Used Pipe Center for sale (14,370)

Condition: ready for operation (used), Year of construction: 2014, machine/vehicle number: 89867, functionality: fully functional, travel distance X-axis: 3,765 mm, travel distance Y-axis: 1,875 mm, travel distance Z-axis: 324 mm, number of slots in tool magazine: 12, overall weight: 4,000 kg, TECHNICAL DETAILS Working area X-axis: 3,765 mm Working area Y-axis: 1,875 mm Working area Z-axis: 324 mm Table length: 3,600 mm Table width: 1,800 mm Tool holding system: HSK-F63 Tool changer positions: 12 positions MACHINE DETAILS Number of milling spindles: 1 piece Weight: 4,000 kg Transport packages: 1 piece EQUIPMENT Flat table BiesseWorks system/software Safety mat Drilling tool included Saw unit included Labelling machine Loading system Fsdpey Nxybofx Amyjpg Unloading system

Condition: ready for operation (used), Year of construction: 2000, operating hours: 23,574 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, controller model: Siemens Sinumerik 840D, spindle speed (max.): 8,000 rpm, The following machine components have been renewed: Fpjdpfx Amoy Nbunsyog - Motor & pump of the hydraulic system - Hydraulic and pneumatic hoses (partially) - Control cabinet LT module replaced - Drum of the Knoll system TECHNICAL DETAILS Travel distance X-axis: 600 mm Travel distance Y-axis: 560 mm Travel distance Z-axis: 560 mm B-axis: 360 x 0.001° (60 rpm) Spindle speed: 8,000 rpm Table size: 6 pallets, each 500 x 400 mm Table width: 400 mm Table length: 500 mm Table load capacity: 350 kg Working feed rate: 1 - 60,000 mm/min Rapid traverse: 60 m/min MACHINE DETAILS CNC control model: Siemens Sinumerik 840D Total length: 7,000 mm Total width: 5,000 mm Coolant supply: 50 bar Coolant system capacity: approx. 1,100 L Motor power: 13 kW / 20 kW Torque: 124 / 191 Nm Total power requirement: 20 kW Dimensions & Weight Space requirement (L x W): 7 x 5 m Machine weight: approx. 16,000 kg Operating hours Power-on time: approx. 48,804 h Spindle operating hours: total 23,574 h EQUIPMENT - Documentation/Manual - Steplessly adjustable spindle speed - Chip conveyor - Knoll cooling unit with drum filter (30/40/50 bar via M-command) - Tool measurement: Renishaw probe - Tool breakage monitoring in the working area - Pallet storage (4 positions) - Pallet sequence operation - Fully enclosed work area in accordance with UVV - Network capability - Technical documents & layout plan

Condition: ready for operation (used), Year of construction: 2016, operating hours: 9,956 h, functionality: fully functional, machine/vehicle number: 17211, travel distance X-axis: 650 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 680 mm, controller model: Siemens Sinumerik 840 D solution Line, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS X-axis travel: 650 mm Fsdpfx Amey Nbt Deyepg Y-axis travel: 650 mm Z-axis travel: 680 mm Table width: 400 mm Table height: 30 mm Table length: 500 mm Table load capacity: 500 kg Max. workpiece height: 850 mm Max. pallet load: 500 kg Pallet changer: 2 pallets, automatic Change time: approx. 8 s Tool magazine: 60 tools Spindle speed (max.): 18,000 rpm Spindle motor power: 32,400 W MACHINE DETAILS Control system: Siemens Sinumerik 840 D Solution Line Dimensions & Weight Dimensions (L x W x H): approx. 5,150 x 2,800 x 3,025 mm Weight: approx. 12,800 kg Noise emission: 80 dB(A) according to EN ISO 3744 Coolant supply: 80 bar Operating hours Total operating hours: 27,412 h Automatic operation: 11,155 h Spindle hours: 9,956 h EQUIPMENT Documentation/manual Chip conveyor Siemens spindle diagnostics & remote diagnostics (Teamviewer) Energy-efficient system with regenerative feedback Standby mode for energy savings Direct drive NC rotary table 6-channel clamping hydraulics (90 bar) Increased spindle torque for high-performance machining Torque support Central coolant supply system Renishaw OMP60 optical touch probe Tool breakage control Pallet sequence operation Crane infeed/outfeed software Signal light for operating states Work area/machine equipment: shower nozzle, cleaning pistol, vortex nozzle, emission extraction interface Foot switch for air nozzle Documentation: fully digital (PDF)

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,082 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, Important information: Auction extended by 14 days. Controller has been subsequently identified as HEIDENHAIN iTNC 530. Previous specification: TNC 426. A new spindle was installed in January 2025! The machine has been regularly maintained! TECHNICAL DETAILS Travel X-axis: 2,800 mm Travel Y-axis: 2,200 mm Travel Z-axis: 800 mm Feeds Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous operation) vertical: 10,000 rpm Spindle speed S1 (continuous operation) universal swivel head 2-axis: 18,000 rpm Fsdpfx Ajy Dgyfjmyepg MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Electrical data Supply voltage: 400 V (–15%, +10%) Frequency: 50 Hz Current consumption: 101.1 A Installed total power: 59.8 kW Operating hours Power-on hours: 98,755 h Program run time: 61,082 h EQUIPMENT High-rigidity gantry design Precision linear guides and ball screws Generous workspace with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, die, and machine building Documentation and acceptance certificate according to ISO standards Tool changer Cooling system Chip conveyor Swiveling milling head with 4th/5th axis

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 675002, travel distance X-axis: 650 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, TECHNICAL DETAILS Travel X-axis: 650 mm Travel Y-axis: 1,100 mm Travel Z-axis: 500 mm C-axis rotation: 360° MACHINE DETAILS Fpodpfoy Rxryex Amyog Control: CNC Dimensions & Weight Dimensions (L x W x H): 3,500 x 1,800 x 2,800 mm Net weight: 13,000 kg EQUIPMENT Chip conveyor Tool magazine Probe

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,067 h, functionality: fully functional, machine/vehicle number: 122616, travel distance X-axis: 500 mm, travel distance Y-axis: 95 mm, travel distance Z-axis: 1,650 mm, controller model: OKUMA OSP P200L, center width: 1,500 mm, TECHNICAL DETAILS Travel X-axis: 500 mm Travel Y-axis: 95 mm Travel Z-axis: 1,650 mm Turning diameter over bed: 550 mm Power: 22.0 kW Distance between centers: 1,500 mm Spindle bore: 80 mm Fedpfjy Rxprjx Amyjpg Counter spindle speed: 4,500 rpm Tool magazine: 44 positions Tool holder: HSK-F63 MACHINE DETAILS Control: OKUMA OSP P200L Dimensions & Weight Dimensions (L x W x H): 5,100 x 2,800 x 2,900 mm Transport weight: 13,700 kg Shipping packages: 7 units Operating hours: 19,067 h EQUIPMENT Automatic workpiece feeder with controlled arm by Pneumotec Automatic bar feeder by LNS Quick Load Servo III Counter spindle VAC-MB11 Milling head with automatic tool changer Turning turret: 12-position tool changer Chip conveyor Turret head Driven tools Bar loader Three-jaw chuck Tool magazine C-axis Documentation CE marking

Condition: excellent (used), Year of construction: 2014, Willemin-Macodel SA Model 308B 5 Axis Machining Center Mfd. 2014 X 160 mm Y 120 mm Z 150 mm # Axis 5 Power 7 hp RPM 30,000 RPM # ATC 28 Taper HSK E32 Fedpfx Amjy Abcxjyepg Willemin-Macodel SA Model 308B 5 Axis Machining Center (2014) X1 6.300" Y1 4.720" Z1 5.910" A1 360.000° B1 130.000° Taper HSKE32 Rapid Feeds 1,181ipm Equipped With 5 Axis 28 Position ATC 30000 RPM Pallet Recognition Fire Protection Auto Fire Suppression Filter Mist Extraction

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE LEVEL PADS TURN MILL DRIVE Fpodpfxeyzkdvs Amyeg EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Fsdpfx Amsyzkdcsyopg Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Year of construction: 2020, condition: excellent (used), machine/vehicle number: 101262, Porta Solutions MULTICENTER 3 SPINDLE 3 Spindle Machining Center Mfd. 2020 SN: 101262 Control: Fanuc Panel i Fsdpfxovn T Das Amyepg Chip Conveyor

Condition: excellent (used), Year of construction: 2022, Swiss CNC Chucker-Convertible Sliding Headstock Lathe W/ "B" Axis Fpjdpfxeyq S Utj Amysg

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,250 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 540 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 32 m/min, feed rate X-axis: 32 m/min, feed rate Y-axis: 32 m/min, feed rate Z-axis: 32 m/min, controller manufacturer: Okuma, controller model: OSP P200M-H, rotary table diameter: 500 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Okuma MU500VA CNC Vertical Machining Centre (2007) Equipped with OKUMA OSP P200M-H CNC CONTROL 20" ROTARY PLATEN 4TH AND 5TH AXIS BUILT IN TRUNION 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE TOOL LENGTH MEASURING Travels X-axis (saddle left/right) – 1250mm, Y-axis (pallet front/back) – 660mm, Z-axis (spindle up/down) – 540mm, A-axis – +20~-110 deg., C-axis – 360 deg., Table surface to spindle nose – 127~667mm Table Table size – ø500mm, Max work size – ø730xh500, Floor to table top – 1073mm, Max load capacity – 500kg Spindle Spindle speed – 15000rpm, Turning specification – C-axis table 1000rpm , No. of spindle ranges – Infinitely variable, Tapered bore – 7/24 taper No.40, Bearing dia – ø70mm Feed Rapid traverse – X-Y: 40m/min, Z:32m/min, Rapid traverse (A-C) – 18,000 deg/min, Cutting feed rate – X-Y-Z: 32m/min Motors Spindle (10min/cont) – 11/7.5kW ATC Tool shank type – MAS BT40 Big plus, Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random Fodpfxoyf Ncqj Amyjpg ATC Retention knob type – MAS 2, Tool capacity – 32, Max. tool dia (w/ adjacent tool) – ø90mm, Max. tool dia (w/o adjacent tool) – ø125mm, Max. tool length – 400mm, Max. tool mass – 8kg, Tool selection – Memory random

Condition: excellent (used), Year of construction: 2007, machine/vehicle number: 126937, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, number of slots in tool magazine: 32, controller manufacturer: Okuma, controller model: P200M-H, rotary table diameter: 400 mm, OKUMA MU-400VA 5-AXIS CNC VERTICAL MACHINING CENTER, FROM AEROSPACE COMPANY, 16" ROTARY PLATEN, 4TH AND 5TH AXIS BUILD IN TRUNION, 15,000 RPM 32 POSITION TOOL CHANGER, OSP P200M-H CNC CONTROL Okuma MU400VA CNC Vertical Machining Centre (2007) Description: Control OSP P200 Table working surface - 15.75", Max table load - 600lbs, X Axis travel - 30", Y Axis travel - 18.11", Z Axis travel - 18.11", A Axis trunnion tilt - +20 to -110deg, B Axis table rotation - 360deg, Table surface to spindle nose - 3.94" - 22.05", Rapids X & Y - 15.75 IPM, Spindle taper - CAT 40, Spindle speeds - 16000 RPM, Spindle Motor - 20HP, Tool magazine capacity - 32 Table Size 15.75" Dia Table Load Capacity 660 LBS # Axis 5 X-Axis (Longitudinal Travel) 30" Y-Axis (Cross Travel) 18.11" Z-Axis (Vertical Travel) 18.11" A-Axis (Trunnion Tilt Range) (±25°) +20° to -110° C-Axis Table Rotation Positioning 360,000° Max/Min Clearance Table Top to Spindle Nose 22.05" / 3.94" Fpsdpfsu Illasx Amysg Distance Floor to Table Top 41.34" Rapid Traverse Rate (X, Y, & Z Axis) 1,574 IPM Spindle Horsepower 20 HP Max Spindle Speed 15,000 RPM Spindle Taper MAS BT40 Big plus Coolant Thru Spindle yes Automatic Tool Changer Capacity (ATC) 32 Electrics 220/3/60 Approximate Machine Dimensions 114" x 160" Approximate Machine Height 116" Approximate Machine Weight 17,000 LBS OKUMA OSP P200M-H CNC CONTROL BUILT IN 4TH AND 5TH AXIS 16" DIAMETER TRUNION TABLE 15,000 RPM SPINDLE LASER TOOL SETTER 32 POSITION AUTOMATIC TOOL CHANGER COOLANT THRU SPINDLE CHIP CONVEYOR

Condition: good (used), machine/vehicle number: 224194-0451, Euroturn (ZPS Mori-Say) 6-32 rebuilt multi-spindle screw machine SN: 224194-0451 6 Spindles 32mm Capacity Voltage: 480v With Spindle Stopping Siemens Control System Pickoff and Back Finish Fjdpfstic Hqjx Amyjpg Stock Reel Cover and Stand Sedimentation Tank Upgrade: Servo Feed Drive in place of main spindle drive Upgrade: Repair Drum Path Quality Inspection Report Machine Install 1-Year Warranty Turnkey Available Call for more information

Condition: used, Year of construction: 2013, 2013 SMC Group Routech Accord 30FX CNC machining center, high performance multi-function work table, 400V, 3 phase, X-axis 20' 10", Y-axis 5' 4.7", dual machining heads, rotation speed 6-18,000 RPM, onboard Rapid 12-tool changer, Rapid 16 rear tool changer, work table, pod, and rail, gantry type, has SMC Group CNC control with remote pendant control, 480V, 3 phase, Becker, model 271407, rotary vane vacuum pump, and (1) Texa, model SAW50RBSBCC000, chilling unit with transformer, winning bidder responsible for proper removal. Fedexdc T Sopfx Amyopg

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Two machines in one, made by the best Swiss CNC manufacturer. 1. Log milling 2.Timber Framing. This machine produced machined log structures for 6 years, (dormant since), of high precision and quality, for very discerning buyers. For progressive builders who want to automate milled log structures up to 8" x 12" material, or use strictly for timber framing. Best suited for USA or Canada customer, for easy truck transport. Delivery, set-up, calibration, operational training arranged at cost. Self-contained Fpedpfewvwl Aex Amyjg Compact design, only 10 feet deep, 8 feet wide. All processes are performed inside the enclosure. Cut-offs fall into and are removed from a central pit. Mill shavings are extracted by air suction, leaving work area remarkably clean. So quiet, you can have a conversation beside the working machine.

Condition: excellent (used), Year of construction: 1997, turning diameter over cross slide: 210 mm, spindle bore: 40 mm, turning diameter: 330 mm, turning diameter over bed slide: 330 mm, turning diameter over top slide: 210 mm, Model: Student 2500 Gap Bed Lathe Swing Over Bed: 330mm Swing Over Topslide: 210mm Swing In Gap: 480mm Distance Between Centres: 1000mm Spindle Speeds: 40-2500 RPM Spindle Bore: 40mm Motor: 2.2 KW Fsdpsy N Uplofx Amyepg Machine with: 3 Jaw Chuck Collet Chuck and Collets Digital Readout Quick Change Toolpost with Holders Dimensions: 2130 x 1020 x 1450mm High Weight: 800 KGS

Condition: excellent (used), Year of construction: 2007, operating hours: 1,000 h, functionality: fully functional, turning diameter over cross slide: 196 mm, spindle bore: 42 mm, turning diameter: 350 mm, turning diameter over bed slide: 350 mm, turning diameter over top slide: 196 mm, center height: 175 mm, turning length: 650 mm, Model: Multiturn 1000 Control: Fanuc Oi-TC Year: 2007 S/No.: N91013 Swing Over Bed: 350mm Swing In Gap: 535mm Swing Over Top Slide: 196mm Distance Between Centres: 650mm Spindle Speeds: 1-3500 RPM (3 Ranges) Spindle Bore: 42mm Motor: 7.5 KW Fpodoy N Uk Nopfx Amyog Machine with: 150mm 3 Jaw Chuck Duplumatic 8 Station Turret Turret Tool Holders Tail Stock Coolant Pump

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, table width: 450 mm, table length: 1,200 mm, spindle nose: BT40, Dugard Eagle 1000 Vertical Machining Centre Model: 1000 VMC Year: 2005 Control: FANUC Oi-MD Table Area: 1200mm x 450mm ‘X’ Traverse: 1020mm ‘Y’ Traverse: 510mm ‘Z’ Traverse: 510mm Fjdjy N Ukcopfx Amyjpg Max. Spindle Speed: 8000 RPM Spindle Taper: BT 40 ATC capacity: 20 station Machine with: Swarf Conveyor

Condition: excellent (used), Year of construction: 2012, travel distance X-axis: 610 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 450 mm, table width: 450 mm, table length: 800 mm, spindle speed (max.): 8,000 rpm, Model: 610L Control: Fanuc Series Oi-MC Year: 2012 Table Area: 800 x 450mm ‘X’ Axis: 610mm ‘Y’ Axis: 460mm Fsdpfx Aoy N Uh Uomyepg ‘Z’ Axis: 450mm Spindle Taper: BT 40 Spindle Speeds: 8000 RPM Carosel 12 Station Tool Changer Dimensions: 2200 x 2300 x 2300mm high Weight: 3400 KGS

Condition: used, Year of construction: 1997, MORI SEIKI SL-35 TURN MILL CENTRE MAKE MORI SEIKI, MADE IN JAPAN MODEL SL-35 YEAR 1997 CONTROL FANUC MSC 516 CHUCK DIA 400.0 mm MAX. TURNING DIA 400.0 mm MAX. TURNING LENGT 780.0 mm SWING OVER BED 600.0 mm OVER CROSS SLIDE 425.0 mm MAX. SPINDLE SPEED 9-2500 rpm TURRET 12 STATIONS TAILSTOCK YES SPINDLE BORE 82.0 mm SPINDLE NOSE A8 RAPID TRAVERSE RATE X: 12,000mm/min & / Z: 15,000mm/min PLUS SWARF CONVEYOR TOOL SETTING PROBE GOOD RANGE OF TOOLING MACHINE MANUALS Fedpfx Asv N D Rtemyspg CLEAN

Condition: used, Year of construction: 2000, travel distance X-axis: 600 mm, travel distance Y-axis: 430 mm, travel distance Z-axis: 460 mm, MORI SEIKI SV-400 WITH 4TH AND 5TH AXIS VERTICAL MACHINING CENTRE MAKE MORI SEIKI, MADE IN JAPAN MODEL SV-400 YEAR 2000 CONTROL MORI FANUC MSC 501 TABLE SIZE 900.0 x 500.0 mm TRAVERSES (XYZ) X: 600.0 mm Y: 430.0 mm Z: 460.0 mm SPINDLE SPEED Up to 12,000 rpm SPINDLE TAPER BT 40 Fsdpfx Amstvau Hoyopg ATC 30 STATIONS RAPID TRAVERSE XYZ: 32,000 mm/min FEEDRATE 1-16000mm/min PLUS NIKKEN 4th and 5th AXIS UNIT RENISHAW PROBBING TWIN SWARF CONVEYOR COOLANT SYSTEM

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Fedpfxjx Th Nyj Amyopg Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 760 MM Bar Capacity – Main Spindle Ø 81 MM Fpedpfxsx Thu No Amyeg MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Fjdpfx Asx Tqkmemyopg Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE
