Used Sawmill Alignment for sale (1,483)

Condition: used, Belt conveyor Hedpsxf D T Nsfx An Nsfn Length: 5.50 m Width: 0.35 m Height: 0.90 m Belt width: 0.22 m

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,500 mm, rapid traverse X-axis: 35 m/min, rapid traverse Y-axis: 35 m/min, rapid traverse Z-axis: 35 m/min, spindle speed (max.): 7,000 rpm, workpiece weight (max.): 15,000 kg, Equipment: rotational speed infinitely variable, FPT Moving Column Milling Machine mod. RONIN CNC Control Heidenhain 530 X axis 8,000 mm Y axis 1,500 mm Z axis (vertical) 2,500 mm Rapid traverse 35,000 mm/min Feed rates 15,000 mm/min Automatic bi-rotational milling head (continuous) – TUPC Spindle taper ISO 50 Max spindle speed 7,000 rpm No. 1 ROTOTRASLATE TRT TABLE Hydrostatic Dimensions 2,000 x 2,000 mm Travelling V axis: 1,500 mm Max load capacity: 15 tons No. 1 ROTARY TABLE Dimensions 1,500 x 1,500 mm Max load capacity: 15 tons Tool changer with 80 positions Total installed power 88.8 kW Equipped with: - Internal high-pressure through spindle: 20 bar Hsdowzxwqjpfx An Nofn - External high-pressure coolant: 4 bar - Chip conveyor - Remote CNC Heidenhain wireless control pendant - Laser probe and software for tool integrity check, tool length & radius measurement - Workpiece measurement and alignment probe USED MACHINE

Condition: used, engines - 55 and 55 kW feed motor - 7.5 kW height adjustment motor - 1.1 kW cutting height - 200 mm cutting width - 350 mm blade saw diameter max.- 300 mm spindle diameter - 2 x 60 mm sleeve diameter - 2 x 70 mm track width - 350 mm total power - 119 kW electric feed regulation automatic central lubrication minimum length of the element - 600 mm electric height adjustment shaft height adjustment six upper pressure rollers pneumatic clamps five anti-ejection pawls ruler stub diameter - 220 mm spindle speed - 4500 RPM dimensions of the machine (length / width / height) - 275 / 235 / 210 cm weight - ~ 7000 kg Hfjdowrw D Ropfx An Njn Feeders: max. cutting length - 1850 mm min. cutting length - 800 mm max. material length - 2500 mm min. material length - 600 mm max. material width - 700 mm max. material height - 200 mm roll width - 700 mm roll diameter - 130 mm number of rolls - 26 3 smooth pressure rollers 4 toothed pulling rollers feed adjustable on the inverter 0-70 m/min. central lubrication of saw guides power of the saw motor - 2 x 9.2 kW feed motor power - 1.5 kW power of the disc spreading motor - 3 kW chain motor power - 1.1 kW dimensions (length / width / height) - 7050 / 2100 / 1850 mm

Condition: used, Board repacking line Manufacturer: PlanSel/Nordautomation Hfodpfx Asykauzon Nen Pack chain conveyor Tilt hoist Board elevator Edge cutting system Measurement system Stacker with spacers Outfeed chain conveyor Boards till 6 m

Condition: used, -Fuel delivery system Hedjwfpwpjpfx An Nefn -Biomass combustion system -Hot water boiler -Ash removal system -Flue gases primary cleaning system -Stairs and service platforms -Draft fan - Automatic control system -Chimney -Circulation system and water treatment Main parameters and guarantee value are calculated according to fuel parameters: -Moisture 60-65 % -Ash till 8 % - Calorific value 7990 kJ/kg and 1907 kcal/kg Main parameters of the furnace 6000 K: - Maximal designed thermal output – 6.5 Mw - Maximum continuous rate – 6 MW - Furnace regulation range 20% - 100% - Volume of furnace- 31.6 m3 - Volume of combustion chamber – 24m3 - Grates area 12 m2 - Grates designed thermal load – 500 Kw/m2 - Combustion chamber designed thermal load – 250 Kw/m3 - Maximum temperature in the combustion chamber - 900°C The following kinds of biomass are accepted for combustion in the furnace: - wood chips – 100% - forest wood residues- 100% - saw dust – 100% (G15) - chunk peat – 100% - bark – 100%

Condition: used, Ražotājs: Munch Modelis: 420 Ražîba: 1 tonna stundā Elektrojauda: 2x75 kW Diametrs 420 mm Komplektā ar dzesētāju pēc kapitālā remonta Hfsdpfxjwfqn Ae An Non clear 134 / 5,000 Translation results Translation result Manufacturer: Munch Model: 420 Production: 1 ton per hour Electric power: 2x75 kW Diameter 420 mm Complete with cooler after overhaul

Condition: new, neu ca. 2 Wochen ab Auftragse Italien 17940 € 344.45 € Dm. 200x78x78 mm 2800 1/min 300 mm 300x150x55 mm 350x150 mm 500x160 mm 3.6 kW 1020 mm 820 mm 2170 mm 440 kg This Grinding machine with fixed table derives from the model R.V. 500 but it differs from it as it is equippedwith a long column supported by four bearings and is opportunely stiffened by a sturdy column support. This Surface grinding machine, due to its stiffness and geometrical stability, is highly suitable for grinding with precision pieces of notable height: single or mass-produced die-shop components, moulds, punches, gears and others. Moreover, the nuts of the vertical translation screw and the dowels to realign the wheel motor to the axis,equipping this model of Grinding machine with fixed table, allow preserving perfect work conditions over the years, too. CAST IRON BED to maintain the geometric stability of the grinding machine in time, too. CAST IRON COLUMN, protected by bellows and supported by four adjustable precision bearings, broadly sized for this type of grinding machine with fixed table. Three-phase MOTOR air-cooled by double jacket, to prevent the overheating of the grinding Hfjdpoyv Iqvsfx An Non machine motorduring continuous machining and to keep the temperature of the motor shaft and of bearings constant. Hardened, ground and dynamically balanced SHAFT, supported by precision ball bearings, widely sized for this type of grinding machine with fixed table and self-adjusting by means of springs for the backlash preload, to absorb thermal expansions. VERTICAL TRANSLATION SCREW supported by opposite and adjustable ball bearings, with apt motion for maintaining, in this model of grinding machine with fixed table, the wheel work field free from hindrances and for avoiding dust depositions. Metal BELLOWS for a better protection of the vertical translation screw of the grinding machine. Opposite bronze NUTS, for the recovery of the eventual wear in time of the vertical translation screw of the grinding machine with fixed table. REGISTRATION DOWELS to re-align the wheel motor of the grinding machine to the axis, obtaining parallel surfaces also in time. HANDWHEEL of the grinding machine, supported by three bearings and engaged on the screw by means of a pair of helical gears, equipped with graduated drum, supported by a trust bearing, for a stock removal of mm 0.01 - 0.02 - 0.03 for each single pass; the rapid feed per handwheel turn is mm 2. KNOB WITH JACK, for the programmable micrometric feed of mm 0.01 - 0.02 - 0.03 - 0.04 per pulse, which allows a simple use by avoiding the constant increment control. SLOT to permit the maximum use in height of the work field of the grinding machine wheel and to clamp non-magnetic parts and accessories such as: magnetic chuck, self-centering chuck and squares. Low-voltage CONTROLS, protection, indicator light and all requisites to comply with safety and conformity regulations provided for this type of grinding machine with fixed table. HANDLES, SHAPES AND SIZES of the grinding machine with fixed table designed to meet the current ergonomic recommendations for work. WITH FOLLOWING ACCESSORIES: Magnetic chuck 300 x 150 mm Wheel flange and cup wheel Semiautomatic dresser with diamond Coolant system Operating manual in German or Italian

Condition: refurbished (used), 1 set = 8 guides suitable for the ESTERER S 71 gang saw, completely refurbished, i.e. all sliding surfaces re-milled to precise angles. Hedpfx Ansywh Hmo Nsfn

Condition: used, Year of construction: 2016, Angular panel saw with automatic pre-loading and twin pusher system for optimised cutting Osi Plus Numerical Control Os Labelling labelling machine with on-board graphic labelling with part drawings Label printing management software Optiplanning Cutting Optimizer Cutting length mm 4500 Cutting width mm 2200 Blade projection 95 mm Motorized rollers for lateral loading on lifting table 4500 x 2200 mm. The translation speed is 10.8 m\min (50hz) - 13.1 m\min (60hz) Automatic recognition of the lost panel (martyr panel) based on the thickness specified in the machine data Low battery stop Automatic side loading buffer. Includes: perimeter nets, double photocell, push-button panel, predisposition electric for the two motorized pre-rollers and the amplification of 4 rollers in place of the fork passages in the pre- intermediate roller conveyor Pre-loading side roller conveyor dim 3800 x 2200 mm with motorized rollers (height from the ground 325 mm) Inertial conveyor for conveying longitudinal trimmings for angular systems 4500 mm (total length 7295 mm) 3000 mm extension to the inertial conveyor to also convey transverse trimmings Long chute for manual conveying of cross-cut trimmings to the centralized inertial conveyor 2050 x 850 mm air curtain discharge table with wheels at the front Air generator up to 6 floors with air curtain MULTIPUSHER 2.4 system with automatic lubrication Additional mobile lateral aligner on the transverse plane. The presence of this device allows to reduce from 1830 to 1220 mm is the minimum length of the panels that must be sent for cross-sectioning. Automatic blade shaft bending detection device for angular systems (longitudinal and transversal) consisting of a sensor that detects the deflection directly on the blade shaft and a device that detects the revolutions blade directly on the spindle. Remote cycle start button panel Automatic panel loading via rear lifting table Automatic double aligner with pneumatic cylinders Additional movable lateral aligner on the transverse plane Main blade, max diameter mm, KW 15 Scoring blade, max diameter mm, KW 2.2 Blade carriage speed 1-140 m/min. – BRUSHLESS motors Longitudinal pusher carriage speed 90 m/min. Cross pusher carriage speed 135 m/min. Hfsdjuc Idxspfx An Nsn Double pusher carriage with 6 grippers on the longitudinal carriage + 10 grippers on the transverse carriage (8 fixed grippers + 2 on the multi-push system) Cutting system for thin panels

Condition: used, Drum wood chipper IDC000024 - Manufacturer: Erjo, - Model: 204 MA, - Capacity: 20 - 40 m3/val., - Weight: 3000 kg, - Electric motor: 30 kW. Hsdjtqz Sbopfx An Nofn

Condition: used, BRUKS 1700 ML industrial drum chipper designed for processing logs, slabs, offcuts and other wood waste into high-quality wood chips. Suitable for demanding sawmill and biomass production. Technical specifications: Manufacturer: BRUKS Model: 1700 ML Capacity: up to 100 m³/h Chip length: 15–30 mm (up to 50 mm) Chipper disc diameter: 1700 mm Hjdpfszpwaqox An Nsfn Number of knives: 4 Knife dimensions: 525 × 180 × 16 mm Disc speed: 530 rpm Infeed opening: 500 × 300 mm 2 upper and 6 lower feed rollers Feed drive power: 2 × 4 kW Required chipper motor power: 75–150 kW Weight: approx. 5 500 kg

Condition: used, Rotary trommel screen Screen length: 7.5 m Screen diameter: 3 m Electric motor: 7.5 kW Hjdpszpxtfsfx An Nofn Overall height with support legs: 6 m Mesh size: 20 × 20 mm

Condition: used, TEDAK 3 Dust Filtration Unit Specifications: Manufacturer: TEDAK AB Country of origin: Sweden Model: TEDAK 3 Article No.: 111200 Serial No.: 13246 Operating pressure: 30 kPa Electrical control cabinet included Filter housing included Hsdpozmd Trjfx An Nofn Suitable for filtration of wood dust, chips and other dry materials in the woodworking industry

Condition: used, HAAS Wood Chip Screening Machine Hjdpfx Ajzmfq Sjn Njfn Manufacturer: HAAS Recycling Systems Country of origin: Germany Type: Vibrating chip screen Designed for screening wood chips, bark and biomass materials Suitable for separating fine particles and contaminants Vibrating screening system Multiple material discharge fractions Approximate dimensions: Length: 4.29 m Width: 2.10 m Suitable for woodworking and biomass processing industries

Condition: reconditioned (used), Year of construction: 2013, functionality: fully functional, We have a Buhrs W+D BB300 10K, 6 stations envelope inserting system with camerasystem available. DL up to C4 envelopes. This machine is built in 2013. This system is ready after completing our full maintenance programm. This machine is therefore ready for a demo! Hfodozv Trcepfx An Nen Year of built 2013 6 station base Configuration: Buhrs BB300 - 10K 6 station base 4 rotary feeders 1 HF3 vacuum friction feeder Divert bin Turning module Alignment module Conveyor belt Autoloader envelope station This system is already equipped with a camerasystem for matching with two camera's. More and other feeders possible.

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, We have a Buhrs W+D BB700 14K servo envelope inserting system available. DL up to C4 envelopes. This machine is built in 2007. Year of built 2007 6 station base Configuration: Mueller Apparatebau single sheet feeder / transactional channel Hodpfxjzv Tz Ro An Njfn Buhrs BB700 - 14K 6 station base 5 rotary feeders 1 HF3 vacuum friction feeder Divert bin Envelope station autoloader Conveyor belt This system is completely prepared for a Mueller transactional system for feeding/reading/collating/folding A4 documents. We do have multiple Mueller transactional system available as well. We can offer this optional. More and other feeders possible. Reading camera's for matching optional! Turnover module, alignment table and mailtable also available optional. Machine has just passed through our complete maintenance program. The machine is therefore 100% complete works like new. Please come over for a test if you like.

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, We have a Buhrs W+D BB700 14K servo envelope inserting system available. DL up to C4 envelopes. This machine is built in 2007. Year of built 2007 6 station base Configuration: Mueller Apparatebau single sheet feeder / transactional channel Buhrs BB700 - 14K 6 station base Hfjdpfx Aezv T Auen Njn 5 rotary feeders 1 HF3 vacuum friction feeder Divert bin Envelope station autoloader Conveyor belt This system is completely prepared for a Mueller transactional system for feeding/reading/collating/folding A4 documents. We do have multiple Mueller transactional system available as well. We can offer this optional. More and other feeders possible. Reading camera's for matching optional! Turnover module, alignment table and mailtable also available optional. Machine has just passed through our complete maintenance program. The machine is therefore 100% complete works like new. Please come over for a test if you like.

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting Hjdpozvduusfx An Nofn - CE compliant Optional against additional charge

Condition: ready for operation (used), Year of construction: 2020, number of ink cartridges: 4, color channels: 4, number of print heads: 4, counter reading (black): 309,030, counter reading (color): 506,975, Equipment: auto duplex, brochure finisher, documentation/manual, raster image processor, An authorized Canon Production partner is offering a Canon imagePress C910 (90ppm) cut-sheet digital press for sale. The printer is in excellent condition; it was originally used as a showroom device and later, in 2023, installed at a small graphic arts customer. It has now been returned to us following the completion of a contract. Configuration: Hjdpozrg Rdjfx An Nsfn - CANON ImagePress C910 main unit (90ppm license) - Multi-drawer Paper Deck-E1 - Staple Finisher W1 Pro - Paper Folding Unit-J1 (performs C/Z folds) - PRISMAsync iPR V910 print server - Stack Bypass-D1 - Stack Bypass Alignment Tray-D1 - Duplex Color Image Reader Unit-M2 Counters: Total (All) 1,002,240 Total (Black/Large) 3,879 Total (Black/Small) 309,030 Total (Full Color+ Single Color/Large) 182,356 Total (Full Color+ Single Color/Small) 506,975 Total (Black & White / Long Sheet) 0 Total (Full Color + Single Color/Long sheet) 2 We would be happy to provide more details, including photos and videos of the device, via WhatsApp. You are welcome to inspect the printer at our facility and perform test prints. The printer is located in Riga, Latvia. We will pack it securely for worldwide shipping.

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 11/2022, total length: 2,750 mm, total width: 1,650 mm, total height: 1,800 mm, overall weight: 750 kg, Equipment: documentation/manual, Automatic CNC machine for UV screen printing – SD2-C4-UV (2022) MACHINE OFFERED: The SD2-C4-UV is an automatic, four-color CNC machine designed for screen printing. The machine performs multi-color printing on flat and three-dimensional (round) products, using UV and IR-cured inks in a single production cycle. The machine allows printing on three-dimensional objects in up to six colors, combining UV and IR technologies. It is intended for printing components made of non-flammable materials and plastics, provided that the temperature of the surfaces of the printed components is controlled. We offer for sale a fully functional, automatic CNC machine for UV screen printing, model SD2-C4-UV, manufactured in 2022 (serial no. 11/2022). The machine operates reliably; the sale is due to a change in the production profile. Hfjdozwdv Uopfx An Non BASIC DATA • Model: SD2-C4-UV • Serial number: 11/2022 • Year of manufacture: 2022 • Condition: used, technically sound • Cycle counter: 381,124 • Documentation: complete operating manual (120 pages) TECHNICAL PARAMETERS • Power supply: 3 × 400 VAC / 50 Hz / max. power 10 kW • Dimensions: 2750 × 1650 × 1800 mm; weight ~750 kg • Operating pressure: 6.0 bar (max. 7.0 bar) • Printing of round objects: diameter 10–150 mm, height up to 250 mm • Printing of flat objects: up to 250 × 100 × 100 mm • Max. printing area: 310 × 180 mm (1 color) • Operation: 1 operator MAIN ADVANTAGES • 4-color UV and IR screen printing in a single cycle (up to 6 colors) • 9 CNC servo drives – full automation of movement • Printing on round (diameter 10–150 mm) and flat objects • Vision system (camera + monitor) for precise screen alignment • Remote service via the Internet; software update • PLC controller with a touch HMI, menu in Polish • Complete safety systems according to CE standards (opto-electronic barriers, foot pedal) • UV reactor with a 200 mm lamp / ~250 W/cm

Condition: repair required (used), Year of construction: 2019, pressing force: 220 t, overall weight: 12,620 kg, controller model: Delem DA-66T, working width: 3,050 mm, number of axes: 6, The press brake cannot be aligned because the X and R axes are blocked. This is a machine that is to be repaired or is intended for a project. TECHNICAL DETAILS Number of axes: 6 Axes: Y1 + Y2 + X + R + Z1 + Z2 Press force: 220 t Max. working width: 3,050 mm Hfsdpozuw Ewjfx An Nen Frame spacing: 2,500 mm Crowning system: CNC-controlled Ram holder: hydraulic Tool holder type: WILA standard MACHINE DETAILS Drive: CNC Control: Delem DA-66T Power: 22 kW Dimensions & Weight Dimensions (L x W x H): 3,750 x 1,900 x 2,900 mm Weight: 12,620 kg Transport packages: 1 EQUIPMENT Tools

Condition: ready for operation (used), Year of construction: 2014, operating hours: 1,618 h, travel distance Z-axis: 430 mm, number of axes: 5, number of slots in tool magazine: 16, table length: 4,300 mm, table width: 2,205 mm, spindle motor power: 13,000 W, spindle speed (max.): 20,000 rpm, swivel angle B-axis (min.): -99 °, swivel angle B-axis (max.): 100 °, swivel angle C-axis (max.): 360 °, This 5-axis BIESSE Rover A FT 2243 including WINSTORE 3D K1 was manufactured in 2014. It operates on a 400 V power supply. With approximately 1,700 hours of axis movement, this CNC wood machining centre is designed for precision and efficiency. If you are looking to get high-quality wood machining capabilities, consider the BIESSE Rover A FT 2243 machine we have for sale. Contact us for further details. Technical Data • Working Table Dimensions: 4,300 × 2,205 mm • Maximum X-Axis Speed: 80 m/min • Maximum Y-Axis Speed: 60 m/min • Maximum Z-Axis Speed: 20 m/min • Z-Axis Travel (3-/4-Axis Version): 325 mm • Z-Axis Travel (5-Axis Version): 430 mm • Maximum Workpiece Clearance in Z: 170 mm • Maximum Workpiece Clearance with Sweeping Arm: 120 mm • X-/Y-Axis Drive: Rack and Pinion • Z-Axis Drive: Ball Screw • Axis Guides: Linear Guides with Recirculating Ball Bearing Blocks • Vacuum Pump Capacity: 300 m³/h at 50 Hz • Vacuum System: 20 Independent CNC-Controlled Zones • Working Fields: 2 • Clamping Areas: 2 in X • Pneumatic Stops: 16 • Grid Table Pitch: 30 mm • Vacuum Module Dimensions: 132 × 146 mm • Vacuum Module Height: 29 mm • Vacuum Module Rotation Increment: 15° • Air Cushion Table Blower: Yes • Maximum Single Panel Thickness: 50 mm • Minimum Single Panel Thickness: 9 mm • Maximum Multiple-Panel Loading Thickness: 20 mm Hfsdpfszuygqex An Non • Maximum Multiple-Panel Unloading Thickness: 60 mm • Protective Board Thickness: 8–25 mm • Maximum Panel Weight: 200 kg • Minimum Loadable Panel Size in Y: 800 mm • Unloading Conveyor Length: 4,800 mm • Maximum Unloadable Panel Length: 4,300 mm 5-Axis Machining Unit • Number of Axes: 5 Interpolating Axes • Tool Interface: HSK F63 • Cooling: Liquid-Cooled • Power S1: 11 kW / 15 HP at 12,000 rpm • Power S6: 13 kW / 17.4 HP at 12,000 rpm • Maximum Spindle Speed: 20,000 rpm • C-Axis Rotation: 360° Continuous • C-Axis Speed: 12.4 rpm • B-Axis Positioning Range: ±100° • B-Axis Speed: 12.4 rpm • Spindle Bearings: Ceramic • Drive Motor: Brushless, Digitally Controlled • Gearbox: Harmonic Reduction Gear • Lubrication: Lifetime Lubrication Drilling Head • Type: BH 26 2L • Maximum Number of Tools: 26 • Vertical Drilling Spindles: 16 • Vertical Spindle Arrangement: 8 in X / 8 in Y • Vertical Spindle Pitch: 32 mm • Horizontal Drilling Spindles: 4 with Double Output • Horizontal Spindle Axis Distance: 32 mm • Grooving Saws: 2 • Grooving Saw Directions: X / Y • Grooving Saw Diameter: 120 mm • Maximum Grooving Depth: 25 mm • Motor Power: 1.7 kW at 2,800 rpm / 3 kW at 6,000 rpm • Maximum Drilling Speed: 6,000 rpm Tool Magazine • Type: Turret Tool Magazine • Capacity: 16 Tools • Tool Position Spacing: 114 mm • Maximum Tool Diameter with Full Magazine: 110 mm • Maximum Individual Tool Weight: 7.5 kg • Maximum Total Tool Weight: 55 kg Automatic Loading / Unloading • Loading Direction: Front • Material Flow: Right to Left • Loading / Unloading System: Type B • Suction Cups: 5 • Automatic Loading Capacity: Up to 3 Panels • Sweeping Arm: Yes • Automatic Table Cleaning: Yes • Loading Table: Automatic X/Y Alignment • Unloading Conveyor: Motorized • Conveyor Control: CNC-Controlled • Conveyor End Detection: Photocell WINSTORE 3D • System: WINSTORE 3D K1 • System Length: 16,000 mm • Beam Length: 8,000 mm • Additional Modules: 3,000 / 6,000 / 8,000 mm • Maximum Suction Frame Length: 5,200 mm • Cross Conveyors: Belt Type, 5,200 mm • Panel Handling: Raw and Thin Panels • Panel Weight Detection: Load Cell

Condition: used, Year of construction: 1998, Window manufacturing system Manufacturer: Weinig Type: Unicontrol 10-5 Year of manufacture: 1998 Technical data Working width: 40 - 220 mm Working height, longitudinal machining: 40 - 100 mm Working height, transverse machining: 40 - 100 mm (80 mm counterpiece height) Workpiece length, longitudinal machining: min. 220 mm + 2 x tenon length Workpiece length, transverse machining: min. 275 mm + 1 x tenon length at 320 mm tool diameter Feed (transverse machining) Motor power: 0.3 kW Feed speed: 3 - 25 m/min Workpiece clamping: by means of 2 clamping jaws Length stop: with scale and magnifying glass for frame or sash outer dimensions Counterpiece: pneumatically controlled - 4 positions - (not for studio windows) up to a wood height of max. 80 mm Double part package: For single or double part feeding. With transverse separation and retention system 1. Wood (lying against the stop) Wood width: 55 - 90 mm 2. Wood Wood width: 130 mm Feed (longitudinal machining) Motor power: 2.2 kW Feed speed: 4 - 18 m/min (continuously variable via frequency converter) Feed roller spacing: 100/120 mm Feed roller width: 30/50 mm Feed roller diameter: 95 mm Machining units Cut-off saw Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 2800 rpm Tool circle diameter: max. 400 mm Adjustment, axial: pneumatically controlled against a 4-position turret 1. Tenon and mortise spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 3250 rpm Tool circle diameter: max. 320 mm Tool clamping length: 320 mm Adjustment, axial: 240 mm Number of tools: 4 x 80 mm Axial adjustment: hydraulic 1. Profiling spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6000 rpm Tool diameter: max. 232 mm Tool zero circle diameter: 130 to 140 mm Tool clamping length: 320 mm Adjustment, axial/radial: 240/80 mm Number of tool positions: 4 x 80 Axial adjustment: hydraulic 2. Profiling spindle Motor power: 11 kW Spindle diameter: 50 mm Spindle speed: 6000 rpm Tool diameter: max. 232 mm Tool zero circle diameter: 130 to 140 mm Tool clamping length: 320 mm Adjustment, axial/radial: 240/80 mm Number of tool positions: 4 x 80 mm Axial adjustment: hydraulic 2 Mechanical spindle brake for profiling spindle 3 Mechanical spindle brake for cut-off saw and profiling and sawing units Profiling milling unit (horizontal, top) before the last profiling spindle radially controlled to 2 positions axially controlled to 2 positions Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 5850 rpm Tool circle diameter: 130 mm Tool clamping length: 40 mm Adjustment, axial: 52 mm Adjustment, radial: 125 mm Profiling milling unit (vertical, right) at the end of the machine radially controlled to 2 positions axially controlled to 2 positions Motor power: 3 kW Spindle diameter: 40 mm Spindle speed: 5850 rpm Tool circle diameter: 210 mm Tool clamping length: 160 mm Adjustment, axial: 90 mm Adjustment, radial: 100 mm Length, tenon and mortise spindle with 640 mm tool clamping length (instead of 320 mm spindle) Motor power: 15 kW Spindle speed: 2925 rpm Number of tool positions: 8 x 80 mm Adjustment, axial: 560 mm Laser alignment light for cut-off saw for detecting the section Hfsdpfxszuyxgj An Non Studio window configuration Swiveling length stop +/- 60 with electronic digital display and pneumatic clamping Sliding counter rail Special pressure pad for angled part production Limitation: Wood thickness max. 120 mm At -60 position: Workpiece width max. 110 mm with 80 mm tenon length, or max. 150 mm with counter profili

Condition: used, Components of a sawing system Manufacturer: Linck Type: VZM & CSMA consisting of: CSMA extraction device Manufacturer: Linck Type: Av / CSMA Year of manufacture: 2018 The CSMA extraction device offers powerful and flexible material handling in automated production lines. It is designed for variable workpiece sizes and ensures continuous material transport. Technical data - Drive power: 4 x 4 kW - Feed rate: 85 m/min VZM centering device Manufacturer: Linck Type: VZM The VZM centering device is designed for precise centering tasks at high feed rates. The robust design allows it to be used under demanding industrial conditions. Technical data Hfsdpfezuz I Nsx An Njn - Drive power: 2 x 7.5 kW - Feed rate: 84 m/min Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 2019, operating hours: 22,918 h, travel distance X-axis: 700 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 380 mm, controller manufacturer: SIEMENS, controller model: 840D, overall weight: 4,250 kg, spindle speed (max.): 24,000 rpm, number of axes: 5, This 5-axis DMG MORI DMP 70 was manufactured in 2019. It features a maximum spindle speed of 24,000 rpm and a weight of 4,250 kg, making it a robust option for precision machining. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMP 70 vertical machining centre we have for sale. Contact us for further details. Hfedpfx Aozx Srysn Njn - Phase: L1/L2/L3/N/PE- Power Consumption: 30 kVA- Maximum Current (A In max): 43.5 A- Rated Current: 50 A- Short-Circuit Current (V max): 5 kA / 440 V max.- Voltage: 400 V ±10%- Frequency: 50 Hz- Control Voltage AC: 230 V- Control Voltage DC: 24 V- Control: 3D Control Siemens 840D SL Operate- Tool Taper: BBT30- Work Table: Integrated NC rotary tilt table, 5-axis simultaneous operation- Swivel Range A-Axis: -120° / +100°- C-Axis Operation: Continuous (Endless)- Maximum Load C-Axis: 100 kg- Table Diameter C-Axis: Ø290 mm- Drives: Torque drives including direct path measurement in A- and C-axis- Software Packages: Sinumerik MDynamics 5-Axis, 3D data model for simulation- Table Options: Clamping pneumatics (1-circuit)- Coolant & Chip Management: Chip conveyor, Production package belt filter with 40 bar internal coolant supply (IKZ), Blow air through spindle center, External blow air, Oil and emulsion mist separator system- Measuring & Monitoring: RENISHAW 3D touch probe kit, Tool breakage monitoring and in-machine measurement, Preparation for 3D quickSET- General Options: Operating mode 3, CE conformity- Automation Interface: Automation interface for external automation on the right- Automation System: DMG MORI WH 3 Cell- Robotic Arm: Fanuc LR Mate 200iD/7L yellow 6-axis robot- Robot Gripper: Double gripper PGN64- Automation Components: 10 DMG drawers, NIO chute, Alignment station, Measuring drawer, Raw material inlay system, Gripper set, Accessories- Machine Operating Hours (from control screen): Machine runtime: 22,918:34 h; Program runtime: 20,920:40 h; Spindle runtime: 18,815:51 h
