Used Gear Honing Machine for sale (68,867)

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25653, Equipped with: -Automatic Central Lubrication System -Machine Guard -Indramat - MTX and Sercos CNC Control -The standard machine is equipped with CNC-control make Indramat - MTX and SERCOS-interface -Tool Dressing (Automatic dressing cycle of the dressing master and honing wheel tip diameter by a diamond coated dressing roll. The dressing cycle of workpieces can be pre-selected) -Electronic Indexing Unit -Operator and Maintenance Manual -All Electrical Drawings -PLC Language in English -Software and Hardware for Remote Diagnosis -High Precision Control of the Stock Allowance Material -Manual Loading on Spindle for Prototypes -Software for Infeed Optimized Cycle Type Reduction (Adaptive Honing) -Software for Vario Speed Dressing -Software for Calibration of Master Gears -Software for Timing Gears (including additional sensor for the hole of 4mm) -Software for Shortening of Workpiece Change-Over Time -Clamping Cylinder -RITTAL Cooling Unit -Lighting for Working Area -Installation of Vibration Detecting Sensors -Coolant Unit -Electrostatic Oil Mist Exhauster IFS With Rigid Piping -Internal Automation -Pallet Ring Conveyor System FlexLink (L-form shape see approved layout) -Parallel - Double Gripper -Pick and Placer Between Pallet Conveyor and Internal Loader -Extended Loading Length of the Pick and Placer Specifications: Bwodpfsw Iquyjx Afpsh Workpiece: -Part Diameter: 20-150 mm -Maximum Face Width: 70 mm -Part Weight: 20 kg -Number of Teeth: 6-150 -Module: 1-5 mm Workpiece Spindle: -Maximum Speed: 6000 1/min -Installed Power: Approx. 25 kW Tool: -OD of Honing Wheel: 270 mm -Widths of Honing Wheel: 20-70 mm -Honing Wheel Material: Ceramics Tool Spindle: -Maximum Speed: 2000 1/min -Installed Power: Approx. 25 kW Machine: -Total Connected Load, Approx: 70 kVA -Floor Space (w x l x H): -Total Weight, Approx: 11 Ton -Bosch Rexroth MTX Control CML 85 Longitudinal Slide, Z-Axis: -Linear Drive -Drive Torque: 3,700 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 400 mm Cross Slide, X-Axis: -Linear Drive -Drive Momentum: 2,150 Nm -Infeed Speed: 60 m/min -Theoretical Infeed: 200 m/min -Drive Length, Maximum: 1050 mm Swiveling Axis, W-Axis: -AC-Servo Drive: 10,000 1/min -Setable Gear Transmission: i=5000:1 -Swiveling Angle: -90 Degrees / +16 Degrees Workpiece Spindle, C-Axis: -Direct Drive, Maximum RPM: 7,000 1/min -Drive Power: 30 kW -Drive Torque: 112 Nm -Digital Measuring System Tool Spindle, B-Axis: -Direct Drive (hollow spindle drive), Maximum RPM: 2000 1/min -Drive Power: 30 kW -Drive Torque: 150 Nm -Digital Measuring System

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Bwsdjrualpepfx Afpsh Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: used, Make: PRÄWEMA, Model: 205HS2-2 / Synchrofine, Year of manufacture: 2008, Machine no.: 077238, Control unit, Manufacturer: Rexroth Indramat, Type: System 200 BTV20, including handheld operation terminal, Workpiece diameter: Ø 95mm, Maximum workpiece length: 59mm, Maximum spindle speed C-axis (workpiece spindle): 6,000 rpm / 7,000 rpm, B-axis (tool spindle): 2,000 rpm, Maximum feed rates Z/X: 60 m/min, Honing head ZNG-No.: 416101804-8, Year: 2008, Serial no.: 221, Machine bed granite, Manufacturer: Eckbert Reitz, Type: HFSL204HS2, Year: 2008, Workpiece automation, Surface finish inspection unit, Oil drip tray, Pump, Manufacturer: Brinkmann, Type: TH160/350-001, Operating hours as of 18.11.25: 69,518 Bodpjx Ahc Nofx Afpjwh +++ Attention: This item is part of an online clearance sale! +++

Condition: used, Year of construction: 2004, workpiece diameter 125 mm module 4 control SIEMENS SINUMERIK travel -x axis 105 mm travel -y axis 40 mm travel -z axis 500 mm workpiece diameter 17 - 39,5 mm workpiece height 6 - 15 mm Bedpsx Szm Asfx Afpjwh Gear Honing Machine | GLEASON-HURTH - ZH 125 The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZH125 | ZH-125

Condition: used, Year of construction: 2005, Technical details: workpiece diameter: 63,5 mm centre distance: 350 mm honing length max.: mm total power requirement: kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,70x2,x2,60 m Technical data G0504 working space Length of the clamping surface mm 1550 Number of T-slots mm 2 Width of the T-slots mm 18 Distance between T-slots mm 180 Center height (tailstocks) mm 350 Swivel range of the fine wheel head (U-axis) degrees Center distance - tailstock / fine wheel min./max. mm 120/225 Input resolution (all NC axes) mm / degrees Delivery slide Movement range (= Z-axis travel) mm 105 Input resolution mm tool Outside diameter min./max. mm 225/275 Hole diameter mm 160 Width mm 60 workpiece Outside diameter min./max. mm 40-150 Module min./max. mm 1.25-4.0 Tooth width max. Mm 45 weight Weight of the machine approx. Kg 5500 Operating fluid requirements Cooling lubricant recommendation, see chap. 8th Hydraulic fluid HLP D 46 approx. Itr 100 Speeds and feeds Tool speed (continuously adjustable) max. 1 / min 2000 Feed rates Rapid traverse / feed Z direction up to m / min 2 X direction up to m / min 2 U-direction up to m / min 2 V-direction up to m / min 2 C3 direction ree / sec 12 Electrical equipment Operating voltage V 400 Control voltage / lighting voltage V DC / AC 24/2 Frequency Hz 50 Power requirement approx. KVA 27 If the electrical installation has to be carried out according to customer specifications, only the information in the electrical documentation applies. Motor data Servo drives: Nm 1 / min Tool drive C1 27.0 00 Workpiece drive C2 27.0 00 X-axis 20.0 00 Z-axis 20.0 00 U-axis 6.0 00 Vertical portal (V1 axis) 6.0 00 Portal horizontal (U1 axis) Gripper axis of rotation C3 5.0 00 Loading slide (X1 axis) 5.0 00 Three-phase motors: KW 1 / min Hydraulic motor 1.5 1410 Central lubrication 0.07 Coolant pump 4 2840 Hydraulic equipment Delivery rate Itr / min 21 System pressure bar 50 Clamping pressure for: headstock max. Bar 35 Clamping tailstock min./max. bar 20 Only available if required. Not all limit values ??can necessarily be reached at the same time. Bjdpfxewrh H Nj Afpswh If several maximum values ??come together in a processing task, performance restrictions must be expected! We reserve the right to make changes to the specified constructions, dimensions and weights *

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: G0504, workpiece diameter (max.): 63 mm, travel distance Z-axis: 105 mm, outer diameter: 275 mm, distance between centers: 350 mm, swivel angle A-axis (min.): -30 °, swivel angle A-axis (max.): 30 °, TECHNICAL DETAILS Workpiece diameter: 63.5 mm Center distance: 350 mm Clamping surface length: 1,550 mm Number of T-slots: 2 T-slot width: 18 mm T-slot spacing: 180 mm Center height (tailstocks): 350 mm Pivoting range of the fine-tuning head (U-axis): +30 / -30 ° Bwsdpfx Afjwmbmlspeh Tailstock/fine-tuning head center distance: min. 120 mm / max. 225 mm Input resolution (all NC axes): 0.001 mm / degree Control: SIEMENS 840D Feed slide Movement range (Z-axis travel): 105 mm Input resolution: 0.001 mm Tool Outer diameter: 225 - 275 mm Bore diameter: 160 mm Width: 60 mm Workpiece details Outer diameter: 40 - 150 mm Module: 1.25 - 4.0 mm Max. tooth width: 45 mm Speeds and feed rates Tool speed: max. 2,000 rpm Feed rate in Z direction: up to 2 m/min Feed rate in X direction: up to 2 m/min Feed rate in U direction: up to 2 m/min Feed rate in V direction: up to 2 m/min C3 direction: max. 12 °/s Servo drives Tool drive C1: 27.0 Nm at 3,000 rpm Workpiece drive C2: 27.0 Nm at 3,000 rpm X-axis: 20.0 Nm at 3,000 rpm Z-axis: 20.0 Nm at 3,000 rpm U-axis: 6.0 Nm at 3,000 rpm Vertical gantry (V1 axis): 6.0 Nm at 3,000 rpm Gripper rotation axis C3: 5.0 Nm at 3,000 rpm Loading slide (X1 axis): 5.0 Nm at 3,000 rpm Three-phase motors Hydraulic motor: 1.5 kW at 1,410 rpm Central lubrication: 0.07 kW at 2,700 rpm Coolant pump: 4 kW at 2,840 rpm Hydraulic equipment Flow rate: 21 l/min System pressure: 50 bar Headstock clamping pressure: max. 35 bar Tailstock clamping pressure: min. 20 bar / max. 35 bar MACHINE DETAILS Weight: 5,500 kg Space required: 2,700 x 2,300 x 2,600 mm Operating fluids Hydraulic fluid: HLP D 46 Hydraulic capacity: 100 l Electrical system Operating voltage: 400 V Control voltage: 24 V DC Lighting voltage: 230 V AC Frequency: 50 Hz Power requirement: approx. 27 kVA EQUIPMENT - Central lubrication system - Coolant pump - Capacitive distance system - Automatic workpiece clamping - Precision wheel head with U-axis - Machine with full hydraulic equipment - Dialog-guided operator terminal

Condition: used, Year of construction: 1996, workpiece diameter 240 mm centre distance 0 mm honing length max. 500 mm max. module 5 total power requirement 12 kW weight of the machine ca. 5000 kg Bwjdpfx Aot Hwvmsfpsh dimensions of the machine ca. m

Condition: used, Year of construction: 1983, workpiece diameter 250 mm centre distance 0 mm honing length max. mm max. module 5 Gear Ø, min./max. 10 / 250 mm Module range 1 - 5 Length of teeth / max. table stroke 500 mm Height of centres of tailstocks 220 mm Max. weight of workpiece 50 / 100 kg Honing head swivelling +/- 35 ° Speeds of honing tool 20 - 500 rpm Size of honing tool, Ø x width 300 x 40 mm Workpiece speeds 500 - 3,000 rpm Total adjustment of cross slide 270 mm Bjdpet Hwzpjfx Afpswh Rapid traverse of cross slide 50 mm Infeed travel of cross slide, mechanical 1 - 8 mm/Ø Roughing / finishing infeed 1 - 29 / 0.2 - 2.8 mm/sec Table speeds, hydraulic 0 - 6 m/min Total electrical load 5.5 kW - 380 V - 50 Hz Weight 3,200 kg Accessories / Special Features * Working parameters can be preset using counters and control units. Automatic working process with workpiece counter. * All roughing and finishing infeeds can be adjusted by a decade switch; as well as by table reverse times and fast infeeds with preset times (1sec = Ø 0.04 mm), set on a potentiometer. Ampere display, etc. * Convex honing and conical honing are possible via templates. Asymmetric honing is also possible if the workpiece is prepared appropriately (i.e. pre-shaped). * Separate honing oil unit with magnetic separator and fine filter. * Mechanical tailstocks for manual loading. * Oil mist separator. * Sliding doors with foot switch. * Separate hydraulic unit. Condition : Good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. We have a large selection of gear machines available. Please let us know your requirements.

Year of construction: 1981, condition: good (used), Manufacturer: National Broach Type: GHC 12" Year of manufacture: 1981 Bedpfxehad Avo Afpjwh workpieceØ max.: 355mm pitch circleØ min/max: 100-152mm tooth width max.: 63,5mm Modu min/max.: 1,25-6,35mm weight: 3,4t Operation: honing internal teeth

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, grinding wheel diameter: 200 mm, workpiece length (max.): 200 mm, TECHNICAL DETAILS Grinding wheel diameter: 100–200 mm Maximum workpiece length: 200 mm MACHINE DETAILS Control: Siemens 840D or equivalent CNC axes: 3–5 axes Drive power: 5–10 kW Coolant tank: 100–200 litres EQUIPMENT Coolant filtration system Universal applicability for different tool types and geometries High flexibility through CNC programming and adaptable clamping devices Process reliability thanks to integrated cooling and filtration system Bsdpfx Aeya Dy Hefpewh Easy maintenance due to modular design and central supply units

Condition: good (used), Year of construction: 2007, max. wheel diameter 500 mm gear width 200-400 mm module 12 turning speeds 0-3250 U/min bracke pressure bis max. 95 Nm inner taper Konus #39 Control Fanuc 16 total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Bjdpfx Aevr Hf Eefpswh Nm.

Condition: used, Year of construction: 2011, machine/vehicle number: 25621, workpiece diameter (max.): 360 mm, Equipped with: Gear Spindle Runout: -Radial (Bore): .00005 -Axial (Face): .00005 Pinion Spindle Runout: -Radial (Bore): .00005 Axial (Face): .00005 Bwodpfxjxdfane Afpjh Axis Repeatability: -X: .0001 -Y: .0001 -Z: .0001 Axis Lost Motion: -X: .00005 -Y: .00005 -Z: .00005 Fanuc 160I MB Control Base Work Holding Draw Bars Automatic Doors Spindle Chiller Transformer Hydraulic System Festo Pneumatics Automation Interface Available SPECIFICATIONS: Maximum Gear Outside Diameter: 360 mm (14.2") Maximum Pinion Outside Diameter: 340 mm (13.4") Maximum Pinion Drive Speed: 3000 rpm Maximum Gear Drive Speed: 1500 rpm Offset Vertical 150 mm ( 5.9") Pinion Cone Range: (90) (135-350) (70) (146-438)* (110) (51-343)* Gear Cone Range: (90) (65-280) (70) (78-306)* (110) (56-284)* Standard Testing Torque Load 2 to 90 Nm (1.5 to 66 ft-lb). Parallel Axis - face-to-face 147 - 362 - Center Distance -7 - 250 Pinion Spindle Bore 39T - Diameter 99.2 mm (3.9") - Depth 419 mm (16.5") Gear Spindle Bore 39T - Diameter 99.2 mm (3.9") - Depth 250 mm (9.8") Floor Space (width & length) 2100 x 2550 mm (82.7 x 100.4") Height (to top of stack light) 2750 mm (108.3") Weight (base machine) 9100 Kg (20062 lbs)

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Bedpfx Ajrtrzdefpswh Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h total power requirement 45 kW weight of the machine ca. 7 t dimensions of the machine ca. 4x3x2,5 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Bsdsv Ehbbopfx Afpjwh Weight of the machine approx. 7,000 kg with robot cell

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the Bwodpfxew N S E Aj Afpsh cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: good (used), Year of construction: 2004, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the Bwjdpfx Aeul Efmsfpeh sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 Bsdpfjxc E H Ssx Afpswh *

Condition: used, Year of construction: 2000, honing diameter 80 / 152 mm stroke 210 mm throat 210 mm total power requirement 4,1 kVA weight of the machine ca. 1,1 t dimensions of the machine ca. 1,22 x 0,87 x 2,44 m Kennametal Extrude Hone Machine , Model 77C, Year 2000 Abrasive Flow Machining for pressure flow lapping, or flow grinding of mech. parts. Bjdpfjx Dxxdjx Afpewh Polishing and deburring or surface modifications of complex components are carried out by means of a viscous abrasive (pressure flow lapping medium) and pressure.

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm gear width 425 mm table hole 125 mm clamping table 550 mm max. module 10 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 22,5 kVa weight of the machine ca. 8,2 t Machine equipment: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport --> Working range Largest module to be milled (in steel 600 N/mm²): 10 mm Bsdpfx Afow A Am Sjpswh --> Straight gear teeth: --> Largest workpiece diameter: 630 mm --> Largest axial slide travel (Z-axis): 425 mm --> Smallest number of teeth to be milled: 8 --> Dimensions Diameter of workpiece table: 550 mm --> Diameter of table bore: 125 mm --> Diameter of workpiece mandrel: 36 mm --> Largest milling cutter that can be clamped: --> Diameter: 192 mm --> Width: 220 mm --> Diameter of milling cutter mandrels: 32 mm --> Centre distance between milling cutter and workpiece: --> Maximum distance: 425 mm --> Minimum distance: 50 mm --> Drive taper for cutter mandrels: Morse taper 5 --> Maximum cutter displacement: 200 mm --> Speeds and feeds Cutter speeds: 45 - 280 rpm --> Axial feed (Z axis): 0.40 - 6.30 mm/rev --> Radial feed (X axis): 0.10 - 1.60 mm/rev --> Tangential feed (Y axis): 0.14 - 2.24 mm/rev Translated with (free version)

Condition: excellent (used), honing diameter 1,5 - 165 mm stroke 80 - 160 mm spindle turning speed range 200 - 2500 U/min stroke speed - under load 80 - 310 Hub/min total power requirement 0,9 kW weight of the machine ca. 0,6 t Bwodpfswva Rnsx Afpsh dimensions of the machine ca. 1,2 x 1,0 x 1,6 m

Condition: ready for operation (used), Year of construction: 2006, max. wheel diameter 150 mm gear width 100 mm Bedpsygm Rusfx Afpewh max. module 3 min. module 1 ical angle +/- 45 ° slide stroke 100 mm number of teeth 5 - 150 clamping length max. 350 mm control Siemens 840 D rated capacity 38 kVA dimensions of machine 2,45 x 2 x H = 2,5 m weight of the machine ca. 8 t

Year of construction: 1963, condition: used, max. wheel diameter 2000 mm gear width 0 mm max. module 0 Weight ca 700 kg dimensions of the machine ca. 2x1,2x1,5 m Bwjdpfxjd Ngrpo Afpjh uncomplete machine body with drive motor. drive unit fully functional. Without grinding unit.

Condition: used, max. wheel diameter 0 mm gear width 0 mm max. module 40 min. module 1 weight of the machine ca. 0,05 t dimensions of the machine ca. 0,5x0,3x0,3 m Bwjdpsvn Unyjfx Afpjh pitch and run-out tester unit for gear measuring machines.

Condition: excellent (used), Year of construction: 2009, Machine-Details: Stock-No. 1022-2352 Type of machine Gear Hobbing Machine - Horizontal Make MONNIER & ZAHNER Type KOEPFER MZ 120 Year of manufacture 2009 Type of control CNC Storage location Monheim (Germany) Country of origin Switzerland Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details: max. wheel diameter 2-45 mm gear width 250 mm max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information: The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical Bjdpfx Afoydc Hajpswh position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, CNC Gear Hobbing Machine Horizontal . no tailstock, just for chuck parts . max. gear diameter: 90 mm . max gear width (b): 50 mm Bwodpfx Aoqaf U Tefpoh . max module: 3
