only the Y-axis has run. Measuring arm and ball screw of the Y-axis are as good as new. Documentation available. On-site inspection is possible. Crsdpfov I U Iyjx Acpjh

Condition: used, Year of construction: 1991, Mori Seiki MV-40B Year of manufacture: 1991 Control: Fanuc/Mitsubishi Travel distances X/Y/Z: 800x400x500 Machine weight: 6050 kg Condition: Still powered on, fully functional. Single-shift operation. Detailed video: ?is=jngWbKO9ybU__SsR Mori Seiki MV-40B Year of manufacture: 1991 Control: Fanuc/Mitsubishi Travel distances X/Y/Z: 800x400x500 Machine weight: 6050 kg Condition: Still powered on, fully functional. Single-shift operation. TECHNICAL DATA - MODEL: MV-40B TRAVEL Max. table travel (X-axis): 800 mm (31.50 in.) Max. saddle travel (Y-axis): 410 mm (16.14 in.) Max. spindle head travel (Z-axis): 510 mm (20.08 in.) Distance from spindle nose to table surface: 150 - 660 mm (5.91 - 25.98 in.) Distance from spindle center to stand front: 755 mm (29.72 in.) TABLE Table size: 1100 x 450 mm (43.31 x 17.72 in.) Max. table load: 700 kg (1540 lb) T-slots (number x size x spacing): 4 x 18 x 100 mm (0.16 x 0.71 x 3.94 in.) SPINDLE Max. spindle speed: 8000 min^-1 [Option: 10000, 12000] Number of spindle speed steps: 2 Spindle taper: No. 40 Front bearing diameter: 65 mm (2.56 in.) FEED Rapid traverse speed (X, Y): 20000 mm/min (787.40 in./min) Rapid traverse speed (Z): 590.55 mm/min (23.25 in./min) Cutting feed rate (X, Y, Z): mm/min (0.85 in./min) Manual feed rate (MF-M4): 0 - 1260 mm/min (0 - 49.61 in./min) [15 steps] Manual feed rate (MF-M5, MY-M4): 0 - 2000 mm/min (0 - 78.74 in./min) [20 steps] Csdpfx Aezwt Elecpjrh AUTOMATIC TOOL CHANGER (ATC) Tool shank: BT-40 Pull stud: 90° special type [MAS P40T-I 45°, II 60°] Number of tool positions: 20 [Option: 30] Max. tool diameter (with adjacent tool): 80 mm (3.15 in.) Max. tool diameter (without adjacent tool): 125 mm (4.92 in.) Max. tool length: 250 mm (9.84 in.) Max. tool weight: 8 kg (17.6 lb) Tool selection: Technical memory random MOTORS Spindle motor (30 min / continuous operation): AC 7.5 / 5.5 kW (10.05 / 7.37 HP) Feed motor (X, Y): 0.9 kW (1.21 HP) Feed motor (Z): 2.8 kW (3.75 HP) Lubricant pump motor: 0.025 kW (0.033 HP) Coolant pump motor: 0.18 kW (0.24 HP) POWER & AIR Electrical connection value (MF-M4): 30.6 kVA Electrical connection value (MF-M5): 31.2 kVA Electrical connection value (MY-M4): 40.2 kVA Compressed air consumption: 0.5 MPa (5 kg/cm²), 260 Nl/min TANK CAPACITIES Lubricant tank: 6 l (1.58 gal) Coolant tank: 135 l (35.64 gal) DIMENSIONS & WEIGHT (INSTALLATION) Max. height: 2770 mm (109.06 in.) Required floor space (W x D): 2480 x 2276 mm (97.64 x 89.61 in.) Total weight (including NC control): 6050 kg (13310 lb)

Condition: used, Year of construction: 2002, turning diameter 390 mm turning length 507 mm control MSG 805 MAPPS max. turning diameter 390 mm greates pass round over bed 680 mm Swing dia. over traverse guideway 510 mm centre distance 618 mm turning speed range - main spindle 45 - 4.500 min/-1 power capacity - main spindel 11 / 7,5 kW spindle bearing diameter 110 mm spindle bore 73 mm max. bar capacity 51 mm Credpfjvzhiqox Acpeh spindle nose JIS A2-6 chucking diameter 210 mm C-Axis 0,001 ° x-axis 235 (195+40) mm z-axis 520 mm number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tool stations max. 3.000 min -1 power capacity driven tool-stations 5,9 / 4,5 kW Shank height for square tool 25 mm Drill shank diameter max. 50 mm turret change time 0,2 sec. tailstock adjustment 490 mm dia. of quill 85 mm taper of center MT 4 quill stroke 120 mm rapid traverse X: 18 / Z: 24 m/min Tipp feed 0 - 1.260 mm/min total power requirement 30,1 kW weight of the machine ca. 4,5 t dimensions of the machine ca. 5,0 x 2,5 x 2,5 m CNC - Turning- and Millingcenter MORI SEIKI - SL 204 MC

Condition: like new (used), Year of construction: 1985, Parts shown by hand not come. 4 axis not come with machine. Crodpfxegw Shrs Acpoh

Condition: excellent (used), Year of construction: 2007, Mori Seiki NH6300 DCG Horizontal Machining Center Installation year: 2007 BT 50 spindle, 10,000 rpm High-pressure coolant through the spindle, 50 bar, with a dedicated paper filter tank 10 pallets, 630 x 630 Continuous B-axis Axis travels: X900, Y800, Z980 Csdpoz Ea Dhefx Acpsrh 180-position tool magazine Tool breakage detection in the magazine Dust extraction system FMS Fastems linear 10-pallet system (5+5) 2 loading stations
