Gearwheel hobbing machine vertical - wheel dia. 0-299mm for sale
Identified location: Ashburn (US) (Edit)
|
4
Zahnradabwälzfräsmaschine Pfauter P250 20-13-001
Lieferzeit: sofort
Nummer: 20-13-001
Maschinendaten
Baujahr: ca. 1965
L x B x H: ca. 1450 x 1100 x 1650 mm
Gewicht: ca. 2000 kg
Sehr Guter Allgemeinzustand
Technische Daten
Größter Werkstück Ø: ca. Ø 250 mm
Min. Modul: ca. 0,3
Max. Modul: ca. 4,5
Max. Fräser Ø: ca. Ø 190 mm
Antriebsleistung: ca. 3,0 kW
Zubehör
-Betriebsanleitung
-Kühlmitteleinrichtung
-Diverse Wechselräder
-Diverse Abwälzfräser
Khzbt0e2
-Diverse Spa... more
|
|
5
max. wheel diameter 1200 mm
gear width 1000 mm
max. module 22
min. module
Control Liebherr LH 90 GH
min. number of teeth 1
Chjzecxi
milling head -swivable +/- 45 °
milling cutter diameter 350 mm
cutter length max. 450 mm
spindle turning speed range 250 U/min
spindle motor 45 kW
milling spindle speeds 25 - 250 U/min
axial adjustment of the spindle slide 1200 mm
radial adjustment 900 mm
tailstock adjustment 800 mm
table diameter 1100 mm
table load 12,5 t
table hole 320 mm
total power requirem... more
|
|
5
1 x gear hobbing machine Pfauter P 2508 BJ 1962 was in operation/ no defects / no operating hours counter until disconnection
Pt2eda more
|
|
4
x-travel: 140 mm
y-travel: 50 mm
z-travel: 200 mm
spindle taper MT: MK4
inclination: 6° li/re °
revolution per minute tool : 100-500 U/min
work piece dimensiones: L:500 mm
workpiece dia.: 280 mm
feed:: 0,35-47 / 15step
tool taper: Dm=27 Passfeder
total power requirement: 3,7 kW
weight of the machine ca.: ca. 2,11 t
space requirements of the machine approx.: L:1,3xB:0,8xH:1,8 m
transport dimensions LxWxH: 1,4x0,9x1,8 m
milling tools max. diameter 100mm x 100 length
S8yj2qegk
roll diameter for int... more
|
|
5
CNC GEAR HOBBING.
Make : CIMA.
Model : CE 260
7 axis.
ALL MOTORS ARE SIEMENS.
CNC control : NUM 760
Max workpiece dia : 300 mm.
Max. hobbing module : 8.
Minimum number of teeth : 4
Max head adjustment : +- 45°
Tailstock travel : 250 mm.
Hob speed : 100-700 rpm.
Max. Worktable speed : 80 rpm.
Min distance between hob and worktable : 20 mm.
Max distance between table and work gear hobbing center : 290 mm.
Min distance between hobbing and work table axes : 125 mm.... more
|
|
6
HORIZONTAL -
ZAHNRADABWÄLZFRÄSMASCHINE WMW
ZFWZ 250 X 2,5 - 20-13-005
Lieferzeit: sofort
Nummer: 20-13-005
Hersteller: WMW
Typ: ZFWZ 250 x 2,5
Mum2o0
MASCHINENDATEN
Baujahr: ca. 1970
L x B x H: ca. 2000 x 1500 x 1700 mm
Gewicht: ca. 950 kg
Guter Allgemeinzustand
TECHNISCHE DATEN
Größter Werkstück Ø: ca. Ø 250 mm
Max. Radbreite: ca. 125 mm
Min. Modul: ca. 0,5
Max. Modul: ca. 2,5
Tischbohrung: MK 3
Abstand Fräser - Werkstück: ca. 11 - 160 mm
Drehzahlbereich: ca. 110 - 220 U/min
Max. Fräs... more
|
|
5
max. wheel diameter 80 mm
gear width 250 mm
max. module 3
min. module 0.5
control SIEMENS 840D
total power requirement kW
weight of the machine ca. 12 t
dimensions of the machine ca. 3 x 4 x 2,8 m
- CNC control SIEMENS 840D
Beomkryl2v more
|
|
3
max. workpiece diameter 125 mm
working diameter max. 115 mm
hobbing length 215 mm
Fn20gfx
total power requirement kW
weight of the machine ca. 6,8 t
dimensions of the machine ca. m
04/1997 more
|
|
5
Gear Hobbing Machine
Manufacturer: CUGIR / Romania
Type: FD 250
Y.o.m: 1983
Ctgvgxvw
Max. gear wheel diameter: 250 mm
Max. module: 6 mm
Axial stroke: 280 mm
Main motor power: 5,5 kw
Machine's net weight: 5400 kg
Accessories: as per attached pictures
Location: our warehouse near Oradea, in ROMANIA.
More details upon request.
More machines available in stock... more
|
|
|
|
3
Gear hobbing machine Gleason Pfauter P 60The machine is a dry hobbing machine with automatic ring loader.Technical data:Largest workpiece diameter 110 (115) mmLargest tool dimensions (diameter / toothed length) 65 / 140 mmLargest axial travel (Z-axis) 220 mmLargest radial travel (X-axis) 80 mmLargest tangential travel (Y-axis) 100 mmLargest milling head swivel angle ( A / -A) 45 / -115 °Milling cutter speeds (spindle S) 300 - 5.000 1/minWorkpiece speed range (C axis) 0 - 3.000 1/minLargest trave... more
|
|
5
max. wheel diameter 120 mm
gear width 250 mm
max. module 3
2rgpim
min. module 0,5
table diameter 145 mm
rotary table speeds infinitely variable 1 - 150 U/min
spindle motor 7,5 kW
milling-head swivable +/- +/- 45 °
tool taper HSK 50
tangential adjustment 108 mm
workpiece diameter 90 mm
workpiece length 200 mm
toolpiece turning speed range 10 - 2000 U/min
control MPST II
total power requirement 30 kVA
weight of the machine ca. 9 t
dimensions of the machine ca. 3,6 x 2,1 x 2,8 m
- CNC cont... more
|
|
3
max. workpiece diameter 125 mm
working diameter max. 115 mm
hobbing length 215 mm
total power requirement kW
weight of the machine ca. 6,8 t
dimensions of the machine ca. m
12/1996
Nn3nv more
|
|
5
-Basic versionLatest generation hobbing machineHigh accuracy with maximum power stability Machine bed StrukturTorque Motor C-axis (option)Automatic backlash compensation (B/C-axis)Chip conveyor, magneticAutomatic lubrication systemAutomatic door systemElectronic handwheel specificationMax. speed of the machine bed Workpiece Diameter - 200 mmTable Diameter - 200 mmMax. Module: Module - 4.0X-axis Travel - 250 mmA-axis Travel - 45°/-45°B-axis RPM - 1200 U/minC-axis RPM - 125 U/minZ-axis Travel - 25... more
|
|
4
Jelenia Góra, Poland
6957 km
1982
good (used)
Gear hobbing machine WMW VEB Modul ZFWZ 250/3 produced in 1982. The machine is hardly used.
The price of the machine: spindles and change wheels.
Technical data :
- module: 6 mm
Bex97vlctz
- milling diameter: 250 mm
- milling length: 275 mm
- dimensions: 3300 x 3475 x 2200 mm
- weight: 5000 + 800 + 900 kg
- installed power: 20 kW
- DTR - technical and operational documentation more
|
|
2
Wheel diameter max 160 mm,
Largest Module 3,
Fyfrazs9
Peak Angle 45 °,
Number of teeth: 6 – 160,
Table Diameter: 150 mm more
|
|
9
Technical data:Largest tip circledm: 710 mmTable diameter: 680 mmMax. Milling height: 400 mmNominal power at 60D: 15 kWTorque: 35-355 rpmDimension L-B-H in mm: 3915 x 2650 x 2410 mmMachine weight approx: 13500 kgOperating hours: no dataAccessories:Clamping mandrelsCooling plant with filterNormal accessories
Ihi2xlt more
|
|
6
max. wheel diameter 120 mm
gear width 250 mm
max. module 3
min. module 0,5
table diameter 145 mm
rotary table speeds infinitely variable 1 - 150 U/min
spindle motor 7,5 kW
milling-head swivable +/- +/- 45 °
tool taper HSK 50
tangential adjustment 108 mm
workpiece diameter 90 mm
workpiece length 200 mm
toolpiece turning speed range 150 - 1500 U/min
Beomm8by27
control MPST II
total power requirement 30 kVA
weight of the machine ca. 9 t
dimensions of the machine ca. 3,6 x 2,1 x 2,8 m
- CNC... more
|
|
6
Fellow gear shaper type Henschel-Röber, Henschel-Werke AG Kassel, machine with ease of use, with instruction manual use from module 0,5 to 6, with several milling cutters.
All information without guarantee. A demonstration is possible at any time in our showroom. The ad was translated automatically and it is possible that some translation errors have occurred.
2rjuhu more
|
|
5
GLEASON-PFAUTER type P200 CNC Gear hobbing machine - 6 axis
Max. gear wheel diameter: 200 mm
Max. module: 5 mm
Max. gear width: 220 mm
SIEMENS SINUMERIK 840 C CNC control
2rf8fq
with pneumatic loading unit.
The machine is in excellent working condition.
More details upon request! more
|
|
4
Jelenia Góra, Poland
6957 km
good (used)
The spherical roller milling machine WMW MODUL ZFWZ 250 / 5N was manufactured in 1977 in Germany.
Technical parameters :
- maximum milling diameter: 250 mm
Beyaa8iaqe
- maximum module: 5 mm more
|
|
2
CNC-Gear Hobbing Machine
manufacturer GLEASON PFAUTER
type Genesis 130 H
control SIEMENS 840D
built 2006
working range
max. work piece diameter 130 mm
max. radial travel (X-Axis) 160 mm
max. tangential travel (Y-Axis) 220 mm
max. axial travel (Z-Axis) 350 mm
max. travel counter support (Z4-Axis) 350 mm
milling head swivelling angle +/- 45 deg
workpiece table
outer diameter 200 mm
clamping diameter 150 mm
inner bore 45 mm
max. table speed 1.000 1/min
milling head
power 11,5 kW
max... more
|
|
7
Manufacturing origin Swiss
Netweight 150 kg
Custom position 8462.21 30
Wn7hrnk7
TECHNICAL DATA
Pivot dia. 0.05 – 2 mm
Pivot length up to 8 mm
Shoulder distance up to 25 mm
Max. blank length approx. 40 mm
Burnishing wheel 62 mm
errors and omissions excepted data given without obligation more
|
|
7
Wheel width: 250 mm
Module-max 6
Workpiece diameter: 400 mm
Axial substalls: 0.1-10 mm/U
Machine weight about 5500 kg
Facilities:
-Tool recordings
-Alternating wheels
Beut93atfu
-Achsmotor has been replaced more
|
|
10
Gear hobbing machine type PE 150 CNC
Fully functional machine - as you can see in the video.
With tail stock, loading unit and documentation.
max. diameter 150 mm
max. module 3 mm
gear width 200 mm
with BOSCH CC300M control.
H2lk3wt
Very good machine, ready for operation.
Location: our warehouse in Romania.
More details upon request. more
|
|
5
Jelenia Góra, Poland
6957 km
good (used)
Gear Hobbing Machine WMW MODUL ZFWZ 160/3 produced in 1971 in Germany.
Gruf3l9
Technical parameters :
- maximum milling diameter: 160 mm
- maximum module: 3 mm more
|
|
6
Code 151301
DESCRIPTION Gear Hobber Ø 250 x modul 6
Make Modul
Model ZFWZ 250/3
Serial number 112 625
Year ± 1983
Ma. Workpiece diameter 250 mm
Max. modul 6
Yfamvg2bs
Max. axialmovement 275 mm
Max. tangential movement 100 mm
Max. gearangle setting 45 degrees
Max. diam. millingcutter 145 mm
Max. millingcutter length 170 mm
Diameter clampingtable 275 mm
Diameter tablcenter positioning 200 mm
Distance millingcutter to clampingsurface min/max. 195 – 470 mm
Distance middle mil... more
|
|
7
two auto cycle auto hob shift
auto hydraulic support lift
support lift long size
Pt0y8y
hob spindle speed 160~530
spindle taper NT40
Main motor 5.5kw
machine weight 6300kg more
|
|
6
HOBBING MACHINE "WAHLI" TYPE W-91
Manufacturing origing Switzerland
Voltage 380/50/3
Net weight 680 kg
Dimensions 720/765/1445 mm
Customs position 8459.2930
TECHNICAL DATA
Max. distance between adjustable drive arbors 65 mm
Max. distance between special drive arbors 90 mm
Max. hobbed length, adjustable over 60 mm 40 mm
Max. component diameter, with dia. 24 mm 50 mm
Largest module 1,5
Number of teeth cut 6-390
Number of teeth cut, with special dividing drive 3-5
Travel of cutter head,includ... more
|
|
8
Gear Hobbing Machine WM R2-4SP
SKU: WEB-1229
Xxiynjtw
For all other inquiries you can freely contact us. more
|
|
2
Porcia, Italy
7026 km
1970
ready for operation (used)
Teeth cylindrical and helical gears
Be89i2rmzh more
|
|
6
Code 151300
DESCRIPTION Gear Hobber Ø 250 x modul 6
Make Modul
Model ZFWZ 250/5
Serial number 113 921
Year 1990 ( 1991 in use )
Ma. Workpiece diameter 250 mm
Max. modul 6
Max. axialmovement 275 mm
Max. tangential movement 100 mm
Max. gearangle setting 45 degrees
Max. diam. millingcutter 145 mm
Max. millingcutter length 170 mm
Foifj720q
Diameter clampingtable 275 mm
Diameter tablcenter positioning 200 mm
Distance millingcutter to clampingsurface min/max. 195 – 470 mm
Dista... more
|
|
5
Max workpiece dia 150φ
Max pith module4
Axial feed travel 400mm
max helix angle ±45°
Max hob shift travel 150、
center distance between hob&table 15~150mm
Teikncg
table top dia 190
hob spindle RPM 100~850rpm
FANUC 15M
machine weight 7000kg more
|
|
6
HOBBING MACHINE "WAHLI" TYPE W-92
Manufacturing origin Swiss
Voltage 380/50/3
Netweight 350 kg
Dimensions 630x530x1350 mm
Customs position 8459.2930
TECHNICAL DATA
Distance between centres 0-35 mm
Max. travel of tailstock spindle 10 mm
Max. displacement of tailstock 10 mm
Tailstock vertical adjustment +/- 0,05 mm
Max. dive hobbing stroke 5 mm
Max. hobbed length, adjustable over 35 mm range 15 mm
Axial adjustment range of head and tailstock spindles 10 mm
Max. hobbed diameter with dia. 24 mm ... more
|
|
5
Max workpiece dia150φ
Max pitch module4
Axial feed travel 400mm
P7jvof
max helix angle ±45°
Max hob shift travel 150
center distance between hob&table 15~150mm
table top dia 190
hob spindle RPM 100~1330rpm
FANUC 18i MB more
|
|
6
HOBBING MACHINE "WAHLI" TYPE W-90
ratio 1:4, oil circulation spindle
2i2voydle
Manufacturing origin Switzerland
Voltage 380 / 50 / 3
Netweight 445 kg
Dimensions 730x780x1380 mm
TECHNICAL DATA
Maximum distance between centres 80 mm
Maximum hobbed lenght 50 mm
Maximum component diam., with 24 mm hob 36 mm
Largest module 1
Number of teeth cut : with ratio 1: 4 6-100
with ratio 1:10 6-200
Full set of change wheels : with ratio 1: 4 64 wheels
with ratio 1:10 45 wheels
Total travel of cutter ... more
|
|
|
Didn't find what you were looking for? Please contact our partners for this category :
Dealer for Gear cutting machines
Dealer for Gear cutting machines
