Used Cnc Machining Center for sale (67,104)

Condition: used, Year of construction: 2013, 2013 SMC Group Routech Accord 30FX CNC machining center, high performance multi-function work table, 400V, 3 phase, X-axis 20' 10", Y-axis 5' 4.7", dual machining heads, rotation speed 6-18,000 RPM, onboard Rapid 12-tool changer, Rapid 16 rear tool changer, work table, pod, and rail, gantry type, has SMC Group CNC control with remote pendant control, 480V, 3 phase, Becker, model 271407, rotary vane vacuum pump, and (1) Texa, model SAW50RBSBCC000, chilling unit with transformer, winning bidder responsible for proper removal. Kdjdoxdc T Sopfx Ab Usw

Condition: used, Year of construction: 2019, Used machine Year of manufacture: 2019 Only 110 operating hours! Equipment and technical data: Travel ranges: - X = 1800 mm - Y = 900 mm - Z = 80 mm Made from 18 mm Koskisen panels Milling bed made of 19 mm MDF as sacrificial plate with guide rails and T-slot nuts for clamping. Chassis with reinforcements, filled with polymer concrete, designed for transport by pallet truck or forklift. Mechanical set consisting of profile rails including linear guides and ball screws (2010 and 1605) for all axes. Shaft couplings and high-performance grease for lubricating the carriages; also includes energy chains with connection sets. Control set comprised of a Triple Beast controller for controlling 3 axes, with Ethernet interface. Kodpew Nadyefx Ab Usdw Leadshine drive for the fourth motor. Four stepper motors, 5.0A, 3Nm each with motor cables, as well as a 48V 6.7A switching power supply, LED board for breakout board, ribbon cable and proximity sensors; small parts such as wire leads, ferrules, control cables, heat shrink tubing, and cable lugs. Fully pre-installed in an aluminum enclosure including electrical kit and emergency stop. - 21.5 inch built-in monitor, including mini PC with Windows 7, Rhino 5.0 CAD software, Estlcam G-code generator, Beamicon2 control software, as well as mouse and keyboard, all pre-installed in an ergonomic console. Tool length sensor for determining tool length and adjusting the active reference point. Special equipment: - High-frequency spindle with 2.2 kW, including clamping nut, frequency inverter, line filter, brake resistor, and collet set. - PC with 8 GB RAM and AMD processor - Rhino 5.0 CAD software for creating both simple 2D data and 3D solids Availability: short-term Location: Flörsheim

Condition: good (used), Year of construction: 2002, Machine is in good condition. Parts shown by hand not come. Kodpfotwpamex Ab Uodw

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Pass-through height. Operator terminal: 24" LED color display. Handheld terminal for controlling axis speeds. Software: "Woodflash". Vacuum pump 90 m³/h, 50 Hz or 108 m³/h, 60 Hz. Milling spindle 12 kW HSK F63 (12,000 rpm). 12-position linear tool changer on the left side of the machine frame + pickup position. Drilling head DH 16 4H 2S: Vertically 12 spindles, horizontally 4 spindles, 2 grooving saws. Storage location: Supplier. Kdsdpfx Aoxyliheb Ujw

Condition: good (used), Year of construction: 2012, Ref. -No.: 10558 Manufacturer: YOU JI Type: HMC 1200 BP Year of construction: 2012 Type of control: CNC Control: FANUC Series 18i-MB Storage location: Halberstadt Country of origin: Taiwan X-Travel: 1800 mm Y-Travel: 1500 mm Z-Travel: 1360 + 990 mm B-Axis: 360 ° W-Axis: 700 mm Table Dimensions (Lengthxwidth): 1200 x 1400 mm Table Load: 5.000 kg Max. Tool Weight: 25 kg Kedpfxexxpbxo Ab Uodw Max. Tool Length: 400 mm Max. Tool Diameter: 125 mm Spindle Speed: 30 - 3.500 RPM Numbers Of Pallets: 2 Further information: 4-axis simultaneous machining IKZ (internal spindle cooling) AKZ (external spindle cooling) Synchronized walking (rigid thread cutting) Renishaw RMP60 workpiece probe (radio) Number of pallet changers for automatic pallet change: 2 Size: 1200 x 1400 mm Tool magazine, number of tools: 60 The machine is currently in production and can be viewed by appointment.

Year of construction: 2022, condition: new, Offer on demand Machine is immediately available Kedpsiw Dgiefx Ab Uedw

Condition: used, Year of construction: 2005, - Fagor 8055 CNC control - Additional tank for internal spindle cooling (15 bar) 400 liters - Year of construction 2005 Technical data: - Travel X/Y/Z: 610 / 455 / 520 mm - Rapid traverse: 24 m/min - Working spindle speed: 8000 rpm - Tool holder: BT40 - Table size: 762 x 363 mm - Maximum table load: 350 kg Kdodpfx Abotvf Hte Uow - Motor power: 18 kW - Operating voltage: 400 V - Weight: 3140 kg

Condition: used, Year of construction: 2019, Used machine Year of manufacture: 2019 Equipment and Technical Data: - For classic nesting processing with wear plate - Machine frame of welded construction with ground and hardened prism guides for the gantry, unit head, and consoles - Gantry-type traveling column - Helical rack and pinion drive in X and Y axes, ball screw in Z axis for precise positioning - Working dimensions: - Max. support area on nesting table: X = 3100 mm, Y = 1560 mm - Max. traverse paths: X = 4695 mm, Y = 2100 mm, Z = 293 mm - Max. clearance height over DYNESTIC table: Z = 100 mm from table top (without wear plate) - Maximum programmable speed Vector speed: 128 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min - DYNESTIC table: - Fixed, continuous processing table with grid layout - Continuous grooves in X and Y directions - Groove spacing: 50 mm - Includes 25 meters of sealing cord for clamping the wear plate - Vacuum fields: Single-circuit vacuum system - Drilling unit 7877: Ksdpfewka Upox Ab Ujdw - 19 spindles - Drive power: 1.7 kW - 13 vertical spindles: - Individually selectable - Arranged in U-shape - 5+4 in X direction, 4 in Y direction - 32 mm spacing - Max. drill diameter: 35 mm - Total drill length: 70 mm from screw-on end (depending on panel thickness) - Spindle stroke: 70 mm - Rotational direction: alternating clockwise/counterclockwise - Speed (max): 1000 - 4400 rpm, infinitely variable - Tool holder: M10 thread, 11 mm fit - Without tool, without holder - 6 horizontal spindles: - 2 double drill spindles in X direction - 1 double drill spindle in Y direction - Tool holder: M10 thread, 11 mm fit - Max. total drill length: 63 mm from screw-on end - Without tool, without holder - Milling unit 7842: - Power: 12.0 kW (S6) - Max. speed = 1000 - 24,000 rpm, infinitely variable - Max. power at 12,000 to 24,000 rpm - Air-cooled - With HSK-F 63 tool holder - With right-hand threaded nut (for right-hand rotating tools) - With collet chuck for HSK shank - Ceramic ball bearings (hybrid bearings) - Tool weight max. 6 kg (incl. holder) - Tools: milling and grinding tools max. Ø 160 mm - Safety enclosure according to CE standard - Side and rear safety fence - Vacuum pump: 500 m³/h, dry-running - Personnel safety ensured by light barriers in the front machine area - Hand-held control device for remote operation of the machine with the following functions: - Start/stop of the processing program - Control of processing cycle speed - Reset button - Manual feed/rapid traverse for all axes - EMERGENCY STOP - CAMPUS V7 CAD/CAM software 1x machine license consisting of: - CAMPUS NC-HOPS: - Graphic variant system with WOP and CAD/CAM features for creating part variants using macro technology - CAMPUS MT-Manager - CAMPUS Workcenter - CAMPUS DXF interface - Automatic central lubrication - Automatic lubrication at defined intervals - Additional sealing against dust via pressurization in each guide carriage

Condition: used, Year of construction: 2019, functionality: fully functional, OPTIMUM - OPTImill F 105 CNC Offer Details Stock number: 1039-8705 Machine type: Machining center - Vertical Manufacturer: OPTIMUM Model: OPTImill F 105 CNC Year of manufacture: 2019 Control: Sinumerik 808D adv. Siemens Location: D-59302 Oelde, Germany Country of origin: - Availability: immediately Delivery terms: ex works Additional information: CNC vertical machining center OPTIMUM - OPTImill F 105 CNC Kjdpfxexvx Sns Ab Ujdw - DEMONSTRATION MACHINE Technical Details Travel X-axis: 550 mm Travel Y-axis: 305 mm Travel Z-axis: 460 mm Control: Sinumerik 808D adv. Siemens Main spindle: Speed range - main spindle: 10 – 10,000 rpm Drive power - main spindle: 11 / 7.5 kW Max. torque: 70 / 48 Nm Tool holder: BT 40 Worktable: Clamping area: 800 x 320 mm Max. table load: 300 kg T-slots: 3x 14 x 100 mm Distance spindle / table: 100 – 600 mm Tool changer: Number of tool stations: 12 positions Tool holder: BT 40 Max. tool diameter: 70 mm Max. tool weight: 6.0 kg Tool-to-tool change time: 7.0 sec Feedrates: Rapid traverse (X / Y / Z): 10 m/min Feed speed: up to 10,000 mm/min Repeatability: +/- 0.008 mm Positioning accuracy: +/- 0.01 mm Total power requirement: 15 kVA Machine weight approx.: 2.9 t Space requirements approx.: 3.5 x 2.5 x 2.4 m Included Accessories Documentation Chip conveyor system Coolant system Tool changer Probe: RENISHAW - Primo

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Kdedpovwbp Ajfx Ab Usw

Condition: good (used), Year of construction: 2010, Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Type: Alpha 1000 Year of construction: 2010 Kjdpfx Aoxxpbfeb Uedw Type of control: CNC Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe - Chip conveyor - Coolant system - Coolant through the spindle - Pallets with 5-way media connection and clamping hydraulics - Extraction system - Swivel spindle A-axis 0 - 90 - NC rotary table B-axis

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Kdedpfx Aevvi Htjb Ujw Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Storage location: Sonnefeld

Condition: good (used), Year of construction: 2013, Ref. -No.: 10450 Manufacturer: SHW Type: UNISPEED 5 Year of construction: 2013 Type of control: CNC Control: HEIDENHAIN iTNC 530 Storage location: Halberstadt Kdjdpfxjxxpano Ab Uew Country of origin: Germany Machine-No.: 32XX X-Travel: 2000 mm Y-Travel: 2300 mm Z-Travel: 1300 mm B-Axis: 360 ° C-Axis: 360 ° W-Axis: 1500 mm Table Load: 15000 kg Max. Tool Weight: 25 kg Max. Tool Length: 500 mm Max. rotary table diameter: 1600 O Table speed range: 5 min/-1 Tool Taper: HSK 100 Tool Piece Magazine With: 150 Pcs./pcs. Turning Speed Range - Stepless: 22 - 8000 RPM Max. Torque: 40 Nm Feed Speeds X/Y/Z Axis: 2 - 30.000 mm / min axes: 5 Rapid Travel X/Y/Z: 30.000 mm / min acceleration: 2 m/s² Dimensions Of The Machine Ca.: 8,4 x 7,1 x 5,3 m Operating hours: 42.499 H Tool change time: 10 s Further information: automatic universal milling head, 360 x 1°; 180 x1° compact coolant system, make Knoll, type KF150/950 high pressure pump belt filter coolant temperature control Blum laser measuring system Renishaw RMP 60M infrared measuring system 140 tool holders HSK 100 included Machine can be inspected under power by appointment.

Condition: used, Year of construction: 2004, Storage location: Nattheim Kjdpfovvi Hysx Ab Ujdw

Condition: used, Year of construction: 1994, Storage location: Nattheim Kdsdowmm Nrepfx Ab Uow

Condition: used, Year of construction: 2002, Machining dimensions (tool diameter 25mm): X=3015 mm Y=1483 mm Z=325 mm Max. travels: X=3268 mm Y=1483 mm Z=325 mm Max. programming speed: X/Y = 75 m/min / Z = 30m/min Tool holder HSK 63F Drilling unit 7964, 14 vertical drilling spindles with 32 mm grid (10 in x / 4 in y) Sawing unit 7946 3.6 kW, 90° pneumatically pivotable Milling unit 7933 9 kW Wood Her Vector axis (C-axis) Tool magazine (6 disk places) Hand control unit Laser device (positioning of the suction cups) PC control panel with 17" monitor Operating system Windows 2000 Software: TwinCAM32 - office version Vacuum pump 100 m³/h Dry running Selective safety mats (3-field division) Kdjdovvi Nbjpfx Ab Uow Storage location: Nattheim

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground ball screws of the highest precision class. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. Such characteristics are important for ensuring balanced movement even in more complex tasks. The movement of the various axes is controlled by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters that can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different P Kdedpfx Ajvvi Nzob Uow

Condition: used, Year of construction: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTIONAL TABLE - WORK CELL VERSIONX400 CELLDrilling and milling made for you!The numerically controlled machining center is equipped with a wide range of milling/drilling tools to meet every need in the processing of wood and similar materials.- More powerful, with drilling spindles with 8,000 rpm and . Technology, the toughest spindle available on the market, with over 1,000 maintenance-free hours of use. Better and more comprehensively equipped, with various configuration options thanks to the multifunctional table to optimally equip the machine according to your needs. Easier and more understandable programming thanks to the integrated MAESTRO CNC CAD-CAM module. Easier to use: the work table is accessible at all times, the electrical cabinet and vacuum pump are integrated, and in the PRO SPACE configuration there are no guards. Supporting structure. The supporting structure consists of a particularly strong monolithic steel base, heavily ribbed and very rigid. The particularly wide support was specifically designed to give the machine stability, ensuring consistent precision regardless of the working conditions and eliminating the need to anchor the machine to the floor. The base forms a large and solid support for the mobile column: the work unit is thus equipped with a balanced, stable, and durable support that can withstand the most extreme stresses, ensuring higher quality performance and greater precision. The mobile gantry consists of a single, solid unit anchored to the base on both sides and slides on pyrotechnic guides with top-quality ball-return slides. The dual motorization along the X-axis ensures top performance even under demanding working conditions. The movement of the lower moving unit (X-axis) and the working unit along the rod of the moving unit (Y-axis) is achieved thanks to a rack/pinion transmission with helical teeth. this creates a greater tooth-to-tooth thrust which achieves greater acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures less wear on the mechanical components and less noise. The vertical Z axis is driven by a screw with ball return which ensures perfect balance with dynamic loading and strong acceleration and deceleration. The main milling unit is directly coupled to the Z axis carriage and ensures absolute quality of finishes as any vibrations are completely eliminated. Translation along the X-Y-Z axes is carried out by brushless motors driven by static inverters; These ensure: - Reduced processing times thanks to improved acceleration - Better positioning accuracy thanks to the high-resolution encoder - Zeroing of setup operations when switching on the machine thanks to absolute encoders - Zeroing of general maintenance operations since there are no brushes with the "brushless" system The management of the axis displacement and, in general, of the machine's working elements is carried out by an industrial NS module with digital D Kdjdpfovvi N Isx Ab Ujw

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground, high-precision recirculating ball screws. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. This characteristic is important for ensuring balanced movement even in more complex tasks. The various axes are driven by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters, which can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different Kdodpfx Abevvi Rfs Ujw

Condition: used, Year of construction: 1999, Storage location: Nattheim Kdsdpfjvvi Rxsx Ab Ujw

Condition: used, Year of construction: 2011, Weight: approx. 4500 kg Storage location: Nattheim Kdodpfxjvvi R Ej Ab Usw

Condition: used, Year of construction: 2019, Incl. tools CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and milling made for you! This numerically controlled machining center is equipped with a wide range of milling and drilling tools to meet every woodworking requirement. - Highly powerful - with 8,000 rpm drilling spindles and . technology, the most stable spindle available on the market, with more than 1,000 maintenance-free hours of use. - Optimally and comprehensively equipped - the vacuum cleaners can be individually configured with the TV FLEX work table to customize the machine to meet individual requirements. - Easy and understandable programming thanks to the integrated Cad-Cam MAESTRO CNC software - Easy to operate; the lowered machine frame makes the work table accessible at all times. The control cabinet and vacuum pump are integrated into the machine bed, and in the PRO SPACE version, no additional structural protective measures are necessary. Supporting structureThe supporting structure consists of a particularly strong monolithic steel base, ribbed and very robust. The particularly wide support was specifically designed to give the machine stability, ensuring constant precision in all working conditions. The machine does not need to be anchored to the ground. The base provides a large and solid support for the mobile column: the work unit is equipped with a balanced, stable and resistant support that can withstand the most extreme stresses, ensuring superior performance and greater precision. The mobile gantry consists of a solid single part anchored to the base and the work unit is fixed to it and moves along Y and Z axes, also on prismatic guides with ball return sliding blocks of the highest quality. The movement of the lower moving unit (X-axis) and the working unit along the crosshead of the moving unit (Y-axis) is achieved thanks to the power transmission via a rack and pinion with helical teeth; This creates a greater tooth-to-tooth thrust, which achieves greater acceleration and higher speed along the X and Y axes. The specially designed helical gearing ensures less wear on the mechanical components and less noise. The vertical Z axis is driven by a screw with ball return, which ensures perfect balance with dynamic loading and strong acceleration and deceleration. The main milling unit is directly coupled to the Z axis carriage and ensures very high quality finishing as vibrations are completely eliminated. Translation along the X-Y-Z axes is carried out by brushless motors driven by static inverters. These ensure:- Reduced machining times thanks to improved acceleration- Better positioning accuracy thanks to the high resolution encoder- Elimination of setup operations when switching on the machine thanks to absolute encoders- Elimination of general maintenance operations as there are no brushes with the "brushless" systemThe management of the axis displacement and in general of the working elements of the machine is done via e Kdsdpfx Abovvi Sco Uew

Condition: used, Storage location: Nattheim Kjdpfswkirqjx Ab Uodw

Condition: used, Year of construction: 2009, Automatic central lubrication Milling unit 7833 2-stage, 11 kW power 1000 - 24000 rpm 1 double drilling spindle in X-direction 1 integrated sawing unit for sawing / grooving in X-direction, traveling Tool changer 7892, 16-way Linear Pick-up changer, permanently installed on the right-hand side of the machine Laser pointer consisting of 2 laser pointers for positioning the vacuum suction cups or tracing the workpiece contour Automatic console - suction cup positioning 6 consoles including 3 suction cup holders per console including 1 vacuum suction cup 80x80 mm per suction cup holder including 4 feeding aids Additional processing fields at the front for 6 consoles Basic unit pneumatics for frame clamping system 7974 (6 consoles) 2D barcode scanner Video camera in the processing head Vacuum pump 140 m³/h Vario tool Change changing unit package consisting of Consists of: Vector axis 7899 (C-axis), fully interpolating, 0-360° continuously rotatable, including pneumatic tool changer 7890, single-slot magazine pick-up system, permanently installed in front of the machine frame on the left. Tool changer 7894, 6-slot pick-up magazine specifically for Vario Tool Change tool holders, permanently installed in the machine frame on the left, can be equipped with a Vario Grip KSJ F 40 collet chuck, 3 Vario Grip KSJ F 40 tool holders (for 2-20 mm ER32 collets), 1 saw blade holder, 3 collets according to customer selection, 1 carbide circular saw blade, max. 220 mm diameter. Ksdpfx Ajvvi Spjb Uedw Storage location: Nattheim

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Ksdpfx Aew Aifzob Usdw
