Used Cnc Measuring Machine for sale (67,476)

Condition: used, TECHNICAL DETAILS - Number of axes : 5 LINEAR AXES - X stroke : 400 [mm] - Y stroke : 250 [mm] - Z stroke : 250 [mm] - Rapid traverse rate : 24 [m/min] - Resolution : 0.0001 [°] GRINDING WHEEL HOLDER HEADSTOCK VERTICAL - C axis : 225 [°] - angular resolution : 0.0002 [°] - Spindle speeds : 12.000 [rpm] - Tool type : HSK-50E - Spindle power : 15 [kW] PART-HOLDER HEADSTOCK - Rotational speed range (rotary axis) : [rpm] - Rotation speed range (universal rotary axis) : [rpm] - angular resolution : 0.0001 [°] POWER SUPPLY - Supply voltage : 400 [V] Fsdpfjwwa Dksx Apwsgf WEIGHT & DIMENSIONS - Machine floor space : 1980 x 1750 [mm] - Machine height : 1960 [mm] - Machine weight : 2800 [kg] EQUIPMENT - CNC : SIEMENS SINUMERIK 840D - Automatic loading and unloading system with 50 positions

Condition: used, CNC press brake FASTI, Type 904-125/30 Serial No. 95-904-5775 Year of manufacture 1995 Press force 125 tons Fedpfx Apshmmfkowjgf Working length 3050 mm Stroke approx. 335 mm Stand distance 300 mm Distance between side stands 2550 mm Tool installation height max. 465 mm (opening width between tool holders) Table width 90 mm (the clamping system is mounted on the table) Table height above floor 875 mm (910 mm with clamping system) Back gauge X-axis 500 mm Back gauge R-axis 115 mm Back gauge Z-axis approx. 1950 mm Lowering speed Y-axis rapid traverse 90 mm/s Lowering speed Y-axis working traverse 8.9 mm/s Return speed Y-axis retraction 75 mm/s Oil capacity approx. 160 liters Motor power 18.5 kW Mains connection 400 volts, 50 Hz, 20 amps - 7-axis CNC control DELEM, Type DA 58 with LCD screen - 1 axis for back gauge - gauge depth (X-axis) - 2 axes for back gauge - gauge height (finger R1 + finger R2) - 2 axes for back gauge - gauge fingers, laterally adjustable (finger Z1 + finger Z2) - 2 axes for press beam with servo valves and measuring system Y1 and Y2 - Operation via electric foot switch and 2-hand control panel or only 2-hand control panel - Hydraulic tool clamping for the upper tool system TRUMPF, with 20 mm clamping groove - Hydraulic tool clamping for the lower tool with 13 mm table groove, depth 21 mm (tool shank 13 x 20 mm) - Safety light curtain FIESSLER, Type AKAS - 2 pcs material support arms, manually adjustable laterally and in height - Electrical diagram, hydraulic diagram, user manual for control system available - Control cabinet on the machine - Without tools Space requirement L x W x H 5000 x 2500 x 3050 mm Transport dimensions L x W x H 5200 x 1900 x 2950 mm Weight 8.5 tons Good condition

Condition: used, Servo press brake SAFAN Type SMK-P 50-2550 TS1 Downstroke bending machine with 4-axis CNC control Serial No. MK 285 Year of manufacture: 1998 CNC control SAFAN software version 5.07 TS1 Press force: 500 kN (50 tons) Fsdpoxpqy Djfx Apwogf Working length: 2550 mm Stroke: 215 mm Clearance between side frames: 2700 mm Tool installation height: max. 414 mm Table width: 55 mm Table height above floor: 950 mm Approach speed: approx. 75 mm/s Return speed: approx. 75 mm/s Working speed: approx. 1.6 to 15 mm/s Motor power: 9 kW Power supply: 400 Volt, 50 Hz, 9 kW - 4-axis CNC control SAFAN software version 5.07 TS1, Y1 and Y2 axis for ram - 2-axis backgauge, X-axis (backgauge depth adjustment), R-axis (backgauge height adjustment) - 2 backgauge fingers, laterally adjustable by hand (Z1, Z2) - Ram drive via 2 servomotors and belt drive - Working speed steplessly adjustable - Operation via electric foot switch and/or two-hand control panel - 13 clamping holders for the upper tool (UKB system, type 50.571, UKB System A) - Tool holder for lower tool, 55 mm wide with 13 mm groove, 21 mm groove depth (Trumpf system or UKB System B) - Supplied without bending tools (a new set from UKB costs approx. 3,600 EUR net) - Displayed total operating hours = 8,120 h - Number of working strokes: 1,049,789 strokes Space requirements (L x W x H): 3450 x 1850 x 2650 mm Weight: 5,000 kg Good condition

Condition: used, CNC Press Brake BEYELER - BYSTRONIC Type PR 8 (2500 kN x 3100 mm) Press brake with 6-axis backgauge and CYBELEC control Serial No.: Year of manufacture: 2001 Pressing force: 250 tons Working length: 3100 mm Stroke: 365 mm Throat depth: 410 mm Clearance between side frames: 2750 mm Table width: 100 mm, 200 mm with table extension Table height above floor: 840 mm Backgauge X-axis: 620 mm travel Backgauge R-axis: 240 mm Approach speed: 200 mm/s Working speed: 1-10 mm/s Y rapid traverse: 200 mm/s Y working traverse: 1-10 mm/s Y return: 135 mm/s Oil capacity: approx. 400 liters Motor power: 18.5 kW Connected load: approx. 25 kW Power supply: 400 Volt, 50 Hz, 50 Amp. - 8 axis CNC control Cybelec DNC 1200 PS/A, X1 + X2 / R1 + R2 / Z1 + Z2 - 2 freely programmable backgauge fingers, laterally movable (Z1+Z2) - Backgauge (X-axis 620 mm) with 3 gauging points up to max. 1080 mm - Ram with servo valves and measuring system Y1 and Y2 - FIESSLER AKAS safety light barrier Fgedpfx Apjya Iaqewsf - Operation via electric foot switch and/or two-hand control panel - Hydraulic upper tool clamping (TRUMPF system) with 20 mm clamping slot - Tool holder for lower tool, height 160 mm x width 60 mm, with holder slot 14 x 23 mm - Tool system TRUMPF, without tools Space requirement (L x W x H): 0 x 2500 x 3400 mm Machine transport height: 3360 mm Weight: 17,000 kg Good condition

Condition: used, CNC turning machine TRAUB, Type TND 400 Serial No. 708, Year of manufacture 1996 CNC control TRAUB TX 8 F Nominal turning diameter: 400 mm Swinging diameter over bed: max. 470 mm Spindle bore in draw tube: 65 mm Motor power, spindle drive: 22 kW Fgsdpfx Aezacwdjpwef Total power consumption: 35 kW Mains connection: 380 volts, 50 Hz - Electronic handwheel - RS 232 data interface - Turret with 12 tool positions, VDI 40 - Includes 8 tool holders, VDI 40 - 3-jaw chuck, Ø 225 mm, SMW Autoblok, Type KNCS-N-Ø 225-65 Includes a large quantity of chuck jaws - Hydraulic internal expanding cylinder, SMW, Type ZHDAS-130-67 - Chip conveyor, KNOLL, Type 200 S-1/600 - Coolant system - Hydraulic unit (L x W x H 650 x 500 x 1000 mm) Space requirement L x W x H: 4800 x 2000 x 2100 mm Space requirement, base machine L x W x H: 3500 x 2000 x 2100 mm Space requirement, chip conveyor L x W x H: 4500 x 700 x 1550 mm Weight: approx. 5 tons Good condition Machine is ready for demonstration. The internal expanding cylinder for workpiece clamping needs to be repaired.

Condition: excellent (used), Year of construction: 2015, operating hours: 3,900 h, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 610 mm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 3,900 h, We offer in very good condition Hurco VMX30 HSi with HSK-A63 spindle and 18k RPM. X-Axis travel: 762mm Y-Axis travel: 508mm Z-Axis travel: 610mm The machine has following options: Internal coolant 20 bar 40 Tool changer 18 k RPM Spindle hSK-A63 Linear Scales Touchprobe Renishaw OMP40 Toolprobe Renishaw TS27R Ultimotion software Fgjdsx N E H Uspfx Apwsf Tool change optimization software Please not vices are not with sale of machine

Condition: excellent (used), Year of construction: 2003, table length 900 mm table width 900 mm x-travel 457 mm y-travel 508 mm Fgedpfxsx Szp Dj Apwjf z-travel 406 mm control Brown & Sharpe weight of the machine ca. 250 t dimensions of the machine ca. 1300 x 1000 x 1600 m

Condition: excellent (used), Year of construction: 2000, x-travel 3000 mm y-travel 1400 mm z-travel 1600 mm control DEA B3C-LC workpiece weight 4500 kg table surface area 4730 x 1465 mm tool taper RENISHAW PH10M weight of the machine ca. 4 t Fodpfx Asxb Eg Nopwogf dimensions of the machine ca. 4 x 3,8 x 3 m

Year of construction: 2022, condition: excellent (used), functionality: fully functional, We offer this like-new LIYU IECHO TK4s cutting plotter / CNC milling machine, manufactured in 2022. Manufacturer: LIYU IECHO Model: TK4s Year of Manufacture: 2022 Condition: Like new Machine Type: Cutting Plotter / CNC Milling Machine PLATINUM Q-CUT 3532 flatbed cutter with camera + 1.8 kW milling module Includes software, monitor, and PC. Used very little and in excellent condition. Working area of 3500 x 3200 mm Equipped with an automatic camera positioning system (CCD), regional vacuum system, AKI system for precise knife depth adjustment, and 2 motors on the X-axis for high accuracy and clean cutting results. Material thickness up to 45 mm Max. cutting speed 1500 mm/s Cutting accuracy ± 0.1 mm Formats: PLT, DXF, HPGL, PDF, EPS Vacuum pump: 7.5 kW 6-zone control system Two cutting heads, safety device, automatic tool adjustment Tools / Applications Kiss-cut, UCT, EOT, EOT3, PRT, DRT, V-CUT, CTT, 1.8 kW router, punching tool. Suitable for cardboard, DiBond, Forex, MDF, wood, acrylic, Plexiglas, vinyl, and many other materials. Cutting area: 3500 mm x 3200 mm Tools: Electric oscillating tool, tangent knife, creasing tool, kiss-cut tool, powerful rotary tool Camera System AKI System Cutting accuracy: 0.1 mm Power supply: 220 V 50 Hz / 380 V 50 Hz Automatic camera positioning system Disassembly, reassembly, and transport costs are additional. A quote for disassembly, reassembly, and training is available from the manufacturer! Fsdpfx Ajy Tk R Hepwegf If the distance is considerable, an inspection can also be carried out via live video. All information is provided without guarantee. Subject to change, errors and omissions. If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, Equipment: documentation/manual, type plate available, PRICE REDUCED!!!!! Taylor Hobson Talyrond 265 roundness measuring system. Extremely accurate; it can measure the roundness of lenses, optics, pistons, turbine components, tubes, and shafts, as well as eccentricity, e.g., of cams on a camshaft or journals of a crankshaft. It is certainly of interest to motorsport and tuning companies. The first photo is a "representative image" from a Taylor Hobson catalog, showing the system's setup, except for the computer, which is a newer model from HP with a small form factor.... Max. diameter 350 mm Max. test piece height 500 mm (higher measurements are possible by measuring in two halves, up to a maximum of 1000 mm....) Self-centering of the workpiece +/- 5 mm Fgjdpfxezcqy Ee Apwsf Max. weight of test piece 40 kg The system has been used very little and has had only two owners. The first owner, from whom I purchased it, was an implant company in Hamburg, where it was used in a "medically clean environment." It is extremely clean and has never been in a dirty machine hall. The year of manufacture is estimated to be between 2002 and 2005. The Taylor-Hobson measurement software is, of course, included and runs on the supplied HP computer (without a password....). Accessories are included: the original Taylor-Hobson desk, computer, monitor, seven (7!) probes, each of which is very expensive to purchase. A sample/sample lens (hemisphere) for calibration is also included! The very detailed operating manual is on the USB stick, and all circuit diagrams and functional schematics are also included! The system will be shipped on two Euro pallets using a freight company. It is already securely fastened to them. The Talyrond 265 and the desk will be wrapped with bubble wrap, etc., and stretch film to provide maximum protection for transport. The system itself is secured with "transport safety screws"... Shipping costs within Germany are included, I will cover them!!! So, within Germany: FREE SHIPPING!!! The measuring system should definitely be set up and commissioned by a Taylor Hobson service technician, who can then recalibrate the system on-site. This is now recommended after a few years. Errors can be made during setup and commissioning. For example, some locking screws are installed for transport, and if you forget to remove them, the system may be damaged when it starts up... A truly well-maintained, very accurate system that will continue to provide excellent service for many years to come!!

Condition: used, Year of construction: 2006, Measurement range width/length/height: 1600/1800/1000 mm Dimensions width/length/height: 2450/2940/3800 mm Maximum workpiece weight: 3500 kg Measurement machine weight: 8500 kg Creep feed: 0 - 5 mm/s Fgodpfx Aszn Iucepwjf Setup operation: 0 - 70 mm/s Series measurement operation Axis: max. 300 mm/s Vector: max. 425 mm/s Software version: Calybso 2023/ Service Pack 2 – Version 7.6.08 Various measuring probes Measuring head

Condition: used, Year of construction: 2008, machine/vehicle number: 220028, CNC control: HEIDENHAIN iTNC 530, travel ranges: X-axis 4300 mm, Y-axis 1500 mm, Z-axis 1300 mm, table size 4970 mm x 1200 mm, max. table load 15,000 kg/m, tool holder ISO 50, multi-angle milling head 45°, automatic angular positioning of axes B and A, spindle motor power 22 kW, hydraulic rotary lock, working feed rate 10,000 mm/min, rapid traverse rate 20,000 mm/min, with coolant system, total spindle operating hours: 25,496 hours. Fgodpfezn A U Rex Apwjf

Condition: ready for operation (used), functionality: fully functional, One used CNC gear grinding machine OERLIKON Opal 800 Max. tip diameter: 1000 mm Min. root diameter: 40 mm Min. module: 1 Max. module: 16 Number of teeth: 999 Fsdpfx Apjyucd Hjwegf Max. gear width: 630 mm Opal grinding wheel and diamond disk Only single profile grinding possible, see photo.

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, CNC Spiral Bevel Gear Cutting Machine Gleason No 631 Year of manufacture: 2011 Control: SIEMENS 840d Retrofitted in 2011/2012 with new control, drives, etc. Fsdpfx Asw Tfb Sopwegf The machine was fully overhauled in 2011. A new control system and drives were installed.

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, 1 used CNC bed type milling machine with Heidenhain control. Additionally, rotary table Fjdpfx Apowxxzqswogf The rotary table has a diameter of 1200 mm. €220,000 – in 2012/2013 rebuilt with a new Rexroth rotary table, fully installed as a C axis. Swivel head is available. A wide range of tools as well as a 3D touch probe are included.

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, CNC Ball and Spherical Honing Machine with Turbo Separator Workpiece diameter (balls): ○22–○64 mm Workpiece diameter (spherical caps): ○22–○64 mm Control: GE FANUC / Series 321i-A Fgedpex U T Aujfx Apwof Measuring unit: Marposs Type 7/MHIS For internal and external measurement For further technical details, see photos.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, Grinding worm dimensions: Min./Max. outer diameter: 280/350 mm Width: 84/104 mm Max. pitch with limitations: MOD 8.0 (DP 3.2) Number of threads: up to 3 with limitations Max. usable width (shift distance): 90 mm For detailed technical information, please refer to the attached PDF file. Fsdpfx Asyfnlkjpwjgf Accessories: Several Fässler diamond wheels Dressing device Grinding stones Turbo separator

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting Fgsdpfxjvt D D Us Apwsf - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: used, Horizontal machining center with 2-fold shuttle table STEINEL type BFZ 5 with CNC control SIEMENS Sinumerik 810 M serial no. 34 year of construction 1988 Travel X: 500 mm, Y: 400 mm, Z: 320 mm Clamping surface, table surface 500 x 400 mm Tool holder ISO 40 Spindle speed max. 6300 rpm infinitely variable Main spindle drive 12 kW Mains connection 380 Volt, 50 Hz, 30 kVA - Tool changer with 24 tool positions - Changing table with 2 stations - Interface for data transfer - Coolant unit with chip conveyor Space requirement L x W x H 4100 x 2500 x 2650 mm Fjdpfx Apsutuyijwjgf Weight approx. 8 tons good condition Transport dimensions: Machine L x W x H 3200 x 2500 x 2650 mm, approx. 7.5 tons. Chip conveyor L x W x H 3500 x 1100 x 2100 mm, approx. 600 kg

Condition: used, 4-axis CNC drilling and milling machine IXION Type 30 CNC W VMC, BAZ, machining center Year of construction approx. 1997, machine overhauled in 2020 Travel X: 600 mm Y: 350 mm Z: 600 mm Table size 800 x 400 mm Fgjdpeu Tln Nsfx Apwef T-slot spacing 75 mm Table load 300 kg Spindle holder SK 40 (tightening bolt DIN 69872 A) Spindle speed 20-5000 rpm Torque at the spindle max. 150 Nm Distance between spindle nose and table max. 660 mm Feed speed X, Y and Z 0 - 5000 mm/min. infinitely variable Rapid traverse speed X, Y and Z 15000 mm/min. Tool change time approx. 5 sec. Tool change time from chip to chip approx. 7.5 sec. Milling capacity in St 60 150 ccm/min. Drilling capacity in St 60 35 mm Thread cutting capacity in St 60 M24 Spindle motor drive power 5 kW (10 kW at 25% duty cycle) Mains connection 400 Volt, 50 Hz - CNC control Heidenhain TNC 415 with 12" TFT display - Electronic handwheel - RS 232 interface - 12-position tool changer - hydro-mechanical tool clamping - Rotary axis as dividing head on the table = 4th axis, MECATECNICA type DCN 250-8, jaws lathe chuck Ø 200 mm Speed approx. 25 rpm, transmission ratio 1:180 - Cabin lighting via 2x halogen spotlights - Chip conveyor with coolant pump - Switch cabinet fixed to the machine Space required for transportation Length 320 cm x width 230 cm x height 300 cm Footprint of the machine with chip conveyor L x W x H 3200 x 3100 x 3000 mm Weight of the machine 3100 kg Weight of the chip conveyor approx. 200 kg good condition

Condition: used, CNC Milling Machine DECKEL Type FP 3 A Tool-tool milling machine with handwheels, also for conventional operation Serial No. 2206 - Built in 1982 GRUNDIG CNC 2101 CNC control system Travel paths X: 490 mm, Y: 300 mm, Z: 340 mm Table size 705 x 425 mm Spindle mount SK 40 Fsdov R E Rdopfx Apwsgf Quill stroke 100 mm Spindle speed 25 - 2500 rpm, 21 steps Feed rate 5 - 500 mm/min, continuously variable Rapid traverse speed 1200 mm/min Spindle motor power: 2/4 kW, pole-changing Power supply: 380 V, 50 Hz - GRUNDIG CNC 2101 CNC control system - Mechanical handwheels for all three axes - Universal tilt-and-turn table - Vertical milling head tilts and is manually adjustable by 200 mm - Hydro-mechanical tool clamping - Coolant system in the machine base - Protective enclosure at the front and sides with three hinged doors - Control cabinet adjacent (L x W = 600 x 430 mm) Space requirement: L x W x H: 1900 x 1700 x 1950 mm Weight: 1700 kg (machine 1540 kg + electrical cabinet 160 kg) Very good condition

Condition: used, CNC Universal Coordinate Drilling and Milling Machine FEHLMANN Type PICOMAX 100-CNC 3 CNC Control HEIDENHAIN TNC 155 Manufacturer's No. 16186651 Year of Manufacture 1986 Spindle Taper FEHLMANN SF32 Drilling Capacity Ø 30 mm in steel Thread Cutting up to M20 in steel Travel X: 850 mm, Y: 435 mm Quill Stroke Z: 210 mm Vertical Movement of Milling Head 580 mm Feed X and Y 1 to 8000 mm/min. Feed Z 1 to 4000 mm/min. Rapid Traverse X and Y 8 m/min. Rapid Traverse Z 4 m/min. Table Clamping Surface 1570 x 500 mm Distance Spindle Nose - Table 130 - 720 mm Overhang Spindle - Column 450 mm Spindle Speed 50 - 7100 RPM, stepless Spindle Drive 10 kW Total Connected Load 20 kW Mains Connection 400 Volt, 50 Hz - CNC Control HEIDENHAIN TNC 155 with TFT monitor - 3 axes controlled, X, Y and Z quill adjustment - hydro-mechanical tool clamping FEHLMANN SF32 - threading device - cable remote control for machine operation and axis movements Fgodpfx Aehik Ezspwef - motorized vertical movement of the milling head with shutdown via adjustable cams - 3D probe RENISHAW, Type MP 11F with FEHLMANN SF32 mount - 20 tool holders FEHLMANN SF32 - swiveling tool holder with 21 tool positions - coolant system in the machine frame - control cabinet fixed to the machine - documentation: operating manual, control manual and electrical diagrams Space Required L x W x H 2350 x 2000 x 2300 mm Weight 3.2 tons very good condition

Condition: used, CNC Gantry-Type Boring and Milling Machine ANAYAK Type HVM-3800-P Bed type milling machine, structure similar to a plate-type boring mill with fixed table Machine No.: M-20021203 Year of manufacture: 2002 ("Refurbished 2025") The machine will be completely workshop overhauled in 2025 and can then be inspected in storage at 37235 Hessisch Lichtenau. Travel distances: X: 3,200 mm, Y: 1,200 mm, Z: 1,500 mm Table size: 3,800 x 1,200 mm T-slots: 8 pieces, 22 mm, spacing 130 mm Table load: max. 25 tons (stationary table – virtually unlimited load capacity) Spindle taper: ISO 50 (DIN69871-A) (drawbar: DIN 69872-B) Spindle speed: 60 – 4,000 rpm, stepless Feed rate: up to 10,000 mm/min, stepless Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Electrical connection: 400 Volt, 50 Hz, 50 kVA - Automatic tool changer for 30 tools - Spindle drive with 2 speed ranges Fodsxcgtgspfx Apwjgf - With automatic tool changer and tool magazine - Orthogonal milling head with hydro-mechanical tool clamping - Orthogonal milling head fully automatic swiveling in two 45° planes – B+C axis - HEIDENHAIN iTNC 530 control, with electronic handwheel - Prepared for wireless touch probe (probe and receiver not included) - Additional HF-spindle, 18,000 rpm – for attachment - Free-standing control cabinet - Chip conveyor positioned between the gantry bed and the machine table - 32,078 operating hours recorded - Coolant system - Free-standing hydraulic unit - Operating manual with circuit diagrams Installation area (L x W): approx. 1,000 x 700 cm Installation height: approx. 410 cm Weight (total): approx. 33 tons Good condition

Condition: used, CNC Tool Milling Machine MIKRON Type WF 40C/3M Fodpfx Apew A Af Ijwjgf with Heidenhain TNC 310 CNC path control Machine No. 440911 Year approx. 1985, overhauled and control retrofit in 11/2000 Travel distances X: 600 mm Y: 600 mm Z: 460 mm Table size 900 x 550 mm Spindle taper ISO 40 Distance spindle nose - table max. 520 mm Spindle speed 31.5 - 3150 rpm, 21 steps Feed rate 1 - 2000 mm/min. Rapid traverse speed X and Y = 5000 mm/min; Z = 4000 mm/min Quill stroke 100 mm Main spindle drive 4 and 5 kW Power connection 400 Volt, 50 Hz, 10.5 kW, 25 Amp. - CNC path control Heidenhain TNC 310, NC software: 286140 07, PLC software: MIKR1 - Spindle speed via 21 gear steps - Vertical milling head swivels left and right - Hydro-mechanical tool clamping vertical and horizontal - Central lubrication - Electronic handwheel - 62,815 operating hours shown - Control cabinet permanently attached to the machine rear - Coolant system integrated in the machine base - Swiveling operator panel - Electrical diagram, control manual available Space requirement L x W x H 2300 x 2000 x 2150 mm Weight 2900 kg Good condition

Condition: used, CNC 5-Axis HMC – Horizontal Machining Center, Milling Center, Manufacturing Center Manufacturer: LICON Model: Liflex 1266 PC B1 Year of construction: 2016, Commissioned: 2017 Equipped with SIEMENS 840D SL (Solution Line) CNC path control, with 5 simultaneously controlled axes Travel paths X: 1200 mm, Y: 660 mm, Z: 650 mm A-axis as swivel bridge +/– 135° (270°) B-axis 360° continuous Axis acceleration X + Y-axis 6 m/s² Axis acceleration Z-axis 9 m/s² Feed force X + Y-axis 7500 N Feed force Z-axis 10000 N Positioning tolerance (X/Y/Z) 0.008 mm A-axis swivel speed 180° rotation in 4 sec. Interference diameter on the swivel bridge max. 1400 mm Transport load on the swivel bridge max. 700 kg Tool holder HSK 63 Spindle speed max. 12,000 rpm, stepless Spindle power 37kW at 40% duty cycle Spindle torque at 40% duty cycle 85 Nm Maximum spindle torque 100 Nm Tool change time (chip-to-chip) approx. 3.7 sec. Tool diameter with adjacent slots occupied Ø 140 mm Tool diameter with adjacent slots free Ø 250 mm Maximum tool length 400 mm Maximum tool weight 20 kg Power supply 400 Volt, 50 Hz Connected load 80 kVA Compressed air connection 5-8 bar - LIFLEX MSP 80/63/85/12,000 motor spindle (output 37kW/40% duty cycle) with liquid cooling and recooling unit - 2-axis rotary tilting table LICON as B- and C-axis, with hydraulic axis clamping - Zero-point clamping system on the swivel axis turntable - Dual pallet changer, without pallets (these need to be newly sourced) - Media transfer of 5 single-action pressure lines for oil or air, for workpiece clamping on the pallets Hydraulic functions from 30-150 bar, with pressure monitoring (controllable via M-functions) - Tool changer with 30 tool positions, disc turret type - Machine designed for dry machining with minimal quantity lubrication (MQL) system - MQL-TSC, internal MQL lubrication supply through the spindle - Scraper belt chip conveyor, discharge height 1150 mm - Licon ECO-Mode (energy-efficient aggregate operation) - Direct linear measurement system on all axes Fgodpfst Ac Efjx Apwef - Operating hours (control voltage on) ≈ 7,500 h Space required for operation L x W x H 9,000 x 5,000 x 3,800 mm Space required for transport L x W x H 6,100 x 4,400 x 3,600 mm Base machine weight approx. 21 tons Total weight: approx. 24 tons Very good condition
