ROLLFORMING LINE 70-309

Condition: used, Year of construction: 1973, spindle diameter 130 mm x-travel 3000 mm y-travel 2000 mm total power requirement 4,5 kW Tsdpfxst Hwt Se Aknsc weight of the machine ca. 30 t Spindle Ø 130 mm Spindle taper SK 50 Working range: X = column, longitudinal 3,000 mm Y = headstock, vertical 2,000 mm Z = spindle stroke 1,000 mm Lower table 3,300 x 2.400 mm Max. weight on table 10 tons/m² Min./ max position of work spindle above table 770 / 2,770 mm Feeds 0.9 - 2,000 mm/min Quick feed for headstock and column 5,000 mm/min Quill feed 0.5 - 1,200 mm/min Speed range, partially infinitely variable 4.5 - 1,250 rpm Weight, approx. 30,000 kg Accessories / Special Features * HEIDENHAIN Digital Display for 3 axes. * Hardened guideways. * Ball screw spindles. * Infinitely variable spindle speeds and feeds. Feeds can be individually driven with motor. * Moving operating platform. * Hanging control panel. * Manual operating control. * Platform. * Hydrostatics in the column displacement. * Mounting plate 3,200 x 2,500 mm, planed, with t-slots. * Top table approx. 1,400 x 2,600 x height 900 mm, one face is handled. * Hydraulic clamping of column and slides. * Motor driven tool clamp. * Lots of accessories, including tool holders with and without tools, separate chip extractor, clamping aids, 1 angle plate, and other plates. Lots of other accessories. This is a strong machine which is very suitable for heavy cuts and therefore ideal for the machine tool industry and for tool manufacturers. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest. We have other horizontal borers on stock. Please let us know what you need.

Condition: ready for operation (used), Year of construction: 1970, functionality: fully functional, shaft length under head: 30 mm, section length (max.): 52 mm, Hilgeland CH1 KHA double-acting press Tjdpfxour N Daj Aknoc Year of construction 1970 The machine is ready for immediate use!

Condition: as good as new (ex-display), FULL LINE of Double-side Sizing-Milling & Edge Banding. Composed of the following machines: Tjdpfx Akedt Rgvenec VZ0200A) Gantry-portal Loader (Double pick-up station) "BARGSTEDT" Mod. TBH 500/D/30/12 VZ0200B) 1st Double-side Sizing & Edge Bander "HOMAG" Mod. KFL 525/8/A3/15 VZ0200C) In-feeding Rollerway "HOMAG" Mod. TDL 310/30/12 with 90° Turning device (from lenghtwise to crosswise) with double cone system VZ0200D) 2nd Double-side Sizing & Edge Bander "HOMAG" Mod. KFL 526/10/A3/30 VZ0200E) In-feeding Rollerway "HOMAG" Mod. TDL 510/25/12 with 90° Turning device (from crosswise to lenghtwise) with double cone system VZ0200F) Cleaning machine "WANDRES" VZ0200G) Gantry-portal Stacker (Double pick-up station) "BARGSTEDT" Mod. TSP 410/D/25/12

Condition: used, Year of construction: 2000, Technical details: turning diameter: 800 mm turning length: 2965 mm max. turning dia. over saddle: 520 mm spindle bore: 92 mm turning speed range: 3 - 1800 U/min spindle head: Größe 11 total power requirement: 37 kW weight of the machine ca.: 6,5 t Tsdpfxexxig Uo Aknec dimensions of the machine ca.: 5,2 x 2,2 x 1,9 m Teach In Control MTC-K 3-jaw chuck ROTAS Dia. 400 mm face plate RÖHM Dia. 630 mm 4-station toolholder system PARAT 1 fixed steady coolant attachment and chip conveyor *

Year of construction: 2014, condition: ready for operation (used), Clamping force: 1600kN, weight: 9t, operational hours counter: 3638h, with Handling Robot ENGEL viper 20. Tsdpfxjh Nypfo Aknsc

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Soraluce model FL8000 high performance travelling column, floor type CNC milling machine TRAVEL (X) 7,500 mm TRAVEL (Y) 1,400 mm TRAVEL (Z) 1,000 mm RAPID TRAVERSE (X,Y,Z) 25,000 mm/min WORKING FEED RANGE (X,Y,Z) 1 – 10,000 mm/min ACCELERATION RATE (Instantaneous not maximum) 1 m/sec2 SPINDLE SPEED 20 - 4,000 Rpm SPINDLE TAPER ISO 50 SPINDLE POWER 28 Kw NC15C - HEIDENHAIN iTNC 530 (Flat 15.1" TFT Screen with digital drives). Single processor version. Prepared for a machine of 10 motors (9 CNC axes + spindle motor). Main push button panel with individually operated push buttons for linear axes (X+, X-, Y+, Y-, Z+, Z-) K20 option for the i530M. Independent AC. Heidenhain digital drive servomotor for each axis HEIDENHAIN HR-410 portable electronic handwheel with 5m spiral cable Automatic Indexing head 28Kw, 760Nm, 0.001°x 0.001°, 4000 Rpm. Continuous air and oil mist lubrication system for head gears. Automatic Tool Clamping device – 15,000N. Automatic hydraulic tool releasing device Spindle taper: BT50 High Torque spindle motor 28kW, 100% ED, digital motor. R10 – ZF gearbox two speed including cooling unit Spindle Speed Range 20 – 4,000Rpm Rapid Feed X-Y-Z axes 25.000mm/min Working Feed range X-Y-Z axes 0 - 10.000mm/min Acceleration rate X- Y -Z axes 1 m/s2 (instantaneous, not maximum) Hydraulic counterbalance system for head/ram assembly X axis driving system by two servomotors, two gearboxes and a double rack & pinion Preloaded ballscrews with double recirculating nuts in Y and Z axes. Automatic centralized lubrication system. Linear Guiding System with recirculating cylindrical rollers in each axis. Automatic centralized lubrication system for the guides. HEIDENHAIN Linear measuring scales in X-Y-Z axes with compressed air purge system - (Precision +/- 0,005mm) H48 – Coolant through the spindle type AD. Todow U Tlzepfx Aknec M3 – Automatic tool changer 40 stations. M6 – Horizontal-vertical tool changing facility. M8 – Motorized tool changing device. Tool changer is driven by a servo motor Hydraulic equipment Front metallic roller blind cover to both upper and lower ram area, together with metallic protection to the lateral side of the column, between the machine table and the rear guideway support, which protects the vertical movement of the ram. CE10 - PROTECTION on the back and both lateral sides of the machine column P20 - Operator's platform fixed to the column and travels together with it in the "X" axis direction. The main operator’s panel is mounted within the operator's platform area for machines without an operator’s pendant and is accessed from the rear of the machine. D7 + D50A - Coolant system with 1000L capacity tank with two pumps providing high and low pressure providing 5 & 12bar and 50L/min flow rate. Paper and Magnetic filtering. E30A – swarf conveyor FL8000 Hinge conveyor belt. Width 350mm PW11B – Pendulum working area system. PM2 x 2 – Machine prepared by Soraluce for the inclusion of two rotary tables. Working area lighting. Electrical cabinet cooling system Electrical cabinet lighting Working methods - According to CE safety regulations Filter to assure electromagnetic compatibility. Protection to both sides of the column with security bumpers Anchoring Bolts Standard Colour - Blue RAL 5005 / Grey RAL 7035 K19 – Two sets of machine documentation (One hard copy, one on CD ROM) Floor plate 8,000 x 1,500 x 300mm

Condition: used, Year of construction: 2001, functionality: fully functional, Press force 85 t, Bending length 2050 mm, Distance between uprights 1750 mm, Control DELEM, Stroke 215 mm, Throat depth 410 mm, Total power 13 kW, Weight 8,750 kg, Machine dimensions 3190 x 2100 x 2375 mm Todpfjw Imq Rjx Aknjc

Condition: used, Year of construction: 2007, Amada punch press EMK 3610NT including MP300 loading unit for sale. We would like to sell the machine as a complete package with tooling and a Wilson X-Sharp grinding machine. Tjdpfjw Hww Hjx Aknec The standard tools are listed in the attached inventory. I can send it to you via email.

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 Tedpeu Nc Riefx Aknoc spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: ready for operation (used), Year of construction: 2010, operating hours: 23,905 h, functionality: fully functional, clamping force: 600 kN, screw diameter: 35 mm, displacement volume: 135 cm³, injection pressure: 2,221 bar, opening stroke: 335 mm, total length: 2,420 mm, total width: 1,700 mm, total height: 3,100 mm, overall weight: 6,700 kg, Equipment: documentation/manual, For sale: Well-maintained injection moulding machine ENGEL INSERT 200V/60 with only 23,905 operating hours. The machine was used exclusively for sampling purposes. Tsdpoy Iwlaefx Aknec Inspection under power possible at any time! Technical specifications as per the pictures! Machine is immediately available!
