Used Cnc Lathe for sale (11,401)

Condition: good (used), Year of construction: 2008, Ref. -No.: 10474 Manufacturer: SPINNER Type: TC77 MCY Year of construction: 2008 Type of control: CNC Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine-No.: AP0XXXXX Chuck diameter: 210 mm Tailstock - diameter: 110 mm Feed speed X / Z: 15/24 mm / min Turning Diameter: 500 mm Max. Torque: 113 Nm Travel -X Axis: 350 mm Travel -Y Axis: 230mm (-110mm +120mm) mm Travel -Z Axis: 1160/1840mm mm Distance Between Centres: 800 / 1500 mm Spindle 1 spindle head diameter (flange): A8 mm Spindle 2 spindle head diameter (flange): A6 mm Quills Morse taper: MK4 Turret places: 12 Pcs Machine length: 3250 mm Machine width: 1980 mm Machine Height: 2090 mm Weight Of The Machine Ca.: 7,5 t Max. swing diameter: 690 mm Further information: Spindle head: A8 Lrjdpox Sw Hrsfx Afzsg Bar capacity: 77mm Bar capacity: 52mm Number of rotating tool positions: 12 Y axis + C axis. Machine can be inspected under power by arrangement.

Condition: good (used), Year of construction: 2002, Ref. -No.: 10434 Manufacturer: OKUMA Type: LC 40 Year of construction: 2002 Type of control: CNC Control: FANUC 18-i TB Storage location: Halberstadt Country of origin: Germany Turning Speeds: 10 - 2.800 RPM Bar passage: 91 mm Chuck diameter: 450 mm Tailstock - diameter: 120 mm Turning Diameter: 550 mm Turning Length: 800 mm Swing Diameter: 800 mm Spindle passage: 90 mm Spindle nose: A2-8 Tailstock Quill Stroke: 150 mm Total Power Requirement: 44 kW Weight Of The Machine Ca.: 8 t Ljdpsx Sw Euefx Afzjrg Number of tool stations: 12 pc

Condition: used, CITIZEN CINCOM R 07 VI is a high-precision CNC automatic lathe (Swiss-type) delivering strong accuracy and reliability. Capacities: 6 axes, 2 spindles; max turning Ø 7 mm, max length 40 mm, spindle bore 12 mm; threading up to Ø4 M, max tapping length 40 mm. Specs: spindle 0–16,000 rpm, 1.1 kW; back spindle up to 10,000 rpm, 0.5 kW; C-axis resolution 1°; supply 3x400 V 50 Hz, total power 4 kVA; weight ~950 kg; footprint 1465×560×1410 mm. Accessories: parts catcher, lamp, bar feeder LNS TRYTON 107, central lubrication, status light. Built to achieve tight tolerances; typical applications include automotive, watchmaking, medical, aerospace, and machine-tool components Lrjdpsx S I Dhjfx Afzeg

Condition: new, The LabTurn 2028 CNC, part of the CNC Slant Bed Lathes category and 2-axis CNC Lathes group, is designed for both CNC training and the efficient production of small workpieces. This compact and mobile lathe combines the functionality of larger production machines with a robust cast-iron inclined bed design, ensuring excellent stability for precise machining. The machine features an 8-station tool turret with four tools each for inside and outside turning and a max spindle speed of 3000 rpm, enabling versatility in various applications. Additionally, the Siemens 808D Advance controller provides an intuitive interface for beginners. The LabTurn includes a 100 mm 3-jaw chuck, hydraulic tailstock, and a well-structured design with an enclosed workspace for safety. Enhance your machining capabilities with the LabTurn and experience the potential for high precision and performance. Request a quote today to explore this superior CNC Slant Bed Lathe. Lredpsuy Iclofx Afzsg

Condition: used, _____ Description: Year of manuf. : 2022 Control : Fanuc 0i-TF Turning diam. : 580 mm Turning length : 3250 mm Mainspindle: Technology:Belt-driven spindle with Gearbox Speed:1.000 rpm Power (max.):45 kW Torque (max.):4.008 Nm Barcapacity:205 mm Workpiececlamping I:3-Jaw chuck, Autogrip AP-230 ø535 mm Workpiececlamping II:Manual 3-Jaw chuck, Chandox SK20 (Rearside Spindlehead) Toolcarrier (X/Y/Z): Technology:Turret with 12 stations Taper:BMT 75 Tooldrive:3.000 rpm, 7 kW, 83 Nm Lrsdpfx Aowt Iwqsfzog Movement in X/Y/Z:340/160/3.250 mm Rapid travers in X/Y/Z:20/7/12 m/min Tailstock: Technology:Towed tailstock with programmable Sleeve Stroke:150 mm Cone:MK5 Equipment/Accessory: Chipmanagement:Chipconveyor Coolingmanagement:Coolant pump Toolmeasurement:Measuringarm, Renishaw RP3 Oilmistseparation:Mechanical extraction, AR Filtrazioni ARNO 3VF YF Shaftprocessing:Manual Steady rest, ø150-300 mm Toolholder:Misc. static and driven toolholder Setup operations:Electronic Handwheel Further Equipment:Automatic Door (pneumatic), Trafo, Oilskimmer Further Accessory:Misc. Jaws and EWS Quickchangeinserts

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Lsdpfx Aexybxxofzorg Description: Year of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 360 mm Turning length : 520 mm Main spindle: Technology:Belt spindle Speed:6,000 rpm Power (max.):18.5 kW Bar capacity:52 mm Workpiece clamping:3-jaw chuck, Samchully MH-206 V1 Tool holder: Technology:12-station turret Tool holder:BMT55 Tool drive:5,000 rpm Features/Accessories: Chip management:Chip conveyor Coolant management:IKZ pump with oil skimmer and high pressure, 10 bar Tool measurement:Automatic measuring arm Automation:Prepared Finished part removal:Parts catcher with collection box Setup operation:Electronic handwheel

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Description: Year of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 395 mm Turning length : 450 mm Mainspindle: Technology:Belt-driven spindle Speed:4.500 rpm Ljdpfx Asxv Nllsfzerg Power (max.):20 kW Torque (max.):169 Nm Bar capacity:67 mm Workpiececlamping:3-Jaw chuck, Samchully MH-208 BVI Subspindle: Technology:Motorspindle Speed:6.000 rpm Power (max.):7,8 kW Torque (max.):45 Nm Workpiececlamping:3-Jaw chuck, Samchully HS-06VI Movement in B:580 mm Rapid travers in B:24 m/min Toolcarrier I (X/Y/Z): Technology:Turret with 12 stations Taper:BMT55 Tooldive:5.000 rpm, 9,3 kW, 44 Nm Movement in X/Y/Z:235/105/580 mm Rapid travers in X/Y/Z:24/10/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal coolant pump with Oilskimmer and Highpressure, 10bar Toolmeasurement:Automatic Measuringarm Rawmaterialfeed I:Interface Barloader prepared Rawmaterialfeed II:Automatic Working Door and Interface Robot prepared Finsihedpartremoval:Part catcher with collecting box Setup operations:Electronic Handwheel Further Equipment:Trafo

Condition: used, Year of construction: 2013, controller manufacturer: Siemens, controller model: 840Dsl, _____ Description: Year of manuf. : 2013 Control : Siemens 840Dsl Turning diam. : 430 mm Turning length : 744 mm Mainspindle: Technology:Motorspindle Speed:5.000 rpm Power (max.):29 kW Torque (max.):250 Nm Barcapacity:65 mm Workpiececlamping:Collet chuck, Hainbuch Spanntop nova Kombi Axzug Gr. 65 Subspindle: Technology:Motorspindle Speed:7.000 rpm Power (max.):22 kW Torque (max.):130 Nm Workpiececlamping:3-Jaw chuck, SMW Autoblok KNCS-N-225-66 Ejector:Pneumatic Movement in Z:750 mm Toolcarrier I (X/Y/Z): Technology:Turret with 12 stations Taper:VDI30 Tooldrive:4.000 rpm, 6,7 kW, 25 Nm Movement in X/Y/Z:270/100/750 mm Eilgang in X/Y/Z:24/10/30 m/min Toolcarrier II (X/Z): Technology:Turret with 12 stations Taper:VDI30 Tooldrive:4.000 rpm, 6,7 kW, 25 Nm Movement in X/Z:205/750 mm Eilgang in X/Z:24/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal coolant pumps with High-pressure, 14 bar Rawmaterialfeed:Barloader, EMCO LM 1200 Finishedpartremoval:Workpiece unloading device (pneumatic) with conveyor belt Oilmistseparation:Mechanical extraction, Absolent Toolholder:Misc. static and driven toolholder Further Accessory:Spindlechiller Lrodpfsw Tg Adex Afzsg

Condition: used, Year of construction: 2004, controller manufacturer: Mitsubishi, controller model: TX-8i, _____ Description: Year of manuf. : 2004 Control : Mitsubishi TX-8i Turning length : 450 mm Mainspindle: Technology:Belt-driven spindle Speed:4.000 rpm Power:18,5 kW Torque:230 Nm Barcapacity:65 mm Lsdpfxoxhbfns Afzorg Workpiececlamping:Collet chuck, Hainbuch Spanntop Gr. 65 Subspindle: Technology:Belt-driven spindle Speed:4.000 rpm Power:11 kW Torque:210 Nm Workpiececlamping:Collet chuck, Hainbuch Spanntop Gr. 65 Ejector:Hydraulic with flush Movement in Z:520 mm Rapid travers in Z:30 m/min Toolcarrier I (X/Y/Z): Technology:Turret with 10 stations Taper:VDI30 Tooldrive:4.000 rpm, 4 kW, 16 Nm Movement in X/Y/Z:140/70/450 mm Rapid travers in X/Y/Z:15/6/30 m/min Toolcarrier II (X/Z): Technology:Turret with 10 stations Taper:VDI30 Tooldrive:4.000 rpm, 4 kW, 16 Nm Movement in X/Y/Z:140/450 mm Rapid travers in X/Y/Z:15/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Cooling unit with Paperbeltfilter Rawmaterialfeed:Barlaoder, FMB SL80S Finished part removal:Hydraulic part catcher with coneyor belt Oilmistseparation:Electrostatic extraction, LTA AC3001 Further Accessory:Misc. Toolholder, Rinsing pistol

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Description: Year of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 360 mm Turning length : 520 mm Lredpfexx Ergsx Afzjg Main spindle: Technology:Belt spindle Speed:6,000 rpm Power (max.):18.5 kW Bar capacity:52 mm Workpiece clamping:3-jaw chuck, Samchully MH-206 V1 Tool holder (X/Y/Z): Technology:12-station turret Tool holder:BMT55 Tool drive:5,000 rpm Features/Accessories: Chip management:Chip conveyor Coolant management:IKZ pump with oil skimmer and high pressure, 10 bar Tool measurement:Automatic measuring arm Automation:Prepared Finished part removal:Parts catcher with collection box Setup operation:Electronic handwheel

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Description: Year of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 395 mm Turning length : 450 mm Mainspindle: Technology:Belt-driven spindle Speed:4.500 rpm Power (max.):20 kW Torque (max.):169 Nm Bar capacity:67 mm Workpiececlamping:3-Jaw chuck, Samchully MH-208 BVI Subspindle: Technology:Turret with 12 stations Taper:BMT55 Tooldive:5.000 rpm, 9,3 kW, 44 Nm Ljdpfxsxybxrs Afzjrg Movement in X/Y/Z:235/105/580 mm Rapid travers in X/Y/Z:24/10/30 m/min : : Equipment/Accessory: Technology:Turret with 12 stations Taper:BMT55 Tooldive:5.000 rpm, 9,3 kW, 44 Nm Movement in X/Y/Z:235/105/580 mm Rapid travers in X/Y/Z:24/10/30 m/min : : : Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal coolant pump with Oilskimmer and Highpressure, 10bar Toolmeasurement:Automatic Measuringarm Rawmaterialfeed I:Interface Barloader prepared Rawmaterialfeed II:Automatic Working Door and Interface Robot prepared Finsihedpartremoval:Part catcher with collecting box Setup operations:Electronic Handwheel Further Equipment:Trafo

Condition: excellent (used), Year of construction: 2019, DMG turning center (Y2019) in outstanding condition with only 2800 spindle hours! Including: Subspindle C-axis Y-axis Chip conveyor Iemca Kid 80 bar feeder Optional: set of static and driven tools + jaws Full technical specifications in the attached documents. Lsdpfx Aoya I Ibofzorg Cnc control M730UM CNC with CELOS Turret 12 stations Distance between centers 700 mm X-axis travel 260 mm Y-axis travel ca 50 mm Z-axis travel 795 mm Max. turning diameter ø 366 mm Swing over bed ø 920 mm Swing over cross-slide 740 mm Bar work capacity 80 mm Immediately available for delivery. Please note: WE HAVE A SECOND IDENTICAL NLX 2500/700 SY (2019) AVAILABLE FOR SALE (without barfeeder) AT THE SAME LOCATION AS THIS MACHINE. LET US KNOW IF YOU ARE CONSIDERING BUYING 2 MACHINES. Please note: The information on this page has been obtained to the best of our ability and belief. This information is provided in good faith, but its accuracy is not guaranteed. Accordingly, this information is not binding and does not constitute a contractual condition. We recommend that you check all essential details during an inspection of the machine. To save unnecessary travel costs for our customers, in most cases we recommend organizing a live video inspection.

Condition: used, Swing Diameter Over Bed: 400 mm Swing Diameter Over Longitudinal Slide: 350 mm Distance Between Centers: 610 mm Travel Limit: 240 mm Suggested Workpiece Diameter: 200 mm Max Longitudinal Travel: 560 mm Machining Length: 550 mm Max Cross Travel: 40 mm + 120 mm Lodpoxg Nd Asfx Afzerg Height of Spindle Axis from Floor: 1135 mm Programmable Spindle Speed Range: 40 to 4000 rpm Spindle Bore Diameter: 52 mm Spindle Interior Cone: MK 6 Slide/Bed Slope: 45/45° Turret Positions: 12 Tools Main Motor: 15 kW Control: Fanuc 6T Equipped with: See photos

Condition: good (used), machine/vehicle number: 86388, Weiler Condor 81 Lead and Feed Screw Lathe Turning length: 750 mm Centre height: 165 mm Spindle bore: 40 mm Speed: 45–2,800 rpm Dimensions (LxWxH): 1,832 x 880 x 1,290 mm With Heidenhain digital readout and extensive accessories! Ljdex Sd Hfspfx Afzjrg

Condition: good (used), In good technical condition and fully operational. Year of manufacture: 1974, with an overhaul including comprehensive modernization (retrofit) of the CNC control system, complete with automatic central lubrication for the axes and hydraulic systems, water cooling, conductive rollers with brushes for a system allowing the possible welding of the workpiece, and complete protection against flying chips. Heidenhain manual plus 4110 control system. Swing diameter over bed: 1,250 mm and over support: 900 mm. Max. workpiece weight: 14,000 kg. Max. workpiece length: 3,000 mm. Ledpfx Asx Ttlaefzsrg Machine weight: 16,350 kg. Machine power: 80 kW. Machine dimensions: Width 3,000 mm, Height 2,100 mm, Length 8,000 mm. Accessories: faceplate including handles, steady rest, raised tool head, universal chuck. Complete technical documentation, service history, and maintenance and overhaul records are available.

Condition: like new (used), Year of construction: 2022, operating hours: 1,496 h, functionality: fully functional, turning diameter over cross slide: 600 mm, turning length: 510 mm, turning diameter: 300 mm, spindle bore: 51 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 205 mm, travel distance Z-axis: 560 mm, spindle motor power: 15 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 36 m/min, type of input current: AC, overall weight: 3,600 kg, power: 30 kW (40.79 HP), input voltage: 400 V, Equipment: documentation/manual, rotational speed infinitely variable, 5-axis CNC lathe "DN Solutions model LYNX 2100LMSA" with sub-spindle, driven tools and CNC FANUC i-PLUS iHMI complete with "TOP model FUSION" bar loader. Ledotq Aylspfx Afzerg

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning diameter over cross slide: 900 mm, turning length: 2,001 mm, turning diameter: 650 mm, spindle bore: 166 mm, spindle speed (max.): 1,500 rpm, spindle speed (min.): 15 rpm, travel distance X-axis: 362 mm, travel distance Z-axis: 2,155 mm, spindle motor power: 45 W, rapid traverse X-axis: 16 m/min, rapid traverse Z-axis: 18 m/min, total height: 2,170 mm, total length: 6,750 mm, total width: 2,250 mm, overall weight: 11,750 kg, bar passage: 165 mm, Equipment: documentation/manual, rotational speed infinitely variable, 2-axis CNC lathe “DOOSAN mod. PUMA 480L” with Fanuc 21i-TB CNC complete with “AUTOBLOK K5Z” steady rest Lredpfeu Ut Elsx Afzjg

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning length: 760 mm, turning diameter over cross slide: 780 mm, turning diameter: 376 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 51 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 4,000 rpm, Equipment: rotational speed infinitely variable, 6-axis CNC lathe with sub-spindle, driven tools and Y axis Lredpfx Ajtvl U Hofzsg

Condition: excellent (used), Year of construction: 2004, A fully operational CNC lathe from Böhringer, model NG180, is available for sale. Lsdpfx Asx Swigofzorg

Condition: used, 10" TAILSTOCK; TOOL SETTER; CHIP CONVEYOR Lrodpfx Afeya U E Tezsg

Condition: used, Chuck 10” Swing over bed Ø630 mm Max. turning length 1078 mm Swing over saddle Ø500 mm Max. turning diameter Ø420 mm Lrjdpfeya U Eajx Afzsg Spindle speed 3500 rpm Spindle nose A2#8 Spindle bore diameter Ø86 mm Number of turret tool stations 10 Tailstock Ø100 mm / MT#5 Main spindle motor 22 kW Machine weight 5300 kg

Condition: used, Year of construction: 2023, Technical details: turning diameter: 770 mm turning diameter over slide: 650 mm turning length: 750 mm max. diameter of work permitted:: 82 mm y-axis: +/- 60 mm turret (x-stations): 12 VDI 40 turning speeds: 4.000 1/min tail stock: ja total power requirement: 47 kVA weight of the machine ca.: 7,8 t dimensions of the machine ca.: 3,3 x 1,9 x 2,3 m Accerories main spindle power 16 / 24 kW Lrsdpoxhd Ufsfx Afzjg CNC lathe, NC-tailstock, C-axis with brake, live tooling (10,5 kW, 5.400 rpm), 3-jaw chuck SCHUNK ROTA THW 260-81, chip conveyor, prepared for oilmist suction, parts catcher and belt (right side), coolant device 300l, 8/20bar, accessories (8pcs. live-toolholder...) approx. 3.000 working hours *

Condition: used, Year of construction: 2000, Technical details: turning diameter: 1600 mm turning length: 3000 mm centre height: 800 mm turning diameter over bed: 1600 mm turning diameter over bed slide: 1400 mm turning dia. over face-slide: 1200 mm max. workpiece weight between centers: 20 to speeds: 5,6 -800 1/min transmission ratio: 3 spindle bore: 112 mm turret (x-stations): 8 / VDI 60 Lrodpshutpvofx Afzeg travel -x axis: 850 mm travel -z axis: 3020 mm rapid power traverse in X-and Z direction: 6 / 10 m/min power maindrive: 46 kW weight of the machine ca.: 22 to. dimensions of the machine ca.: 7,2 x 4 (3,11) x 2,7 m tech-in lathe, flatbed, tailstock, 8-pos. BARUFFALDI turret with 4 live tools, power 9kW, 4-pos. BARUFFALDI square-headed turret horizontal, C-axis, 3-jaw hydr. chuck SMW Autoblock KNCS 800/165, dia. 800mm, quick adjustment, power cylinder with 2 pressure clamping system, chipconveyor, coolant device, accessories *

Condition: used, Year of construction: 2001, operating hours: 51,500 h, machine/vehicle number: IntNr230346, CNC sliding headstock lathe STAR SR20R, year 2001 Control, Fanuc, Series 18i-T, 7 axes (X/Z/Y/C1/X1/Z1(C2), Bar Ø max. 20 mm, Lsdpfx Afox Sv Uhezorg turning length max. 205 mm, Main spindle, max. speed 10,000 rpm, C-axis 0.001 degrees, Counter spindle with collet chuck, max. speed 8,000 rpm, C-axis, Tool holder for a total of 19 tools (linear tool holder, front attachment, rear machining), parts conveyor belt, standard guide bush unit Loading magazine FMB turbo 3-26/3200 / A /, year 2001 Machine coolant: oil. Extinguishing system Kraft & Bauer The machine can be inspected under power by appointment. Changes and errors in the technical data and information as well as subject to prior sale! used CNC sliding headstock lathe STAR SR20R, year 2001 control, make Fanuc, series 18i-T, 7 axes (X/Z/Y/C1/X1/Z1(C2), bar-Ø max. 20 mm, turning length max. 205 mm, main spindle, speed max. 10.000 rpm, C-axis 0,001 degree, counter spindle with collet, speed max. 8.000 rpm, C-axis, tool holder for a total of 19 tools (linear tool holder, front attachment, rear machining), parts conveyor belt, standard guide bush unit loading magazine FMB turbo 3-26/3200 / A /, year 2001 Machine coolant: oil. Extinguishing system Kraft & Bauer The machine can be inspected under power by appointment. Changes and errors in the technical data and information as well as subject to prior sale!

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Max. machining length : 320 [mm] - Travel : 325 [mm] - Spindle speeds : 200 - 8.000 [rpm] - Spindle power : 5,5 / 7,5 [kW] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Z stroke : 290 [mm] - X stroke : 370 [mm] - Spindle speeds : 200 - 8.000 [rpm] - Spindle power : 2,7 / 3,7 [kW] - C axis indexing precision : 0,001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 10 - Number of motorized positions : 4 - Live tools speed : 200 - 5.000 [rpm] - X/Y stroke : 110 / 400 [mm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 200 - 5.000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 15 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.520 x 1.300 [mm] - Machine height : 2.229 [mm] - Machine weight : 3.500 [kg] Lsdpfx Aexrvxdefzorg EQUIPMENT - CNC : Mitsubishi Meldas M70 - 3 colors status lamp - Rotating guide bush - Parts catcher - Parts conveying strip - Chips conveyor : LNS - Coolant tank * with high-pressure pump : Coolblaster [bars] - Bar loader : IEMCA BOSS 332R - Fire extinguisher * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer - Ejection of workpiece
