Used Profiling Center for sale (17,523)

Condition: excellent (used), Year of construction: 2018, MORBIDELLI M100 CNC Machining Center Working Area X-Y: 3,110 x 1,320 mm Max. workpiece height above suction cups: Z180 mm Technical Data Working range X axis: 3,110 mm * Working range Y axis: 1,320 mm * Panel passage Y: 1,600 mm Panel passage Z: 180 mm Workpiece length for pendulum operation: 1,400 + 1,400 mm Travel speed of X-Y axes: PRO-SPACE: 56 m/min (184 ft/min) Travel speed of X-Y axes: PRO-SPEED: 78 m/min (256 ft/min) PRO-SPACE Safety Devices 1 Enables the machine to be installed without perimeter safety fencing, thereby reducing space requirements. The safety devices are mounted directly to the machine frame. Max. X-axis speed = 25 m/min. 63.03.73 "TECPAD wired" remote control with 7" touchscreen display Tool Changer TRB11 (configuration Y=1,320) Tool Changer FAST14 1 vacuum pump, capacity 250/300 m³/h at 50/60 Hz F31LTC drilling unit The F31LTC drilling head is equipped as follows: Connection for vertical and horizontal drills Ø 10 mm, WELDON type (max drill length = 70 mm) Distance between spindles: 32 mm 21 vertical spindles, selectable independently 5 horizontal drill heads with dual output (one on each side), 3 in X direction and 2 in Y direction Drill spindle speed: 4,500 rpm (with optional inverter 2,500–8,000 rpm) 1 integrated saw blade in X direction (max diameter 125 mm, thickness 2.2–6 mm) Saw blade speed: 5,500 rpm Drilling unit with inverter Pressure booster on the Z-axis 5-axis unit, version "JQX" 10 kW The 5-axis unit includes: HSK 63F tool holder with double reference surface for rigid connection between taper and electrospindle Standard electronic control of rotation speed from 1,800 to 24,000 rpm, with static inverter and quick stop function Continuous power (S1/S6): 8.5/10 kW (11.5/13.6 HP) from 12,000 rpm B-axis rotation: ± 185° B-axis rotation speed: 7,000°/min C-axis rotation: ± 320° C-axis rotation speed: 7,000°/min Right- and left-hand rotation programmable via NC Internal air blast to ensure optimal tool holder coupling Cooling system with circulating fluid and external heat exchanger Ceramic ball bearings on main spindle Internal pressurized air circuit to prevent contamination by dust Surrounding extraction hood for chip removal with pneumatic ON/OFF function Extraction hood for 5-axis electrospindle 6 "TV FLEX" worktables 1,300 Chip and waste conveyor belt for X=3,110 mm 4 loading aid devices H=75 1,300 Front stops H=75 for 6 supports Main front reference stop Vacuum suction cups 145x145 mm, H=75 mm – 12 pcs Vacuum suction cups 145x55 mm, H=75 mm, rotatable – 6 pcs Additional hardware dongle for Maestro CNC (for USB port) High-performance PC Location: ex works customer site - Immediately available - Hsdpfjx Nrwgex Agzsg System must be dismantled by the seller

Condition: like new (used), Year of construction: 2017, operating hours: 23,043 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 375 mm, controller manufacturer: Heidenhain TNC 640, workpiece weight (max.): 250 kg, spindle speed (min.): 20,000 rpm, spindle motor power: 35,000 W, Year of construction: 2017 CNC controller: Heidenhain TNC 640 Axes X-axis travel mm: 400 Y-axis travel mm: 400 Z-axis travel mm: 375 C-axis degrees: 360º (0,001) B-axis degrees: -5 / +110º Milling/turning table nc: Number of pallets: 30 places with robot Table dimensions mm: 450x400 Max. workpiece weight kg: 250 Spindle Spindle speed rpm: 20000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/86 Hsdpfx Asx Nhrajgzsg Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: HSK-A 63 Tool magazine slots: 60 Tool changer: Double gripper Equipment Chip conveyor Infrared probe Rinsing gun NC swivel rotary table Preparation for the use of the 3D quickSET Laser tool measurement for measuring tool length and diameter Direct measuring system XYZ Spindle active cooling unit MPC – Machine Protection Control Prepareted for automatation via M65 Paper band filter Machine running times Under power: 43989 Spindle Working: 23043

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Hjdpfsxy Tmzox Agzjg Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Location: Nattheim

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: G3169-0110, turning length: 530 mm, turning diameter: 420 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 65 mm, travel distance X-axis: 220 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 550 mm, overall weight: 4,700 kg, turning diameter over bed slide: 800 mm, HYUNDAI WIA L200SY CNC TURNING CENTER Year: 2012 | Fanuc 18i-TB CNC Control SN: G3169-0110 • 5-Axis CNC Turning Center – Hyundai WIA L200SY • Main Chuck: 8″ | Sub Spindle: 5″ • Live Tooling & Y-Axis + C-Axis indexing • Max Turning Diameter: approx. 419–420 mm / 16.5″ • Max Turning Length: approx. 520–530 mm / ~20.5–20.9″ • Swing Over Bed: approx. 800 mm / 31.5″ • X Travel: approx. 220 mm / 8.7″ • Z Travel: approx. 550 mm / 21.7″ • Y Travel: approx. 80 mm / 3.1″ • Max Spindle Speed: up to 4,000 rpm • Main Spindle Power: ~20 HP (~15 kW) • Sub Spindle Speed up to 6,000 rpm • C-Axis indexing: 0.001° possible • Tool Stations: approx. 12 • Coolant system and chip conveyor included • Approx. Dimensions: 120″ × 68″ × 80″ • Approx. Weight: ~10,500 lbs (~4,760 kg) Hedpfxox I A Hco Agzeg NOTE: MACHINE WAS REMOVED FROM GOOD WORKING CONDITION 2 YEARS AGO. PLANNED TO PUT BACK IN SERVICE BUT SELLER WILL NO LONGER BE DOING MACHINING.

Condition: excellent (used), Year of construction: 2015, Machine type: 5-Axis Machining Centre (Simultaneous) Year of manufacture: 2015 Control: HAAS CNC control to DIN 66025 X-axis travel: 762 mm Y-axis travel: 508 mm Z-axis travel: 508 mm Max. spindle speed: 15,000 rpm Spindle motor power: 22.4 kW (vector drive) Spindle taper: SK 40 (DIN 69871) Max. torque: 122 Nm (at 2,000 rpm) Table dimensions: ∅ 630 x 500 mm Max. workpiece weight: 300 kg Number of simultaneously controlled axes: 5 C-axis rotation range: 360° continuous B-axis swivel range: -35° / +110° Rapid traverse rates (X, Y, Z): 30.5 m/min Tool magazine (positions): 40+1 (side-mounted) Coolant system capacity: 284 litres Machine weight: approx. 8.2 t Cooling systems: - Through-Spindle Coolant (TSC), 21 bar - Programmable coolant nozzle (P-COOL) - Additional coolant filtration system (25 μm) Hsdjx Nh N Sopfx Agzeg - Hand rinsing gun with coolant Measuring and probing systems: - RENISHAW probing system (WIPS-R) - Work probe - Tool measurement system Chip management: - Hinged belt chip conveyor Software & Control: - High-Speed Machining (HSM) - Ethernet interface - Macros - Coordinate rotation and scaling

Condition: used, Year of construction: 2007, travel distance X-axis: 5,000 mm, travel distance Y-axis: 800 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 D, CONTROLS .. SIEMENS SINUMERIK 840 D WORKING RANGE -CUBIC- .. X-axis travel: 5000 mm .. Y-axis travel: 800 mm .. Z-axis travel: 600 mm SPINDLE / HEAD .. spindle revolutions (max): 6000 /min .. spindle revolutions (max): 8000 /min .. tool fixture: ISO SK 50 .. drive power: 26 kW AXIS DRIVES .. number of gears: 2 TOOL MAGAZINE .. number of positions: 52 .. tool diameter max.: 120 mm .. - with free neighbour positions: 180 mm .. tool length max.: 400 mm .. tool weight max.: 15 kg .. tool changing time: 9 s AUTOMATIC WORKLOAD EQUIPMENT .. number of store positions: 36 DIMENSIONS / WEIGHTS .. total weight approx.: 24000 kg ATTACHMENTS .. European CE standards: yes Hsdpfjx N Dvzex Agzsg Operating hours 65´040h Accessories: Coolant system Chip conveyor

Condition: ready for operation (used), Year of construction: 1998, Homag Processing Center Genius BAZ20/30/14/D Electronically controlled milling and edge-banding machine, post-processing, and drilling center designed for batch production of furniture parts, solid wood, or similar materials. Base Machine: - Heavy-duty, stable machine bed with a compact linear guide system. - Aggregate carrier with linear guide system, ball screw, and digital AC servo motor for Z-axis positioning, travel distance 340 mm - Automatic central lubrication for all drives and linear guides - Designed for the attachment of various table configurations Control System: Wood Wop 5.0 - Enlarged Z-axis travel, 500 mm - Extended safety step mat - Manual through-feed table B20/30+40/…/D - Motorized width adjustment of the longitudinal console D-table - Chip conveyor belt for B../30+40/K - Stop pins for laminate overhang - Main spindle, 12 kW - Chain tool changer, 70 positions for B20, for HSK 63 F tools - Aggregate interface for main spindle - Electrical/electronic interface 220/24 volt - Edge gluing aggregate, 4 sides for main spindle - Melting unit with granulate container - External automatic triple edge changer - Rack changer system for aggregates and tools - Rabbet pressure zone for main spindle - Flush trimming unit for tool changer - Saw and crosscut unit for tool changer Hsdox Nrk Hopfx Agzog - Boring/milling unit with 4 spindles for tool changer - Lock case milling unit for rotary magazine - Vertical milling unit with tracing ring - Sanding unit with air blast nozzle - CNC programming system Wood-Wop - Post-processor for BAZ - Free-standing control panel Location: Ex works, customer site - Immediately available - Machine must be dismantled by the buyer.

Condition: good (used), Year of construction: 2005, Tool holder BT 40, Hedowbaqlspfx Agzog 12.000 rpm, 60 tool places in tool changer, 70 bar IKZ, laser Renishaw OMI-2. Parts shown by hand not come.

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Hsdpsxy Tmnofx Agzsg

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, Portal Machining Center – Universal – 5-axis machining Brand: AXA / Type: VPC-40-U / Year of construction: 2003 Description: Compact gantry design with overhead guides,automatic 1-axis swivel head and integrated NC rotary table for 5-sided machining. Condition: Ready for use / operational Operating hours (switch-on time): approx. 63.400 h TECHNICAL DATA Machining paths: - X-path (longitudinal movement): 2.300 mm vertical / 2.000 mm horizontal - Y-path (cross movement): 1.200 mm - Z-path (vertical movement): 600 mm - Distance between table and spindle nose: Zmin vert./hori. 110/160 mm - Rotary table – spindle nose: Zmin vert./hori. 110/160 mm Working table: - Table clamping surface: 1.100 x 1.100 mm - Table load: 1,5 tons Feed rates: - Max. Feed force: 9.000 N - Rapid traverse in X/Y/Z: 20/20/20 m/min Hedpfx Aex Np Dqjgzsg Main drive / Spindle head: - Main drive AC – Hollow shaft motor 40 % ED: 30 kW - Speed range, continuously variable: 30 – 10.000 rpm - Tool holder: SK 40, DIN 69871A / 69872A Tool changer (chain magazine) - Tool stations: 36 positions Working spindle: 1-axis swivel head with 1° pitch Hirth spline instead of the standard 2.5° pitch. NC - Horizontal rotary table integrated into the machine table: - Rectangular face plate 1.100 x 1.100 mm EQUIPMENT / ACCESSORIES: - CNC-Control: Heidenhain iTNC 530 - Table height increase: fixed table by 150 mm. This means that the top edge of the fixed table and the rotary table are at the same height. - Coolant through the spindle - Chip conveyor (hinged belt) - Integrated 200 l coolant tank with pump for external cooling - Full machine enclosure - Extraction unit for extraction on both sides with work area enclosure - Manual spray guns - Electric hand wheel - Tool probe system TT 130, brand: Heidenhain There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: good (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, For sale: CU 1000 Pilote Technologie machining centre. Dimensions and machining travels: X-axis (longitudinal) travel: 1000 mm, Y-axis (transversal): 500 mm, Z-axis (vertical): 500 mm. Year of manufacture: 1998. CNC Fanuc OM. 4th axis – rotary table. Hsdoxv Ah Tepfx Agzjg

Condition: used, Year of construction: 2003, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, controller manufacturer: HEIDENHAIN, CONTROLS .. NC controls HEIDENHAIN WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 400 mm .. Z-axis travel: 400 mm TABLE .. table surface (left-right): 700 mm .. table surface (front-back): 500 mm SPINDLE / HEAD .. spindle revolutions (max): 10000 /min .. tool fixture: ISO SK 40 TOOL MAGAZINE .. number of positions: 16 DIMENSIONS / WEIGHTS .. space requirements -left/right-: 5000 mm .. space requirements -front/back-: 3700 mm .. total height: 2500 mm Hodpfox N Dvuox Agzsg .. total weight approx.: 4500 kg 26,000 operating hours, 3,812 working hours

Condition: ready for operation (used), Vertical machining center, Mori Seiki MV-Junior Hedox I D Syopfx Agzeg

Condition: good (used), Year of construction: 2010, Machine is in good condition. Parts shown by hand not come. Hodpfx Agox N Atfozog

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Pass-through height. Operator terminal: 24" LED color display. Handheld terminal for controlling axis speeds. Software: "Woodflash". Vacuum pump 90 m³/h, 50 Hz or 108 m³/h, 60 Hz. Milling spindle 12 kW HSK F63 (12,000 rpm). 12-position linear tool changer on the left side of the machine frame + pickup position. Drilling head DH 16 4H 2S: Vertically 12 spindles, horizontally 4 spindles, 2 grooving saws. Storage location: Supplier. Hodpfx Agjxy Tlwjzsg

Condition: used, Year of construction: 2015, turning diameter 250 mm turning length 600 mm control FANUC Series 31i-Model A travel -x axis 180 mm travel -y axis +/-45 mm - - - - - Main spindle - - - - - - - - - - - Hjdpsx I Shpofx Agzsg turning speeds 0 - 5.000 U/min bar capacity 65 mm --- Subspindle --- - - - - - - turning speeds 0 - 7.000 U/min bar capacity 42 mm --- upper turret 1 --- - - - - - - numbers of positions in the tool changer 12 tool taper BMT 45 Number of axles X1 / Y1 / Z1 St. Tools speed 8.000 U/min --- upper turret 2 --- - - - numbers of positions in the tool changer 12 tool taper BMT 45 Tools speed 8.000 U/min Number of axles X3 /Y3 / Z3 St. --- lower turret 3 --- - - - numbers of positions in the tool changer 12 tool taper BMT 45 Number of axles X2 / Z2 St. Tools speed 8.000 U/min CNC Turning- and Milling Center | SPINNER - TTS 65 Triplex equipped with a main spindle and a sub-spindle, each including a C-axis, three triplex turrets designed for driven tools, as well as a bar feeder (Top Automazioni X-Files-S Series 3000, SX version). The machine has only 3.500h processing time hours. The machine is in good condition and can be inspected under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TTS65Triplex | TTS 65Triplex | TTS-65-Triplex | TTS-65 Triplex

Condition: good (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 630 mm, For sale 1 machining center Hartford LG 800S Year 2007 3 axes Fanuc A1100 Machining Capacities Hodpexvz Tnsfx Agzeg Axis travels X/Y/Z: 800 mm (X-axis) x 510 mm (Y-axis) x 630 mm (Z-axis) Table dimensions: 950 mm x 510 mm Maximum workpiece weight: 500 kg Spindle speed: Typically 8,000 rpm, optionally 10,000 rpm Spindle taper: BT40 (or ISO 40) Tool magazine (ATC): 24-position automatic tool changer Machine weight: Approx. 5,800 kg BT MACHINES PURCHASE AND SALE ALL TYPES OF INDUSTRIAL EQUIPMENT ALL TYPES OF MACHINE TOOLS

Condition: good (used), Year of construction: 2013, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,300 mm, rotary table diameter: 1,250 mm, Manufacturer: MATEC Type: 40HV Control: HeidenHain iTNC530 Year of manufacture: 2014 NC rotary table 1250 mm at 50 rpm Full C-axis 360,000 rpm with HIGH TORQ Drive HSK-100 with 90 kW and 15,000 rpm 5-axis simultaneous package Last service in 2023 Specifications Metric US Standard X-axis 4000 mm Y-axis 1200 mm Z-axis 1300 mm A-axis 105° B-axis 360,000° Table length 4500 mm Table width 1200 mm Table diameter Ø 1250 mm Tool holder 100 ISO/Bt/Mk Spindle power 90 kW Speed 15,000 RPM Tool changer 60 Internal coolant supply 70 Number of controlled axes 5 Chip conveyor Yes Cooling system Hodowc I Tdjpfx Agzeg Yes Dimensions (estimate) Length 10500 mm Width 4500 mm Height 4100 mm Weight 34000 kg Please note: The information on this page has been obtained to the best of our knowledge and belief, and where possible, from the manufacturer. The information is provided in good faith, but its accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contractual terms. We recommend that you check all important details.

Condition: used, turning diameter over bed 280 mm turning diameter over slide rest 160 mm turning length 500 mm centre height 140 mm centre distance 500 mm spindle bore 36 mm Hjdpex Ni Dkofx Agzsg spindle turning speed range 15 - 3550 U/min spindle head DIN 55022 Gr. 5 feeds - longitudinal 0,008 - 0,560 mm/U feeds - cross 0,004 - 0,280 mm/U thread - mm pitch 0,2 - 12 mm dia. of leadscrew 24 mm lead of leadscrew 6 mm tailstock taper MT 3 tailstock quill stroke 90 mm tailstock adjustment out of the central pos. 15 mm total power requirement 2,2 kW weight of the machine ca. 0,6 t - machine out of teaching shop - Accessories: DRO on 3 axis, 3-jaw chuck RÖHM 160 mmø, MULTIFIX-head A, running center

Condition: good (used), Year of construction: 2009, operating hours: 48,570 h, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Make: MIYANO Model: ABX-64SY Year of manufacture: 2009 FANUC 31i control Hsdpfxjxzrpwj Agzsg Driven tools Turret C-axis Parts conveyor belt Chip conveyor Parts gripper Multifeed bar loader

Condition: used, Year of construction: 2011, · Working area: 2,550 x 1,067 mm · X-Y travel: 2,980 x 1,450 mm · Z-axis travel length: 150 mm · Clearance height: 120 mm Drilling Unit F14: · Drilling head with 8 + 6 spindles · 5 individually selectable vertical spindles in X · 3 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm (6,000 rpm available as an option) · Power: 2.2 kW · Grid: 32 mm · Drill holder: M10 with 11 mm positive fit · Pneumatic feed stroke: 60 mm Grooving saw unit in "X": · Integrated in the drilling head · Grooving saw blade with a maximum diameter of 120 mm Main milling unit: · Tool interface HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S1) · Motor power: 7.5 kW (10 HP) from 12,000 rpm (S6) · Right-/left-hand rotation · Ceramic bearings · Prepared for use with angle drives Tool changer TR10: Automatic lateral tool changer for 10 tools. · Number of tool positions: 10 · Maximum tool diameter: 120 mm · Maximum weight per tool: 4.5 kg · Maximum total tool weight: 28 kg A central extraction port collects all processing units into a single connection with D=200 mm. This reduces the required extraction capacity to approx. 3,200 m³/h. TVF worktable: The worktable is designed to provide the operator with maximum "freedom of movement." The vacuum quick-clamping system offers maximum flexibility for precise positioning and optimal holding of workpieces. · 4 TVF supports, L=1100 mm, infinitely adjustable in X · 12 TVF vacuum cups 120 x 120 mm, infinitely adjustable in Y Hodpfsxy Ndisx Agzsg · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (total 4 pcs.) · Retractable reference stops controlled via CNC Automatic central lubrication: The correct amount of lubricating grease is distributed via an electronic CNC control unit (X, Y, Z axes) Vacuum system (base machine): · Vacuum pump: 90 m³/h · Power: 2.2 kW · Max. negative pressure (at pump): 0.9 bar PROGRAMMING SYSTEM XILOG PLUS Software features: - Import of DXF files - Import of ASCII files - User interface in operator’s native language Safety devices with bumpers Machine technical data: · Total connected load max.: 18 kW · Recommended fuse: 64 A · Power supply: 400 V 50-60 Hz · Compressed air: 6-7 bar · System pressure (recommended): 8 bar · Compressed air consumption: 200 Nl/min · Central extraction port Ø: 200 mm · Extraction speed: 30 m/sec · Air consumption (central extraction): 3,200 m³/h · Negative pressure: 3,000 Pascal · Weight: approx. 2,500 kg Remote control of machine functions 6 TVF supports L=1,100 mm and 18 vacuum cups 120x120 mm Cross lasers for vacuum cup positioning Two cross lasers mounted on the unit carrier allow for easy positioning of the vacuum cups. Location: Nattheim

Condition: good (used), Year of construction: 2004, functionality: fully functional, * CNC-control Heidenhain iTNC 530 * Number of Controlled Axes: 5 + spindle * NC-swivel-type rotary table, diameter 800 mm - Workpiece weight in clamped horizontal position 1000 kg - Positioning mode for both axes 600 kg (upper 30 deg. 500 kg) - 4-5 axes simultaneous mode 400 kg - Swivel range 45 deg. to the work spindle, 25 deg. away from the work spindle * 60-Position Tool Changer * Direct Measuring System, Resolution 0.001 mm * Coolant System (no coolant through spindle) * Chip Conveyor Technical details x-travel 800 mm y-travel 1000 mm z-travel 655 mm tool taper ISO 40 spindle turning speed range 0 - 15000 rpm Hsdpsx Nn U Iofx Agzog feed range 10000 mm/min rapid traverse 30 m/min power capacity (100/40% ED) 18/24 kW total power requirement 40 kW weight of the machine ca. 10,5 t

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Hjdpow Dcccsfx Agzog

Condition: good (used), Year of construction: 1999, functionality: fully functional, Technical details x-travel 1350 mm y-travel 900 mm z-travel 750 mm Hjdpfx Agox Nn T Djzsg power capacity - milling spindle 22 kW table surface area 1400 x 840 mm spindle turning speed range 12000 rpm tool taper ISO 40 feed range 0 - 10000 mm/min rapid traverse 30 m/min total power requirement 46 kW weight of the machine ca. 10,1 t CNC-control Heidenhain TNC 426 M 46-station ATC Coolant system Coolant through spindle Chip conveyor Direct measuring system with 0.001 mm resolution Electronic handwheel

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Hjdpfow Dcb Sex Agzjg
