Used Vertical Router for sale (7,536)

Condition: used, functionality: unexamined, machine/vehicle number: ML944E08, spindle speed (max.): 8,000 rpm, type of input current: three-phase, overall weight: 5,500 kg, input voltage: 400 V, CHEVALIER QP2033-L vertical machining center. The machine is available for inspection in Riga, Latvia. The machine is currently powered on and can be inspected by appointment. Kjdjzfgmxopfx Airedn Additional photos and technical information are available upon request.

Condition: ready for operation (used), Industrial CNC router for sale – AXYZ Automation Group Automation Series 6010, fitted with a high-speed Perske GmbH spindle. This is a large-format production machine suitable for woodworking, plastics, signage, and light aluminium work. Solid gantry construction with vacuum bed – ideal for sheet materials. ⚙️ Key Specs Model: AXYZ 6010 (6000 Series) Kedjy A R Dxopfx Airjdn Bed Size: approx. 10ft x 6ft (3048 x 2150mm) Spindle: Perske high-speed spindle Power: approx. 4kW / 5.5HP Speed: up to 18,000 – 21,000 RPM Bed: Vacuum table (grid type) Axes: 3-axis gantry CNC Power: 3-phase Build: Heavy-duty industrial frame

Condition: new, Year of construction: 2024, New Grundfos Pump - Vertical, multistage centrifugal pump with integrated frequency converter. inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via DIN flanges. The pump is fitted with a 3-phase, fan-cooled asynchronous motor. The motor includes a frequency converter and PI controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement. An operating panel on the motor terminal box enables setting of required setpoint as well as setting of pump to "Min." or "Max." operation or to "Stop". The operating panel has indicator lights for "Operation" and "Fault". Communication with the pump is possible by means of Grundfos GO Remote (accessory). The remote control enables further settings as well as reading out of a number of parameters such as "Actual value", "Speed", "Power input" and total "Power consumption". The terminal box holds terminals for these connections: • pump start/stop input (potential-free contact) • remote setpoint setting via analog signal, 0-10 V, 0(4)-20 mA • 10 V voltage supply for setpoint potentiometer, Imax = 5 mA • three analog sensor inputs, 0-10 V, 0(4)-20 mA • 24 V voltage supply for sensor, Imax = 40 mA • one analog output Kdjdjyug R Rspfx Airon • three digital inputs • two Pt100 inputs • two potential-free fault signal relays with changeover contact, reporting "Fault", "Operation" or "Ready" • RS-485 GENIbus connection • interface for Grundfos CIM fieldbus module

Condition: new, Year of construction: 2024, NEW Grundfos - The pump is fitted with a 3-phase, fan-cooled, permanent-magnet, synchronous motor. The motor efficiency is classified as IE5 in accordance with IEC 60034-30-2. The motor includes a frequency converter and PI controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement. An operating panel on the motor terminal box enables setting of required setpoint as well as setting of pump to "Min." or "Max." operation or to "Stop". The Grundfos Eye indicator on the operating panel provides visual indication of pump status: "Power on": Motor is running (rotating green indicator lights) or not running (permanently green indicator lights) "Warning": Motor is still running (rotating yellow indicator lights) or has stopped (permanently yellow indicator lights) "Alarm": Motor has stopped (flashing red indicator lights). Communication with the pump is possible by means of Grundfos GO Remote (accessory). The remote control enables further settings as well as reading out of a number of parameters such as "Actual value", "Speed", "Power input" and total "Power consumption". The terminal box has a number of inputs and outputs enabling the motor to be used in advanced applications where many inputs and outputs are required: • two dedicated digital inputs • three analog inputs, 0(4)-20 mA, 0-5 V, 0-10 V, 0.5 – 3.5 V • 5 V voltage supply to potentiometer and sensor • one analog output, 0-10 V, 0(4)-20 mA Kodsyug Hxspfx Airjdn • two configurable digital inputs or open-collector outputs • two Pt100/Pt1000 inputs • LiqTec, dry-running protection sensor input • Grundfos Digital Sensor input and output • 24 V voltage supply for sensors • two signal-relay outputs (potential-free contacts) • GENIbus connection • interface for Grundfos CIM fieldbus module.

Condition: used, functionality: unexamined, total height: 5,000 mm, total width: 1,200 mm, total length: 3,600 mm, input voltage: 400 V, input frequency: 50 Hz, DenoLift Vertical Carousel / Paternoster approx. 5 m – Fully Functional – Industrial We have a used DenoLift carousel (paternoster) that we are considering selling and would like to know if this system might be of interest to you. Specifications (indicative): Kdedpfxoyplqre Airjn Brand: DenoLift (Denocard) Type: vertical carousel / paternoster Dimensions: approx. 3.6 meters long × 1.2 meters wide Height: approx. 4 – 5.5 meters Control: numeric keypad with LED display (older model) Price: 5000 EUR This is an industrial storage system with significant capacity. The installation is currently set up and can be dismantled and collected by arrangement. Upon request, we can provide additional photos, a video of the system in operation, and any available technical data.

Condition: excellent (used), Horizontal/vertical rotary table Chuck: Ø 350 mm Shelf diameter: Ø 400 mm Height without mandrel: 140 mm Total height: 250 mm Base dimensions: Length 430 mm x Depth 370 mm Kdjdpfx Aieyr Numjron Weight: approx 150 kg Possibility to work horizontally or vertically The increment is done by the front handle

Condition: like new (used), 30m3 insulated stainless steel tank Dim. 3.40x 6.80. 12 cm insulation, insulated with wool and metal sheet lower bottom insulated with polyurethane foam. Kdedshr Rp Sopfx Airjn We offer transport with our own semi-trailer.

Condition: excellent (used), Velo Kieselgur filter vertical 10 m2 used in beverage industry, in very good condition. Complete with wiring and control desk. Kodoq U A Huepfx Airjdn

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Kdsdpfxoxc I Dgj Airjn Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm

Condition: new, functionality: fully functional, power: 400 kW (543.85 HP), fuel type: electric, color: dark red, overall weight: 38,000 kg, axle configuration: 2 axles, brakes: other, Year of construction: 2026, Mobile vertical shaft crusher is a specially designed mobile stone crushing screening plant on a portable double axle chassis, consisting of feeder bunker, VSI 900 Vertical shaft impact crusher, vibrating screen and conveyor belts. It can be fed directly with the material in stream areas or it can produce sand and gravel from the sieve material in the crushing plants. The GNR - MVSI 900 Vertical Shaft Crusher that gives this facility its name; - Maximum feeding size 50-55 mm - Rotor size 900 mm Ksdpfewnp Akox Airsdn - Engine power 2x200 kW - The capacity 80-210 tons per hour. For more information please call us.

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, table width: 700 mm, table length: 500 mm, No minimum price – guaranteed sale to the highest bidder! Machining center with a manually rotatable and swiveling machine table! TECHNICAL DETAILS Travel ranges x-axis: 500 mm y-axis: 400 mm z-axis: 400 mm Table Table surface: 700 x 500 mm Spindle Tool holder: 40 SK/ISO Spindle speeds: 20 - 4,500 rpm Spindle drive: 12 kW Feed rates Feed rates: 5,000 mm/min Kdjdpfxezb Uz Dj Airen Control system: Heidenhain TNC 124 MACHINE DETAILS Total power requirement: 13 kW Machine weight: approx. 2,800 kg Space requirement: approx. 3 x 2 x 2 m

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: YS-2674, turning height: 1,250 mm, workpiece weight (max.): 5,000 kg, turning diameter: 1,600 mm, faceplate diameter: 1,250 mm, controller model: Fanuc 0i-TD, TECHNICAL DETAILS Faceplate diameter: 1,250 mm Max. torque on faceplate: 12,500 Nm Turning height: 1,250 mm Max. turning diameter: 1,600 mm Max. workpiece weight: 5,000 kg Table speed: 2 - 300 rpm Travel range X-axis: 1,475 mm Travel range Z-axis: 900 mm Kodpfx Aezb Uy Tsirodn Rapid traverse: 10 m/min Spindle taper: ISO BT50 Number of tool positions: 12 MACHINE DETAILS Control system: Fanuc 0i-TD Total power: 75 kW Dimensions & Weight Footprint: approx. 4.7 x 5.8 x 5.5 m Machine weight: approx. 32 t EQUIPMENT Tool changer magazine for 12 turning tools with BT 50 shank Note: The €5,000 for dismantling and loading applies to the preparation for EU transport. Preparation for sea transport is possible; costs upon request.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 42,400 h, functionality: fully functional, travel distance X-axis: 800 mm, spindle speed (max.): 5,000 rpm, turning length: 300 mm, spindle bore: 79 mm, controller model: Siemens 840D, TECHNICAL DETAILS Turning length: 300 mm Travel range X-axis: 800 mm Travel range Z-axis: 300 mm Speed range main drive: 20 - 5,000 rpm Speed range C-axis: 0 - 100 rpm Spindle bore: 79 mm Torque main drive: 200 Nm Torque at the spindle: 240 Nm Torque clamping device: 28 Nm Rapid traverse X-direction: 100 m/min Rapid traverse Z-axis: 45 m/min Tools and tool magazine Number of positions in the tool magazine: 12 Speed of powered tool max.: 6,000 rpm Tool holder: VDI 40 Clamping area in the work area (W x H): 340 x 430 mm Number of T-slots according to DIN 650: 7 MACHINE DETAILS Kodpfszb Efgex Airjdn Control model: Siemens 840D Power main spindle: 27 / 20 kW Total power consumption: 50 kVA Electrical version - voltage/frequency: 3~ / 400 V / 50 Hz Interface: yes Spindle operating hours: 42,400 h Power-on hours: 93,728 h Dimensions & Weight Machine dimensions (L x W x H): 3,200 x 3,950 x 2,800 mm Chip conveyor dimensions (L x W x H): 3,400 x 1,150 x 2,180 mm Machine weight: 8 t EQUIPMENT High-pressure coolant system (capacity: 500 l) Chip conveyor with oil mist separator / industrial filter IFM 1000CTV Workpiece loading and unloading device with 20 stations Power chuck (225 mm) Hydraulics 6x various turning tool holders 2x various tool holders (rotating)

Condition: ready for operation (used), Year of construction: 2007, operating hours: 36,012 h, functionality: fully functional, travel distance X-axis: 635 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 510 mm, controller model: 3D Heidenhain i TNC 530, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 635 mm Travel range, Y-axis: 460 mm Travel range, Z-axis: 510 mm Spindle speed range: 20 - 10,000 rpm Table dimensions: 790 x 560 mm Table load capacity: 600 kg Tool holder: SK 40 Number of tool magazine slots: 20 MACHINE DETAILS Control system: 3D Heidenhain i TNC 530 Kjdpfx Aiszb Dzmoredn Total power consumption: 13.9 kW Operating hours (according to counter) Spindle hours: 36,050 h Power-on hours: 91,000 h Dimensions & Weight Dimensions (L x W x H): 3,000 x 2,000 x 2,150 mm Machine weight: 3.6 t

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, table load: 1,200 kg, rotational speed (max.): 8,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,660 mm Travel range Y-axis: 760 mm Travel range Z-axis: 660 mm Table size: 760 x 2,000 mm Table load capacity max.: 1,200 kg Tool holder: SK 40 Tool changer: 2 x 24 Tool diameter max.: 80 mm Tool diameter with free adjacent slot max.: 110 mm Tool length max.: 350 mm Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min Kdedpfx Ajzb D N Rjirsn MACHINE DETAILS Control system: MAZATROL M-PLUS Dimensions & Weight Space requirement: approx. 6.0 x 4.0 x 3.5 m Machine weight: approx. 8.1 t Total power requirement: 32.8 kVA The machine has been regularly serviced.

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Rotary table Table diameter: 400 mm Table load: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manually 350 mm) Maximum tool weight: 6 kg Kedpfszara Uox Airodn MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: ready for operation (used), Year of construction: 1998, operating hours: 26,000 h, functionality: fully functional, machine/vehicle number: J0124, travel distance X-axis: 1,800 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain iTNC 426, rotational speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,800 mm Travel range Y-axis: 850 mm Travel range Z-axis: 750 mm Spindle nose to table distance range: 200 mm - 950 mm Spindle center to column distance: 920 mm Table dimensions X: 2,000 mm Table dimensions Y: 800 mm Max. table load: 2,200 kg Tool interface: SK50 Magazine capacity: 30 Spindle speed: 6,000 rpm Feed rate: 5 m/min Rapid traverse: 12 m/min MACHINE DETAILS Control system: Heidenhain iTNC 426 Dimensions & Weight Dimensions (L x W x H): approx. 5,700 x 3,850 x 3,350 mm Weight: approx. 16,500 kg Operating Hours Kdodpezdpqwofx Airen Total operating hours: approx. 51,000 h Spindle operating hours: approx. 26,000 h EQUIPMENT 4th axis installed as a rotary table Documentation/Manual Spindle speed infinitely adjustable Chip conveyor Coolant system Vices

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 020033, spindle speed (max.): 5,000 rpm, spindle diameter: 110 mm, controller model: Siemens SINUMERIK, empty load weight: 11,000 kg, counter spindle speed (max.): 5,000 rpm, The machine is expected to be available for approximately €4,000, including loading onto a truck (FOB). TECHNICAL DETAILS Working area X1-axis: 1,190 mm Working area Y1-axis: 120 mm Working area Z1-axis: 260 mm Working area X3-axis: 540 mm Working area Y3-axis: 120 mm Working area Z3-axis: 260 mm Handling space X1-axis: 490 mm Axes and Feed Feed force X1/Z1/Y1: approx. 8/10/10 kN Feed force X3/Z3/Y3: approx. 8/10/10 kN Rapid traverse speed X1/Z1/Y1: approx. 80/40/7.5 m/min Rapid traverse speed X3/Z3/Y3: approx. 40/40/7.5 m/min Acceleration X1/Z1/Y1: 7/7/7 m/s² Acceleration X3/Z3/Y3: 7/7/7 m/s² Spindle Speed at main and counter spindle: 5,000 RPM Power at 100% duty cycle, main spindle: 20 kW Torque at 100% duty cycle: 105 Nm Power at 40% duty cycle: 27 kW Torque at 40% duty cycle: 145 Nm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose diameter (cylindrical): 140 mm Hydraulic full-stroke cylinder OVS80 - Main spindle Piston stroke: 32 mm Piston area: 34.36 cm² Clamping pressure: 8 to 80 bar Tensile or compressive force at 80 bar: max. 27.2 kN Leakage oil volume at operating pressure 80 bar: max. 2.2 l/min Hydraulic full-stroke cylinder OVS65 - Counter spindle Piston stroke: 32 mm Piston area: 26.1 cm² Clamping pressure: 8 to 100 bar Tensile or compressive force at 100 bar: max. 26.1 kN Leakage oil volume at operating pressure 100 bar: max. 3 l/min Y-axis Slide travel: 120 mm Feed force: 10 kN Rapid traverse: 7.5 m/min Resolution: 0.05 mm Speed of driven tools: 6,000 RPM MACHINE DETAILS Kedpfezdqdfox Airodn Control system: Siemens SINUMERIK Unloading device Swivel angle: 90 degrees Swivel time: 2 s Slide travel: 100 mm Rapid traverse speed: 6 m/min Workpiece weight: approx. 10 kg Workpiece diameter: 200 mm Electrical data Rated power: 45 kW Apparent power: 53 kVA Rated current: 76 A Voltage: 400 V Frequency: 50/60 Hz Dimensions and weight Dimensions with chip conveyor (L x W x H): 2,770 x 4,435 x 2,750 mm Weight: approx. 11,000 kg EQUIPMENT Two tool holders with 12 tool positions each, VDI 30 Note: Further technical data can be found in the attached data sheet. The machine is not equipped with a B-axis.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 15744, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, table load: 1,500 kg, TECHNICAL DETAILS Travel range, X-axis: 800 mm Travel range, Y-axis: 600 mm Travel range, Z-axis: 600 mm Table length: 1,000 mm Table width: 560 mm Kdedszcymzepfx Airen Table load: max. 1,500 kg Spindle connection: HSK63 Tool changer: 30 positions Rapid traverse rate: 35 m/min Acceleration: 5 m/s² MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 4,200 x 2,500 x 2,800 mm Weight: 7,200 kg Total connected load (including cooling unit): 42 kVA

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 15125250184, travel distance X-axis: 2,500 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS Number of axes: 3 Travel in X-axis: 2,500 mm Travel in Y-axis: 920 mm Travel in Z-axis: 820 mm B-axis rotation: 105° Table length: 3,100 mm Table width: 900 mm Table length: 3,100 mm Table width: 900 mm Tool holder: SK40 Max. spindle speed: 18,000 rpm MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 7,500 x 4,500 x 300 mm Net weight: 22,000 kg Kodpezdkhksfx Airsdn Shipping packages: 3 EQUIPMENT External coolant system Chip conveyor Tool magazine (30 pieces)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 216327, travel distance X-axis: 1,660 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol 640M, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Number of axes: 3 Travel range, X-axis: 1,660 mm Travel range, Y-axis: 510 mm Travel range, Z-axis: 510 mm Table length: 2,000 mm Table width: 510 mm Tool holder: ISO40 Max. spindle speed: 12,000 rpm MACHINE DETAILS Control system: Mazatrol 640M Operating time according to control system display: 40,843 h Dimensions & Weight Dimensions (L x W x H): 5,120 x 3,000 x 2,800 mm Unladen weight: 8,250 kg EQUIPMENT Chip conveyor Kdedpfxezdf Dhs Airen Tool magazine with 30 positions Tools included

Condition: ready for operation (used), Year of construction: 2009, operating hours: 3,275 h, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 510 mm, table load: 1,000 kg, rotational speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! Machine with only 3,275 spindle hours! TECHNICAL DETAILS Travel in X-axis: 1,100 mm Travel in Y-axis: 600 mm Travel in Z-axis: 510 mm Table size: 1,300 x 600 mm T-slots: 6 (size 18) Maximum table load: 1,000 kg Spindle speed range: 60 - 12,000 rpm Drive power: 10 / 17 kW Spindle mounting: ISO 40 / DIN 69871A Kjdpfx Aiozdkgaorjdn Magazine: 32 positions MACHINE DETAILS Drive power: 10 / 17 kW Internal cooling (IKZ): 20 bar Coolant tank volume: 480 l Spindle hours: 3,275 h Machine operating hours: 15,883 h Control operating hours: 17,706 h

Condition: used, machine/vehicle number: 006488, X axis working area: 2500 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Number of controlled axes: 3 axes Total number of drilling spindles: 11 Ksdpfxowuclxj Airodn

Condition: used, machine/vehicle number: 008255, X axis working area: 3050 mm Y axis working area: 850 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Total number of drilling spindles: 19 Kedpfxjx A Td Ej Airjdn Total number of tool changer positions: 4

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Ksdpfsyzkdcox Airedn Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System
