Used Hermle C 40 U for sale (145)

Condition: reconditioned (used), Year of construction: 2016, CNC Vertical Machining Center HERMLE C 400 U With Heidenhain TNC 640 CNC Control Year of manufacture: 09/2016 Travel distances: X 850 Y 700 Z 500 mm Spindle speed range: 20 – 18,000 rpm, stepless Including the following accessories: - NC rotary swivel table Ø 650 mm x 540 mm (T-slots for SRT) - Vertical tool changer with 38 magazine slots (HSK 63) - Additional magazine with 50 magazine positions (ZM 50) - Through-spindle coolant supply 40 bar with paper band filter - Scale air purging - Fine filter for through-spindle coolant supply 40 bar - Scraper belt conveyor - Chip cart 450 liters - Coolant unit - Air blow-off unit - Spindle center compressed air - Manual cabin door, manual cabin roof - Polycarbonate safety windows - Electronic thermal compensation - Electronic handwheel - BLUM tool breakage/control & measurement A2 - Heidenhain 3D touch probe - Chip rinsing pistol Bwodpfxew Ewmfs Aftei - Oil mist extraction unit - Control cabinet cooling device (RITTAL) - 4 adjustable machine feet - Operating manuals

Condition: ready for operation (used), Year of construction: 2014, operating hours: 4,890 h, spindle speed (max.): 18,000 rpm, overall weight: 10,500 kg, controller manufacturer: HEIDENHAIN, controller model: 530, number of axes: 5, Universal machining centre manufactured in 2014. This 5 axis HERMLE C 400 U features a high-pressure IKZ, laser measuring system, and a 35-tool magazine. With a spindle speed of 18,000 rpm and a net weight of 10,500 kg, it offers robust capabilities for various machining tasks. Consider the opportunity to buy this HERMLE C 400 U universal machining centre. Contact us for further details. Bedpfx Afoyhp T Ijtjwi • Tool magazine: 36 tools (large drum/barrel type) • High-pressure through-spindle coolant (IKZ) • Laser measuring system • Spindle hours: 4,890 h • Operating hours: 5,800 h • Supply voltage: 400 V / 3~ • Mains frequency: 50 Hz • Control voltage: 24 V • Rated current: 55 A • Power consumption: 34 kVA • IKZ with paper belt filter and 80 bar • Tool measurement length and break A2 • Rotary Table 650mm Additional equipment • Suction (mist extraction) • 3D measuring probe Technical Specification Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 2008, operating hours: 27,167 h, functionality: fully functional, Technical Data – HERMLE C 40 UP Control System: - Heidenhain iTNC 530 - Travel X/Y/Z: 850/700/500 mm Bjdpfx Afoxx Rxrstjwi Options: - Heidenhain DNC - DXF Import - Kinematic Opt iTNC Main Spindle: - Speed: 18,000 rpm - Tool Holder: HSK-A63 Tool Magazine: - Additional Magazine ZM43 Feed / Axes: - Linear guideways – Dynamic Version - Table variant: NC-SRT Ø 420 mm, worm gear drive - Table axis: A-axis offset from center - Table specification: Pallet clamping system Coolant System: - Internal coolant supply 80 bar - Coolant filter type: Paper band filter for internal coolant system Chip Disposal: - Scraper belt conveyor Cab / Safety: - Base structure - Automatic cabin door - Manual roof cover - Laminated safety glass window Electrics: - Frequency: 50 Hz - Country key: DE Pallet Automation: - Pallet changer: PW160, 400 × 400 mm - Pallet storage MMS / Measuring Systems: - External MQL (Minimum Quantity Lubrication) - Tool breakage monitoring A2 Blum - Heidenhain touch probe - Prepared for additional touch probe Software / Options: - Event Messenger - Tool identification HSK - Machine license: TCS-Soflex - System monitoring Free Accessories: - Electronic thermal compensation - Electronic hand-held control module - Oil mist extraction (prepared & with post filter) - Flange for oil mist extraction - Sealing air for scales - Chip washdown gun - Bed flushing - Internal & external air blast - Signal light - Test documentation - Test protocol: C 40 iTNC 530 PW160

Condition: excellent (used), Year of construction: 1998, x-travel 800 mm y-travel 600 mm Bwodpfxox Dndco Aftei z-travel 500 mm

Condition: ready for operation (used), Year of construction: 2003, Make: HERMLE Type of machine: C 800 U Year of manufacture: 2003 Control system: Siemens 840D Machine's weight: 9.000,- Tool holder: SK40 x-travel: 800 mm Bwedpfjtmtxmjx Aftji y-travel: 600 mm z-travel: 500 mm Speed range: 16.000 min-1 Number of tools in the magazine: 80 Pl.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, table width: 540 mm, table length: 540 mm, rotational speed (max.): 8,000 rpm, CNC Control: Heidenhain TNC 426 WORKING AREA: X – Y – Z Travels: mm 800 – 600 – 500 FEED RATES: Feed force: N 8,000 Rapid traverse: m/min 30 Acceleration: m/s² 5 MAIN SPINDLE: Power (40% ED): kW 15 Torque (40% ED): Nm 130 Taper: SK 40 Speed range: rpm 20 – 8,000 Bsdpfx Aoyq S Dzeftjwi TOOL CHANGER: Tool magazine capacity: 30 positions Maximum tool diameter: mm 80 With adjacent pockets free: mm 125 Maximum tool length: mm 300 Maximum tool weight: kg 8 NC TILTING ROTARY TABLE: Clamping surface dimensions: mm 540 × 540 Maximum table load: kg 300 A-axis tilting range: -20° / +90° C-axis rotation range: 360°

Condition: excellent (used), HERMLE C 42 U is a 2 x 5‑axis machining centres with loading robot, engineered for high precision and reliability. Table 400×400 mm, table load 450 kg, travels X800 Y800 Z550 mm, A ±130°. Spindle HSK‑A63 0–18,000 rpm, 42 kW, 148 Nm; rapid 45/45/40 m/min. Tool magazines 42+160, 54 pallets, KUKA robot, coolant 80 bar, Renishaw/BLUM. Suited for tight tolerances in automotive, aerospace, watchmaking, medical. Bwodpfxsx S I Akj Aftoi

Condition: good (used), Year of construction: 2000, functionality: fully functional, Machine parameters: Travels in X, Y, Z axes: 650X450X450 mm Bedpfoyg R S Asx Aftewi Description: The machine is in good technical condition; test runs are possible by prior arrangement. HSK 63. Heidenhain 426/430. - The current condition corresponds to the machine's age, and there are currently no issues. X-axis ball screw was replaced on 5.1.2022. Hydraulics were overhauled on 25.4.2024. - Spindle hours: 41,273, machine hours: 89,892 - Number of axes: 5. Video of the machine available on request.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 18,396 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain 530, number of axes: 3, In 2022, the tool magazine door was replaced. In 2023, the SIMODRIVE 611/18A servo converter was replaced! TECHNICAL DETAILS Travel X-axis: 650 mm Travel Y-axis: 450 mm Travel Z-axis: 450 mm Tool holder: SK 40 Number of axes: 3 MACHINE DETAILS Control: Heidenhain 530 Bsdpfx Afsx Up E Eetswi Operating hours Spindle hours: 18,396 Machine hours: 56,040

Condition: excellent (used), Year of construction: 1998, Heidenhain TNC 426 control Bwjdpfxowhrfzs Aftei Travel X/Y/Z: 600/450/450 mm Spindle speed 10,000 rpm Tool magazine for 30 tools, SK 40

Condition: used, Year of construction: 2013, x-travel 450 mm y-travel 600 mm z-travel 330 mm control iTNC 530 HSCI Heidenhain turning speeds max. 18.000 min/-1 power capacity - main spindel 31 / 17 kW max. Torque 98 / 54 Nm tool taper HSK A63 rotary table dia. 320 mm Swivel range A: +/- 135 ° rotatable C: 360 ° max. table load 300 kg Number of revolutions A: 25 / C: 40 rpm T-slots 4x 14H7 number of toolpositions 55 pos. tool taper HSK A63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 8,0 kg max. total weight 220 kg change-time chip to chip 4,5 sec Accelaration 8 m/sec² Feed force 4,5 kN rapid traverse ( X / Y / Z ) 30 m/min total power requirement 40 kVA weight of the machine ca. 9,0 t dimensions of the machine ca. 6,5 x 6,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 22 U - Good condition! - Linear axes XYZ and drives renewed - new spindle Q1/2024 Bwsdpfx Aot Syf Ujftji - Optional: Internal coolant supply retrofitting possible (by Hermle, for an additional charge) - Additional container with paper belt filter incl. level monitoring - Conversion of coolant lubricant tank (lifting pump incl. level monitoring)

Year of construction: 2002, condition: excellent (used), HERMLE C 800 U CNC machining center Accessories incl.: among others: 3D touch probe, tool holder set, various clamping devices, chip tray, hydr. aggregate, double back-up Bedpsmqk E Tofx Aftswi Technical Data speed: 0- 18`000 rpm spindle nose: HSK-A63 Feeding speed: 1-35 m/min feed force: 8000 N X-axis: 800 mm Y-axis: 600 mm Z-axis: 500 mm dimensions of the machine: 2700 x 2210 x 2930 mm Weight: 8500 kg No responsibility is taken for the accuracy, completeness and timeliness of the information.

Condition: used, Year of construction: 2013, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t dimensions of the machine ca. 15 x 7,5 x 3,5 m Bodpfx Asuyl Tbsftswi 5 Axis - CNC Machining Center Universal HERMLE - C 30 U Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Automatic cabin door Rotating transparent window - incl. 32x HSK 63 holders - incl. 10x collets Also available as a production cell (2x Hermle C 30 U + Kuka Automation)

Condition: used, Year of construction: 2014, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t dimensions of the machine ca. 15 x 7,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 30 U Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Bwodpfx Ajuyl Thoftji Automatic cabin door Rotating transparent window - incl. 32x HSK 63 holders - incl. 10x collets Also available as a production cell (2x Hermle C 30 U + Kuka Automation)

Condition: used, Year of construction: 2013, x-travel 650 mm y-travel 600 mm z-travel 500 mm Control iTNC 530 Heidenhain turning speeds 18.000 U/min power capacity - main spindel 10 / 15 kW tool taper HSK A 63 rotary table dia. 630 mm center bore 32 H7 Swivel range A: ° rotatable C: 360 ° max. table load 1.000 kg number of toolpositions 32 pos. tool taper HSK A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg Bsdpfx Afeuwv Dljtjwi rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8.500 N total power requirement 43 kVA weight of the machine ca. 9,5 t dimensions of the machine ca. 15 x 7,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 30 U - 2x Hermle C 30 U Linear axes dynamic version 6-fold rotary union Blown air through the center of the spindle Automatic cabin door Rotating transparent window - 1x Kuka KR 180 R2900 prime 6 axes Load capacity: 180 kg Reach: 2,896 mm 66x spaces for workpiece pallets 2x changing places 1x turning station 8x gripper spaces - incl. 1x Schunk gripper - incl. 66x workpiece pallets - incl. 64x HSK 63 holders - incl. 20x collets Also available as a single machine Hermle C 30 U.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 48,702 h, functionality: fully functional, machine/vehicle number: 16261, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller model: Siemens Sinumerik 840 D pl , spindle speed (max.): 28,000 rpm, TECHNICAL DETAILS Travel Paths X-axis travel: 650 mm Y-axis travel: 600 mm Z-axis travel: 500 mm Main Spindle Spindle speed range: 20 – 28,000 rpm Spindle drive power: 23 / 18 kW Max. torque: 79 Nm Tool taper: HSK-A63 NC Rotary Swivel Table Clamping surface: Ø 630 mm Swivel range A: +30° / -115° Rotatable C: 360° Max. table load: 500 kg Max. workpiece dimensions: Ø 630 x 313 mm Table rotation speed A: 25 / C: 65 rpm Tool Changer Number of tool stations: 117 Max. tool diameter: 90 mm Max. tool length: 300 mm Feed Rates Rapid traverse (X / Y / Z): 60 m/min Acceleration: 10 m/s² Feed force: 8.5 kN MACHINE DETAILS Control: Siemens Sinumerik 840 D pl Space Requirement & Weight Required space approx.: 8.5 x 5.5 x 3.0 m Machine weight approx.: 10,500 kg Total power requirement: 43 kVA Bwodpfx Afsxbz A Hstoi Operating hours: 48,702 h EQUIPMENT - Documentation - High-pressure cooling - Coolant system - Internal coolant supply: 80 bar / 1,300 l - Electronic handwheel - Fully enclosed cabin - FASTEMS pallet pool / 15 positions - Chip conveyor - Paper band filter - Renishaw probe - Tool breakage monitoring Note: Transport lifting gear must be provided by the buyer. The pallet system cannot be observed under power. The Fastems controller is defective.

Condition: ready for operation (used), Year of construction: 2007, operating hours: 14,000 h, spindle speed (max.): 18,000 rpm, overall weight: 10,500 kg, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, controller manufacturer: SIEMENS, controller model: 840 D, number of axes: 5, This 5-axis HERMLE C40U universal machining centre was manufactured in 2007. It features a travel of 850 mm in the X-axis, 700 mm in the Y-axis, and 500 mm in the Z-axis, with a rapid traverse of 45 m/min. The machine is equipped with a spindle speed of 18,000 rpm and a tool changer with 38 positions. If you are looking to get high-quality machining capabilities, consider the HERMLE C40U machine we have for sale. Contact us for further details. • Operating voltage: 400 V / 3~ • Mains frequency: 50 Hz • Control voltage: 24 V • Total power: 41 kVA • Total nominal current: 60 A • Master circuit diagram: 1-322-MS-96-002 • Rapid traverse: 45 m/min • Tool changer: 38 positions • Axis configuration: 5-axis • Linear axes: X, Y, Z • Rotary axes: A-axis (off-centre), C-axis (NC swivel rotary table Ø420 mm) • NC swivel rotary table: Ø420 mm • Internal coolant supply (IKZ): 80 bar • Laser tool measurement / breakage monitoring • Measuring probe: Heidenhain • Electronic handwheel • Electronic thermal compensation • Spindle hours: approx. 14,000 h (spindle replaced 11.2017) • Accessories: Without tools, tool holders and zero-point clamping systems Additional equipment • Paper band filter • Chip conveyor • Chip flushing gun • Oil mist extraction Bsdpfxoyly A Io Aftewi Technical Specification Taper Size HSK 63

Condition: good (used), Year of construction: 2003, For technical data, see images.... Bwedpfx Afsx R S R Nstei

Condition: used, Year of construction: 2010, USED MACHINING CENTER HERMLE MODEL C 40 UP Year of manufacture: 2010 Control unit: HEIDENHAIN iTNC 530 Travel: X 850 mm, Y 700 mm, Z 500 mm Linear axes (X-Y-Z): Dynamic version Milling spindle: 18,000 rpm Spindle taper: HSK-A63 Tool magazine with 38 positions NC tilting rotary table, diameter 800 mm for PALLET CHANGER C axis with torque motor, A axis with tandem drive includes pallet clamping system, hydraulic and pneumatic extension, bed wash, automatic opening/closing cabin door (Load capacity 1,400 kg) Pallet changer device PW 800 for SRT 800 PW - 630 x 630 Load capacity: 800 kg Rotating load/unload station for PW 800 Additional control for clamping system operation for PW 800 Bwjdoxvq Iuspfx Aftei Internal coolant supply 80 bar including: Paper filter, Standard coolant system, Linear scale pressurization, bed wash Chip conveyor Air blow cleaning device Manually opening/closing cabin cover Polycarbonate safety windows HEIDENHAIN thermal compensation Electronic handwheel Renishaw touch probe incl. pre-arrangement Laser system – Blum Chip cleaning gun Signal lamp 2 pallets 630x630 mm Additional articulated arm

Condition: used, Year of construction: 2004, x-travel 650 mm y-travel 600 mm z-travel 500 mm control Sinumerik 840 D pl Siemens turning speed range - main spindle 20 - 28.000 min/-1 power capacity - main spindel 23 / 18 kW max. Torque 79 Nm tool taper HSK-A63 table surface area Ø 630 mm Swivel range A: +30° / -115 ° rotatable C: 360 ° max. table load 500 kg max. workpiece sizes Ø 630 x 313 mm table speed A:25 / C:65 min/-1 number of toolpositions 117 pos. max. tool diameter 90 (125) mm Bwedpfx Aexmagzoftoi max. tool length 300 mm rapid traverse ( X / Y / Z ) 60 m/min Accelaration 10 m/s² feed power 8,5 kN total power requirement 43 kVA weight of the machine ca. 10,5 t dimensions of the machine ca. 8,5 x 5,5 x 3,0 m 5 Axis CNC - Machining Center Universal HERMLE - C 30 UP Dynamic - FASTEMS - incl. FASTEMS FPC-400 Pallet-System / 15-pos. - palletchanger - Tool-Magazine 117 pos. - ca. 9.000h Spindle-hrs. after change - FASTEMS Computer is not working

Condition: excellent (used), Year of construction: 2007, operating hours: 36,900 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: Heidenhain, controller model: 530, spindle speed (max.): 28,000 rpm, 5-Axis Machining Center Manufacturer: Hermle Model: C30U Year of manufacture: 2007 Control: Heidenhain iTNC-530 Power-on hours: approx. 36,900 h Program run hours: approx. 10,760 h S/N: XXXXX Technical Specifications: ----- • Travel X-Y-Z: 650 x 600 x 500 mm • C-axis: 360° • A-axis: +/-115° • Swiveling rotary table Ø280 mm • 6x rotary feedthrough • Spindle speed: 28,000 rpm • Magazine: 32x HSK-A63 • Standard coolant system • 3D probe Renishaw • Laser bridge for tool measurement • Option: Blowing air through spindle • Option: Glass scales with purge air • Option: Electronic thermal compensation • Chip tray • Weight: 9,500 kg Accessories: ----- • Documentation • Rinsing gun • Handwheel • Holder package with 20x HSK-A63 tool holders Bwodpfx Afeynb S Netji

Condition: ready for operation (used), Year of construction: 2003, operating hours: 27,804 h, functionality: fully functional, machine/vehicle number: 16165, travel distance X-axis: 915 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: HEIDENHAIN iTNC 530, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 915 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Number of axes: 5 Maximum spindle speed: 12,000 rpm Table length: 900 mm Table width: 500 mm Number of T-slots: 8 T-slot spacing: 65 mm T-slot width: 14 mm Maximum workpiece weight on table: 700 kg Maximum workpiece length: 900 mm Maximum workpiece width: 500 mm Maximum workpiece height: 500 mm Bedpfx Afoyhnudstswi Number of tools: 16 Maximum tool diameter: 125 mm Diameter with adjacent pockets empty: 180 mm Maximum tool length: 300 mm Maximum tool weight: 6 kg Tool holder: SK 40 Milling head swiveling range: -5° to +95° Rapid traverse: Longitudinal: 30 m/min Cross: 30 m/min Vertical: 20 m/min MACHINE SPECIFICATIONS Compressed air connection: 6 bar Electrical connection: 50 Hz, 3 x 400 Volt Spindle drive power: 32 kW Total power requirement: 26 kVA Noise level: 78 dB (A) Dimensions & Weight Dimensions (L x W x H): 2,760 x 2,390 x 2,370 mm Machine weight: approx. 7,300 kg Operating Hours Power-on time: 86,672 h Operating time: 34,362 h Spindle run time: 27,804 h EQUIPMENT 3-jaw chuck Ø 200 mm Workpiece probe HEIDENHAIN TS 640 Rotary table 4th axis HOFMANN type RW/NC-160 Rinsing gun RS 232 interface Ethernet interface Electrical cabinet air conditioning unit

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Heidenhain, controller model: TNC430, rotary table diameter: 540 mm, spindle speed (max.): 16,000 rpm, operating hours of spindle: 32,000 h, spindle nose: HSK63, number of slots in tool magazine: 30, Equipment: rotational speed infinitely variable, Very well-maintained HERMLE C800-U. Swiveling rotary table: 540 x 540mm Program runtime only approx. 34,000 hours. Field of application: Toolmaking Bwjdpfx Afjx Hg E Tjtei Service carried out by the manufacturer. Last spindle head replacement: 04/2017 New A-axis drive Heidenhain iR probe

Condition: good (used), Year of construction: 2008, functionality: fully functional, operating hours: 121,665 h, travel distance X-axis: 650 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, overall weight: 9,500 kg, controller model: Heidenhain iTNC530, coolant supply: 40 bar, rapid traverse Z-axis: 60,000 m/min, rapid traverse X-axis: 60,000 m/min, rapid traverse Y-axis: 60,000 m/min, rotary table diameter: 280 mm, rotational speed (max.): 18,000 rpm, operating hours of spindle: 59,846 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Heidenhain iTNC 530 Spindle HSK63 18,000 rpm (new spindle 08/2024) 32 tool positions plus additional magazine ZM157 Rotary table SRT 280 mm worm drive 6-way rotary union on the table for zero-point clamping system External coolant supply Bwjdpfx Afjyc Nkpotji Chip flushing pistol Oil mist extraction Internal coolant supply 40 bar Automatic cabin door Blow-off device Chip conveyor Handwheel Thermal compensation Renishaw probe Kinematic option Preparation for BLUM tool measurement fork version Preparation for PCS order management Interface for robot RS2 (we currently have a suitable RS2 robot with control system and pallets available in a current auction) Machine ON: 121,665 h Spindle ON: 59,846 h (new spindle 08/2024) Very well-maintained condition

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller manufacturer: Heidenhain, controller model: 530, rotary table diameter: 280 mm, spindle speed (max.): 16,000 rpm, 5-axis machining center Manufacturer: Hermle Model: C20U Year of manufacture: 2006 Control: Heidenhain iTNC-530 Power-on hours: approx. 48,000 h Spindle hours: approx. 20,500 h Serial number: XXXXX Technical specifications: ----- • Travel (X-Y-Z): 600 x 450 x 450 mm • C-axis: 360° • A-axis: +/-115° • Swivelling rotary table Ø280 mm • Spindle: 16,000 rpm • Magazine: 30x SK-40 • Additional magazine with 43 stations • Standard coolant system • Air blast through spindle + blow-off device • Blum laser for tool breakage detection and measurement • Renishaw 3D probe • Electrical thermal compensation • Sealing air for glass scales • Chip conveyor Bedpfx Aswqnnkeftewi Accessories: ----- • Documentation • Rinsing gun • Handwheel • Maintenance history
