MK3 bench drill

Flott SB 32 ST-FB

Condition: used, Year of construction: 1982, Technical details: bore capacity in steel (diameter): 28 mm throat: 300 mm bore stroke: 150 mm drill capacity in cast iron: 30 mm spindle taper MT: MK3 spindle speed:: 200; 300; 500; 800; 1250; 2000 / 6 step U/min feed: manuell mm/U Distance spindle/table max.: 50 - 600 mm table clamping surface:: 330 x 300 mm table rotating: nein ° drill table adjustment: 550 (Handkurbel) mm column diameter: Ø 125 mm total power requirement: 1,5 kW weight of the machine ca.: ca. 300 kg Bwsdeu Idkbjpfx Akxjl dimension machine xH: 0,7 x 0,45 x 1,87 m Equipped with RÖHM Supra 3 - 16mm quick-action chuck Machine vice *

Condition: good (used), Year of construction: 1988, machine/vehicle number: 251500126, Offer 24156 Technical data: - Drilling capacity in steel ST 60 18 mm - Drill spindle mount MK 2 - Drill spindle stroke 100 mm Bwsdpfx Akjvxhdcoxjl - Drill spindle speeds approx. 340 - 2400 rpm - Right and left rotation - Projection 250 mm - Max. distance table - drill spindle 670 mm - Table with 2 T-slots 320 x 280 mm - Height adjustable via rack with hand crank - Drive 400 V / 0.75 kW - Space requirement approx. W 500 x H 1750 x D 750 mm - Weight approx. 180 kg - with: - Keyless drill chuck

Condition: good (used), Type: SSB 3 A Machine No.: 5607 Bsdpfx Akexlqxfjxswl Year of manufacture: 1973 Equipment: - MK3 quill - Machine lamp - Quick-action drill chuck incl. morse taper arbor, clamping range 3-16 mm - Infinitely variable speeds Range 1: 0-900 rpm Range 2: 0-1700 rpm - Thread cutting device Condition: good, workshop-tested, speed variator with new bearings

Condition: used, Boring power 23.0 / 28.0 mm Boring depth max. 140 mm Center of spindle to wall or column 300 mm Column diameter 125 mm Bwedoxabbyopfx Akxel Size of table plate 415 x 385 mm Speed 100 - 2000 U/min. spindle taper MT 2 MK voltage 380 V Motor output 0.9 / 1.4 KW weight of the machine ca. 225 kg Dimensions (L/W/H) 900 x 600 x 1960 mm maintained condition (!!) Furnishing: - V-belt operated column drilling machine - Right/left running of the work spindle - Pole-changing drive motor - manual spindle feed via cross handle - Work table with 2x T-slots - Table height adjustment via hand crank - machined base plate with 3x T-slots - manual V-belt tension (front handwheel) - Connection cable including 16A plug * Machine link: ?machineno=1008-9103760

Condition: good (used), Year of construction: 1993, machine/vehicle number: 399/093, Offer 24464 Bwedpfx Akeuzwc Dsxsl Technical data: - with ECKOLD pressure joining pliers, type MZ - Working pressure infinitely variable max. up to 500 bar - Joining gun pressure force 25 Kn - Single cycle or continuous cycle - Infinitely variable number of cycles - Hose package power unit - tongs approx. 4 m - Hydraulic oil capacity 15 ltr - Drive 400 V / 3 kW - Space requirement approx. W 550 x H 850 x D 650 mm - Weight approx. 150 kg

Condition: used, Drilling machine, bench drill, pillar drill, column drill Bwjdpefla Riofx Akxol -Handover: in its current condition as inspected -Motor: HEW 0.8 kW -Table size: Ø 355 mm -Spindle mount: MK3 -Travel distance: 500 mm -Protrusion: 300 mm -Columns: Ø 110 mm -Spindle stroke: 150 mm -Translation about: V-belt -Dimensions: 850/500/H1850 mm -Weight: 294 kg

Year of construction: 2003, condition: good (used), Type: TLI 4500/2044 Device no.: 03502 Year:2003 unit height: approx. 4500 mm unit width: approx. 2000 mm Bedpshyhlksfx Akxswl unit depth: approx. 7010 mm Number of rolls: 44 Roll width: approx. 1680 mm shelf load: 150 kg Total load: 7000 kg superstructure see photo 3000 mm Color: beige

Condition: ready for operation (used), machine/vehicle number: 2522, See pictures for condition and details Bedotxtfvopfx Akxewl

Condition: new, bore capacity in steel (diameter) 32,0 mm throat 255 mm bore stroke 120 mm morse taper 4 MK Bedexaaqgjpfx Akxjwl table: 385 x 335 mm turning speeds 80 - 2130 U/min total power requirement 1,1 / 2,2 kW weight 125 kg range L-W-H 460 x 900 x 1730 mm Furnishing: - Surface-machined work table - Height adjustable via rack and hand crank - Ground base plate with T-slots for clamping high workpieces - V-belt drive with balanced drive pulleys for smooth running - Adjustable drilling depth stop for precise infeed of the quill - Powerful 2-stage motor, speed range from 80 - 2130 rpm - Direction of rotation switch for clockwise and counterclockwise rotation included in the scope of delivery - Cross line laser device for comfortable work - Compact, stable cast iron construction in a modern design - Stable and polished steel column, designed for heavy use Scope of delivery: - Drill chuck arbor MK 4 / B 18 - Keyless chuck 1 - 16 mm / B 18 - Cam switch for right-left rotation - Cross line laser device - T-nuts - Height-adjustable protective cover

Condition: used, Year of construction: 1975, drilling capacity steel/cast iron 23,30 mm Bwodpoymp Snsfx Akxsl throat 300 mm bore stroke 140 mm spindle taper MT MK 3 spindle turning speed range 208- 2000 U/min table travel 400 mm weight of the machine ca. 275 kg table-size 415 x 300 mm distance work spindle /surface of the table 450 mm voltage 400 V connected load 0,9/1,4 kW
