Used Grain Mill for sale (10,479)

Condition: used, Year of construction: 1980, Technical details: x-travel: 850 mm y-travel: 280 mm z-travel: 355 mm spindle taper ISO: SK 45 / SK 45 spindle head swivable left - right: je 90° ° range of revolution per miute: 28 - 1400 / 18 step U/min distance table/horizontal spindle: min.: 60 / max.: 180 mm table surface area: 1070 x 270 mm table load: 1000 kg table swivelling +/-: je 45° Grad feed:: X+Y: 16 - 800 und Z: 5 - 250 mm/min total power requirement: 8,0 kW machine weight approx.: 3100 kg dimension machine xH: 2,1 x 1,8 x 2,15 m dimensions electric cabinet: L: 0,8 x B: 0,45 x H: 1,65 m clamping surface area: 315 x 1250 mm Horizontal beam adjustment manual 650 mm mounted on table: clamping head with 3-jaw chuck Ø 200 mm with inner jaws, center height 165 mm Coolant system Hand crank Dsdpfou Ndf Ijx Ak Aecp Milling arbor Ø 22 x 620 mm with form cutter 80 x Ø 8 mm *

Condition: used, Year of construction: 1990, TECHNICAL DETAILS Travel ranges X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 400 mm Work table Table size: 680 × 380 mm Control system CNC control: Philips 432 Feed rate and rapid traverse Feed rate range: 1–3,000 mm/min Rapid traverse: 6 m/min Spindle and tool holder Tool holder: ISO 40 Speed range: 20–3,150 rpm Main drive: 5 kW Milling head Swivel range of milling head: ±90° Performance data Total power requirement: 12 kW Machine weight: approx. 1.2 t Dimensions Dsdpfx Aksz S Name Ascp Space requirement: approx. 2.5 × 2 × 2 m EQUIPMENT Swiveling milling head Philips 432 CNC control

Condition: used, Year of construction: 1990, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel ranges X-axis: 600 mm Y-axis: 500 mm Dcsdpfxjz S I Suj Ak Aep Z-axis: 500 mm Work table Table size: 500 mm Feed rate and rapid traverse Feed rate range: 2–10,000 mm/min Rapid traverse: 10 m/min Spindle and tool holder Tool holder: ISO 40 Speed range: 0–6,300 rpm Main drive: 8 kW Control system CNC control: Dialog 11 Performance data Total power consumption: 23 kVA Machine weight: approx. 5,050 kg Dimensions Space requirement: approx. 3.0 × 2.5 × 2.0 m Overhaul and modernization Overhaul: 2010 by FPS Modernization: 2010 by FPS EQUIPMENT Splash guard cabin Rotary table as 4th axis Tool changer magazine with 40 positions Dialog 11 control

Year of construction: 2008, condition: used, Equipment: workpiece handling system, sub-spindle, live tooling on both turrets, two turrets, the upper turret is equipped with an additional milling spindle. Rated current: 119A, max. upstream fuse rating: 125A, control voltage: 24V DC, connected load: 70kW, control system: Siemens 800D, operating hours: 92,329h, a machine retrofit is required before the machine can be put back into operation. An on-site inspection is possible. Dcjdo Ah Tx Tepfx Ak Aep

Condition: used, Year of construction: 1987, x-travel 500 mm y-travel 430 mm z-travel 400 mm Control HEIDENHAIN, TNC 114 B Dcjdps Adakfefx Ak Ajp table surface area 800 x 390 mm spindle taper SK 40 spindle turning speed range 50 - 2500 U/min spindle drive 3 kW max. torque on the spindle 5 Nm feeds X-axis 4 - 1600 mm/min feeds Y-axis 4 - 1600 mm/min feeds Z-axis 4 - 1000 mm/min rapid traverse X/Y/Z axis 1,6 / 1,6 / 1,0 m/min power feed x/y/z 5000 N table load capacity max. 250 kg total power requirement 6 kW weight of the machine ca. 1,6 t dimensions of machine L x W x H 1,70 x 1,50 x 2,03 m Accessories: vertical head with hydr. tool clamping and quill retraction, solid table, various tool fixtures, coolant

Condition: good (used), Aciera f3 milling machine. Automatic longitudinal feed (x-axis). Spindle mount: W20 Power supply: 400V Axis travel: X-axis: 300 mm Dcjdpfx As Ahd Ufek Asp Y-axis: 300 mm Z-axis: 135 mm

Condition: good (used), Aciera f3 milling machine. Spindle speed is controlled by a frequency converter. Automatic longitudinal feed (X-axis). Automatic feed for the Z-axis. Spindle taper: W20 Power supply: 400V Axis travel X-axis: 300 mm Y-axis: 300 mm Z-axis: 135 mm Dodpfo Ahd T Tsx Ak Aocp Digital readouts on all axes.

Condition: used, Year of construction: 1973, Indexing milling cutter with 3-roller feed spindle, 30 mm diameter. Location: Nattheim. Djdpfszd Tg Aox Ak Ajcp

Condition: used, Year of construction: 2002, machine/vehicle number: 6243, travel distance X-axis: 5,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 1,500 mm, Equipment: documentation/manual, Base machine / travel ranges: X-axis machine stand 5,000 mm, Y-axis spindle head slide 2,100 mm, Z-axis spindle head 1,500 mm. Machine stand: Compact, torsion-resistant welded construction with hardened flat guide rails and telescopic steel covers to protect against chips and coolant. Spindle head slide: Cast iron design with hydraulic weight compensation, guided by combined roller/plain bearing guides. Machine bed: Flat bed design with approximately 1,200 mm guide rail width and roller compact guides for high precision. Automatic universal milling head: CNC-swiveling milling head arbor 340 x 1°, Hirth gearing approximately 125 kN; milling head 180 x 1°, approximately 100 kN; milling spindle with hydromechanical tool quick-change system, clamping force approximately 25 kN; tool holder SK 50, DIN 69871. Main drive: 37 kW at 100% ED, 53 kW at 40% ED; externally ventilated AC motor, 2-stage gearbox with automatic changeover; speed 22–4,000 1/min. Feed drives: Digital AC individual drives; X/Y: 2–12,000 mm/min, Z: 2–15,000 mm/min. Control system / measuring systems: Central operation via Heidenhain TNC 430 M. Direct, non-contact linear measuring systems. Optional: Heidenhain iTNC 530. Electrical system: EN 60204 / VBG 4, 400/230 V ±10%, 3 phases, 50 Hz, 24 V control voltage; connected load approximately 80 kVA. Control cabinet IP54, main motor IP55. Lubrication: Main gearbox / milling head drive oil circulation lubrication; main spindle grease long-life lubrication; guides / ball screws pulse central lubrication. Coolant: Dcodpfx Aksz Dvycj Asp Internal / external coolant supply with paper band filter. Max. 50 l/min at 10 bar or 47 l/min at 16 bar; tank 500 l. Coolant / air changeover. Oil cooler for temperature stabilization and increased manufacturing accuracy. Leveling system: Electromechanical, via 2 vertical ball screws with separate drives, measuring systems, and CNC axes. Working platform: Moves in the X direction, with CNC control panel; electrically secured door with viewing window. Pick-up station: 10 tools; max. tool weight 25 kg, length 400 mm, Ø 125 mm, with free adjacent slots Ø 250 mm. Clamping plate: 3,500 x 3,000 mm; T-slots 22 H12 DIN 650, spacing 250 mm; clamping surface accuracy class 1 DIN 876. CNC rotary table: Clamping surface 1,250 x 1,600 mm / Ø 1,800 mm; Hirth division 360 x 1°; 6 longitudinal slots 22 H12, 2 positioning slots 22 H7; T-slot spacing 160 mm; centering bushing Ø100 H7 x 20 mm; max. 5 1/min; tilting moment 85,000 Nm; tangential moment 120,000 Nm; table load max. 11,500 kg. Additional equipment: Oriented spindle holder 360 x 1°; hinged band chip conveyor for X=5,000 mm, feed width approximately 350 mm, discharge height approximately 1,250 mm; 3D touch probe; electronic handwheel HR 410 for 3 axes; pendulum machining for 2 work areas with monitored safety areas; manually adjustable splash guard. Collision monitoring: Brankamp CMS with piezoelectric strain gauge; if the process limit is exceeded, the axes are braked and the machine is switched off. Painting: Machine / control cabinet RAL 7035, milling head / spindle head RAL 5021; DD structured paint, semi-gloss, oil and alkali resistant. Power connection: 400 V, 3 phases, 50 Hz, 80 kVA, 160 A slow-blow; compressed air 4–6 bar, connection G 1/4. CE-relevant environmental protection to be provided on-site; adapter plates for chip / coolant return are not included. Coordinate information: Y 730.0124. Documentation: Operating manual SHW-UF6L and Heidenhain TNC

Condition: ready for operation (used), Year of construction: 2012, operating hours: 10,000 h, functionality: fully functional, turning length: 1,000 mm, turning diameter over cross slide: 800 mm, spindle motor power: 26,000 W, spindle speed (max.): 4,000 rpm, spindle bore: 91 mm, travel distance X-axis: 370 mm, travel distance Y-axis: 70 mm, travel distance Z-axis: 1,050 mm, rotational speed (max.): 4,000 rpm, feed length X-axis: 25,000 mm, feed length Y-axis: 15,000 mm, feed length Z-axis: 30,000 mm, total height: 2,574 mm, total length: 3,930 mm, total width: 2,280 mm, spindle nose: A2-8, overall weight: 9,100 kg, Equipment: documentation/manual, The Mori Seiki NZX 2500/1000Y is an extremely robust and versatile CNC turning machine, designed for companies that demand high levels of productivity, accuracy, and flexibility. The machine is equipped with a Y-axis, which, in addition to conventional turning operations, enables complex milling and drilling operations. In combination with powered tools, this offers extensive possibilities for completely machining workpieces in a single setup. Dcedpfxez R T Exj Ak Asp The two turrets provide a large tool capacity and enable simultaneous operations. This makes the NZX 2500/1000Y particularly suitable for complex workpieces and series production. Additional options & accessories: - Double turret configuration (Turret 1 and Turret 2) - Y-axis - Powered tools - Interface for bar feeding - SMW Autoblok (SLU-X-2_ZS) hydraulic chuck - Renishaw measuring arm for tool measurement on Turret 1 and Turret 2 - High-pressure pump - HAINBUCH SPANNTOP nova Kombi Axfix Gr. 65 chuck - Various tool holders (powered and static) - All original Mori Seiki documentation Weight & dimensions: 9100 kg approx. 3930x2280x2574 mm (LxWxH)

Condition: used, Rotor diameter = 400 mm Rotor width = 700 mm Dsdpfxj Admcuo Ak Ascp Number of rotor blades = 3 Number of stator blades = 2

Condition: used, Year of construction: 2005, 1 used, very well-maintained crankshaft milling attachment for mounting, e.g., on a lathe for milling crankshafts or other milling operations. Manufacturer: SEMA, Origin: Austria Model: SE 100 Year of Manufacture: 2005 Technical Data: Spindle mounting: ISO 50, Runout / Test mandrel L=300 mm = 0.01 mm Speed range, continuously variable: Currently set to 2,000 rpm Spindle is designed for: Up to 3,000 rpm Drive power: Currently 15 kW The milling spindle is designed for: Up to 25 kW Bearing diameter: 110 mm The 2 bolted adapter plates under the milling spindle are each bolted on. These plates can be used for your lathe, modified, or may need to be newly manufactured. Mounting surface of the milling spindle: L x W: 490 x 250 mm Accessories / Special Features: Dedpfxjddziyj Ak Ascp Milling spindle: • The milling spindle is mounted on the flat support of your lathe • Continuously variable speed adjustment, frequency inverter manufacturer LENZE, designed for up to 30 kW • Right / Left rotation • Lifetime-lubricated spindle bearings • Stable construction with hardened and ground spindle • High precision • 2-fold supported spindle with 5 spindle bearings • Workpiece clamping via a threaded spindle • Mobile carriage with control panel • Emergency stop • Lockable main switch Indexing gear for the main spindle: • A long drive rod is mounted in the spindle bore and connected to the gear • Continuously variable speed adjustment, frequency inverter manufacturer LENZE • Right / Left rotation • Jog operation, fast / slow The pictures show this unit mounted on a universal lathe SARO SPA 10 x 3000 for milling crankshafts. This lathe is not included in the scope of supply! Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 1981, Table size 1300 x 400 mm Tool holder DIN 2080 ISO 40 Travel ranges X-axis, automatic/manual 1000 / 1020 mm Y-axis, automatic/manual 350 / 370 mm Z-axis, automatic/manual 430 / 450 mm Speed range, 2 steps 32 – 1400 rpm Quill in vertical milling head yes Milling head, swiveling ± 90° Feed range X/Y-axis, stepless 10 – 1000 mm/min Feed range Z-axis, stepless 4 – 400 mm/min Rapid traverse X/Y-axis 5 m/min Rapid traverse Z-axis 1.8 m/min Dodpod D Tf Hsfx Ak Ascp Drive power, vertical + horizontal 3.2/4 kW Space requirement L x W x H 3200 x 2700 x 2200 mm Weight 2400 kg Accessories / Special features: • NC point-to-point control HEIDENHAIN TNC 131 S • RS 232 interface • Stepless feed • Automatic and/or manual operation possible • Safety devices / prompts to secure the hand crank when the X-Y and Z axes are moved manually, as well as the manual tool clamping • Vertical and horizontal milling spindle • Quill in vertical milling head • Hydraulic axis clamping • Central lubrication • Coolant system Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Condition: used, Year of construction: 1991, Technical details: x-travel: 1050 mm y-travel: 600 mm z-travel: 650 mm range of revolution per miute: 40 - 1720 / 12 step U/min spindle taper: SK 50 spindle head swivable left - right: 90° re/li und 45° = 360° ° distance spindle nose and table: 0 - 600 mm table surface area: 1700 x 470 mm feed continuous: X/Y= 15 - 625 + Z= 7,5 - 312 mm rapid traverse Z-axis: 1250 mm/min. rapid traverse:: X/Y: 2500 mm/min. total power requirement: 11,1 kW weight of the machine ca.: 2500 kg machine dimensions LxWxH: ca. 2,45 x 2,0 x 2,85 m Equipment: with Huron universal milling head coolant system control panel machine feet Accessories Machine vice (jaw width 120mm) * Dsdpfx Akjva Hd Rs Aecp

Condition: used, Year of construction: 2014, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, CNC control: HEIDENHAIN iTNC 530 (HSCI) with a 15.1" flat-screen display and a pivoting control panel 2. Work table / Clamping surface Length: 2,200 mm Width: 1,000 mm Maximum transport load: 7,200 kg Number of T-slots: 7 Size of T-slots: 22 H12 mm Reference slot: 22 H7 mm Dcsdpsz Tugbofx Ak Ajp T-slot spacing: 140 mm 3. Automatic milling head (Option -AIH60A OIL) Design: Diagonal, swiveling in 2 planes Speed range: 0 – 6,000 rpm (Option) Tool holder: DIN 69871 AD (ISO 50) / Taper DIN 69871 Draw bolt: DIN 69872 Form A Tool clamping force: 15,000 N Lubrication: Automatic grease cycle lubrication (housing made of steel cast GS 60, designed for 45 kW and max. 2,000 Nm) 4. Main spindle drive motor / Manufacturer: Siemens, main spindle drive, Type: 1PH7 Drive power max. (Option): 36 kW from 376 rpm (standard equipment 30 kW) Maximum torque (Option): 930 Nm (constant up to 376 rpm; optional in gearbox up to 1,460 Nm or 1,750 Nm) Speed control / Gearbox: 3-stage (oil-cooled) with automatic switching and helical gears made of hardened chrome-nickel steel Spindle speeds (6,000 rpm Option): Low range: 0 – 984 rpm Medium range: 918 – 2,456 rpm High range: 2,404 – 6,000 rpm 5. Axis drives and axis feeds Axis drive motors: Manufacturer Siemens (digital AC drives) Rapid traverse max. (X/Y/Z axis): 15,000 mm/min Working feed max. (X/Y/Z axis): 12,000 mm/min Feed force max. (X/Y/Z axis): 24,000 N Measuring system: Linear measuring system “Heidenhain” (0.001 mm) in all axes Machine weight: approx. 17,000 kg Connection power: approx. 54 kVA Materials: Machine bed, work table, machine frame and vertical slide made of lamellar graphite cast iron GG30; milling slide made of nodular graphite cast iron GJS-600 Guide rails: Hardened and ground with Turcite B sliding strip coating (in X/Y/Z) Hydraulic system: Manufacturer Rexroth (including hydraulic weight compensation in the vertical axis) Lubrication & cooling: Automatic central lubrication of axes/ball screws, control cabinet with lighting and air conditioning unit Additional control: Portable electronic handwheel “Heidenhain HR-410” with axis selection, additional electric foot pedal for manual tool change Enclosure & Safety: 4-sided splash guard enclosure with large sliding doors, safety switches (CE compliant) and safety fencing for the rear.

Condition: excellent (used), Year of construction: 1998, Control system: Heidenhain TNC 124 Travel ranges X/Y/Z: 500 x 400 x 400 mm Dcsdpfx Ao Aa D Dhek Aep Spindle speed: 4,500 rpm Tool holder: SK 40 Manual rotary table with tilting axis: 700 x 500 mm

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning length: 1,011 mm, turning diameter: 658 mm, spindle bore: 102 mm, travel distance X-axis: 615 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 1,077 mm, rotational speed (max.): 3,300 rpm, rotational speed (min.): 50 rpm, bar passage: 102 mm, total height: 2,720 mm, total length: 6,585 mm, total width: 2,800 mm, overall weight: 13,400 kg, We are pleased to offer this Mazak Integrex i-400 x 1000 multitasking CNC machine, manufactured in 2011 and equipped with Mazatrol Matrix control. A versatile machine combining turning and milling operations in a single setup, ideal for precision machining and complex (bigger) components. Technical specifications: Turning diameter: 658 mm Dcedpfx Aksz Rt Dtj Aep Max. turning length: 1011 mm Bar capacity: 102 mm Travel on X-axis: 615 mm Travel on Y-axis: 250 mm Travel on Z-axis: 1.077 mm B-axis travel: -120/+120° Main and spindle: 50 - 3300 1/min. B-axis index increments: 0,0001° C-axis indexing of spindle: 0.0001° Milling spindle: 12,000 rpm (Capto C6) Tool magazine: 36 tool positions NC Tailstock: MK5 We realise that you may wish to receive further information or view the machine. In that case, please contact us, providing your company details so that we can get in touch with you. About Mamach Machinehandel: With over 40 years’ experience in the CNC machinery sector, we are now one of Europe’s leading suppliers of metalworking machinery. Our success is based on high quality, customer-focused service and a strong international network. Discover our wide range of used CNC lathes and machining centres – we’d be happy to advise you personally!

Condition: used, Year of construction: 2004, turning diameter 820 mm turning length 3000 mm control Siemens 840 D workpiece weight 2,5 t drive of main spindle 77 kW spindle nose A15 spindle bore 160 mm Workpiece head (C-axis) 0,005 grad max. torque on the working spindle 2500 Nm main spindle speeds: 0-2.430 U/min feeds z-axis 0,1-18.000 mm/min rapid traverse Z-axis 18 m/min feeds x-axis 0,1-30.000 mm/min rapid traverse X-axis 30 m/min steady 50-350 Spannbereich tailstock - quill dia 180 mm tailstock - travel of quill 170 mm y-axis -100/+150 mm rapid traverse y-axis 12.000 mm/min b-axis -105/+95 Grad milling spindle - taper HSK100 milling spindle motor 43 kW milling head speed 1-5.500 U/min max. torque on the milling spindle 336 Nm tool changer 96 Plätze weight of tools max. 15 kg total power requirement 166 KVA weight of the machine ca. 40 t dimensions of the machine ca. 112x4,4x3,85 m Dcedpez S Nx Aofx Ak Aop

Condition: good (used), Year of construction: 1962, Spindle mounting, vertical + horizontal SK / ISO 40 Angular table clamping surface 700 x 285 mm X-axis travel 500 mm Y-axis 200 + approx. 250 mm Z-axis 400 mm Quill stroke approx. 80 mm 18 main spindle speeds 40 - 2000 rpm 18 feed speeds 8 - 400 mm/min rapid traverse 1200 mm/min Djdpfx Asm Uygvek Ajcp drive power 2,2 kW dimensions L x W x H 1150 x 1050 x 1650 mm Machine weight 1000 kg Accessories / special features: - Vertical milling head, swiveling R/L - Fixed angle clamping table - Feed + rapid traverse in all axes Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: excellent (used), Catalog number 8133 Dcedpfx Ao Afdbdjk Aep TECHNICAL DATA - Number of working spindles: 2 - Spindles pneumatically pressed against the material - Spindle diameter: 30mm - 2 pneumatic clamps - Hydraulically adjustable feed - Pump motor: 1kW - Max milling height: 60mm - Max milling length: 1200mm - Max milling width: 180mm - Motors: 2 x 2.6kW - Diameter of dust extraction nozzle: 2 x 80mm - Dimensions (L/W/H): 2650x800x1420mm - Weight: 760kg ADVANTAGES - Hydraulically adjustable carriage - Milling heads included, 2 pieces - Used milling machine, very good condition Net price: 9900 PLN Net price: 2302 EUR, depending on the exchange rate of 4.30 EUR (Prices may vary due to significant fluctuations)

Condition: used, Year of construction: 2004, CNC turning and milling center with C-axis and Y-axis, 2 turrets, and subspindle. Technical details turning diameter 210 mm turning length 700 mm control Okuma OSP-E 100 L total power requirement 35,7 kVA weight of the machine ca. 7,1 t dimensions of the machine ca. 2660 x 2000 x 2330* mm CNC control: Okuma OSP-E 100 L Maximum turning diameter: 210 mm Swing over bed: 400 mm Distance between spindle noses: 960 mm Main spindle: Spindle bore: 53 mm Speed range: 50 to 6000 rpm Motor power: 11/7.5 kW Subspindle: Dcjdpjzzwmuefx Ak Ajp Spindle nose: JIS A2-6 Speed range: 38 to 5000 rpm Motor power: 11/7.5 kW Z-axis: Travel: 700 / 700 mm (ZA + ZB) Rapid traverse: 40000 mm/min W-axis: Travel: 940 mm Rapid traverse: 40000 mm/min X-axis: Travel: 167 / 192 mm (XA + XB) Rapid traverse: 30000 mm/min Y-axis: Travel: 92 mm (+50/-42 mm) Rapid traverse: 15000 mm/min C-axis: Indexing: 360 x 0.001 deg. Rapid traverse: 400 rpm Disc turret: 2 x 12 stations Tool holder mount: VDI 30 mm Power of driven tools: 4 kW Total connected load: 35.7 kVA Machine weight: 7100 kg Machine dimensions: 2660 x 2000 x 2330 mm* Plus swarf conveyor and bar loader Accessories FMB Turbo 5-42/6200/A bar loader, year of manufacture 2005 Chip conveyor Coolant system Collet chuck for main and subspindle Both turrets equipped with tool holders Machine documentation.

Condition: used, Year of construction: 2009, controller manufacturer: Fanuc, controller model: 30i (MSX-711), _____ Description: Year of manuf. : 2009 Control : Fanuc 30i (MSX-711) Turning diam. : 920 mm Turning length : 1800 mm In General: Year of manufacture:2009 Control system:Fanuc 30i (MSX-711) Dcodps Ad Uhrjfx Ak Aop Max. turning diameter:920 (470) mm Turning length:1,800 mm Bar capacity:103 mm Milling spindle:8,000 rpm, HSK 100 Main spindle: RPM:2,400 Max. power:37 kW Max. torque:1,432 Nm C-axis:0.001° Chuck:SMW Autoblok KNCS 500-155 Sub spindle: RPM:2,400 Max. power:37 kW Max. torque:1,432 Nm C-axis:0.001° Chuck:SMW Autoblok KNCS 500-155 Tool carrier I (X/Y/Z/B): Technology:Traveling column with milling spindle Milling spindle:8,000 rpm Power:30 kW Torque:302 Nm Tool holder:HSK 100 X-axis:1,040 mm Y-axis:510 (+/- 255 mm) mm Z-axis:1,940 mm B-axis:+/- 120°, index 1° Tool carrier II (X/Z): Technology:Cross slide with tool turret Tool drive:6,000 rpm, 40 Nm Number of stations:10 X-axis:267 mm Z-axis:1,830 mm Tool magazine: Technology:Chain magazine Tool changer:Double gripper Number of stations:80 Max. tool diameter:120 mm (250) Max. tool length:600 mm Equipment: Chip Removal:Chip Conveyor Coolant Supply:High pressure pumps Workpiece Measurement:Renishaw RMP 60 Emulsion Mist Separator:Electrostatic Setup:Electronic Handwheel Chuck:2x SMW Autoblock KNCS 500-155

Condition: new, Year of construction: 2026, Firebox output: 175 kW Operating output: 140 kW Flue diameter: 200 mm Warm air duct: 1 x 500 mm Firebox length: 950 mm Firebox width: 600 mm Firebox height: 860 mm Air flow rate: 8900 m³/h Power consumption: 3500 W Designed for room volume: 3000 m³ Area to be heated: 500/600 m² Oven height without warm air ducts: 2200 mm Oven width: 930 mm Oven length without flue gas fan: 1700 mm Dcodpoi Hplrefx Ak Asp Weight: 615 kg

Condition: good (used), Year of construction: 1990, 1 used, well-maintained CNC tool milling machine, traveling column design, with CNC path control GRUNDIG Dialog 11 Table size 1600 x 675 mm Tool holder SK / ISO 40 Travel distances X-axis, longitudinal 1200 mm Y-axis, transverse 600 mm Z-axis, vertical 500 mm Table load 2000 kg Spindle speed range 20 – 6300 rpm Feed rate range, stepless 2 – 10,000 mm/min Rapid traverse in all axes 10 m/min Quill stroke 80 mm Drive power 100% ED 7.5 kW 40% ED 12 kW Machine dimensions L x W x H 3600 x 3000 x 2300 mm Machine weight 6800 kg Control cabinet dimensions L x W x H 1700 x 900 x 1750 mm Control cabinet weight 470 kg Accessories / Special features: • CNC tool milling machine suitable for tool and fixture manufacturing, training, and mold making • CNC path control GRUNDIG Dialog 11 • Screen graphics, dialog-guided input, 3D linear interpolation, circular interpolation, helical interpolation, polar coordinate input, numerous drilling and milling cycles, cycle input graphically supported, milling cycles "contour pocket" for automatic free milling of irregular pockets, even with islands, shifting and rotation of the coordinate system • Electronic handwheel • RS 232 interface • Swiveling vertical milling head +/- 90° • Hydraulic tool clamping, DIN 2080 with clamping groove, Ott system • Quill adjustment 80 mm • Horizontal milling attachment • Full protection enclosure • Ball screw spindles in all 3 axes • Coolant system • Lighting Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 Dedjhhuf Hjpfx Ak Ajcp D - 44143 Dortmund - Wambel

Condition: good (used), Main spindle with drive motor, universal milling head, milling holder, milling extension, angle milling head, upper support, upper slide, dovetail guide, tool slide, cross table Dedpfx Ajrc Ik Hsk Aecp -Manufacturer: Mikron, upper support tool slide from CNC milling machine Mikron UME 600 -Motor: Siemens 380V 3.7/5.25 kW see photo nameplate -Speed: 1500/9000 rpm -Spindle head: SK40 mount -Dimensions: 1550/560/H735 mm -Weight: 555 kg
