Used Plan Lathe for sale (9,303)

Condition: good (used), Year of construction: 2011, Swing 806mm, maximum cutting diameter 533mm, 762mm between centres, 660mm maximum cutting length, 76mm Bar capacity, 254mm 3 jaw chuck, 22.4kW Spindle Motor, 3400rpm spindle, Cgedpjywuvhjfx Ab Uor 12 Station turret, tailstock, coolant, tool setter.

Condition: excellent (used), Year of construction: 2020, Maximum turning diameter 550mm, swing over bed 950mm, Swing over cross-slide 715mm, spindle speed 3,500rpm, Y axis +80/-60mm, distance between centres 898mm, milling speed 12,000 rpm, main spindle bar capacity 78mm, 16 station turret, Codpfx Asywuibob Ujgr spindle power 40/25Kw, Fanuc I series control, 3 jaw chuck main, tool setter, swarf conveyor,

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. Cgedpfx Ajyykxwob Usr As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: good (used), Year of construction: 1956, Heavy-duty lathe, lathe, lead screw lathe, lead screw lathe Cedpfx Ajh Uuzyjb Usgr -Manufacturer: Meuser, lead screw and feed screw lathe type M3A -Turning length: 1400 mm -Turning diameter over bed: 550 mm -Turning diameter without bed: 800 mm -Turning diameter over support: 300 mm -Spindle bore: Ø 58 mm -Spindle speeds: 15 - 810 rpm -Three-jaw chuck: Röhm Ø 250 mm -Faceplate: 500 mm -Accessories: incl. tool holder/tools (see photos) -Tailstock mount: MK5 -Dimensions: 2770/1160/H1310 mm

Condition: used, Year of construction: 1974, functionality: fully functional, Lead and feed screw lathe Make: Heidenreich & Harbeck Model M530K Year: 1974 Technical Data Cjdpfx Aboyyk Raj Ujgr Manufacturer: Heidenreich & Harbeck Model: M530K Year of manufacture: 1974 Control: Conventional Centre distance: 2000 mm Swing over bed: 530 mm Swing over cross slide: 280 mm Spindle bore: 70 mm Spindle speed: 9 - 1800 rpm Dimensions (L x W x H): 4.05 x 1.50 x 1.40 m Machine weight: approx. 4 t Equipment - Röhm 3-jaw chuck, D 250 mm - 1 fixed steady rest - Removable gap bed over 400 mm length - 2-axis digital readout - 1 drill chuck - Coolant pump All data subject to change without notice. A powered demonstration is possible at any time in our showroom.

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Equipment: rotational speed infinitely variable, Citizen M32-2M3 CNC Swiss-type Turning Machine Year of manufacture: 2002 Control: Mitsubishi Meldas 635 Max machining diameter: 32 mm Cedpfox Dncfox Ab Usgr 7 controlled servo axes: X1/Z1/Y1/X2/Z2/X3/Z3 4 driven tools on the vertical holder C-axis: main and sub spindle Including accessories: FMB Turbo 5-42 bar feeder Extraction system Parts conveyor 5 driven tools for turret 5 standard holders (turning/boring holders) for turret - Available immediately -

Condition: good (used), Year of construction: 2004, functionality: fully functional, Equipment: rotational speed infinitely variable, Citizen C16-VII CNC Swiss Lathe Year of manufacture: 2004 Control: Mitsubishi Meldas 635 Max. machining diameter: 16 mm C-axis: Main and sub-spindle 5 controllable servo axes: X1/Z1/Y1/X2/Z3 4 driven tools on the vertical holder Cgsdpfev Rhd Hox Ab Uor C-axis: Main and sub-spindle Includes accessories: LNS Express 220 loading magazine, 16 mm and 10 mm conversion kit Donaldson Torit extraction system Chip conveyor - Available immediately -

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Equipment: rotational speed infinitely variable, Citizen R07-VI CNC Swiss-type lathe Year of construction 2015, in very good condition, annual maintenance has been carried out every year since new 2 identical machines are available, both ready for immediate delivery Cgodsyk Iv Tepfx Ab Ujr Control: Fanuc Max. machining diameter: 7mm Number of servo axes: 6 Z1/X1/Y1/X2/Y2/Z2 Number of C-axes: 2 main and sub-spindle Number of tool positions: 5x turning tool holders / 2x driven tool positions / 3x drilling stations front and rear Including accessories: Iemca Elite 112 EVO bar feeder Büchele SFB-100 high-pressure unit Kraft und Bauer fire extinguishing system

Condition: excellent (used), Year of construction: 2005, operating hours: 5,423 h, turning length: 510 mm, turning diameter: 356 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 590 mm, spindle motor power: 15,000 W, total height: 2,230 mm, total length: 3,495 mm, total width: 2,050 mm, overall weight: 5,800 kg, CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 520 C-axis: 360º (0.001°) Turning length mm: 515 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Counter spindle Counter spindle travel mm: 525 Equipment Chip conveyor Signal lamp Tool measuring arm Workarea light Working time hours Under power: 7.456 Cutting Time: 5.423 Basic machine dimensions / weight Length mm: 3.495 Width mm: 2.050 Csdsui Ndbepfx Ab Ujgr Height mm: 2.230 Weight kg: 5.800

Condition: reconditioned (used), Year of construction: 2012, functionality: fully functional, MAZAK QUICK TURN NEXUS 250-II MY Max. turning diameter: 380 mm Max. machining length: 504 mm Max. milling speed: 4,500 rpm Max. spindle speed: 4,000 rpm Max. bar diameter: 74 mm Machine is equipped with: - CNC control Mazatrol Matrix Nexus 2 - KITAGAWA three-jaw chuck B-210, diameter 254 mm - Tool Eye - C-axis - Y-axis - automatic parts catcher - NC tailstock - reinforced coolant pump Cgodpfxjyy Ad Ee Ab Uor - MAYFRAN chip conveyor - 8 fixed tool holders - 2 driven tool holders

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, X-axis travel: 140 mm Y-axis travel: +/- 40 mm Z-axis travel (1+2): 450 / 410 mm Turning length: 750 mm Turning diameter over cross slide: 250 mm Turning diameter: 190 mm Distance between centres: 750 mm Max. bar diameter: 52 mm Spindle speed (max.): 4,000 rpm Main spindle speed range: 60 - 6,000 rpm Drive power - main spindle: 22 / 18.5 kW Max. torque: 198 Nm Counter spindle B-axis travel: 525 mm Feeds Feed rate X (1+2): 18,000 mm/min Feed rate Y: 6,000 mm/min Feed rate Z (1+2): 24,000 mm/min Feed rate B: 24,000 mm/min Number of turrets: 2 Number of tool stations: 2x 16 pos. Shank height for square tool: 20 mm Shank diameter for drills: 25 mm Turret indexing time: 0.2 s Tool holder: VDI 30 Speed range - driven tool stations (max.): 6,000 rpm Drive power - driven tool stations: 5.5 / 3.7 / 2.2 kW Rapid traverse X (1+2): 18 m/min Rapid traverse Y: 6 m/min Csdpfx Aoyyupmsb Uegr Rapid traverse Z (1+2): 24 m/min Rapid traverse B: 24 m/min Rapid traverse C: 400 rpm MACHINE DETAILS Control: MSX 501 Fanuc drives Machine is in excellent condition

Condition: used, Year of construction: 2018, Lathes Travel distance X: 221 mm Travel distance Y :100 mm Travel distance Z: 400 mm turning length: 380 mm max. circulation diameter: 280 mm spindle boring: 65 mm input Power: 11 kW max. turning moment: 80 NM Cgedpfx Aeyx T Huob Ujr range of revolution from: 100 rpm range of revolutions till: 4500 rpm Control: Fanuc 0i-TF Powered tools: 12 working hours approx: 813 h control Fanuc Scrapper chip conveyor

Condition: good (used), Year of construction: 2004, functionality: fully functional, Fanuc control, 16 mm spindle bore, sub-spindle, 3 driven radial tools, high-pressure pump, Cgedpoyyxqnefx Ab Usr fire extinguishing system, FMB bar feeder, extensive accessories.

Condition: good (used), Year of construction: 2005, functionality: fully functional, Fanuc control, spindle bore 26 mm, sub spindle, 4 driven tools (axial) for sub spindle, 3 driven tools (radial) for main spindle and sub spindle, FMB bar feeder, fire extinguishing system, Cjdoyyxkzspfx Ab Usgr high-pressure pump, lots of accessories.

Condition: excellent (used), CATALOG NUMBER 6901 TECHNICAL DATA - max turning length: 1200 mm - max turning diameter: 210 mm - max turning diameter with standard steady rest: 90 mm - max dimension of square material for turning with automatic feed: 100 mm - 3 hydraulic copy attachments - additional 3 tools on hydraulic pistons (2 pieces installed) - 4 spindle speeds - automatic or manual machine operation - spindle motor power: 9 kW - hydraulic pump motor power: 3 kW - extraction nozzle diameter: 90 mm - transport dimensions (L/W/H): 3700x2100x2000 mm - weight: approx. 3000 kg ADVANTAGES – Italian production – automatic hydraulic copy attachment – original technical documentation (DTR) – not repainted – used lathe, in very good condition Net price: 63,900 PLN Net price: 15,200 EUR Net price calculated at the rate 4.2 PLN/EUR Cgsdoyy Ngmspfx Ab Uer (In case of significant currency fluctuations, the price may change)

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Matador VS-2 Lead and Feed Screw Lathe with 3-Axis Digital Readout by K&C—NEW in Special Light Grey Paintwork!!! Technical Data: >> Machine No. 92-027, Year of manufacture: 1992 >> Centre height: 140 mm >> Distance between centres: 500 mm >> Spindle speeds: 15 – 3550 rpm >> Spindle bore: 36 mm >> Short Taper Spindle Nose DIN 55022-5 with bayonet lock >> Tailstock taper: MT 3 >> Feed rates: 0.012 to 0.9 mm/rev >> Thread cutting: Metric, Inch, Module, and Diametral Pitch >> Metric thread pitches: 0.25 to 12 mm Cgedeyylq Uspfx Ab Usr >> Weight: approx. 700 kg >> Length: 1.4 m, Height: 1.2 m, Depth: 0.55 m Accessories and Equipment: >> 3-axis digital readout by K&C, brand new, 12-month manufacturer’s warranty with operating manual Functions: mm/inch switching, coordinate selection ABS/INC, value halving, reference mark, tool programming for 200 tools, taper calculation, radius/diameter display, quick zeroing, count direction switching >> 1 piece 3-jaw chuck with 1 set of jaws >> 1 piece 4-jaw chuck with 1 set of jaws >> Electronic spindle protection >> Multifix size A with 2 tool holders >> Motor brake >> Bed stop About the machine: Offered here is a Weiler Matador VS-2 in very good condition. The machine is, of course, fully functional and has been freshly repainted in light grey. A very attractive machine. The 3-axis digital readout by K&C has been retrofitted. All measuring scales are new and fitted with protective covers to prevent contamination. The carriage movement is smooth and even throughout. Take the opportunity to view this machine under power on site and convince yourself of its condition.

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Matador VS-2 Lead and Feed Screw Lathe with 3-Axis Digital Readout by K&C - NEW - Special Light Grey Paint Finish!!! Technical Data: >> Machine no. 92-029 - Year of manufacture: 1992 >> Center height: 140 mm >> Center distance: 500 mm >> Spindle speed: 15 – 3550 rpm >> Spindle bore: 36 mm >> Short taper spindle nose DIN 55022-5 with bayonet lock >> Tailstock taper: MK 3 >> Feeds from 0.012 to 0.9 mm/rev >> Thread types: Metric, Imperial, Module, and Diametral Pitch >> Metric thread pitches from 0.25 to 12 mm >> Weight approx. 700 kg >> Length: 1.4 m, Height: 1.2 m, Depth: 0.55 m Accessories and Equipment: >> 3-axis digital readout by K&C, new, 12-month manufacturer's warranty, with operating manual Functions: Switching between mm/inch, ABS/INC coordinate selection, value halving, reference point, tool programming for up to 200 tools, taper calculation, radius/diameter display, quick zeroing, count direction switching >> 1 three-jaw chuck, 1 set of jaws >> 1 four-jaw chuck, 2 sets of jaws Csdpfx Aoyylqheb Uogr >> Electronic spindle protection >> Multifix size A with 2 tool holders >> Motor brake >> Bed stop About the machine: Offered here is a Weiler Matador VS-2 in very good condition. The machine is, of course, fully functional and has been newly painted in light grey. A very attractive machine. The 3-axis digital readout by K&C has been retrofitted. All scales are new and equipped with protective covers to shield them from dirt. The carriage runs smoothly and evenly. Take the opportunity to view this machine under power on site and see its condition for yourself.

Condition: excellent (used), Distance between points 1000mm Machinable Diameter on Baseplate 575 mm Diameter Machinable on Trolley 300 mm Longitudinal Bed Width 410 mm Machine Speed Range 20- 1600 rpm No. of speeds 16 speeds Head Pitch Ø 52 mm Tailstock shank Ø 70 mm Tailstock Stroke 220 mm Main engine power 12 H.P. Machine weight 2200kg Cgjdpevi Rviofx Ab Ujr Machine dimensions 3300 x 1300 x 1500 mm Machine rebuilt and painted in RAL 7031 color. Main motor winding 380-660V Second hand 315mm chuck Suitable to R.D. 1215/97 with national safety protections of tempered glass. Equipment certified by OCA Authorized Control Body. Instruction book

Condition: excellent (used), Brand: DMTG DALIAN Model: CKE 6180 Z Cnc : FAGOR 8055 iT Turning diameter : 800 mm Turning length: 2.000 mm Center height over bed: 400 mm Cedpfx Absu U Htcj Uegr Face slide travel: 420 mm Longitudinal travel : 1.835 mm Spindle bore: 100 mm Spindle speeds: 40-1000 rpm Feed in X : 0-4000 m/min Feed range Z direction : 0-8000 m/ min Turret : 4 estaciones Chuck diameter 4 jaw: 400 mm Quill stroke: 260 mm Voltage : 400 v Total power requirement: 18,5 kw Machine dimensions : 4.500 x 2.000 x 1.800 mm

Condition: excellent (used), Year of construction: 2009, Heidenhain digital display Working area Centre height: 310 mm Centre distance: 1625 mm Max. turning diameter in the gap: 880 mm Max. turning diameter over bed: 620 mm Turning diameter in front of the longitudinal carriage: 580 mm Turning diameter over cross slide: 425 mm Bed width: 350 mm Length of the gap in front of the faceplate: 200 mm Main spindle bore: 80 mm Spindle mounting: DIN 55027/8 Optional Camlock spindle mounting: DIN 55029/8 12 spindle speeds: 30 – 1500 rpm Cross slide travel: 365 mm Top slide travel: 165 mm Drive power: 5.5 kW Coolant pump motor power: 0.06 kW Cgodpfoyyv N Ujx Ab Uer Weight: 1805 kg

Condition: used, Year of construction: 2005, turning diameter 290 mm Cgedpfxjyb S Ihe Ab Uer turning length 300 mm control Heidenhain greates pass round over bed 380 mm total power requirement --- kW weight of the machine ca. --- t dimensions of the machine ca. --- m

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Matador VS-2 Lead and Feed Screw Lathe with 3-Axis Digital Readout by K&C NEW in Special Light Grey Finish!!! Technical Data: >> Machine No. 92-028 Year of manufacture: 1992 >> Centre height: 140 mm >> Centre distance: 500 mm >> Spindle speed: 15 – 3550 rpm >> Spindle bore: 36 mm >> Short taper spindle nose DIN 55022-5 with bayonet lock >> Tailstock MK 3 >> Feeds: 0.012 to 0.9 mm/rev Codsyyb T Sopfx Ab Ujgr >> Possible threads: Metric, Imperial, Module, and Diametral Pitch >> Metric thread pitches from 0.25 to 12 mm >> Weight approx. 700 kg >> Length 1.4 m, Height 1.2 m, Depth 0.55 m Accessories and Equipment: >> 3-axis digital readout by K&C, new, 12-month manufacturer warranty with operating manual Functions: Switchable mm/inch, coordinate selection ABS/INC, display value halving, reference point, tool programming for 200 tools, taper calculation, radius/diameter, quick zeroing, change of counting direction, >> 1 piece 3-jaw chuck, 1 set of jaws >> 1 piece 4-jaw chuck, 1 set of jaws >> Electronic spindle guard >> Multifix size A with 2 tool holders >> Motor brake >> Bed stop About the machine: Offered here is a Weiler Matador VS-2 in very good condition. The machine is, of course, fully functional and has been repainted in light grey. A very nice machine. The 3-axis digital readout from K&C has been retrofitted. All measuring scales are new and equipped with cover plates to protect them from dirt. The slides move freely and smoothly. Take the opportunity to inspect this machine under power on site and see its condition for yourself.

Condition: used, CATALOG NUMBER 7650 Technical data: - max working length: 1500 mm - max working diameter: 250 mm - milling (disc cutter): 7.5 kW - spindle – 2800 rpm 3 kW - spindle speeds: 700/1200/1500/2000 rpm - grinding unit: 0.75 kW - hydraulic motor: 3 kW - total power: 17.75 kW - air supply requirement: 6-8 bar - feeder for beams up to 150x150 mm - extraction port diameter: 100 mm, 160 mm - transport dimensions (L/W/H): 4350x2300x1980 mm - weight: approx. 3000 kg ADVANTAGES – German-made – automatic hydraulic duplicator – original DTR documentation – not repainted – used lathe, in very good condition Net price: 69,900 PLN Net price: 16,640 EUR Cgodpeyyyt Refx Ab Uor Net price calculated at an exchange rate of 4.2 PLN/EUR (in case of significant exchange rate fluctuations, the price may change)

Condition: used, Year of construction: 2009, Technical details: turning diameter: 270 -300 mm turning length: 710 mm total power requirement: 43 kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: 3,16 x 2,15 x 2,15 m Cjdpsw Dud Eefx Ab Ujgr The machine does not include a chuck or tools – the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one. *

Condition: used, Year of construction: 2008, Out of valve production Codpeynkgvsfx Ab Ujgr *
