Gear Grinding Machine

REISHAUER RZ 150

Condition: used, Year of construction: 2005, Reishauer RZ150 gear grinding machine Bsdpfsxz E Srex Afpelc

Condition: good (used), Year of construction: 2004, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence Bodpsul Efmsfx Afpolc - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: good (used), functionality: fully functional, turning diameter: 655 mm, turning diameter over bed slide: 655 mm, turning length: 5,000 mm, Swing diameter over bed 655 mm Swing diameter over support 390 mm Turning length 5000 mm Bedpfx Aew N D T Sofpjlc Spindle bore 82 mm Spindle speed 9-1120 rpm Feed rate 0.049-3 mm/rev Total connected load 12 kW

Condition: good (used), Year of construction: 1989, total height: 6,450 mm, For sale Beche short-stroke die hammer KGH 4B. Machine weight 65 t Working capacity 40 kJ max. impact frequency 98 min Bljdsrt Uc Eopfx Afpec max. usable number of blows 41 min max. bear stroke 790 mm Machine is disassembled Technical data on request

Condition: good (used), Year of construction: 1980, travel distance X-axis: 1,985 mm, travel distance Y-axis: 1,620 mm, travel distance Z-axis: 1,330 mm, table load: 10,000 kg, table length: 1,700 mm, table width: 1,520 mm, incl. universal milling head incl. spindle extension incl. angle plate height 1400 mm incl. digital read out sytem X - Travel: 1985mm Y - Travel: 1620mm Z - Travel: 1330mm W - Travel: 410mm Table Length: 1700mm Bjdswrn Imspfx Afpjlc Table Width: 1520mm Table load: 10000 Speeds / ranges:2,5 - 1000Rpm Spindle Taper: iso 50ISO/Bt/Mk Length: 460mm Width: 4800mm Height: 6000mm Weight: 25000kg

Condition: used, x-travel 1050 mm y-travel 600 mm Bjdpsvnh Umofx Afpslc z-travel 600 mm control Fanuc weight of the machine ca. 7200 kg

Condition: new, Capacity, Ø mm ----- 57 x 2 Radius, min/max ----- 20/250 Radius difference ----- 50/230 Bending speed/repeatability ----- 230º/s. ±0.05 Length of mandrel ----- 1 000-∞ Weight ----- 5000kg Machine dimensions ----- 3.0 x 1.6 x 1.5 Tube rotation ----- 0-360°/sec Length feeding ----- 0-1800 mm/sec Degree of tolerance ----- 0,05°/mm Standard components conform to VDMA, ISO and DIN standards OPTIONS * Online connection with CAD system and measuring machine * Automatic tube magazine with free programmable robot or loading arm * Weld seam detector and tube positioner electromagnetic or optic detection Bledpfx Ajga T E Ajfpoc * Free radius bending * Simulation/Collision Control * Bed length extension

Condition: excellent (used), functionality: fully functional, Swing over bed: 1290mm Swing over cross slide: 910mm Swing in gap (l:500mm): 1580mm Center distance: 6000mm Spindlebore: 155mm Spindle speed: 6-800rpm Spindle nose: ASA A2 11" Workpiece between centers: 20 tons Taper in tailstock: Mk6 Longd.feed: 0.045-5mm/r Crossfeed: 0.0220-1.5mm/r Thread metric: 0.5-56 Thread's modulus: 0.25-28 Threads whitworth: 1/2-84/ " Bljdpfxjwc Nzpo Afpjc Spindle motor: 30 hp Manufacturing year: 1971 Length: 9500mm Width: 2000mm Height: 1600mm Weight: 13400kg Sony DRO cross slide 3 pcs. Steady rests Face plate 4-jaw chuck Hardened guideways Power on topslide

Condition: good (used), Year of construction: 2000, machine/vehicle number: 13639, Control Heidenhain X-Way 1,200 mm Y-way 800 mm Z-way 500 mm Main spindle: Speed 16,000 rpm Drive power - main spindle 17 kW Spindle Tool holder Type HSK63 Spindle diameter in front. Bearing 70 mm Upgraded Tool changer Size: 100 Swing round table: Round table diameter 800 mm Swivel range A: -15 / + 97° rotatable C: 360° max. table load approx. 1,000 kg max. tool diameter 80 mm max. tool byway. with free neighbor box. 125 mm max. tool length 300 mm max. tool weight 8 kg Feeds: Blodpfx Aoinh Rqofpec Rapid response ( X / Y / Z ) 30 m/min Total power requirement 31 kVA Machine weight 15 tons Space requirements approx. 6.0 x 5.0 x 3.6 m other equipment - Documentation - Chip conveyors - electronic heat compensation Y- + Z-axis

Year of construction: 1983, condition: excellent (used), machine/vehicle number: 03.2133, Arthur Klink - internal broaching machine (KOM 138) machine type: internal vertical hydraulic broaching machine manufacturer: Arthur Klink type: RISZ 16 x1250 x400 built in: 1983 stroke: 1250mm pulling force: 16.000KG Bjdod Nb A Njpfx Afpjlc working stations: 3 PCs drive: hydraulic system equipment: coolant system, magnetic chip conveyer remark: in an excellent condition, ready to use, perfect slides Optional accessories available on request: pulling head, pick up tool holder Information about us: we are specialized for second hand broaching machine and still have anytime about 80 pcs of used broaching machines in our stock, vertical and horizontal machines from 3000kg up 63.000kg pulling force and from 1000mm stroke up to 3500mm stroke
