Used Vbmt Turning Plate for sale (17,909)

Condition: excellent (used), Year of construction: 2007, operating hours: 10,066 h, functionality: fully functional, CTX 410 V3 2-axis universal lathe with HEIDENHAIN Plus iT CNC control and SlimLinePanel - C-axis - Driven tools - AC main drive 21 kW, 240 Nm - Sauter disc turret - Partial hollow clamping device - Chip conveyor - Tailstock Turret disc with 12 tool stations, shank diameter 40 mm according to DIN 69880 instead of diameter 30 mm Bar machining package consisting of: - Hydraulic hollow clamping device Pull tube inner dia. max. 66 mm - Workpiece removal unit, pneumatically swiveling Crodpfx Abeyx Ax Te Uoa for parts Ø65 mm x 120 mm long, - 4-color signal light (Note: Additional connection for bar feeder or bar loading magazine required)

Year of construction: 2024, condition: new, Mobile panel transport cart New demo unit, year of manufacture: 2024 - Stacking of panel heights up to 1,600 mm, electrically operated - Tilt angle forward/backward 100°, electrically operated - Head joint rotation angle CW/CCW 180° Codpfx Asw I Upnsb Uora - Head joint rotation angle: 360° - Load capacity 120 kg - Panel sizes up to 2,100 x 3,200 mm - Total height 2,090 mm - With 6 high-performance suction pads, width adjustable The Mobilifter ML-120 consists of: - A mobile chassis - An electric lifting and tilting system - An automatic vacuum unit - A wireless electric control - Weight 170 kg Availability: short notice Location: Flörsheim

Condition: used, Hydraulic Guillotine Shear STEINER Type HTS 30/20 R Machine No. 315 Year of manufacture: 1982 Cutting length: 3050 mm Cutting thickness: 20 mm Backgauge: 800 mm, motorized Motor power: approx. 30 kW Power supply: 400 Volts, 50 Hz - Backgauge with ELGO positioning control - Backgauge adjustment via ball screws - SICK safety light curtain at the front as reach-in protection - 3 material support arms with ball transfers - Electric foot switch - Spare blade - Oil cooler with air heat exchanger - Very robust machine with extremely solid construction Machine footprint (L x W x H): 4650 x 2610 x 3200 mm Machine weight: 27,000 kg Transport dimensions (base machine) (L x W x H): 4650 x 2610 x 3200 mm Transport dimensions (additional) (L x W x H): 3500 x 2450 x 1400 mm Total weight: 27,000 kg Good condition Machine can be inspected at our warehouse in 37235 Hessisch Lichtenau, test cuts possible. Cjdpfx Absd Hxx As Ujra Currently, the hold-down devices are being resealed; the resulting price adjustment will be made in the coming days.

Condition: good (used), Year of construction: 2015, Main and counter spindle 3 turrets Backside machining Crsdjyx Tk Tspfx Ab Uea Fire extinguishing system Kraft & Bauer High-pressure system Büchele Bar feeder FMB Turbo 2-20

Condition: excellent (used), Year of construction: 2005, turning length: 1,585 mm, turning diameter: 760 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 630 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,585 mm, bar passage: 80 mm, Max. turning Ø: 760mm Crodpfx Ajvgcpveb Usa X-axis: 630mm Y-axis: 230mm Z-Axis: 1585mm B Axis: 225° Spindle bore: 80mm Speed range: 6000Rpm B-Axis Speedranges:12000Rpm B-Axis power: 19kW Length: 7000mm Width: 2700mm Height: 2800mm Weight: 14500kg

Year of construction: 2007, condition: good (used), Make: Okuma Type: LVT-300 M Control: OSP-P200L Year: 2007 X Travel 210 Z Travel 360 Power 22 kW Driven live tools 7.5 kw / 3000 Rpm In feed table Out feed table Package jaws Package tool holders Chip conveyor Coolant system 9 Bar Grundfos Specifications Metric US Standard Max. turning Ø 280 mm Table Ø 210 mm Horizontal movement support 360 mm ATC / revolver 12 Speeds / ranges 4000 Rpm Cjdpjku Aaajfx Ab Usra C-Axis 360000 ° Dimensions (Estimate) There are no dimensions for this machine (yet). Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 1991, condition: good (used), Make: HAEUSLER Type: VRM-HY Year: 1991 Specifications Metric US Standard Rolling width 3000 mm Rolling thickness 3x toproll Ø 120 mm Rolling thickness 5x toproll Ø 150 mm Rolling thickness prebending Crodpfxokwcc Ne Ab Usa 100 mm Top Roll Ø 910 + 820 + 740 mm Bottom Roll Ø 940 mm Side roll Ø 780 mm Number of rolls 4 Rolling speed 2 + 4 Adjustiment lower roll 200 mm/min. Adjustment side rolls 500 mm/min. Number of driven rolls 2 Power 300 kW Dimensions (Estimate) Length 8000 mm Width 5400 mm Height 5400 mm Weight 290000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Share on

Year of construction: 1980, condition: good (used), Make: HAEUSLER Type: VRM-HY Year: 1980 Specifications Metric US Standard Rolling width 3000 mm Rolling thickness 3x toproll Ø 130 mm Rolling thickness 5x toproll Ø 140 mm Rolling thickness prebending Csdpfx Askvm Szob Usra 120 mm Top Roll Ø 950 mm Bottom Roll Ø 850 mm Side roll Ø 180 mm Number of rolls 4 Rolling speed 2 + 4 Adjustiment lower roll 0 - 400 mm/min. Adjustment side rolls 0 - 400 mm/min. Number of driven rolls 2 Power 132 + 37 kW Dimensions (Estimate) Length 12000 mm Width 5440 mm Height 5650 mm Weight 286000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 1978, condition: good (used), Make: HAEUSLER Type: VRM-HY Year: 1978 Specifications Metric US Standard Rolling width Crjdokvm S Nopfx Ab Uea 3050 mm Rolling thickness 3x toproll Ø 60 mm Rolling thickness 5x toproll Ø 70 mm Rolling thickness prebending 50 mm Top Roll Ø 630 mm Bottom Roll Ø 600 mm Side roll Ø 500 mm Number of rolls 4 Rolling speed 0 - 5 Adjustiment lower roll 200 mm/min. Adjustment side rolls 200 mm/min. Number of driven rolls 2 Power 120 kW Dimensions (Estimate) Length 5790 mm Width 4200 mm Height 4200 mm Weight 85000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, Time recording from Feb. 2025 Operating hours = 16085 h Main spindle = 616 h Milling spindle = 369 h CNC control Siemens Sinumerik Si 840D sl Max. center distance 4500 mm Working height 1375 mm X-axis travel -15 +725 mm Y-axis travel -245 + 4756 mm Swing diameter over cross slide 780 mm Swing diameter over bed 820 mm C-axis, smallest increment +/-0.001° Main spindle A15 with BVG; 3135 N;/2000 rpm Spindle head DIN 55026 Form A 15 Max. speed 3000 rpm Max. torque 3135 Nm Drilling/milling unit Codpfx Aeyxp H Dob Ujra Milling power (40/100% duty cycle) 36.5/29.8 kW Torque up to 1110 rpm (40/100% duty cycle) 328/261 Nm Max. spindle speed 5000 rpm Swivel range (B-axis) -105 +95° Vertical travel (Y-axis) -250 +250 mm SR5 steady rest with eccentric fine adjustment 45–310 mm C8 tool system Tool magazine (2 magazines) 144 Tailstock Quad diameter MK6 180 mm Quad stroke 170 mm Quad force (adjustable) 5–28 kN Quad fine adjustment +/- 0.15 mm Optional equipment Coolant tank capacity 990 l Workpiece measurement MC (Reinshaw) Software Gear hobbing &more

Condition: good (used), NC horizontal boring mill with point-to-point control HEIDENHAIN TNC 124 Year of manufacture: 1982 / retrofitted with control in 1997 Spindle diameter: 150 mm Spindle taper: ISO 50 Travel distances: X-axis, table (cross): 3000 mm Y-axis, spindle head (vertical): 2000 mm W-axis, quill travel: 1100 mm Codpfx Aboyxp D Ne Uora Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), NC plate boring mill with point-to-point and linear HEIDENHAIN TNC 124 control Year of manufacture: 1975 / retrofitted with CNC control in 1997 Spindle diameter: 130 mm Spindle taper: ISO 50 T-slot clamping surface: 6000 x 3000 mm Travel distances: X-axis, table (cross): 6000 mm Y-axis, spindle head (vertical): 3000 mm W-axis, quill travel: 1100 mm Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 Credjyxp Dpspfx Ab Uja DE - 44143 Dortmund - Wambel / Germany

Year of construction: 2026, condition: new, NEW - - Ideal for removing plates from your standing plate storage. - For in-plant transport of the plates to the standing or lying panel dividing saw. - The steplessly height-adjustable support surface can be exactly to the height of your panel saw. height of your panel saw. - Panels weighing up to max. 250 kg can be transported or transported or swiveled by one operator alone. Technical data: Support height - standing: approx. 120 - 340 mm - lying: approx. 890 - 1200 mm max. plate size: 5200 × 2100 mm load capacity: 250 kg Location: ex stock 54634 Bitburg - immediately available- Crjdpfx Aod Tyaasb Uoa Will be shipped for 90,- Euro net within Germany

Condition: good (used), Year of construction: 2002, Control: FANUC 18i-T Turning diameter: 32 mm Turning length: 120 mm Max. main spindle speed: 8,000 rpm Max. sub spindle speed: 8,000 rpm SLIDE 1 X-axis travel 1: 65 mm Y-axis travel 1: 350 mm Tool stations: 6 / 4 positions Fixed stations: 6 Driven stations: 4 SLIDE 2 X-axis travel 2: 265 mm Z-axis travel 2: 320 mm Tool stations: 2 / 3 positions Fixed stations: 2 Driven stations: 3 Y2 SLIDE Tool stations: 3 / 2 / 2 positions External machining: 3 Internal machining: 2 Credjyxpqvspfx Ab Uja Driven stations: 2 Weight: 4,500 kg Bar feeder: IEMCA BOSS

Condition: ready for operation (used), Year of construction: 2000, operating hours: 21,269 h, functionality: fully functional, machine/vehicle number: 0082, turning length: 1,500 mm, turning diameter: 580 mm, travel distance X-axis: 598 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,660 mm, TECHNICAL DETAILS Travel X-axis: 598 mm Travel Y-axis: 230 mm Travel Z-axis: 1,660 mm Max. turning diameter: 580 mm Turning length: 1,500 mm Swing diameter over bed: 610 mm Swing diameter over cross slide: 580 mm Crsdpfsyxmyujx Ab Uja Main Spindle Main spindle speed range: 12 - 2,800 rpm Spindle bearing diameter: 150 mm Spindle bore: 110 mm Spindle nose: JIS A2-11 Main spindle drive power: 37 (30) kW C-axis accuracy: 0.001° Rapid traverse X/Y: 12,000 mm/min Rapid traverse Z: 20,000 mm/min Rapid traverse C: 100 rpm Cutting feed rate: 0.001 - 1,000 mm/rev Tool Turret Type: H2 ATC Number of tool stations: 2 (1x L-Tool / 1x M-Tool) positions Driven stations: stepless Speed range - driven tool stations: 40 - 3,000 rpm Tool shank height: 25 mm Boring bar holder diameter: 50 mm Tailstock Quill diameter: 120 mm Quill stroke: 170 mm Tailstock taper: MT 5 Tool Magazine Number of tool stations: 50 positions Tool holder: MAS BT 50 Max. tool diameter: 170 mm Max. tool length: 350 mm Max. tool weight: 20 kg Magazine drive: 3.2 kW MACHINE DETAILS Total power requirement: 53 kVA Dimensions & Weight Space requirement: 6.0 x 3.2 x 3.0 m Machine weight: 18.5 t Operating Hours Main switch on-hours: 79,607 h NC operating hours: 27,814 h Main spindle hours: 21,269 h EQUIPMENT Chip conveyor Central coolant system High-pressure coolant system, 20 bar Tailstock Signal lamp C-axis Y-axis Hydraulic unit Steady rest Various tool holders (44 pcs.) Three-jaw chuck Schunk - ROTA NC 400-120 Electronic handwheel

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, spindle speed (max.): 7,000 rpm, spindle bore: 42 mm, controller model: Siemens 840 D - SL, counter spindle speed (max.): 7,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Bar diameter: 42 mm Travel X-axis 1/2/3: 180 mm Travel Y-axis 1/3: ±45 mm Travel Z-axis 1/2/3: 704 / 620 / 704 mm Crjdpfx Aboyxmnxo Uja Main spindle Speed: 7,000 rpm Drive power: 22 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Counter spindle Speed: 7,000 rpm Drive power: 19 kW / 16.5 kW Spindle torque: 128 Nm / 100 Nm Spindle bore: 42 mm C-axis: 0.001° Spindle nose: 110 mm Tool turret Number of turrets: 2 + 1 pos Number of tool stations: 3 x 12 pos Number of live tool stations: 3 x 12 pos Rotational speed of driven tools: 8,000 rpm Power: 11.4 kW / 2.3 kW Torque: 26 Nm / 14 Nm Tool holder: VDI 25 Rapid traverse (X / Y / Z): 30 m/min Acceleration: 0.5 g MACHINE DETAILS Control: Siemens 840 D - SL Total power requirement: 60 kW Dimensions & Weight Space requirement: approx. 8.2 x 3.3 x 2.5 m Machine weight: approx. 7.5 t EQUIPMENT Documentation Knoll chip conveyor High-pressure coolant (14 bar) Parts catcher Counter spindle Interface for bar feeder Spinner Barload BL 0146 bar loading magazine C-axis: 2x 0.001° Hydraulic unit Hainbuch collet chuck Y-axis: 2x ±45 mm Various tool holders Various collets Tool measuring arm

Condition: new, Year of construction: 2025, The machine on offer is a new stock machine. We will be happy to provide you with a suitable quotation. Credpfoychtpjx Ab Uea

Condition: new, Year of construction: 2022, functionality: fully functional, The tool holder is completely new and still in its original packaging. There is a second one, which is used but shows no signs of wear. (see picture) Spindle MTSK-40 Gear ratio 1:1 Max rpm. 6000 Maximum torque [Nm] 50 External cooling Yes Internal cooling Yes Internal cooling P=30 BAR Cjdpjuzwutofx Ab Uera The holder can also be used for the following CMZ machines. CMZ - TA15M/Y/MS/MY/YS 15 PCS. CMZ - TX52 Y2 QUATTRO CMZ - TX52 Y2 TWIN CMZ - TX66 Y2 QUATTRO CMZ - TX66 Y2 TWIN CMZ - TX66 Y3 CMZ - TA20M/Y/MS/MY/YS 15 PCS. CMZ - TA25M/Y/MS/MY/YS 15 PCS. CMZ - TA30M/Y/MS/MY/YS 15 PCS. CMZ - TTL 52 CMZ - TTL 66 CMZ - TX52 Y3

Condition: new, Year of construction: 2025, operating hours: 10 h, functionality: fully functional, turning diameter over cross slide: 38 mm, spindle speed (max.): 6,500 rpm, spindle bore: 42 mm, rotational speed (max.): 6,500 rpm, power: 23 kW (31.27 HP), The machine on offer is a new stock machine. We are happy to prepare a customized machine offer for you. Csdpoychqusfx Ab Uera

Condition: new, sheet width 2550 mm 4 mm sheet thickness for stainless steel 2 mm rear stop 750 mm total power requirement 7,5 kW Crodpfoyyc Azsx Ab Uja weight of the machine ca. 3050 kg dimensions 3300 x 2230 x 1360 mm Standard equipment: - All-steel welded construction with static and dynamic frame rigidity frame rigidity - Direct drive with brake motor - Specially alloyed cutting blades - 750 mm motorized, digitally adjusted backgauge with ball screws recirculating ball screws - Manual blade gap adjustment system - Mechanical sheet clamping system with plastic base - Work table with insert plates - foot switch for single and repeat cutting cycles - 1 x squaring arm 1000 mm long with metric scale - 2 x 800 mm front material support arms - Front stop - Finger protection - front and rear covers - Rear light guards - CE declaration of conformity Youtube video link: ?v=pCuKwtBIQto&ab_channel=BaestleinGmbH

Condition: used, Year of construction: 1995, sheet width 6500 mm plate thickness 3 mm back stop - adjustable 1000 mm dimensions 7300x2400x2300 mm Codpfx Abjyyc Aus Uora Weight 20000 kg Equipment/accessories: - 1 x set of knives

Condition: good (used), Year of construction: 2008, functionality: fully functional, Okuma Multus B300-W 6-axis turning and milling center - Okuma OSP P200L - Year 2008 Crjdpfx Ajyg Rf Neb Uea - Cutting time: 10,500 h - H1 milling spindle: 6,000 rpm - Main spindle: 3,800 rpm, Rota NC 315-86 - Counter spindle: 5,000 rpm - ATC 60 system HSKA-63 (60 tools) - Geometry: very good - Marpos tool sensor

Condition: good (used), Year of construction: 1999, functionality: fully functional, Okuma Macturn 30 1SW 1000, OSP 7000M, chip conveyor, ATC 24 BT40, coolant pump 8 bar, gear milling option, approx. 12,500 spindle hours, HS Big Bore, GS Standard Bore Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, a tour of our showroom (30 Okuma machines) including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. Bjsvkhv0lno Credpfx Abevta Rks Usa We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage.

Condition: good (used), Year of construction: 2001, functionality: fully functional, spindle speed (min.): 5,000 rpm, travel distance X-axis: 700 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 700 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 25 rpm, type of input current: three-phase, Equipment: rotational speed infinitely variable, TECHNICAL DETAILS 2x Pallets 500 x 500 mm Codpfsyrgzkex Ab Usra Travel distances X: 700 mm, Y: 800 mm, Z: 700 mm Table size: 500 mm x 500 mm Rotary table/B-axis: indexed in 1° steps, 360 positions Table load capacity: 800 kg Spindle speed: 5,000 rpm Distance spindle nose to table surface: 150 mm - 850 mm Tool holder: MAS BT 50 Tool magazine (ATC): 60 positions, chain magazine Maximum tool length: 450 mm MACHINE DETAILS Control: CNC OSP 100M Dimensions & Weight Machine weight: 21,000 kg Dimensions (L x W x H): 5,500 x 3,160 x 3,300 mm Spindle hours: 18,500 EQUIPMENT Chip conveyor, coolant system, and pocket filter system for internal cooling

Condition: good (used), Year of construction: 1998, functionality: fully functional, OKUMA LCC15, OSP 700L, collet chuck, chip conveyor, coolant pump, touch setter, chip conveyor, parts catcher, V12 turret direct mounting. Cjdpfxsyq S E Se Ab Ujra A very compact and efficient machine for bar stock workpieces. * The LNS bar feeder is included free of charge with the machine, but it is not part of the sale and must be electronically serviced by an LNS technician.
