Used Vertical gear hobbing machines - gear diameter 1000-1999mm for sale (28)

Condition: used, Year of construction: 2004, max. wheel diameter 200 mm gear width 250 mm max. module 5 min. module 0,1 milling tool taper HSK 80 B spindle turning speed range 0 - 1000 U/min control 840 D total power requirement 15 kW weight of the machine ca. 10,2 t dimensions of the machine ca. 4.455 x 3.160 x 3.335 m Gleason-PFAIJTER CNC gear milling machine GP200 for gear cutting of shaft and wheel-shaped workpieces with all rollable profiles and shapes that regularly occur on the cylindrical workpiece circumference. Optionally for wet milling with cooling lubricants (basic version) and/or dry milling (option). Working area and technical data: Max. workpiece diameter that can be cut .. 200 mm Machine nominal module ..... approx. 5 mm (Guide value depending on the respective machining task and the specific machine equipment.) Cebov Eha Do Hn Tq Ejgt Smallest/largest distance between milling cutter and workpiece axis ... 15/215 mm The travel paths and angles mentioned above can be restricted if necessary depending on the workpiece and tool dimensions, the gear data and the workpiece-dependent machine equipment Accessories 1 compressed air maintenance unit (make FESTO) 1 signal light (3-color) to display machine statuses 1 work area light 1 control cabinet light 1 set of tools for machine operation and maintenance 2 operating instructions 2 programming instructions 2 maintenance instructions 1 set of electrical documents in German or English

Condition: excellent (used), Year of construction: 1976, Pfauter vertical gear hobbing machine P400 Gear milling machine Manufacturer: Pfauter Germany Model: P 400 Year of manufacture: 1976 Control type: conventional Wheel diameter - max.: 400 mm Wheel width: 290 mm Module - max.: 6 Module - min.: 0.5 Voltage: 220/380 V Frequency: 50 Hz Dimensions approx.: 2400 x 1650 x 2400 mm Total power requirement: 20kvA The machine is in a well-maintained original condition. Ceb Hnjvwcugj Tq Esgt The complete, detailed documentation is available. Inspections under power can be arranged at short notice. We are happy to answer any further questions you may have. Price, ex warehouse here plus VAT. Condition: good - ready for demonstration Delivery: ex warehouse - as seen Payment: net - after receipt of invoice Subject to prior sale, errors excepted. We ask for your order. Other machines and systems available from stock - please enquire. We look forward to hearing from you.

Condition: used, max. wheel diameter 1500 mm gear width 000 mm axial slide travel 600 mm distance - table - arm of counterstay 1482 mm distance between table/spindle 1067 mm milling spindle - taper 55 diameter of hob 350 mm width of hob 400 mm axis distance between spindles min. / max. 50 / 935 mm adjustment of milling-spindle 250 mm milling slide swivelling 15 / 120 Grad table diameter 1200 mm table hole 300 mm taper MK 6 turning speed - milling spindle 25 - 150 U/min feeds axial 1 - 1000 mm/min radial feed 1 - 1000 mm/min tangential feed 1 - 500 mm/min electrics - voltage/frequency 380 / 50 V/Hz control Sinumerik 3 total power requirement 100 kVA weight of the machine ca. 22 t dimensions of the machine ca. 10,3 x 7,4 x 5,3 m Cob Hov Saw Ien Tq Eogt Machine has only internal milling head.

Condition: excellent (used), Functionality: fully functional, We are selling this hobbing machine. Equipped, fully functional, can send a video of the machine via whatsapp. Cgjbev D U N Aj Hn Tq Est

Condition: excellent (used), Max. Wheel Dia: 1600 mm Min. wheel Dia: 800 mm Gear width: 560 mm Max. module: 16 Min. Module: 4 Table dia: 1350 mm Cgob Hnsv Igc No Tq Eet Table load cap: 7000 Kg Machine weight: ca. 18 Tonnes Machine with change gear, arbors, fixtures set Machine is in excellent condition

Condition: used, Year of construction: 1963, max. module 12 mm max. workpiece diameter 1200 mm workpiece width - max. 540 mm min. number of teeth 12 Work piece table diameter 1075 mm Workpiece table bore 200 mm speeds 29-174 U/min total power requirement 23 kW weight of the machine ca. 17,2 t dimensions of the machine ca. 5050 x 2940 x 2770 m Accessories/ equipment: Cgsb Hnsv Ey Rue Tq Est - change gears - Milling arbors - operation manual

Condition: good (used), Year of construction: 1984, max. wheel diameter 400 mm gear width 275 mm max. module 6 Cobov T Nqae Hn Tq Eogt weight of the machine ca. 5,5 t

Condition: good (used), Year of construction: 1981, Max. module 16 Min. module 4 Max. wheel diameter 1600 mm Mon. wheel diameter 800 mm Table load 700 kg Cgjb Hn Tqev Urtts Est Machine weight 19 t Dimensions L x W x H 4300 x 2000 x 3170

Condition: used, Year of construction: 2002, max. wheel diameter 1.200 mm gear width 000 mm max. module 16 tip circle diameter 270 mm cutter length max. 350 mm radial slide travel 650 mm tangential adjustment 300 mm axial slide travel 700 mm pivoting angle 45 Grad table diameter 1.200 mm table load capacity 150 kN feed x+y: 3 m/min feeds - axial 4.000 mm/min feeds x/z 3.000 mm/min Tools speed 33 - 330 U/min turning speed workpiece table 0 - 10 mm/U electrics - voltage/frequency 400 / 50 V/Hz Cgeb Hn Tqev Sawnj Eet connected load 80 kVA control Siemens 840 C weight of the machine ca. 18,8 t dimensions of the machine ca. 11,9 x 5,1 x 4,3 m

Condition: excellent (used), I am selling this machine, connected, can be tested. Max. workpiece diameter ..... 1600 mm Module ..... 16 - Power of the main electric motor ..... 12 kW Cgsb Hnev Nqpps Tq Eet Dimensions l x w x h ..... 4300 x 2000 x 3170 mm Machine weight ..... 18500 kg Can send a video of the machine, via whatsapp.

Condition: used, Gear hobbing machine Modul 3 x diameter 160 mm Cebewal A Re Hn Tq Esgt

Condition: used, max. wheel diameter 1800 mm gear width 725 mm Cgeb Hevyliren Tq Ejt max. module 5 Control Siemens 840D sl axial travel 725 mm turning speed range - stepless 44 - 440 U/min cutter diameter max. 240 mm cutter width - max. 300 mm table diameter 1500 mm boring diameter 350 mm weight of the machine ca. 27 t dimensions of the machine ca. 8,8 x 6,1 x 3,25 m Equipment / Accessories: - max. distance from clamping table to counterholder/to center of milling spindle: 1045 mm - milling spindle: - max. axis distance between milling spindle and clamping spindle with/without counterholder: 1200 mm - min. axis distance between milling spindle and clamping spindle with/without counterholder: 525 mm - quick cutter change device - chip extraction device - milling arbors - documentation

Condition: used, Year of construction: 1975, diameter of hob 130 mm cutter width - max. 160 mm adjustment of the milling spindle 115 mm milling slide swivelling 240 Grad feed: 2 table bore diameter 63 mm milling arbors 22;27;32 table diameter 250 mm dist. cutter spindle - workpiece spindle max. 210 mm dist. cutter spindle - workpiece spindle min. 10 mm min. number of teeth 6 milling width max. 245 mm working diameter max. 250 mm base area 625x1720 mm milling spindle turning speeds 1.) 96-320 U/min milling spindle turning speeds 2.) 120-400 U/min total power requirement 18,4 kW weight 3600 kg dimensions of the machine ca. 3,69x2,17x2,51 m max. module 6 Wheel diameter - max. 250 mm Module - max. 6 Table diameter 250 mm Table bore 63 mm Total power requirement 17 kW Machine weight approx. 3.6 t Dra8Mt Space requirement approx. 3.69 x 2.17 x 2.51 m Equipment/accessories: - Milling arbors Csbevz Ec Uj Hn Tq Eogt - Clamping device - Changing wheels - documentation

Condition: ready for operation (used), Gear hobbing machine horizontal Pfauter P160 With accessories Cob Hnjv Hulps Tq Eegt

Year of construction: 1989, Condition: good (used), piece diametre 1500MM max coupling 914MM poids 15 tonnes Cjb Hjfl Aaqjn Tq Eegt

Condition: used, Year of construction: 1993, max. wheel diameter 125 mm total power requirement 34 kW kW Cjb Hjtugkrjn Tq Ejgt weight of the machine ca. ca6.9 t t dimensions of the machine ca. ca. 3.3 x 2,1 x 2,5 m m

Condition: used, Year of construction: 1984, max. wheel diameter 1500 mm gear width 700 mm max. module 5 Control Liebherr LH90 smallest number of teeth to be hobbed 6 milling head: Motorfräskopf milling spindle speeds (infinitely variable) 44 - 440 U/min milling head -swivable +/- 45 ° table diameter 1100 mm max. table load 8000 kg total power requirement 66 kVA Equipment / Accessories: - chip extraction device - milling arbors - documentation Cgsbovvcgto Hn Tq Eet

Condition: used, Year of construction: 1989, max. wheel diameter 400 mm gear width 275 mm max. module 6 Overall size 300x330x245 cm weight of the machine ca. 5,5 t Specification: Max wheel diameter: 400 mm Min module: 1 Max module: 6 Table diameter: 370 mm Max wheel diameter: -With counterstay: 340 mm -Without counterstay: 400 mm Max axial offset: 275 mm Max tangential adjustment: 100 mm Tooth helical angle: 45 degrees Max cutter diameter: 145 mm Max hobbing length: 170 mm Hob turning speeds capacity: 63-180 U/min Feeds infinitely variable axial: 0,2-10 mm/U Feeds infinitely variable tangential: 0,1-5 mm/U Radial for spur gears: 0,1-4 mm/U Radial for worm gears: 0,025-1 mm/U Rapid traverse axial: 500 mm/min Rapid traverse tangential: 250 mm/min Cgebou A I Ele Hn Tq Est Radial for spur gears: 400 mm/U Radial for worm gears: 100 mm/U Motor power: 7.4 kW

Condition: used, Year of construction: 1976, min. wheel diameter 630 mm max. wheel diameter 710 mm max. module 10 gear width 400 mm milling spindle turning speed range: 50-400 U/min milling spindle turning speed range: 40-400 U/min weight of the machine ca. 9,2 t Overall size 338x272x225 cm Specification: Working range: Wheel diameter: -Max.: 710 mm -Min.: 630 mm Gear width: 400 mm Module: -Max.: 10 -Min.: 1 Max. axial feeding travel: 400 mm Max. tangential feeding travel (hob shift): 200 mm Max. helix angle: 45 degrees Min. number of teeth hobbed: 10 Min. number of teeth hobbed with indexing drive: 5 Cgob Hn Tqou Elq Rj Eot Dimensions: Max. hob diameter: 200 mm Max. hob length: 250 mm Diameter of working table: 580 mm Diameter of hole in working table: -Max.: 250 mm -Min.: 100 mm Depth of hole in working table: -Max.: 300 mm -Min.: 45 mm Distance center of hob to working table surface: -Min.: 175 mm -Max.: 575 mm Distance center of hob to center of working table -Min.: 50 mm -Max.: 505 mm Driving taper for hob arbor (step taper): 50 mm Capacity: Hob speeds of universal hobbing head steeped: 50-400 rpm Milling spindle speeds (infinitely variable): 40-400 rpm Axial feeds (infinitely variable): 0,2-10 mm/rev Tangenial feeds (infinitely variable): 0,1-5 mm/rev Radial feeds (infinitely variable): 0,1-1 mm/rev Main motor: Power capacity: 29 kW 3-phase alternate current: 15 kW Direct current: 10 kW Connected load: 35 kVA

Condition: good (used), max. wheel diameter 630 mm gear width 375 mm max. module 10 clamping table 550 mm table hole 125 mm milling spindle speeds infinitely variable 62 - 390 U/min taper MORSE 5 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm Cgob Hnjua It Us Tq Eet main drive motor 7,5 kW total power requirement 21 kVa weight of the machine ca. 8,2 t Equipment of the machine: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport - Year of construction approx. 1976

Condition: good (used), Year of construction: 1975, max. wheel diameter 400 mm gear width 290 mm max. module 6 min. module 0,5 weight 4,6 t total power requirement 17 kW Working area: 1. largest module to be milled 6 mm 2. straight toothing a) Largest workpiece Ø 400 mm b) Largest length of toothing 290 mm 3. smallest number of teeth to be milled for 1-speed sub-gear 6 with 2-speed gearbox 3 Dimensions: 1. Ø of the workpiece table 400 mm 2. Ø of the table dimensions 80 mm 3. diameter of the workpiece mandrel 36 mm 4. largest clampable milling cutter: Ø diameter 160 mm Length 160 mm 5. diameter of the milling cutter arbour centre distance between milling cutter and workpiece a) Largest distance 300 mm b) Smallest distance 30 mm 7. drive cone for milling arbors MK 4 Csb Hn Tqeugawxe Ejgt 8. maximum milling cutter displacement: a) Tangential milling 120 mm b) Shifting 100 mm

Condition: good (used), Year of construction: 1973, max. wheel diameter 400 mm gear width 290 mm max. module 6 min. module 0,5 weight 4,6 t milling arbors 22 ; 32 mm total power requirement 17 kW Working area: Cgjb Hsvylhuon Tq Est 1. largest module to be milled 6 mm 2. straight toothing a) Largest workpiece Ø 400 mm b) Largest length of toothing 290 mm 3. smallest number of teeth to be milled for 1-speed sub-gear 6 with 2-speed gearbox 3 Dimensions: 1. Ø of the workpiece table 400 mm 2. Ø of the table dimensions 80 mm 3. diameter of the workpiece mandrel 36 mm 4. largest clampable milling cutter: Ø diameter 160 mm Length 160 mm 5. diameter of the milling cutter arbour 32; 40 6. centre distance between milling cutter and workpiece a) Largest distance 300 mm b) Smallest distance 30 mm 7. drive cone for milling arbors MK 4 8. maximum milling cutter displacement: a) Tangential milling 120 mm b) Shifting 100 mm

Condition: used, max. wheel diameter 900 mm gear width 370 mm max. module 10 Cjbou A I Duj Hn Tq Eegt min. module 1 total power requirement 20 kW weight of the machine ca. 9 t Year of construction: approx. 1981 Accessories: - Universal milling head, tangential milling head, - change wheels - 2 cutting units, - little used

Condition: good (used), Year of construction: 1975, max. wheel diameter 400 mm gear width 290 mm max. module 6 Cjb Hnoul Em Rj Tq Ejgt min. module 0,5 weight 4,6 t voltage 220/380 V frequency 50 Hz dimensions 3010 x 1800 x 2200 mm total power requirement 17 kW Working area: 1. largest module to be milled 6 mm 2. straight toothing a) Largest workpiece Ø 400 mm b) Largest length of toothing 290 mm 3. smallest number of teeth to be milled for 1-speed sub-gear 6 with 2-speed gearbox 3 Dimensions: 1. Ø of the workpiece table 400 mm 2. Ø of the table dimensions 80 mm 3. diameter of the workpiece mandrel 36 mm 4. largest clampable milling cutter: Ø diameter 160 mm Length 160 mm 5. diameter of the milling cutter arbour 32; 40 6. centre distance between milling cutter and workpiece a) Largest distance 300 mm b) Smallest distance 30 mm 7. drive cone for milling arbors MK 4 8. maximum milling cutter displacement: a) Tangential milling 120 mm b) Shifting 100 mm Accessories: Interchangeable wheels

Condition: good (used), Year of construction: 1973, max. wheel diameter 400 mm gear width 290 mm max. module 6 Ceb Hjtycl Uon Tq Esgt min. module 0,5 weight 4,6 t voltage 220/380 V frequency 50 Hz dimensions 3010 x 1800 x 2200 mm total power requirement 17 kW Working area: 1. largest module to be milled 6 mm 2. straight toothing a) Largest workpiece Ø 400 mm b) Largest length of toothing 290 mm 3. smallest number of teeth to be milled for 1-speed sub-gear 6 with 2-speed gearbox 3 Dimensions: 1. Ø of the workpiece table 400 mm 2. Ø of the table dimensions 80 mm 3. diameter of the workpiece mandrel 36 mm 4. largest clampable milling cutter: Ø diameter 160 mm Length 160 mm 5. diameter of the milling cutter arbour 32; 40 6. centre distance between milling cutter and workpiece a) Largest distance 300 mm b) Smallest distance 30 mm 7. drive cone for milling arbors MK 4 8. maximum milling cutter displacement: a) Tangential milling 120 mm b) Shifting 100 mm
