Used Schoen Hydraulic Press for sale (40)

Condition: ready for operation (used), Year of construction: 1991, machine/vehicle number: 4079, functionality: fully functional, power: 7.5 kW (10.20 HP), pressing force: 30 t, stroke length: 500 mm, table width: 1,200 mm, table length: 1,000 mm, table height: 850 mm, ram plate width: 600 mm, ram plate length: 400 mm, distance table to ram: 800 mm, oil tank capacity: 400 l, total length: 2,200 mm, total width: 2,400 mm, total height: 3,500 mm, overall weight: 4,000 kg, year of last overhaul: 2023, Equipment: CE marking, safety light barrier, For sale is a hydraulic double-column press. Manufacturer: Hans Schoen, Type: NH/D 30S. Codpfxszzd Rge Aktjri The machine is in perfect working order and can be inspected while powered on.

Condition: used, Year of construction: 1981, pressure 030 t throat 250 mm stroke 100 mm table-size 500 x 400 mm max. distance table - ram 320 mm ram surface 350 x 220 mm hole in the table 130 x 100 mm total power requirement 5,5 kW weight of the machine ca. 2 t dimensions of the machine ca. 1,8 x 1,6 x 2,5 m Fabricated construction with light guard and two hand switch. Crjdpj Ad Rlmsfx Aktoi

Condition: good (used), Year of construction: 1979, functionality: unexamined, pressing force: 40 t, overall weight: 5,000 kg, Equipment: safety light barrier, SHC 40 Hans Schoen Crodpez S E S Sjfx Aktsi

Condition: refurbished (used), Year of construction: 1987, machine/vehicle number: 3163, functionality: fully functional, pressing force: 25 t, stroke length: 100 mm, table width: 360 mm, table length: 220 mm, Equipment: safety light barrier, Schoen hydraulic double-column press NH 25 (3163) completely overhauled machine – year of manufacture 1987/2026 Pressing force 250 kN Installation height: 280 mm Stroke: 100 mm Table (width): 360 mm Table (depth): 220 mm The machine is undergoing a general overhaul Crjdpfxjzd Akqo Aktji new control system new light curtain hydraulic system revised

Condition: good (used), Year of construction: 1997, Hydraulic press, two-column press, oil hydraulic press, hydraulic press, high-speed press, high-speed hydraulic press, double-column press, single-column press -Manufacturer: Hans Schoen, Hydraulic press type TES/20 with safety device -Pressing force: 20 tons -Motor: 3 kW -Clamping table: 500 x 440 mm / Bore Ø 150 mm -Max. insertion height: 395 mm -Protrusion: 260 mm -Max. stroke: 250 mm -Hole: Ø 40 mm -Operation: Two-hand operation / foot pedal -Safety device: Sick 14-FGS -Dimensions: 1340/1050/H2460 mm Code Ahghmepfx Akteri -Weight: 1740 kg

Condition: excellent (used), Year of construction: 1989, functionality: fully functional, power: 3 kW (4.08 HP), input voltage: 380 V, input frequency: 50 Hz, type of input current: three-phase, pressing force: 16 t, stroke length: 100 mm, table width: 440 mm, table length: 320 mm, clearance between the columns: 500 mm, oil tank capacity: 60 l, total length: 1,040 mm, total width: 1,030 mm, total height: 2,000 mm, 16 ton hydraulic press for sale in good condition HANS SCHOEN TES 16 two-column hydraulic press Year of manufacture: 1986 Pressing force 160 kN motor power: 3kw 380v 50Hz two-hand operation Installation height: 280 mm Stroke: 100 mm Table width: 440 mm Table depth: 320 mm Machine dimensions: height: 200cm width: 103cm length: 104cm Cjdpszf Ilcefx Aktjri weight: 1000kg.

Condition: ready for operation (used), Year of construction: 1985, functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS GENERAL DATA Manufacturer: Schoen Type: SH/LF100 Crodpfj Adu Ryex Aktei Year of manufacture: 1985 Machine type: Hydraulic press PRESS Pressing force: 100 t Table dimensions: 1,200 × 1,200 mm MACHINE DETAILS DIMENSIONS AND WEIGHT Length: 3,000 mm Width: 2,000 mm Height: 3,200 mm Weight: 12,000 kg

Condition: good (used), Year of construction: 1980, power: 3 kW (4.08 HP), pressing force: 10 t, stroke length: 300 mm, total length: 1,400 mm, total width: 1,300 mm, total height: 3,300 mm, overall weight: 2,000 kg, Equipment: documentation/manual, safety light barrier, Year of manufacture: 1980 Equipment: – Filter cleaning, upper and lower stroke limit, – 2 operating modes – Venting system – Safety light curtain Cedpfx Ae Aaviioktori – Safety distance 110 mm (min.) – After-travel distance 12 mm (max.)

Condition: good (used), Year of construction: 1982, Press force: max. 200 kN Cjdpjzvfp Hefx Aktori Safety distance: 100mm Post-travel: max. 10 mm Motor power: 3 kW

Condition: refurbished (used), Year of construction: 1979, machine/vehicle number: 2386, functionality: fully functional, pressing force: 25 t, stroke length: 100 mm, table width: 440 mm, table length: 320 mm, installation height: 280 mm, hydraulic refurbished SCHOEN double column press TES 25 Year of manufacture 1979/2025 Pressing force 250 kN Installation height: 280 mm Stroke: 100 mm Table width: 440 mm Table depth: 320 mm Crjdpfxsvw Spmj Aktji The machine is being refurbished - new control system - new light barriers - revision of the hydraulics

Condition: repair required (used), Year of construction: 1980, functionality: limited functionality, For sale is a Hans Schön hydraulic press with a capacity of 650 kN. It was last used approximately 8 years ago. At that time, the machine had a problem with a hydraulic hose (possibly a broken hydraulic hose or a leaking connection). Crjdpfxex Ehmys Aktoi This was not repaired because the press was no longer needed. Otherwise, the machine operated perfectly until the last use. The press does not have a valid safety inspection certificate.

Condition: used, Year of construction: 1982, Technical details: pressure: 16 t stroke: 250 mm throat: 270 mm dayligth: ca. 400 mm table surface area: 800 x 500 mm boring diameter: Ø 50 mm ram surface area: 220 x 360 mm mortise hole in ram: Ø 40 mm table height over floor: 970 mm Crjdpfx Aju Nfmysktei voltage: 380 / 50 Hz V control voltage: 220 V / 50 Hz total power requirement: 3,0 kW weight of the machine ca.: 2,3 t dimension machine xH: 1,8 x 1,5 x 2,72 m Press frame in robust welded construction. Adjustment of the operating mode via switch: inching, two-hand, foot or continuous operation with feed Press has a piece counter on the side with overload protection (pressure relief valve) with cutting shock damping Light curtain SICK optical electronics (can be repaired optionally) *

Condition: used, Year of construction: 1978, pressure 7 t Crodpfovnwfbox Aktei throat 180 mm stroke 100 mm table surface area 300x300 mm ram surface Ø105 mm hole in the table Ø60 mm table height 1050 mm tool hole in ram Ø30 mm total power requirement kW dimensions of the machine ca. BxTxH 1200x1200x2100 mm

Year of construction: 1978, condition: used, Pressing force: 75/5kN, motor power: 11kW, an on-site inspection is possible. Csdpfx As Adt H Tsktjri

Condition: repair required (used), Year of construction: 1972, machine/vehicle number: 611, functionality: limited functionality, pressing force: 100 t, For sale is a Hans Schön hydraulic press with 100 ton capacity. It was last used approximately 7 years ago. At that time, the machine had an issue with a hydraulic valve, which was not repaired since the press was no longer needed. Otherwise, the machine ran flawlessly until then. The press does not have UVV (accident prevention certification)! Cedpfxex Ehlcs Aktjri

Condition: excellent (used), Year of construction: 1990, Force 25tons Throat 160mm Daylight 500mm Table size 650x650mm Ram size round 140mm Stroke 130mm requested power 4 KW Csdpfxefcw Apj Aktsri Weight 2000Kg height 2100mm width 1100mm depth 1500mm

Condition: used, Double-column hydraulic press SCHÖN, type UTE 100 Special Special press with additional side press cylinders – vertical and horizontal, each with 100 tons capacity. Machine no. 1800, year of construction 1977 Rebuilt according to UVV standards in 09/1991 by Livenbrück Vertical pressure force: 100 tons Vertical ram stroke: 150 mm Vertical installation height: 375 mm (400 mm) Horizontal pressure force: 100 tons Horizontal ram stroke: 60 mm Horizontal installation width: 600 mm Table surface: 600 x 480 mm Table opening: Ø 100 mm Ram surface: Ø 200 mm (vertical and horizontal) Piston rod: Ø approx. 240 mm (vertical and horizontal) Clamping pin bore: Ø 50 mm Ram stroke: 150 mm Installation height: max. 435 mm Table height above floor: 820 mm Oil tank capacity: approx. 375 liters Motor power: 15 kW Mains connection: 400 volts, 50 Hz - Column guidance via the large piston with anti-rotation device - Stepless press force adjustment - Adjustable pressure holding time for vertical and horizontal - Switching for working movement: vertical only or combined vertical and horizontal Codpfx Akjz A R Irotori - 2-hand operation for stroke release - Control cabinet located on the side, fixed to the machine - Light curtain SICK, type LVU 306, for safety operation Space required for the press L x W x H: 2050 x 1550 x 2230 mm Weight: approx. 5 tons Good condition

Year of construction: 2000, condition: excellent (used), Force: 300 tons Windows: Yes Daylight: 1000mm Table: 1800x1000mm Ram: 1800x1000mm Stroke: 600mm Weight: 43 tons Height: 4700mm Siemens S7 control Floorstanding Sick lightguards Crsdpfx Aogbvkvektji Die cushion: 200mm stroke

Condition: used, Single-column hydraulic press SCHÖN type FES / C 7 Machine no. No. 4281 Year of construction 1995 Pressure force 7 ton. throat 170 mm Projection round cycle station 60 mm Table size 310 x 200 mm Rotary indexing table Ø 400 mm, with 12 indexing stations Plunger surface approx. Ø 100 mm Plunger plate 315 x 200 x 35 mm Credsr I E Itspfx Aktei Ram stroke 100 mm Installation height rotary table - ram plate max. 130 mm Table height above floor 890 mm Ram speed rapid traverse downwards approx. 300 mm/sec. Ram speed rapid traverse upwards approx. 300 mm/sec. Ram speed Working speed approx. 30 mm/sec. Drive power 1.5 kW Mains connection 380 Volt, 50 Hz Tank capacity approx. 50 liters hydraulic oil - Rotary indexing control via SIEMENS S7- 1200 - GECHTER pneumatic rotary indexing table with 12 indexing stations - Mechanically adjustable fixed stop - Adjustable pressure holding time in the UT - electrical 2- manual operation Space requirement L x W x H 1450 x 850 x 1900 mm weight 700 kg good condition

Condition: used, Double-column Hydraulic Press SCHÖN Type SH 25 Machine No. 2440 Year of manufacture: 1979 Press force: 25 tons Column spacing: 630 mm Lateral passage between columns: 120 mm Table area: 580 x 320 mm Ram area: 360 x 220 mm Clamping pin hole: Ø 40 mm Maximum ram stroke: 100 mm Maximum installation height: 270 mm Credjyz Dr Tspfx Aktsi Table height above floor: 900 mm Motor power: 7.5 kW Power supply: 380 Volt, 50 Hz - Main cylinder overhauled in 2025 - SICK LUV 206 safety light curtain - Two-hand control - Stroke counter - Rapid stroke and working stroke - Stroke limitation dependent on pressure or position - Mechanically adjustable fixed stop - Press force regulation - Press time extension 1–10 s (pressure holding time) - No operating manual and no wiring diagrams Required space (L x W x H): 1450 x 1100 x 2200 mm Weight: 1200 kg In good condition

Condition: good (used), Year of construction: 1978, Hydraulic press, two-column press, oil hydraulic press, hydraulic press, high-speed press, high-speed hydraulic press -Manufacturer: Hans Schoen, Hydraulic press type SH 100 Cjdpoyzd I Ujfx Aktori -Pressing force: 100 tons -Motor: 11 kW -Clamping table: 580 x 440 mm / Bore Ø 150 mm -Max. insertion height: 435 mm -Projection: 650 mm -Max. stroke: 150 mm -Hole: Ø 50 mm -Documents: Operating instructions/circuit diagram -Dimensions: 1640/1300/H2650 mm -Weight: 4440 kg

Year of construction: 1981, condition: ready for operation (used), Press force: 650kN, Stroke: 150mm, Pressure piston diameter: 190mm, Column spacing X/Y: 950mm/460mm, Installation height: 500mm, Table dimensions X/Y: 900mm/870mm, max. stroke: 150mm, Operating pressure: 200bar, Machine dimensions X/Y/Z: approx. 1500mm/1750mm/2400mm, Weight: approx. 3000kg. Documentation available. An on site inspection is possible. Cedpfxsyq R D Hj Aktjri

Condition: good (used), Year of construction: 2000, table width: 1,000 mm, table length: 1,800 mm, ram plate width: 600 mm, total length: 25,000 mm, total width: 27,000 mm, total height: 47,000 mm, overall weight: 43,000 kg, die cushion stroke: 200 mm, Siemens Simatic OP 27 control system Crsdpfx Aketiwgistji Light barrier Sick Separate control cabinet Ritta Side passages Ground level installation

Year of construction: 1990, condition: used, pressure 100 t throat 275 mm stroke 150 mm table surface area 860x550 mm ram surface 600x400 mm table height 810 mm tool hole in ram Ø 50 mm Crodpfx Akslp U Tustoi dayligth max. 475 mm weight of the machine ca. 7 t dimensions of the machine ca. BxTxH 2000x2500x3300 mm

Condition: ready for operation (used), Year of construction: 1998, power: 37 kW (50.31 HP), pressing force: 250 t, stroke length: 150 mm, table width: 900 mm, table length: 1,000 mm, overall weight: 16,000 kg, Very nice and well maintained hydraulic press. 250 tons pressing force. Approximate dimensions: Crodpfjry Trpex Aktoi H: 380 cm. W: 200 cm. L: 200 cm. Weight: 16,000 kg. Can be loaded by crane on collection against payment. Transportation can be arranged. Sold for customers. Location: DK-7600 Struer. Make an appointment for a demonstration.
